Akai CFTD2052 User manual

SERVICE MANUAL
CFTD2052
Design and specifications are subject to change without notice.
ORIGINAL
MFR'S VERSION A
LCD COLORTELEVISION/DVDVIDEO PLAYER

A1-1
CAUTION
THIS LCD COLOR TELEVISION EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OFTHIS PRODUCT, PLEASE READ THIS SERVICE MANUAL CARE-
FULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE,
CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHERTHAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE.
VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT
STARE INTO BEAM.
CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE
STANDARDS, 21 CFR SUBCHAPTER J.
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
PREPARATION OF SERVICING
The laser diode used for a pickup head may be destroyed with external static electricity.
Moreover, even if it is operating normally after repair when static electricity discharge is received at the
time of repair, the life of the product may be shortened.
Please perform the following measure against static electricity, be careful of destruction of a laser diode
at the time of repair.
• Place the unit on a workstation equipped to protect against static electricity, such as conductive mat.
• Soldering iron with ground wire or ceramic type is used.
• A worker needs to use a ground conductive wrist strap for body.

A1-2
SERVICING NOTICES ON CHECKING
6. AVOID AN X-RAY1. KEEP THE NOTICES
As for the places which need special attentions,
they are indicated with the labels or seals on the
cabinet, chassis and parts. Make sure to keep
the indications and notices in the operation
manual.
3. USE THE DESIGNATED PARTS
5. TAKE CARE TO DEAL WITH THE
CATHODE-RAY TUBE
In the condition that an explosion-proof
cathode-ray tube is set in this equipment, safety
is secured against implosion. However, when
removing it or serving from backward, it is
dangerous to give a shock. Take enough care
to deal with it.
Safety is secured against an X-ray by consider-
ing about the cathode-ray tube and the high
voltage peripheral circuit, etc.
Therefore, when repairing the high voltage pe-
ripheral circuit, use the designated parts and
make sure not modify the circuit.
Repairing except indicates causes rising of high
voltage, and it emits an X-ray from the cathode-
ray tube.
HOW TO ORDER PARTS
PERFORM A SAFETY CHECK AFTER
SERVICING
7.
Confirm that the screws, parts and wiring which
were removed in order to service are put in the
original positions, or whether there are the
portions which are deteriorated around the
serviced places serviced or not. Check the
insulation between the antenna terminal or
external metal and the AC cord plug blades.
And be sure the safety of that.
(INSULATION CHECK PROCEDURE)
1.
2.
3.
4.
Unplug the plug from the AC outlet.
Remove the antenna terminal on TV and turn
on the TV.
Insulation resistance between the cord plug
terminals and the eternal exposure metal
[Note 2] should be more than 1M ohm by
using the 500V insulation resistance meter
[Note 1].
If the insulation resistance is less than 1M
ohm, the inspection repair should be
required.
[Note 1]
If you have not the 500V insulation
resistance meter, use a Tester.
[Note 2]
External exposure metal:Antenna terminal
Earphone jack
2. AVOID AN ELECTRIC SHOCK
There is a high voltage part inside. Avoid an
electric shock while the electric current is
flowing.
The parts in this equipment have the specific
characters of incombustibility and withstand
voltage for safety. Therefore, the part which is
replaced should be used the part which has
the same character.
Especially as to the important parts for safety
which is indicated in the circuit diagram or the
table of parts as a mark, the designated
parts must be used.
4. PUT PARTS AND WIRES IN THE
ORIGINAL POSITION AFTER
ASSEMBLING OR WIRING
There are parts which use the insulation
material such as a tube or tape for safety, or
which are assembled in the condition that
these do not contact with the printed board.
The inside wiring is designed not to get closer
to the pyrogenic parts and high voltage parts.
Therefore, put these parts in the original
positions.
Please include the following informations when you order parts. (Particularly the VERSION LETTER.)
1. MODEL NUMBER and VERSION LETTER.
The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be
found at the end of the SERIAL NUMBER.
2. PART NO. and DESCRIPTION
You can find it in your SERVICE MANUAL.

A1-3
IMPORTANT SAFEGUARDS
1.
2.
3.
4.
5.
6.
7.
8.
8A.
9.
10.
11.
12.
13.
14.
15.
16.
READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
HEEDWARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.Use a damp
cloth for cleaning.
ATTACHMENTS
Do not use attachments not recommended by the unit's manufacturer as they may cause hazards.
WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table.The
unit may fall, causing serious injury, and serious damage to the unit. Use only
with a cart, stand, tripod, bracket, or table recommended by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
VENTILATION
Slots and openings in the cabinet and in the back or bottom are provided for ventilation, to ensure reliable
operation of the unit, and to protect it from overheating.These openings must not be blocked or covered.The
openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface.This unit
should never be placed near or over a radiator or heat source.This unit should not be placed in a built-in installa-
tion such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have
been adhered to.
POWER SOURCES
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure
of the type of power supply to your home, consult your appliance dealer or local power company.For units
intended to operate from battery power, or other sources, refer to the operating instructions.
GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way.This is a safety feature.If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug. If your unit is equipped with a 3-wire
grounding-type plug, a plug having a third (grounding) pin, this plug will only fit into a grounding-type power
outlet.This too, is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they
exit from the appliance.
LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system.This will prevent damage to the unit
due to lightning and power line surges.
POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or circuits.When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be
fatal.
OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out
parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A

A1-4
IMPORTANT SAFEGUARDS (CONTINUED)
OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and support-
ing structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location
of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage
or other hazards.Refer all servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following condi-
tions:
REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by the
manufacturer or those that have the same characteristics as the original parts.
Unauthorized substitutions may result in fire, electric shock or other hazards.
SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
DISCTRAY
Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury.
CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the
wall outlet.Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of
the other equipment carefully and follow the instructions when making any connections.
SOUNDVOLUME
Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound
may cause hearing or speaker damage.
SOUND DISTORTION
Do not allow the product output distorted sound for a longtime. It may cause speaker overheating and fire.
HEADPHONES
When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously
with high volume sound, it may cause hearing damage.
LASER BEAM
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser
beam. It may cause sight damage.
DISC
Do not use a cracked, deformed, or repaired disc.These discs are easily broken and may cause serious per-
sonal injury and product malfunction.
NOTETO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
a.
b.
c.
d.
e.
f.
When the power-supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen into the unit.
If the unit has been exposed to rain or water.
If the unit does not operate normally by following the operating instructions. Adjust only those controls that
are covered by the operating instructions, as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to restore the unit to its normal
operation.
If the unit has been dropped or the cabinet has been damaged.
When the unit exhibits a distinct change in performance, this indicates a need for service.

A1-5
EXAMPLE OF ANTENNA GROUNDING AS PERTHE NATIONAL ELECTRICAL CODE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD
IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A

1.
2.
3.
Remove the Back Cabinet. (Refer to item 1 of the DISASSEMBLY INSTRUCTIONS.)
Slide the Rack Loading toward the arrow direction by hand to release the lock. (Refer to Fig. 1)
Take out the Disc from the DVD Deck. Be careful not to scratch on the Disc.
DISC REMOVAL METHOD AT NO POWER SUPPLY
Fig. 1
DVD Deck
Rack Loading
PARENTAL CONTROL - RATING LEVEL
4 DIGIT PASSWORD CANCELLATION
If the stored 4 digit password in the Rating Level menu needs to be cancelled, please follow the steps below.
Turn Unit ON.
Set the DVD mode.
Press and hold the '7' key on the remote control unit.
Simultaneously press and hold the 'STOP' key on the front panel.
Hold both keys for more than 3 seconds.
The On Screen Display message 'PASSWORD CLEAR' will appear.
The 4 digit password has now been cleared.
1.
2.
3.
4.
5.
6.
7.
A1-6

CONTENTS
CAUTION ...................................................................................................................................
SERVICING NOTICE ON CHECKING .....................................................................................
HOW TO ORDER PART ...........................................................................................................
IMPORTANT SAFEGUARDS ...................................................................................................
DISC REMOVAL METHOD AT NO POWER SUPPLY ...........................................................
PARENTAL CONTROL - RATING LEVEL ..............................................................................
CONTENTS................................................................................................................................
GENERAL SPECIFICATIONS ..................................................................................................
DISASSEMBLY INSTRUCTIONS
1. REMOVAL OF MECHANICAL PARTS AND P. C. BOARDS .........................................
2. REMOVAL OF DVD DECK PARTS .................................................................................
3. REMOVAL AND INSTALLATION OF FLAT PACKAGE IC .............................................
SERVICE MODE LIST...............................................................................................................
CONFIRMATION OF HOURS USED........................................................................................
WHEN REPLACING EEPROM (MEMORY) IC .......................................................................
ELECTRICAL ADJUSTMENTS ................................................................................................
BLOCK DIAGRAMS
DVD ........................................................................................................................................
TV ...........................................................................................................................................
POWER ..................................................................................................................................
TV POWER.............................................................................................................................
PRINTED CIRCUIT BOARDS
LCD .........................................................................................................................................
DVD/OPERATION2................................................................................................................
AV/REMOCON/SIDE JACK/OPERATION1/START SW/END SW ......................................
AV/REMOCON/SIDE JACK/OPERATION1 ..........................................................................
POWER/BACK LIGHT ...........................................................................................................
SCHEMATIC DIAGRAMS
MPEG/MICON/DSP ...............................................................................................................
MEMORY2..............................................................................................................................
RF AMP ..................................................................................................................................
AUDIO/VIDEO ........................................................................................................................
MOTOR DRIVE ......................................................................................................................
REGULATOR2 .......................................................................................................................
OPERATION2 ........................................................................................................................
TUNER/STEREO ...................................................................................................................
MICON ....................................................................................................................................
SOUND AMP..........................................................................................................................
IN/OUT....................................................................................................................................
POWER ..................................................................................................................................
OPERATION/AV JACK/REMOCON......................................................................................
DECODER..............................................................................................................................
SCALER1 ...............................................................................................................................
SCALER2 ...............................................................................................................................
LVDS.......................................................................................................................................
TV POWER ............................................................................................................................
INVERTER..............................................................................................................................
START SW/END SW .............................................................................................................
INTERCONNECTION DIAGRAM .............................................................................................
WAVEFORMS............................................................................................................................
MECHANICAL EXPLODED VIEWS .........................................................................................
DVD DECK EXPLODED VIEWS ..............................................................................................
MECHANICAL REPLACEMENT PARTS LIST........................................................................
DVD DECK REPLACEMENT PARTS LIST .............................................................................
ELECTRICAL REPLACEMENT PARTS LIST .........................................................................
A1-1
A1-2
A1-2
A1-3~A1-5
A1-6
A1-6
A2-1
A3-1~A3-6
B1-1~B1-4
B2-1~B2-3
B3-1, B3-2
C-1
C-1
C-2
D-1~D-3
E-1, E-2
E-3, E-4
E-5, E-6
E-7, E-8
F-1, F-2
F-3,F-4
F-5, F-6
F-7,F-8
F-9, F-10
G-1, G-2
G-3, G-4
G-5, G-6
G-7, G-8
G-9, G-10
G-11, G-12
G-13, G-14
G-15, G-16
G-17, G-18
G-19, G-20
G-21, G-22
G-23, G-24
G-25, G-26
G-27, G-28
G-29, G-30
G-31, G-32
G-33, G-34
G-35, G-36
G-37, G-38
G-39, G-40
G-41, G-42
H-1~H-3
I1-1, I1-2
I2-1, I2-2
J1-1
J2-1
J3-1~J3-3
A2-1

GENERAL SPECIFICATIONS
G-1 TV LCD LCD Size / Visual Size 20.1 inch / 510.0mmV
System LCD Type Color TFT LCD
Number of Pixels 640(H) x 480(V)
View Range Left/Right 80/80 degree
Up/Down 70/70 degree
Color System NTSC
Speaker 2 Speaker
Position Front
Size 1.8 x 3.9 inch
Impedance 16 ohm
Sound Output Max 2.5W + 2.5W
10%(Typical) ---
G-2 DVD System Color System NTSC
Disc DVD, CD-DA, CD-R/RW
DVD-R/RW (Video Format Only)
Disc Diameter 120 mm , 80 mm(with Disc Adapter)
Deck Disc Loading System Slot in Type
Motor 3 Motors
Pick up 1-Lens 2-Beams System
Playback time(Max)
DVD 1-Layer 135min (4.7GB)
DVD 2-Layer 245min (8.5GB)
CD 74min
Video CD --
Search speed Fwd 4 step
Actual 2-45 times (DVD)
4-40 times (CD)
Rev 4 step
Actual 2-45 times (DVD)
4-40 times (CD)
Slow speed Fwd 1/7 -1/2 times
Actual --
Rev 1/7 -1/2 times
Actual --
G-3 Tuning Broadcasting System US System M
System Tuner and System 1Tuner
Receive CH Destination US(W/CABLE)
Tuning System F-Synth
Input Impedance VHF/UHF 75 Ohm
CH Coverage 2~69, 4A, A-5~A-1, A~I, J~W, W+1~W+84
Intermediate Picture(FP) 45.75MHz
Frequency Sound(FS) 41.25MHz
FP-FS 4.50MHz
Preset CH No
Stereo/Dual TV Sound US-Stereo
Tuner Sound Muting Yes
G-4 Signal Video Signal Input Level 1 V p-p/75 ohm
Output Level --
S/N Ratio (Weighted) --
Horizontal Resolution at DVD Mode --
--
RGB Signal Output Level --
Audio Signal Input Level -8.0dBm/50k ohm
Output Level --
Digital Output Level 0.5 V p-p/75 ohm
S/N Ratio at DVD (Weighted) --
Harmonic Distortion --
Frequency Response : at DVD --
at Video CD --
at SVCD --
at CD --
G-5 Power Power Source AC 120V, 60Hz
DC --
Power Consumption at AC 77W at 120V 60Hz
at DC --
Stand by (at AC) 1W at 120V 60Hz
Per Year -- kWh/Year
Protector Power Fuse Yes
A3-1

GENERAL SPECIFICATIONS
Safety Circuit Yes
IC Protector(Micro Fuse) No
G-6 Regulation Safety UL
Radiation FCC
Laser DHHS
G-7 Temperature Operation
+5
o
C ~ +40
o
C
Storage
-20
o
C ~ +60
o
C
G-8 Operating Humidity Less than 80% RH
G-9 On Screen Menu(TV) Yes
Display Menu Type Icon
TV Setup Yes
Picture Yes
Audio Yes
Picture Preference Yes
Color Temperature Yes
Auto Dimmer No
CH Tuning Yes
TV/CABLE Yes
Add/Delete Yes
Auto CH Memory Yes
V-Chip Yes
Language Yes
Clock Set No
Pin Code Registration No
Sound System No
AV2 Output Source No
Control Level Yes
Volume Yes
Brightness Yes
Contrast Yes
Color Yes
Tint Yes
Sharpness Yes
Bass Yes
Treble Yes
Balance Yes
Stereo Yes
Pin Code No
CH/AV/DVD Yes
Component Yes
Hotel Lock No
CH Label No
Sleep Timer Yes
Caption / Text Yes
Volume Yes
Sound Mute Yes
V-chip Rating Yes
G-10 On Screen Menu (DVD) Yes
Display Menu Type Character
Language Yes
Menu Yes
Subtitle Yes
Audio Yes
Picture Yes
TV Screen Size(4:3) Yes
OSD Display On/Off Yes
JPEG Interval No
Select Files No
Sound Yes
DRC (Dynamic Range Control) Yes
dts Decode No
Output(5.1ch/ 2ch) No
Surround On/Off No
Center On/Off No
Sub Woofer On/Off No
Parental Yes
Password Lock/ Un Lock Yes
A3-2

GENERAL SPECIFICATIONS
Rating Level Yes
Other Yes
OSD Language(Set up Language) Yes
Output(RGB/Composite) No
Eject Yes
No disc Yes
Reading Yes
Play Yes
Still/Pause Yes
Stop Yes
Prohibit Mark Yes
Step Yes
Skip(>>|) Yes
Skip(|<<) Yes
Random Yes (CD,MP3)
Repeat Yes
Slow+ Yes
Slow- Yes
Search+ Yes
Search- Yes
Jump Yes
Resume Yes
Title No. Yes
Chapter No. Yes
Track No. Yes
Time Yes
Subtitle No. Yes
Angle No. Yes
Vocal On/Off Yes
Audio No. Yes
Audio Stereo L/R No
Zoom Yes
Marker No. Yes
Program Play Back Yes (CD,MP3)
Surround On/Off No
Screen Saver No
MP3 Folder Name Yes
File Name Yes
File No Yes
Time Yes
Track No Yes
G-11
OSD Language
(TV) English, French, Spanish
(DVD) English, French, Spanish
G-12 Clock and Sleep Timer Max Time 120 Min
Timer Step 10 Min
On/Off Timer Program(On Timer / Off Timer) No
Wake Up Timer No
Timer Back-up (at Power Off Mode) more than -- Min Sec
G-13 Remote Unit RC-HE
Control Glow in Dark Remocon No
Format NEC
Custom Code 71-8E h
Power Source Voltage(D.C) 3V
UM size x pcs UM-4 x 2 pcs
Keys Total Keys 47 Keys
Power Yes
1Yes
2Yes
3Yes
4Yes
5Yes
6Yes
7Yes
8Yes
9Yes
0Yes
Eject Yes
A3-3

GENERAL SPECIFICATIONS
Play Yes
Stop Yes
Search+ Yes
Search- Yes
Skip+ Yes
Skip- Yes
Slow+ Yes
Slow- Yes
Still/Pause/Step Yes
Display/Call Yes
TV/DVD Yes
Cancel Yes
Audio Select Yes
Angle Yes
Subtitle Yes
Top Menu Yes
Setup/TV Menu Yes
Return Yes
DVD Menu Yes
Up/ Set+/ CH Up Yes
Down/ Set-/ CH Down Yes
Left/Select- Yes
Right/Select+ Yes
Select/Enter Yes
Play Mode Yes
Marker Yes
Input Select Yes
Volume + Yes
Volume - Yes
Repeat A-B Yes
Zoom/ Quick View Yes
Mute Yes
Sleep Yes
Jump/Closed Caption Yes
Freeze frame Yes
G-14 Features CATV Yes
Auto Shut Off Yes
Auto CH Memory Yes
V-Chip Yes
Type USA Type
Auto Search No
SAP Yes
PC Monitor Input No
S-Video Input Yes
Game Position No
FM Transmitter No
Surround Yes
Stable Sound No
Energy Star No
Closed Caption Yes
Comb Filter Yes
3D
Power On Memory No
Freeze frame Yes
Parental Lock (DVD Only) Yes
WMA No
JPEG No
Video CD Playback No
SVCD Playback
No
Overlay Graphics And Text No
Command List No
Entry Point Jump No
MP3 Playback Yes
Digital Out (Dolby Digital) Yes
(MPEG) Yes
(PCM) Yes
(DTS) Yes
A3-4

GENERAL SPECIFICATIONS
Down Mix Out (Dolby Digital) Yes
(DTS) No
Surround (Tru Surround) No
Screen Saver No
Available Scan Rates (Component) 480i/480p
Audio DAC 192kHz / 24bit
G-15 Accessories Owner's Manual Language English / Spanish
w/Guarantee Card
No
Remote Control Unit Yes
Rod Antenna
No
Poles --
Terminal --
Loop Antenna
No
Terminal --
U/V Mixer
No
DC Car Cord (Center+)
No
Guarantee Card Yes
Warning Sheet
No
Circuit Diagram
No
Antenna Change Plug
No
Service Facility List
No
Important Safeguard
No
Dew/AHC Caution Sheet
No
Quick Set-up Sheet
No
Battery Yes
UM size x pcs UM-4 x 2 pcs
OEM Brand No
AC Adapter
No
AC Cord (for AC Adapter)
No
AV Cord (2Pin-1Pin)
No
Registration Card
No
Information Sheet Yes
75 ohm Coaxial Cable/w Core Yes
300 ohm to 75 ohm Antenna Adapter
No
G-16 Interface Switch Front Power (Tact) Yes
Channel Up Yes
Channel Down Yes
Volume Up Yes
Volume Down Yes
Play Yes
Eject Yes
Skip+, Search+ Yes
Skip-, Search- Yes
Still/Pause No
Stop Yes
Main Power SW No
Rear Main Power SW No
Indicator Power Yes (Red)
Stand-by No
On Timer No
Terminals Rear Video Input 1 RCA x 1
Audio Input 1 RCA x 2(Stereo)
S- Input 1 Yes
Video Output No
Audio Output No
Component Yes
Euro Scart(21Pin) No
PC Monitor Input No
Digital Audio Output Coaxial (DVD Only)
DC Jack (Center +) No
VHF/UHF Antenna Input F Type
AC Outlet No
Side Video Input 2 RCA x 1
Audio Input 2 RCA x 2(Stereo)
Other Terminal Headphone
G-17 Set Size Approx. W x D x H (mm) 594 x 215 x 436
w/o Handle, Stand Approx. W x D x H (mm) 594 x 99 x 393
A3-5

GENERAL SPECIFICATIONS
G-18 Weight Net (Approx.) 9.0kg (19.8 lbs)
Net w/o Handle, Stand (Approx.) 8.0kg (17.6 lbs)
Gross (Approx.) 11.0kg (24.3 lbs)
G-19 Carton Master Carton No
Content --- Sets
Material --- / ---
Dimensions W x D x H(mm) ---
Description of Origin ---
Gift Box Yes
Material Double/White
W/Color Photo Label No
W/Handle No
Dimensions W x D x H(mm) 694x535x295
Design As Per Buyer 's
Description of Origin Yes
Drop Test 1 Corner / 3 Edges / 6 Surfaces
Height (cm) 62
Container Stuffing (40' container) 582
Sets
G-20 Material Cabinet Front PS 94V0 DECABROM
Rear PS 94V0 DECABROM
Jack Panel --
PCB Non-Halogen Demand No
Eyelet Demand No
G-21 Environment Pb Free Lead-free Solder No
Other No
Cd Free No
A3-6

DISASSEMBLY INSTRUCTIONS
B1-1
(1)
(1) (1)
(1)
Handle
1. REMOVAL OF MECHANICAL PARTS
AND P.C. BOARDS
1-1: HANDLE (Refer to Fig. 1-1)
1.
2. Remove the 4 screws (1). Remove the Handle in the direction of arrow.
Fig. 1-1
1-3: BACK CABINET (Refer to Fig. 1-3)
1.
2.
3.
4.
Remove the 8 screws (1).
Remove the screw (2).
Remove the screw (3).
Remove the Back Cabinet in the direction of arrow.
Fig. 1-3
(1)
(1)
(1)
(1) (3) (1)
(1)
(1)
(2)
Back Cabinet
(1)
1-4: BACK ANGLE (Refer to Fig. 1-4)
1.
2.
3.
4.
5.
6.
7.
8.
Remove the screw (1).
Remove the AC-Cord Holder in the direction of arrow (A).
Remove the screw (2).
Remove the 4 screws (3).
Remove the 2 screws (4).
Remove the Jack Plate and Jack Shield in the direction
of arrow (B).
Remove the 3 screws (5).
Remove the Back Angle in the direction of arrow (C).
Fig. 1-4
1-2: HINGE ASS'Y (Refer to Fig. 1-2)
1.
2.
3.
4.
5.
6.
7.
8.
Remove the 2 screws (1).
Remove the Hinge Cover in the direction of arrow (A).
Remove the 4 screws (2).
Remove the Stand Block in the direction of arrow (B).
Remove the 4 screws (3).
Remove the Hinge Ass'y in the direction of arrow (C).
Remove the 4 screws (4).
Remove the Stand in the direction of arrow (C).
Fig. 1-2
(1)
(1)
(A)
(3)
(B)
Hinge Cover (2)
(2) (2)
Stand
Hinge Ass'y
Stand Angle Ass'y
(C)
(2)
(4)
(4)
(4)
(4)
(A)
(1)
AC-Cord Holder
(2)
(3) (3)
Jack Plate
Jack Shield
Jack Plate
Jack Shield
(4)
(3)
(4)
(B)
(5)
(B)
(5)
Back Angle
(C)
(3)
(5)

DISASSEMBLY INSTRUCTIONS
B1-2
1-5: DVD DECK (Refer to Fig. 1-5)
1.
2.
3.
4.
Short circuit the position shown in Fig. 1-5 using a
soldering. If you remove the DVD Deck with no soldering
iron, the Laser may be damaged.
Disconnect the following connectors:
(CP2301, CP2302 and CP2601).
Remove the 4 screws (1).
Remove the DVD Deck in the direction of arrow.
Fig. 1-5
(1)
Pick Up PCB
(1)
(1)
DVD Deck
Short circuit using
a soldering iron.
(1)
1-6: SIDE PANEL/OPERATION 2 PCB (Refer to Fig. 1-6)
1.
2.
3.
4.
5.
Disconnect the following connector:
(CP2251).
Remove the 2 screws (1).
Remove the Side Panel in the direction of arrow (A).
Remove the 3 screws (2).
Remove the Operation 2 PCB in the direction of arrow (B).
Fig. 1-6
Side Panel
(1) (1)
(A)
(B)
Operation 2 PCB
(2)
(2)
(2)
NOTE
Use the Lead Free solder and the exclusive soldering iron.
Manual soldering conditions
• Soldering temperature: 320 ± 20°C
• Soldering time: Within 3 seconds
• Soldering combination: Sn-3.0Ag-0.5Cu
When Soldering/Removing of solder, use the drawing
equipment over the Pick Up Unit to keep the Fluk smoke
away from it.
When installing of the DVD Deck, remove all the soldering
on the short circuit position after the connection of Pick Up
PCB and DVD PCB connector.
1.
2
3.
4.
1-7: DVD PCB (Refer to Fig. 1-7)
1.
2.
3.
Disconnect the following connectors:
(CP701 and CP3804).
Remove the 4 screws (1).
Remove the DVD Shield Ass'y, FFC Shield and DVD
PCB in the direction of arrow.
Fig. 1-7
(1)
(1) (1)
DVD Shield Ass'y
DVD PCB
(1)
FFC Shield

DISASSEMBLY INSTRUCTIONS
B1-3
CP802
Move upward
Fig. 1-8-A
LCD PCB
Cable
1-8: LCD PCB (Refer to Fig. 1-8-B)
1.
2.
3.
4.
5.
6.
7.
Disconnect the following connectors:
(CP102, CP103, CP104, CP802 and CP3805).
(Remove CP802 cable as shown Fig. 1-8-A.)
Remove the screw (1).
Remove the MPEG Shield.
Remove the 4 screws (2).
Remove the PCB Angle in the direction of arrow (A).
Remove the 4 screws (3).
Remove the LCD PCB in the direction of arrow (B).
1-10: POWER PCB (Refer to Fig. 1-10)
1.
2.
3.
Disconnect the following connector:
(CP3802).
Remove the 4 screws (1).
Remove the Power PCB in the direction of arrow.
Fig. 1-10
(1) (1)
(1)
(1) Power PCB
1-9: BACK LIGHT PCB (Refer to Fig. 1-9)
1.
2.
3.
Disconnect the following connectors:
(CP3803, CP7001, CP7002, CP7003, CP7004, CP7005
and CP7006).
Remove the 4 screws (1).
Remove the Back Light PCB in the direction of arrow.
Fig. 1-9
(1)
(1)
(1)
(1)
Back Light PCB
(2)
(2)
(2)
PCB Angle
MPEG Shield
(2)
Fig. 1-8-B
(1)
(A)
(B)
(3)
(3)
(3) (3)
LCD PCB
1-11: SIDE JACK PCB (Refer to Fig. 1-11)
1.
2.
3.
Disconnect the following connector:
(CP705).
Remove the 3 screws (1).
Remove the Jack Plate, Jack Shield and Side Jack PCB
in the direction of arrow.
Fig. 1-11
(1)
Side Jack PCB
(1) (1)
Jack Plate
Jack Shield

DISASSEMBLY INSTRUCTIONS
B1-4
1-14: LCD COVER/LCD PANEL (Refer to Fig. 1-14)
1.
2.
3.
4.
Remove the 8 screws (1).
Remove the LCD Block in the direction of arrow (A).
Remove the 4 screws (2).
Remove the LCD Panel in the direction of arrow (B).
Fig. 1-14
(1)
LCD Cover
(A)
LCD Panel
(2)
(B)
Front Cabinet
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(2)
(2)
(2)
1-13:
1.
2.
3.
4.
Remove the 2 screws (1).
Remove the Operation 1 PCB in the direction of arrow (A).
Remove the 2 screws (2).
Remove the Remocon PCB in the direction of arrow (B).
(2)
OPERATION 1 PCB/REMOCON PCB
(Refer to Fig. 1-13)
(2)
Remocon PCB
(B)
Fig. 1-13
(1)
Operation 1 PCB
(1)
(A)
1-12: AV PCB (Refer to Fig. 1-12)
1.
2.
3.
Disconnect the following connectors:
(CP101, CP1001 and CP2201).
Remove the 6 screws (1).
Remove the AV PCB in the direction of arrow.
(1)
AV PCB
(1)
(1)
(1)
(1) (1)
Fig. 1-12

DISASSEMBLY INSTRUCTIONS
B2-1
2. REMOVAL OF DVD DECK PARTS
2-1:
Remove the 3 screws (1).
Remove the Loading Motor Ass'y.
Remove the 2 screws (2).
Remove the Motor and Loading Worm.
Disconnect the following connector: (CP2).
Remove the screw (3).
Unlock the 2 supports (4) and remove the Start SW
PCB Ass'y.
Unlock the 2 supports (5) and remove the End SW
PCB Ass'y.
1.
2.
3.
4.
5.
6.
7.
8.
Fig. 2-1-A
NOTE
1.
2.
In case of the Loading Worm installation, check if the
value of the Fig. 2-1-B is correct.
When installing the wire, install it correctly as Fig. 2-1-B.
Fig. 2-1-B
LOADING MOTOR ASS'Y/START SW PCB ASS'Y/
END SW PCB ASS'Y (Refer to Fig. 2-1-A)
Loading Motor Bracket
(1)
(1) (1)
Motor
Loading Worm
Start SW PCB Ass'y
(2) (2)
(3)
(4)
(4)
(5)(5)
End SW PCB Ass'y
29.7 ± 0.1mm
Safety surface for pressing
of the insert.
Motor
Loading Worm
Fig. 2-1-C
Start SW PCB Ass'y End SW PCB Ass'y
Motor
Red
Black
Red
Black
2-2:
Remove the screw (1).
Remove the Traverse Unit Rod.
Remove the 2 screws (2).
Unlock the 2 supports (3) and remove the CD Deck
Block.
Remove the 2 screws (4).
Unlock the 2 supports (5) and remove the Traverse
Unit Holder.
Remove the 4 Insulators.
1.
2.
3.
4.
5.
6.
7.
TRAVERSE UNIT ROD/TRAVERSE UNIT HOLDER/
CD DECK/INSULATOR (Refer to Fig. 2-2)
2-3: MOUTH ASS'Y (Refer to Fig. 2-3)
Remove the 2 screws (1).
Remove the Mouth Ass'y.
1.
2.
Fig. 2-3
(1)
Mouth Ass'y
• Screw Torque: 1 ± 0.2kgf•cm
Fig. 2-2
• Screw Torque: 3 ± 0.5kgf•cm
Traverse Unit Rod
(1)
(2)
CD Deck
(2)
(3)
(3)
(4)
(4)
Traverse Unit Holder
Insulator
Insulator
Insulator
Insulator
(5)
(5)
(1)
• Screw Torque: 0.8 ± 0.2kgf•cm

DISASSEMBLY INSTRUCTIONS
B2-2
2-6:2-4:
Remove the screw (1).
Remove the Disc L Lever and Disc L Lever Spring.
Remove the Stopper Spring.
Unlock the support (2) and remove the Locker Stopper.
Unlock the support (3) and remove the Disc Stopper.
Remove the Upper Roller, Roller Rubber and Roller
Gear.
1.
2.
3.
4.
5.
6.
DISC L LEVER/DISC STOPPER/LOCKER STOPPER/
ROLLER GEAR (Refer to Fig. 2-4-A)
Fig. 2-4-A
Disc L Lever
(1)
Disc L Lever Spring
Stopper Spring
Locker Stopper
(2)
(3)
Disc Stopper
Upper Roller
Roller Rubber
Roller Gear
• Screw Torque: 1.1 ± 0.2kgf•cm
2-5:
Remove the Guide Arm Spring.
Unlock the 3 supports (1) and remove the Rack Loading.
Remove the Rack Gear and Mid Rack Gear.
1.
2.
3.
Fig. 2-5
RACK LOADING/RACK GEAR/GUIDE ARM
SPRING/MID RACK GEAR (Refer to Fig. 2-5)
NOTE
1.In case of the Upper Roller installation, install correctly
as Fig. 2-4-B.
Fig. 2-4-B
[OK] [NG]
Upper Roller Upper Roller
Roller Gear Roller Gear
Rack Loading
Guide Arm Spring
Rack Gear
Mid Rack Gear
LINK R ASS'Y/LINK L/LINK MID/LINK SPRING
(Refer to Fig. 2-6)
Remove the screw (1).
Remove the Link Spring.
Unlock the support (2) and remove the Link L.
Unlock the support (3) and remove the Link Mid.
Remove the screw (4).
Unlock the 4 supports (5) and remove the Link R Ass'y.
1.
2.
3.
4.
5.
6.
Fig. 2-6
• Screw Torque: 0.7 ± 0.1kgf•cm (Screw (1))
• Screw Torque: 1.5 ± 0.2kgf•cm (Screw (4))
(1)
Link Spring
Link L
(2)
(3)
Link Mid
(4)
Link R Ass'y
(5)
(5) (5)
(5)
(1)
Mid Roller Gear 2
Arm Roller Ass'y
Terminal Gear
Mid Roller Gear 1
Fig. 2-7
• Screw Torque: 1.5 ± 0.2kgf•cm
2-7: ARM ROLLER ASS'Y/MID ROLLER 1/2 GEAR/
TERMINAL GEAR (Refer to Fig. 2-7)
Remove the screw (1).
Remove the Arm Roller Ass'y.
Remove the Terminal Gear and Mid Roller Gear 1.
Unlock the support (2) and remove the Mid Roller Gear 2.
1.
2.
3.
4.
(2)
(1) (1)
(1)
