S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

CT-X409

• TYPE:

S/M Code No. 09–992–326–60A

STEREO CAR CASSETTE

RECEIVER

HJB,HJW(207)HJB,HJW(207)

YUST(409/419),YZ1ST(309),

YZST(319),YJST(459)

• BASIC TAPE MECHANISM:CDS-36SCH-94

CT-X459

CT-X319

CT-X419

CT-X309

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

41US ...................XX..................................A...................

40US ...................XX...................................B..................

30Z1 ...................XX....................................C.................

31ZS ...................XX.....................................D................

45JS ...................XX......................................E...............

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 706 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 704 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 703 87-010-198-080 CAP, CHIP 0.022 ABCDE...............

C 702 87-010-263-010 CAP, ELECT 100-10V ABCDE...............

C 705 87-010-314-080 C-CAP,S 22P-50V ABCDE...............

C 708 87-010-314-080 C-CAP,S 22P-50V ABCDE...............

C 707 87-010-314-080 C-CAP,S 22P-50V ABCDE...............

C 701 87-010-380-010 CAP,E 47-16 SME ABCDE...............

C 709 87-012-358-080 C-CAP,S 0.47-10 F Z ABCDE...............

C 710 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 711 87-010-404-010 CONDENSER 4.7-50 ABCDE...............

C 712 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............

D 701 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............

D 702 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............

IC 701 8Z-KTG-621-010 C-IC,TC9323F-007 ABCDE...............

L 702 87-003-097-080 COIL,1UH ABCDE...............

L 701 87-003-149-080 COIL,47UH ABCDE...............

Q 702 87-A30-282-040 C-TR,DTA114TKA ABCDE...............

Q 701 87-A30-287-040 C-TR,DTC114TKA ABCDE...............

S 751 87-A91-152-010 SW,SL 1-1-2 SSSS212-11-A ABCDE...............

X 701 87-A70-175-010 VIB,XTAL 4.5MHZ AT-49 ABCDE...............

C 307 87-010-198-080 CAP, CHIP 0.022 ABCDE...............

C 308 87-010-198-080 CAP, CHIP 0.022 ABCDE...............

C 305 87-010-263-010 CAP, ELECT 100-10V ABCDE...............

C 306 87-010-263-010 CAP, ELECT 100-10V ABCDE...............

C 303 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 304 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 309 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 302 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............

C 301 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............

C 311 87-010-263-010 CAP, ELECT 100-10V ABCDE...............

C 310 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

CN 301 87-009-031-010 CONNECTOR, 3P ABCDE...............

CN 302 87-099-408-010 CONN,8P EH V WHT ABCDE...............

CNA 302 8Z-KTG-652-010 CONN ASSY,8P MOTOR ABCDE...............

IC 301 87-A21-191-010 IC,KIA6225S ABCDE...............

ANT 101 8Z-KT1-614-010 ANT,AW-002 ABCDE...............

C 102 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 106 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 109 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 105 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............

C 101 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............

C 103 87-010-380-010 CAP,E 47-16 SME ABCDE...............

C 104 87-010-380-010 CAP,E 47-16 SME ABCDE...............

C 118 87-010-182-080 C-CAP,S 2200P-50 B ..CDE...............

C 117 87-010-182-080 C-CAP,S 2200P-50 B ..CDE...............

C 118 87-010-197-080 CAP, CHIP 0.01 DM AB..................

C 110 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 117 87-010-197-080 CAP, CHIP 0.01 DM AB..................

C 112 87-010-198-080 CAP, CHIP 0.022 ABCDE...............

C 115 87-010-213-080 C-CAP,S 0.015-50 B ABCDE...............

C 116 87-010-213-080 C-CAP,S 0.015-50 B ABCDE...............

C 114 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 113 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

ELECTRICAL MAIN PARTS LIST - 2

C 111 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 119 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 124 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 122 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 121 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 123 87-010-380-010 CAP,E 47-16 SME ABCDE...............

C 120 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

D 101 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............

D 102 87-020-465-080 DIODE,1SS133 (110MA) ABCDE...............

L 101 87-003-143-080 COIL 4.7 UH ABCDE...............

L 102 8Z-KT1-619-010 COIL,68MH K7-D ABCDE...............

Q 104 87-A30-287-040 C-TR,DTC114TKA ABCDE...............

Q 101 87-A30-287-040 C-TR,DTC114TKA ABCDE...............

Q 103 87-A30-289-040 C-TR,2SA1037AK(R) ABCDE...............

Q 109 87-A30-289-040 C-TR,2SA1037AK(R) ABCDE...............

Q 102 89-324-122-080 TR,2SC2412K ABCDE...............

Q 108 89-324-122-080 TR,2SC2412K ABCDE...............

Q 107 89-324-122-080 TR,2SC2412K ABCDE...............

Q 110 87-A30-287-040 C-TR,DTC114TKA ABCDE...............

TU 101 8Z-KT1-631-010 TU UNIT, FAE347-A02 ABCDE...............

C 408 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCDE...............

C 407 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCDE...............

C 402 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 409 87-010-198-080 CAP, CHIP 0.022 ABCDE...............

C 404 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 403 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 401 87-010-380-010 CAP,E 47-16 SME ABCDE...............

C 405 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 406 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 410 87-010-198-080 CAP, CHIP 0.022 ABCDE...............

C 418 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 411 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 412 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 417 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 419 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 416 87-A11-177-080 C-CAP,S 0.15-16 K B ABCDE...............

C 415 87-A11-177-080 C-CAP,S 0.15-16 K B ABCDE...............

C 413 87-A11-177-080 C-CAP,S 0.15-16 K B ABCDE...............

C 414 87-A11-177-080 C-CAP,S 0.15-16 K B ABCDE...............

C 423 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 424 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 422 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 421 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

C 420 87-010-401-010 CAP, ELECT 1-50V ABCDE...............

IC 401 8Z-KT1-622-010 C-IC,LC75374E ABCDE...............

C 605 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 606 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 609 87-012-157-080 C-CAP,S 330P-50 CH ABCDE...............

C 601 87-016-669-080 C-CAP,S 0.1-25 K B ABCDE...............

C 604 87-016-669-080 C-CAP,S 0.1-25 K B ABCDE...............

C 602 87-016-669-080 C-CAP,S 0.1-25 K B ABCDE...............

C 603 87-016-669-080 C-CAP,S 0.1-25 K B ABCDE...............

C 607 87-A11-179-010 CAP,E 10-16-105 D5*L11 KMF ..CDE...............

C 607 87-A11-243-010 CAP,E 10-16 M 105 VZ AB..................

C 608 8Z-KT1-633-090 CAP,E 3300U-16 PW ABCDE...............

C 612 87-012-157-080 C-CAP,S 330P-50 CH ABCDE...............

C 610 87-012-157-080 C-CAP,S 330P-50 CH ABCDE...............

C 611 87-012-157-080 C-CAP,S 330P-50 CH ABCDE...............

IC 601 8Z-KTG-622-010 IC,TA8252H ABCDE...............

C 207 87-010-112-010 CAP,ELECT 100-16V ABCDE...............

C 201 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 202 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 204 87-010-198-080 CAP, CHIP 0.022 ABCDE...............

C 209 87-010-248-010 CAP, ELECT 220-10V ABCDE...............

ELECTRICAL MAIN PARTS LIST - 3

C 205 87-010-263-010 CAP, ELECT 100-10V ABCDE...............

C 206 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............

C 203 87-010-322-080 C-CAP,S 100P-50 CH ABCDE...............

C 208 87-010-380-010 CAP,E 47-16 SME ABCDE...............

C 210 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 211 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE...............

C 212 87-010-378-010 CAP, ELECT 10-16SME ABCDE...............

C 213 87-010-380-010 CAP,E 47-16 SME ABCDE...............

C 251 87-010-198-080 CAP, CHIP 0.022 ABCDE...............

CN 201 8Z-KT1-611-010 CONN,16P CAM-B51 ABCDE...............

D 204 87-001-783-080 DIODE,1N4002 ABCDE...............

D 201 87-001-783-080 DIODE,1N4002 ABCDE...............

D 203 87-001-783-080 DIODE,1N4002 ABCDE...............

D 202 87-001-783-080 DIODE,1N4002 ABCDE...............

D 205 87-017-932-080 ZENER,MTJ6.2B ABCDE...............

D 206 87-070-334-080 ZENER,MTZJ10B ABCDE...............

D 251 87-070-136-080 ZENER,MTZJ5.1B ABCDE...............

F 201 8Z-KT1-617-010 FUSE,10A 32V ABCDE...............

IC 201 88-KTD-604-010 IC,BA09T ABCDE...............

IC 251 88-KT1-606-080 IC,PST994D ABCDE...............

L 201 8Z-KT1-615-010 FLTR,AMORPHOUS -CHOKE ABCDE...............

Q 203 87-A30-168-010 TR,2SB1566F ABCDE...............

Q 202 87-A30-168-010 TR,2SB1566F ABCDE...............

Q 204 87-A30-287-040 C-TR,DTC114TKA ABCDE...............

Q 205 87-A30-287-040 C-TR,DTC114TKA ABCDE...............

Q 207 87-A30-287-040 C-TR,DTC114TKA ABCDE...............

Q 208 87-A30-294-040 C-TR,DTB123YK ABCDE...............

Q 206 89-423-953-010 TR,2SD2395F ABCDE...............

Q 201 8Z-KTH-626-080 TR,KTC3203Y ABCDE...............

C 801 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

D 805 87-017-932-080 ZENER,MTJ6.2B ABCDE...............

D 802 87-017-932-080 ZENER,MTJ6.2B ABCDE...............

D 803 87-017-932-080 ZENER,MTJ6.2B ABCDE...............

D 801 87-017-932-080 ZENER,MTJ6.2B ABCDE...............

D 804 87-017-932-080 ZENER,MTJ6.2B ABCDE...............

D 806 87-027-262-010 LEDE,TLR-124(RED) ABCDE...............

L 801 87-003-149-080 COIL,47UH ABCDE...............

Q 801 87-A30-287-040 C-TR,DTC114TKA ABCDE...............

C 451 87-010-401-040 CAP,E 1-50 SME ABCDE...............

C 452 87-010-401-040 CAP,E 1-50 SME ABCDE...............

C 508 87-010-175-080 CAP 560P ABCDE...............

C 505 87-010-175-080 CAP 560P .B..................

C 506 87-010-175-080 CAP 560P .B..................

C 507 87-010-175-080 CAP 560P ABCDE...............

C 501 87-010-378-040 CAP,E 10-16 .B..................

C 502 87-010-378-040 CAP,E 10-16 .B..................

C 503 87-010-378-040 CAP,E 10-16 ABCDE...............

C 504 87-010-378-040 CAP,E 10-16 ABCDE...............

J 501 88-KTA-604-010 JACK,PIN 4P V-TYPE A...................

J 501 88-KTA-605-010 JACK,PIN 2P V-TYPE .BCDE...............

Q 502 87-A30-281-040 C-TR,DTC363TK ABCDE...............

Q 503 87-A30-281-040 C-TR,DTC363TK ABCDE...............

Q 504 87-A30-281-040 C-TR,DTC363TK ABCDE...............

Q 501 87-A30-281-040 C-TR,DTC363TK ABCDE...............

C 905 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................

C 902 87-010-197-080 CAP, CHIP 0.01 DM ABCDE...............

C 904 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............

C 903 87-012-349-080 C-CAP,S 1000P-50 CH ABCDE...............

C 901 87-012-358-080 C-CAP,S 0.47-10 F Z ABCDE...............

D 905 87-020-585-080 CHIP-ZENER,02CZ6.2Y AB..................

D 903 87-020-585-080 CHIP-ZENER,02CZ6.2Y ABCDE...............

D 902 87-020-585-080 CHIP-ZENER,02CZ6.2Y ABCDE...............

D 904 87-020-585-080 CHIP-ZENER,02CZ6.2Y AB..................

D 901 87-020-585-080 CHIP-ZENER,02CZ6.2Y ABCDE...............

ELECTRICAL MAIN PARTS LIST - 4

IC 902 87-A90-951-010 RCR UNIT,SBX1971-52 AB..................

IC 901 88-KTD-602-010 C-IC,TC9297F ABCDE...............

J 901 87-A60-249-010 JACK,MOJ-B32 ABCDE...............

LCD 901 8Z-KTG-606-010 LCD,ZKT-16 ABCDE...............

PL 906 8Z-KT1-641-010 LAMP,T-3 ABCDE...............

PL 907 8Z-KT1-641-010 LAMP,T-3 ABCDE...............

PL 904 8Z-KT1-641-010 LAMP,T-3 ABCDE...............

PL 903 8Z-KT1-641-010 LAMP,T-3 ABCDE...............

PL 901 8Z-KT1-641-010 LAMP,T-3 ABCDE...............

PL 902 8Z-KT1-641-010 LAMP,T-3 ABCDE...............

PL 905 8Z-KT1-641-010 LAMP,T-3 ABCDE...............

S 907 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 901 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 904 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 909 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 903 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 905 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 906 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 902 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 908 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 916 87-A90-001-010 C-SW,TACT SKQMAL ABCDE...............

S 917 87-A90-001-010 C-SW,TACT SKQMAL ABCDE...............

S 918 87-A90-001-010 C-SW,TACT SKQMAL ABCDE...............

S 919 87-A90-001-010 C-SW,TACT SKQMAL ABCDE...............

S 910 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 915 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 911 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 912 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 914 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 913 87-A91-159-010 SW,TACT SKHLAD ABCDE...............

S 920 87-A90-001-010 C-SW,TACT SKQMAL ABCDE...............

S 921 87-A90-001-010 C-SW,TACT SKQMAL ABCDE...............

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

41US ...................XX..................................A...................

40US ...................XX...................................B..................

30Z1 ...................XX....................................C.................

31ZS ...................XX.....................................D................

45JS ...................XX......................................E...............

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-KT1-023-010 DOOR,CASS ABCDE...............

8Z-KTA-002-010 CABI,REAR -T10 ABCDE...............

8Z-KTA-011-010 CABI,BASE -T10 ABCDE...............

8Z-KTA-012-010 CABI,TRIM -T10 ABCDE...............

8Z-KTB-002-010 RING,OVAL T -T ABCDE...............

8Z-KTG-001-010 WINDOW,LCD X419 IR A...................

8Z-KTG-002-010 CABI,FRONT -T16 ABCDE...............

8Z-KTG-003-010 WINDOW,LCD X409 IR .B..................

8Z-KTG-004-010 WINDOW,LCD X4059 IR ....................

8Z-KTG-005-010 WINDOW,LCD X459 ....E...............

8Z-KTG-009-010 WINDOW,LCD X4019 IR ....................

8Z-KTG-010-010 WINDOW,LCD X419 ....................

8Z-KTG-017-010 WINDOW,LCD X309 ..C.................

8Z-KTG-021-010 WINDOW,LCD X319 ...D................

8Z-KT1-007-010 BTN,+/- -T ABCDE...............

8Z-KT1-008-010 BTN,SEL -T ABCDE...............

8Z-KT1-010-010 BTN,H-BASS -T ABCDE...............

8Z-KT1-011-010 BTN,U/D -T ABCDE...............

8Z-KT3-002-010 BTN,P.SET -T3 ABCDE...............

8Z-KT5-019-010 BTN,M.INF -T ABCDE...............

8Z-KTA-005-010 BTN,EJ -T10 ABCDE...............

8Z-KTA-006-010 BTN,FF -T10 ABCDE...............

8Z-KTA-007-010 BTN,REW -T10 ABCDE...............

8Z-KTA-008-010 BTN,DETACH -T10 ABCDE...............

8Z-KTF-003-010 BTN,TETRA BALD -T ABCDE...............

8Z-KTG-006-010 BTN,PWR -T ABCDE...............

8Z-KTG-007-010 BTN,TWIN T/M -T ABCDE...............

8Z-KTG-008-010 BTN,CD/MD IN -T ABCDE...............

87-KTE-205-010 SPR-C,EJ/FF/REW ABCDE...............

8Z-KT1-209-010 LENS,IR -T AB..................

8Z-KT1-211-010 COVER, TOP -T ABCDE...............

8Z-KT1-212-010 COVER, BOTTOM -T ABCDE...............

8Z-KT1-219-010 HLDR,TR -T ABCDE...............

8Z-KT1-220-010 HLDR,JACK F -T A...................

8Z-KT1-235-010 COVER, CONN.BLIND -T ..CD................

8Z-KT1-236-010 CAP,LAMP BLU AB.DE...............

8Z-KT1-237-010 CAP,LAMP GRN AB.DE...............

8Z-KT1-244-010 SPR-T,DOOR Z ABCDE...............

8Z-KT1-255-010 HLDR,TR -TA ABCDE...............

8Z-KT1-257-010 HLDR,ISO-WIRE -T ..CD................

8Z-KT4-201-010 COVER, CD BLIND -T ABCDE...............

8Z-KT4-203-010 CAP, LAMP ORN ..C.................

8Z-KT5-020-010 HLDR,M.INF -T ABCDE...............

8Z-KT5-201-010 COVER, ISO BLIND -T AB..E...............

8Z-KTA-202-010 HLDR,DECK CDS36 ABCDE...............

8Z-KTA-203-010 LEVER,DFP LOCK -T10 ABCDE...............

8Z-KTA-204-010 LEVER,DEF HOOK -T10 ABCDE...............

8Z-KTA-205-010 HLDR,JACK -T10 .BCDE...............

8Z-KTA-210-010 HLDR,LCD -T10 ABCDE...............

8Z-KTA-213-010 LENS,L -T10 ABCDE...............

8Z-KTA-214-010 LENS,R -T10 ABCDE...............

8Z-KTA-221-010 SPR-C,DETACH LOCK-T10 ABCDE...............

8Z-KTA-222-010 SPR-T,DETACH LOCK-T10 ABCDE...............

8Z-KTA-223-010 SPR-C,RELEASE -T10 ABCDE...............

8Z-KTG-202-010 HLDR,P-IC -T16 ABCDE...............

8Z-KTG-211-010 CASE,LCD LENS -T16 ABCDE...............

ACCESSORIES LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

41US ...................XX..................................A...................

40US ...................XX...................................B..................

30Z1 ...................XX....................................C.................

31ZS ...................XX.....................................D................

45JS ...................XX......................................E...............

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-KTG-901-010 IB,YU(3L) 419 A...................

8Z-KTG-902-010 IB,INST,YU (3L)419 A...................

8Z-KTG-903-010 IB,YU(3L) 409 .B..................

8Z-KTG-904-010 IB,INST,YU (3L)409 .B..................

8Z-KTG-905-010 IB,YL(3L) 4019/4059 ....................

8Z-KTG-906-010 IB,INST,YL (3L)4019/4059 ....................

8Z-KTG-907-010 IB,YZ(9L) 409/419 ..CD................

8Z-KTG-908-010 IB,INST,YZ (6L)409/419 ..CD................

8Z-KTG-909-010 IB,INST,YZ (CZ-PO-H)409/419 ..CD................

8Z-KTG-910-010 IB,YV(ER) 419 ....................

8Z-KTG-911-010 IB,INST,YV (ER) 419 ....................

8Z-KTG-912-010 IB,Y(E CH A) 459 ....E...............

8Z-KTG-913-010 IB,Y,INST (E CH A)459 ....E...............

86-KT1-237-010 HLDR,REAR MTG ABCDE...............

87-B10-141-010 NUT,5 TYPE-2 ABCDE...............

87-B10-144-010 W,5.2-10-0.5 ABCDE...............

87-B10-145-010 W-SPR,5.3-8.5-1.5 ABCDE...............

88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK ABCDE...............

8Z-KT1-030-010 CASE,DFP -T ABCDE...............

8Z-KT1-231-010 HLDR,HALF -T ABCDE...............

8Z-KT1-232-010 KEY,REMOVE -T ABCDE...............

8Z-KT1-616-010 CONN ASSY,16P B52 AB..E...............

8Z-KTG-951-010 SPKR,16CM ASSY ....E...............

* 87-B10-143-010 UT1+5-15 W/O SLOT ABCDE...............

* 88-KT1-247-010 S-SCREW,HEXAGON ABCDE...............

* 8Z-KT1-251-010 S-SCREW,5*6 TH+ TAPPING ST ABCDE...............

Printed in Singapore

Tokyo Japan

737004

Other manuals for CT-X409

Table of contents

Popular Car Receiver manuals by other brands

Linear Series

Linear Series LS5050 Operation and installation manual

Kenwood

Kenwood KRC-160 instruction manual

Sony

Sony XR-CA430X Service manual

T+A Elektroakustik

T+A Elektroakustik K1 CD-RECEIVER operating instructions

SoundMax

SoundMax SM-CDM1052 instruction manual

Xtrons

Xtrons HD107HD user manual

Mopar

Mopar RB3 manual

Clarion

Clarion ADDZEST DMZ615 owner's manual

Sony

Sony XAV-601BT Specifications

PIE

PIE GM12-POD/S Operation manual

Hyundai

Hyundai H-910H instruction manual

Sony

Sony XR-C6100 Service manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Installation/connections

Motorola

Motorola VWA63 Service manual

Sound Storm

Sound Storm STM93R user manual

Nextar

Nextar D3201 instruction manual

Alpine

Alpine CDE-163BT owner's manual

Kenwood

Kenwood KDC-X303 quick start guide

Aiwa CT-X409 User manual

Popular Car Receiver manuals by other brands
