AIS LSOFTMOD User manual

ASSEMBLY INSTRUCTIONS APPLY TO MODELS:
LSOFTMOD
LSOFTMOD2
LSOFTMODRH
LSOFTMODLH
LSOFTCRNR90
LSOFTCRNR45
LSOFTCRNR
LSOFTPL
LSOFTPL2
-
OND
- - -
REV
DRAWING NUMBER
COLLECTION:
DATE
CHECKED BY DRAWN BY
2/23/2024
LSOFTMOD-GAI
SOFT GANGING ASSEMBLY INSTRUCTIONS
1:12
SCALE
1 OF 3
www.ais-inc.com

STEP 1 = CHAIR
Carefully unpackage
chair and lay flat on a
padded surface as shown
in picture above
STEP 2 = LEGS
Attach 4 legs to the
underside of the base.
Than carefully lift chair
upright with 2 people as
to not break the legs
STEP 3 = CHAIR CONNECTION
Join both chairs side by
side, than loosen both
knobs on brackets
STEP 4 = CHAIR CONNECTION CONT'D
Rotate both brackets 90 degress
over the adjoing chair until it lines
up with exposed hole, than using
2 people, push chairs tight
together while 1 person secures
all 4 knobs on the brackets
-
OND
- - -
REV
DRAWING NUMBER
COLLECTION:
DATE
CHECKED BY DRAWN BY
2/23/2024
LSOFTMOD-GAI
SOFT ASSEMBLY GANGING INSTRUCTIONS
1:20
SCALE
2 OF 3
PART NUMBER
-
www.ais-inc.com

A
DETAIL
A
SCALE
1 : 8
7/8" Washer
Hex Head Bolt
CASTER OPTION ASSEMBLY INSTRUCTIONS
STEP 1 = CHAIR
Carefully unpackage
chair and lay flat on a
padded surface as shown
in picture
STEP 2 = CASTERS
Align holes in caster with
the holes on the underside
of the base
STEP 3 = CONNECTION
Secure using (4x) 7/8"
Washer and (4x) 5/16-18
1-1/4" LG Hex Head Bolts
STEP 4 = CONNECTION CONT'D
Using 2 people, carefully
lift chair upright
STEP 5 = FINISHED
Proceed to STEP 3 on
page 2 Tools Required: 1/2" Wrench
-
OND
- - -
REV
DRAWING NUMBER
COLLECTION:
DATE
CHECKED BY DRAWN BY
2/23/2024
LSOFTMOD-GAI
SOFT GANGING ASSEMBLY INSTRUCTIONS CONT'D
1:12
SCALE
3 OF 3
PART NUMBER
-
www.ais-inc.com
