Aiwa HS-JS189 User manual

S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
HS-JS189
• TYPE: YH,YJ,YL,YU,YZ
S/M Code No. 09–992–407–6T1
STEREO RADIO CASSETTE RECORDER

ELECTRICAL MAIN PARTS LIST - 1/2
NOTE: The characters in the suffix column indicate the part usage.
YL .....................XX..................................A...................
YH .....................XX...................................B..................
YJ .....................XX....................................C.................
YZ .....................XX.....................................D................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 201 87-010-115-010 E-CAP 100-4 ABCD................
C 204 87-010-115-010 E-CAP 100-4 ABCD................
C 203 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 209 87-010-198-080 CAP, CHIP 0.022 ABCD................
C 207 87-010-490-010 CAP,E 0.1-50 GAS ABCD................
C 208 87-010-490-010 CAP,E 0.1-50 GAS ABCD................
C 202 87-010-501-010 CAP GAS 47UF 4V ABCD................
C 205 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 206 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 218 87-010-175-080 CAP 560P ABCD................
C 217 87-010-175-080 CAP 560P ABCD................
C 214 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................
C 213 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................
C 210 87-010-198-080 CAP, CHIP 0.022 ABCD................
C 219 87-010-503-010 CAP,E 220-4 GAS ABCD................
C 215 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 211 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 212 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 216 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 224 87-010-115-010 E-CAP 100-4 ABCD................
C 223 87-010-115-010 E-CAP 100-4 ABCD................
C 221 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 222 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 220 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 225 87-010-501-010 CAP GAS 47UF 4V ABCD................
C 240 87-016-350-080 CAP,E 470-4 M 5L MA ABCD................
C 241 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 242 87-016-462-080 C-CAP,S 1-16 F ABCD................
IC 201 87-001-943-080 IC,TA8155F ABCD................
J 202 87-099-890-010 JACK,3.5 ST W/S BLK ABCD................
J 201 87-A60-319-010 JACK,DC DIA 2.75 ABC.................
J 201 87-A60-849-010 JACK,DC DIA 2.75 BLK ...D................
MIC 201 82-TP3-609-010 ECM ABCD................
Q 201 89-327-125-080 CHIP TR,2SC2712GR ABCD................
Q 202 89-327-125-080 CHIP TR,2SC2712GR ABCD................
S 2 87-A90-519-010 SW,SL 2-2-2 ABCD................
S 4 87-A90-519-010 SW,SL 2-2-2 ABCD................
S 7 87-A90-520-010 SW,SL 2-4-2SHORTING ABCD................
S 6 87-A90-917-010 C-SW,SL 1-1-2 SS-350-B12W-C-L ABCD................
C 303 87-016-492-080 C-CAP,S 0.33-16 FZ ABCD................
C 304 87-016-492-080 C-CAP,S 0.33-16 FZ ABCD................
S 3 87-A90-519-010 SW,SL 2-2-2 ABCD................
C 308 87-010-115-010 E-CAP 100-4 ABCD................
C 306 87-010-182-080 C-CAP,S 2200P-50 B ABCD................
C 305 87-010-182-080 C-CAP,S 2200P-50 B ABCD................
C 307 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 309 87-010-503-010 CAP,E 220-4 GAS ABCD................
C 302 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 301 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 313 87-010-503-010 CAP,E 220-4 GAS ABCD................
C 310 87-010-503-010 CAP,E 220-4 GAS ABCD................
C 312 87-A10-264-080 C-CAP,S 0.1-16ZF ABCD................
C 311 87-A10-264-080 C-CAP,S 0.1-16ZF ABCD................
IC 301 87-001-371-080 IC,LA4533M * ABCD................
J 301 85-HRL-623-010 JACK,3.5 ST BLK ABCD................
Q 205 89-327-125-080 CHIP TR,2SC2712GR ABCD................
VR 301 87-A90-521-010 VR,RTRY 10K H ABCD................
C 402 87-010-178-080 CHIP CAP 1000P ABCD................
C 404 87-010-503-010 CAP,E 220-4 GAS ABCD................
C 401 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 403 87-A10-264-080 C-CAP,S 0.1-16ZF ABCD................
IC 401 87-017-370-080 IC,MM1038AFF ABCD................
L 7 87-A50-364-010 COIL,15UH K CW45-708630 ABCD................
SFR 401 87-A90-518-010 SFR,1K V ABCD................
LED 301 87-017-827-070 C-LED,SEC 1201C RED ABCD................
C 226 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................
C 227 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 228 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 229 87-010-501-010 CAP GAS 47UF 4V ABCD................
C 232 87-010-174-080 CAP CHIP SL470P (K) ABCD................
C 231 87-010-179-080 CAP,CHIP S B1200P ABCD................
C 230 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
L 8 87-007-189-010 COIL OSC ABCD................
Q 204 87-026-263-080 C-TR,RN1410 ABCD................
Q 203 89-332-654-080 CHIP TRANSISTOR, 2SC3265Y ABCD................
87-A90-739-010 FLTR,KIT ABCD................
BPF 1 87-030-312-010 FLTR, GFMB3-1-T ABCD................
C 101 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 104 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 107 87-010-326-080 C-CAP,S 3P-50 UJ ABCD................
C 108 87-010-337-080 C-CAP,S 22P-50 UJ ABCD................
C 109 87-010-338-080 C-CAP,S 27P-50 UJ ABCD................

ELECTRICAL MAIN PARTS LIST - 2/2
C 102 87-010-503-010 CAP,E 220-4 GAS ABCD................
C 105 87-012-157-080 C-CAP,S 330P-50 CH ABCD................
C 111 87-010-331-080 C-CAP,S 8P-50 UJ ABCD................
C 113 87-010-501-010 CAP GAS 47UF 4V ABCD................
C 115 87-012-140-080 CAP 470P ABCD................
C 112 87-016-461-080 C-CAP,S 0.47-16F ABCD................
C 114 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 117 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 116 87-A10-264-080 C-CAP,S 0.1-16ZF ABCD................
C 118 87-A10-264-080 C-CAP,S 0.1-16ZF ABCD................
C 121 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 122 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 123 87-A10-264-080 C-CAP,S 0.1-16ZF ABCD................
C 124 87-A10-264-080 C-CAP,S 0.1-16ZF ABCD................
CF 1 87-A90-128-010 FLTR,AM IF CFAL-455 ABCD................
IC 101 87-A20-851-040 C-IC,TA2111F ABCD................
L 6 87-A50-365-010 COIL,ANT BFS5-826241 ABCD................
L 5 87-A90-177-010 IFT,AM IF 5P ABCD................
L 4 87-A90-180-010 IFT,AM OSC 5P ABCD................
L 1 8Z-HJ9-605-010 BAR-ANT,MW ABCD................
L 3 8Z-HJ9-608-010 COIL,FM OSC(EX) ABCD................
L 2 8Z-HJ9-609-010 COIL,FM RF(EX) ABCD................
S 1 87-036-322-010 SW,SL 2-2-3 ABCD................
VC 1 87-A91-241-010 TUN-CAP,20P-82P-160P 16X16 ABCD................
C 244 87-016-462-080 C-CAP,S 1-16 F ABCD................
C 245 87-016-462-080 C-CAP,S 1-16 F ABCD................
LED 201 87-A40-571-040 C-LED,SEC2764C RED/GRN ABCD................
Q 209 89-327-125-080 CHIP TR,2SC2712GR ABCD................
Q 210 89-327-125-080 CHIP TR,2SC2712GR ABCD................

MECHANICAL PARTS LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
YL .....................XX..................................A...................
YH .....................XX...................................B..................
YJ .....................XX....................................C.................
YZ .....................XX.....................................D................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-HJ9-007-010 WINDOW,TUNE ABCD................
8Z-HJA-010-010 LID,CASS YL A...................
8Z-HJA-011-010 LID,CASS YZ ...D................
0001 8Z-HJA-001-010 LID,CASS Y .BC.................
0001 8Z-HJA-004-010 PANEL,CASS ABCD................
0001 8Z-HJA-005-010 WINDOW,PANEL ABCD................
0001 8Z-HJA-006-010 PANEL,MIC ABCD................
87-067-103-010 SCREW, VFT2+1.4-3 ABCD................
87-352-508-310 VT2+1.4-3.5 BLK ABCD................
0001 8Z-HJA-201-010 HLDR,MIC ABCD................
8Z-HJA-012-010 CABI,REAR YZ ...D................
0001 87-HJA-008-010 POINTER,TUN ABCD................
0001 8Z-HJ9-004-010 LID,BATT ABCD................
0001 8Z-HJA-002-010 FRAME,CENTER ABCD................
0001 8Z-HJA-003-010 CABI,REAR ABC.................
0001 87-HJA-017-010 KNOB,RTRY TUN ABCD................
0001 87-HJA-021-010 KNOB,RTRY VOL ABCD................
0001 8Z-HJ9-008-010 KNOB,SL BAND ABCD................
0001 8Z-HJ9-009-010 KNOB,SL POWER ABCD................
0001 8Z-HJ9-010-010 KNOB,SL S-BASS ABCD................
0001 8Z-HJ9-011-010 KNOB,SL PAUSE ABCD................
0001 8Z-HJ9-012-010 KNOB,SL OSC ABCD................
0001 8Z-HJ9-014-010 BTN,PLAY ABCD................
0001 8Z-HJ9-015-010 BTN,REC ABCD................
0001 8Z-HJ9-016-010 BTN,STOP ABCD................
0001 8Z-HJ9-017-010 BTN,FF ABCD................
0001 8Z-HJ9-018-010 BTN,REW ABCD................
87-067-271-010 SCREW VFT2+1.7-4 ABCD................
87-067-769-010 VT2+1.7-8(3) BLK ABCD................
87-264-528-310 SCREW, V+1.7-3.5 ABCD................
87-264-529-310 V 1.7-4 SCREWS ABCD................
87-354-529-310 VT2+1.7-4 ABCD................
8Z-HJ9-204-010 TERMINAL,BAT (-) ABCD................
0001 87-HJA-202-010 LEVER,REC ABCD................
0001 87-HJA-203-010 SPR-P,CASS ABCD................
0001 87-HJA-206-010 SPR-T,CASS ABCD................
0001 87-HJA-207-010 SPR-E,REC ABCD................
0001 8Z-HJ9-201-010 LEVER,PAUSE ABCD................
0001 8Z-HJ9-205-010 TERMINAL,BAT (+) ABCD................
* 0001 8Z-HJ9-202-010 PLATE,KNOB PAUSE ABCD................
87-A90-739-010 FLTR,KIT ABCD................

ACCESSORIES / PACKAGE LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
YL .....................XX..................................A...................
YH .....................XX...................................B..................
YJ .....................XX....................................C.................
YZ .....................XX.....................................D................
YU .....................XX......................................E...............
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-HJA-903-010 IB,YU(3L)C ....E...............
8Z-HJA-904-010 IB,YJ(ECC)C .BC.................
8Z-HJA-906-010 IB,YL(3L)C A...................
8Z-HJA-907-010 IB,YZ(EGF)C ...D................
8Z-HJA-908-010 IB,YZ(SID)C ...D................
8Z-HJA-909-010 IB,YZ(PHNCZ)C ...D................
84-447-019-110 CLIP, BELT ABCDE...............
87-B30-080-110 HEADPHONE,HP-M009(F) ....E...............
87-B30-168-110 HEADPHONE,HP-MOO6(K) ABCD................
87-B30-168-210 HEADPHONE,HP-MOO6(K) ....................

SCHEMATIC DIAGRAM - 1 (MAIN)
