Bitwig Studio
Program Documentation
English
Manual Version 1.0

2
Table of Contents
Introduction.................................................................................................................................3
System Requirements & Product Support..............................................................................3
Installation & Setup ....................................................................................................................4
Operation ....................................................................................................................................5
MPD218 ..................................................................................................................................6
MPD226 ..................................................................................................................................7
MPD232 ................................................................................................................................10
MPK225 ................................................................................................................................13
MPK249 & MPK261 ..............................................................................................................15
Trademarks & Licenses ...........................................................................................................19

3
Introduction
This program documentation describes how you can use our MPD2 Series and MPK2 Series
controllers in Bitwig Studio. These control mappings enable you to use each supported
controller for basic track-mixing, clip- and scene-launching, and more when you are using its
Bitwig Studio program.
To get started, see the Installation & Setup chapter install the files you just downloaded.
System Requirements & Product Support
For complete system requirements, compatibility information, and product registration, visit
the Akai Professional website: akaipro.com.
For additional support, visit akaipro.com/support.

4
Installation & Setup
In order for Bitwig Studio to recognize your controller, you need to install the “script” file you
just downloaded and select your controller in the Preferences.
To do this:
1. Move the script file you just downloaded to the location for your operating system:
•Windows: [your user directory]\My Documents\Bitwig Studio\Controller Scripts\
•Mac OS X: [your user directory]/Documents/Bitwig Studio/Control Scripts/
2. Connect your controller’s USB port to your computer, and make sure your controller is
powered on.
3. Open Bitwig Studio.
4. In Bitwig Studio, click the Options menu, and select Preferences.
5. Click the Controllers tab, and then click Detect available controllers. Bitwig Studio will
automatically detect and recognize your controller.
6. Click OK to close the Preferences window.
7. Select and load the Bitwig program on your controller, and get started!
Important: Each time you use your controller with Bitwig Studio, select the Bitwig Studio
program by doing the following:
1. Press Preset. The display will show the current program name (flashing).
2. Turn the Data Dial to browse through the list of available programs. Select the Bitwig
program, and then press the Data Dial.

5
Operation
This chapter describes how you can use following controllers in Bitwig Studio:
MPD218 MPK225
MPD226 MPK249
MPD232 MPK261
Important: Each time you use your controller with Bitwig Studio, select the Bitwig Studio
program by doing the following:
1. Press Preset. The display will show the current program name (flashing).
2. Turn the Data Dial to browse through the list of available programs. Select the Bitwig
program, and then press the Data Dial.

6
MPD218
Important: Remember to select and load the Bitwig program each time you use your
MPD218 with Bitwig Studio.
Pads: Press the pads to play the active instrument track. Press Pad Bank to change the
current pad bank.
Knobs: Turn the knobs to control macros or parameters of the active track, depending on
your MPD218’s current control bank:
•Control Bank A: Turn the knobs to control Macros 1–6 of the current device.
•Control Bank B: Turn the knobs to control Parameters 1–6 of the current device.
•Control Bank C: Turn the knobs to control Parameters 7–12 of the current device.
Press Ctrl Bank to change the current control bank.

7
MPD226
Important: Remember to select and load the Bitwig program each time you use your
MPD226 with Bitwig Studio.
Transport Buttons (Stop, Play, Record):Press these buttons to stop playback or recording
(Stop), start playback or recording (Play), or record-arm the active track(s) (Record).
Pads: Press the pads to play MIDI notes or to launch clips or scenes, depending on the
current mode:
•Instrument Mode: Press the pads to play MIDI notes on the active track. If the track’s
instrument is Drum Machine, pads that have a corresponding instrument for that note
will be lit.
•Clip Mode: Press the pads to trigger clips; the pads act as a 4x4 Clip Launcher. A pad’s
color indicates its current state:
oGreen: The clip in that slot is playing.
oAmber: There is a clip in that slot, but it is not playing.
oRed: The clip in that slot is recording.
oOff: There is no clip in that slot.
Press Pad Bank to change the scene of clips that the pads will trigger. Pad Bank A
corresponds to Scenes 1–4, Pad Bank B corresponds to Scenes 5–8, and Pad Bank C
corresponds to Scenes 9–12.
•Scene Mode: Press the pads to trigger scenes (columns of clips). Each pad corresponds to
the scene with the same number (e.g., Pad 1 triggers Scene 1, Pad 2 triggers Scene 2, etc.).
Use the switches in Control Bank A to select the current mode (described below).

8
Knobs: Turn the knobs to control certain parameters, depending on MPD226’s current control
bank:
•Control Bank A: Turn the knobs to control Macros 1–4 of the primary device.
•Control Bank B: Turn the knobs to control the Pan knobs of the tracks. Each knob
corresponds to the track with the same number (e.g., Knob 1 controls the panning of
Track 1, Knob 2 controls the panning of Track 2, etc.).
•Control Bank C: Turn the knobs to control the Send for Effect Track 1 of the tracks. Each
knob corresponds to the track with the same number (e.g., Knob 1 controls the send
level of Track 1, Knob 2 controls the send level of Track 2, etc.).
Press Ctrl Bank to cycle through the control banks.
Faders: Move the faders to control certain parameters, depending on MPD226’s current
control bank:
•Control Bank A: Move the faders to control the first 4 macros of the current device.
•Control Bank B: Move the faders to control the Volume faders of the tracks. Each fader
corresponds to the track with the same number (e.g., Fader 1 controls the volume of
Track 1, Fader 2 controls the volume of Track 2, etc.).
•Control Bank C: Move the faders to control the Send for Effect Track 2 of the tracks.
Each fader corresponds to the track with the same number (e.g., Fader 1 controls the
send level of Track 1, Fader 2 controls the send level of Track 2, etc.).
Press Ctrl Bank to cycle through the control banks.

9
Switches: Press the switches to select modes or enable/disable certain track parameters,
depending on MPD226’s current control bank:
•Control Bank A: Press a switch to select the mode for the pads:
oSwitch 1: Press Switch 1 to select Instrument Mode (described above).
oSwitch 2: Press Switch 2 to select Clip Mode (described above). Once you are in
this mode, you can press Switch 2 to switch between Tracks 1–4 and Tracks 5–8.
oSwitch 3: Press Switch 3 to select Scene Mode (described above).
oSwitch 4: Press Switch 4 to turn notifications on or off. When on, a small message
will appear when you adjust a control, enter another mode, etc.
•Control Bank B: Press the switches to record-arm or -disarm the tracks. Each switch
corresponds to the track with the same number (e.g., Switch 1 record-arms or -disarms
Track 1, Switch 2 record-arms or -disarms Track 2, etc.).
•Control Bank C: Press the switches to mute or unmute the tracks. Each switch
corresponds to the track with the same number (e.g., Switch 1 mutes or unmutes Track
1, Switch 2 mutes or unmutes Track 2, etc.).
Press Ctrl Bank to cycle through the control banks.

10
MPD232
Important: Remember to select and load the Bitwig program each time you use your
MPD232 with Bitwig Studio.
Transport Buttons (Stop, Play, Record):Press these buttons to stop playback or recording
(Stop), start playback or recording (Play), or record-arm the active track(s) (Record).
Pads: Press the pads to play MIDI notes or to launch clips or scenes, depending on the
current mode:
•Instrument Mode: Press the pads to play MIDI notes on the active track. If the track’s
instrument is Drum Machine, pads that have a corresponding instrument for that note
will be lit.
•Clip Mode: Press the pads to trigger clips; the pads act as a 4x4 Clip Launcher. A pad’s
color indicates its current state:
oGreen: The clip in that slot is playing.
oAmber: There is a clip in that slot, but it is not playing.
oRed: The clip in that slot is recording.
oOff: There is no clip in that slot.
Press Pad Bank to change the scene of clips that the pads will trigger. Pad Bank A
corresponds to Scenes 1–4, Pad Bank B corresponds to Scenes 5–8, and Pad Bank C
corresponds to Scenes 9–12.
•Scene Mode: Press the pads to trigger scenes (columns of clips). Each pad corresponds to
the scene with the same number (e.g., Pad 1 triggers Scene 1, Pad 2 triggers Scene 2, etc.).
Use the switches in Control Bank A to select the current mode (described below).
