AKE PowerCom INNOVA Plus Business User manual

N
F
not used
U
R
A
N
®
PowerCom INNOVA plus
Business
F
R
#33508
#33354
Operating Device #33435
PTT Two-way-radio push to talk
iVOX Intelligent fit for motorbike voice operating switch
ENT Phone control (depending on the type of phone)
MUTE Driver entertainment loudness (optionally)
LED Power on control
When with very loud driving noises the iVOX is blocked,
please use the PTT button.
Bluetooth Adapter
AA D&S Pro v4.11 #39354
Integrated power supply
Voice control via phone
Activatable automatic call acceptance
Individual volume adjustment and storage
Mobile Phone
Bluetooth 4 Helmet Connector
BT-HC2.4 Pro v4.06 #39353
Duplex / Stereo switching via control input.
Integrated power supply
For manually switching, press the key once briefly
(toggle mode) on the Bluetooth Helmet Connector
Blue LED flashes 1 x each - Duplex to Helmet
Blue LED flashes 2 x each - Stereo to Helmet
HC2.4a universal type
HC2.4b optimized for Schuberth helmet with Sena BT
HC2.4c optimized for Nolan helmet with B901L
Control Center v5.031 #30375
Integrated driving noise measurement for automatic
volume and microphone threshold control
Priority-controlled signal lowering
Smart phone
Phone call
& Music App
Two-way-Radio
wired connected
AKE Elektronik D 73230 Kirchheim – Tel.: [phone] E-Mail: [email protected]– –
Example settings for first use, turn carefully!
Phone Mic level: Outgoing mic-signal on Connector U
2-W-Radio Mic level:
Intercom 1, 2: Volume of voice monitor, if switched on
Treshold: Mic signal treshold without driving noise
Noise compensation:
Outgoing mic-signal on Connector F
Intercom
Treshold adjustment depending from driving noise
Bluetooth-Helmet pairing switch
hold down, connect and wait
for alternate red / blue blinking.
for pairing
Optimise noise reduction
required, use a close talk
capsule and mount the mic.
really close to the mouth!
Fuse max 1A! +12V switched power
or Stabilizer Output
GND
BT: Cut through
blue
black
red
yellow
green
Red Ignition switch or battery positive pole
Black Battery negative pole
Blue cut through with Bluetooth helmet
Yellow Connect to black for switching on the with BT-helmet
Green Not used
(12V)
Auto Pwr-On with wired helmet,
voice-monitor
Power stabilizer #73104
Optional, use additional for bad battery power
or board power noise interference
Highlights:
ü2-way-radio, Smartphone, GPS and others, together in one system
üFree speech via radio also away from the motorbike *
ü
Always if no duplex voice connection to helmet reqired (no PTT, no iVOX and no phone
call active), the AKE PowerCom Control Box switches the AKE Helmet Connector
automatically to Stereo Audio transfer.
*)
100% noise reduction when not speaking *
üDriving noise depended volume control
üAutomatically Stereo / Duplex-Switching for optimized music quality *
patent pending
Please read this before you install the PowerCom System
Quick Start Guide
Motorbike
Electronic case, etc.
A
Input +12V switched power
(9 - 18 V)
Battery 0V


Output 12V stabil
Mic. for
noise control
Isolated GND
U
GPS (optionally)
Mic volume
Music (optionally)
06.20
For Schuberth helmet
with Sena Bluetooth
Helmet examples:
ŸNolan 100.5 with B901
Bluetooth
ŸSchuberth SC1 with Sena
Bluetooth
ŸAny helmet with AKE
Bluetooth-Modul # 31426
For Bluetooth on the man systems:
Pair BT-HC2.4 with 1. Phone-profile
and deactivate StandBy-Mode!
Pair BT-HC2.4 with 1. Phone-
profile, note additional info!
Pair Bluetooth Helmet-Connector
BT-HC2.4
Bluetooth hand held # 31430
with buckle clip, usable on any helmet
with wired microphone and speaker set.
Second helmet
port (optionally)
