Aiwa Csd-el33 User manual

COMPACT

DISC

STEREO

RADIO

CASSETTE

RECORDER

CSD-EL33

En

(English)

CorviPACT

.8Z-CH2-908-01

4

990428AYK-H-6

DIGITAL

AUDIO

ee

ENGLISH

WARNING

TO

REDUCE

THE

RISK

OF

FIRE

OR

ELECTRIC

SHOCK,

DO

NOT

EXPOSE

THIS

APPLIANCE

TO

RAIN

OR

MOISTURE.

CAUTION

(

RISK

OF

ELECTRIC

SHOCK

DO

NOT

OPEN

CAUTION

TO

REDUCE

THE

RISK

OF

ELECTRIC

SHOCK,

DO

NOT

REMOVE

COVER

(OR

BACK).

NO

USER-SERVICEABLE

PARTS

INSIDE.

REFER

SERVICING

TO

QUALIFIED

SERVICE

PERSONNEL.

CAUTION

Use

of

controls

or

adjustments

or

performance

of

procedures

other

than

those

specified

herein

may

result

in

hazardous

radiation

exposure.

This

compact

disc

player

is

classified

as

a

CLASS

1

LASER

product.

The

CLASS

1

LASER

PRODUCT

label

is

located

on

the

exterior.

CLASS

1_

LASER

PRODUCT

KLASSE

1

LASER

PRODUKT

LUOKAN

1

LASER

LAITE

KLASS

1

LASER

APPARAT

CAUTION!

Invisible

laser

radiation

when

open

and

inter-

locks

defeated.

Avoid

exposure

to

beam.

ADVARSEL!

Usynlig

laserstaling

ved

abning,

nar

sikkerhedsafbrydereer

ude

af

funktion.

Undga

udseetielse

for

straling.

VAROITUS!

Laitteen

kayttaminen

muulla

kuin

tassa

kayttéohjeessa

mainitulla

tavalla

saattaa

antistaa

kayttajan

turvallisuusluokan

1

ylittavalle

nakymatt6émalle

lasersateilylle.

VARNING!

Om

apparaten

anvands

pa

annat

satt

an

i

denna

bruksanvisning

Specificerats,

kan

anvandaren

utsatta

fér

osynlig

laser-stralning,

som

6verskrider

gransen

fér

laserklass

1.

OBSERVERA

Sa

lange

som

apparaten

4r

ansluten

tili

natet

flyter

en

svag

strom

genom

densamma,

aven

da

den

ar

avstangd.

Om

man

under

en

langre

tid

ej

har

for

avsikt

att

anvanda

den,

drag

da

ur

natkabeln.

BEMARK

Apparatet

er

stadig

forbundet

med

lysnettet,

sA

laenge

stikket

er

tilsluttet

til

stikkontakten,

selv

om

afbryteren

er

slaet

fra.

Hvis

apparatet

ikke

bruges

i

leengere

tid,

skal

netledningen

treekkes

ud.

2

ENGLISH

PRECAUTIONS

Read

the

Operating

Instructions

carefully

and

completely

before

operating

the

unit.

Be

sure

to

keep

the

Operating

Instructions

for

future

reference.

All

warnings

and

cautions

in

the

Operating

Instructions

and

on

the

unit

should

be

strictly

followed,

as

well

as

the

safety

suggestions

below.

Installation

1

Water

and

moisture

-

Do

not

use

this

unit

near

water,

such

as

near

a

bathtub,

washbow/l,

kitchen

sink,

laundry

tub,

in

a

wet

basement,

swimming

pool,

or

the

like.

2

Heat

-

Do

not

use

this

unit

near

sources

of

heat,

including

heating

vents,

stoves,

or

other

appliances

that

generate

heat.

It

also

should

not

be

placed

in

temperatures

less

than

5°C

or

greater

than

35°C.

3

Mounting

surface

-

Place

the

unit

on

a

flat,

even

surface.

-

4

Ventilation

-

The

unit

should

be

situated

with

adequate

space

around

it

so

that

proper

heat

ventilation

is

assured.

Allow

10

cm

clearance

from

the

rear

and

the

top

of

the

unit

and

5

cm

from

each

side.

-

Do

not

place

the

unit

on

a

bed,

rug,

or

similar

surface

that

may

block

the

ventilation

openings.

-

Do

not

install

the

unit

in

a

bookcase,

cabinet,

or

airtight

rack

where

ventilation

may

be

impeded.

5

Objects

and

liquid

entry

-

Take

care

that

objects

or

liquids

do

not

get

inside

the

unit

through

the

ventilation

openings.

6

Carts

and

stands

-

When

placed

or

mounted

on

a

stand

or

cart,

the

unit

should

be

moved

with

care.

Quick

stops,

excessive

force,

and

uneven

surfaces

may

cause

the

unit

or

cart

to

overturn

or

fall.

7

Condensation

-

Moisture

may

form

on

the

CD

pickup

lens

when:

-

The

unit

is

moved

from

a

cold

spot

to

a

warm

spot

-

The

heating

system

has

just

been

turned

on

-

The

unit

is

used

in

a

very

humid

room

-

The

unit

is

cooled

by

an

air

conditioner

When

this

unit

has

condensation

inside,

it

may

not

function

normally.

Should

this

occur,

leave

the

unit

for

a

few

hours,

then

try

to

operate

again.

8

Wall

or

ceiling

mounting

-

The

unit

should

not

be

mounted

on

a

wall

or

ceiling,

unless

specified

in

the

Operating

Instructions.

Electric

Power

1

Power

sources

-

Use

on

batteries

or

AC

house

current,

as

specified

in

the

Operating

Instructions

and

marked

on

the

unit.

2

AC

power

cord

-

When

disconnecting

the

AC

power

cord,

pull

it

out

by

the

AC

power

plug.

Do

not

pull

the

cord

itsel!.

-

Never

handle

the

AC

power

plug

with

wet

hands,

as

this

could

result

in

fire

or

shock.

-

Power

cords

should

be

firmly

secured

to

avoid

being

bent,

pinched,

or

walked

upon.

Pay

particular

attention

to

the

cord

from

the

unit

to

the

power

socket.

-

Avoid

overloading

AC

power

plugs

and

extension

cords

beyond

their

capacity,

as

this

could

result

in

fire

or

shock.

3

When

not

in

use

-

Unplug

the

AC

power

cordfrom

the

AC

power

socket

or

remove

all

the

batteries

ifthe

unit

will

not

be

used

for

several

months

or

more.

When

the

cord

is’

plugged

in,

a

small

amount

of

current

continues

to

flow

to

the

unit,

even

when

the

power

is

turned

off.

Maintenance

Clean

the

unit

only

as

recommended

in

the

Operating

Instructions.

Damage

Requiring

Service

Have

the

units

serviced

by

a

qualified

service

technician

if:

-

The

AC

power

cord

or

plug

has

been

damaged

-

Foreign

objects

or

liquid

have

got

inside

the

unit

-

The

unit

has

been

exposed

to

rain

or

water

-

The

unit

does

not

seem

to

operate

normally

-

The

unit

exhibits

a

marked

change

in

performance

-

The

unit

has

been

dropped,

or

the

cabinet

has

been

damaged

g

DO

NOT

ATTEMPT

TO

SERVICE

THE

UNIT

YOURSELF.

TABLE

OF

CONTENTS

PREPARATIONS

POWER

SUPPLY

........csscscsscrscssssecsorncsscssrsnrnsssesaesorsocengesenseee

REMOTE

CONTROL

.........csesssessesnssccsssresssersnersesseenetteansansens

BEFORE

OPERATION

on

SETTING

THE

CLOCK

SOUND

ADJUSTING

THE

SOUND........sssssssessosssssntesensessescnssenseeneay

6

TAPE

PLAYBACK

TAPE

OPERATIONS

.......ssssssssssseessonsessssecssseesssessnsesnucsenseseeas

7

RADIO

RECEPTION

MANUAL.

TUNING.

......ccssesccsscnsssenssensenenereatsnneeaneetnnenesnsenseces

PRESETTING

STATIONS

CD

PLAYING

CD

OPERATIONS.

........ssccccsssssesenssnsonneseeseesensnenensreneneten

sens

10

RECORDING

RECORDING.

........csscsccccsecsssecesssssearseaneassersetuennseateaneneion

seers

12

TIMER

PLAY/TIMER

RECORDING

SETTING

THE

SLEEP

TIMER

......-sssssssscssesenseensnenscnectenseeas

GENERAL

CARE

AND

MAINTENANCE

..........csscscscessesssensensseeernm

ences

TROUBLESHOOTING

GUIDE

a

SPECIFICATIONS

..........sc0ss0se0es

aie

PARTS

INDEX.........ccsessssssssseserenerssssserntsnseneseanesseserteneinn

nase

ENGUSH

3

PREPARATIONS

POWER

SUPPLY

USING

ON

AC

HOUSE

CURRENT

Connect

the

AC

cord

as

illustrated

below.

@

to

the

AC

inlet

of

the

unit

@

toanac

power

Tp

socket

c

a

AC

cord

(supplied)

CAUTION

Use

only

the

supplied

AC

cord.

Use

with

other

cords

may

result

in

the

risk

of

fire.

USING

ON

BATTERIES

Open

the

lid

of

the

battery

compartment

on

the

rear

and

insert

eight

R14

(size

C)

batteries,

not

supplied,

as

illustrated

below.

Then

close

the

lid.

To

switch

from

AC

power

supply

to

battery

power

supply,

disconnect

the

AC

cord

from

the

AC

inlet.

a

The

batteries

need

to

be

replaced

when:

The

OPE/BATT

indicator

becomes

dim,

the

tape

speed

slows

down,

volume

decreases,

or

sound

is

distorted

during

operation.

Notes

on

batteries

To

avoid

damage

from

leakage

or

explosion,

observe

the

following:

¢

Insert

the

batteries

with

the

®

and

©

marks

correctly

aligned.

*

Do

not

mix

different

types

of

batteries

or

old

batteries

with

new

ones.

¢

Never

recharge

the

batteries,

apply

heat

to

them

or

take

them

apart.

*

Remove

dead

batteries.

If

liquid

leaks

from

the

batteries,

wipe

thoroughly

to

remove.

NOTE

If

power

is

interrupted

for

more

than

12

hours,

all

settings

stored

in

memory,

such

as

the

clock,

the

timer,

and

the

presetting

of

the

broadcasting

stations,

are

cleared

and

need

to

be

set

again.

4

ENGLISH

REMOTE

CONTROL

INSERTING

BATTERIES

Detach

the

battery

cover

on

the

rear

of

the

remote

control

and

insert

two

R6

(size

AA)

batteries.

R6

(AA)

When

fo

replace

the

batteries

The

maximum

operational

distance

between

the

remote

control

and

the

remote

sensor

on

the

main

unit

should

be

approximately

5

meters.

When

this

distance

decreases,

replace

the

batteries

with

new

ones.

USING

THE

REMOTE

CONTROL

Some

operations

can

be

performed

using

the

buttons

on

the

remote

control

only,

or

those

on

the

main

unit

only,

while

others

can

be

performed

using

the

buttons

on the

main

unit

as

well

as

the

remote

control.

This

instructions

manual

clearly

describes

the

buttons

available

for

each

operation.

To

use

the

buttons

Point

the

remote

control

at

the

remote

sensor

on

the

main

unit

to

use

the

buttons

on

the

remote

control.

Remote

sensor

To

use

the

FUNCTION

button

The

FUNCTION

button

substitutes

for

the

function

buttons

(TAPE,

RADIO/BAND,

CD)

on the

main

unit.

Each

time

the

FUNCTION

button

is

pressed

while

the

power

ison,

the

is

selected

cyclically

in

the

following

orcer:

[”

TAPE

——>

RADIO

——>

CD

“J

NOTE

°

If

the

unit

is

not

going

to

be

used

for

an

extend:c-period

of

time,

remove

the

batteries

to

prevent

possible

¢lectrolyte

leakage.

*

The

remote

control

may

not

operate

correctly

vinen:

—

The

line

of

sight

between

the

remote

contro!

and

the

unit

°

is

exposed

to

intense

light,

such

as

direct

suiléght

—

Other

remote

controls

are

used

nearby

(television,

etc.)

¢

The

®

button

on

the

remote

control

has

the

same

function

-

as

that

of

the

<{

button

on

the

main

unit.

BEFORE

OPERATION

TAPE/REVERSE

MODE

RADIO/BAND

7

POWER

To

turn

the

unit

on

Press

one

of

the

FUNCTION

buttons

(TAPE/REVERSE

MODE,

RADIO/BAND,

CD).

Playback

of

the

inserted

disc

or

tape

begins,

or

the

previously

tuned

station

is

received

(Direct

Play

Function).

The

POWER

button

is

also

available.

After

use

Press

the

POWER

button

to

turn

off

the

power.

The

display

changes

to

the

clock.

NOTE

When

using

on

the

batteries,

you

cannot

turn

the

power

on

with

the

remote

control.

To

use

the

headphones

Connect

headphones

with

a

stereo

mini

plug

(93.5

mm)

to

the

©

(headphones)

jack.

No

sound

is

output

from

the

speakers

while

the

headphones

are

plugged

in.

SETTING

THE

CLOCK

2

VOLUME/TIMER

a

CLOCK

Press

the

CLOCK

button.

©

flashes.

(12-hour

standard)

Turn

the

VOLUME/TIMER

control

to

adjust

the

clock.

For

quick

adjustment,

turn

the

control

quickly.

You

can

also

press

the

<<

or

BP

button.

Holding

these

buttons

down

will

vary

the

time

in

20-minute

units.

Press

the

ENTER

button

to

complete

the

setting.

©

on

the

display

disappears

and

the

clock

starts

from

00

seconds.

To

display

the

current

time

Press

the

CLOCK

button.

To

return

to

the

operation

display,

press

the

CLOCK

button

or

one

of

the

function

buttons.

To

switch

to

the

12/24-hour

standard

While

the

clock

is

displayed,

press

the

Il

button.

If

the

clock

display

flashes

while

the

power

is

off

This

is

caused

by

a

power

interruption.

The

current

time

needs

to

be

reset.

If

power

is

interrupted

for

more

than

approximately

12

hours,

all

settings

stored

in

memory

after

purchase

need

tobe

reset.

ENGGUSH

5

ADJUSTING

THE

SOUND

VOLUME/TIMER

1]

on

=

DISPLAY

Q

a

3MODE

EQUALIZER

|

FBASS

EK

VOL

(ROCK/POPNAZZ)

—

QSURROUND

|

VOLUME

CONTROL

Turn

the

VOLUME/TIMER

control

on

the

main

unit

or

press

the

VOL

buttons

on

the

remote

control.

To

display

the

current

volume

level

Press

the

DISPLAY

button

on

the

remote

control.

The

volume

level

is

displayed

for

4

seconds.

SUPER

T-BASS

SYSTEM

The

T-BASS

system

enhances

the

realism

of

low-frequency

sound.

Press

the

T-BASS

button.

To

cancel,

press

the

button

again.

NOTE

Low

frequency

sound

may

be

distorted

when

the

T-BASS

system

is

used

for

a

disc

or

tape

in

which

low

frequency

sound

is

originally

emphasized.

In

this

case,

cancel

the

T-

BASS

system.

Q

SURROUND

SYSTEM

The

Q

SURROUND

system

built

into

this

unit

uses

only

two

speakers

at

the

left

and

right

to

create

an

atmosphere

that

sounds

as

if

you

are

surrounded

by

two

front

speakers

and

two

rear

speakers.

Press

the

QQURROUND

button.

To

cancel,

press

the

button

again.

NOTE

*

The

Q

SURROUND

system

does

not

work

in

monaural

mode.

*

At

higher

volumes,

turning

Q

SURROUND

on

may

cause

.

sound

distortion.

In

this

case,

turn

the

volume

down.

6

ENGLISH

EQUALIZER

MODE

Press

one

of

the

3-MODE

EQUALIZER

buttons;

ROCK,

POP

or

JAZZ

to

activate

the

desired

equalizer

mode.

To

cancel,

press

the

button

again.

When

using

the

remote

control,

press

the

EQ

button

repeatedly

to

select

the

desired

equalizer

mode

or

no

equalization.

&

POP

MEO

_

JAZZ

oe

oo

STEEP

i

ROCK:

Powerful

sound

emphasizing

treble

and

bass

POP:

More

presence

in

the

vocals

and

midrange

JAZZ:

Accented

lower

frequencies

for

jazz-type

music

TAPE

PLAYBACK

TAPE

OPERATIONS

TAPE/REVERSE

OPEN

mark

MODE

OoOo00

oooo0

ooo0000

ex

INSERTING

A

TAPE

Use

Type

I

(normal)

tapes

only.

Press

the

TAPE/REVERSE

MODE

button

and

press

the

OPEN

mark

to

open

the

cassette

holder.

Insert

a

tape

with

the

exposed

side

facing

forward.

Push

the

cassette

holder

to

close.

To

select

a

reverse

mode

Each

time

the

TAPE/REVERSE

MODE

button

is

pressed,

the

reverse

mode

changes.

Lz

—s¢z-s¢2)-1

To

play

one

side

only,

select

=.

To

play

from

front

side

to

back

side

once

only,

select

C=.

To

play

both

sides

repeatedly,

select

(=).

PLAYING

BACK

A

TAPE

Insert

a

tape.

Press

the

<>

button

(or

the

>

button

on

the

remote

control)

to

start

play.

Playback

side

of

the

tape

The

tape

counter

indicates

the

tape

running

length

“4:

The

side

facing

upward

is

being

played

(forward).

b:

The

opposite

side

is

being

played

(reverse).

To

stop

play,

press

the

MH

button.

To

pause

play,

press

the

II

button.

To

resume

play,

press

again.

To

change

the

playback

side,

press

the

<4

button

in

play

mode.

To

fast

forward

or

rewind,

press

the

<<

or

B®

button

in

stop

mode.

Then

press

the

I

button

to

stop

the

tape.

To

start

play

when

the

power

is

off

(Direct

Play

Function)

Press

the

TAPE/REVERSE

MODE

button.

The

power

is

turned

on

and

play

of

the

inserted

tape

begins.

To

set

the

tape

counter

to

0000

Press

the

lf

button

in

stop

mode.

The

counter

is

also

set

to

0000

when

the

cassette

holder

is

opened.

About

cassette

tapes

¢

To

prevent

accidental

erasure,

break

off

the

plastic

tabs

on

the

cassette

tape

with

a

screwdriver

or

other

pointed

tool

after

recording.

Tab

for

side

A

To

record

on

the

tape

again,

cover

the

tab

openings

with

adhesive

tape,

etc.

*

120-minute

or

longer

tapes

are

extremely

thin

and

easily

deformed

or

damaged.

They

are

not

recommended.

¢

Take

up

any

slack

in

the

tape

with

a

pencil

or

similar

tool

before

use.

Slack

tape

may

break

or

jam

inthe

mechanism.

ENGLISH

7

RADIO

RECEPTION

MANUAL

TUNING

7

Press

the

RADIO/BAND

button

repeatedly

to

select

the

desired

band.

ieee

—»>

MW

—>

LW

a

lf

the

power

is

turned

off,

the

previously

tuned

station

will

be

played

(Direct

Play

Function).

When

using

the

remote

control,

press

the

BAND

button

repeatedly

while

the

power

is

on.

2

Press

the

<4

or

>

button

to

select

a

station.

Each

time

the

button

is

pressed,

the

frequency

changes.

During

FM

stereo

reception,

"STEREO"

is

displayed.

STEREO

frequency

To

search

for

a

station

quickly

(Auto

Search)

Keep

the

<<

or

®

button

pressed

until

the

radio

starts

searching

for

a

station.

After

tuning

in

to

a

station,

the

search

stops.

To

stop

the

Auto

Search

manually,

press

the

<<

or

DP

button.

*

The

Auto

Search

may

not

stop

at

stations

with

very

weak

signals.

For

better

reception

FM

Extend

the

FM

antenna

and

orient

it

for

the

best

reception.

MW/LW

The

MW/LW

antenna

is

inside

the

unit.

Position

the

unit

for

the

best

reception.

8

ENGLISH

When

an

FM

stereo

broadcast

contains

noise

Press

the

MODE

button

on

the

remote

control.

MONO

appears

on

the

display.

Noise

is

reduced,

although

reception

is

monaural.

MONO

To

restore

stereo

reception,

repeat

the

above

again.

To

change

the

MW

tuning

interval

The

default

setting

of

the

MW

tuning

interval

is

9

kHz/step.

If

you

use

this

unit

in

an

area

where

the

frequency

allocation

system

is

10

kHz/step,

change

the

tuning

interval.

Press

the

POWER

button

while

pressing

the

RADIO/BAND

button.

To

reset

the

interval,

repeat

this

procedure.

NOTE

When

the

MW

tuning

interval

is

changed,

all

preset

stations

(see

"PRESETTING

STATIONS")

are

cleared.

The

preset

stations

have

to

be

set

again.

PRESETTING

STATIONS

RADIO/BAND

0-9,+10

<>

BAND

>

_

<4

>>

Til

You

can

preset

up

to

15

stations

in

each

band.

Whena

station

is

stored,

a

preset

number

is

assigned

to

the

station.

Use

the

preset

number

to

tune

in

to

a

preset

station

directly.

7

Press

the

RADIO/BAND

button

on

the

main

unit

or

the

BAND

button

on

the

remote

control

to

select

a

band.

Then,

press

the

<<

or

>>

button

to

select

a

station.

2

Press

the

II

button

to

store

the

station.

A

station

is

assigned

a

preset

number,

beginning

from

1

in

consecutive

order

for

each

band.

Frequency

Preset

number

3

Repeat

steps

1

and

2.

PRESET

NUMBER

TUNING

Use

the

remote

control

to

select

the

preset

number

directly.

17

Press

the

RADIO/BAND

button

on

the

main

unit

or

the

BAND

button

on

the

remote

control

to

select

a

band.

2

Press

the

numbered

buttons

to

select

a

preset

number.

Example:

To

select

preset

number

15,

press

the

+10

and

5

buttons.

To

select

preset

number

10,

press

the

+10

andO

buttons.

Another

method

to

select

a

preset

number

Press

the

RADIO/BAND

button

to

select

a

band.

Then,

press

the

<{>

button

(or

the

B

bution)

repeatedly.

Each

time

the

button

is

pressed,

the

number

is

selected.

To

clear

a

preset

station

Select

the

preset

station

to

be

cleared.

Then,

press

the

Ml

button,

and

press

the

Il

button

within

4

seconds.

The

preset

numbers

of

all

other

stations

in

the

band

with

higher

numbers

are

also

decreased

by

one.

W«GLIsH

9

CD

PLAYING

CD

OPERATIONS

CD

OPEN

LOADING

A

DISC

Press

the

CD

button,

press

the

CD

OPEN

button

to

open

the

disc

compartment,

and

load

a

disc with

a

label

side

up.

Then

press

the

CD

OPEN

button

again

to

close

the

disc

compartment.

Press

to

open.

Total

number

of

tracks

PLAYING

A

DISC

Load

a

disc.

Press

the

<>

button

(or

the

button

on

the

remote

control).

Play

begins

with

the

first

track.

Elapsed

playing

time

Track

number

being

played

10

ENGLISH

To

stop

play,

press

the

I

button.

To

pause

play,

press

the

II

button.

To

resume

play,

press

again.

To

search

for

a

particular

point

during

playback,

keep

the

<<

or

>

button

pressed

and

release

the

button

at

the

desired

point.

To

skip

to

the

beginning

of

a

track

during

playback,

press

the

<<

or

B®

button

repeatedly.

To

remove

the

disc,

press

the

CD

OPEN

button.

To

start

play

when

the

power

is

off

(Direct

Play

Function)

Press

the

CD

button.

The

power

is

turned

on

and

play

of

the

loaded

disc

begins.

To

replace

the

disc

before

play,

press

the

CD

OPEN

button

to

open

the

disc

compartment.

Selecting

a

track

with

the

remote

control

Press

the

numbered

buttons

and

the

+10

button

to

select

a

track.

Example:

To

select

the

25th

track,

press

the

+10,

+10

and

5

butions.

To

select

the

10th

track,

press

the

+10

and

0

buttons.

The

selected

track

starts

to

play

and

play

continues

to

the

end

of

that

disc.

NOTE

¢

Do

not

use

irregular

shape

CDs

(example:

heart-shaped,

octagonal

ones).

It

may

result

in

malfunctions.

¢

When

loading

an

8-cm

(3-inch)

disc,

put

it

onto

the

inner

circle

of

the

tray.

*

Do

not

place

more

than

one

compact

disc

on

the

disc

tray.

RANDOM

PLAY

PROGRAMMED

PLAY

All

the

tracks

on

the

disc

can

be

played

randomly.

Up

to

30

tracks

can

be

programmed

from

the

inserted

disc.

Use

the

remote

control.

7

Press

the

MODE

button

on

the

remote

control

repeatedly

until

RANDOM

lights

up

on

the

7

Press

the

MODE

button

on

the

remote

control

display...

repeatedly

until

MEMO

flashes

on

the

display.

RANDOM

MEMO

flashes

2

Press

the

<>

button

to

start

play.

2

Press

the

numbered

buttons

and

the

+10

button

to

program

a

track.

To

cancel

the

random

play

Example:

Press

the

MODE

button

twice

in

stop

mode.

RANDOM

To

select

the

12th

track,

press

the

+10

and

2

buttons.

disappears

and

the

normal

display

appears.

To

select

the

20th

track,

press

the

+10,

+10

and

0

buttons.

NOTE

Total

playing.time

of

¢

Even

if

the

<4

button

is

pressed,

a

previously

played

track

Program

number

the

selected

tracks

cannot

be

skipped.

The

unit

returns

to

the

beginning

of

the

current

track

only.

*

During

random

play,

one-track

repeat

(@

1)

cannot

be

performed.

¢

If

you

select

tracks

with

the

numbered

buttons,

random

play

is

cancelled.

Selected

track

number

Total

number

of

selected

tracks

REPEAT

PLAY

3

Repeat

step

2

to

program

other

tracks.

One

track

or

all

the

tracks

can

be

played

repeatedly.

4

Press

the

REPEAT

button

repeatedly

on

the

remote

Press

the

button

to

start

play.

control.

Each

time

it

is

pressed,

the

play

mode

can

be

selected

To

check

the

program

cyclically.

Each

time

the

>

button

is

pressed

in

stop

mode,a_

track

number

and

program

number

will

be

displayed.

Only

the

current

track

is

repeated.

(@

1

is

displayed.)

To

clear

the

program

Roy

Press

the

ll

button

in

stop

mode.

an

i

tracks

are

repeated.

(C

is

displayed.)

Removing

the

CD

from

the

unit

will

also

clear

the

poogram.

The

repeat

play

is

cancelled.

(>

disappears.)

To

add

tracks

to

the

program

Before

playing,

repeat

step

2.

The

new

track

will

be

programmed

after

the

last

track.

To

change

the

programmed

tracks

Clear

the

program

and

repeat

all

the

steps.

NOTE

¢

If

the

total

playing

time

of

selected

tracks

exceeds

O9

minutes

and

59

seconds,

or

if

a

track

number

31

«r

higher

is

selected,

the

total

playing

time

of

the

selected

tacks

will

be

represented

by

--:--.

Although

the

total

playingtime

cannot

be

seen,

the

tracks

are

memorized.

¢

During

programmed

play,

the

random

play

cannoibe

selected.

To

repeat

random

play

First

press

the

MODE

button

to

activate

random

play.

Then

press

the

REPEAT

button

so

that

@

lights

up

on

the

display.

EN;

KISH

11

RECORDING

This

section

explains

how

to

record

from

the

radio

or

CD

player.

RADIO/BAND

cD

@REC/RECMUTE

M@ UI

Preparation

¢

Set

the

tape

to

the

point

where

recording

will

start.

¢

Use

Type

I

(normal)

tapes

only.

7

insert

the

tape

to

be

recorded.

Insert

the

tape

with

the

side

to

be

recorded

on

facing

up

and

the

exposed

side

facing

forward.

Insert

with

the

recording

side

up.

2

Press

the

TAPE/REVERSE

MODE

button

to

select

the

reverse

mode.

To

record

on

one

side

only,

select

=.

To

record

on

both

sides,

select

C=

or

C=).

If

the

recording

starts

from

the

reverse

side,

recording

will

be

done

on

this

side

only

even

if

C=

or

C2)

is

selected.

3

Press

one

of

the

function

buttons

and

prepare

the

source

to

be

recorded.

To

record

from

a

CD,

press

the

CD

button

and

load

the

disc,

then

press

the

<4

or

®P

button

to

select

the

track

to

be

recorded

first.

To

record

from

a

radio

broadcast,

press

the

RADIO/

BAND

button

and

tune

in

to

a

station.

4

Press

the

@

REC/REC

MUTE

button

to

start

recording.

REC

on

the

display

flashes.

When

the

selected

function

is

CD,

playback

and

recording

start

simultaneously.

To

stop

recording,

press

the

I

button.

To

pause

recording,

press

the

Il

button.

(Applicable

when

the

source

is

RADIO.)

To

resume

recording,

press

again.

To

record

only

the

selected

tracks

Select

the

tracks

in

the

same

procedure

for

programmed

play

(page

11),

then

start

recording.

12

ENGLISH

NOTE

lf

squealing

or

beating

sounds

occur

when

recording

an

MW

or

LW

broadcast,

press

the

MODE

button

on

the

remote

conirol,

so

as

to

eliminate

the

noise.

Each

time

the

button

is

pressed,

the

dot

light

on

the

display

is

turned

on

and

off.

The

dot

light

INSERTING

BLANK

SPACES

When

recording

from

a

radio

broadcast,

4-second

blank

spaces

can

be

inserted

at

the

desired

point.

This

helps

you

locate

the

desired

portion

on

the

tape

when

it

is

played

back

later

on

another

cassette

deck,

etc.,

having

music

sensor

function.

NOTE

Blank

spaces

cannot

freely

be

inserted

when

recording

from

a

CD

or

tape.

1

Press

the

@

REC/REC

MUTE

button

during

recording

or

while

in

recording

pause

mode.

The

flashing

REC

on

the

display

becomes

quicker

and

the

tape

runs

without

recording

(blank

spaces

are

inserted).

After

4

seconds,

the

tape

pauses

(recording

pause

mode).

To

make

blank

spaces

less

than

4

seconds,

press

the

@

REC/REC

MUTE

button

again

while

REC

flashes

quickly.

To

make

blank

spaces

more

than

4

seconds,

press

the

@

REC/REC

MUTE

button

again

after

the

deck

enters

the

recording

pause mode.

Each

time

it

is

pressed,

a

4-

second

blank

space

is

added.

2

Press

the

II

button

to

resume

recording.

To

erase

a

recording

1

Press

the

TAPE/REVERSE

MODE

button

and

insert

the

tape

to

be

erased.

2

Set

the

tape

to

the

point

where

the

erasure

is

to

be

started.

3

Press

the

@

REC/REC

MUTE

button

to

start

the

erasure.

Sound

adjustment

during

recording

The

output

volume

and

tone

of

the

speakers

or

headphones

may

be

freely

varied

without

affecting

the

level

of

the

recording.

TIMER

PLAY/TIMER

RECORDING

The

unit

can

be

turned

on

at

a

specified

time

every

day

with

the

built-in

timer.

TAPE/REVERSE

MODE

RADIO/BAND

Preparation

Make

sure

the

clock

is

set

correctly.

7

Press

the

TIMER

button

once

for

timer

play

so

that

©

flashes.

Press

the

TIMER

button

twice

for

timer

recording

so

that

©

and

REC

flash.

:

D

vay’

TIMER

O!

Turn

the

VOLUME/TIMER

control

to

adjust

the

timer-on

time.

Press

the

ENTER

button

to

designate

the

timer-

on

time.

Timer-on

time

Prepare

the

source.

To

listen

to

a

CD,

press

the

CD

button

and

load

the

disc.

To

listen

to

a

tape,

press

the

TAPE/REVERSE

MODE

button

and

insert

the

tape.

To

listen

to

the

radio,

press

the

RADIO/BAND

button

and

tune

in

to

a

station.

To

record

from

a

radio

broadcast,

press

the

RADIO/

BAND

button

and

tune

in

to

a

station,

and

insert

the

tape

to

be

recorded

on.

Turn

the

VOLUME/TIMER

control

to

set

the

volume.

Press

the

POWER

button

to

turn

the

unit

off.

When

the

timer-on

time

is

reached,

the

unit

turns

on

and

play

begins

with

the

selected

source.

The

unit

will

turn

off

automatically

after

180

minutes.

NOTE

¢

Timer

play

and

timer

recording

will

not

begin

unless

the

power

is

turned

off.

If

you

used

the

unit

after

setting

the

timer,

prepare

the

source,

adjust

the

volume

and

tone,

then

turn

off

the

power.

¢

Timer

recording

from

a

CD

is

not

possible.

To

check

the

timer-on

time

For

timer

play,

press

the

TIMER

button

once.

For

timer

recording,

press

the

TIMER

button

twice.

The

timer-on

time

is

displayed.

After

checking

the

time,

press

the

ENTER

button

to

restore

the

display.

To

cancel

timer

standby

mode

Press

the

TIMER

button

repeatedly

so

that

©

or

OREC

disappears

on

the

display.

To

restore

the

timer

standby

mode,

press

again

to

display

©

or

®REC.

To

reset

the

timer

Set

the

timer

again

from

the

beginning.

SETTING

THE

SLEEP

TIMER

The

unit

can

be

turned

off

automatically

at

a

specified

time.

7

Press

the

SLEEP

button.

2

Within

4

seconds,

press

the

SLEEP

bution

repeatedly

to

select

the

time

until

the

power

is

turned

off.

Each

time

it

is

pressed,

the

time

changes

between

30

and

180

minutes

as

follows.

Pen

rt

ee]

To

check

the

time

remaining

until

the

power

is

turned

off

Press

the

SLEEP

button

once.

The

remaining

time

is

displayed

for

4

seconds.

ENG

LisH

13

CARE

AND

MAINTENANCE

Occasional

care

and

maintenance

of

the

unit

and

the

software

are

needed

to

optimize

the

performance

of

your

unit.

To

clean

the

cabinet

Use

a

soft

and

dry

cloth.

If

the

surfaces

are

extremely

dirty,

use

a

soft

cloth

lightly

moistened

with

mild

detergent

solution.

Do

not

use

strong

solvents,

such

as

alcohol,

benzine

or

thinner

as

these

could

damage

the

finish

of

the

unit.

To

clean

the

heads

and

tape

paths

After

every

10

hours

of

use,

clean

the

heads

and

tape

paths

with

a

head

cleaning

cassette

or

cotton

swab

moistened

with

cleaning

fluid

or

denatured

alcohol.

(These

cleaning

kits

are

commercially

available.)

When

cleaning

with

a

cotton

swab

@,

wipe

the

heads

@

and

®,

capstans

@,

and

pinchrollers

©.

After

cleaning

the

heads

and

tape

paths

with

a

liquid

head

cleaning

cassette

or

a

moistened

swab,

wait

until

the

cleaned

parts

are

completely

dry

before

inserting

the

tapes.

To

demagnetize

the

heads

The

heads

may

become

magnetized

after

long-term

use.

This

may

narrow

the

output

range

of

recorded

tapes

and

increase

noise.

After

20

to

30

hours

use,

demagnetize

the

heads

with

any

commercially

available

demagnetizer.

Care

of

discs

e

When

a

disc

becomes

dirty,

wipe

the

disc

from

the

centre

out

with

a

cleaning

cloth.

After

playing

a

disc,

store

the

disc

in

its

case.

Do

not

leave

the

disc

in

places

that

are

hot

or

humid.

Care

of

tapes

*

Store

tapes

in

their

cases

after

use.

*

Do

not

leave

tapes

near

magnets,

motors,

television

sets,

Or

any

source

of

magnetism.

This

will

downgrade

the

sound

quality

and

cause

noise.

*

Do

not

expose

tapes

to

direct

sunlight,

or

leave

them

ina

car

parked

in

direct

sunlight.

14

ENGLISH

TROUBLESHOOTING

GUIDE

If

the

unit

fails

to

perform

as

described

in

these

Operating

Instructions,

check

the

following

guide.

GENERAL

There

is

no

sound.

¢

Is

the

AC

cord

connected

properly?

If

you

intend

to

use

the

unit

on

batteries,

are

he

batteries

correctly

inserted?

*

Was

an

incorrect

function

button

pressed?

An

erroneous

display

or

a

malfunction

occirs.

—

Reset

the

unit

as

stated

below.

TUNER

SECTION

The

reception

contains

noise

interferencesor

the

sound

is

distorted.

els the

unit

picking

up

external

noise

or

multipith

distortion?

—

Change

the

orientation

of

the

antenna

or

tie

unit.

—

Move

the

unit

away

from

other

electrical

a)pliances.

CASSETTE

DECK

SECTION

The

tape

does

not

run.

*Is

the

deck

in

pause

mode?

(—

page

7)

The

sound

is

off-balance

or

not

adequatelyhigh.

els

the

playback

head

dirty?

(—

page

14)

Recording

is

not

possible.

¢

Is

the

erasure

prevention

tab on

the

tape

broten

off?

(>

page

7)

els

the

recording

head

dirty?

(+

page

14)

Erasure

is

not

possible.

¢ls the

erasure

head

dirty?

(—

page

14)

¢ls

a

metal

tape

or

CrOz

tape

being

used?

High

frequency

sound

is

not

emitted.

¢

Is

the

recording/playback

head

dirty?

(~

page

14)

The

tape

is

not

removed.

—

If

you

try

to

use

the

unit

when

the

batteries

are

depleted,

the

tape

may

stop

during

play

or

recording

and

the

cassette

holder

will

not

open.

Should

this

occur,

replace

the

batteries

win

new

ones

or

connect

the

supplied

AC

cord

to

the

unit,

then

remove

the

tape.

CD

PLAYER

SECTION

The

CD

player

does

not

play.

els

the

disc

correctly

inserted?

(—

page

10)

els

the

disc

dirty?

(—

page

14)

els the

lens

affected

by

condensation?

—

Wait

approximately

one

hour

and

try

again

=

To

reset

If

an

unusual

condition

occurs

in

the

display

winco

w

or

the

cassette

deck,

reset

the

unit

as

follows.

1

Press

the

POWER

button

to

turn

off

the

power.

2

Press

the

POWER

button

to

turn

the

powerback

on

while

pressing

the

li

button.

Everything

stored

in

memory

after

purchase

is

cancelled.

If

the

power

cannot

be

turned

off

in

step

1

because

of

a

malfunction,

reset

by

disconnecting

the

AC

cord

ard

remove

all

the

batteries,

and

then

repeat

step

2.

SPECIFICATIONS

FM

tuner

section

Tuning

range

Antenna

87.5

MHz

to

108

MHz

Rod

antenna

MW

tuner

section

Tuning

range

531

kHz

to

1602

kHz

(9

kHz

step)

530

kHz

to

1710

kHz

(10

kHz

step)

Antenna

Ferrite

bar

antenna

LW

tuner

section

Tuning

range

Antenna

153

kHz

to

288 kHz

Ferrite

bar

antenna

Cassette

deck

section

Track

format

4

tracks,

2

channels

stereo

Frequency

response

Normal

tape:

50

Hz

—

12500

Hz

Recording

system

AC

bias

Heads

Recording/playback

head

x

1,

Erasure

head

x

1

Compact

disc

player

section

Laser

Semiconductor

laser

(A

=

780

nm)

D-A

converter

1

bit

dual

General

Speakers

100

mm

cone

type

x

2

Power

output

5

W

+5

W

(DIN

MUSIC

POWER)

4.5

W

+

4.5

W

(10%

T.H.D./3.2

Q

DC)

3.3

W

+

3.3

W

(DIN

1%

Rated

Power)

Output

PHONES

(stereo

minijack)

Power

requirements

12

V

DC

using

eight

size

C

(R14)

batteries

230

V

AC,

50

Hz

Power

consumption

22

W

Dimensions

of

main

unit

(W

x

H

x

D)

445

x

168

x

237

mm

Weight

of

main

unit

4.1

kg

not

including

batteries

Accessories

AC

cord

(1)

Remote

control

(1)

¢

Specifications

and

external

appearance

are

subject

to

change

without

notice.

*

Specifications,

trade

mark,

model

name

and

double

square

symbol

[8]

are

marked

on

the

bottom

of

the

unit.

COPYRIGHT

Please

check

the

laws

on

copyright

relating

to

recordings

from

discs,

radio

or

external

tapes

for

the

country

in

which

the

machine

is

being

used.

NOTE

AIWA

CO.

LTD.

-

JAPAN

-

DECLARES

UNDER

ITS

OWN

RESPONSIBILITY

THAT

THE

PRODUCT

DESCRIBED

IN

THIS

MANUAL

IS

IN

COMPLIANCE

WITH

THE

DIRECTIVES

OF

D.M

28.8.95

No.

548,

ACCORDING

TO

THE

STIPULATIONS

OF

PARAGRAPH

3

OF

ATTACHMENT

A

OF

D.M.

25.6.85

AND

PARAGRAPH

3

OF

ATTACHMENT

1

OF

D.M.

27.8.87

(REGULATIONS

REGARDING

FREQUENCIES).

The

above

information

is

only

for

Htaly.

,

ENcEISH

15

PARTS

INDEX

@

TAPE/REVERSE

MODE

(5,

7)

RADIO/BAND

(5,

8,

9)

CD

(5,

10)

©

OPE/BATT

indicator

(4)

©

POWER

(5,

13)

©

3-MODE

EQUALIZER

(6)

@

|

(headphones)

(5)

@O

Disc

compartment

(10)

O

<<,

P

TUNING

+/-

(7,

8,

9,

10)

<4»

PLAY/DIR/PRESET

(7,

9,

10)

@

REC/REC

MUTE

(12)

WM

STOP/CLEAR

(5,

7,

9,

10, 11,

12)

Il

PAUSE/SET

(7,

9,

10,

12)

©

SLEEP

(13)

©

ENTER

(5,

13)

@

VOLUME/TIMER

(5,

6,

13)

@

TIMER

(13)

CLOCK

(5)

®

QSURROUND

(6)

T-BASS

(6)

@®

CD

OPEN

(10)

®

Display

16

ENGLISH

8006

86

O09

18)

Sa

®

DISPLAY

(6)

@

BAND

(8,

9)

@

IE

PAUSE

(7,

9,

10,

12)

@

POWER

(5)

@®

EQ

(6)

@

MODE

(8,

11,

12)

@

Numbered

buttons

(9,

10,

11)

@

REPEAT

(11)

@

FUNCTION

(4)

®

VOL

N/V

(6)

®

</P>

SKIP/SEARCH

(7,

8, 9,

10)

>

PLAY

(4,

7,

9,

10)

W@

STOP

(7,

9,

10,

11,

12)

Aiwa CSD-EL33 User manual
