S E R V I C E M A N U A L
SIMPLE MANUAL
• Replace this Service Manual with ”Revision Publishing” when it is issued.
CSD-ED27
• TYPE: HRJ(S),LH(S),EZ(S)
S/M Code No. 09–994-327-4T2
COMPACT DISK STEREO RADIO
CASSETTE RECORDER
• BASIC TAPE MECHANISM :TN-21ZVC-1812
• BASIC CD MECHANISM :KSM-213 CDM
ELECTRICAL MAIN PARTS LIST - 1
NOTE: The characters in the suffix column indicate the part usage.
HRJ(S) .................XX...................................B..................
LH(S) ..................XX....................................C.................
EZ(S) ..................XX.....................................D................
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 305 87-010-213-080 C-CAP,S 0.015-50 B ABCD................
C 308 87-010-260-080 CAP, ELECT 47-25V ABCD................
C 309 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 304 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 302 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 301 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 303 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 307 87-010-544-080 CAP, ELECT 0.1-50V ABCD................
C 306 87-010-546-080 CAP, ELECT 0.33-50V ABCD................
C 319 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 312 87-010-213-080 C-CAP,S 0.015-50 B ABCD................
C 317 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 318 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 313 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 314 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 315 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 316 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 310 87-010-544-080 CAP, ELECT 0.1-50V ABCD................
C 311 87-010-546-080 CAP, ELECT 0.33-50V ABCD................
C 327 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 324 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 321 87-010-260-080 CAP, ELECT 47-25V ABCD................
C 326 87-010-400-080 CAP, ELECT 0.47-50V ABCD................
C 325 87-010-400-080 CAP, ELECT 0.47-50V ABCD................
C 329 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 322 87-010-402-080 CAP, ELECT 2.2-50V ABCD................
C 320 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 337 87-010-178-080 CHIP CAP 1000P ABCD................
C 330 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 332 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 331 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 333 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 338 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 336 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 335 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 334 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 339 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 341 87-010-178-080 CHIP CAP 1000P ABCD................
C 348 87-010-235-080 CAP,E 470-16 SME ABCD................
C 346 87-010-235-080 CAP,E 470-16 SME ABCD................
C 342 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 345 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 344 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 343 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 347 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 340 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 355 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 351 87-010-401-080 CAP, ELECT 1-50V ABCD................
CN 320 87-049-469-010 CONN,4P V ABCD................
CN 330 87-099-565-010 CONN,6P TUC-P4P-B1 ABCD................
D 301 87-A40-466-080 ZENER,MTZJ2.7A ABCD................
IC 302 87-A20-946-040 C-IC,MM1434XF ABCD................
IC 301 87-A21-111-040 C-IC,M62495FP ABCD................
IC 303 87-A21-193-010 IC,TA8227P ABCD................
J 301 87-009-216-010 JACK, DIA 3.5 ABCD................
Q 301 89-318-154-080 TR,2SC1815 (0.4W) ABCD................
Q 302 89-318-154-080 TR,2SC1815 (0.4W) ABCD................
S 301 87-A90-815-010 SW,PUSH 2-2-6 SPUN19-S-501 ABCD................
C 204 87-010-221-080 CAP, ELECT 470-10V ABCD................
C 206 87-010-248-080 CAP, ELECT 220-10V ABCD................
C 205 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 203 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 202 87-018-209-080 CAP, CER 0.1-50V ABCD................
C 210 87-010-198-080 CAP, CHIP 0.022 ABCD................
C 212 87-010-198-080 CAP, CHIP 0.022 ABCD................
C 213 87-010-248-080 CAP, ELECT 220-10V ABCD................
C 211 87-010-260-080 CAP, ELECT 47-25V ABCD................
C 220 87-016-495-090 CAP,E 3300-25 SMG ABCD................
C 232 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 231 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 230 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 233 87-018-134-080 CAPACITOR,TC-U 0.01-16 ABCD................
C 264 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 265 87-010-236-080 CAP,E 1000-10 SME ABCD................
C 262 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 263 87-010-385-080 CAP, ELECT 220-25V ABCD................
C 261 87-018-209-080 CAP, CER 0.1-50V ABCD................
CN 210 87-049-919-010 CONN,3P EH V WHT ABCD................
CN 220 87-049-469-010 CONN,4P V ABCD................
CN 230 87-A60-915-010 CONN,16P H TSK-B16P-A1 ABCD................
CN 260 87-A60-914-010 CONN,5P H TSK-B05P-A1 ABCD................
D 204 87-017-148-080 ZENER,HZS6A1L ABCD................
D 201 87-017-162-080 ZENER,HZS7C3L ABCD................
D 225 87-027-399-080 ZENER,HZ7A3L (200MA) A...................
D 225 87-027-607-080 ZENER,HZ7B3L .BCD................
D 220 87-070-345-080 DIODE,IN4148 ABCD................
D 221 87-070-345-080 DIODE,IN4148 ABCD................
D 261 87-017-139-010 ZENER,HZS15-2 ABCD................
IC 260 87-070-416-010 IC,NJU7201 L55 ABCD................
Q 207 89-113-184-080 TR,2SA1318T ABCD................
Q 204 89-113-184-080 TR,2SA1318T ABCD................
Q 202 89-213-702-010 TR,2SB1370 (1.8W) ABCD................
Q 205 89-318-154-080 TR,2SC1815 (0.4W) ABCD................
Q 206 89-318-154-080 TR,2SC1815 (0.4W) ABCD................
Q 203 89-318-154-080 TR,2SC1815 (0.4W) ABCD................
Q 210 89-112-965-080 TR,2SA1296 (0.75W) ABCD................
Q 223 87-026-291-080 TR,DTC124XS ABCD................
Q 222 87-026-463-080 TR,2SA933S (0.3W) ABCD................
Q 225 89-318-154-080 TR,2SC1815 (0.4W) ABCD................
Q 260 89-320-011-080 TR,2SC2001 (15W) ABCD................
Q 270 89-112-965-080 TR,2SA1296 (0.75W) ABCD................
R 290 87-029-124-090 RESISTOR, FUSE 1/4W 2.2 ABCD................
C 405 87-010-178-080 CHIP CAP 1000P ABCD................
C 407 87-010-248-080 CAP, ELECT 220-10V ABCD................
C 401 87-012-145-080 CAP, CHIP S 270P CH ABCD................
C 411 87-010-177-080 C-CAP,S 820P-50 SL ABCD................
C 419 87-010-177-080 C-CAP,S 820P-50 SL ABCD................
C 412 87-010-260-080 CAP, ELECT 47-25V ABCD................
C 417 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 418 87-010-402-080 CAP, ELECT 2.2-50V ABCD................
C 410 87-010-402-080 CAP, ELECT 2.2-50V ABCD................
C 416 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 415 87-010-406-080 CAP, ELECT 22-50 ABCD................
C 413 87-012-158-080 C-CAP,S 390P-50 CH ABCD................
C 425 87-010-177-080 C-CAP,S 820P-50 SL ABCD................
C 426 87-010-186-080 CAP,CHIP 4700P ABCD................
C 424 87-010-194-080 CAP, CHIP 0.047 ABCD................
C 428 87-010-260-080 CAP, ELECT 47-25V ABCD................
C 427 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 423 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 422 87-010-406-080 CAP, ELECT 22-50 ABCD................
C 429 87-012-153-080 C-CAP,S 120P-50 CH ABCD................
C 420 87-012-158-080 C-CAP,S 390P-50 CH ABCD................
C 433 87-010-177-080 C-CAP,S 820P-50 SL ABCD................
C 434 87-010-186-080 CAP,CHIP 4700P ABCD................
C 430 87-010-213-080 C-CAP,S 0.015-50 B ABCD................
C 437 87-010-213-080 C-CAP,S 0.015-50 B ABCD................
C 439 87-010-401-010 CAP, ELECT 1-50V ABCD................
C 432 87-010-401-010 CAP, ELECT 1-50V ABCD................
C 435 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 431 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 438 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 436 87-012-153-080 C-CAP,S 120P-50 CH ABCD................
C 442 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 455 87-010-194-080 CAP, CHIP 0.047 ABCD................
CN 410 87-049-469-010 CONN,4P V ABCD................
CN 420 87-009-030-010 CONNECTOR 2P PH M ABCD................
D 408 87-070-345-080 DIODE,IN4148 ABCD................
D 403 87-070-345-080 DIODE,IN4148 ABCD................
D 405 87-070-345-080 DIODE,IN4148 ABCD................
D 402 87-070-345-080 DIODE,IN4148 ABCD................
D 406 87-070-345-080 DIODE,IN4148 ABCD................
D 407 87-070-345-080 DIODE,IN4148 ABCD................
D 410 87-070-345-080 DIODE,IN4148 ABCD................
D 411 87-070-345-080 DIODE,IN4148 ABCD................
IC 420 87-A21-145-040 C-IC,BA4560F-E2 ABCD................
IC 430 87-A21-145-040 C-IC,BA4560F-E2 ABCD................
L 401 87-007-342-010 COIL,OSC 85K BIAS ABCD................
Q 408 87-026-462-080 TR,2SC1740 S(RS 0.3W) ABCD................
Q 407 87-026-463-080 TR,2SA933S (0.3W) ABCD................
Q 406 87-026-463-080 TR,2SA933S (0.3W) ABCD................
Q 409 89-110-155-080 TR,2SA1015(0.4W) ABCD................
Q 401 89-318-155-080 TR,2SC1815 (0.4W) ABCD................
Q 403 89-318-155-080 TR,2SC1815 (0.4W) ABCD................
Q 411 89-110-155-080 TR,2SA1015(0.4W) ABCD................
Q 410 89-318-155-080 TR,2SC1815 (0.4W) ABCD................
Q 421 87-026-496-080 FET,2SJ103GR ABCD................
Q 420 87-026-496-080 FET,2SJ103GR ABCD................
Q 432 89-110-155-080 TR,2SA1015(0.4W) ABCD................
Q 433 89-110-155-080 TR,2SA1015(0.4W) ABCD................
Q 431 89-328-786-080 TR,2SC2878B ABCD................
Q 430 89-328-786-080 TR,2SC2878B ABCD................
C 608 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 603 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 606 87-010-312-080 C-CAP,S 15P-50 CH ABCD................
C 601 87-010-313-080 CAP, CHIP 18P ABCD................
C 602 87-010-315-080 C-CAP,S 27P-50 CH ABCD................
C 607 87-010-317-080 C-CAP,S 39P-50 CH ABCD................
C 605 87-010-319-080 C-CAP,S 56P-50 CH ABCD................
C 609 87-010-384-080 CAP, ELECT 100-25V ABCD................
C 610 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 613 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 611 87-010-385-080 CAP, ELECT 220-25V ABCD................
C 614 87-010-400-080 CAP, ELECT 0.47-50V ABCD................
C 615 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 612 87-010-402-080 CAP, ELECT 2.2-50V ABCD................
C 621 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
ELECTRICAL MAIN PARTS LIST - 2
C 623 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 651 87-010-405-080 CAP, ELECT 10-50V ABCD................
CN 610 87-099-761-010 CONN,23P H 9604 ABCD................
CN 630 87-A60-076-010 CONN,12P H 9604S-12F ABCD................
CN 660 87-A60-916-010 CONN,5P B TSK-B05X-A1 ABCD................
CN 670 87-A60-917-010 CONN,16P B TSK-B16X-A1 ABCD................
D 623 87-020-465-080 DIODE,1SS133 (110MA) ABCD................
IC 601 8Z-CH4-636-010 IC,LC867132V-**** ABCD................
L 603 87-003-102-080 COIL, 10UH ABCD................
L 601 87-003-102-080 COIL, 10UH ABCD................
Q 602 87-026-237-080 CHIP-TR,DTC124XK ABCD................
Q 604 87-026-237-080 CHIP-TR,DTC124XK ABCD................
Q 603 87-026-463-080 TR,2SA933S (0.3W) ABCD................
Q 652 87-026-239-080 TR,DTC114TK (0.2W) ABCD................
Q 651 87-026-239-080 TR,DTC114TK (0.2W) ABCD................
X 601 87-030-273-010 VIB,XTAL 32.768K5PPM ABCD................
X 602 87-030-376-080 VIB,CER CSA5.76MG200 ABCD................
CN 620 87-099-761-010 CONN,23P H 9604 ABCD................
CN 640 87-A60-076-010 CONN,12P H 9604S-12F ABCD................
D 645 87-A40-622-010 LED,L-34HDSL RED ABCD................
D 643 87-A40-622-010 LED,L-34HDSL RED ABCD................
D 644 87-A40-622-010 LED,L-34HDSL RED ABCD................
D 646 87-A40-622-010 LED,L-34HDSL RED ABCD................
D 642 87-A40-623-010 LED,L-34GDSL GRN ABCD................
D 641 87-A40-623-010 LED,L-34GDSL GRN ABCD................
LCD 601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4 ABCD................
Q 612 87-026-464-080 TR,DTC114TS (0.3W) ABCD................
Q 611 87-026-464-080 TR,DTC114TS (0.3W) ABCD................
Q 623 87-026-239-080 TR,DTC114TK (0.2W) ABCD................
Q 624 87-026-239-080 TR,DTC114TK (0.2W) ABCD................
Q 625 87-026-239-080 TR,DTC114TK (0.2W) ABCD................
S 621 87-A90-164-080 SW,TACT SKQAB(N) ABCD................
C 509 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 501 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 504 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 502 87-010-221-080 CAP, ELECT 470-10V ABCD................
C 503 87-010-221-080 CAP, ELECT 470-10V ABCD................
C 507 87-018-209-080 CAP, CER 0.1-50V ABCD................
C 506 87-018-209-080 CAP, CER 0.1-50V ABCD................
C 508 87-A10-381-080 CAP,E 1000-10 RE ABCD................
C 510 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 511 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 516 87-010-545-080 CAP, ELECT 0.22-50V ABCD................
C 515 87-012-157-080 C-CAP,S 330P-50 CH ABCD................
C 513 87-018-209-080 CAP, CER 0.1-50V ABCD................
C 514 87-018-209-080 CAP, CER 0.1-50V ABCD................
C 525 87-010-176-080 C-CAP,S 680P-50 SL ABCD................
C 527 87-010-186-080 CAP,CHIP 4700P ABCD................
C 529 87-010-545-080 CAP, ELECT 0.22-50V ABCD................
C 528 87-012-156-080 C-CAP,S 220P-50 CH ABCD................
C 536 87-010-158-080 C-CAP,S 22P-50 SL ABCD................
C 533 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................
C 538 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 531 87-010-374-080 CAP, ELECT 47-10V ABCD................
C 532 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 539 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 530 87-012-140-080 CAP 470P ABCD................
C 540 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 545 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 549 87-010-198-080 CAP, CHIP 0.022 ABCD................
C 548 87-010-248-080 CAP, ELECT 220-10V ABCD................
C 547 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 546 87-010-374-080 CAP, ELECT 47-10V ABCD................
C 543 87-010-403-080 CAP, ELECT 3.3-50V ABCD................
C 541 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 551 87-010-178-080 CHIP CAP 1000P ABCD................
C 557 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 558 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 556 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 552 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 553 87-010-248-080 CAP, ELECT 220-10V ABCD................
C 554 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 559 87-010-315-080 C-CAP,S 27P-50 CH ABCD................
C 550 87-010-374-080 CAP, ELECT 47-10V ABCD................
C 555 87-010-403-080 CAP, ELECT 3.3-50V ABCD................
C 561 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 566 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 562 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 565 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 560 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 569 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 563 87-012-156-080 C-CAP,S 220P-50 CH ABCD................
C 564 87-018-121-080 CAP, CER 150P-50V ABCD................
C 567 87-018-127-080 CAP, CER 470P-50V ABCD................
C 573 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 572 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 571 87-010-248-080 CAP, ELECT 220-10V ABCD................
C 579 87-010-263-080 CAP, ELECT 100-10V ABCD................
C 576 87-010-312-080 C-CAP,S 15P-50 CH ABCD................
C 575 87-010-312-080 C-CAP,S 15P-50 CH ABCD................
C 574 87-018-134-080 CAPACITOR,TC-U 0.01-16 ABCD................
C 578 87-018-209-080 CAP, CER 0.1-50V ABCD................
C 582 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
ELECTRICAL MAIN PARTS LIST - 3
C 587 87-010-322-080 C-CAP,S 100P-50 CH ABCD................
C 589 87-010-322-080 C-CAP,S 100P-50 CH ABCD................
C 581 87-010-322-080 C-CAP,S 100P-50 CH ABCD................
C 583 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 585 87-010-405-080 CAP, ELECT 10-50V ABCD................
C 580 87-012-153-080 C-CAP,S 120P-50 CH ABCD................
C 584 87-012-156-080 C-CAP,S 220P-50 CH ABCD................
C 586 87-012-156-080 C-CAP,S 220P-50 CH ABCD................
C 593 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 590 87-010-322-080 C-CAP,S 100P-50 CH ABCD................
C 591 87-010-322-080 C-CAP,S 100P-50 CH ABCD................
C 592 87-010-322-080 C-CAP,S 100P-50 CH ABCD................
CN 510 87-099-554-010 CONN,6P TUC-P6X-B1 ABCD................
CN 520 87-A60-424-010 CONN,16P V TOC-B ABCD................
CN 550 87-009-030-010 CONNECTOR 2P PH M _ ABCD................
D 503 87-070-345-080 DIODE,IN4148 ABCD................
D 501 87-070-345-080 DIODE,IN4148 ABCD................
D 502 87-070-345-080 DIODE,IN4148 ABCD................
D 505 87-070-345-080 DIODE,IN4148 ABCD................
D 504 87-070-345-080 DIODE,IN4148 ABCD................
D 510 87-070-345-080 DIODE,IN4148 ABCD................
D 511 87-070-345-080 DIODE,IN4148 ABCD................
IC 501 87-A20-446-010 C-IC,LA9241ML ABCD................
IC 502 87-A20-459-010 C-IC,LC78622ED ABCD................
IC 503 87-A20-856-010 IC,BA6898S ABCD................
L 501 87-003-102-080 COIL, 10UH ABCD................
L 504 87-005-847-080 COIL,2.2UH(CECS) ABCD................
L 502 87-008-372-010 FILTER, EMI BL OIRNI ABCD................
L 505 87-008-372-010 FILTER, EMI BL OIRNI ABCD................
Q 502 87-026-291-080 TR,DTC124XS ABCD................
Q 504 87-026-463-080 TR,2SA933S (0.3W) ABCD................
Q 501 89-112-965-080 TR,2SA1296 (0.75W) ABCD................
Q 503 89-113-184-080 TR,2SA1318T ABCD................
SFR 501 87-024-176-080 SEMI-FIXED RESISTOR, 100K ABCD................
X 501 81-592-641-080 CERALOCK 16.93MHZ ABCD................
C 902 87-A11-132-080 CAP,TC U 0.01-50 K B ABCD................
C 904 87-A11-132-080 CAP,TC U 0.01-50 K B ABCD................
C 903 87-A11-132-080 CAP,TC U 0.01-50 K B ABCD................
C 901 87-A11-132-080 CAP,TC U 0.01-50 K B ABCD................
CN 910 87-049-919-010 CONN,3P EH V WHT ABCD................
D 903 87-A40-465-090 DIODE,FR202 ABCD................
D 904 87-A40-465-090 DIODE,FR202 ABCD................
D 902 87-A40-465-090 DIODE,FR202 ABCD................
D 901 87-A40-465-090 DIODE,FR202 ABCD................
F 901 87-A90-092-080 PROTECTOR,2.5A 491 .BCD................
C 5 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD................
C 6 87-010-312-080 C-CAP,S 15P-50 CH ABCD................
C 6 87-010-313-080 CAP, CHIP 18P ABC.................
C 1 87-010-314-080 C-CAP,S 22P-50V ABCD................
C 8 87-012-349-080 C-CAP,S 1000P-50 CH ABCD................
C 7 87-014-049-080 CAP,PP 470P-100 J ABCD................
C 5 87-A11-067-080 C-CAP,S 1-10 K B ABCD................
C 19 87-010-112-080 CAP, ELECT 100-16V ABCD................
C 13 87-010-150-080 C-CAP,S 6P-50 CH ABCD................
C 17 87-010-198-080 CAP, CHIP 0.022 ABCD................
C 14 87-010-303-080 C-CAP,S 330P-50CH ABCD................
C 16 87-010-380-080 CAP, ELECT 47-16V ABCD................
C 18 87-015-819-080 CAPACITOR,0.01 ABCD................
C 20 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 25 87-016-460-080 C-CAP,S 0.22-16 B ABCD................
C 29 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................
C 28 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................
C 36 87-010-112-080 CAP, ELECT 100-16V ABCD................
C 31 87-010-213-080 C-CAP,S 0.015-50 B .B.D................
C 30 87-010-213-080 C-CAP,S 0.015-50 B .B.D................
C 38 87-010-380-080 CAP, ELECT 47-16V ABCD................
C 33 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 34 87-010-401-080 CAP, ELECT 1-50V ABCD................
C 39 87-010-404-080 CAP, ELECT 4.7-50V ABCD................
C 35 87-015-819-080 CAPACITOR,0.01 ABCD................
C 44 87-010-311-080 CAP 12P ABCD................
C 49 87-012-156-080 C-CAP,S 220P-50 CH ABCD................
C 55 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 53 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 52 87-010-197-080 CAP, CHIP 0.01 DM ABCD................
C 51 87-010-316-080 C-CAP,S 33P-50 CH ABCD................
C 54 87-014-055-080 CAP,PP 820P-100 J ...D................
C 71 87-015-819-080 CAPACITOR,0.01 ABCD................
C 78 87-018-209-080 CAP, CER 0.1-50V ...D................
CF 3 82-785-747-080 CF,MS2 GHY,R ABCD................
CF 2 82-785-747-080 CF,MS2 GHY,R ABCD................
CF 1 87-A91-094-010 FLTR,CDA10.7 MG80A ABCD................
D 6 87-017-072-080 ZENER,HZS3B1 ABCD................
D 1 87-020-465-080 DIODE,1SS133 (110MA) ABCD................
D 2 87-020-465-080 DIODE,1SS133 (110MA) ABCD................
D 5 87-A40-615-070 VARI-CAP,KV1311NT ABCD................
D 4 87-A40-615-070 VARI-CAP,KV1311NT ABCD................
D 3 87-A40-616-070 VARI-CAP,SVC384(S/T) ABCD................
IC 1 87-A21-184-010 IC,TA2104AN ABCD................
IC 2 87-A21-185-040 C-IC,LC72121M ABCD................
L 9 87-005-849-080 COIL,10UH(CECS) ABCD................
L 8 87-005-849-080 COIL,10UH(CECS) ABCD................
L 2 87-A50-347-010 COIL,FM BPF EX ABCD................
ELECTRICAL MAIN PARTS LIST - 4
L 4 87-A50-420-010 COIL,MW OSC(SYN) ABCD................
L 5 87-A50-424-010 COIL,FM RF EX(SYN) ABCD................
L 6 87-A50-427-010 COIL,FM OSC EX(SYN) .BCD................
L 6 87-A50-454-010 COIL,FM OSC U(SYN) A...................
L 3 87-A91-095-010 BAR-ANT,MW FOR 2B(SYN) ABC.................
L 3 87-A91-096-010 BAR-ANT,MW/LW FOR 3B(SYN) ...D................
L 7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK) ABCD................
L 51 87-A50-421-010 COIL,LW OSC(SYN) ...D................
Q 1 89-319-233-080 TR,2SC1923 (0.1W) ABCD................
Q 54 87-026-214-080 TR,DTA114YS (0.3W) ...D................
Q 52 87-026-447-080 TR,2SC1740S R ABCD................
Q 51 87-A30-092-080 FET,2SK439E/F ...D................
Q 53 89-320-011-080 TR,2SC2001 (15W) ...D................
Q 72 87-026-215-080 TR,DTC114YS ABCD................
TC 1 87-011-220-080 TRIMMER CAP 20P VTC ABCD................
TC 51 87-011-233-080 TRIMER,50P VCT54 ...D................
X 1 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 ABCD................
ELECTRICAL MAIN PARTS LIST - 5
NOTE: The characters in the suffix column indicate the part usage.
HRJ(S) .................XX...................................B..................
LH(S) ..................XX....................................C.................
EZ(S) ..................XX.....................................D................
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
84-CD8-083-010 BADGE,AIWA 30.5-5.2 2.5LEAD ABCD................
88-CH6-019-010 PANEL,CD ABCD................
8Z-CDB-006-010 LID,CASS .B..................
8Z-CDB-007-010 LID,BATT ABCD................
8Z-CDB-008-010 WINDOW,CASS ABCD................
8Z-CDB-009-010 WINDOW,CD ABCD................
8Z-CDB-012-010 GRILLE,SPKR L ABCD................
8Z-CDB-013-010 GRILLE,SPKR R ABCD................
8Z-CDB-014-010 ARM,MAIN HANDL ABCD................
8Z-CDB-015-010 COVER, HANDLE ABCD................
8Z-CDB-037-010 LENS,LED ABCD................
8Z-CDB-043-010 LID,CD(U) A...................
8Z-CDB-044-010 LID,CASS(U) A.CD................
8Z-CDB-047-010 CHAS,CD(U) A.CD................
8Z-CDB-048-010 KEY,FUNCT(U) A.CD................
8Z-CDB-051-010 CHAS,CD(LH) ..C.................
8Z-CDB-074-010 LID,CD U (W) ....................
8Z-CDB-075-010 LID,CASS U (W) ....................
8Z-CDB-076-010 LID,BATT U (W) ....................
8Z-CDB-089-010 ARM,MAIN HANDL (W) ....................
8Z-CDB-090-010 COVER, HANDL (W) ....................
8Z-CDB-091-010 CHAS,CD (W) ....................
8Z-CDB-092-010 GRILLE,SPKR L (W) ....................
8Z-CDB-093-010 GRILLE,SPKR R (W) ....................
8Z-CHB-006-010 WINDOW,LCD(U) A...................
8Z-CHB-007-010 WINDOW,LCD(EX) .BCD................
8Z-CHB-015-010 CABI,REAR(U) ABC.................
8Z-CHB-016-010 PANEL,FRONT(U) ABCD................
8Z-CHB-018-010 CABI,REAR (EZ) ...D................
8Z-CHB-030-010 LID,CD ABC.................
8Z-CHB-036-010 CABI,FRONT U (W) ....................
8Z-CHB-037-010 CABI,REAR U (W) ....................
8Z-CDB-016-010 KEY,VOL ABCD................
8Z-CDB-017-010 KEY,FUNCTION .B..................
8Z-CDB-018-010 KEY,CASS REC ABCD................
8Z-CDB-019-010 KEY,CASS PAUSE ABCD................
8Z-CDB-020-010 KEY,CASS PLAY ABCD................
8Z-CDB-021-010 KEY,CASS STOP ABCD................
8Z-CDB-022-010 KEY,CASS FF ABCD................
8Z-CDB-023-010 KEY,CASS REW ABCD................
8Z-CDB-024-010 KEY,Q-SOUND ABCD................
8Z-CDB-025-010 KEY,EQ ABCD................
8Z-CDB-026-010 KEY,CD A ABCD................
8Z-CDB-027-010 KEY,CD B ABCD................
8Z-CDB-077-010 KEY,CASS REC (W) ....................
8Z-CDB-078-010 KEY,CASS PAUSE (W) ....................
8Z-CDB-079-010 KEY,CASS PLAY (W) ....................
8Z-CDB-080-010 KEY,CASS STOP (W) ....................
8Z-CDB-081-010 KEY,CASS FF (W) ....................
8Z-CDB-082-010 KEY,CASS REW (W) ....................
8Z-CDB-083-010 KEY,EQ (W) ....................
8Z-CDB-084-010 KEY,VOL (W) ....................
82-CD8-212-010 SPR-T,CAM CD ABCD................
84-CD5-215-010 GEAR ABCD................
84-CD5-216-010 BRACKET ABCD................
84-CT5-209-010 PLATE,MAGNET ABCD................
87-036-368-010 MAGNET ABCD................
87-A90-147-010 COVER,AC SEL SW .BC.................
87-CD7-206-010 DOOR,CD LOCKER ABCD................
87-CD7-207-010 HLDR,LOCKER ABCD................
88-CD8-209-010 SPR-C,BATT ABCD................
88-CD8-222-010 SPR-P,DAMP CD ABCD................
88-CD9-207-010 COVER, AC SOCKET ABCD................
88-CD9-210-010 BASE,CHUCK ABCD................
88-CD9-211-010 RING,CHUCK ABCD................
88-CT6-206-010 CUSHION,CD ABCD................
8Z-CD8-215-010 HLDR,BAR ANT ABCD................
8Z-CDB-204-010 HLDR,KEY FUNC ABCD................
8Z-CDB-208-010 HLDR,SPKR ABCD................
8Z-CDB-210-010 SPR-T,LID CASS ABCD................
8Z-CDB-211-010 SPR-T,LID CD ABCD................
8Z-CDB-212-010 HLDR,PWB ABCD................
8Z-CDB-215-010 HLDR,LID CD ABCD................
8Z-CDB-222-010 PLATE,FM ABCD................
8Z-CHB-207-010 HLDR,LCD ABCD................
87-251-091-410 U+3-3 ABCD................
87-261-032-410 V+2-3 GLD ABCD................
87-261-096-410 SCREW,V+3-10 GLD ABCD................
87-651-035-410 VT1 2-6 GLD ABCD................
87-661-096-410 SCREW,VFT1+3-10 ABCD................
87-741-074-410 UT2+2.6-8 ABCD................
87-741-096-410 UT2+3-10 ABCD................
87-741-102-410 UT2+3-20 ABCD................
87-745-094-410 UT2+3-6 ABCD................
MECHANICAL PARTS LIST - 1
87-751-034-410 SCREW VT2+2-5 ABCD................
87-B10-102-010 UT2+3-15 W/O ABCD................
81-590-677-010 SWITCH LEAF ABCD................
87-043-116-010 ANT,WHIP ABCD................
87-A60-177-010 JACK,AC U W/SW A...................
87-A60-178-010 JACK,AC E W/SW .BCD................
87-A90-146-010 SW,SL 1-1-2 .BC.................
8Z-CDB-620-010 PT,U A...................
8Z-CDB-621-010 PT,E ...D................
8Z-CDB-622-010 PT,H .BC.................
8Z-CHB-619-010 FF-CABLE, 12P 1.25 140MM FRONT ABCD................
8Z-CHB-620-010 FF-CABLE, 23P 1.25 140MM DISP ABCD................
8Z-CHB-622-010 FF-CABLE, 16P 1.0 150MM CD-RF ABCD................
8Z-CHB-625-010 WIRE ASSY,260 26 FM-ANT ABCD................
CNA 680 8Z-CHB-621-010 CONN ASSY,9P CD ABCD................
SP 2 88-CD8-622-010 SPKR,F 77 7OHM 3W ABCD................
SP 1 88-CD8-622-010 SPKR,F 77 7OHM 3W ABCD................
MECHANICAL PARTS LIST - 2
ACCESSORIES LIST
NOTE: The characters in the suffix column indicate the part usage.
HRJ(S) .................XX...................................B..................
LH(S) ..................XX....................................C.................
EZ(S) ..................XX.....................................D................
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CHB-906-010 IB,LH(ESP)FM ..C.................
8Z-CHB-907-010 IB,H(ECA)FM .B..................
8Z-CHB-908-010 IB,EZ(9L)FM ...D................
8Z-CHB-915-010 IB,U(ESF)B ....................
8Z-CHB-916-010 IB,LH(ESP)B ....................
8Z-CHB-917-010 IB,H(ECA)B ....................
8Z-CHB-918-010 IB,EZ(9L)B ....................
8Z-CHB-925-010 IB,U(ESF)FM A...................
87-099-789-010 PLUG,ADPTR IR44 .BC.................
87-A80-081-010 AC CORD SET ASSY,EZ BLK .BCD................
87-A80-109-010 AC CORD,HK7281 BLK U A...................
Printed in Singapore
Tokyo Japan
4
931196
Other manuals for CSD-ED27
4
Table of contents
Other Aiwa Cassette Player manuals
