AIS P-INSTRUCTMGP User manual

© 2012, AIS
Phone: [phone] Fax: [phone] Web: www.ais-inc.com
Catalog Product Date
All Matrix Gallery Panel Install (P-INSTRUCTMGP)
Details
06/01/12 1 of 2
Matrix Gallery Panels mount to Matrix frames in place of wing panels for structural support. Gallery panels are
shipped ready to install with the required glides and hex head bolts included.
Product and Parts
To the right is a visual guide to the parts used in the
gallery panel installation.
1. Matrix Frame (stand alone product)
2. Hex Head Bolts (2.25”)
3. Gallery Panel
Installation
Align gallery panel with frame and use hex head bolts to
secure the gallery panel to the frame.
1/4-20 Hex Head Bolt (2.25”)
2.25”
1
2
3
2
2
2
Align gallery panel with frame.
Use hex head bolts to
secure gallery panel to
frame.

© 2012, AIS
Phone: [phone] Fax: [phone] Web: www.ais-inc.com
Catalog Product Date
All Matrix Gallery Panel Install (P-INSTRUCTMGP) 06/01/12 2 of 2
Details
Matrix Gallery Panels mount to Matrix frames in place of wing panels for structural support. Gallery panels are
shipped ready to install with the required glides and hex head bolts included.
Product and Parts
To the right is a visual guide to the parts used in the
gallery panel installation.
1. Matrix Frame (stand alone product)
2. Hex Head Bolts (5.25”)
3. Gallery Panel
Installation
Align gallery panel with frame and use hex head bolts to
secure the gallery panel to the frame.
12
3
2
2
2
1
1/4-20 Hex Head Bolt (5.25”)
5.25”
Align gallery panel with
frame.
Use hex head bolts to
secure gallery panel to
frame.
