Aiwa NSX-S559 User manual
S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
NSX-S559
NSX-S555
• TYPE: LH,HA
COMPACT DISC STEREO SYSTEM
• BASIC TAPE MECHANISM:2ZM-3MK2 YPR4NM
• BASIC CD MECHANISM:4ZP-1 Z3RDSHM/4ZP-1 Z3RDSCHM
S/M Code No. 09–994–401–7T3
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICAL PARTS LIST-1/4 (MAIN ZZA-7 )<LH>
NOTE: The characters in the suffix column indicate the part usage.
LHJSKM(559) ............XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 307 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 309 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 302 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 301 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 305 87-012-145-080 CAP, CHIP S 270P CH A...................
C 306 87-012-145-080 CAP, CHIP S 270P CH A...................
C 303 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 304 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 314 87-010-178-080 CHIP CAP 1000P A...................
C 313 87-010-178-080 CHIP CAP 1000P A...................
C 315 87-010-178-080 CHIP CAP 1000P A...................
C 316 87-010-178-080 CHIP CAP 1000P A...................
C 310 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 311 87-010-198-080 CAP, CHIP 0.022 A...................
C 312 87-010-198-080 CAP, CHIP 0.022 A...................
C 324 87-010-260-080 CAP, ELECT 47-25V A...................
C 325 87-010-370-080 CAP,E 330-6.3 SME A...................
C 327 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 328 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 321 87-016-492-080 C-CAP,S 0.33-16 FZ A...................
C 322 87-016-492-080 C-CAP,S 0.33-16 FZ A...................
C 339 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 337 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 332 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 336 87-010-401-080 CAP, ELECT 1-50V A...................
C 335 87-010-401-080 CAP, ELECT 1-50V A...................
C 340 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 354 87-010-175-080 CAP 560P A...................
C 358 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 359 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 357 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 356 87-010-260-080 CAP, ELECT 47-25V A...................
C 352 87-012-140-080 CAP 470P A...................
C 351 87-012-140-080 CAP 470P A...................
C 355 87-012-349-080 C-CAP,S 1000P-50 CH A...................
C 360 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 363 87-A10-772-080 CAP,M 5600P-50 J A...................
C 370 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 378 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 379 87-010-406-080 CAP, ELECT 22-50 A...................
C 374 87-016-083-080 C-CAP,S 0.15-16 RK A...................
C 373 87-016-083-080 C-CAP,S 0.15-16 RK A...................
C 386 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 380 87-010-406-080 CAP, ELECT 22-50 A...................
C 388 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 392 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 394 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 391 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 393 87-010-319-080 C-CAP,S 56P-50 CH A...................
CN 301 87-099-827-010 CONN,3P S2M-3W A...................
CN 351 87-099-832-010 CONN,8P S2M-8W A...................
D 352 87-A40-269-080 C-DIODE,MC2836 A...................
IC 303 87-A20-783-040 C-IC,BA7762AFS A...................
L 301 87-A50-049-010 COIL,TRAP 85K(COI) A...................
L 302 87-A50-049-010 COIL,TRAP 85K(COI) A...................
L 351 87-007-342-010 COIL,OSC 85K BIAS A...................
Q 358 87-026-610-080 TR,KTC3198GR A...................
Q 359 87-026-610-080 TR,KTC3198GR A...................
Q 357 87-026-610-080 TR,KTC3198GR A...................
Q 351 87-A30-087-080 C-FET,2SK2158 A...................
Q 353 87-A30-087-080 C-FET,2SK2158 A...................
Q 354 87-A30-087-080 C-FET,2SK2158 A...................
Q 355 87-A30-105-080 C-TR,RT1P 441C A...................
SFR 351 87-A90-433-080 SFR,50K H NVZ6TLTA A...................
SFR 352 87-A90-433-080 SFR,50K H NVZ6TLTA A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
C 101 87-010-178-080 CHIP CAP 1000P A...................
C 102 87-010-178-080 CHIP CAP 1000P A...................
C 103 87-010-405-080 CAP, ELECT 10-50V A...................
C 104 87-010-405-080 CAP, ELECT 10-50V A...................
C 107 87-010-408-080 CAP, ELECT 47-50V A...................
C 108 87-010-408-080 CAP, ELECT 47-50V A...................
C 112 87-010-260-080 CAP, ELECT 47-25V A...................
C 111 87-010-260-080 CAP, ELECT 47-25V A...................
C 117 87-016-247-080 C-CAP,0.1-50 F A...................
C 118 87-016-247-080 C-CAP,0.1-50 F A...................
C 114 87-A10-685-080 C-CAP,S 470P-100 J CH A...................
C 113 87-A10-685-080 C-CAP,S 470P-100 J CH A...................
C 123 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 124 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 122 87-010-178-080 CHIP CAP 1000P A...................
C 121 87-010-178-080 CHIP CAP 1000P A...................
C 129 87-010-191-080 C-CAP,S 0.015-50 F A...................
C 128 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 126 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 125 87-012-368-080 C-CAP,S 0.1-50 F A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICAL PARTS LIST-2/4 (MAIN ZZA-7)<LH>
C 127 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 130 87-010-191-080 C-CAP,S 0.015-50 F A...................
C 131 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 132 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 133 87-010-197-080 CAP, CHIP 0.01 DM A...................
D 104 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 102 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 103 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 109 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 101 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 108 87-A40-488-080 DIODE,1SS244 A...................
D 107 87-A40-488-080 DIODE,1SS244 A...................
D 112 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 114 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 110 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 113 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 115 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 111 87-A40-270-080 C-DIODE,MC2838 A...................
J 203 87-A60-238-010 TERMINAL,SP 4P (MSC) A...................
J 201 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM A...................
L 101 87-003-383-010 COIL,1UH-S A...................
L 102 87-003-383-010 COIL,1UH-S A...................
Q 106 87-A30-075-080 C-TR,2SA1235F A...................
Q 105 87-A30-075-080 C-TR,2SA1235F A...................
Q 103 87-A30-075-080 C-TR,2SA1235F A...................
Q 104 87-A30-075-080 C-TR,2SA1235F A...................
Q 108 87-A30-076-080 C-TR,2SC3052F A...................
Q 109 87-A30-076-080 C-TR,2SC3052F A...................
Q 107 87-A30-076-080 C-TR,2SC3052F A...................
Q 101 87-A30-257-080 C-TR,2SD1306E A...................
Q 102 87-A30-257-080 C-TR,2SD1306E A...................
Q 110 87-A30-076-080 C-TR,2SC3052F A...................
Q 116 87-A30-097-010 TR,FN 1016 A...................
Q 115 87-A30-097-010 TR,FN 1016 A...................
Q 118 87-A30-098-010 TR,FP 1016 A...................
Q 117 87-A30-098-010 TR,FP 1016 A...................
Q 112 87-A30-190-080 TR,CC5551 A...................
Q 111 87-A30-190-080 TR,CC5551 A...................
Q 126 87-A30-075-080 C-TR,2SA1235F A...................
Q 127 87-A30-075-080 C-TR,2SA1235F A...................
Q 129 87-A30-076-080 C-TR,2SC3052F A...................
Q 128 87-A30-076-080 C-TR,2SC3052F A...................
Q 124 87-A30-106-070 C-TR,CMBT5551 A...................
Q 123 87-A30-106-070 C-TR,CMBT5551 A...................
Q 130 87-A30-076-080 C-TR,2SC3052F A...................
Q 131 87-A30-076-080 C-TR,2SC3052F A...................
R 129 87-A00-257-080 RES,M/F 0.15-1W J A...................
R 130 87-A00-257-080 RES,M/F 0.15-1W J A...................
R 132 87-A00-257-080 RES,M/F 0.15-1W J A...................
R 131 87-A00-257-080 RES,M/F 0.15-1W J A...................
R 144 87-A00-440-050 RES,220-1/2W J RP A...................
R 146 87-A00-440-050 RES,220-1/2W J RP A...................
R 145 87-A00-440-050 RES,220-1/2W J RP A...................
R 143 87-A00-440-050 RES,220-1/2W J RP A...................
R 165 87-A00-257-080 RES,M/F 0.15-1W J A...................
R 166 87-A00-257-080 RES,M/F 0.15-1W J A...................
C 204 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 203 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 209 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 211 87-010-181-080 CAP,CHIP S 1800P A...................
C 212 87-010-181-080 CAP,CHIP S 1800P A...................
C 218 87-010-260-080 CAP, ELECT 47-25V A...................
C 217 87-010-260-080 CAP, ELECT 47-25V A...................
C 216 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 215 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 210 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 214 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 213 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 219 87-A10-946-080 C-CAP,S 220P-100 J CH A...................
C 229 87-010-993-080 C-CAP,S 0.056-25 B A...................
C 226 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 225 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 220 87-A10-946-080 C-CAP,S 220P-100 J CH A...................
C 231 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 239 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 232 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 230 87-010-993-080 C-CAP,S 0.056-25 B A...................
C 240 87-010-408-080 CAP, ELECT 47-50V A...................
D 203 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 202 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 201 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 204 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 207 87-A40-488-080 DIODE,1SS244 A...................
D 208 87-A40-488-080 DIODE,1SS244 A...................
D 214 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 211 87-A40-270-080 C-DIODE,MC2838 A...................
J 205 87-A60-751-010 JACK,PIN 2P R/W BLUE A...................
L 201 87-003-383-010 COIL,1UH-S A...................
L 202 87-003-383-010 COIL,1UH-S A...................
Q 204 87-A30-075-080 C-TR,2SA1235F A...................
Q 203 87-A30-075-080 C-TR,2SA1235F A...................
Q 205 87-A30-075-080 C-TR,2SA1235F A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICAL PARTS LIST-3/4 (MAIN ZZA-7)<LH>
Q 206 87-A30-075-080 C-TR,2SA1235F A...................
Q 209 87-A30-076-080 C-TR,2SC3052F A...................
Q 208 87-A30-076-080 C-TR,2SC3052F A...................
Q 207 87-A30-076-080 C-TR,2SC3052F A...................
Q 202 87-A30-257-080 C-TR,2SD1306E A...................
Q 201 87-A30-257-080 C-TR,2SD1306E A...................
Q 210 87-A30-076-080 C-TR,2SC3052F A...................
Q 219 87-A30-119-040 C-TR,2SC3906K R A...................
Q 212 87-A30-190-080 TR,CC5551 A...................
Q 211 87-A30-190-080 TR,CC5551 A...................
Q 218 87-A30-255-010 TR,2SB1342 A...................
Q 217 87-A30-255-010 TR,2SB1342 A...................
Q 215 87-A30-256-010 TR,2SD1933 A...................
Q 216 87-A30-256-010 TR,2SD1933 A...................
Q 225 87-A30-076-080 C-TR,2SC3052F A...................
Q 224 87-A30-076-080 C-TR,2SC3052F A...................
Q 226 87-A30-076-080 C-TR,2SC3052F A...................
Q 227 87-A30-076-080 C-TR,2SC3052F A...................
Q 220 87-A30-119-040 C-TR,2SC3906K R A...................
R 234 87-A00-258-080 RES,M/F 0.22-1W J A...................
R 231 87-A00-258-080 RES,M/F 0.22-1W J A...................
R 232 87-A00-258-080 RES,M/F 0.22-1W J A...................
R 233 87-A00-258-080 RES,M/F 0.22-1W J A...................
R 265 87-A00-258-080 RES,M/F 0.22-1W J A...................
R 266 87-A00-258-080 RES,M/F 0.22-1W J A...................
C 5 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 6 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 3 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 4 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 1 87-012-369-080 C-CAP,S 0.047-50F A...................
C 2 87-012-369-080 C-CAP,S 0.047-50F A...................
C 9 87-A10-520-090 CAP,E 3300-35 M SMG A...................
C 10 87-A10-520-090 CAP,E 3300-35 M SMG A...................
C 29 87-010-247-080 CAP, ELECT 100-50V A...................
C 23 87-010-247-080 CAP, ELECT 100-50V A...................
C 24 87-010-247-080 CAP, ELECT 100-50V A...................
C 26 87-010-263-080 CAP, ELECT 100-10V A...................
C 22 87-010-385-080 CAP, ELECT 220-25V A...................
C 21 87-010-385-080 CAP, ELECT 220-25V A...................
C 25 87-010-430-080 CAP, ELECT 100-63 A...................
C 27 87-012-140-080 CAP 470P A...................
C 30 87-010-112-080 CAP, ELECT 100-16V A...................
C 31 87-010-235-080 CAP,E 470-16 SME A...................
C 34 87-010-405-080 CAP, ELECT 10-50V A...................
C 33 87-010-405-080 CAP, ELECT 10-50V A...................
C 61 87-010-260-080 CAP, ELECT 47-25V A...................
C 62 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 92 87-010-248-080 CAP, ELECT 220-10V A...................
C 93 87-010-380-080 CAP, ELECT 47-16V A...................
C 91 87-010-401-080 CAP, ELECT 1-50V A...................
CNA 1 8Z-NF8-669-010 CONN ASSY,9P VH A...................
D 1 87-017-447-010 DIODE,GBU4DL A...................
D 9 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 8 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 4 87-070-274-080 DIODE,1N4003 SEM A...................
D 3 87-070-274-080 DIODE,1N4003 SEM A...................
D 6 87-070-274-080 DIODE,1N4003 SEM A...................
D 5 87-070-274-080 DIODE,1N4003 SEM A...................
D 7 87-A40-383-080 ZENER,MTZJ30A A...................
D 10 87-A40-345-080 ZENER,MTZJ10C A...................
D 64 87-070-274-080 DIODE,1N4003 SEM A...................
D 62 87-A40-269-080 C-DIODE,MC2836 A...................
D 61 87-A40-270-080 C-DIODE,MC2838 A...................
D 92 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 91 87-020-465-080 DIODE,1SS133 (110MA) A...................
JW 16 87-008-372-080 FILTER, EMI BL OIRNI A...................
Q 2 87-026-609-080 TR,KTA1266GR A...................
Q 1 87-026-609-080 TR,KTA1266GR A...................
Q 5 87-026-610-080 TR,KTC3198GR A...................
Q 8 87-A30-075-080 C-TR,2SA1235F A...................
Q 6 87-A30-076-080 C-TR,2SC3052F A...................
Q 9 87-A30-196-080 TR,2SC4115SRS A...................
Q 4 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 61 87-A30-074-080 C-TR,RT1P 141C A...................
Q 64 87-A30-075-080 C-TR,2SA1235F A...................
Q 62 87-A30-075-080 C-TR,2SA1235F A...................
Q 66 87-A30-075-080 C-TR,2SA1235F A...................
Q 65 87-A30-076-080 C-TR,2SC3052F A...................
Q 67 87-A30-076-080 C-TR,2SC3052F A...................
Q 63 87-A30-076-080 C-TR,2SC3052F A...................
Q 92 87-026-609-080 TR,KTA1266GR A...................
Q 91 87-A30-076-080 C-TR,2SC3052F A...................
WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P A...................
C 457 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 458 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 451 87-010-401-080 CAP, ELECT 1-50V A...................
C 452 87-010-401-080 CAP, ELECT 1-50V A...................
C 459 87-A11-004-080 CAP,M 0.022-50 J DE A...................
C 460 87-A11-004-080 CAP,M 0.022-50 J DE A...................
C 465 87-A11-004-080 CAP,M 0.022-50 J DE A...................
C 466 87-A11-004-080 CAP,M 0.022-50 J DE A...................
IC 451 87-A21-031-040 C-IC,BU4551BF A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICAL PARTS LIST-4/4 (MAIN ZZA-7)<LH>
C 601 87-010-180-080 C-CER 1500P A...................
C 602 87-010-180-080 C-CER 1500P A...................
C 605 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 606 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 619 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 613 87-016-081-080 C-CAP,S 0.1-16 RK A...................
C 614 87-016-081-080 C-CAP,S 0.1-16 RK A...................
C 617 87-A11-008-080 CAP,M 0.056-50 J DE A...................
C 618 87-A11-008-080 CAP,M 0.056-50 J DE A...................
C 616 87-A11-011-080 CAP,M 0.12-50 J DE A...................
C 615 87-A11-011-080 CAP,M 0.12-50 J DE A...................
C 620 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 627 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 622 87-010-401-080 CAP, ELECT 1-50V A...................
C 621 87-010-401-080 CAP, ELECT 1-50V A...................
C 625 87-010-405-080 CAP, ELECT 10-50V A...................
C 629 87-010-405-080 CAP, ELECT 10-50V A...................
C 626 87-010-405-080 CAP, ELECT 10-50V A...................
C 624 87-A10-773-080 CAP,M 0.10-50 J A...................
C 623 87-A10-773-080 CAP,M 0.10-50 J A...................
C 637 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 636 87-010-194-080 CAP, CHIP 0.047 A...................
C 635 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 634 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 630 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 633 87-010-263-080 CAP, ELECT 100-10V A...................
C 632 87-010-263-080 CAP, ELECT 100-10V A...................
C 638 87-010-314-080 C-CAP,S 22P-50V A...................
C 639 87-010-314-080 C-CAP,S 22P-50V A...................
C 631 87-010-992-080 C-CAP,S 0.047-25 B A...................
C 641 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CN 604 87-099-570-010 CONN,13P TUC-P13P-B1 A...................
CN 602 87-A60-131-010 CONN,6P V FE A...................
CN 601 88-NF9-657-010 CONN,30P H BLK TYK-B(X) A...................
D 601 87-A40-002-080 ZENER,MTZJ5.1C A...................
D 602 87-A40-438-080 ZENER,MTZJ4.7A A...................
IC 601 87-A21-011-040 C-IC,M62445FP-600D A...................
J 602 87-A60-398-010 JACK,PIN 2P R/W HSP-242V24 A...................
Q 601 87-026-609-080 TR,KTA1266GR A...................
C 732 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 733 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 731 87-010-560-080 CAP,E 10-50 GAS A...................
C 734 87-012-157-080 C-CAP,S 330P-50 CH A...................
JR 703 87-012-368-080 C-CAP,S 0.1-50 F A...................
Q 732 87-A30-075-080 C-TR,2SA1235F A...................
Q 731 87-A30-076-080 C-TR,2SC3052F A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
MECHANICAL PARTS LIST-1/1 (MAIN ZZA-7)<LH>
NOTE: The characters in the suffix column indicate the part usage.
LHJSKM(559) ............XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICAL PARTS LIST-1/2 (FRONT ZZA-6)<LH>
NOTE: The characters in the suffix column indicate the part usage.
LHJSKM(559) ............XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 503 87-010-112-040 CAP,E 100-16 A...................
C 502 87-010-186-080 CAP,CHIP 4700P A...................
C 506 87-010-320-080 CHIP CAP 68P A...................
C 504 87-010-405-040 CAP,E 10-50 A...................
C 507 87-010-544-040 CAP,E 0.1-50 SME A...................
C 509 87-010-544-040 CAP,E 0.1-50 SME A...................
C 505 87-010-546-040 CAP,E 0.33-50 A...................
J 501 87-A60-651-010 JACK,3.5MONO A...................
Q 504 87-A30-075-080 C-TR,2SA1235F A...................
Q 502 87-A30-076-080 C-TR,2SC3052F A...................
Q 505 87-A30-076-080 C-TR,2SC3052F A...................
Q 503 87-A30-076-080 C-TR,2SC3052F A...................
Q 501 87-A30-087-080 C-FET,2SK2158 A...................
VR 501 87-NB7-602-010 VR,RTRY 10KAX1 1 V A...................
88-NF8-205-010 GUIDE,FL A...................
* 8Z-NF8-201-010 GUIDE,OPE A...................
* 8Z-NF8-202-010 GUIDE,FUN A...................
C 209 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 202 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 208 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 203 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 206 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 207 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 205 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 204 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 201 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 210 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 211 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 254 87-010-194-080 CAP, CHIP 0.047 A...................
C 252 87-010-198-080 CAP, CHIP 0.022 A...................
C 256 87-015-699-040 CAP,E 10-50 7L A...................
C 251 87-015-699-040 CAP,E 10-50 7L A...................
C 259 87-015-699-040 CAP,E 10-50 7L A...................
C 255 87-A10-797-040 CAP,E 47-35 M 5L SRM A...................
C 262 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 260 87-010-198-080 CAP, CHIP 0.022 A...................
C 301 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 302 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 314 87-010-194-080 CAP, CHIP 0.047 A...................
C 311 87-010-194-080 CAP, CHIP 0.047 A...................
C 313 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 312 87-010-405-040 CAP,E 10-50 A...................
C 324 87-010-194-080 CAP, CHIP 0.047 A...................
C 321 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 325 87-010-263-040 CAP,E 100-10 A...................
C 322 87-015-694-040 E/CAP 0.47-50 A...................
C 323 87-016-459-040 CAP,E 470-10 SMG A...................
C 332 87-010-178-080 CHIP CAP 1000P A...................
C 337 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 336 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 331 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 334 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 335 87-012-140-080 CAP 470P A...................
C 333 87-012-140-080 CAP 470P A...................
C 338 87-012-155-080 C-CAP 180P-50CH A...................
C 339 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 341 87-010-194-080 CAP, CHIP 0.047 A...................
C 340 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 351 87-010-382-040 CAP,E 22-25 SME A...................
C 401 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 452 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 453 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 454 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 455 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 457 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 451 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 456 87-012-158-080 C-CAP,S 390P-50 CH A...................
C 601 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 604 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 603 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 602 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 701 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CON 102 87-099-015-010 CONN,13P 6216V A...................
CON 101 88-NF9-658-010 CONN,30P BLK TYK-B(P) A...................
CON 301 87-099-017-010 CONN, 15P 6216 V A...................
D 207 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 208 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 209 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 206 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 213 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 216 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 219 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 217 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 214 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 212 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 215 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 218 87-020-465-080 DIODE,1SS133 (110MA) A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICAL PARTS LIST-2/2 (FRONT ZZA-6)<LH>
D 226 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 222 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 225 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 221 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 224 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 223 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 220 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 227 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 252 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 253 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 251 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 311 87-A40-509-080 ZENER,MTZJ6.8C A...................
D 323 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 324 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 321 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 334 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 336 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 333 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 331 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 332 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 335 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 351 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 352 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 452 87-017-932-080 ZENER,MTJ6.2B A...................
D 451 87-020-465-080 DIODE,1SS133 (110MA) A...................
EMI 201 87-008-372-080 FILTER, EMI BL OIRNI A...................
EMI 202 87-A50-322-080 C-COIL,S BK2125 LM252 A...................
EMI 701 87-A50-322-080 C-COIL,S BK2125 LM252 A...................
FL 401 8Z-NF8-616-010 FL,SVA-11MM22 A...................
IC 201 8Z-NF8-675-010 C-IC,UPD780228GF-037-3BA A...................
IC 251 87-A20-914-010 IC,SPS-442-1-F A...................
IC 451 87-A21-023-040 C-IC,BA3835F A...................
IC 601 87-A21-021-040 C-IC,BU2099FV A...................
L 331 87-A50-434-010 COIL,CLK 4.19M(TOKO) A...................
LED 311 87-A40-317-080 LED,SLR-342VCT31 RED A...................
LED 601 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 602 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 603 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 604 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 607 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 608 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 606 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 605 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 609 87-A40-619-080 LED,SLR-56PT-TE7-W GRN A...................
LED 614 87-A40-619-080 LED,SLR-56PT-TE7-W GRN A...................
LED 612 87-A40-619-080 LED,SLR-56PT-TE7-W GRN A...................
LED 613 87-A40-619-080 LED,SLR-56PT-TE7-W GRN A...................
LED 610 87-A40-619-080 LED,SLR-56PT-TE7-W GRN A...................
LED 611 87-A40-619-080 LED,SLR-56PT-TE7-W GRN A...................
LED 632 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 634 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 633 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
LED 631 87-A40-619-040 LED,SLR-56PT-T31-W GRN A...................
Q 207 87-A30-087-080 C-FET,2SK2158 A...................
Q 251 87-A30-074-080 C-TR,RT1P 141C A...................
Q 302 87-A30-067-080 C-TR,2SA 1298Y A...................
Q 301 87-A30-067-080 C-TR,2SA 1298Y A...................
Q 303 87-A30-240-080 TR,CSA1585BC A...................
Q 311 87-026-610-080 TR,KTC3198GR A...................
Q 312 87-A30-087-080 C-FET,2SK2158 A...................
Q 322 87-A30-073-080 C-TR,RT1N 141C A...................
Q 323 87-A30-087-080 C-FET,2SK2158 A...................
S 405 87-A91-024-080 SW,TACT KSH0611BT A...................
S 403 87-A91-024-080 SW,TACT KSH0611BT A...................
S 401 87-A91-024-080 SW,TACT KSH0611BT A...................
S 404 87-A91-024-080 SW,TACT KSH0611BT A...................
S 402 87-A91-024-080 SW,TACT KSH0611BT A...................
S 408 87-A91-024-080 SW,TACT KSH0611BT A...................
S 407 87-A91-024-080 SW,TACT KSH0611BT A...................
S 409 87-A91-024-080 SW,TACT KSH0611BT A...................
S 406 87-A91-024-080 SW,TACT KSH0611BT A...................
S 412 87-A91-024-080 SW,TACT KSH0611BT A...................
S 418 87-A91-024-080 SW,TACT KSH0611BT A...................
S 419 87-A91-024-080 SW,TACT KSH0611BT A...................
S 410 87-A91-024-080 SW,TACT KSH0611BT A...................
S 414 87-A91-024-080 SW,TACT KSH0611BT A...................
S 415 87-A91-024-080 SW,TACT KSH0611BT A...................
S 411 87-A91-024-080 SW,TACT KSH0611BT A...................
S 417 87-A91-024-080 SW,TACT KSH0611BT A...................
S 413 87-A91-024-080 SW,TACT KSH0611BT A...................
S 416 87-A91-024-080 SW,TACT KSH0611BT A...................
S 428 87-A91-024-080 SW,TACT KSH0611BT A...................
S 424 87-A91-024-080 SW,TACT KSH0611BT A...................
S 420 87-A91-024-080 SW,TACT KSH0611BT A...................
S 425 87-A91-024-080 SW,TACT KSH0611BT A...................
S 421 87-A91-024-080 SW,TACT KSH0611BT A...................
S 426 87-A91-024-080 SW,TACT KSH0611BT A...................
S 423 87-A91-024-080 SW,TACT KSH0611BT A...................
S 422 87-A91-024-080 SW,TACT KSH0611BT A...................
S 427 87-A91-024-080 SW,TACT KSH0611BT A...................
S 434 87-A91-024-080 SW,TACT KSH0611BT A...................
SW 252 87-A90-535-010 SW,RTRY EC16B24304 A...................
SW 253 87-A90-950-010 SW,RTRY EC12E12504 ENCORDER A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
MECHANICAL PARTS LIST-1/1<LH>
NOTE: The characters in the suffix column indicate the part usage.
LHJSKM(559) ............XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
88-NF8-205-010 GUIDE,FL A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICAL PARTS LIST-1/1 (PT ZZA-8)<LH>
NOTE: The characters in the suffix column indicate the part usage.
LHJSKM(559) ............XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 1 87-010-387-080 CAP,E 470-25 SME A...................
C 8 87-A10-520-090 CAP,E 3300-35 M SMG A...................
C 9 87-A10-520-090 CAP,E 3300-35 M SMG A...................
C 3 87-A11-148-080 CAP,TC U 0.1-50 Z F A...................
C 4 87-A11-148-080 CAP,TC U 0.1-50 Z F A...................
C 5 87-A11-148-080 CAP,TC U 0.1-50 Z F A...................
C 6 87-A11-148-080 CAP,TC U 0.1-50 Z F A...................
C 31 87-010-403-080 CAP, ELECT 3.3-50V A...................
CN 1 87-A60-851-010 CONN,9P V VH A...................
D 6 87-017-447-010 DIODE,GBU4DL A...................
D 4 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 3 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 2 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 5 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 1 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 31 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 32 87-020-465-080 DIODE,1SS133 (110MA) A...................
PR 1 87-026-682-080 PROTECTOR,10A 60V491 A...................
PR 2 87-026-682-080 PROTECTOR,10A 60V491 A...................
PT 2 8Z-NF8-663-010 PT,SUB ZNF-8(H) A...................
Q 31 87-026-245-080 TR,DTC114ES A...................
Q 32 87-A30-198-080 TR,KTC3199GR A...................
RY 1 87-A91-281-010 RELAY,AC DC12V OSA-SS-212DM5 A...................
S 1 87-A90-165-010 SW,SL 1-2-3 SWS2301 A...................
T 2 87-A60-317-010 TERMINAL, 1P MSC A...................
T 1 87-A60-317-010 TERMINAL, 1P MSC A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
NOTE: The characters in the suffix column indicate the part usage.
URTM ...................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 701 87-010-381-080 0E CAP, ELECT 330-16V ABC.................
C 702 87-010-404-080 0E CAP, ELECT 4.7-50V ABC.................
C 704 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 703 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 711 87-010-260-080 0E CAP, ELECT 47-25V ABC.................
C 711 87-010-553-080 0E CAP,E 47-16 ....................
C 712 87-010-831-080 0E C-CAP,U,0.1-16F ABC.................
C 718 87-012-179-080 0E C-CAP,U 20P-50 CH .BC.................
C 714 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 717 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 719 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 727 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................
C 728 87-010-248-080 0E CAP, ELECT 220-10V ABC.................
C 721 87-012-176-080 0E CAP 15P ABC.................
C 722 87-012-176-080 0E CAP 15P ABC.................
C 720 87-012-195-080 0E C-CAP,U 100P-50CH ABC.................
C 729 87-012-274-080 0E CHIP CAP,U 1000P-50B ABC.................
C 725 87-018-131-080 0E CAP, CER 1000P-50V ....................
CN 701 87-A60-650-010 1A CONN,16P H GRY TUC-P16X-C1 ....................
CN 701 87-A60-700-010 0E CONN,13P H GRY TUC-P13X-C1 ABC.................
D 721 87-017-149-080 0E ZENER,HZS6A2L .BC.................
D 722 87-020-465-080 0E DIODE,1SS133 (110MA) ....................
D 721 87-A40-234-080 0E ZENER,MTZJ5.6A A...................
IC 721 87-070-127-110 1C IC,LC72131 D ABC.................
Q 713 87-A30-072-080 0E C-TR,RT1P 144C ....................
Q 712 87-A30-072-080 0E C-TR,RT1P 144C ....................
Q 711 87-A30-196-080 0E TR,2SC4115SRS A...................
Q 711 87-A30-234-080 0E TR,CSC4115BC .BC.................
X 721 87-A70-061-010 1A VIB,XTAL 4.500MHZ CSA-309 ABC.................
C 872 87-010-400-080 0E CAP, ELECT 0.47-50V AB..................
C 873 87-010-404-080 0E CAP, ELECT 4.7-50V AB..................
C 877 87-012-278-080 0E C-CAP,U 2200P-50 B AB..................
C 878 87-012-278-080 0E C-CAP,U 2200P-50 B AB..................
C 889 87-010-248-080 0E CAP, ELECT 220-10V AB..................
C 884 87-010-260-080 0E CAP, ELECT 47-25V AB..................
C 883 87-010-404-080 0E CAP, ELECT 4.7-50V AB..................
C 885 87-010-545-080 0E CAP, ELECT 0.22-50V A...................
C 886 87-010-545-080 0E CAP, ELECT 0.22-50V A...................
C 888 87-010-787-080 0E CAP, U 0.022-25 AB..................
C 881 87-012-141-080 0E CHIP-CAPACITOR,0.22-16F AB..................
C 882 87-012-172-080 0E CAPACITOR CHIP U 10P CH AB..................
C 887 87-012-286-080 0E CAP, U 0.01-25 AB..................
C 885 87-016-460-080 0E C-CAP,S 0.22-16 B .B..................
C 886 87-016-460-080 0E C-CAP,S 0.22-16 B .B..................
IC 871 87-070-060-040 1F IC,TA2040AF AB..................
Q 873 87-026-226-080 0E CHIP-TR,DTA143EK AB..................
X 891 87-030-394-010 1B VIB,CER CSA3.6MGF228 AB..................
C 705 87-010-213-080 0E C-CAP,S 0.015-50 B ....................
C 706 87-010-213-080 0E C-CAP,S 0.015-50 B ....................
C 705 87-A10-592-080 0E C-CAP,S 0.015-50 J B .BC.................
C 706 87-A10-592-080 0E C-CAP,S 0.015-50 J B .BC.................
C 733 87-010-180-080 0E C-CER 1500P ....................
C 738 87-010-180-080 0E C-CER 1500P ....................
C 737 87-010-180-080 0E C-CER 1500P ....................
C 734 87-010-180-080 0E C-CER 1500P ....................
C 735 87-010-213-080 0E C-CAP,S 0.015-50 B ....................
C 736 87-010-213-080 0E C-CAP,S 0.015-50 B ....................
C 736 87-010-987-080 0E C-CAP,S 1500P-50 CH .BC.................
C 733 87-010-987-080 0E C-CAP,S 1500P-50 CH .BC.................
C 735 87-010-987-080 0E C-CAP,S 1500P-50 CH .BC.................
C 734 87-010-987-080 0E C-CAP,S 1500P-50 CH .BC.................
C 734 87-012-280-080 0E CAP, U 3300P-50 ....................
C 733 87-012-280-080 0E CAP, U 3300P-50 ....................
C 738 87-A10-592-080 0E C-CAP,S 0.015-50 J B .BC.................
C 737 87-A10-592-080 0E C-CAP,S 0.015-50 J B .BC.................
C 752 87-010-220-080 0E C-CAP,S 0.018-25 B .B..................
C 751 87-010-220-080 0E C-CAP,S 0.018-25 B .B..................
C 758 87-012-167-080 0E C-CAP,U 5P-50 CH ABC.................
C 757 87-012-188-080 0E C-CAP,U 47P-50 CH ABC.................
C 753 87-012-195-080 0E C-CAP,U 100P-50CH ....................
C 752 87-012-282-080 0E CAP, U 4700P-50 ....................
C 756 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 751 87-012-365-080 0E C-CAP,S 0.027-25VBK ..C.................
C 752 87-012-365-080 0E C-CAP,S 0.027-25VBK ..C.................
C 766 87-010-197-080 0E CAP, CHIP 0.01 DM ....................
C 769 87-010-260-080 0E CAP, ELECT 47-25V ABC.................
C 768 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 765 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 764 87-012-337-080 0E C-CAP,U 56P-50 CH ABC.................
C 774 87-010-263-080 0E CAP, ELECT 100-10V ABC.................
C 771 87-010-383-080 0E CAP, ELECT 33-25V ABC.................
C 777 87-010-400-080 0E CAP, ELECT 0.47-50V ABC.................
C 775 87-010-404-080 0E CAP, ELECT 4.7-50V ABC.................
C 777 87-010-493-040 0E CAP,E 0.47-50 GAS ....................
C 777 87-010-493-080 0E CAP,E 0.47-50 GAS ....................
C 770 87-010-829-080 0E CAP, U 0.047-16 ABC.................
ELECTRICAL PARTS LIST-1/3 (TUNER ZZA-1)<LH>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
C 780 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................
C 786 87-010-401-080 0E CAP, ELECT 1-50V ABC.................
C 785 87-010-401-080 0E CAP, ELECT 1-50V ABC.................
C 786 87-010-405-080 0E CAP, ELECT 10-50V ABC.................
C 785 87-010-405-080 0E CAP, ELECT 10-50V ABC.................
C 785 87-010-494-080 0E CAP ELECT GAS 1/50 ....................
C 786 87-010-494-080 0E CAP ELECT GAS 1/50 ....................
C 787 87-012-275-080 0E C-CAP,U 1200P-50 B ABC.................
C 788 87-012-275-080 0E C-CAP,U 1200P-50 B ABC.................
C 784 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 796 87-010-403-080 0E CAP, ELECT 3.3-50V ABC.................
C 794 87-010-406-080 0E CAP, ELECT 22-50 ABC.................
C 795 87-010-596-080 0E CAP, S 0.047-16 ..C.................
C 793 87-012-273-080 0E C-CAP,U 820P-50 B ABC.................
C 797 87-012-276-080 0E CAP, CHIP SS 1500 PBK A...................
C 798 87-012-276-080 0E CAP, CHIP SS 1500 PBK A...................
D 771 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................
D 773 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................
IC 771 87-A20-913-010 1D IC,LA1837NL ABC.................
L 771 87-A50-266-010 1A COIL,FM DET-2N(TOK) ABC.................
L 772 87-A90-052-010 1C FLTR,CFMT-450A(TOK) ....................
L 772 87-A90-053-010 1C FLTR,PCFMT-060(TOK) AB..................
L 772 87-A90-733-010 1A FLTR,PCFAZH-450 (TOK) ....................
L 772 87-A91-110-010 FLTR,PCFJZH-450 (TOK) ..C.................
L 781 87-005-847-080 0E COIL,2.2UH(CECS) ....................
L 792 87-A50-027-010 1A COIL,1 POLE MPX(TOK) ....................
L 791 87-A50-027-010 1A COIL,1 POLE MPX(TOK) ....................
X 771 87-030-354-010 1A VIB,CF BFU 450C ....................
C 859 87-012-286-080 0E CAP, U 0.01-25 ....................
C 865 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ....................
C 866 87-010-405-080 0E CAP, ELECT 10-50V ....................
C 864 87-010-405-080 0E CAP, ELECT 10-50V ....................
C 869 87-012-180-080 0E C-CAP,U 22P-50 CH ....................
C 868 87-012-184-080 0E C-CAP,U 33P-50 CH ....................
C 862 87-012-199-080 0E CAP 220P ....................
C 861 87-012-199-080 0E CAP 220P ....................
C 863 87-012-270-080 0E CAP, U 470P-50 ....................
C 867 87-012-286-080 0E CAP, U 0.01-25 ....................
IC 851 87-A20-440-040 1H C-IC,BU1920FS ....................
L 851 87-005-847-080 0E COIL,2.2UH(CECS) ....................
Q 853 87-A30-076-080 0E C-TR,2SC3052F ....................
X 851 87-A70-091-010 1B VIB,XTAL 4.332MHZ CSA-309 ....................
C 820 87-010-260-080 0E CAP, ELECT 47-25V ABC.................
C 942 87-012-172-080 0E CAPACITOR CHIP U 10P CH ....................
C 941 87-012-180-080 0E C-CAP,U 22P-50 CH ....................
C 947 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 940 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 944 87-014-049-080 0E CAP,PP 470P-100 J ....................
C 944 87-014-051-080 0E CAPACITOR (PP), 560P ....................
C 949 87-A10-039-080 0E C-CAP,U 470P-50 J CH ....................
C 958 87-010-197-080 0E CAP, CHIP 0.01 DM ....................
C 956 87-010-263-080 0E CAP, ELECT 100-10V ....................
C 959 87-010-831-080 0E C-CAP,U,0.1-16F ....................
C 952 87-012-286-080 0E CAP, U 0.01-25 ABC.................
C 954 87-012-358-080 0E C-CAP,S 0.47-10 F Z ....................
C 950 87-014-073-080 0E CAP,PP 4700P-100 J ....................
C 963 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ABC.................
C 962 87-010-401-080 0E CAP, ELECT 1-50V ....................
C 964 87-012-170-080 0E C-CAP,U 8P-50 CH A...................
C 961 87-012-174-080 0E CAP CHIP CERA SS 12P CHJ .BC.................
C 960 87-012-350-080 0E C-CAP,1-25 F ....................
CF 802 82-785-747-010 1A CF MS2 GHY R ....................
CF 802 87-008-261-010 1A FILTER, SFE10.7MA5-A ABC.................
CF 801 87-008-261-010 1A FILTER, SFE10.7MA5-A ABC.................
CF 801 87-008-423-010 1A CERAMIC FILTER, SFE10.7 ....................
D 944 87-020-465-080 0E DIODE,1SS133 (110MA) ....................
D 942 87-A40-270-080 0E C-DIODE,MC2838 ....................
FFE 801 A8-6ZA-190-030 0E 6ZA-1 FEUNM ....................
FFE 801 A8-6ZA-191-130 6ZA-1 FEENM ....................
FFE 801 A8-6ZA-192-030 2Y 6ZA-1 FEJNM .B..................
FFE 801 A8-6ZA-199-170 6ZA-1 FEENC ....................
FFE 801 A8-6ZA-19A-070 6ZA-1 FEJNC ....................
FFE 801 A8-6ZA-19D-070 1H 6ZA-1 YFEJNC A...................
FFE 801 A8-8ZA-190-030 8ZA-1 FEUNM ..C.................
FFE 801 A8-8ZA-192-070 8ZA-1 FEUNC ....................
FFE 801 A8-8ZA-193-070 1E 8ZA-1 YFEUNC ....................
J 801 87-033-241-010 1B TERMINAL,ANT AJ-2039 ....................
J 801 87-A60-702-010 1B TERMINAL,ANT 4P CJ-9036 ABC.................
J 801 87-A60-703-010 1A TERMINAL,ANT 3P CJ-9037 ....................
J 940 81-754-629-010 0E CONNECTOR, 2P ....................
L 832 87-005-847-080 0E COIL,2.2UH(CECS) ....................
L 943 87-005-372-080 0E COIL S 1MHM ....................
L 942 87-A50-019-010 0E COIL,OSC LW(COI) ....................
L 941 87-A50-020-010 0E COIL,ANT LW(COI) ....................
L 941 87-A50-022-010 0E COIL,ANT SW(COI) ....................
L 944 87-A50-159-010 0E COIL,10MH K C2B ....................
L 942 87-A50-173-010 0E COIL,OSC SW-N(COI) ....................
L 943 87-A50-432-010 COIL,1MH K CW ....................
L 981 87-A50-430-010 COIL,ANT MW(3BSW) ....................
L 982 87-A50-431-010 COIL,OSC MW(3BSW) ....................
L 981 87-NF4-650-010 1D COIL,AM PACK 4N(TOK) A...................
L 981 87-NF4-651-010 1C COIL,AM PACK2N(TOM) ....................
ELECTRICAL PARTS LIST-2/3 (TUNER ZZA-1)<LH>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
L 981 88-NF8-625-110 1D COIL,AM PACK3N(TOK) ....................
L 981 8Z-ZA1-664-010 COIL,AM PACK 4(TOK) .BC.................
L 981 8Z-ZA1-665-010 COIL,AM PACK 2(TOK) ....................
Q 712 87-A30-072-080 0E C-TR,RT1P 144C ABC.................
Q 805 89-327-143-080 0E TR,2SC2714 (0.1W) ABC.................
Q 943 87-A30-075-080 0E C-TR,2SA1235F ....................
Q 942 87-A30-075-080 0E C-TR,2SA1235F ....................
Q 949 87-A30-076-080 0E C-TR,2SC3052F ....................
Q 945 87-A30-076-080 0E C-TR,2SC3052F ....................
Q 944 87-A30-076-080 0E C-TR,2SC3052F ....................
Q 948 87-A30-086-070 0E C-TR,CSD1306E ....................
Q 947 89-503-602-080 1A C-FET,2SK360E ....................
Q 947 89-505-434-540 0E C-FET,2SK543(4/5) ....................
Q 951 87-A30-074-080 0E C-TR,RT1P 141C ....................
SCR 981 87-A40-618-080 VARI-CAP,SVC 348(S/T) ....................
TC 942 87-011-164-010 0E CAPACITOR,TRIMMER 30P ....................
TC 941 87-011-173-010 1A CERAMIC TRIMMER 20P ....................
TC 941 87-011-220-080 1A TRIMMER CAP 20P VTC ....................
TC 943 87-011-221-080 1A CAP, TRIMMER 30P ....................
ELECTRICAL PARTS LIST-3/3 (TUNER ZZA-1)<LH>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
NOTE: The characters in the suffix column indicate the part usage.
HASC2M(555) ............XX...............................................N......
¦¦+
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 503 87-010-112-040 CAP,E 100-16 ..CD..G....LMN......
C 508 87-010-178-080 CHIP CAP 1000P ......G....LMN......
C 502 87-010-186-080 CAP,CHIP 4700P ..CD..G....LMN......
C 506 87-010-320-080 CHIP CAP 68P ..CD..G....LMN......
C 504 87-010-405-040 CAP,E 10-50 ......G....LMN......
C 504 87-010-405-080 CAP, ELECT 10-50V ..CD................
C 507 87-010-544-040 CAP,E 0.1-50 SME ..CD..G....LMN......
C 509 87-010-544-040 CAP,E 0.1-50 SME ..CD..G....LMN......
C 505 87-010-546-040 CAP,E 0.33-50 ..CD..G....LMN......
J 501 87-A60-651-010 JACK,3.5MONO ..CD..G....LMN......
Q 504 87-A30-075-080 C-TR,2SA1235F ..CD..G....LMN......
Q 502 87-A30-076-080 C-TR,2SC3052F ..CD..G....LMN......
Q 501 87-A30-087-080 C-FET,2SK2158 ..CD..G....LMN......
VR 501 87-NB7-602-010 VR,RTRY 10KAX1 1 V ..CD..G....LMN......
C 1 87-010-387-080 CAP,E 470-25 SME AB....G.IJKLMN......
C 1 87-010-388-080 CAP ELECT 1000-25V SME ..CDEF..............
C 4 87-010-403-080 CAP, ELECT 3.3-50V ....................
C 2 87-018-209-010 CAP 0.1 ..CD....IJK.........
C 9 87-A10-520-090 CAP,E 3300-35 M SMG ..CD..G....LMN......
C 8 87-A10-520-090 CAP,E 3300-35 M SMG ..CD..G....LMN......
C 3 87-A11-148-080 CAP,TC U 0.1-50 Z F ......G....LMN......
C 5 87-A11-148-080 CAP,TC U 0.1-50 Z F ......G....LMN......
C 4 87-A11-148-080 CAP,TC U 0.1-50 Z F ......G....LMN......
C 6 87-A11-148-080 CAP,TC U 0.1-50 Z F ......G....LMN......
C 31 87-010-403-040 CAP,E 3.3-50 SME ......G.IJKLMN......
CN 1 87-A60-850-010 CONN,7P V VH AB..EF..IJK.........
CN 1 87-A60-851-010 CONN,9P V VH ..CD..G....LMN......
D 6 87-017-447-010 DIODE,GBU4DL ..CD................
D 6 87-A40-548-090 DIODE,D3SBA20 ......G....LMN......
D 32 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFG.IJKLMN......
D 31 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFG.IJKLMN......
PR 1 87-026-682-080 PROTECTOR,10A 60V491 ......G....LMN......
PR 2 87-026-682-080 PROTECTOR,10A 60V491 ......G....LMN......
PR 1 87-A91-276-080 FUSE,125MA 125V F 251 ....................
PT 2 8Z-NF8-660-010 PT,SUB ZNF-8(D) ....................
PT 2 8Z-NF8-661-010 PT,SUB ZNF-8(U) AB..................
PT 2 8Z-NF8-662-010 PT,SUB ZNF-8(E) ....EF..IJK.........
PT 2 8Z-NF8-663-010 PT,SUB ZNF-8(H) ..CD..G....LMN......
Q 31 87-026-245-080 TR,DTC114ES ......G.IJKLMN......
Q 32 87-A30-198-080 TR,KTC3199GR ......G.IJKLMN......
RY 1 87-045-389-010 RELAY,OSA-SS-212DM5 ....................
RY 1 87-A90-976-010 RELAY,AC12V SDT-S-112LMR AB..EF..IJK.........
RY 1 87-A91-281-010 RELAY,AC DC12V OSA-SS-212DM5 ..CD..G....LMN......
S 1 87-A90-165-010 SW,SL 1-2-3 SWS2301 ..CD..G....LMN......
T 2 87-A60-317-010 TERMINAL, 1P MSC ABCDEFG.IJKLMN......
T 1 87-A60-317-010 TERMINAL, 1P MSC ABCDEFG.IJKLMN......
88-NF8-205-010 GUIDE,FL ABCDEFG....LMN......
* 8Z-NF8-201-010 GUIDE,OPE ABCDEFG.............
* 8Z-NF8-201-110 GUIDE,OPE ...........LMN......
* 8Z-NF8-202-010 GUIDE,FUN ABCDEFG....LMN......
C 201 87-012-156-080 C-CAP,S 220P-50 CH ABCDEFG....LMN......
C 254 87-010-194-080 CAP, CHIP 0.047 ABCDEFG....LMN......
C 252 87-010-198-080 CAP, CHIP 0.022 ABCDEFG....LMN......
C 251 87-015-699-040 CAP,E 10-50 7L ABCDEFG....LMN......
C 256 87-015-699-040 CAP,E 10-50 7L ABCDEFG....LMN......
C 259 87-015-699-040 CAP,E 10-50 7L ABCDEFG....LMN......
C 255 87-A10-586-040 CAP,E 47-35 7L SR ABCDEF..............
C 255 87-A10-797-040 CAP,E 47-35 M 5L SRM ......G....LMN......
C 260 87-010-198-080 CAP, CHIP 0.022 ABCDEFG....LMN......
C 302 87-010-182-080 C-CAP,S 2200P-50 B ABCDEFG....LMN......
C 301 87-010-182-080 C-CAP,S 2200P-50 B ABCDEFG....LMN......
C 311 87-010-194-080 CAP, CHIP 0.047 ABCDEFG....LMN......
C 314 87-010-194-080 CAP, CHIP 0.047 ABCDEFG....LMN......
C 312 87-010-405-040 CAP,E 10-50 ABCDEFG....LMN......
C 324 87-010-194-080 CAP, CHIP 0.047 ABCDEFG....LMN......
C 323 87-010-248-040 CAP,E 220-10 SME ABCDEF..............
C 325 87-010-263-040 CAP,E 100-10 ABCDEFG....LMN......
C 322 87-015-694-040 E/CAP 0.47-50 ABCDEFG....LMN......
C 323 87-016-459-040 CAP,E 470-10 SMG ......G....LMN......
C 332 87-010-178-080 CHIP CAP 1000P ABCDEFG....LMN......
C 334 87-010-312-080 C-CAP,S 15P-50 CH ABCDEFG....LMN......
C 333 87-012-140-080 CAP 470P ABCDEFG....LMN......
C 335 87-012-140-080 CAP 470P ABCDEFG....LMN......
C 338 87-012-155-080 C-CAP 180P-50CH ABCDEFG....LMN......
C 339 87-012-156-080 C-CAP,S 220P-50 CH ABCDEFG....LMN......
C 341 87-010-194-080 CAP, CHIP 0.047 ABCDEFG....LMN......
C 340 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFG....LMN......
C 351 87-010-382-040 CAP,E 22-25 SME ABCDEFG....LMN......
C 401 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFG....LMN......
C 455 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG....LMN......
C 457 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG....LMN......
C 456 87-012-158-080 C-CAP,S 390P-50 CH ABCDEFG....LMN......
C 601 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG....LMN......
C 604 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFG....LMN......
C 603 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFG....LMN......
C 602 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFG....LMN......
ELECTRICAL PARTS LIST- 1/6 <HA>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
C 701 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG....LMN......
CON 102 87-099-015-010 CONN,13P 6216V ABCDEFG....LMN......
CON 101 87-099-720-010 CONN,30P TYK-B(P) ABCDEF..............
CON 101 88-NF9-658-010 CONN,30P BLK TYK-B(P) ......G....LMN......
CON 301 87-099-013-010 CONN,11P 6216 V AB..EF..............
CON 301 87-099-017-010 CONN, 15P 6216 V ..CD..G....LMN......
D 204 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFG....LMN......
D 311 87-A40-509-080 ZENER,MTZJ6.8C ABCDEFG....LMN......
D 452 87-017-932-080 ZENER,MTJ6.2B ABCDEFG....LMN......
EMI 201 87-008-372-080 FILTER, EMI BL OIRNI ABCDEFG....LMN......
EMI 202 87-A50-322-080 C-COIL,S BK2125 LM252 ABCDEFG....LMN......
EMI 701 87-A50-322-080 C-COIL,S BK2125 LM252 ABCDEFG....LMN......
FL 401 8Z-NF8-616-010 FL,SVA-11MM22 ABCDEFG....LMN......
FL 401 8Z-NH8-603-010 FL,BJ674GNK ....................
IC 201 8Z-NF8-602-010 C-IC,UPD780228GF-031-3BA ABCDEF..............
IC 201 8Z-NF8-675-010 C-IC,UPD780228GF-037-3BA ......G....LMN......
IC 251 87-A20-914-010 IC,SPS-442-1-F ..CDEF..............
IC 251 87-A20-951-010 IC,TSOP1838RF1 ......G....LMN......
IC 251 87-NF8-614-010 IC,SPS-442-1-W AB..................
IC 451 87-A21-023-040 C-IC,BA3835F ABCDEFG....LMN......
IC 601 87-A21-021-040 C-IC,BU2099FV ABCDEFG....LMN......
L 331 87-A50-434-010 COIL,CLK 4.19M(TOKO) ABCDEFG....LMN......
LED 311 87-A40-317-080 LED,SLR-342VCT31 RED ABCDEFG....LMN......
LED 611 87-A40-619-080 LED,SLR-56PT-TE7-W GRN ABCDEFG....LMN......
LED 634 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABCDEFG....LMN......
LED 633 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABCDEFG....LMN......
Q 207 87-A30-087-080 C-FET,2SK2158 ABCDEFG....LMN......
Q 251 87-A30-074-080 C-TR,RT1P 141C ABCDEFG....LMN......
Q 302 87-A30-067-080 C-TR,2SA 1298Y ...DEFG....LMN......
Q 301 87-A30-067-080 C-TR,2SA 1298Y ...DEFG....LMN......
Q 301 87-A30-159-080 C-TR,KTA1298Y ABC.................
Q 302 87-A30-159-080 C-TR,KTA1298Y ABC.................
Q 303 87-A30-200-080 TR,2SA1585SR ...........LMN......
Q 303 87-A30-240-080 TR,CSA1585BC ABCDEFG.............
Q 311 87-026-610-080 TR,KTC3198GR ABCDEFG....LMN......
Q 312 87-A30-087-080 C-FET,2SK2158 ABCDEFG....LMN......
Q 322 87-A30-073-080 C-TR,RT1N 141C ABCDEFG....LMN......
Q 323 87-A30-087-080 C-FET,2SK2158 ABCDEFG....LMN......
S 434 87-A90-164-080 SW,TACT SKQAB(N) AB..................
S 431 87-A91-024-080 SW,TACT KSH0611BT ..CDEFG....LMN......
S 432 87-A91-024-080 SW,TACT KSH0611BT ..CDEFG....LMN......
S 430 87-A91-024-080 SW,TACT KSH0611BT ..CDEFG....LMN......
SW 252 87-A90-535-010 SW,RTRY EC16B24304 ABCDEFG....LMN......
SW 253 87-A90-950-010 SW,RTRY EC12E12504 ENCORDER ABCDEFG....LMN......
C 309 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 302 87-010-318-080 C-CAP,S 47P-50 CH ABCDEFG.IJKLMN......
C 301 87-010-318-080 C-CAP,S 47P-50 CH ABCDEFG.IJKLMN......
C 305 87-012-145-080 CAP, CHIP S 270P CH ABCDEFG.IJKLMN......
C 306 87-012-145-080 CAP, CHIP S 270P CH ABCDEFG.IJKLMN......
C 303 87-012-157-080 C-CAP,S 330P-50 CH ABCDEFG.IJKLMN......
C 304 87-012-157-080 C-CAP,S 330P-50 CH ABCDEFG.IJKLMN......
C 314 87-010-178-080 CHIP CAP 1000P ..CD..G....LMN......
C 315 87-010-178-080 CHIP CAP 1000P ..CD..G....LMN......
C 313 87-010-178-080 CHIP CAP 1000P ..CD..G....LMN......
C 316 87-010-178-080 CHIP CAP 1000P ..CD..G....LMN......
C 313 87-010-180-080 C-CER 1500P AB..EF..IJK.........
C 314 87-010-180-080 C-CER 1500P AB..EF..IJK.........
C 316 87-010-182-080 C-CAP,S 2200P-50 B AB..EF..IJK.........
C 315 87-010-182-080 C-CAP,S 2200P-50 B AB..EF..IJK.........
C 310 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 311 87-010-198-080 CAP, CHIP 0.022 ABCDEFG.IJKLMN......
C 312 87-010-198-080 CAP, CHIP 0.022 ABCDEFG.IJKLMN......
C 324 87-010-260-080 CAP, ELECT 47-25V ABCDEFG.IJKLMN......
C 325 87-010-370-080 CAP,E 330-6.3 SME ABCDEFG.IJKLMN......
C 327 87-010-404-080 CAP, ELECT 4.7-50V ABCDEFG.IJKLMN......
C 328 87-010-404-080 CAP, ELECT 4.7-50V ABCDEFG.IJKLMN......
C 322 87-016-492-080 C-CAP,S 0.33-16 FZ ABCDEFG.IJKLMN......
C 321 87-016-492-080 C-CAP,S 0.33-16 FZ ABCDEFG.IJKLMN......
C 335 87-010-401-080 CAP, ELECT 1-50V ABCDEFG.IJKLMN......
C 336 87-010-401-080 CAP, ELECT 1-50V ABCDEFG.IJKLMN......
C 354 87-010-175-080 CAP 560P ABCDEFG.IJKLMN......
C 359 87-010-183-080 C-CAP,S 2700P-50 B ABCDEFG.IJKLMN......
C 358 87-010-183-080 C-CAP,S 2700P-50 B ABCDEFG.IJKLMN......
C 357 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFG.IJKLMN......
C 356 87-010-260-080 CAP, ELECT 47-25V ABCDEFG.IJKLMN......
C 352 87-012-140-080 CAP 470P ABCDEFG.IJKLMN......
C 351 87-012-140-080 CAP 470P ABCDEFG.IJKLMN......
C 355 87-012-349-080 C-CAP,S 1000P-50 CH ABCDEFG.IJKLMN......
C 360 87-010-183-080 C-CAP,S 2700P-50 B ABCDEFG.IJKLMN......
C 363 87-A10-292-080 CAP,M 5600P-50 J ......G.IJKLMN......
C 363 87-A10-772-080 CAP,M 5600P-50 J ABCDEF..............
C 379 87-010-406-080 CAP, ELECT 22-50 ABCDEFG.IJKLMN......
C 374 87-016-083-080 C-CAP,S 0.15-16 RK ABCDEFG.IJKLMN......
C 373 87-016-083-080 C-CAP,S 0.15-16 RK ABCDEFG.IJKLMN......
C 382 87-010-312-080 C-CAP,S 15P-50 CH AB..................
C 380 87-010-406-080 CAP, ELECT 22-50 ABCDEFG.IJKLMN......
C 388 87-012-156-080 C-CAP,S 220P-50 CH ABCDEFG.IJKLMN......
C 393 87-010-319-080 C-CAP,S 56P-50 CH ABCDEFG.IJKLMN......
C 392 87-010-319-080 C-CAP,S 56P-50 CH ABCDEFG.IJKLMN......
C 394 87-010-319-080 C-CAP,S 56P-50 CH ABCDEFG.IJKLMN......
C 391 87-010-319-080 C-CAP,S 56P-50 CH ABCDEFG.IJKLMN......
CN 301 87-099-827-010 CONN,3P S2M-3W ABCDEFG.IJKLMN......
ELECTRICAL PARTS LIST- 2/6 <HA>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
CN 351 87-099-832-010 CONN,8P S2M-8W ABCDEFG.IJKLMN......
D 352 87-A40-269-080 C-DIODE,MC2836 ABCDEFG.IJKLMN......
IC 303 87-A20-783-040 C-IC,BA7762AFS ABCDEFG.IJKLMN......
L 301 87-A50-049-010 COIL,TRAP 85K(COI) ABCDEFG.IJKLMN......
L 302 87-A50-049-010 COIL,TRAP 85K(COI) ABCDEFG.IJKLMN......
L 351 87-007-342-010 COIL,OSC 85K BIAS ABCDEFG.IJKLMN......
Q 359 87-026-610-080 TR,KTC3198GR ABCDEFG.IJKLMN......
Q 358 87-026-610-080 TR,KTC3198GR ABCDEFG.IJKLMN......
Q 357 87-026-610-080 TR,KTC3198GR ABCDEFG.IJKLMN......
Q 356 87-A30-076-080 C-TR,2SC3052F ........IJK.........
Q 351 87-A30-087-080 C-FET,2SK2158 ABCDEFG.IJKLMN......
Q 353 87-A30-087-080 C-FET,2SK2158 ABCDEFG.IJKLMN......
Q 354 87-A30-087-080 C-FET,2SK2158 ABCDEFG.IJKLMN......
Q 355 87-A30-105-080 C-TR,RT1P 441C ABCDEFG.IJKLMN......
Q 383 87-A30-075-080 C-TR,2SA1235F AB..................
SFR 352 87-A90-433-080 SFR,50K H NVZ6TLTA ABCDEFG.IJKLMN......
SFR 351 87-A90-433-080 SFR,50K H NVZ6TLTA ABCDEFG.IJKLMN......
C 457 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 458 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 452 87-010-401-080 CAP, ELECT 1-50V ABCDEFG.IJKLMN......
C 451 87-010-401-080 CAP, ELECT 1-50V ABCDEFG.IJKLMN......
C 459 87-A10-299-080 CAP,M 0.022-50 J ......G.IJKLMN......
C 455 87-A10-305-080 CAP,M 0.068-50 J ......G.IJKLMN......
C 456 87-A10-305-080 CAP,M 0.068-50 J ......G.IJKLMN......
C 459 87-A11-004-080 CAP,M 0.022-50 J DE ABCDEF..............
C 460 87-A10-299-080 CAP,M 0.022-50 J ......G.IJKLMN......
C 466 87-A10-299-080 CAP,M 0.022-50 J ......G.IJKLMN......
C 465 87-A10-299-080 CAP,M 0.022-50 J ......G.IJKLMN......
C 465 87-A11-004-080 CAP,M 0.022-50 J DE ABCDEF..............
C 466 87-A11-004-080 CAP,M 0.022-50 J DE ABCDEF..............
C 460 87-A11-004-080 CAP,M 0.022-50 J DE ABCDEF..............
IC 451 87-A21-031-040 C-IC,BU4551BF ABCDEFG.IJKLMN......
87-067-579-010 TAPPING SCREW, BVT2+3-8 AB..................
87-067-703-010 TAPPING SCREW, BVT2+3-10 ....EF..IJK.........
C 9 87-010-917-090 CAP,E 3300-50 M SMG ....EF..IJK.........
C 4 87-012-368-080 C-CAP,S 0.1-50 F ABCDEFG.IJKLMN......
C 5 87-012-368-080 C-CAP,S 0.1-50 F ABCDEFG.IJKLMN......
C 3 87-012-368-080 C-CAP,S 0.1-50 F ABCDEFG.IJKLMN......
C 6 87-012-368-080 C-CAP,S 0.1-50 F ABCDEFG.IJKLMN......
C 1 87-012-369-080 C-CAP,S 0.047-50F ABCDEFG.IJKLMN......
C 2 87-012-369-080 C-CAP,S 0.047-50F ABCDEFG.IJKLMN......
C 9 87-A10-520-090 CAP,E 3300-35 M SMG ABCD..G....LMN......
C 10 87-010-917-090 CAP,E 3300-50 M SMG ....EF..IJK.........
C 10 87-A10-520-090 CAP,E 3300-35 M SMG ABCD..G....LMN......
C 27 87-010-197-080 CAP, CHIP 0.01 DM ...........LMN......
C 29 87-010-247-080 CAP, ELECT 100-50V ABCDEFG.IJKLMN......
C 28 87-010-263-080 CAP, ELECT 100-10V ABCDEFG.IJKLMN......
C 22 87-010-385-080 CAP, ELECT 220-25V ABCDEFG....LMN......
C 21 87-010-385-080 CAP, ELECT 220-25V ABCDEFG....LMN......
C 24 87-010-408-080 CAP, ELECT 47-50V ........IJK.........
C 23 87-010-408-080 CAP, ELECT 47-50V ........IJK.........
C 25 87-010-430-080 CAP, ELECT 100-63 ABCDEFG.IJKLMN......
C 27 87-012-140-080 CAP 470P ABCDEFG.IJK.........
C 30 87-010-112-080 CAP, ELECT 100-16V ABCDEFG.IJKLMN......
C 31 87-010-235-080 CAP,E 470-16 SME ABCDEFG.IJKLMN......
C 33 87-010-405-080 CAP, ELECT 10-50V ..CD..G.............
C 34 87-010-405-080 CAP, ELECT 10-50V ..CD..G.............
C 34 87-016-100-080 CAP,E 10-50 BP ...........LMN......
C 33 87-016-100-080 CAP,E 10-50 BP ...........LMN......
C 61 87-010-260-080 CAP, ELECT 47-25V ABCDEFG.IJKLMN......
C 62 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFG.IJKLMN......
C 92 87-010-248-080 CAP, ELECT 220-10V ..CDEF..I...........
C 93 87-010-380-080 CAP, ELECT 47-16V ..CDEF..I...........
C 91 87-010-401-080 CAP, ELECT 1-50V ..CDEF..I...........
CN 91 87-A60-109-010 CONN,2P V S2M-2W ..CDEF..I...........
CNA 1 8Z-NB8-604-010 CONN ASSY,7P VH AB..................
CNA 1 8Z-NF8-669-010 CONN ASSY,9P VH ..CD..G....LMN......
CNA 1 8Z-NF8-670-010 CONN ASSY,7P 480 VH ....EF..IJK.........
D 1 87-017-447-010 DIODE,GBU4DL ..CD................
D 1 87-017-654-060 DIODE,GBU6J AB..EF..............
D 8 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFG.IJKLMN......
D 9 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFG.IJKLMN......
D 4 87-070-274-080 DIODE,1N4003 SEM ABCDEFG.IJKLMN......
D 3 87-070-274-080 DIODE,1N4003 SEM ABCDEFG.IJKLMN......
D 6 87-070-274-080 DIODE,1N4003 SEM ABCDEFG.IJKLMN......
D 5 87-070-274-080 DIODE,1N4003 SEM ABCDEFG.IJKLMN......
D 7 87-A40-383-080 ZENER,MTZJ30A ABCDEFG.IJKLMN......
D 1 87-A40-547-090 DIODE,D5SBA20 ........IJK.........
D 1 87-A40-548-090 DIODE,D3SBA20 ......G....LMN......
D 10 87-A40-345-080 ZENER,MTZJ10C ABCDEFG.IJKLMN......
D 64 87-070-274-080 DIODE,1N4003 SEM ABCDEFG.IJKLMN......
D 62 87-A40-269-080 C-DIODE,MC2836 ABCDEFG.IJKLMN......
D 61 87-A40-270-080 C-DIODE,MC2838 ABCDEFG.IJKLMN......
JW 16 87-008-372-080 FILTER, EMI BL OIRNI ..CDEFG.IJKLMN......
Q 1 87-026-609-080 TR,KTA1266GR ABCDEFG.IJKLMN......
Q 2 87-026-609-080 TR,KTA1266GR ABCDEFG.IJKLMN......
Q 5 87-026-610-080 TR,KTC3198GR ABCDEFG.IJKLMN......
Q 8 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 9 87-A30-196-080 TR,2SC4115SRS ABCDEFG.IJKLMN......
Q 4 89-213-702-010 TR,2SB1370 (1.8W) ABCDEFG.IJKLMN......
Q 61 87-A30-074-080 C-TR,RT1P 141C ..CDEFG.IJKLMN......
Q 64 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
ELECTRICAL PARTS LIST- 3/6 <HA>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Q 66 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 62 87-A30-107-070 C-TR,CMBT5401 ....................
Q 91 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
R 20 87-A00-261-080 RES,M/F 0.56-1W J AB..................
WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P ABCDEFG.IJKLMN......
87-067-703-010 TAPPING SCREW, BVT2+3-10 ABCDEFG.IJKLMN......
C 102 87-010-178-080 CHIP CAP 1000P ABCDEFG.IJKLMN......
C 101 87-010-178-080 CHIP CAP 1000P ABCDEFG.IJKLMN......
C 109 87-010-322-080 C-CAP,S 100P-50 CH AB..................
C 103 87-010-405-080 CAP, ELECT 10-50V ABCDEFG.IJKLMN......
C 104 87-010-405-080 CAP, ELECT 10-50V ABCDEFG.IJKLMN......
C 108 87-010-408-080 CAP, ELECT 47-50V ABCDEFG.IJKLMN......
C 107 87-010-408-080 CAP, ELECT 47-50V ABCDEFG.IJKLMN......
C 112 87-010-260-080 CAP, ELECT 47-25V ABCDEFG.IJKLMN......
C 111 87-010-260-080 CAP, ELECT 47-25V ABCDEFG.IJKLMN......
C 110 87-010-322-080 C-CAP,S 100P-50 CH AB..................
C 118 87-016-247-080 C-CAP,0.1-50 F ABCDEF..............
C 117 87-016-247-080 C-CAP,0.1-50 F ABCDEF..............
C 113 87-A10-685-080 C-CAP,S 470P-100 J CH ...DEF..............
C 114 87-A10-685-080 C-CAP,S 470P-100 J CH ...DEF..............
C 113 87-A10-812-080 C-CAP,S 220P-200 J CH ABC.................
C 114 87-A10-812-080 C-CAP,S 220P-200 J CH ABC.................
C 114 87-A10-946-080 C-CAP,S 220P-100 J CH ......G.IJKLMN......
C 113 87-A10-946-080 C-CAP,S 220P-100 J CH ......G.IJKLMN......
C 117 87-A11-185-080 C-CAP, 0.47-50 F Z ......G.IJKLMN......
C 118 87-A11-185-080 C-CAP, 0.47-50 F Z ......G.IJKLMN......
C 123 87-010-176-080 C-CAP,S 680P-50 SL ABCDEFG.IJKLMN......
C 124 87-010-176-080 C-CAP,S 680P-50 SL ABCDEFG.IJKLMN......
C 129 87-010-191-080 C-CAP,S 0.015-50 F ABCDEFG.IJKLMN......
C 130 87-010-191-080 C-CAP,S 0.015-50 F ABCDEFG.IJKLMN......
C 131 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFG.IJKLMN......
C 133 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFG.IJKLMN......
C 132 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFG.IJKLMN......
C 136 87-012-368-080 C-CAP,S 0.1-50 F ABCDEFG.IJKLMN......
D 108 87-A40-488-080 DIODE,1SS244 ABCDEFG.IJK.........
D 107 87-A40-488-080 DIODE,1SS244 ABCDEFG.IJK.........
D 111 87-A40-270-080 C-DIODE,MC2838 ABCDEFG.IJKLMN......
J 203 87-033-240-010 TERMINAL,SP 4P32SV1-05 AB..................
J 203 87-A60-238-010 TERMINAL,SP 4P (MSC) ..CDEFG.IJKLMN......
J 201 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM ABCDEF..............
J 201 87-A60-929-010 JACK,DIA6.3 BLK ST W/S TAI ......G.IJKLMN......
L 101 87-003-383-010 COIL,1UH-S ABCDEFG.IJKLMN......
L 102 87-003-383-010 COIL,1UH-S ABCDEFG.IJKLMN......
Q 104 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 103 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 105 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 106 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 108 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 109 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 107 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 101 87-A30-086-070 C-TR,CSD1306E ...........LMN......
Q 102 87-A30-086-070 C-TR,CSD1306E ...........LMN......
Q 104 87-A30-107-070 C-TR,CMBT5401 AB..................
Q 103 87-A30-107-070 C-TR,CMBT5401 AB..................
Q 105 87-A30-107-070 C-TR,CMBT5401 AB..................
Q 106 87-A30-107-070 C-TR,CMBT5401 AB..................
Q 102 87-A30-257-080 C-TR,2SD1306E ABCDEFG.IJK.........
Q 101 87-A30-257-080 C-TR,2SD1306E ABCDEFG.IJK.........
Q 110 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 115 87-A30-097-010 TR,FN 1016 ..CD..G....LMN......
Q 116 87-A30-097-010 TR,FN 1016 ..CD..G....LMN......
Q 118 87-A30-098-010 TR,FP 1016 ..CD..G....LMN......
Q 117 87-A30-098-010 TR,FP 1016 ..CD..G....LMN......
Q 119 87-A30-109-010 TR,2SD 2495 AB..................
Q 112 87-A30-190-080 TR,CC5551 ABCDEFG.IJKLMN......
Q 111 87-A30-190-080 TR,CC5551 ABCDEFG.IJKLMN......
Q 119 87-A30-215-010 TR,2SD2025 ....EF..IJK.........
Q 119 87-A30-256-010 TR,2SD1933 ....................
Q 126 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 127 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 129 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 128 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 124 87-A30-106-070 C-TR,CMBT5551 ABCDEFG.IJKLMN......
Q 123 87-A30-106-070 C-TR,CMBT5551 ABCDEFG.IJKLMN......
Q 126 87-A30-107-070 C-TR,CMBT5401 AB..................
Q 122 87-A30-108-010 TR,2SB1626 AB..................
Q 121 87-A30-108-010 TR,2SB1626 AB..................
Q 120 87-A30-109-010 TR,2SD 2495 AB..................
Q 122 87-A30-214-010 TR,2SB1344 ....EF..IJK.........
Q 121 87-A30-214-010 TR,2SB1344 ....EF..IJK.........
Q 120 87-A30-215-010 TR,2SD2025 ....EF..IJK.........
Q 121 87-A30-255-010 TR,2SB1342 ....................
Q 122 87-A30-255-010 TR,2SB1342 ....................
Q 120 87-A30-256-010 TR,2SD1933 ....................
Q 130 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 131 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
R 131 87-A00-257-080 RES,M/F 0.15-1W J ABCDEFG.IJKLMN......
R 132 87-A00-257-080 RES,M/F 0.15-1W J ABCDEFG.IJKLMN......
R 132 87-A00-258-080 RES,M/F 0.22-1W J ....................
R 131 87-A00-258-080 RES,M/F 0.22-1W J ....................
R 144 87-A00-439-050 RES,180-1/2W J RP AB..EF..IJK.........
R 143 87-A00-439-050 RES,180-1/2W J RP AB..EF..IJK.........
ELECTRICAL PARTS LIST- 4/6 <HA>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
R 145 87-A00-439-050 RES,180-1/2W J RP AB..EF..IJK.........
R 146 87-A00-439-050 RES,180-1/2W J RP AB..EF..IJK.........
R 146 87-A00-440-050 RES,220-1/2W J RP ..CD..G....LMN......
R 145 87-A00-440-050 RES,220-1/2W J RP ..CD..G....LMN......
R 144 87-A00-440-050 RES,220-1/2W J RP ..CD..G....LMN......
R 143 87-A00-440-050 RES,220-1/2W J RP ..CD..G....LMN......
TH 102 87-A91-042-080 C-THMS,100K 55001 ...DEFG.IJKLMN......
TH 101 87-A91-042-080 C-THMS,100K 55001 ...DEFG.IJKLMN......
C 203 87-010-177-080 C-CAP,S 820P-50 SL ABCDEFG.IJKLMN......
C 204 87-010-177-080 C-CAP,S 820P-50 SL ABCDEFG.IJKLMN......
C 209 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFG.IJKLMN......
C 212 87-010-181-080 CAP,CHIP S 1800P ABCDEFG.IJKLMN......
C 211 87-010-181-080 CAP,CHIP S 1800P ABCDEFG.IJKLMN......
C 217 87-010-260-080 CAP, ELECT 47-25V ABCDEFG.IJKLMN......
C 218 87-010-260-080 CAP, ELECT 47-25V ABCDEFG.IJKLMN......
C 210 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFG.IJKLMN......
C 213 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFG.IJKLMN......
C 214 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFG.IJKLMN......
C 219 87-A10-946-080 C-CAP,S 220P-100 J CH ABCDEFG.IJKLMN......
C 228 87-010-186-080 CAP,CHIP 4700P ABCDEFG.IJKLMN......
C 227 87-010-186-080 CAP,CHIP 4700P ABCDEFG.IJKLMN......
C 224 87-010-190-080 S CHIP F 0.01 ABCDEFG.IJKLMN......
C 223 87-010-190-080 S CHIP F 0.01 ABCDEFG.IJKLMN......
C 229 87-010-993-080 C-CAP,S 0.056-25 B ABCDEFG.IJKLMN......
C 225 87-012-368-080 C-CAP,S 0.1-50 F ABCDEFG.IJKLMN......
C 226 87-012-368-080 C-CAP,S 0.1-50 F ABCDEFG.IJKLMN......
C 220 87-A10-946-080 C-CAP,S 220P-100 J CH ABCDEFG.IJKLMN......
C 234 87-010-190-080 S CHIP F 0.01 ABCDEFG.IJKLMN......
C 233 87-010-190-080 S CHIP F 0.01 ABCDEFG.IJKLMN......
C 232 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 231 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 239 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 238 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFG.IJKLMN......
C 237 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFG.IJKLMN......
C 230 87-010-993-080 C-CAP,S 0.056-25 B ABCDEFG.IJKLMN......
C 236 87-016-285-080 CAP,E 47-100SME AB.DEFG....LM.......
C 235 87-016-285-080 CAP,E 47-100SME AB.DEFG....LM.......
C 236 87-A10-121-080 CAP,E 47-100 REA ........IJK.........
C 235 87-A10-121-080 CAP,E 47-100 REA ........IJK.........
C 240 87-010-408-080 CAP, ELECT 47-50V AB....G.IJKLMN......
D 208 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFG.IJKLMN......
D 207 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFG.IJKLMN......
D 208 87-A40-488-080 DIODE,1SS244 ABCDEFG.IJK.........
D 207 87-A40-488-080 DIODE,1SS244 ABCDEFG.IJK.........
D 211 87-A40-270-080 C-DIODE,MC2838 ABCDEFG.IJKLMN......
J 204 87-A60-750-010 JACK,PIN 4P R/W BLUE AB.DEFG.IJKLM.......
J 205 87-A60-751-010 JACK,PIN 2P R/W BLUE ..C..........N......
L 202 87-003-383-010 COIL,1UH-S ABCDEFG.IJKLMN......
L 201 87-003-383-010 COIL,1UH-S ABCDEFG.IJKLMN......
Q 206 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 205 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 203 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 204 87-A30-075-080 C-TR,2SA1235F ABCDEFG.IJKLMN......
Q 209 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 208 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 207 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 202 87-A30-086-070 C-TR,CSD1306E ...........LMN......
Q 201 87-A30-086-070 C-TR,CSD1306E ...........LMN......
Q 201 87-A30-257-080 C-TR,2SD1306E ABCDEFG.IJK.........
Q 202 87-A30-257-080 C-TR,2SD1306E ABCDEFG.IJK.........
Q 210 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 219 87-A30-106-070 C-TR,CMBT5551 ...........LMN......
Q 219 87-A30-119-040 C-TR,2SC3906K R ABCDEFG.IJK.........
Q 211 87-A30-190-080 TR,CC5551 ABCDEFG.IJKLMN......
Q 212 87-A30-190-080 TR,CC5551 ABCDEFG.IJKLMN......
Q 217 87-A30-255-010 TR,2SB1342 ABCDEFG.IJKLMN......
Q 218 87-A30-255-010 TR,2SB1342 ABCDEFG.IJKLMN......
Q 216 87-A30-256-010 TR,2SD1933 ABCDEFG.IJKLMN......
Q 215 87-A30-256-010 TR,2SD1933 ABCDEFG.IJKLMN......
Q 224 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 225 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 227 87-A30-076-080 C-TR,2SC3052F ABCDEFG.IJKLMN......
Q 220 87-A30-106-070 C-TR,CMBT5551 ...........LMN......
Q 220 87-A30-119-040 C-TR,2SC3906K R ABCDEFG.IJK.........
R 232 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFG.IJKLMN......
R 233 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFG.IJKLMN......
R 231 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFG.IJKLMN......
R 234 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFG.IJKLMN......
R 265 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFG.IJKLMN......
R 266 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFG.IJKLMN......
C 602 87-010-180-080 C-CER 1500P ABCDEFG.IJKLMN......
C 601 87-010-180-080 C-CER 1500P ABCDEFG.IJKLMN......
C 605 87-010-318-080 C-CAP,S 47P-50 CH ABCDEFG.IJKLMN......
C 606 87-010-318-080 C-CAP,S 47P-50 CH ABCDEFG.IJKLMN......
C 619 87-010-185-080 C-CAP,S 3900P-50 B ABCDEFG.IJKLMN......
C 614 87-016-081-080 C-CAP,S 0.1-16 RK ABCDEFG.IJKLMN......
C 613 87-016-081-080 C-CAP,S 0.1-16 RK ABCDEFG.IJKLMN......
C 617 87-A10-304-080 CAP,M 0.056-50 J ......G.IJK.........
C 618 87-A10-304-080 CAP,M 0.056-50 J ......G.IJK.........
C 618 87-A10-305-080 CAP,M 0.068-50 J ...........LMN......
C 617 87-A10-305-080 CAP,M 0.068-50 J ...........LMN......
C 617 87-A11-008-080 CAP,M 0.056-50 J DE ABCDEF..............
ELECTRICAL PARTS LIST- 5/6 <HA>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
C 618 87-A11-008-080 CAP,M 0.056-50 J DE ABCDEF..............
C 616 87-A11-011-080 CAP,M 0.12-50 J DE ABCDEFG.IJKLMN......
C 615 87-A11-011-080 CAP,M 0.12-50 J DE ABCDEFG.IJKLMN......
C 620 87-010-185-080 C-CAP,S 3900P-50 B ABCDEFG.IJKLMN......
C 627 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 622 87-010-401-080 CAP, ELECT 1-50V ABCDEFG.IJKLMN......
C 621 87-010-401-080 CAP, ELECT 1-50V ABCDEFG.IJKLMN......
C 626 87-010-405-080 CAP, ELECT 10-50V ABCDEFG.IJKLMN......
C 629 87-010-405-080 CAP, ELECT 10-50V ABCDEFG.IJKLMN......
C 625 87-010-405-080 CAP, ELECT 10-50V ABCDEFG.IJKLMN......
C 623 87-A10-307-080 CAP,M 0.1-50 J ......G.IJKLMN......
C 624 87-A10-307-080 CAP,M 0.1-50 J ......G.IJKLMN......
C 623 87-A10-773-080 CAP,M 0.10-50 J ABCDEF..............
C 624 87-A10-773-080 CAP,M 0.10-50 J ABCDEF..............
C 637 87-010-183-080 C-CAP,S 2700P-50 B ABCDEFG.IJKLMN......
C 636 87-010-194-080 CAP, CHIP 0.047 ..CD..G....LMN......
C 635 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 634 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 630 87-010-213-080 C-CAP,S 0.015-50 B ABCDEFG.IJKLMN......
C 633 87-010-263-080 CAP, ELECT 100-10V ABCDEFG.IJKLMN......
C 632 87-010-263-080 CAP, ELECT 100-10V ABCDEFG.IJKLMN......
C 639 87-010-314-080 C-CAP,S 22P-50V ABCDEFG.IJKLMN......
C 638 87-010-314-080 C-CAP,S 22P-50V ABCDEFG.IJKLMN......
C 631 87-010-992-080 C-CAP,S 0.047-25 B ABCDEFG.IJKLMN......
C 641 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 669 87-010-322-080 C-CAP,S 100P-50 CH ......G.IJKLMN......
C 678 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 677 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
C 670 87-010-322-080 C-CAP,S 100P-50 CH ......G.IJKLMN......
C 680 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFG.IJKLMN......
CN 604 87-099-570-010 CONN,13P TUC-P13P-B1 ABCDE.G.IJ.LMN......
CN 601 87-099-719-010 CONN,30P TYK-B(X) ABCDEF..............
CN 602 87-A60-131-010 CONN,6P V FE ABCDEFG.IJKLMN......
CN 605 87-A60-189-010 CONN,16P V TUC-P16P-B1 .....F....K.........
CN 601 88-NF9-657-010 CONN,30P H BLK TYK-B(X) ......G.IJKLMN......
D 601 87-A40-002-080 ZENER,MTZJ5.1C ABCDEFG.IJKLMN......
D 603 87-A40-234-080 ZENER,MTZJ5.6A ......G.IJKLMN......
D 602 87-A40-438-080 ZENER,MTZJ4.7A ABCDEFG.IJKLMN......
IC 601 87-A21-011-040 C-IC,M62445FP-600D ABCDEFG.IJK.........
IC 601 87-A21-202-040 C-IC,M62445AFP ...........LMN......
J 602 87-A60-398-010 JACK,PIN 2P R/W HSP-242V24 ABCDEFG.IJK.........
J 602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN ...........LMN......
Q 601 87-026-609-080 TR,KTA1266GR ABCDEFG.IJKLMN......
Q 604 87-A30-142-040 C-TR,DTA123EKA ......G.IJKLMN......
C 735 87-010-178-080 CHIP CAP 1000P ......G....LMN......
C 732 87-010-196-080 CHIP CAPACITOR,0.1-25 ..CD..G....LMN......
C 733 87-010-196-080 CHIP CAPACITOR,0.1-25 ..CD..G....LMN......
C 731 87-010-405-080 CAP, ELECT 10-50V ....................
C 733 87-010-544-080 CAP, ELECT 0.1-50V ....................
C 731 87-010-560-080 CAP,E 10-50 GAS ..CD..G....LMN......
C 734 87-012-157-080 C-CAP,S 330P-50 CH ..CD..G....LMN......
JR 703 87-012-368-080 C-CAP,S 0.1-50 F ...D..G....LMN......
Q 732 87-A30-075-080 C-TR,2SA1235F ..CD..G....LMN......
Q 731 87-A30-076-080 C-TR,2SC3052F ..CD..G....LMN......
ELECTRICAL PARTS LIST- 6/6 <HA>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
NOTE: The characters in the suffix column indicate the part usage.
ULHRTCNM ...............XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 701 87-010-381-080 CAP, ELECT 330-16V A...................
C 702 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 709 87-012-195-080 C-CAP,U 100P-50CH A...................
C 703 87-012-286-080 CAP, U 0.01-25 A...................
C 704 87-012-286-080 CAP, U 0.01-25 A...................
C 711 87-010-260-080 CAP, ELECT 47-25V A...................
C 711 87-010-553-080 CAP,E 47-16 ....................
C 712 87-010-831-080 C-CAP,U,0.1-16F A...................
C 718 87-012-179-080 C-CAP,U 20P-50 CH ....................
C 715 87-012-195-080 C-CAP,U 100P-50CH ....................
C 714 87-012-286-080 CAP, U 0.01-25 A...................
C 717 87-012-286-080 CAP, U 0.01-25 A...................
C 713 87-012-286-080 CAP, U 0.01-25 ....................
C 719 87-012-286-080 CAP, U 0.01-25 A...................
C 727 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 728 87-010-248-080 CAP, ELECT 220-10V A...................
C 721 87-012-176-080 CAP 15P A...................
C 722 87-012-176-080 CAP 15P A...................
C 720 87-012-195-080 C-CAP,U 100P-50CH A...................
C 725 87-012-274-080 CHIP CAP,U 1000P-50B A...................
C 723 87-012-274-080 CHIP CAP,U 1000P-50B A...................
C 729 87-012-274-080 CHIP CAP,U 1000P-50B A...................
C 725 87-018-131-080 CAP, CER 1000P-50V ....................
C 805 87-012-286-080 CAP, U 0.01-25 ....................
C 806 87-012-286-080 CAP, U 0.01-25 ....................
CN 701 87-A60-650-010 CONN,16P H GRY TUC-P16X-C1 ....................
CN 701 87-A60-700-010 CONN,13P H GRY TUC-P13X-C1 A...................
D 721 87-017-149-080 ZENER,HZS6A2L A...................
D 722 87-020-465-080 DIODE,1SS133 (110MA) ....................
IC 721 87-070-127-110 IC,LC72131 D A...................
Q 712 87-A30-072-080 C-TR,RT1P 144C ....................
Q 713 87-A30-072-080 C-TR,RT1P 144C ....................
Q 711 87-A30-234-080 TR,CSC4115BC A...................
X 721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................
C 872 87-010-400-080 CAP, ELECT 0.47-50V ....................
C 873 87-010-404-080 CAP, ELECT 4.7-50V ....................
C 877 87-012-278-080 C-CAP,U 2200P-50 B ....................
C 878 87-012-278-080 C-CAP,U 2200P-50 B ....................
C 889 87-010-248-080 CAP, ELECT 220-10V ....................
C 884 87-010-260-080 CAP, ELECT 47-25V ....................
C 883 87-010-404-080 CAP, ELECT 4.7-50V ....................
C 886 87-010-545-080 CAP, ELECT 0.22-50V ....................
C 885 87-010-545-080 CAP, ELECT 0.22-50V ....................
C 888 87-010-787-080 CAP, U 0.022-25 ....................
C 881 87-012-141-080 CHIP-CAPACITOR,0.22-16F ....................
C 882 87-012-172-080 CAPACITOR CHIP U 10P CH ....................
C 887 87-012-286-080 CAP, U 0.01-25 ....................
C 886 87-016-460-080 C-CAP,S 0.22-16 B ....................
C 885 87-016-460-080 C-CAP,S 0.22-16 B ....................
IC 871 87-070-060-040 IC,TA2040AF ....................
Q 873 87-026-226-080 CHIP-TR,DTA143EK ....................
X 891 87-030-394-010 VIB,CER CSA3.6MGF228 ....................
C 706 87-A10-592-080 C-CAP,S 0.015-50 J B A...................
C 705 87-A10-592-080 C-CAP,S 0.015-50 J B A...................
C 733 87-010-987-080 C-CAP,S 1500P-50 CH A...................
C 736 87-010-987-080 C-CAP,S 1500P-50 CH A...................
C 735 87-010-987-080 C-CAP,S 1500P-50 CH A...................
C 734 87-010-987-080 C-CAP,S 1500P-50 CH A...................
C 733 87-012-280-080 CAP, U 3300P-50 ....................
C 734 87-012-280-080 CAP, U 3300P-50 ....................
C 731 87-012-286-080 CAP, U 0.01-25 A...................
C 738 87-A10-592-080 C-CAP,S 0.015-50 J B A...................
C 737 87-A10-592-080 C-CAP,S 0.015-50 J B A...................
C 752 87-010-220-080 C-CAP,S 0.018-25 B ....................
C 751 87-010-220-080 C-CAP,S 0.018-25 B ....................
C 758 87-012-167-080 C-CAP,U 5P-50 CH A...................
C 757 87-012-188-080 C-CAP,U 47P-50 CH A...................
C 753 87-012-195-080 C-CAP,U 100P-50CH ....................
C 752 87-012-282-080 CAP, U 4700P-50 ....................
C 755 87-012-286-080 CAP, U 0.01-25 ....................
C 756 87-012-286-080 CAP, U 0.01-25 A...................
C 752 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 751 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 761 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 766 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 769 87-010-260-080 CAP, ELECT 47-25V A...................
C 763 87-010-829-080 CAP, U 0.047-16 A...................
C 765 87-012-286-080 CAP, U 0.01-25 A...................
C 768 87-012-286-080 CAP, U 0.01-25 A...................
C 762 87-012-286-080 CAP, U 0.01-25 ....................
C 764 87-012-337-080 C-CAP,U 56P-50 CH A...................
C 773 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 774 87-010-263-080 CAP, ELECT 100-10V A...................
C 771 87-010-383-080 CAP, ELECT 33-25V A...................
C 777 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 778 87-010-401-080 CAP, ELECT 1-50V A...................
ELECTRICAL PARTS LIST-1/3 (TUNER ZZA-1)<HA>
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
This manual suits for next models
1
Table of contents
Other Aiwa Stereo System manuals
