S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
•If requiring information about the CD mechanism, see Service Manual of
4ZG-1, S/M Code No. 09-983-249-3OT.
XR-MT1000
• BASIC TAPE MECHANISM: 2ZM–3MK2 YPR4N
• BASIC CD MECHANISM: 4ZG–1 Z3DSHNM • TYPE: U
S/M Code No. 09–985–272–5FP
STEREO SYSTEM
AMPLIFIER CASSETTE
DECK GRAPHIC EQUALIZER CD PLAYER SPEAKERS REMOTE
CONTROL
MX-NMT1000 RC-7AS09
SX-NMT1000
SX-R275
SX-C605
DX-NM1000FX-NM1000 GE-NMT1000

ELECTRICAL MAIN PARTS LIST - 1/8 (MX-NMT1000)
NOTE: The characters in the suffix column indicate the part usage.
U ......................XX..................................A...................
REF.NO PARTS NO. DESCRIPTION SUFFIX
C 209 87-010-071-040 CAP,E 1-50 5L A...................
C 201 87-010-192-080 C-CAP,S 0.022-50 F A...................
C 207 87-010-194-080 CAP, CHIP 0.047 A...................
C 205 87-010-194-080 CAP, CHIP 0.047 A...................
C 202 87-010-264-040 CAP,E 100-10 5L A...................
C 206 87-010-405-040 CAP,E 10-50 A...................
C 203 87-010-490-040 CAP, ELECT 0.1-50 A...................
C 208 87-A10-189-040 CAP,E 220-10 A...................
C 204 87-A10-586-040 CAP,E 47-35 7L SR A...................
C 211 87-012-140-080 CAP 470P A...................
C 222 87-010-401-040 CAP,E 1-50 SME A...................
C 220 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 221 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 241 87-010-178-080 CHIP CAP 1000P A...................
C 248 87-010-192-080 C-CAP,S 0.022-50 F A...................
C 243 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 244 87-010-316-080 C-CAP,S 33P-50 CH A...................
C 242 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 247 87-016-669-080 C-CAP,S 0.1-25 K B A...................
D 201 87-017-931-080 ZENER,MTZJ5.6B A...................
D 202 87-A40-468-080 C-DIODE,HSM2836CTR A...................
D 205 87-A40-470-080 DIODE,1SS254 A...................
D 203 87-A40-470-080 DIODE,1SS254 A...................
D 243 87-A40-470-080 DIODE,1SS254 A...................
D 241 87-A40-470-080 DIODE,1SS254 ....................
D 240 87-A40-470-080 DIODE,1SS254 ....................
D 244 87-A40-470-080 DIODE,1SS254 A...................
IC 202 87-A20-914-010 IC,SPS-442-1-F A...................
IC 201 88-SP1-609-010 IC,UPD780228-XXXX A...................
Q 201 87-A30-087-080 C-FET,2SK2158 A...................
Q 220 87-A30-071-080 C-TR,RT1N 144C A...................
Q 241 87-026-263-080 C-TR,RN1410 A...................
Q 240 87-A30-074-080 C-TR,RT1P 141C A...................
SW 201 87-A90-535-010 SW,RTRY EC16B24304 A...................
X 201 87-A70-075-080 VIB,CER 4.19MHZ CRHF A...................
C 608 87-010-166-080 C-CAP,S 100P-50 SL A...................
C 604 87-010-166-080 C-CAP,S 100P-50 SL A...................
C 602 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 603 87-010-186-080 CAP,CHIP 4700P A...................
C 605 87-010-321-080 CHIP CAPACITOR,82P(J) A...................
C 601 87-010-405-040 CAP,E 10-50 A...................
C 609 87-010-545-040 CAP,E 0.22-50 SME A...................
C 610 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 614 87-010-248-040 CAP,E 220-10 SME A...................
C 615 87-010-378-040 CAP,E 10-16 A...................
C 611 87-010-406-040 CAP,E 22-50 SME A...................
C 619 87-016-526-080 C-CAP,S 0.47-16 BK A...................
CN 601 87-099-212-010 CONN,5P 6216 V A...................
D 600 87-A40-470-080 DIODE,1SS254 A...................
FB 601 87-008-372-080 FILTER, EMI BL OIRNI A...................
IC 601 87-017-888-080 IC,NJM4558MD A...................
J 602 87-A60-284-010 JACK,3.5MO (MSC) A...................
J 601 87-A60-284-010 JACK,3.5MO (MSC) A...................
Q 600 87-A30-087-080 C-FET,2SK2158 A...................
C 804 87-010-159-080 C-CAP,S 27P-50 SL A...................
C 805 87-010-159-080 C-CAP,S 27P-50 SL A...................
C 802 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 801 87-010-263-040 CAP,E 100-10 A...................
C 803 87-010-405-040 CAP,E 10-50 A...................
C 806 87-016-526-080 C-CAP,S 0.47-16 BK A...................
D 801 87-070-136-080 ZENER,MTZJ5.1B A...................
D 802 87-A40-470-080 DIODE,1SS254 A...................
IC 801 88-NF5-615-040 C-IC,MSM6654A-521GS-KR1 A...................
X 801 87-A70-075-080 VIB,CER 4.19MHZ CRHF A...................
C 0 87-010-374-080 CAP, ELECT 47-10V ....................
C 503 87-010-180-080 C-CER 1500P A...................
C 504 87-010-180-080 C-CER 1500P A...................
C 513 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 514 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 511 87-010-405-080 CAP, ELECT 10-50V A...................
C 512 87-010-405-080 CAP, ELECT 10-50V A...................
C 519 87-012-142-080 CAP, S 0.33-16 A...................
C 522 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 521 87-010-194-080 CAP, CHIP 0.047 A...................
C 520 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 523 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 535 87-010-195-080 C-CAP,S 0.068-25 F A...................
C 537 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 534 87-010-263-080 CAP, ELECT 100-10V A...................
C 533 87-010-263-080 CAP, ELECT 100-10V A...................
C 538 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 539 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 531 87-010-405-080 CAP, ELECT 10-50V A...................
C 536 87-012-142-080 CAP, S 0.33-16 A...................
C 545 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 542 87-010-314-080 C-CAP,S 22P-50V A...................

ELECTRICAL MAIN PARTS LIST - 2/8 (MX-NMT1000)
C 541 87-010-314-080 C-CAP,S 22P-50V A...................
C 540 87-010-314-080 C-CAP,S 22P-50V A...................
D 532 87-A40-438-080 ZENER,MTZJ4.7A A...................
D 531 87-A40-438-080 ZENER,MTZJ4.7A A...................
IC 501 87-A20-954-040 C-IC,M62445FP-601 A...................
87-022-200-080 RESISTOR, METAL 0.56 1W A...................
C 0 87-012-157-080 C-CAP,S 330P-50 CH ....................
C 109 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 105 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 108 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 106 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 107 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 101 87-016-520-090 CAP,E 3300-65 A...................
C 102 87-016-520-090 CAP,E 3300-65 A...................
C 103 87-016-658-090 CAP,E 4700-35 SMG A...................
C 104 87-016-658-090 CAP,E 4700-35 SMG A...................
C 110 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 111 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 112 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 116 87-010-247-080 CAP, ELECT 100-50V A...................
C 113 87-010-247-080 CAP, ELECT 100-50V A...................
C 119 87-010-260-080 CAP, ELECT 47-25V A...................
C 118 87-010-263-080 CAP, ELECT 100-10V A...................
C 115 87-010-385-080 CAP, ELECT 220-25V A...................
C 114 87-010-385-080 CAP, ELECT 220-25V A...................
C 117 87-010-430-080 CAP, ELECT 100-63 A...................
C 124 87-010-112-080 CAP, ELECT 100-16V A...................
C 121 87-010-174-080 CAP CHIP SL470P (K) A...................
C 125 87-010-235-080 CAP,E 470-16 SME A...................
C 123 87-010-247-080 CAP, ELECT 100-50V A...................
C 122 87-010-263-080 CAP, ELECT 100-10V A...................
C 120 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 130 87-010-399-010 CAP, ELECT 3300-35V A...................
C 131 87-010-399-010 CAP, ELECT 3300-35V A...................
C 132 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 133 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 900 87-010-178-080 CHIP CAP 1000P A...................
C 908 87-010-190-080 S CHIP F 0.01 A...................
C 907 87-010-190-080 S CHIP F 0.01 A...................
C 904 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 906 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 905 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 903 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 909 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 910 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 942 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 941 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 945 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 944 87-010-993-080 C-CAP,S 0.056-25 B A...................
C 943 87-010-993-080 C-CAP,S 0.056-25 B A...................
C 946 87-010-993-080 C-CAP,S 0.056-25 B A...................
CN 905 87-099-196-010 CONN,8P 6216 V A...................
D 102 87-017-447-010 DIODE,GBU4DL A...................
D 101 87-017-654-060 DIODE,GBU6J A...................
D 107 87-070-274-080 DIODE,1N4003 SEM A...................
D 109 87-070-274-080 DIODE,1N4003 SEM A...................
D 108 87-070-274-080 DIODE,1N4003 SEM A...................
D 106 87-070-274-080 DIODE,1N4003 SEM A...................
D 104 87-A40-468-080 C-DIODE,HSM2836CTR A...................
D 105 87-A40-469-080 C-DIODE,HSM2838CTR A...................
D 103 87-A40-470-080 DIODE,1SS254 A...................
D 115 87-A40-004-080 ZENER,MTZJ16A A...................
D 110 87-A40-341-080 ZENER,MTZJ 36 A A...................
D 112 87-A40-345-080 ZENER,MTZJ10C A...................
D 111 87-A40-468-080 C-DIODE,HSM2836CTR A...................
D 130 87-017-447-010 DIODE,GBU4DL A...................
FC 101 87-033-213-080 CLAMP, FUSE A...................
FC 102 87-033-213-080 CLAMP, FUSE A...................
J 901 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM A...................
J 902 87-A60-617-010 TERMINAL,SP 4P (MSC) A...................
J 903 87-A60-652-010 JACK,PIN 4P ORN/BLK A...................
J 904 87-A60-658-010 JACK,PIN 6P WHITE/RED A...................
J 905 87-A60-658-010 JACK,PIN 6P WHITE/RED A...................
L 901 87-003-383-010 COIL,1UH-S A...................
L 902 87-003-383-010 COIL,1UH-S A...................
L 912 87-003-383-010 COIL,1UH-S A...................
L 911 87-003-383-010 COIL,1UH-S A...................
L 913 87-003-383-010 COIL,1UH-S A...................
PR 105 87-026-681-080 PROTECTOR,5A 60V 491 ....................
PR 106 87-026-681-080 PROTECTOR,5A 60V 491 ....................
PR 103 87-026-682-080 PROTECTOR,10A 60V491 ....................
PR 104 87-026-682-080 PROTECTOR,10A 60V491 ....................
PR 106 87-026-690-080 FUSE,5A 125V 251 A...................
PR 105 87-026-690-080 FUSE,5A 125V 251 A...................
PR 104 87-026-691-080 FUSE,10A 125V 251 A...................
PR 103 87-026-691-080 FUSE,10A 125V 251 A...................
PR 101 87-A90-195-080 PROTECTOR 7A 125V 49 ....................
PR 102 87-A90-195-080 PROTECTOR 7A 125V 49 ....................
PR 102 87-A90-210-080 FUSE,7A 125V 251 A...................
PR 101 87-A90-210-080 FUSE,7A 125V 251 A...................
Q 103 87-026-610-080 TR,KTC3198GR A...................
Q 109 87-A30-075-080 C-TR,2SA1235F A...................

ELECTRICAL MAIN PARTS LIST - 3/8 (MX-NMT1000)
Q 107 87-A30-075-080 C-TR,2SA1235F A...................
Q 106 87-A30-076-080 C-TR,2SC3052F A...................
Q 108 87-A30-076-080 C-TR,2SC3052F A...................
Q 104 87-A30-076-080 C-TR,2SC3052F A...................
Q 105 87-A30-083-080 TR,CSD1489B A...................
Q 101 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 102 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 111 87-026-609-080 TR,KTA1266GR A...................
Q 112 87-026-609-080 TR,KTA1266GR A...................
Q 115 87-A30-075-080 C-TR,2SA1235F A...................
Q 114 87-A30-075-080 C-TR,2SA1235F A...................
Q 110 87-A30-076-080 C-TR,2SC3052F A...................
R 909 87-A00-126-080 RES M/F 220-1/WJ VIP A...................
R 911 87-A00-126-080 RES M/F 220-1/WJ VIP A...................
R 910 87-A00-126-080 RES M/F 220-1/WJ VIP A...................
R 912 87-A00-126-080 RES M/F 220-1/WJ VIP A...................
RY 101 87-A90-464-010 RELAY, DG12D2-O(M) A...................
S 101 87-036-173-010 SW,SL 2-2-4 SDKG(*) ....................
T 102 87-A60-317-010 TERMINAL, 1P MSC A...................
T 101 87-A60-317-010 TERMINAL, 1P MSC A...................
W 0 88-SP1-625-010 WIRE ASSY,1P (GRN) ....................
W 0 88-SP1-626-010 WIRE ASSY,1P (YEL) ....................
W 0 88-SP1-627-010 WIRE ASSY,1P (BLU) ....................
W 0 88-SP1-628-010 WIRE ASSY,1P (BLK) ....................
W 0 88-SP1-629-010 WIRE ASSY,1P (WHT) ....................
W 101 85-NF5-628-010 F-CABLE 7P-2.5 A...................
C 201 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 202 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 209 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 213 87-010-186-080 CAP,CHIP 4700P A...................
C 214 87-010-186-080 CAP,CHIP 4700P A...................
C 211 87-010-187-080 CAP CHIP S5600P A...................
C 212 87-010-187-080 CAP CHIP S5600P A...................
C 217 87-010-260-080 CAP, ELECT 47-25V A...................
C 218 87-010-260-080 CAP, ELECT 47-25V A...................
C 215 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 216 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 210 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 219 87-A10-516-080 C-CAP,S 100P-200 J CH A...................
C 223 87-010-405-080 CAP, ELECT 10-50V A...................
C 227 87-010-407-080 CAP, ELECT 33-50V A...................
C 220 87-A10-516-080 C-CAP,S 100P-200 J CH A...................
C 231 87-010-186-080 CAP,CHIP 4700P A...................
C 232 87-010-186-080 CAP,CHIP 4700P A...................
C 235 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 234 87-010-401-080 CAP, ELECT 1-50V A...................
C 233 87-010-401-080 CAP, ELECT 1-50V A...................
D 207 87-A40-470-080 DIODE,1SS254 A...................
D 208 87-A40-470-080 DIODE,1SS254 A...................
D 209 87-A40-470-080 DIODE,1SS254 A...................
D 203 87-A40-470-080 DIODE,1SS254 A...................
D 201 87-A40-470-080 DIODE,1SS254 A...................
D 205 87-A40-470-080 DIODE,1SS254 A...................
D 206 87-A40-470-080 DIODE,1SS254 A...................
D 202 87-A40-470-080 DIODE,1SS254 A...................
D 204 87-A40-470-080 DIODE,1SS254 A...................
D 213 87-070-136-080 ZENER,MTZJ5.1B A...................
D 214 87-070-136-080 ZENER,MTZJ5.1B A...................
D 211 87-A40-370-090 DIODE,RK46-P20 A...................
D 212 87-A40-370-090 DIODE,RK46-P20 A...................
D 210 87-A40-470-080 DIODE,1SS254 A...................
D 218 87-A40-470-080 DIODE,1SS254 A...................
D 219 87-A40-470-080 DIODE,1SS254 A...................
D 216 87-A40-470-080 DIODE,1SS254 A...................
D 215 87-A40-470-080 DIODE,1SS254 A...................
D 217 87-A40-470-080 DIODE,1SS254 A...................
D 220 87-A40-345-080 ZENER,MTZJ10C A...................
D 225 87-A40-470-080 DIODE,1SS254 A...................
D 221 87-A40-470-080 DIODE,1SS254 A...................
D 226 87-A40-470-080 DIODE,1SS254 A...................
D 227 87-A40-470-080 DIODE,1SS254 A...................
D 222 87-A40-470-080 DIODE,1SS254 A...................
D 223 87-A40-488-080 DIODE,1SS244 A...................
D 224 87-A40-488-080 DIODE,1SS244 A...................
D 295 87-A40-470-080 DIODE,1SS254 A...................
D 296 87-A40-470-080 DIODE,1SS254 A...................
Q 204 87-A30-075-080 C-TR,2SA1235F A...................
Q 202 87-A30-086-040 C-TR,CSD1306E A...................
Q 201 87-A30-086-040 C-TR,CSD1306E A...................
Q 207 87-A30-107-080 C-TR,CMBT5401 A...................
Q 208 87-A30-107-080 C-TR,CMBT5401 A...................
Q 209 87-A30-107-080 C-TR,CMBT5401 A...................
Q 213 87-A30-076-080 C-TR,2SC3052F A...................
Q 214 87-A30-076-080 C-TR,2SC3052F A...................
Q 211 87-A30-076-080 C-TR,2SC3052F A...................
Q 212 87-A30-076-080 C-TR,2SC3052F A...................
Q 217 87-A30-097-010 TR,FN 1016 A...................
Q 218 87-A30-097-010 TR,FN 1016 A...................
Q 219 87-A30-098-010 TR,FP 1016 A...................
Q 210 87-A30-107-080 C-TR,CMBT5401 A...................
Q 216 87-A30-190-080 TR,CC5551 A...................
Q 215 87-A30-190-080 TR,CC5551 A...................

ELECTRICAL MAIN PARTS LIST - 4/8 (MX-NMT1000)
Q 227 87-A30-072-080 C-TR,RT1P 144C A...................
Q 228 87-A30-073-080 C-TR,RT1N 141C A...................
Q 226 87-A30-075-080 C-TR,2SA1235F A...................
Q 225 87-A30-076-080 C-TR,2SC3052F A...................
Q 220 87-A30-098-010 TR,FP 1016 A...................
Q 222 87-A30-106-080 C-TR,CMBT5551 A...................
Q 221 87-A30-106-080 C-TR,CMBT5551 A...................
Q 229 87-A30-107-080 C-TR,CMBT5401 A...................
Q 223 87-A30-162-010 FET,2SK2937 A...................
Q 224 87-A30-162-010 FET,2SK2937 A...................
Q 291 87-A30-074-080 C-TR,RT1P 141C A...................
Q 295 87-A30-106-080 C-TR,CMBT5551 A...................
Q 290 87-A30-107-080 C-TR,CMBT5401 A...................
R 239 87-A00-262-080 RES,M/F 0.15-2W J A...................
R 238 87-A00-262-080 RES,M/F 0.15-2W J A...................
R 237 87-A00-262-080 RES,M/F 0.15-2W J A...................
R 240 87-A00-262-080 RES,M/F 0.15-2W J A...................
TH 201 87-A90-221-080 C-THMS,100K A...................
TH 202 87-A90-221-080 C-THMS,100K A...................
88-SP1-211-010 GUIDE,FUN A...................
88-SX1-203-010 GUIDE,FL A...................
C 101 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 301 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 302 87-010-404-080 CAP, ELECT 4.7-50V A...................
D 304 87-A40-470-080 DIODE,1SS254 A...................
D 305 87-A40-470-080 DIODE,1SS254 A...................
D 302 87-A40-470-080 DIODE,1SS254 A...................
D 301 87-A40-470-080 DIODE,1SS254 A...................
D 303 87-A40-470-080 DIODE,1SS254 A...................
FL 301 88-SP1-610-010 FL,10-BT-208GK A...................
LED 304 87-A40-497-080 LED,SML11516C A...................
LED 305 87-A40-497-080 LED,SML11516C A...................
LED 302 87-A40-497-080 LED,SML11516C A...................
LED 301 87-A40-497-080 LED,SML11516C A...................
LED 303 87-A40-497-080 LED,SML11516C A...................
Q 307 87-026-226-080 CHIP-TR,DTA143EK A...................
Q 303 87-A30-071-080 C-TR,RT1N 144C A...................
Q 305 87-A30-071-080 C-TR,RT1N 144C A...................
Q 304 87-A30-071-080 C-TR,RT1N 144C A...................
Q 301 87-A30-071-080 C-TR,RT1N 144C A...................
Q 302 87-A30-071-080 C-TR,RT1N 144C A...................
Q 306 89-112-965-080 TR,2SA1296 (0.75W) A...................
S 307 87-A90-809-080 SW,TACT TSTA-2 A...................
S 309 87-A90-809-080 SW,TACT TSTA-2 A...................
S 301 87-A90-809-080 SW,TACT TSTA-2 A...................
S 303 87-A90-809-080 SW,TACT TSTA-2 A...................
S 308 87-A90-809-080 SW,TACT TSTA-2 A...................
S 305 87-A90-809-080 SW,TACT TSTA-2 A...................
S 304 87-A90-809-080 SW,TACT TSTA-2 A...................
S 306 87-A90-809-080 SW,TACT TSTA-2 A...................
S 302 87-A90-809-080 SW,TACT TSTA-2 A...................
S 310 87-A90-809-080 SW,TACT TSTA-2 A...................
S 314 87-A90-809-080 SW,TACT TSTA-2 A...................
S 311 87-A90-809-080 SW,TACT TSTA-2 A...................
S 313 87-A90-809-080 SW,TACT TSTA-2 A...................
S 312 87-A90-809-080 SW,TACT TSTA-2 A...................
S 315 87-A90-809-080 SW,TACT TSTA-2 A...................
C 0 87-010-374-080 CAP, ELECT 47-10V ....................
C 603 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 604 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 606 87-010-369-080 C-CAP,S 0.033-25 K B A...................
C 605 87-010-369-080 C-CAP,S 0.033-25 K B A...................
C 608 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 607 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 602 87-010-545-040 CAP,E 0.22-50 SME A...................
C 601 87-010-545-040 CAP,E 0.22-50 SME A...................
C 612 87-010-112-080 CAP, ELECT 100-16V A...................
C 614 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 613 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 611 87-010-405-080 CAP, ELECT 10-50V A...................
CN 611 87-099-212-010 CONN,5P 6216 V A...................
IC 601 87-A20-804-040 C-IC,NJM2152M A...................
C 0 87-010-544-080 CAP, ELECT 0.1-50V ....................
C 701 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 702 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 709 87-010-956-080 CHIP-CAP,S 0.068-25B A...................
C 708 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 707 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 705 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 706 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 703 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 704 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 719 87-010-178-080 CHIP CAP 1000P A...................
C 716 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 715 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 717 87-010-188-080 CAP,CHIP 6800P A...................
C 718 87-010-188-080 CAP,CHIP 6800P A...................
C 711 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 712 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 713 87-010-198-080 CAP, CHIP 0.022 A...................
C 714 87-010-198-080 CAP, CHIP 0.022 A...................
C 710 87-010-956-080 CHIP-CAP,S 0.068-25B A...................

ELECTRICAL MAIN PARTS LIST - 5/8 (MX-NMT1000)
C 720 87-010-178-080 CHIP CAP 1000P A...................
C 721 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 722 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 731 87-010-112-080 CAP, ELECT 100-16V A...................
C 738 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 736 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 735 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 737 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 730 87-010-404-080 CAP, ELECT 4.7-50V A...................
IC 701 87-A20-869-040 C-IC,M62449FP A...................
88-AR1-625-010 PWB,TUNER HE HR 4M ....................
C 701 87-010-260-080 CAP, ELECT 47-25V A...................
C 702 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 709 87-012-195-080 C-CAP,U 100P-50CH A...................
C 703 87-012-286-080 CAP, U 0.01-25 A...................
C 704 87-012-286-080 CAP, U 0.01-25 A...................
C 712 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 711 87-010-263-080 CAP, ELECT 100-10V A...................
C 715 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 715 87-012-195-080 C-CAP,U 100P-50CH ....................
C 717 87-012-286-080 CAP, U 0.01-25 A...................
C 714 87-012-286-080 CAP, U 0.01-25 A...................
C 713 87-012-286-080 CAP, U 0.01-25 A...................
C 719 87-012-286-080 CAP, U 0.01-25 A...................
C 727 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 728 87-010-248-080 CAP, ELECT 220-10V A...................
C 721 87-012-176-080 CAP 15P A...................
C 722 87-012-176-080 CAP 15P A...................
C 720 87-012-195-080 C-CAP,U 100P-50CH ....................
C 725 87-012-274-080 CHIP CAP,U 1000P-50B A...................
C 723 87-012-274-080 CHIP CAP,U 1000P-50B A...................
CN 601 87-099-028-010 CONN,11P 6216 H A...................
D 710 87-A40-470-080 DIODE,1SS254 ....................
D 721 87-A40-234-080 ZENER,MTZJ5.6A A...................
IC 721 86-NFZ-655-010 IC,LC72131D(Z) A...................
Q 711 87-A30-083-080 TR,CSD1489B A...................
X 721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................
C 758 87-012-167-080 C-CAP,U 5P-50 CH A...................
C 757 87-012-188-080 C-CAP,U 47P-50 CH A...................
C 756 87-012-286-080 CAP, U 0.01-25 A...................
C 755 87-012-286-080 CAP, U 0.01-25 A...................
C 761 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 769 87-010-260-080 CAP, ELECT 47-25V ....................
C 769 87-010-408-080 CAP, ELECT 47-50V A...................
C 763 87-010-829-080 CAP, U 0.047-16 A...................
C 765 87-012-286-080 CAP, U 0.01-25 A...................
C 766 87-012-286-080 CAP, U 0.01-25 A...................
C 764 87-012-337-080 C-CAP,U 56P-50 CH A...................
C 773 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 774 87-010-263-080 CAP, ELECT 100-10V A...................
C 771 87-010-383-080 CAP, ELECT 33-25V A...................
C 777 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 779 87-010-401-080 CAP, ELECT 1-50V A...................
C 778 87-010-401-080 CAP, ELECT 1-50V A...................
C 775 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 771 87-010-407-080 CAP, ELECT 33-50V ....................
C 770 87-010-829-080 CAP, U 0.047-16 A...................
C 772 87-010-829-080 CAP, U 0.047-16 A...................
C 776 87-012-286-080 CAP, U 0.01-25 A...................
C 780 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 781 87-010-405-080 CAP, ELECT 10-50V A...................
C 782 87-010-405-080 CAP, ELECT 10-50V A...................
C 789 87-012-275-080 C-CAP,U 1200P-50 B A...................
C 788 87-012-280-080 CAP, U 3300P-50 A...................
C 787 87-012-280-080 CAP, U 3300P-50 A...................
C 784 87-012-286-080 CAP, U 0.01-25 A...................
C 783 87-012-286-080 CAP, U 0.01-25 A...................
C 793 87-010-177-080 C-CAP,S 820P-50 SL ....................
C 796 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 791 87-010-405-080 CAP, ELECT 10-50V A...................
C 794 87-010-406-080 CAP, ELECT 22-50 A...................
C 795 87-010-596-080 CAP, S 0.047-16 A...................
C 799 87-010-829-080 CAP, U 0.047-16 A...................
C 793 87-012-273-080 C-CAP,U 820P-50 B A...................
C 790 87-012-275-080 C-CAP,U 1200P-50 B A...................
C 798 87-012-276-080 CAP, CHIP SS 1500 PBK ....................
C 797 87-012-276-080 CAP, CHIP SS 1500 PBK ....................
C 798 87-012-278-080 C-CAP,U 2200P-50 B A...................
C 797 87-012-278-080 C-CAP,U 2200P-50 B A...................
D 771 87-A40-470-080 DIODE,1SS254 ....................
D 773 87-A40-470-080 DIODE,1SS254 A...................
IC 771 87-A20-438-010 IC,LA1837 A...................
IC 771 87-A20-913-010 IC,LA1837NL ....................
L 771 87-A50-266-010 COIL,FM DET-2N(TOK) A...................
L 772 87-A90-052-010 FLTR,CFMT-450A(TOK) ....................
L 772 87-A90-733-010 FLTR,PCFAZH-450 (TOK) A...................
L 781 87-005-847-080 COIL,2.2UH(CECS) A...................
L 791 87-A50-027-010 COIL,1 POLE MPX(TOK) ....................
L 792 87-A50-027-010 COIL,1 POLE MPX(TOK) ....................
L 791 87-A50-209-010 COIL,1POLE MPX(MIT) A...................
L 792 87-A50-209-010 COIL,1POLE MPX(MIT) A...................
X 771 87-030-354-010 VIB,CF BFU 450C ....................

ELECTRICAL MAIN PARTS LIST - 6/8 (MX-NMT1000)
C 813 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 818 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 819 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 814 87-012-286-080 CAP, U 0.01-25 A...................
C 812 87-012-286-080 CAP, U 0.01-25 A...................
C 829 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 828 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 820 87-010-260-080 CAP, ELECT 47-25V ....................
C 820 87-010-408-080 CAP, ELECT 47-50V A...................
C 821 87-012-286-080 CAP, U 0.01-25 A...................
C 823 87-012-286-080 CAP, U 0.01-25 A...................
C 822 87-012-286-080 CAP, U 0.01-25 A...................
C 944 87-010-575-080 C-CAP,S 560P-50 UJ ....................
C 942 87-012-172-080 CAPACITOR CHIP U 10P CH ....................
C 941 87-012-180-080 C-CAP,U 22P-50 CH ....................
C 947 87-012-286-080 CAP, U 0.01-25 ....................
C 943 87-012-286-080 CAP, U 0.01-25 ....................
C 945 87-012-286-080 CAP, U 0.01-25 ....................
C 940 87-012-286-080 CAP, U 0.01-25 ....................
C 949 87-A10-039-080 C-CAP,U 470P-50 J CH ....................
C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 956 87-010-263-080 CAP, ELECT 100-10V ....................
C 957 87-010-311-080 CAP 12P ....................
C 954 87-010-400-080 CAP, ELECT 0.47-50V ....................
C 958 87-012-286-080 CAP, U 0.01-25 ....................
C 953 87-012-286-080 CAP, U 0.01-25 ....................
C 952 87-012-286-080 CAP, U 0.01-25 ....................
C 950 87-A10-913-080 C-CAP, 4700P-50 J CH ....................
C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 962 87-010-401-080 CAP, ELECT 1-50V ....................
C 961 87-012-170-080 C-CAP,U 8P-50 CH A...................
CF 802 82-785-747-010 CF MS2 GHY R ....................
CF 801 87-008-261-010 FILTER, SFE10.7MA5-A A...................
CF 802 87-008-261-010 FILTER, SFE10.7MA5-A A...................
CF 801 87-008-423-010 CERAMIC FILTER, SFE10.7 ....................
D 942 87-A40-270-080 C-DIODE,MC2838 ....................
D 941 87-A40-470-080 DIODE,1SS254 ....................
D 944 87-A40-470-080 DIODE,1SS254 ....................
FFE 801 A8-6ZA-191-130 6ZA-1 FEENM ....................
FFE 801 A8-8ZA-190-030 8ZA-1 FEUNM A...................
FFE 801 A8-8ZA-193-070 8ZA-1 YFEUNC ....................
J 801 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 ....................
J 801 87-A60-657-010 TERMINAL,4P HSP-154V5-02 A...................
L 832 87-005-847-080 COIL,2.2UH(CECS) A...................
L 943 87-005-372-080 COIL S 1MHM ....................
L 942 87-A50-019-010 COIL,OSC LW(COI) ....................
L 941 87-A50-020-010 COIL,ANT LW(COI) ....................
L 945 87-A50-022-010 COIL,ANT SW(COI) ....................
L 944 87-A50-159-010 COIL,10MH K C2B ....................
L 946 87-A50-173-010 COIL,OSC SW-N(COI) ....................
L 983 86-NF4-666-010 AM PACK 3(TOK) ....................
L 981 87-NF4-650-010 COIL,AM PACK 4N(TOK) A...................
L 981 87-NF4-651-010 COIL,AM PACK2N(TOM) ....................
Q 807 87-A30-072-080 C-TR,RT1P 144C ....................
Q 806 87-A30-072-080 C-TR,RT1P 144C A...................
Q 805 89-327-143-080 TR,2SC2714 (0.1W) A...................
Q 941 87-A30-074-080 C-TR,RT1P 141C ....................
Q 943 87-A30-075-080 C-TR,2SA1235F ....................
Q 942 87-A30-075-080 C-TR,2SA1235F ....................
Q 945 87-A30-076-080 C-TR,2SC3052F ....................
Q 944 87-A30-076-080 C-TR,2SC3052F ....................
Q 949 87-A30-076-080 C-TR,2SC3052F ....................
Q 946 87-A30-086-070 C-TR,CSD1306E ....................
Q 948 87-A30-086-070 C-TR,CSD1306E ....................
Q 947 89-503-602-080 C-FET,2SK360E ....................
Q 951 87-A30-074-080 C-TR,RT1P 141C ....................
Q 950 87-A30-086-070 C-TR,CSD1306E ....................
Q 952 87-A30-086-070 C-TR,CSD1306E ....................
TC 942 87-011-164-010 CAPACITOR,TRIMMER 30P ....................
TC 943 87-011-164-010 CAPACITOR,TRIMMER 30P ....................
TC 941 87-011-173-010 CERAMIC TRIMMER 20P ....................
C 404 87-010-401-080 CAP, ELECT 1-50V A...................
C 405 87-010-401-080 CAP, ELECT 1-50V A...................
C 403 87-010-401-080 CAP, ELECT 1-50V A...................
C 406 87-010-401-080 CAP, ELECT 1-50V A...................
C 402 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 401 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 408 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 407 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 419 87-010-401-080 CAP, ELECT 1-50V A...................
C 410 87-010-401-080 CAP, ELECT 1-50V A...................
C 412 87-012-349-080 C-CAP,S 1000P-50 CH A...................
C 418 87-012-349-080 C-CAP,S 1000P-50 CH A...................
C 420 87-010-401-080 CAP, ELECT 1-50V A...................
C 427 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 426 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 425 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 428 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 429 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 424 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 423 87-A10-229-080 C-CAP,S 0.68-10 K W5 A...................
C 439 87-010-994-080 C-CAP,S 680P-50 CH A...................

C 438 87-010-994-080 C-CAP,S 680P-50 CH A...................
C 430 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 433 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 434 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 437 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 436 88-710-839-810 CAP,M 0.022-50 J TFL A...................
C 435 88-710-839-810 CAP,M 0.022-50 J TFL A...................
C 446 87-010-374-080 CAP, ELECT 47-10V A...................
C 444 87-A10-891-080 CAP,E 4.7-25 SME(K) A...................
C 451 87-010-112-080 CAP, ELECT 100-16V A...................
C 452 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 459 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 457 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 455 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 453 87-010-248-080 CAP, ELECT 220-10V A...................
C 454 87-010-263-080 CAP, ELECT 100-10V A...................
C 456 87-010-374-080 CAP, ELECT 47-10V A...................
C 458 87-010-374-080 CAP, ELECT 47-10V A...................
C 462 87-010-314-080 C-CAP,S 22P-50V A...................
C 461 87-010-314-080 C-CAP,S 22P-50V A...................
C 463 87-010-314-080 C-CAP,S 22P-50V A...................
D 401 87-A40-470-080 DIODE,1SS254 A...................
D 402 87-A40-470-080 DIODE,1SS254 A...................
D 451 87-070-136-080 ZENER,MTZJ5.1B A...................
D 452 87-A40-442-080 ZENER,MTZJ9.1A A...................
IC 402 87-020-818-080 IC,TC4066BF A...................
IC 403 87-020-818-080 IC,TC4066BF A...................
IC 401 87-A20-853-010 C-IC,M62463FP A...................
Q 401 87-A30-074-080 C-TR,RT1P 141C A...................
Q 402 87-A30-104-080 C-TR,RT1N 441C A...................
C 952 87-010-263-080 CAP, ELECT 100-10V A...................
C 953 87-010-380-080 CAP, ELECT 47-16V A...................
C 951 87-010-401-080 CAP, ELECT 1-50V A...................
D 952 87-A40-470-080 DIODE,1SS254 A...................
D 951 87-A40-470-080 DIODE,1SS254 A...................
Q 952 87-026-609-080 TR,KTA1266GR A...................
Q 951 87-A30-076-080 C-TR,2SC3052F A...................
C 0 87-010-182-080 C-CAP,S 2200P-50 B ....................
C 0 87-012-145-080 CAP, CHIP S 270P CH ....................
C 304 87-010-178-080 CHIP CAP 1000P A...................
C 303 87-010-178-080 CHIP CAP 1000P A...................
C 308 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 307 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 301 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 302 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 306 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 305 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 309 87-010-405-080 CAP, ELECT 10-50V A...................
C 312 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 311 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 313 87-010-260-080 CAP, ELECT 47-25V A...................
C 314 87-010-260-080 CAP, ELECT 47-25V A...................
C 310 87-010-405-080 CAP, ELECT 10-50V A...................
C 317 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 318 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 316 87-A10-596-080 C-CAP,S 100P-100 J CH A...................
C 315 87-A10-596-080 C-CAP,S 100P-100 J CH A...................
C 352 87-010-178-080 CHIP CAP 1000P A...................
C 356 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 357 87-010-260-080 CAP, ELECT 47-25V A...................
C 354 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 351 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 353 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 355 87-010-405-080 CAP, ELECT 10-50V A...................
C 359 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 358 87-A10-596-080 C-CAP,S 100P-100 J CH A...................
C 381 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 391 87-010-401-080 CAP, ELECT 1-50V A...................
D 305 87-A40-470-080 DIODE,1SS254 A...................
D 306 87-A40-470-080 DIODE,1SS254 A...................
D 307 87-A40-470-080 DIODE,1SS254 A...................
D 303 87-A40-470-080 DIODE,1SS254 A...................
D 308 87-A40-470-080 DIODE,1SS254 A...................
D 301 87-A40-470-080 DIODE,1SS254 A...................
D 304 87-A40-470-080 DIODE,1SS254 A...................
D 302 87-A40-470-080 DIODE,1SS254 A...................
D 309 87-A40-470-080 DIODE,1SS254 A...................
D 315 87-A40-470-080 DIODE,1SS254 A...................
D 316 87-A40-470-080 DIODE,1SS254 A...................
D 317 87-A40-470-080 DIODE,1SS254 A...................
D 310 87-A40-470-080 DIODE,1SS254 A...................
D 318 87-A40-470-080 DIODE,1SS254 A...................
D 312 87-A40-488-080 DIODE,1SS244 A...................
D 311 87-A40-488-080 DIODE,1SS244 A...................
D 351 87-A40-470-080 DIODE,1SS254 A...................
D 355 87-A40-470-080 DIODE,1SS254 A...................
D 352 87-A40-470-080 DIODE,1SS254 A...................
D 354 87-A40-470-080 DIODE,1SS254 A...................
D 353 87-A40-470-080 DIODE,1SS254 A...................
D 356 87-A40-488-080 DIODE,1SS244 A...................
Q 303 87-A30-075-080 C-TR,2SA1235F A...................
Q 306 87-A30-075-080 C-TR,2SA1235F A...................
ELECTRICAL MAIN PARTS LIST - 7/8(MX-NMT1000)

Q 305 87-A30-075-080 C-TR,2SA1235F A...................
Q 304 87-A30-075-080 C-TR,2SA1235F A...................
Q 307 87-A30-076-080 C-TR,2SC3052F A...................
Q 308 87-A30-076-080 C-TR,2SC3052F A...................
Q 309 87-A30-076-080 C-TR,2SC3052F A...................
Q 301 87-A30-086-080 C-TR,CSD1306E A...................
Q 302 87-A30-086-080 C-TR,CSD1306E A...................
Q 310 87-A30-076-080 C-TR,2SC3052F A...................
Q 318 87-A30-076-080 C-TR,2SC3052F A...................
Q 317 87-A30-076-080 C-TR,2SC3052F A...................
Q 316 87-A30-108-010 TR,2SB1626 A...................
Q 315 87-A30-108-010 TR,2SB1626 A...................
Q 314 87-A30-109-010 TR,2SD 2495 A...................
Q 313 87-A30-109-010 TR,2SD 2495 A...................
Q 312 87-A30-190-080 TR,CC5551 A...................
Q 311 87-A30-190-080 TR,CC5551 A...................
Q 353 87-A30-075-080 C-TR,2SA1235F A...................
Q 352 87-A30-075-080 C-TR,2SA1235F A...................
Q 355 87-A30-076-080 C-TR,2SC3052F A...................
Q 354 87-A30-076-080 C-TR,2SC3052F A...................
Q 359 87-A30-076-080 C-TR,2SC3052F A...................
Q 351 87-A30-086-080 C-TR,CSD1306E A...................
Q 358 87-A30-108-010 TR,2SB1626 A...................
Q 357 87-A30-109-010 TR,2SD 2495 A...................
Q 356 87-A30-190-080 TR,CC5551 A...................
Q 360 87-A30-107-080 C-TR,CMBT5401 A...................
Q 381 87-A30-086-080 C-TR,CSD1306E A...................
R 331 87-022-050-080 RES,M/F 0.22-1W J A...................
R 332 87-022-050-080 RES,M/F 0.22-1W J A...................
R 333 87-022-050-080 RES,M/F 0.22-1W J A...................
R 334 87-022-050-080 RES,M/F 0.22-1W J A...................
R 367 87-022-050-080 RES,M/F 0.22-1W J A...................
R 366 87-022-050-080 RES,M/F 0.22-1W J A...................
C 805 87-010-154-080 CAP CHIP 10P A...................
C 806 87-010-378-080 CAP, ELECT 10-16V A...................
C 807 87-010-378-080 CAP, ELECT 10-16V A...................
C 801 87-010-401-080 CAP, ELECT 1-50V A...................
C 802 87-010-401-080 CAP, ELECT 1-50V A...................
C 841 87-010-154-080 CAP CHIP 10P A...................
C 857 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 856 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 853 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 854 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 858 87-010-374-080 CAP, ELECT 47-10V A...................
C 851 87-010-374-080 CAP, ELECT 47-10V A...................
C 852 87-010-374-080 CAP, ELECT 47-10V A...................
C 855 87-010-374-080 CAP, ELECT 47-10V A...................
C 881 87-010-260-080 CAP, ELECT 47-25V A...................
D 802 87-A40-466-080 ZENER,MTZJ2.7A A...................
D 801 87-A40-466-080 ZENER,MTZJ2.7A A...................
IC 802 87-017-726-080 IC,BU4052 BCF A...................
IC 801 87-A20-715-010 IC,M62439SP A...................
Q 883 87-A30-075-080 C-TR,2SA1235F A...................
Q 882 87-A30-076-080 C-TR,2SC3052F A...................
Q 881 87-A30-087-080 C-FET,2SK2158 A...................
ELECTRICAL MAIN PARTS LIST - 8/8 (MX-NMT1000)

SCHEMATIC DIAGRAM _1 (MX-NMT1000: MAIN)

SCHEMATIC DIAGRAM _2 (MX-NMT1000: FRONT)

SCHEMATIC DIAGRAM _3 (MX-NMT1000: TUNER)

SCHEMATIC DIAGRAM _4 (MX-NMT1000: PROLOGIC)

SCHEMATIC DIAGRAM _5 (MX-NMT1000: TUNER FRONT END)

NOTE: The characters in the suffix column indicate the part usage.
U ......................XX..................................A...................
REF.NO PARTS NO. DESCRIPTION SUFFIX
87-B00-002-010 BADGE,AIWA 30 ABS SIL A...................
88-SP1-002-010 CABI,STEEL A...................
88-SPM-001-010 CABI,FR ....................
88-SPM-003-010 PANEL,REAR USNM ....................
88-SPM-017-010 CABI,FR U A...................
88-SPM-022-010 PANEL,REAR HRJSNM ....................
88-SPM-024-010 PANEL,REAR KSNM ....................
88-SPM-030-010 PANEL,REAR USN A...................
88-SPM-034-010 PANEL,REAR KSN ....................
88-SPM-041-010 PANEL,REAR HES ....................
88-SU1-014-010 RING,FOOT A...................
88-SP1-005-010 KEY,FUN A...................
88-SP1-006-010 KEY,POWER A...................
88-SP1-007-010 KEY,BBE A...................
88-SP1-008-010 KEY,KARAOKE A...................
88-SP1-010-010 KNOB,RTRY VOL A...................
88-SP1-011-010 RING,VOL A...................
88-SP1-012-010 KEY,TUNING A...................
88-SP1-014-010 REFLECTOR,FUN A...................
88-SP1-015-010 KEY,ASSY FUN A...................
88-SP1-016-010 LENS,SENSOR ....................
88-SP1-004-010 WINDOW,DISPLAY A...................
87-085-213-010 FOOT,H12.5 A...................
88-AR1-203-010 HLDR,TU A...................
88-SP1-208-010 COVER, FAN A...................
87-067-641-010 UTT2+3-8(W/O SLOT)BL A...................
87-067-688-010 BVTT+3-6 A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
87-067-822-010 BVT2+3-20 W/O SLOT A...................
87-078-019-010 S-SCREW,IT+4-6 ....................
87-078-191-010 S-SCREW,IT+4-10 A...................
87-591-094-410 TAPPING SCREW, QIT+3-6 A...................
87-591-095-410 TAPPING SCREW, QIT+3-8 (GLD) A...................
87-085-185-010 BUSHING, AC CORD (E) ....................
87-085-189-010 BUSHING, CORD (U) A...................
88-905-281-110 FF-CABLE, 5P 1.25 280MM A...................
88-908-071-110 FF-CABLE, 8P 1.25 70MM A...................
88-911-121-110 FF-CABLE,11P 1.25 A...................
0101 87-A90-796-010 FAN,F614R-12MC-15-300MM A...................
F 101 87-035-364-010 FUSE, 1.6A 250V ....................
F 101 87-035-367-010 FUSE, 3.15A 250V ....................
F 101 87-035-488-010 FUSE,3.15A 125V D UL A...................
PT 101 88-SPM-601-010 PT,U A...................
PT 101 88-SPM-602-010 PT,HE ....................
PT 101 88-SPM-606-010 PT,K ....................
W 0 88-904-151-110 FF-CABLE, 4P 1.25 150MM ....................
W 103 87-050-053-010 AC CORD ASSY,U-2 A...................
W 103 87-050-079-010 AC-CORD ASSY,E ....................
87-022-200-080 RESISTOR, METAL 0.56 1W A...................
W 0 88-SP1-625-010 WIRE ASSY,1P (GRN) ....................
W 0 88-SP1-626-010 WIRE ASSY,1P (YEL) ....................
W 0 88-SP1-627-010 WIRE ASSY,1P (BLU) ....................
W 0 88-SP1-628-010 WIRE ASSY,1P (BLK) ....................
W 0 88-SP1-629-010 WIRE ASSY,1P (WHT) ....................
W 101 85-NF5-628-010 F-CABLE 7P-2.5 A...................
88-SP1-211-010 GUIDE,FUN A...................
88-SX1-203-010 GUIDE,FL A...................
MECHANICAL PARTS LIST - 1 (MX-NMT1000)

NOTE: The characters in the suffix column indicate the part usage.
YU .....................XX..................................A...................
REF.NO PARTS NO. DESCRIPTION SUFFIX
88-SX1-202-010 GUIDE,LED OPE AB..................
CN 101 87-099-194-010 CONN,6P 6216V AB..................
LED 105 87-A40-521-040 LED,SEL6513C TP5 PGRN AB..................
LED 106 87-A40-521-040 LED,SEL6513C TP5 PGRN AB..................
LED 101 87-A40-521-040 LED,SEL6513C TP5 PGRN AB..................
LED 104 87-A40-521-040 LED,SEL6513C TP5 PGRN AB..................
LED 103 87-A40-521-040 LED,SEL6513C TP5 PGRN AB..................
LED 102 87-A40-521-040 LED,SEL6513C TP5 PGRN AB..................
S 102 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 104 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 103 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 101 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 105 87-A90-809-080 SW,TACT TSTA-2 AB..................
88-SX1-203-010 GUIDE,FL AB..................
88-SX1-610-010 CORD,FG 11P AB..................
C 5 87-010-190-080 S CHIP F 0.01 AB..................
C 6 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 7 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 4 87-010-197-080 CAP, CHIP 0.01 DM AB..................
C 1 87-010-263-040 CAP,E 100-10 AB..................
C 8 87-010-312-080 C-CAP,S 15P-50 CH AB..................
C 9 87-010-320-080 CHIP CAP 68P AB..................
C 2 87-010-494-040 CAP,E 1-50 GAS AB..................
C 3 87-010-496-040 CAP,E 3.3-50 GAS AB..................
C 12 87-010-197-080 CAP, CHIP 0.01 DM AB..................
C 13 87-010-246-040 CAP,E 47-35 SME AB..................
C 10 87-010-316-080 C-CAP,S 33P-50 CH AB..................
C 11 87-018-134-080 CAPACITOR,TC-U 0.01-16 AB..................
C 251 87-010-178-080 CHIP CAP 1000P AB..................
C 255 87-010-178-080 CHIP CAP 1000P AB..................
C 256 87-010-178-080 CHIP CAP 1000P AB..................
C 253 87-010-178-080 CHIP CAP 1000P AB..................
C 252 87-010-178-080 CHIP CAP 1000P AB..................
C 254 87-010-178-080 CHIP CAP 1000P AB..................
C 257 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
CN 3 87-099-194-010 CONN,6P 6216V AB..................
CN 303 87-099-015-010 CONN,13P 6216V AB..................
CN 302 87-099-194-010 CONN,6P 6216V AB..................
D 2 87-070-136-080 ZENER,MTZJ5.1B AB..................
D 1 87-A40-470-080 DIODE,1SS254 AB..................
FB 304 87-008-474-080 F-BEAD,EMI BL02RN1 AB..................
FB 306 87-008-474-080 F-BEAD,EMI BL02RN1 AB..................
FB 307 87-008-474-080 F-BEAD,EMI BL02RN1 AB..................
FB 303 87-008-474-080 F-BEAD,EMI BL02RN1 AB..................
FB 305 87-008-474-080 F-BEAD,EMI BL02RN1 AB..................
FB 302 87-008-474-080 F-BEAD,EMI BL02RN1 AB..................
FB 301 87-008-474-080 F-BEAD,EMI BL02RN1 AB..................
FL 201 88-SX1-609-010 FL,6-BT-293GK AB..................
IC 1 88-SX1-606-010 IC,UPD78045H-XXXX AB..................
L 3 87-005-152-080 COIL,10UH AB..................
L 2 87-005-152-080 COIL,10UH AB..................
L 1 87-005-152-080 COIL,10UH AB..................
L 5 87-005-152-080 COIL,10UH AB..................
L 301 87-005-152-080 COIL,10UH AB..................
LED 203 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN AB..................
LED 202 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN AB..................
LED 201 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN AB..................
LED 204 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN AB..................
Q 2 87-026-263-080 C-TR,RN1410 AB..................
Q 3 87-A30-074-080 C-TR,RT1P 141C AB..................
Q 1 89-324-123-080 C-TR,2SC2412K S AB..................
Q 302 87-A30-076-080 C-TR,2SC3052F AB..................
Q 301 87-A30-076-080 C-TR,2SC3052F AB..................
S 201 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 202 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 203 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 204 87-A90-809-080 SW,TACT TSTA-2 AB..................
X 1 87-A70-075-080 VIB,CER 4.19MHZ CRHF AB..................
ELECTRICAL MAIN PARTS LIST - 1 (DX-NM1000)

SCHEMATIC DIAGRAM _1 (DX-NM1000: MAIN / FRONT / KEY)

MECHANICAL PARTS LIST - 1 (DX-NM1000)
NOTE: The characters in the suffix column indicate the part usage.
YU .....................XX..................................A...................
REF.NO PARTS NO. DESCRIPTION SUFFIX
87-B00-002-010 BADGE,AIWA 30 ABS SIL AB..................
88-SU1-014-010 RING,FOOT AB..................
88-SX1-001-010 CABI,FR .B..................
88-SX1-002-010 CABI,STEEL AB..................
88-SX1-016-010 CABI,REAR YSNM ....................
88-SX1-017-010 CABI,REAR YJSNM ....................
88-SX1-018-010 CABI,REAR YUSNM ....................
88-SX1-019-010 CABI,FR U A...................
88-SX1-020-010 CABI,REAR YLSNM ....................
88-SX1-021-010 CABI,REAR YS ....................
88-SX1-022-010 CABI,REAR YLSN .B..................
88-SX1-023-010 CABI,REAR YUSN A...................
88-SX1-024-010 CABI,REAR YSN ....................
88-SX1-005-010 KEY,OPEN AB..................
88-SX1-006-010 KEY,OPE AB..................
88-SX1-007-010 BTN,DISC 1 AB..................
88-SX1-008-010 BTN,DISC 2 AB..................
88-SX1-009-010 BTN,DISC 3 AB..................
88-SX1-010-010 KEY,ASSY DISC AB..................
88-SX1-012-010 REFLECTOR,PLAY AB..................
88-SX1-013-010 REFLECTOR,FF AB..................
88-SX1-014-010 REFLECTOR,REW AB..................
88-SX1-015-010 KEY,ASSY OPE AB..................
88-SX1-201-010 GUIDE,LED DISC AB..................
86-NF6-007-010 WINDOW,TOP .B..................
86-NF6-101-010 WINDOW TOP UL A...................
88-SX1-003-010 PANEL,TRAY AB..................
88-SX1-004-010 WINDOW,DISPLAY AB..................
84-ZG1-245-210 CAP,OPTICAL AB..................
87-067-703-010 TAPPING SCREW, BVT2+3-10 AB..................
87-591-094-410 TAPPING SCREW, QIT+3-6 AB..................
0003 88-906-201-110 FF-CABLE,6P 1.25 AB..................
W 2 88-906-481-110 FF-CABLE, 6P 1.25 480MM AB..................
W 1 88-913-121-110 FF-CABLE,P1.25 AB..................
88-SX1-202-010 GUIDE,LED OPE AB..................
88-SX1-203-010 GUIDE,FL AB..................
88-SX1-610-010 CORD,FG 11P AB..................

NOTE: The characters in the suffix column indicate the part usage.
MUSN ...................XX..................................A...................
REF.NO PARTS NO. DESCRIPTION SUFFIX
88-SW1-201-010 GUIDE,LED OPE AB..................
D 702 87-002-787-080 LED,SEL 6215S RED AB..................
D 712 87-070-197-080 LED,SLP7118C-51-S-T1 AB..................
D 711 87-070-197-080 LED,SLP7118C-51-S-T1 AB..................
D 713 87-070-197-080 LED,SLP7118C-51-S-T1 AB..................
S 701 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 704 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 703 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 702 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 714 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 711 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 715 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 712 87-A90-809-080 SW,TACT TSTA-2 AB..................
S 713 87-A90-809-080 SW,TACT TSTA-2 AB..................
C 603 87-010-101-080 CAP, ELECT 220-16 AB..................
C 609 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 605 87-010-198-080 CAP, CHIP 0.022 AB..................
C 604 87-010-237-080 CAP, ELECT 1000-16V AB..................
C 607 87-010-263-080 CAP, ELECT 100-10V AB..................
C 602 87-010-381-080 CAP, ELECT 330-16V AB..................
C 606 87-010-546-080 CAP, ELECT 0.33-50V AB..................
C 601 87-015-997-010 CAP, ELECT 2200UF-16V AB..................
C 614 87-010-197-080 CAP, CHIP 0.01 DM AB..................
C 611 87-010-312-080 C-CAP,S 15P-50 CH AB..................
C 612 87-010-316-080 C-CAP,S 33P-50 CH AB..................
C 610 87-010-320-080 CHIP CAP 68P AB..................
C 613 87-010-404-080 CAP, ELECT 4.7-50V AB..................
D 603 87-017-931-080 ZENER,MTZJ5.6B AB..................
D 602 87-017-931-080 ZENER,MTZJ5.6B AB..................
D 604 87-A40-470-080 DIODE,1SS254 AB..................
FB 301 87-008-372-080 FILTER, EMI BL OIRNI AB..................
FB 603 87-008-372-080 FILTER, EMI BL OIRNI AB..................
FB 602 87-008-372-080 FILTER, EMI BL OIRNI AB..................
FB 601 87-008-372-080 FILTER, EMI BL OIRNI AB..................
IC 601 88-SW1-608-010 IC,M38503M2 AB..................
L 601 87-005-130-080 COIL,10UH AB..................
L 603 87-005-130-080 COIL,10UH AB..................
Q 603 87-026-263-080 C-TR,RN1410 AB..................
Q 609 87-A30-071-080 C-TR,RT1N 144C AB..................
Q 605 87-A30-073-080 C-TR,RT1N 141C AB..................
Q 604 87-A30-073-080 C-TR,RT1N 141C AB..................
Q 606 87-A30-074-080 C-TR,RT1P 141C AB..................
Q 608 87-A30-076-080 C-TR,2SC3052F AB..................
Q 607 87-A30-076-080 C-TR,2SC3052F AB..................
Q 602 89-318-155-080 TR,2SC1815 (0.4W) AB..................
Q 601 89-318-155-080 TR,2SC1815 (0.4W) AB..................
Q 610 87-A30-076-080 C-TR,2SC3052F AB..................
W 601 88-SW1-607-010 CORD,FG9P AB..................
X 601 87-A70-120-080 VIB,8.00MHZ AB..................
C 307 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 302 87-010-318-080 C-CAP,S 47P-50 CH AB..................
C 301 87-010-318-080 C-CAP,S 47P-50 CH AB..................
C 306 87-012-145-080 CAP, CHIP S 270P CH AB..................
C 305 87-012-145-080 CAP, CHIP S 270P CH AB..................
C 303 87-012-157-080 C-CAP,S 330P-50 CH AB..................
C 304 87-012-157-080 C-CAP,S 330P-50 CH AB..................
C 316 87-010-178-080 CHIP CAP 1000P AB..................
C 315 87-010-178-080 CHIP CAP 1000P AB..................
C 314 87-010-180-080 C-CER 1500P AB..................
C 313 87-010-180-080 C-CER 1500P AB..................
C 311 87-010-198-080 CAP, CHIP 0.022 AB..................
C 312 87-010-198-080 CAP, CHIP 0.022 AB..................
C 319 87-012-141-080 CHIP-CAPACITOR,0.22-16F AB..................
C 317 87-012-142-080 CAP, S 0.33-16 AB..................
C 318 87-012-142-080 CAP, S 0.33-16 AB..................
C 324 87-010-260-080 CAP, ELECT 47-25V AB..................
C 325 87-010-370-080 CAP,E 330-6.3 SME AB..................
C 328 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 327 87-010-404-080 CAP, ELECT 4.7-50V AB..................
C 322 87-012-141-080 CHIP-CAPACITOR,0.22-16F AB..................
C 321 87-012-141-080 CHIP-CAPACITOR,0.22-16F AB..................
C 320 87-012-141-080 CHIP-CAPACITOR,0.22-16F AB..................
C 339 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 337 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 332 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 335 87-010-401-080 CAP, ELECT 1-50V AB..................
C 336 87-010-401-080 CAP, ELECT 1-50V AB..................
C 340 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 359 87-010-183-080 C-CAP,S 2700P-50 B AB..................
C 358 87-010-183-080 C-CAP,S 2700P-50 B AB..................
C 357 87-010-197-080 CAP, CHIP 0.01 DM AB..................
C 356 87-010-260-080 CAP, ELECT 47-25V AB..................
C 351 87-012-140-080 CAP 470P AB..................
C 352 87-012-140-080 CAP 470P AB..................
C 360 87-010-183-080 C-CAP,S 2700P-50 B AB..................
C 371 87-010-179-080 CAP,CHIP S B1200P AB..................
ELECTRICAL MAIN PARTS LIST - 1/2 (FX-NM1000)

C 373 87-010-179-080 CAP,CHIP S B1200P AB..................
C 372 87-010-179-080 CAP,CHIP S B1200P AB..................
C 374 87-010-179-080 CAP,CHIP S B1200P AB..................
C 378 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 370 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 376 87-010-545-080 CAP, ELECT 0.22-50V AB..................
C 375 87-010-545-080 CAP, ELECT 0.22-50V AB..................
C 388 87-010-154-080 CAP CHIP 10P AB..................
C 385 87-010-184-080 CHIP CAPACITOR 3300P(K) AB..................
C 386 87-010-196-080 CHIP CAPACITOR,0.1-25 AB..................
C 381 87-010-197-080 CAP, CHIP 0.01 DM AB..................
C 383 87-010-197-080 CAP, CHIP 0.01 DM AB..................
C 382 87-010-318-080 C-CAP,S 47P-50 CH AB..................
C 384 87-010-402-080 CAP, ELECT 2.2-50V AB..................
D 352 87-A40-269-080 C-DIODE,MC2836 AB..................
D 351 87-A40-470-080 DIODE,1SS254 AB..................
IC 302 87-A20-355-010 IC,CXA1553P AB..................
IC 301 87-A20-455-010 IC,HA12211 AB..................
L 302 87-A50-049-010 COIL,TRAP 85K(COI) AB..................
L 301 87-A50-049-010 COIL,TRAP 85K(COI) AB..................
L 351 87-007-342-010 COIL,OSC 85K BIAS AB..................
Q 358 87-026-610-080 TR,KTC3198GR AB..................
Q 357 87-026-610-080 TR,KTC3198GR AB..................
Q 359 87-026-610-080 TR,KTC3198GR AB..................
Q 355 87-A30-074-080 C-TR,RT1P 141C AB..................
Q 354 87-A30-087-080 C-FET,2SK2158 AB..................
Q 353 87-A30-087-080 C-FET,2SK2158 AB..................
Q 351 87-A30-087-080 C-FET,2SK2158 AB..................
Q 360 87-A30-073-080 C-TR,RT1N 141C AB..................
Q 382 87-A30-076-080 C-TR,2SC3052F AB..................
Q 381 87-A30-076-080 C-TR,2SC3052F AB..................
SFR 302 87-A90-636-080 SFR,33K H RH0638C LG AB..................
SFR 303 87-A90-636-080 SFR,33K H RH0638C LG AB..................
SFR 301 87-A90-636-080 SFR,33K H RH0638C LG AB..................
SFR 304 87-A90-636-080 SFR,33K H RH0638C LG AB..................
SFR 306 87-A90-637-080 SFR,47K H RH0638C LG AB..................
SFR 305 87-A90-637-080 SFR,47K H RH0638C LG AB..................
SFR 351 87-A90-637-080 SFR,47K H RH0638C LG AB..................
SFR 352 87-A90-637-080 SFR,47K H RH0638C LG AB..................
D 501 87-A40-269-080 C-DIODE,MC2836 AB..................
Q 506 87-A30-073-080 C-TR,RT1N 141C AB..................
Q 504 87-A30-073-080 C-TR,RT1N 141C AB..................
Q 502 87-A30-085-070 C-TR,CSA1362GR AB..................
Q 503 87-A30-085-070 C-TR,CSA1362GR AB..................
Q 501 89-112-965-080 TR,2SA1296 (0.75W) AB..................
ELECTRICAL MAIN PARTS LIST - 2/2 (FX-NM1000)
