Aiwa CSD-A100 User manual

SERVICE MANUAL
DATA
BASIC TAPE MECHANISM : ZZM-1 YR2NP
BASIC CD MECHANISM : DA11T3C
COMPACT DISC STEREO
CASSETTE RECEIVER
CSD-A100
S/M Code No. 09-003-342-2R6
G(S),V(S)
REVISION
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-003-342-2T6).
All manuals and user guides at all-guides.com
all-guides.com

2
SPECIFICATIONS
GSC MODEL VSC MODEL
REF. NO PART NO. KANRI DESCRIPTION
NO.
ACCESSORIES/PACKAGE LIST
1 8A-CDA-904-010 IB,G(E)FM<GSC>
1 8A-CDA-907-010 IB,V(ER)FM<VSC>
! 2 87-050-076-010 AC CORD SET ASSY,E<VSC>
! 2 87-A80-144-010 AC CORD SET ASSY,G BLK<GSC>
•
Design and specifications are subject to change without
notice.
•
Design and specifications are subject to change without
notice.
All manuals and user guides at all-guides.com

3
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-
ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
tävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL
PICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
Precaution to replace Optical block
(SF-P101NR)
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder
1
16
TO/FROM CD C.B
PICK UP ASSY
SF-P101NR
All manuals and user guides at all-guides.com

4
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
87-A20-955-010 IC,LA1828
87-A21-064-010 IC,LA4227
87-A21-443-040 C-IC,M62495AFP
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A20-856-010 IC,BA6898S
8A-CD9-610-010 C-IC,LC865516A-5P16
87-A21-607-010 IC,NJM14558LD
TRANSISTOR
89-327-143-080 TR,2SC2714 (0.1W)
87-026-447-080 TR,2SC1740S R
87-026-463-080 TR,2SA933S (0.3W)
87-A30-288-040 C-TR,DTC114YKA
89-318-154-080 TR,2SC1815 (0.4W)
89-112-965-080 TR,2SA1296 (0.75W)
87-026-291-080 TR,DTC124XS
89-213-702-010 TR,2SB1370 (1.8W)
87-026-462-080 TR,2SC1740 S(RS 0.3W)
89-109-332-380 TR,2SA933RS
89-113-187-080 TR,2SA1318TU
87-A30-436-040 C-TR,DTC144TKA
89-317-403-080 TR,2SC1740S
87-A30-287-040 C-TR,DTC114TKA
87-026-464-080 TR,DTC114TS (0.3W)
DIODE
87-020-465-080 DIODE,1SS133 (110MA)
87-A40-916-040 C-VARI-CAP,HVC202A
87-A40-650-080 ZENER,MTZJ6.8A
87-A40-912-040 C-DIODE,HSC277B-TRF<VSC>
87-070-345-080 DIODE,IN4148
87-A40-648-080 ZENER,MTZJ8.2A
87-A40-234-080 ZENER,MTZJ5.6A
87-017-978-080 DIODE,1N4003
87-017-932-080 ZENER,MTJ6.2B
87-A40-465-010 DIODE,FR202
MAIN C.B
C211 87-A11-177-080 C-CAP,S 0.15-16 K B
C212 87-A11-177-080 C-CAP,S 0.15-16 K B
C215 87-016-460-080 C-CAP,S 0.22-16 B
C216 87-016-460-080 C-CAP,S 0.22-16 B
C231 87-010-213-080 C-CAP,S 0.015-50 B
C232 87-010-213-080 C-CAP,S 0.015-50 B
C233 87-A10-201-080 C-CAP,S0.33-16 KB
C234 87-A10-201-080 C-CAP,S0.33-16 KB
C235 87-016-669-080 C-CAP,S 0.1-25 K B
C236 87-016-669-080 C-CAP,S 0.1-25 K B
C237 87-010-371-080 CAP, ELECT 470-6.3V
C239 87-010-197-080 CAP, CHIP 0.01 DM
C240 87-010-197-080 CAP, CHIP 0.01 DM
C247 87-010-401-080 CAP, ELECT 1-50V
C248 87-010-401-080 CAP, ELECT 1-50V
C310 87-010-248-080 CAP, ELECT 220-10V
C316 87-010-263-080 CAP, ELECT 100-10V
C317 87-015-819-080 CAPACITOR,0.01
C801 87-010-248-080 CAP, ELECT 220-10V
C805 87-012-365-080 C-CAP,S 0.027-25VBK
C806 87-012-365-080 C-CAP,S 0.027-25VBK
C807 87-010-405-080 CAP, ELECT 10-50V
C808 87-010-405-080 CAP, ELECT 10-50V
C809 87-010-401-080 CAP, ELECT 1-50V
C810 87-010-401-080 CAP, ELECT 1-50V
C811 87-010-178-080 CHIP CAP 1000P
C812 87-010-178-080 CHIP CAP 1000P
C816 87-010-180-080 C-CER 1500P
C817 87-010-180-080 C-CER 1500P
C821 87-010-401-080 CAP, ELECT 1-50V
C822 87-010-401-080 CAP, ELECT 1-50V
C829 87-010-178-080 CHIP CAP 1000P
C830 87-010-178-080 CHIP CAP 1000P
C833 87-018-195-080 CAP, CER 1200P-16V
C834 87-010-248-080 CAP, ELECT 220-10V
C843 87-010-197-080 CAP, CHIP 0.01 DM
C844 87-018-124-080 CAP, CER 270P-50V
C845 87-010-178-080 CHIP CAP 1000P
C846 87-010-263-080 CAP, ELECT 100-10V
C851 87-010-186-080 CAP,CHIP 4700P
C852 87-010-178-080 CHIP CAP 1000P
C853 87-A11-132-080 CAP,TC U 0.01-50 K B
CN201 87-099-018-010 CONN,16P
CN801 87-A60-110-010 CONN,4P V S2M-4W
CNA302 8A-CDA-629-010 CONN ASSY,6P MA-TU
L801 87-007-342-010 COIL,OSC 85K BIAS
SW801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01
CD C.B
C30 87-010-260-080 CAP, ELECT 47-25V
C251 87-010-404-080 CAP, ELECT 4.7-50V
C261 87-010-402-080 CAP, ELECT 2.2-50V
C262 87-010-402-080 CAP, ELECT 2.2-50V
C263 87-010-178-080 CHIP CAP 1000P
C264 87-010-178-080 CHIP CAP 1000P
C265 87-010-263-080 CAP, ELECT 100-10V
C266 87-010-263-080 CAP, ELECT 100-10V
C267 87-010-112-080 CAP, ELECT 100-16V
C268 87-010-112-080 CAP, ELECT 100-16V
C271 87-010-237-080 CAP, ELECT 1000-16V
C272 87-010-237-080 CAP, ELECT 1000-16V
C278 87-010-405-080 CAP, ELECT 10-50V
C279 87-010-385-080 CAP, ELECT 220-25V
! C301 87-016-495-000 CAP,E 3300-25 M SMG
C306 87-010-404-080 CAP, ELECT 4.7-50V
C307 87-010-401-080 CAP, ELECT 1-50V
C308 87-010-221-080 CAP, ELECT 470-10V
C311 87-010-374-080 CAP, ELECT 47-10V
C312 87-010-385-080 CAP, ELECT 220-25V
C321 87-010-197-080 CAP, CHIP 0.01 DM
C322 87-010-263-080 CAP, ELECT 100-10V
C325 87-010-405-080 CAP, ELECT 10-50V
C401 87-010-403-080 CAP, ELECT 3.3-50V
C402 87-010-197-080 CAP, CHIP 0.01 DM
C403 87-010-263-080 CAP, ELECT 100-10V
C404 87-010-248-080 CAP, ELECT 220-10V
C405 87-010-197-080 CAP, CHIP 0.01 DM
C406 87-010-374-080 CAP, ELECT 47-10V
C407 87-010-178-080 CHIP CAP 1000P
C408 87-010-198-080 CAP, CHIP 0.022
C409 87-010-248-080 CAP, ELECT 220-10V
C410 87-010-263-080 CAP, ELECT 100-10V
C411 87-A11-177-080 C-CAP,S 0.15-16 K B
C412 87-010-401-080 CAP, ELECT 1-50V
C413 87-016-369-080 C-CAP,S 0.033-25 B K
C414 87-010-405-080 CAP, ELECT 10-50V
C416 87-010-545-080 CAP, ELECT 0.22-50V
C417 87-012-157-080 C-CAP,S 330P-50 CH
C418 87-010-213-080 C-CAP,S 0.015-50 B
C419 87-A11-608-080 C-CAP,S 0.33-25 K B
C420 87-016-369-080 C-CAP,S 0.033-25 B K
C421 87-A11-177-080 C-CAP,S 0.15-16 K B
C422 87-010-184-080 CHIP CAPACITOR 3300P(K)
C423 87-010-992-080 C-CAP,S 0.047-25 B
C425 87-010-176-080 C-CAP,S 680P-50 SL
C426 87-A11-608-080 C-CAP,S 0.33-25 K B
All manuals and user guides at all-guides.com

5
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C428 87-010-197-080 CAP, CHIP 0.01 DM
C429 87-010-186-080 CAP,CHIP 4700P
C430 87-012-156-080 C-CAP,S 220P-50 CH
C431 87-010-545-080 CAP, ELECT 0.22-50V
C432 87-010-374-080 CAP, ELECT 47-10V
C433 87-010-401-080 CAP, ELECT 1-50V
C434 87-010-184-080 CHIP CAPACITOR 3300P(K)
C435 87-010-197-080 CAP, CHIP 0.01 DM
C436 87-010-374-080 CAP, ELECT 47-10V
C437 87-010-404-080 CAP, ELECT 4.7-50V
C438 87-016-669-080 C-CAP,S 0.1-25 K B
C439 87-010-178-080 CHIP CAP 1000P
C440 87-010-145-080 C-CAP,S 1P-50 CH
C441 87-010-197-080 CAP, CHIP 0.01 DM
C442 87-010-313-080 CAP, CHIP 18P
C445 87-012-368-080 C-CAP,S 0.1-50 F
C446 87-012-368-080 C-CAP,S 0.1-50 F
C447 87-012-368-080 C-CAP,S 0.1-50 F
C448 87-010-315-080 C-CAP,S 27P-50 CH
C450 87-012-140-080 CAP 470P
C451 87-012-156-080 C-CAP,S 220P-50 CH
C455 87-010-247-080 CAP, ELECT 100-50V
C457 87-010-312-080 C-CAP,S 15P-50 CH
C458 87-010-312-080 C-CAP,S 15P-50 CH
C459 87-010-263-080 CAP, ELECT 100-10V
C460 87-015-819-080 CAPACITOR,0.01
C461 87-010-197-080 CAP, CHIP 0.01 DM
C462 87-010-248-080 CAP, ELECT 220-10V
C463 87-010-197-080 CAP, CHIP 0.01 DM
C465 87-010-404-080 CAP, ELECT 4.7-50V
C466 87-012-368-080 C-CAP,S 0.1-50 F
C467 87-010-263-080 CAP, ELECT 100-10V
C469 87-012-154-080 C-CAP,S 150P-50 CH
C471 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C473 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C474 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C475 87-010-197-080 CAP, CHIP 0.01 DM
C476 87-010-236-080 CAP,E 1000-10 SME
C477 87-010-197-080 CAP, CHIP 0.01 DM
C478 87-010-263-080 CAP, ELECT 100-10V
C479 87-010-197-080 CAP, CHIP 0.01 DM
C480 87-010-221-080 CAP, ELECT 470-10V
C481 87-010-405-080 CAP, ELECT 10-50V
C482 87-010-405-080 CAP, ELECT 10-50V
C489 87-012-368-080 C-CAP,S 0.1-50 F
C490 87-012-368-080 C-CAP,S 0.1-50 F
C491 87-010-197-080 CAP, CHIP 0.01 DM
C492 87-010-221-080 CAP, ELECT 470-10V
C494 87-010-197-080 CAP, CHIP 0.01 DM
C501 87-012-368-080 C-CAP,S 0.1-50 F
C502 87-010-322-080 C-CAP,S 100P-50 CH
C503 87-010-322-080 C-CAP,S 100P-50 CH
C504 87-010-322-080 C-CAP,S 100P-50 CH
C505 87-010-322-080 C-CAP,S 100P-50 CH
C506 87-010-322-080 C-CAP,S 100P-50 CH
C510 87-016-669-080 C-CAP,S 0.1-25 K B
C831 87-010-198-080 CAP, CHIP 0.022
CN202 8A-CH4-689-010 CONN,3P V 2.5
CN205 87-A60-109-010 CONN,2P V S2M-2W
CN301 8A-CH4-689-010 CONN,3P V 2.5
CN401 87-A60-424-010 CONN,16P V TOC-B
CN403 87-099-201-010 CONN,8P 6216 H
CN802 8A-CH4-687-010 CONN,4P V 2.5
CNA402 8A-CDA-625-010 CONN ASSY,6P CD-ME
L401 87-003-102-080 COIL, 10UH
L404 87-003-152-080 COIL, 100UH
R840 87-029-124-010 RES,FUSE 2.2-1/4
SFR430 87-024-437-080 SFR100K,RH063EC
X401 8Z-CD5-633-010 VIB, CER16.93MHZ FCR16.93M2
FRONT C.B
C601 87-010-313-080 CAP, CHIP 18P
C602 87-010-315-080 C-CAP,S 27P-50 CH
C603 87-010-319-080 C-CAP,S 56P-50 CH
C604 87-010-317-010 CHIP CAP,S 39P CH
C605 87-010-264-040 CAP,E 100-10 5L
C606 87-012-368-080 C-CAP,S 0.1-50 F
C607 87-015-779-010 CHIP CAPACITOR, 0.01
C608 87-010-415-080 CAP ELE SRE 10-50V
C609 87-010-493-080 CAP,E 0.47-50 GAS
C611 87-A10-189-040 CAP,E 220-10
C613 87-012-368-080 C-CAP,S 0.1-50 F
C614 87-010-312-080 C-CAP,S 15P-50 CH
C627 87-015-779-010 CHIP CAPACITOR, 0.01
C628 87-015-779-010 CHIP CAPACITOR, 0.01
C629 87-015-779-010 CHIP CAPACITOR, 0.01
C630 87-010-264-040 CAP,E 100-10 5L
C631 87-015-779-010 CHIP CAPACITOR, 0.01
CN601 87-099-757-010 CONN,16P 9604S F
CN602 87-A60-079-010 CONN,08P H 9604S-08F
CNA604 8A-CDA-623-010 CONN ASSY,7P KEY
JW603 87-008-372-080 FILTER, EMI BL OIRNI
JW605 87-003-097-080 COIL,1UH
JW606 87-003-097-080 COIL,1UH
JW608 87-003-097-080 COIL,1UH
JW627 87-008-372-080 FILTER, EMI BL OIRNI
JW633 87-003-098-080 COIL,2.2UH
L601 87-003-098-080 COIL,2.2UH
LED611 87-CD8-616-010 LED,SA36-11 HWA-11.0
S601 87-A91-704-080 SW,TACT EVQ 214 05R
S602 87-A91-704-080 SW,TACT EVQ 214 05R
S603 87-A91-704-080 SW,TACT EVQ 214 05R
S604 87-A91-704-080 SW,TACT EVQ 214 05R
S605 87-A91-704-080 SW,TACT EVQ 214 05R
S611 87-A91-704-080 SW,TACT EVQ 214 05R
X601 87-030-273-010 VIB,XTAL 32.768K5PPM
X602 87-030-376-080 VIB,CER CSA5.76MG200
TUNER C.B
C1 87-010-314-080 C-CAP,S 22P-50V<GSC>
C1 87-010-313-080 CAP, CHIP 18P<VSC>
C2 87-010-316-080 C-CAP,S 33P-50 CH
C3 87-010-314-080 C-CAP,S 22P-50V<GSC>
C3 87-010-313-080 CAP, CHIP 18P<VSC>
C4 87-010-148-080 CAP, CHIP S 4P-50 C CH<VSC>
C5 87-010-378-080 CAP, ELECT 10-16V
C7 87-012-154-080 C-CAP,S 150P-50 CH<VSC>
C7 87-012-156-080 C-CAP,S 220P-50 CH<GSC>
C8 87-010-992-080 C-CAP,S 0.047-25 B<VSC>
C8 87-010-197-080 CAP, CHIP 0.01 DM<GSC>
C9 87-010-311-080 CAP 12P<GSC>
C9 87-010-154-080 CAP CHIP 10P<VSC>
C10 87-010-197-080 CAP, CHIP 0.01 DM
C11 87-010-327-080 C-CAP,S 4P-50 UJ<VSC>
C11 87-010-152-080 C-CAP,S 8P-50 CH<GSC>
C12 87-010-314-080 C-CAP,S 22P-50V
C13 87-010-322-080 C-CAP,S 100P-50 CH
C14 87-010-148-080 CAP, CHIP S 4P-50 C CH
C15 87-016-669-080 C-CAP,S 0.1-25 K B
C16 87-010-178-080 CHIP CAP 1000P<GSC>
C17 87-016-669-080 C-CAP,S 0.1-25 K B
C18 87-016-669-080 C-CAP,S 0.1-25 K B<VSC>
C18 87-010-198-080 CAP, CHIP 0.022<GSC>
C19 87-016-669-080 C-CAP,S 0.1-25 K B
C20 87-010-400-080 CAP, ELECT 0.47-50V
C21 87-010-403-080 CAP, ELECT 3.3-50V
C22 87-010-197-080 CAP, CHIP 0.01 DM
C24 87-010-189-080 C-CAP,S 8200P-50 B<VSC>
All manuals and user guides at all-guides.com

6
REF. NO PART NO. KANRI DESCRIPTION
NO. REF. NO PART NO. KANRI DESCRIPTION NO.
C25 87-010-189-080 C-CAP,S 8200P-50 B<VSC>
C26 87-012-358-080 C-CAP,S 0.47-10 F Z
C27 87-012-358-080 C-CAP,S 0.47-10 F Z
C28 87-010-992-080 C-CAP,S 0.047-25 B<VSC>
C28 87-010-992-080 C-CAP,S 0.047-25 B<GSC>
C29 87-010-992-080 C-CAP,S 0.047-25 B<GSC>
C29 87-010-992-080 C-CAP,S 0.047-25 B<VSC>
C30 87-010-248-080 CAP, ELECT 220-10V
C31 87-010-379-080 CAP, ELECT 22-16V
C32 87-010-197-080 CAP, CHIP 0.01 DM
C33 87-010-197-080 CAP, CHIP 0.01 DM
C34 87-010-197-080 CAP, CHIP 0.01 DM
C35 87-010-197-080 CAP, CHIP 0.01 DM
C36 87-010-263-080 CAP, ELECT 100-10V
C37 87-010-197-080 CAP, CHIP 0.01 DM
C38 87-010-197-080 CAP, CHIP 0.01 DM<GSC>
C41 87-010-321-080 CHIP CAPACITOR,82P(J)<GSC>
C42 87-010-150-080 C-CAP,S 6P-50 CH<GSC>
C44 87-012-140-080 CAP 470P<GSC>
C51 87-010-197-080 CAP, CHIP 0.01 DM
C52 87-010-316-080 C-CAP,S 33P-50 CH<VSC>
C53 87-010-341-080 C-CAP,S47P-50UJ<VSC>
C54 87-010-197-080 CAP, CHIP 0.01 DM<VSC>
C56 87-010-331-080 C-CAP,S 8P-50 UJ<VSC>
C57 87-010-197-080 CAP, CHIP 0.01 DM<VSC>
C61 87-010-318-080 C-CAP,S 47P-50 CH<VSC>
CF1 87-A90-128-010 FLTR,AM IF CFAL-455
CF2 87-008-261-010 FILTER, SFE10.7MA5-A
CF3 87-008-261-010 FILTER, SFE10.7MA5-A
CN2 87-A60-116-010 CONN,6P H S2M-6WR
L2 87-A50-560-010 COIL,FM BPF(ACD)
L3 8A-CD9-660-010 BAR-ANT,MW 2B-ACD(COI)<VSC>
L3 8A-CD9-661-010 BAR-ANT,MW/LW 3B-ACD(COI)<GSC>
L4 87-A50-562-010 COIL,FM RF EX(ACD)<GSC>
L4 87-A50-647-010 COIL,FM2 RF V(ACD)<VSC>
L5 87-A50-564-010 COIL,FM OSC EX(ACD)<GSC>
L5 87-A50-649-010 COIL,FM2 OSC V(ACD)<VSC>
L6 87-A50-337-010 COIL,AM OSC (TOKO)<VSC>
L7 87-A50-579-010 COIL,AM IFT(ACD)
L8 87-A50-335-010 COIL,FM IFT (TOKO)
L9 87-A50-577-010 COIL,FM DET(ACD)
L10 87-005-849-080 COIL,10UH(CECS)
L16 87-A50-569-010 COIL,LW OSC-ACD(COI)<GSC>
L17 87-A50-337-010 COIL,AM OSC (TOKO)<GSC>
L52 87-A50-648-010 COIL,FM1 RF V(ACD)<VSC>
L53 87-A50-650-010 COIL,FM1 OSC V(ACD)<VSC>
PVC1 87-A91-635-010 TUN-CAP,20P-140P E-ACD(MITSUMI
<GSC>
PVC1 87-A91-169-010 TUN-CAP,40P-140P FA-22124 AN00
<VSC>
SW1 87-A91-884-010 SW,SL-4-4 SK44D01G6A<VSC>
SW1 87-A91-549-010 SW,SL-6-4 SK64D01G06<GSC>
TC5 87-011-253-080 TRIMER,30P LAR<GSC>
TC6 87-011-253-080 TRIMER,30P LAR<GSC>
TC51 87-011-253-080 TRIMER,30P LAR<VSC>
TC52 87-011-253-080 TRIMER,30P LAR<VSC>
HP C.B
CN204 87-A60-685-010 CONN,4P H WHT EH
CN605 87-A60-117-010 CONN,7P H S2M-7WR
CNA203 8A-CDA-628-110 CONN ASSY,4P MA-HP
J251 87-A60-569-010 JACK,HTJ-035-18
S606 87-A90-696-080 SW,TACT TS2103-03-430
S607 87-A90-696-080 SW,TACT TS2103-03-430
S608 87-A90-696-080 SW,TACT TS2103-03-430
S614 87-A90-696-080 SW,TACT TS2103-03-430
S615 87-A90-696-080 SW,TACT TS2103-03-430
BATT1 C.B
C901 87-010-192-080 C-CAP,S 0.022-50 F
C902 87-010-192-080 C-CAP,S 0.022-50 F
C903 87-010-192-080 C-CAP,S 0.022-50 F
C904 87-010-192-080 C-CAP,S 0.022-50 F
CNA901 8A-CDA-627-010 CONN ASSY,3P PWR
! PR901 87-A90-092-080 PROTECTOR,2.5A 491
SP901 87-CD6-213-010 SPR-C,BATT (-)
SP902 87-CD6-213-010 SPR-C,BATT (-)
BATT2 C.B
SP903 87-CD6-213-010 SPR-C,BATT (-)
SP904 87-CD6-213-010 SPR-C,BATT (-)
MOTOR C.B
M2 9X-262-576-910 MOTOR GEAR ASSY
PIN3 91-564-722-110 CONNECTOR 6P
SW1 91-572-085-120 LEAF SW
All manuals and user guides at all-guides.com
all-guides.com

87
• Regarding connectors, they are not stocked as they are not the initial order items.
The connectors are available after they are supplied from connector manufacturers upon the order is received.
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
IC BLOCK DIAGRAM
IC, M62495AFP
AUTO RESET
IC, BA6898S
IC, LA1828 IC, NJM14558L
A OUTPUT
A– INPUT
A+ INPUT
V–
B+ INPUT
B– INPUT
B OUTPUT
V+
AB
All manuals and user guides at all-guides.com

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
K
109
WIRING-1 (MAIN/CD)
R318 R317
R8200
R8190
C317
All manuals and user guides at all-guides.com

1211
SCHEMATIC DIAGRAM-1 (MAIN)
C239, C240
IC203
R203, R204
R205, R206
*:0.01
M62495AFP
6.8K
1.2K
MTJ6.2B
1N4148100
MTZJ6.8A
100
D810
1SS133 D809
1SS133
C484
220P
C483 220P
270
270
R236
3.9k
R217 JR
R218 JR
2.2k
R838 JR
R311
JR R312 JR
C280
JR
C281
JR
R822
22k
R821
22k
R820 8.2k R819 8.2k
1/4W
R808 220
1/4W
IC801 NJM14558LD
(TO DECK CHASSIS)
JW129 1k
LED606
6224-10ID RED
LED607
6224-10ID RED
J901
DRY BATTERY
R14X8
DC 12V
1/4W
1/4W
AC230V 50Hz
All manuals and user guides at all-guides.com

1413
SCHEMATIC DIAGRAM-2 (CD)
All manuals and user guides at all-guides.com

1234567
A
B
C
D
E
F
G
H
I
J
K
WIRING-2 (MOTOR)
PIN3
M3
SW1
_
+
M2
M3
(SPINDLE MOTOR)
SW1
(INSIDE LIMIT SW)
M2
(SLED MOTOR)
TO B CD C.B CNA402
H MOTOR C.B
_+
1615
TRANSISTOR ILLUSTRATION
E
B
C
ECB ECB ECB
BCE
2SC2714
DTC114TK
DTC114YK
DTC124XK
DTC144TK
2SA1296
2SC1815 2SA933
2SC1740
DTC114TS
DTC124XS
2SA1318
2SB1370
All manuals and user guides at all-guides.com
all-guides.com

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
K
1817
WIRING-3 (FRONT/HP/BATT1/BATT2)
JW604
AC230V 50Hz
C627
C628
C629
C630
C631
All manuals and user guides at all-guides.com

2019
SCHEMATIC DIAGRAM-3 (FRONT)
CN602
CONN, 8P H 9604S-08F
NM
NM
NM
NM
NM
JW604
4.7k
6224
NM
NM
6224
NM
NM NM NM
NM
NM
NM
NM
JW605 1 H
JW606 1 H
+
C630
100 10V
C629
0.01
JW603
FB
C631 0.01
DTC114TK
JR604 4.7k
JR605 4.7k
JW615 1k JW614 1k JW613 1k
C627 0.01
JW608
1 H
JW633 2.2 H
JW627 FB
C628
0.01
All manuals and user guides at all-guides.com

1234567
A
B
C
D
E
F
G
H
I
J
K
WIRING-4 (TUNER: VSC)
2221
1234567
A
B
C
D
E
F
G
H
I
J
K
WIRING-5 (TUNER: GSC)
C038
All manuals and user guides at all-guides.com

2423
SCHEMATIC DIAGRAM-4 (TUNER: VSC) SCHEMATIC DIAGRAM-5 (TUMER: GSC)
FM BALANCE ADJ.
470
#
FM BPF
JW
FM RFEX
L005 FM OSC EX
CH
C038
0.01
HVC202A
All manuals and user guides at all-guides.com

2625
< TUNER SECTION >
(VSC MODEL)
1. AM Freq. Range Adjustment
L006 ....................................................................... 530kHz
TC003................................................................... 1605kHz
2. AM Tracking Adjustment
L003 ....................................................................... 603kHz
TC004................................................................... 1404kHz
3. AM IF Adjustment
Settings: • Test point: IC001 (LA1828) 19PIN
• Adjustment location: L007
Method: Adjust L007 so that the output level at 1400kHz
becomes maximum.
4. FM Freq. Range Adjustment
L053 .....................................................................65.0MHz
TC052...................................................................74.0MHz
5. FM1 Tracking Adjustment
L052 .....................................................................65.0MHz
TC051...................................................................74.0MHz
6. FM2 Freq. Range Adjustment
L005 .....................................................................87.5MHz
TC001.................................................................108.0MHz
7. FM2 Tracking Adjustment
L004 .....................................................................88.0MHz
TC002.................................................................108.0MHz
8. FM IF Adjustment
Settings: • Test point: IC001 (LA1828) 19PIN
• Adjustment location: L008
Method: Adjust L008 so that the output level at 98.0MHz
becomes balanced.
9. FM Balance Adjustment
Settings: • Test point: IC001 (LA1828) 19PIN
• Adjustment location: L009
Method: Adjust L009 so that the output level at 98.0MHz
becomes balanced.
(GSC MODEL)
1. LW Freq. Range Adjustment
L016 ....................................................................... 150kHz
TC005..................................................................... 285kHz
2. MW Freq. Range Adjustment
L017 ....................................................................... 530kHz
TC003................................................................... 1605kHz
3. MW Tracking Adjustment
L003 ....................................................................... 603kHz
TC004................................................................... 1404kHz
4. LW Tracking Adjustment
TC006..................................................................... 288kHz
5. AM IF Adjustment
Settings: • Test point: IC001 (LA1828) 19PIN
• Adjustment location: L007
Method: Adjust L007 so that the output level at 1400kHz
becomes maximum.
6. FM Freq. Range Adjustment
L005 .....................................................................87.5MHz
TC001.................................................................108.0MHz
7. FM Tracking Adjustment
L004 .....................................................................88.0MHz
TC002.................................................................108.0MHz
8. FM IF Adjustment
Settings: • Test point: IC001 (LA1828) 19PIN
• Adjustment location: L008
Method: Adjust L008 so that the output level at 98.0MHz
becomes balanced.
9. FM Balance Adjustment
Settings: • Test point: IC001 (LA1828) 19PIN
• Adjustment location: L009
Method: Adjust L009 so that the output level at 98.0MHz
becomes balanced.
< DECK SECTION >
10. Tape Speed Adjustment
Settings : • Test tape : TTA–100
• Test point : J251 (PHONES jack)
• Adjustment location : SFR of deck motor
Method : Play back the test tape and adjust SFR so that
the frequency counter reads 3000Hz ± 30Hz.
11. Head Azimuth Adjustment
Settings : • Test tape : TTA–320
• Test point : J251 (PHONES jack)
• Adjustment location : Azimuth adjustment
screw
Method : Play back the 8kHz signal of the test tape and
adjust screw so that the output becomes
maximum.
12. Bias frequncy Adjustment
L801..................................................................85kHz±0.5kHz
< CD SECTION >
13. FE Balance Adjustment
Settings : • Test point : IC401 PIN58 (VR), IC401 PIN 20
(FE)
• Adjustment location : SFR430
Method : Playback the disc and adjust SFR430 so that the
test point voltage becomes 0V.
ELECTRICAL ADJUSTMENT
!
RPH
0
M1 (TAPE MOTOR)
MAIN C.B
A
L801
IC801
CN201
CN801
@
IC404
IC001
SFR430 #
CN401
CD C.B
B
TUNER C.B
(VSC MODEL)
D
1
7
2
123
83 96
L009
TC051
L006
L053
L052 TC052
PVC001
TC1TC2
TC4 TC3
L005
L007
L008
L004
L003
(BAR ANT)
5
IC001
19
TUNER C.B
(GSC MODEL)
D
7
3
4
4
21
85 96
L009
L016 L017
TC006
TC005
PVC001
TC1
TC2
TC4 TC3
L005
L007
L008
L004
L003
(BAR ANT)
19
PHONES
J251
H.P. C.B
E
0!
All manuals and user guides at all-guides.com
all-guides.com

27
PRACTICAL SERVICE FIGURE
< TUNER SECTION >
< FM1 SECTION > (VSC)
Sensitivity: Less than 20dB (65.0MHz)
(THD 3%) Less than 18dB (70.0MHz)
Less than 20dB (74.0MHz)
Signal to Noise Ratio: More than 60dB (at 70.0MHz)
(Input 60dB)
Distortion: Less than 2.0% (at 70.0MHz)
(Input 60dB)
Intermediate frequency: 10.7MHz ±0.1MHz
< FM2 SECTION > (VSC/GSC)
Sensitivity: Less than 18dB (87.5MHz)
(THD 3%) Less than 18dB (98.0MHz)
Less than 18dB (108.0MHz)
Signal to Noise Ratio: More than 60dB (at 98.0MHz)
(Input 60dB)
Distortion: Less than 2.0% (at 98.0MHz)
(Input 60dB)
Intermediate frequency: 10.7MHz ±0.1MHz
Stereo separation: More than 25dB (at 98.0MHz)
< AM SECTION > (VSC/GSC)
Sensitivity: Less than 48dB (at 603kHz)
(S/N 10dB) Less than 46dB (at 999kHz)
Less than 44dB (at 1404kHz)
Distortion: Less than 3.0%
(Input 74dB)
Intermediate frequency: 455kHz±3.5kHz
< LW SECTION > (GSC)
Sensitivity: Less than 60dB (at 153kHz)
(S/N 10dB) Less than 56dB (at 198kHz)
Less than 52dB (at 288kHz)
Signal to Noise Ratio: More than 30dB
Distortion: Less than 3.0% (at 198kHz)
(Input 80dB)
< CASSETTE SECTION > (VSC/GSC)
Tape speed: 3000Hz+3%-2%
Wow & flutter: Less than 0.35% (JIS RMS)
S/N ratio: More than 35dB
Distortion: Less than 3.0% (PB)
Noise (PB): Less than 1mV
(DC, MIN)
Less than 1.2mV (AC, MIN)
Erasing Ratio (W/O FILTER): More than 45dB
All manuals and user guides at all-guides.com

28
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30, 31
32, 33
34
35
IC, LA9241ML
Pin No. Pin Name I/O Description
IC DESCRIPTION
FIN2
FIN1
E
F
TB
TE-
TE
TESI
SCI
TH
TA
TD-
TD
JP
TO
FD
FD-
FA
FA-
FE
FE-
AGND
NC
SP
SPG
SP-
SPD
SLEQ
SLD
SL-, SL+
JP-, JP+
TGL
TOFF
I
I
I
I
I
I
O
I
I
I
O
I
I
I
O
O
I
I
I
O
I
—
—
O
I
I
O
I
O
I
I
I
I
Pin to which external pickup photo diode is connected. RF signal is created by adding
with the FIN1 pin signal. FE signal is created by subtracting from the FIN1 pin signal.
Pin to which external pickup photo diode is connected.
Pin to which external pickup photo diode is connected. TE signal is created by
subtracting from the F pin signal.
Pin to which external pickup photo diode is connected.
DC component of the TE signal is input.
Pin to which external resistor setting the TE signal gain is connected between the TE
pin.
TE signal output pin.
TES “Track Error Sense” comparator input pin. TE signal is passed through a band-
pass filter then input.
Shock detection signal input pin.
Tracking gain time constant setting pin.
TA amplifier output pin.
Pin to which external tracking phase compensation constants are connected between
the TD and VR pins.
Tracking phase compensation setting pin.
Tracking jump signal (kick pulse) amplitude setting pin.
Tracking control signal output pin.
Focusing control signal output pin.
Pin to which external focusing phase compensation constants are connected between
the FD and FA pins.
Pin to which external focusing phase compensation constants are connected between
the FD– and FA– pins.
Pin to which external focusing phase compensation constants are connected between
the FA and FE pins.
FE signal output pin.
Pin to which external FE signal gain setting resistor is connected between the FE pin.
Analog signal GND.
No connection.
Signal ended output of the CV+ and CV- pin input signal.
Pin to which external spindle gain setting resistor in 12 cm mode is connected.
Pin to which external spindle phase compensation constants are connected together
with SPD pin.
Spindle control signal output pin.
Pin to which external sled phase compensation constants are connected.
Sled control signal output pin.
Sled advance signal input pin from microprocessor.
Tracking jump signal input pin from DSP.
Tracking gain control signal input from DSP. Low gain when TGL = H.
Tracking off control signal input pin from DSP. Off when TOFF = H.
All manuals and user guides at all-guides.com

29
Pin No. Pin Name I/O Description
36
37
38
39, 40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
TES
HFL
SLOF
CV–, CV+
RFSM
RFS-
SLC
SLI
DGND
FSC
TBC
NC
DEF
CLK
CL
DAT
CE
DRF
FSS
VCC2
REFI
VR
LF2
PH1
BH1
LDD
LDS
VCC1
O
O
I
I
O
I
O
I
—
O
I
—
O
I
I
I
I
O
I
—
—
O
I
I
I
O
I
—
Pin from which TES signal is output to DSP.
“High Frequency Level”is used to judge whether the main beam position is on top of
bit or on top of mirror.
Sled servo off control input pin.
CLV error signal input pin from DSP.
RF output pin.
RF gain setting and EFM signal 3T compensation constant setting pin together with
RFSM pin.
“Slice Level Control”is the output pin which controls the RF signal data slice level by
DSP.
Input pin which control the data slice level by the DSP.
Digital system GND.
Output pin to which external focus search smoothing capacitor is connected.
“Tracking Balance Control”EF balance variable range setting pin.
No connection.
Disc defect detector output pin.
Reference clock input pin. 4.23 MHz of the DSP is input.
Microprocessor command clock input pin.
Microprocessor command data input pin.
Microprocessor command chip enable input pin.
“Detect RF”RF level detector output.
“Focus Search Select”focus search mode (± search/+ search) select pin.
Servo system and digital system Vcc pin.
Pin to which external bypass capacitor for reference voltage is connected.
Reference voltage output pin.
Disc defect detector time constant setting pin.
Pin to which external capacitor for RF signal peak holding is connected.
Pin to which external capacitor for RF signal bottom holding is connected.
APC circuit output pin.
APC circuit input pin.
RF system Vcc pin.
All manuals and user guides at all-guides.com

30
1
2
3
4
5
6
7
8
9
10
11
12, 13
14
15
16
17
18
19, 20
21
22
23
24
25
26
27
28
29
30
31
32, 33
34
35
36
37
38
39
40
41
42
Pin No. Pin Name I/O Description
DEFI
TAI
PDO
VVSS
ISET
VVDD
FR
VSS
EFMO
EFMIN
T2
CLV+, CLK-
___
V/P
HFL
TES
TOFF
TGL
JP+, JP-
PCK
FSEQ
VDD
SL+
SL-
—
PUIN
_______
RW
EMPH
C2F
DOUT
T3, T4
N.C.
MUTEL
LVDD
LCHO
LVSS
RVSS
RCHO
RVDD
MUTER
I
I
O
—
I
—
I
—
O
I
I
O
O
I
I
O
O
O
O
O
—
O
O
—
I
O
O
O
O
I
—
O
—
O
—
—
O
—
O
Defect sense signal (DEF) input pin. (Connect to 0V when not used).
Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V.
Phase comparator output pin to control external VCO.
For PLL. GND pin for built-in VCO. Be sure to connect to 0V.
Pin to which external resistor adjusting the PD0 output current.
Power supply pin for built-in VCO.
Pin for VCO frequency range adjustment.
Digital system GND. Be sure to connect to 0V.
For slice level control. EFM signal output pin.
EFM signal input pin.
Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V.
Disc motor control output. Three level output is possible using command.
Rough servo or phase control automatic selection monitoring output pin. Rough servo
at H. Phase servo at L.
Track detect signal input pin. Schmidt input.
Tracking error signal input pin. Schmidt input.
Tracking OFF output pin.
Tracking gain selection output pin. Gain boost at L.
Track jump control signal output pin. Three level output is possible using command.
EFM data playback clock monitoring pin 4.3218 MHz when phase is locked in.
Sync signal detection output pin. H when the sync signal which is detected from EFM
signal and thesync signal which is internally generated agree.
Digital system power supply pin.
Moves the sled to outer circumference.
Moves the sled to inner circumference.
Not connected.
CD pickup inner switch detection.
Read, wright signal.
De-emphasis monitor output pin. De-emphasis disc is being played back at H.
C2 flag output pin.
DIGITAL OUT output pin. (EIAJ format).
Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V.
Not used. Set the pin to open.
L-channel mute output pin.
L-channel 1-bit DAC. L-channel power supply pin.
L-channel output pin.
L-channel GND. Be sure to connect to 0V.
R-channel GND. Be sure to connect to 0V.
R-channel 1-bit DAC. R-channel output pin.
R-channel power supply pin.
R-channel mute output pin.
IC, LC78622ED
All manuals and user guides at all-guides.com
