Aiwa CSD-FD83 User manual

SERVICE MANUAL
DATA
CSD-FD83
CSD-FD85
HA, HR, HT, EZ
HR,EZ,K
COMPACT DISC
STEREO CASSETTE RECORDER
BASIC TAPE MECHANISM : ZZM-1 AR2NC
BASIC CD MECHANISM : CMS-B31TG6
S/M Code No. 09-007-424-9R2
REVISION
 This Service Manual is the Revision Publishing and replaces Simple Manual
CSD-FD 3(HA,EZ) (S/M Code No. 09-003-424-9T2).
 This Service manual does not include Electrical adjustment, IC BLOCK DIAGRAM
and IC DESCRIPTION. These items will be issued in the next supplement.

Tuner section
Frequency range, antenna FM: 87.5 MHz to 108 MHz, Rod antenna
85HR,83HR,83HA,83HT:
AM: 531/530 - 1,602/1,710 kHz
(9/10 kHz step , Ferrite bar antenna
EZ,K:
MW: 531/530 - 1,602/1,710 kHz
(9/10 kHz step , Ferrite bar antenna
LW: 153 - 288 kHz, Ferrite bar antenna
Deck section
Track format 4 tracks, 2 channels
Frequency range Normal tape: 50 - 12,500 Hz(EIAJ
Recording system AC bias
Erasing system Magnet erase
Heads Recording/playback head (1 ,
Erase head (1
CD player section
isc Compact disc
Scanning method Non-contact optical scanner
(semiconductor laser
General
Speaker 100 mm cone type (2 ,
36 mm cone type (2
Output Headphones jack (stereo mini-jack
Power output 85HR:
10W + 10W (EIAJ 5 ohms DC ,
7.2W + 7.2W (DIN 1% Rated Power DC
83EZ:
5W + 5W (DIN MUSIC POWER ,
4.5W + 4.5W (EIAJ 3.2 ohms, T.H.D.
10% , 3.3W + 3.3W (DIN 1% Rated
Power
85EZ,85K:
16W + 16W (DIN MUSIC POWER ,
10W + 10W (EIAJ 5 ohms, T.H.D.
10% , 7.6W + 7.6W (DIN 1% Rated
Power
SPECIFICATIONS
 2 
83HR,83HA,83HT:
4.5W + 4.5W (EIAJ 3.2 ohms, DC ,
3.3W + 3.3W (DIN 1% Rated Power
Power requirements 85HR,83HR,83HA,83HT:
DC 12V using eight size C (R14
batteries, AC 110-120 V/220-240 V
switchable, 50/60 Hz
EZ, K:
DC 12V using eight size C (R14
batteries, AC 230V, 50 Hz
Power consumption 85HR,83HR,83HA,83HT,85EZ,85K:
35W
83HR,83HA,83HT:
22W
imensions (W x H x ) 85HR,85EZ,85K:
460 x 198.3 x 261.2 mm
83EZ,83HR,83HA,83HT:
460 x 191.9 x 261.2 mm
Weight (excluding batteries) 85HR,85EZ,85K:
4.7 kg
83EZ,83HR,83HA,83HT:
4 kg
 Design and specifications are subject to change without notice.
 Manufactured under license from Dolby Laboratories Licensing
Corporation.
DOLBY, the double-D symbol and "PRO LOGIC" are
trademarks of Dolby Laboratories Licensing Corporation.
ACCESSORIES / PACKAGE LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
1 8A-CHE-902-110 IB,LH(ESP)B<83HA>
1 8A-CH4-906-110 IB,EZ(9L)B<83EZ>
1 8A-CH4-901-110 IB,H(ECA)B<83HR>
1 8A-CHE-906-110 IB,EZ(9L)B,FD 85<85EZ>
1 8A-CHE-905-110 IB,K(E)B,FD 85<85K>
1 8A-CHE-901-110 IB,H(ECA)B,FD 85<85HR>
1 8A-CH4-911-110 IB,HT(EC-H)B<83HT>
2 8 -A80-034-010 AC CORD SET ASSY,K<85K>
2 8 -A80-036-010 AC CORD SET ASSY,E<HR,HT,EZ>
2 8 -A80-119-010 AC CORD SET ASSY,AZ<83HA>
3 8 -A91-01 -010 PLUG,CONVERSION<HR,83HA,83HT>
4 8Z-CK4-962-010 RC UNIT,RC-ZAT04
!
!
!
!

This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!!
WHEN SERVICING, DO NOT APPROACH THE LASER
EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS
NECESSARY TO CONFIRM LASER BEAM EMISSION.
BE SURE TO OBSERVE FROM A DISTANCE OF MORE
THAN 30cm FROM THE SURFACE OF THE OBJECTIVE
LENS ON THE OPTICAL PICK UP BLOCK.
Caution: Invisible laser radiation when
open and interlocks defeated avoid
exposure to beam.
Advarsel: Usynlig laserståling ved åbning
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa
mainitulla tavalla saataa altistaa käyt täjän
turvallisuusluokan 1 ylittävälle näkymättömälle
lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som
specificeras i denna bruksanvising, kan användaren
utsättas för osynling laserstrålning, som överskrider
gränsen för laserklass 1.
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
CAUTION
Use of controls or adjustments or performance of proce
dures other than those specified herin may result in
hazardous radiation exposure.
ATTENTION
Lutillisation de commandes, réglages ou procédures
autres que ceux spécifiés peut entraîner une dangereuse
exposition aux radiations.
ADVARSEL
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer
ude af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1
LASER product.
The CLASS 1 LASER PRODUCT label is located on the
rear exterior.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
 3 
PICK-UP ASSY. P.C.B Solder
11315
SHORT
LAND
119753
21416 A12 10 8 6 4
Body or clothes electrostatic potential could
ruin laser diode in the optical block. Be
sure ground body and workbench,
and use care the clothes do not
touch the diode.
1) After the connection, remove solder
shown in the right figure.
Precaution to replace Optical block

ELECTRICAL MAIN PARTS LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
 4 
IC
87-A21-550-010 IC,TA2149N
87-A21-185-040 C-IC,LC72121M
87-A21-090-010 IC,LA4600<83HR,83EZ,83HA,83HT>
87-A21-552-010 IC,LA4663A<85HR,85K,85EZ>
87-A21-520-040 C-IC,M61509FP
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A21-093-010 IC,LA6541D
8A-CH4-661-010 C-IC,LC867132V-5P07
87-A21-245-010 IC,RPM6938-V4
87-A21-431-010 IC, A4560N
TRANSISTOR
89-327-143-080 TR,2SC2714 (0.1W)
87-026-447-080 TR,2SC1740S R
89-111-624-080 TR,2SA1162Y
87-026-213-080 CHIP-TR,DTC114YK
89-503-025-010 C-FET,2SK302GR<85K,83EZ,85EZ>
89-320-011-080 TR,2SC2001K(15W)<85HR,85K,EZ>
87-026-230-080 CHIP-TR,DTA114YK<85K,83EZ,85EZ>
89-327-125-080 CHIP TR,2SC2712GR
89-318-154-080 TR,2SC1815Y(0.4W)
89-112-965-080 TR,2SA1296GR(0.75W)
87-026-463-080 TR,2SA933SRS(0.3W)
87-026-291-080 TR,DTC124XS
89-213-702-080 TR,2S 1370E
89-113-187-080 TR,2SA1318TU
87-026-239-080 C-TR,DTC114TK (0.2W)
87-026-210-080 CHIP-TR,DTC144EKA
87-026-464-080 TR,DTC114TS (0.3W)
DIODE
87-070-345-080 DIODE,IN4148
87-017-072-080 ZENER,HZS3 1
87-027-703-080 ZENER,HZ7A1L (5MA)
87-A40-648-080 ZENER,MTZJ8.2A
87-A40-234-080 ZENER,MTZJ5.6A
87-017-978-080 DIODE,1N4003
87-027-702-080 DIODE,ZENER HZ6C2L (200MA)
87-020-465-080 DIODE,1SS133 (110MA)
87-070-178-090 DIODE,1N5402- D54<85HR,85K,85EZ>
87-A40-465-010 DIODE,FR202<83HR,83EZ,83HA,83HT>
MAIN C.
C211 87-010-805-080 CAP,S 1-16
C212 87-010-805-080 CAP,S 1-16
C215 87-016-460-080 C-CAP,S 0.22-16
C216 87-016-460-080 C-CAP,S 0.22-16
C231 87-010-213-080 C-CAP,S 0.015-50
C232 87-010-213-080 C-CAP,S 0.015-50
C233 87-A10-201-080 C-CAP,S0.33-16 K
C234 87-A10-201-080 C-CAP,S0.33-16 K
C235 87-016-669-080 C-CAP,S 0.1-25 K
C236 87-016-669-080 C-CAP,S 0.1-25 K
C237 87-010-408-080 CAP,ELECT 47-50V<85HR,85K,85EZ>
C237 87-010-371-080 CAP,E 470-6.3<83HR,83EZ,83HA,83HT>
C239 87-010-197-080 CAP,CHIP 0.01 DM
C240 87-010-197-080 CAP,CHIP 0.01 DM
C247 87-010-401-080 CAP,ELECT 1-50V
C248 87-010-401-080 CAP,ELECT 1-50V
C309 87-010-197-080 CAP,CHIP 0.01<85HR,85K,85EZ,83HA>
C310 87-010-248-080 CAP,ELECT 220-10V
C316 87-010-263-080 CAP,ELECT 100-10V<83HR,83HA,83HT>
C317 87-010-197-080 CAP,CHIP 0.01 DM<EXCEPT 83EZ>
C801 87-010-248-080 CAP,ELECT 220-10V
C805 87-012-365-080 C-CAP,S 0.027-25V K
C806 87-012-365-080 C-CAP,S 0.027-25V K
C807 87-010-405-080 CAP,E 10-50<83HR,83EZ,83HA,83HT>
C807 87-010-382-080 CAP,ELECT 22-25V<85HR,85K,85EZ>
C808 87-010-405-080 CAP,E 10-50V<83HR,83EZ,83HA,83HT>
C808 87-010-382-080 CAP,ELECT 22-25V<85HR,85K,85EZ>
C809 87-010-401-080 CAP,ELECT 1-50V
C810 87-010-401-080 CAP,ELECT 1-50V
C811 87-010-178-080 CHIP CAP 1000P
C812 87-010-178-080 CHIP CAP 1000P
C816 87-010-180-080 C-CER 1500P
C817 87-010-180-080 C-CER 1500P
C821 87-010-401-080 CAP,ELECT 1-50V
C822 87-010-401-080 CAP,ELECT 1-50V
C823 87-010-178-080 CHIP CAP 1000P
C824 87-010-178-080 CHIP CAP 1000P
C829 87-010-178-080 CHIP CAP 1000P
C830 87-010-178-080 CHIP CAP 1000P
C834 87-010-248-080 CAP,ELECT 220-10V
C843 87-010-197-080 CAP,CHIP 0.01 DM
C844 87-018-124-080 CAP,CER 270P-50V
C845 87-010-178-080 CHIP CAP 1000P
C846 87-010-263-080 CAP,ELECT 100-10V
C851 87-010-186-080 CAP,CHIP 4700P
C852 87-010-178-080 CHIP CAP 1000P
C853 87-A11-132-080 CAP,TC U 0.01-50 K
CN201 87-099-018-010 CONN,16P<83HR,83EZ,83HA,83HT>
CN201 8A-CHE-621-010 CONN,16P V 6207<85HR,85K,85EZ>
CN801 87-A60-110-010 CONN,4P V S2M-4W
CNA302 8A-CH4-629-010 CONN ASSY,6P MA-TU
CNA803 8A-CH4-623-010 CONN ASSY,2P KEY
FC201 8A-CD9-620-010 FF-CA LE, 16P FR-MAIN
L201 87-003-097-080 COIL,1UH<85HR,85K,85EZ>
L202 87-003-097-080 COIL,1UH<85HR,85K,85EZ>
L203 87-003-097-080 COIL,1UH<85HR,85K,85EZ>
L801 87-007-342-010 COIL,OSC 85K IAS
SW801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01
CD C.
C30 87-010-260-080 CAP,E 47-25V
C251 87-010-404-080 CAP,E 4.7-50V<83HR,83EZ,83HA,83HT>
C263 87-010-178-080 CHIP CAP 1000P<FD83>
C264 87-010-178-080 CHIP CAP 1000P<FD83>
C266 87-010-545-080 CAP,E 0.22-50V<FD83>
C267 87-010-545-080 CAP,E 0.22-50V<FD83>
C271 87-010-237-080 CAP,ELECT 1000-16V<FD83>
C272 87-010-237-080 CAP,ELECT 1000-16V<FD83>
C276 87-010-237-080 CAP,ELECT 1000-16V<85HR,85K,85EZ>
C277 87-010-237-080 CAP,ELECT 1000-16V<85HR,85K,85EZ>
C277 87-010-404-080 CAP,E 4.7-50V<83HR,83EZ,83HA,83HT>
C278 87-010-263-080 CAP,ELECT 100-10V<83EZ>
C279 87-010-405-080 CAP,ELECT 10-50V<83HR,83HA,83HT>
C279 87-010-263-080 CAP,ELECT 100-10V<83EZ>
C281 87-010-263-080 CAP,ELECT 100-10V<85HR,85K,85EZ>
C301 87-010-121-010 CAP,E 6800-25V<85HR,85K,85EZ>
C301 87-016-495-000 CAP,E 3300-25<83HR,83EZ,83HA,83HT>
C302 87-010-265-080 CAP,ELECT 33-16V<85HR,85K,85EZ>
C306 87-010-404-080 CAP,ELECT 4.7-50V
C307 87-010-401-080 CAP,ELECT 1-50V
C308 87-010-221-080 CAP,ELECT 470-10V
C311 87-010-263-080 CAP,ELECT 100-10V
C312 87-010-385-080 CAP,ELECT 220-25V
C321 87-010-197-080 CAP,CHIP 0.01 DM
C322 87-010-263-080 CAP,ELECT 100-10V
C325 87-010-405-080 CAP,ELECT 10-50V
C401 87-010-403-080 CAP,ELECT 3.3-50V
C402 87-010-197-080 CAP,CHIP 0.01 DM
C403 87-010-263-080 CAP,ELECT 100-10V
C404 87-010-248-080 CAP,ELECT 220-10V
*NOTE:<FD83>=83HR,83EZ,83HA,83HT <FD85>=85HR,85K,85EZ

DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
 5 
C405 87-010-197-080 CAP,CHIP 0.01 DM
C406 87-010-374-080 CAP,ELECT 47-10V
C407 87-010-178-080 CHIP CAP 1000P
C408 87-010-198-080 CAP,CHIP 0.022
C409 87-010-248-080 CAP,ELECT 220-10V
C410 87-010-263-080 CAP,ELECT 100-10V
C411 87-A11-177-080 C-CAP,S 0.15-16 K
C412 87-010-401-080 CAP,ELECT 1-50V
C413 87-016-369-080 C-CAP,S 0.033-25 K
C414 87-010-405-080 CAP,ELECT 10-50V
C416 87-010-545-080 CAP,ELECT 0.22-50V
C417 87-012-157-080 C-CAP,S 330P-50 CH
C418 87-010-213-080 C-CAP,S 0.015-50
C419 87-A11-608-080 C-CAP,S 0.33-25 K
C420 87-016-369-080 C-CAP,S 0.033-25 K
C421 87-A11-177-080 C-CAP,S 0.15-16 K
C422 87-010-183-080 C-CAP,S 2700P-50
C423 87-010-956-080 CHIP-CAP,S 0.068-25
C424 87-010-993-080 C-CAP,S 0.056-25
C425 87-010-176-080 C-CAP,S 680P-50 SL
C426 87-A11-608-080 C-CAP,S 0.33-25 K
C428 87-010-197-080 CAP,CHIP 0.01 DM
C429 87-010-186-080 CAP,CHIP 4700P
C430 87-012-156-080 C-CAP,S 220P-50 CH
C431 87-010-545-080 CAP,ELECT 0.22-50V
C432 87-010-374-080 CAP,ELECT 47-10V
C433 87-010-401-080 CAP,ELECT 1-50V
C434 87-010-184-080 CHIP CAPACITOR 3300P(K)
C435 87-010-197-080 CAP,CHIP 0.01 DM
C436 87-010-374-080 CAP,ELECT 47-10V
C437 87-010-404-080 CAP,ELECT 4.7-50V
C438 87-016-669-080 C-CAP,S 0.1-25 K
C439 87-010-178-080 CHIP CAP 1000P
C440 87-010-145-080 C-CAP,S 1P-50 CH
C441 87-010-197-080 CAP,CHIP 0.01 DM
C442 87-010-312-080 C-CAP,S 15P-50 CH
C445 87-012-368-080 C-CAP,S 0.1-50 F
C446 87-012-368-080 C-CAP,S 0.1-50 F
C447 87-012-368-080 C-CAP,S 0.1-50 F
C448 87-010-315-080 C-CAP,S 27P-50 CH
C450 87-012-140-080 CAP 470P
C451 87-012-156-080 C-CAP,S 220P-50 CH
C455 87-010-247-080 CAP,ELECT 100-50V
C457 87-010-312-080 C-CAP,S 15P-50 CH
C458 87-010-312-080 C-CAP,S 15P-50 CH
C459 87-010-263-080 CAP,ELECT 100-10V
C460 87-015-819-080 CAPACITOR,0.01
C461 87-010-197-080 CAP,CHIP 0.01 DM
C462 87-010-248-080 CAP,ELECT 220-10V
C463 87-A11-155-080 CAP,TC U 0.01-16 Z F
C465 87-010-404-080 CAP,ELECT 4.7-50V
C466 87-012-368-080 C-CAP,S 0.1-50 F
C467 87-010-263-080 CAP,ELECT 100-10V
C469 87-012-154-080 C-CAP,S 150P-50 CH
C470 87-010-544-080 CAP,ELECT 0.1-50V
C471 87-010-196-080 CHIP CAPACITOR,0.1-25
C472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C473 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C474 87-010-196-080 CHIP CAPACITOR,0.1-25
C475 87-010-197-080 CAP,CHIP 0.01 DM
C476 87-010-236-080 CAP,E 1000-10 SME
C477 87-010-197-080 CAP,CHIP 0.01 DM
C478 87-010-263-080 CAP,ELECT 100-10V
C479 87-010-197-080 CAP,CHIP 0.01 DM
C480 87-010-221-080 CAP,ELECT 470-10V
C481 87-010-405-080 CAP,ELECT 10-50V
C482 87-010-405-080 CAP,ELECT 10-50V
C489 87-012-368-080 C-CAP,S 0.1-50 F
C490 87-012-368-080 C-CAP,S 0.1-50 F
C491 87-010-197-080 CAP,CHIP 0.01 DM
C492 87-010-221-080 CAP,ELECT 470-10V
C493 87-010-190-080 S CHIP F 0.01
C494 87-A11-155-080 CAP,TC U 0.01-16 Z F
C501 87-012-368-080 C-CAP,S 0.1-50 F
C502 87-010-322-080 C-CAP,S 100P-50 CH
C503 87-010-322-080 C-CAP,S 100P-50 CH
C504 87-010-322-080 C-CAP,S 100P-50 CH
C505 87-010-322-080 C-CAP,S 100P-50 CH
C506 87-010-322-080 C-CAP,S 100P-50 CH
C510 87-016-669-080 C-CAP,S 0.1-25 K
C831 87-010-198-080 CAP,CHIP 0.022
CN202 8A-CH4-693-010 CONN,5P V 2.5
CN203 8A-CH4-687-010 CONN,4P V 2.5<85HR,85K,85EZ>
CN205 87-A60-109-010 CONN,2P V S2M-2W
CN301 8A-CH4-689-010 CONN,3P V 2.5
CN303 8A-CH4-686-010 CONN,2P V 2.5<83HR,83EZ,83HA,83HT>
CN304 8A-CH4-686-010 CONN,2P V 2.5<83HR,83EZ,83HA,83HT>
CN401 87-A60-424-010 CONN,16P V TOC-
CN403 87-099-201-010 CONN,8P 6216 H
CN802 8A-CH4-692-010 CONN,4P H 2.5
CNA204 8A-CHE-631-010 CONN ASSY,6P I-AMP<85HR,85K,85EZ>
CNA212 8A-CHE-632-010 CONN ASSY,6P O-AMP<85HR,85K,85EZ>
CNA402 8A-CD9-625-010 CONN ASSY,6P CD-ME
FC401 8A-CD9-621-010 FF-CA LE, 16P CD-RF
FC403 8A-CD9-622-010 FF-CA LE, 8P CD-FR
L401 87-003-102-080 COIL,10UH
L402 87-003-098-080 COIL,2.2UH<85HR,85K,85EZ>
L404 87-003-152-080 COIL,100UH
R840 87-029-124-010 RES,FUSE 2.2-1/4
SFR430 87-024-437-080 SFR100K,RH063EC
SW205 87-036-389-010 SW,PUSH 1-1-1 R8120125
X401 8Z-CD5-633-010 VI ,CER16.93MHZ FCR16.93M2
POWER AMP C. <85HR,85K,85EZ>
C251 87-010-401-080 CAP,ELECT 1-50V<85HR,85K,85EZ>
C255 87-010-260-080 CAP,ELECT 47-25V<85HR,85K,85EZ>
C263 87-018-121-080 CAP,CER 150P-50V<85HR>
C264 87-018-121-080 CAP,CER 150P-50V<85HR>
C267 87-010-404-980 CAP,E 4.7-50 M SME<85HR,85K,85EZ>
C268 87-010-404-980 CAP,E 4.7-50 M SME<85HR,85K,85EZ>
C269 87-010-384-080 CAP,ELECT 100-25V<85HR,85K,85EZ>
C274 87-018-209-080 CAP,CER 0.1-50V<85HR,85K,85EZ>
C275 87-010-260-080 CAP,ELECT 47-25V<85HR,85K,85EZ>
C278 87-010-378-080 CAP,ELECT 10-16V<85HR,85K,85EZ>
C279 87-010-236-080 CAP,E 1000-10 SME<85HR,85K,85EZ>
C280 87-010-236-080 CAP,E 1000-10 SME<85HR,85K,85EZ>
CN204 8A-CH4-688-010 CONN,6P V 2.5<85HR,85K,85EZ>
CN212 8A-CH4-688-010 CONN,6P V 2.5<85HR,85K,85EZ>
CNA211 8A-CHE-638-010 CONN ASSY,6P S-PWR<85HR,85K,85EZ>
R275 87-025-329-080 RESISTOR, 1/4W 2.2<85HR,85K,85EZ>
R276 87-025-329-080 RESISTOR, 1/4W 2.2<85HR,85K,85EZ>
R277 87-025-329-080 RESISTOR, 1/4W 2.2<85HR,85K,85EZ>
R278 87-025-329-080 RESISTOR, 1/4W 2.2<85HR,85K,85EZ>
FRONT C.
C601 87-010-313-080 CAP,CHIP 18P
C602 87-010-315-080 C-CAP,S 27P-50 CH
C603 87-010-319-080 C-CAP,S 56P-50 CH
C604 87-010-312-080 C-CAP,S 15P-50 CH
C605 87-010-317-080 C-CAP,S 39P-50 CH
C608 87-010-196-080 CHIP CAPACITOR,0.1-25
C610 87-010-555-040 CAP,E 100-10 GAS
C611 87-010-196-080 CHIP CAPACITOR,0.1-25
C612 87-A10-189-040 CAP,E 220-10
C613 87-010-495-040 CAP,E 2.2-50 GAS
C614 87-010-196-080 CHIP CAPACITOR,0.1-25
C615 87-010-493-040 CAP,E 0.47-50 GAS
C616 87-010-494-040 CAP,E 1-50 GAS
*NOTE:<FD83>=83HR,83EZ,83HA,83HT <FD85>=85HR,85K,85EZ

DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
 6 
C617 87-010-178-080 CHIP CAP 1000P
C618 87-010-498-040 CAP,E 10-16 GAS
C620 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C625 87-010-196-080 CHIP CAPACITOR,0.1-25
CN601 87-099-033-010 16P 6216 H
CN602 87-099-201-010 CONN,8P 6216 H
CNA603 8A-CH4-624-010 CONN ASSY,4P TU-FR
JW611 87-003-097-080 COIL,1UH
JW612 87-003-097-080 COIL,1UH
JW637 87-003-097-080 COIL,1UH
LCD601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4
LED602 88-CD6-630-010 LED,934ID RED
LED603 88-CD6-630-010 LED,934ID RED
LED604 88-CD6-630-010 LED,934ID RED
LED606 88-CD6-630-010 LED,934ID RED
LED607 88-CD6-630-010 LED,934ID RED
LED610 88-CD6-630-010 LED,934ID RED
LED611 88-CD6-631-010 LED,934GD GRN
LED612 88-CD6-630-010 LED,934ID RED
S601 87-A91-704-080 SW,TACT EVQ 214 05R
S603 87-A91-704-080 SW,TACT EVQ 214 05R
S604 87-A91-704-080 SW,TACT EVQ 214 05R
S605 87-A91-704-080 SW,TACT EVQ 214 05R
S606 87-A91-704-080 SW,TACT EVQ 214 05R
S607 87-A91-704-080 SW,TACT EVQ 214 05R
S608 87-A91-704-080 SW,TACT EVQ 214 05R
S613 87-A91-704-080 SW,TACT EVQ 214 05R
S621 87-A91-704-080 SW,TACT EVQ 214 05R
S622 87-A91-704-080 SW,TACT EVQ 214 05R
S623 87-A91-704-080 SW,TACT EVQ 214 05R
X601 87-030-273-010 VI ,XTAL 32.768K5PPM
X602 87-030-376-080 VI ,CER CSA5.76MG200
TUNER C.
C1 87-010-312-080 C-CAP,S 15P-50 CH
C2 87-010-316-080 C-CAP,S 33P-50 CH
C3 87-010-312-080 C-CAP,S 15P-50 CH
C5 87-016-669-080 C-CAP,S 0.1-25 K <HR,83HA,83HT>
C5 87-012-360-080 CAP,CER 1-10<85K,83EZ,85EZ>
C6 87-010-313-080 CAP,CHIP 18P<83HR,85HR,83HA,83HT>
C7 87-014-049-080 CAP,PP 470P-100 J
C8 87-012-349-080 C-CAP,S 1000P-50 CH
C10 87-010-197-080 CAP,CHIP 0.01 DM
C11 87-010-197-080 CAP,CHIP 0.01 DM
C12 87-010-197-080 CAP,CHIP 0.01 DM
C13 87-010-150-080 C-CAP,S 6P-50 CH
C14 87-010-303-080 C-CAP,S 330P-50CH
C15 87-010-178-080 CHIP CAP 1000P
C16 87-010-374-080 CAP,ELECT 47-10V
C17 87-010-198-080 CAP,CHIP 0.022
C18 87-015-835-080 C-CAP,0.047 D
C19 87-010-263-080 CAP,ELECT 100-10V
C20 87-010-404-080 CAP,ELECT 4.7-50V
C21 87-010-197-080 CAP,CHIP 0.01 DM
C22 87-010-197-080 CAP,CHIP 0.01 DM
C23 87-010-197-080 CAP,CHIP 0.01 DM
C24 87-010-303-080 C-CAP,S 330P-50CH
C25 87-016-460-080 C-CAP,S 0.22-16
C27 87-A11-067-080 C-CAP,S 1-10 K
C28 87-016-669-080 C-CAP,S 0.1-25 K
C29 87-016-669-080 C-CAP,S 0.1-25 K
C30 87-010-220-080 C-CAP,S 0.018-25
C31 87-010-220-080 C-CAP,S 0.018-25
C33 87-012-358-080 C-CAP,S 0.47-10 F Z
C34 87-012-358-080 C-CAP,S 0.47-10 F Z
C35 87-015-819-080 CAPACITOR,0.01
C36 87-010-263-080 CAP,ELECT 100-10V
C37 87-010-197-080 CAP,CHIP 0.01 DM
C38 87-010-263-080 CAP,ELECT 100-10V
C39 87-010-404-080 CAP,ELECT 4.7-50V
C40 87-010-197-080 CAP,CHIP 0.01 DM
C41 87-010-178-080 CHIP CAP 1000P
C42 87-010-178-080 CHIP CAP 1000P
C43 87-010-178-080 CHIP CAP 1000P
C44 87-010-311-080 CAP 12P
C45 87-010-312-080 C-CAP,S 15P-50 CH
C46 87-010-197-080 CAP,CHIP 0.01 DM
C47 87-010-197-080 CAP,CHIP 0.01 DM
C48 87-010-197-080 CAP,CHIP 0.01 DM
C49 87-012-140-080 CAP 470P
C50 87-010-197-080 CAP,CHIP 0.01 DM
C51 87-010-316-080 C-CAP,S 33P-50 CH<85K,83EZ,85EZ>
C52 87-010-197-080 CAP,CHIP 0.01 DM<85K,83EZ,85EZ>
C53 87-010-197-080 CAP,CHIP 0.01 DM<85K,83EZ,85EZ>
C54 87-014-055-080 CAP,PP 820P-100 J<85K,83EZ,85EZ>
C55 87-010-197-080 CAP,CHIP 0.01 DM<85K,83EZ,85EZ>
C56 87-010-312-080 C-CAP,S 15P-50 CH<85K,83EZ,85EZ>
C71 87-010-197-080 CAP,CHIP 0.01 DM
C72 87-010-263-080 CAP,ELECT 100-10V
C73 87-010-197-080 CAP,CHIP 0.01 DM
C75 87-010-197-080 CAP,CHIP 0.01 DM
C92 87-010-197-080 CAP,CHIP 0.01 DM
C93 87-010-197-080 CAP,CHIP 0.01 DM
CF1 87-A91-094-010 FLTR,CDA10.7 MG80A
CF2 87-008-261-010 FILTER,SFE10.7MA5-A
CF3 87-008-261-010 FILTER,SFE10.7MA5-A
CN2 87-099-854-010 CONN,6P S2M-6W
CN3 87-A60-110-010 CONN,4P V S2M-4W
D3 87-A40-616-070 VARI-CAP,SVC384(S/T)
D4 87-A40-128-080 C-VARI-CAP,HVU202A
D5 87-A40-128-080 C-VARI-CAP,HVU202A
HD1 88-CD6-661-010 HLDR, AR ANT.
HD2 88-CD6-661-010 HLDR, AR ANT.
L2 87-A50-560-010 COIL,FM PF(ACD)
L3 8A-CH4-670-010 AR-ANT,MW 2 -ACH<HR,83HA,83HT>
L3 8A-CH4-671-010 AR-ANT,MW/LW 3 -ACH<85K,EZ>
L4 87-A50-420-010 COIL,MW OSC(SYN)
L5 87-A50-566-010 COIL,FM RF EX(ACH)
L6 87-A50-567-010 COIL,FM OSC(ACH)
L7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK)
L8 87-005-849-080 COIL,10UH(CECS)
L51 87-A50-421-010 COIL,LW OSC(SYN)<85K,83EZ,85EZ>
TC1 87-011-254-080 TRIMER,20P LAR
TC51 87-A91-659-010 TRIMMER,50P 4.0X4.5 <85K,EZ>
X1 87-A70-061-010 VI ,XTAL 4.500MHZ CSA-309
HP C.
C275 87-016-280-080 CAP,E 3.3-50 M P <FD83>
C276 87-016-280-080 CAP,E 3.3-50 M P <FD83>
CN204 8A-CH4-687-010 CONN,4P V 2.5<83HR,83EZ,83HA,83HT>
CNA202 8A-CHE-634-010 CONN ASSY,5P MA-MPUHP<FD85>
CNA203 8A-CH4-628-010 CONN ASSY,5P MA-HP<FD83>
J251 87-A60-569-010 JACK,HTJ-035-18
L283 87-003-098-080 COIL,2.2UH<85HR,85K,85EZ>
KEY C.
CN605 87-A60-109-010 CONN,2P V S2M-2W
S614 87-A91-704-080 SW,TACT EVQ 214 05R
S615 87-A91-704-080 SW,TACT EVQ 214 05R
ATT1 C.
C901 87-018-209-080 CAP, CER 0.1-50V<85HR,85K,85EZ>
C901 87-018-205-080 CAP, CERA-SOL 0.022<FD83>
C902 87-018-209-080 CAP, CER 0.1-50V<85HR,85K,85EZ>
C902 87-018-205-080 CAP, CERA-SOL 0.022<FD83>
C903 87-018-209-080 CAP, CER 0.1-50V<85HR,85K,85EZ>
*NOTE:<FD83>=83HR,83EZ,83HA,83HT <FD85>=85HR,85K,85EZ

!
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
 7 
C903 87-018-205-080 CAP, CERA-SOL 0.022<FD83>
C904 87-018-209-080 CAP, CER 0.1-50V<85HR,85K,85EZ>
C904 87-018-205-080 CAP, CERA-SOL 0.022<FD83>
C905 87-018-209-080 CAP, CER 0.1-50V<85HR,85K,85EZ>
C906 87-018-209-080 CAP, CER 0.1-50V<85HR,85K,85EZ>
C907 87-018-209-080 CAP, CER 0.1-50V<85HR,85K,85EZ>
C908 87-018-209-080 CAP, CER 0.1-50V<85HR,85K,85EZ>
CNA901 8A-CD9-627-010 CONN ASSY,3P PWR<FD83>
CNA901 8A-CHE-637-010 CONN ASSY,3P PWRUHP<85HR,85K,85EZ>
F901 87-035-192-010 FUSE, 4AT 250V T218<85HR,85K,85EZ>
F901 87-035-347-010 FUSE,2.5A 250V T<FD83>
FC901 87-033-213-010 CLAMP,FUSE SMK
FC902 87-033-213-010 CLAMP,FUSE SMK
ATT2 C.
SP C. <83HR,83EZ,83HA,83HT>
CNA204 8A-CH4-633-010 CONN ASSY,4P SP
POWER SAVE SW C. <85HR,85K,85EZ>
S270 87-A91-377-010 SW,PUSH 2-2-2 SPUN192600
SP-L C. <85HR,85K,85EZ>
C291 87-010-627-080 CAP,E 2.2-16 M 5L P SRE
C293 87-010-627-080 CAP,E 2.2-16 M 5L P SRE
CN291 8A-CH4-686-010 CONN,2P V 2.5
SP-R C. <85HR,85K,85EZ>
C292 87-010-627-080 CAP,E 2.2-16 M 5L P SRE
C294 87-010-627-080 CAP,E 2.2-16 M 5L P SRE
CN292 8A-CH4-686-010 CONN,2P V 2.5
AC VOLTAGE SW C. <83HR,85HR,83HA,83HT>
SW901 87-A91-369-010 SW,AC SL 2 2 2
CD MOTOR C.
M1 SJ-310-060-1A0 MOTOR,FEED
SW1 S4-090-001-740 SW,LEAF
PN SJ-370-060-1A0 CONN,WAFER
*NOTE:<FD83>=83HR,83EZ,83HA,83HT <FD85>=85HR,85K,85EZ
DG
S
2SK302
E C B
2SA1296
2SA1318
2SC1815
E C B
2SA933S
2SC1740S
2SC2001
DTC114TS
DTC124XS
B C E
2SB1370
BE
C
2SA1162
2SC2712
2SC2714
DTA114YK
DTC114TK
DTC114YK
DTC144EKA
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
!
!
!
TRANSISTOR ILLUSTRATION
!

SCHEMATIC DIAGRAM  1 (MAIN / CD : 1 / 2 <CSD-FD83>)
 9 
HP C.B

32 31 2930 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
WIRING-2 (MAIN / CD 1 / 2 <CSD-FD85>)
- 10 -
