S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
HS-PX297
HS-GM1000
• TYPE: (297)Y1,(1000)Y1
S/M Code No. 09–993–410–9T1
STEREO CASSETTE PLAYER

ELECTRICAL MAIN PARTS LIST - 1/2
NOTE: The characters in the suffix column indicate the part usage.
[S]297Y1 ...............XX..................................A...................
[DL]297Y1 ..............XX...................................B..................
[S]1000Y1 ..............XX....................................C.................
[L]1000Y1 ..............XX.....................................D................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 109 87-010-828-080 CHIP CAPACITOR,U 0.033-25F ABCD................
C 104 87-012-273-080 C-CAP,U 820P-50 B ABCD................
C 101 87-012-273-080 C-CAP,U 820P-50 B ABCD................
C 103 87-012-273-080 C-CAP,U 820P-50 B ABCD................
C 102 87-012-273-080 C-CAP,U 820P-50 B ABCD................
C 108 87-016-114-080 C-CAP,U0.01-25B ABCD................
C 107 87-016-114-080 C-CAP,U0.01-25B ABCD................
C 105 87-016-286-080 C-CAP,TN 2.2-6.3 F93 ABCD................
C 106 87-016-286-080 C-CAP,TN 2.2-6.3 F93 ABCD................
C 110 87-010-828-080 CHIP CAPACITOR,U 0.033-25F ABCD................
C 113 87-010-987-080 C-CAP,S 1500P-50 CH ABCD................
C 114 87-010-987-080 C-CAP,S 1500P-50 CH ABCD................
C 116 87-012-285-080 C-CAP,U 8200P-50 B ABCD................
C 115 87-012-285-080 C-CAP,U 8200P-50 B ABCD................
C 117 87-012-286-080 CAP, U 0.01-25 ABCD................
C 118 87-012-286-080 CAP, U 0.01-25 ABCD................
C 119 87-A10-828-080 C-CAP,U 0.33-6.3 K B ABCD................
C 112 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 111 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 127 87-012-274-080 CHIP CAP,U 1000P-50B ABCD................
C 128 87-012-274-080 CHIP CAP,U 1000P-50B ABCD................
C 129 87-A10-025-080 C-CAP,U 0.22-16Z F ABCD................
C 121 87-A10-827-080 C-CAP,U 0.47-6.3 K B ABCD................
C 122 87-A10-827-080 C-CAP,U 0.47-6.3 K B ABCD................
C 120 87-A10-828-080 C-CAP,U 0.33-6.3 K B ABCD................
C 125 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 123 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 126 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 124 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 134 87-010-746-080 CAP, TANTAL 10-4 ABCD................
C 136 87-016-288-080 C-CAP,TN 4.7-6.3 F93 ABCD................
C 131 87-016-429-080 C-CAP,E 100-4 5.5N ABCD................
C 132 87-016-429-080 C-CAP,E 100-4 5.5N ABCD................
C 130 87-A10-025-080 C-CAP,U 0.22-16Z F ABCD................
C 138 87-A10-025-080 C-CAP,U 0.22-16Z F ABCD................
C 139 87-A10-025-080 C-CAP,U 0.22-16Z F ABCD................
C 137 87-A10-952-080 C-CAP,TN 22-4 M A MCM ABCD................
C 135 87-A10-952-080 C-CAP,TN 22-4 M A MCM ABCD................
C 133 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 149 87-016-286-080 C-CAP,TN 2.2-6.3 F93 ABCD................
C 140 87-016-288-080 C-CAP,TN 4.7-6.3 F93 ABCD................
C 148 87-016-288-080 C-CAP,TN 4.7-6.3 F93 ABCD................
C 143 87-A10-707-080 C-CAP,U 0.47U-16 F Z ABCD................
C 141 87-A10-707-080 C-CAP,U 0.47U-16 F Z ABCD................
C 142 87-A10-707-080 C-CAP,U 0.47U-16 F Z ABCD................
C 147 87-A10-708-080 C-CAP,U 0.68U-10 F Z ABCD................
C 146 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 145 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 144 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 151 87-010-784-080 C-CAP,U 0.012-25 B ABCD................
C 152 87-010-784-080 C-CAP,U 0.012-25 B ABCD................
C 150 87-016-288-080 C-CAP,TN 4.7-6.3 F93 ABCD................
C 153 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
IC 101 87-A21-174-010 C-IC,TA2103F ABCD................
J 101 87-A60-416-010 JACK,3.5 BLK ST 3P ABCD................
Q 105 87-026-331-080 CHIP TRANSISTOR DTA114YU ABCD................
Q 106 87-026-331-080 CHIP TRANSISTOR DTA114YU ABCD................
Q 107 87-026-350-080 CHIP TRANSISTOR DTC114TU ABCD................
Q 104 87-026-352-080 CHIP-TR,DTC144TU ABCD................
Q 102 87-026-352-080 CHIP-TR,DTC144TU ABCD................
Q 101 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABCD................
R 108 87-022-243-080 CHIP RES,U 15K-1/16W F ABCD................
R 107 87-022-243-080 CHIP RES,U 15K-1/16W F ABCD................
R 102 87-022-279-080 C-RES,U 470-1/16W F ABCD................
R 101 87-022-279-080 C-RES,U 470-1/16W F ABCD................
R 109 87-022-292-080 CHIP RES U 330K-1/16W F ABCD................
R 119 87-022-216-080 C-RES,U 1.1K-1/16W F ABCD................
R 115 87-022-251-080 C-RES,U 33K-1/16W F ABCD................
R 116 87-022-251-080 C-RES,U 33K-1/16W F ABCD................
R 118 87-022-251-080 C-RES,U 33K-1/16W F ABCD................
R 117 87-022-251-080 C-RES,U 33K-1/16W F ABCD................
R 110 87-022-292-080 CHIP RES U 330K-1/16W F ABCD................
R 120 87-022-216-080 C-RES,U 1.1K-1/16W F ABCD................
R 121 87-022-241-080 CHIP RESTOR 12K 1/16W F ABCD................
R 122 87-022-241-080 CHIP RESTOR 12K 1/16W F ABCD................
R 129 87-022-254-080 C-RES,U 43K-1/16 WF ABCD................
R 124 87-022-293-080 CHIP RES U 390K-1/16W F ABCD................
R 123 87-022-293-080 CHIP RES U 390K-1/16W F ABCD................
R 137 87-022-223-080 CHIP RES 2.2K 1/16W F ABCD................
S 102 87-A90-330-080 C-SW,SL 1-1-2 SSSS81 ABCD................
S 101 87-A90-330-080 C-SW,SL 1-1-2 SSSS81 ABCD................
S 103 87-A90-400-080 C-SW,SL 1-1-4 SSSS81 ABCD................
VR 101 87-A90-116-080 C-VR,RTRY20KCX2V0103 ABCD................

ELECTRICAL MAIN PARTS LIST - 2/2
C 402 87-012-286-080 CAP, U 0.01-25 ABCD................
C 401 87-012-286-080 CAP, U 0.01-25 ABCD................
C 403 87-012-286-080 CAP, U 0.01-25 ABCD................
C 406 87-A10-025-080 C-CAP,U 0.22-16Z F ABCD................
C 409 87-A10-260-080 C-CAP,U 0.1-16 K B ABCD................
C 407 87-A10-263-080 C-CAP,U 0.1-16ZF ABCD................
C 405 87-A10-707-080 C-CAP,U 0.47U-16 F Z ABCD................
C 408 87-A10-950-080 C-CAP,S 4.7-10 Z F ABCD................
IC 401 87-A20-961-040 C-IC,MM1279XV ABCD................
Q 401 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABCD................
Q 402 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABCD................
Q 403 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABCD................
Q 404 89-333-266-080 CHIP TR,2SC3326B ABCD................
Q 405 89-333-266-080 CHIP TR,2SC3326B ABCD................
SFR 401 87-024-406-080 C-SFR,6.8K RH03A3A ABCD................
TH 401 87-A90-855-080 C-THMS,SC20-3K102K ABCD................
PS 501 87-A90-526-010 SNSR,NJL 5163-F1-B ABCD................
Q 502 87-026-350-080 CHIP TRANSISTOR DTC114TU ABCD................
Q 501 89-333-266-080 CHIP TR,2SC3326B ABCD................
D 601 87-A40-643-040 C-LED,SML-211UT ABCD................
Q 601 87-026-352-080 CHIP-TR,DTC144TU ABCD................
C 702 87-010-746-080 CAP, TANTAL 10-4 ABCD................
C 701 87-010-746-080 CAP, TANTAL 10-4 ABCD................
C 703 87-A10-263-080 C-CAP,U 0.1-16ZF ABCD................
D 701 87-A40-642-040 C-DIODE,1SS367 ABCD................
IC 701 87-A20-785-080 C-IC,S-81215SG-QK-T1 ABCD................
Q 704 87-026-334-080 CHIP TRANSISTOR DTA143TU ABCD................
Q 705 87-026-334-080 CHIP TRANSISTOR DTA143TU ABCD................
Q 703 87-026-350-080 CHIP TRANSISTOR DTC114TU ABCD................
Q 706 87-026-352-080 CHIP-TR,DTC144TU ABCD................
Q 707 87-026-352-080 CHIP-TR,DTC144TU ABCD................
Q 701 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABCD................
Q 702 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABCD................
C 805 87-010-274-080 C-CAP,TN 3.3-4 ABCD................
C 808 87-012-274-080 CHIP CAP,U 1000P-50B ABCD................
C 807 87-012-274-080 CHIP CAP,U 1000P-50B ABCD................
C 801 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 803 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
C 802 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
D 801 87-A40-642-040 C-DIODE,1SS367 ABCD................
IC 801 8Z-HK6-605-010 C-IC,MSM6576-99-GS-K ABCD................
Q 801 87-026-337-080 C-TR,DTA144TU ABCD................
Q 803 87-026-349-080 CHIP TRANSISTOR DTC143TU ABCD................
Q 802 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABCD................
R 807 87-022-292-080 CHIP RES U 330K-1/16W F ABCD................
R 810 87-022-292-080 CHIP RES U 330K-1/16W F ABCD................
R 811 87-022-292-080 CHIP RES U 330K-1/16W F ABCD................
R 814 87-022-292-080 CHIP RES U 330K-1/16W F ABCD................
R 821 87-022-292-080 CHIP RES U 330K-1/16W F ABCD................
S 807 87-036-373-080 C-SW,SLIDE 1-1-2(E) ABCD................
S 808 87-A90-330-080 C-SW,SL 1-1-2 SSSS81 ABCD................
S 802 87-A90-356-210 SW,LEAF 6ZM-2 ABCD................
S 801 87-A90-455-010 SW,PUSH HXW4001 ABCD................
S 804 87-A90-665-180 C-SW,TACT LS7A2M ABCD................
S 803 87-A90-665-180 C-SW,TACT LS7A2M ABCD................
S 805 87-A90-665-180 C-SW,TACT LS7A2M ABCD................
S 806 87-A90-665-180 C-SW,TACT LS7A2M ABCD................
S 809 87-A91-335-080 C-SW,PUSH 1-1-1 SPVG11 ABCD................
X 801 87-A70-079-110 VIB,XTAL 32.768KHZ M VT-200 ABCD................
C 901 87-A11-056-080 C-CAP,U 1-10 Z F ABCD................
J 901 87-A60-319-010 JACK,DC DIA 2.75 ABCD................

MECHANICAL PARTS LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
[S]297Y1 ...............XX..................................A...................
[DL]297Y1 ..............XX...................................B..................
[S]1000Y1 ..............XX....................................C.................
[L]1000Y1 ..............XX.....................................D................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-HK6-008-010 WINDOW,CASS N .B.D................
8Z-HK6-220-010 STOPPER,CASS ABCD................
8Z-HKC-001-010 LID,ASSY CASS S A.C.................
8Z-HKC-002-010 LID,CASS S A.C.................
8Z-HKC-005-010 LID,ASSY CASS LD .B..................
8Z-HKC-006-010 LID,CASS LD .B..................
8Z-HKC-012-010 WINDOW,CASS S A.C.................
8Z-HKD-001-010 LID,ASSY CASS L ...D................
8Z-HKD-002-010 LID,CASS L ...D................
87-067-738-010 HINGE SCREW 1.4-1 BLK N ABCD................
87-HK5-237-010 S-SCREW,1.4-2 CR NL ABCD................
* 8Z-HK6-223-010 S-SCREW,+1.4-0.7-1 CR NL ABCD................
8Z-HK6-202-010 HLDR,CASS R ABCD................
8Z-HK6-203-010 HLDR,CASS L ABCD................
8Z-HK6-207-010 SPR-P,CLIK ABCD................
8Z-HK6-004-010 FRAME,CENTER N .B.D................
8Z-HK6-009-010 LENS,LED ABCD................
8Z-HKD-003-010 CABI,REAR 297 S A...................
8Z-HKD-004-010 CABI,REAR 1000 L ...D................
8Z-HKD-005-010 CABI,REAR 297 LD .B..................
8Z-HKD-006-010 LID,BATT 297 S A...................
8Z-HKD-007-010 LID,BATT 1000 L ...D................
8Z-HKD-008-010 LID,BATT 297 LD .B..................
8Z-HKD-010-010 FRAME,CENTER A.C.................
8Z-HKD-011-010 CABI,REAR 1000 S ..C.................
8Z-HKD-012-010 LID,BATT 1000 S ..C.................
8Z-HK6-006-010 KEY,MSP ABCD................
8Z-HK6-007-010 KEY,CONT ABCD................
8Z-HK6-010-010 KNOB,SL OPEN ABCD................
8Z-HK6-011-010 KNOB,SL HOLD A.C.................
8Z-HK6-012-010 KNOB,SL A A.C.................
8Z-HK6-013-010 KNOB,SL B A.C.................
8Z-HKC-014-010 KNOB,SL HOLD S ...D................
8Z-HKC-015-010 KNOB,SL A S ...D................
8Z-HKC-016-010 KNOB,SL B S ...D................
8Z-HKC-023-010 KNOB,SL HOLD L .B..................
8Z-HKC-024-010 KNOB,SL A L .B..................
8Z-HKC-025-010 KNOB,SL B L .B..................
87-067-384-010 SCREWVT1.4-3.5HL ABCD................
87-067-430-010 VT1.4-5 BLK ABCD................
87-067-535-010 SCREW VT+1.4-3.5 ABCD................
87-067-732-010 TAPPING SCREW, VT1.4-3 ABCD................
87-067-746-010 SCREW,M 1.4-2(H0.5) ABCD................
87-078-113-010 S-SCRW,+1.4-3.5 HL(B ABCD................
87-263-500-310 SCREW V+1.4-1.4 ABCD................
87-HK5-235-010 S-SCREW,1.4-0.6-2.5 ABCD................
88-HK5-228-010 S-SCREW,+1.4-2 CR ABCD................
* 8Z-HK6-224-010 S-SCREW,SERR+1.4-3 CR ABCD................
87-HK6-203-010 SPR-P,POP UP ABCD................
8Z-HK6-205-010 HLDR,JACK ABCD................
8Z-HK6-206-010 SPR-P,CASS ABCD................
8Z-HK6-208-010 HLDR,BATT ABCD................
8Z-HK6-209-010 PLATE,IND ABCD................
8Z-HK6-210-010 GEAR,MSP ABCD................
8Z-HK6-211-010 SPR,CLICK MSP ABCD................
8Z-HK6-213-010 SPR-C,BATT M ABCD................
8Z-HK6-225-010 SPR-E,EJECT L ABCD................
* 8Z-HK6-201-010 PLATE,HINGE ABCD................
* 8Z-HK6-204-010 PLATE,EJECT ABCD................
* 8Z-HK6-212-010 PLATE,BATT P ABCD................
* 8Z-HKD-201-010 PLATE,STOPPER ABCD................

ACCESSORIES / PACKAGE LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
[S]297Y1 ...............XX..................................A...................
[DL]297Y1 ..............XX...................................B..................
[S]1000Y1 ..............XX....................................C.................
[L]1000Y1 ..............XX.....................................D................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-HKD-907-010 IB,Y(EGFSI) S ABCD................
8Z-HKD-908-010 IB,Y(DPHNCZ) S AB..................
87-B30-254-010 HEADPHONE,HP-M007B(T) ABCD................

SCHEMATIC DIAGRAM - 1 (MAIN)

PrintedinSingapore
Tokyo Japan
4
9630469
