Table of contents
Foreword
Mandatory regulations
Overview
1 — Introduction
1.1 About SHDSL ................................................................................................... 1-2
1.2 Overview of the Speed Touch 591s .................................................................. 1-2
1.3 Compatibility ..................................................................................................... 1-4
1.4 Part numbers .................................................................................................... 1-5
2 — Features and typical applications
2.1 Frame relay ....................................................................................................... 2-2
2.2 V.35/X.21 circuit emulation ............................................................................... 2-4
2.3 T1/E1 circuit emulation ..................................................................................... 2-5

Table of contents
iv Speed Touch 591s Technical Practices
90-8785-01 February 2001
Installation
3 —Installation
3.1 Verifying the shipment ...................................................................................... 3-2
3.2 Installing the Speed Touch 591s and power supply ......................................... 3-3
Configuration
4 —Configuring generic node parameters
4.1 Node parameter configuration .......................................................................... 4-2
4.2 Configuring the network port ............................................................................. 4-8
5 —Configuring frame relay port parameters
5.1 Configuring the user port name and options ..................................................... 5-2
5.2 Configuring the user port stream ...................................................................... 5-6
5.3 Configuring user port stream options ................................................................ 5-8
5.4 Configuring frame forwarding stream options ................................................. 5-14
6 —Configuring frame relay connections
6.1 Configuring frame relay connection options ..................................................... 6-2
6.2 Configuring frame relay traffic parameters ....................................................... 6-4
6.3 Configuring network interworking ..................................................................... 6-5
6.4 Configuring service interworking ....................................................................... 6-7
6.5 Configuring frame forwarding connection options ............................................ 6-8
7 —TCA profiles
7.1 Overview ........................................................................................................... 7-2
7.2 TCA profile types and parameters .................................................................... 7-3
7.3 Maximum permissible time ............................................................................... 7-4
7.4 FRCC-type TCA profiles ................................................................................... 7-5
7.5 FRSC-type TCA profiles ................................................................................... 7-8
8 —Configuring the V.35/X.21 CE user port
8.1 Configuring the user port name and options ..................................................... 8-2
8.2 Configuring user port circuit parameters ........................................................... 8-5
9 —Configuring V.35/X.21 CE connections
9.1 Configuring connection options ........................................................................ 9-2

Table of contents
Speed Touch 591s Technical Practices v
February 2001 90-8785-01
10 —Configuring the T1/E1 CE port
10.1 Configuring the T1/E1 port name and service options .................................... 10-2
10.2 Configuring the T1 port physical options ........................................................ 10-5
10.3 Configuring the E1 port physical options ...................................................... 10-10
10.4 Configuring trunk conditioning parameters ................................................... 10-11
11 —Configuring T1/E1 CE connections
11.1 Connection options ......................................................................................... 11-2
12 —Configuring T1/E1 CE channel groups
12.1 Configuring channel groups ............................................................................ 12-2
12.2 Creating channel groups ................................................................................. 12-3
12.3 Adding channels ............................................................................................. 12-3
12.4 Naming channel groups ..................................................................................12-4
12.5 Displaying channels in a channel group ......................................................... 12-5
12.6 Configuring the padding octet pattern ............................................................. 12-5
12.7 Configuring the playout buffer size ................................................................. 12-6
12.8 Configuring the number of data octets ............................................................ 12-7
12.9 Deleting channels and channel groups ........................................................... 12-8
Maintenance
13 —Maintenance and file transfers
13.1 System maintenance ...................................................................................... 13-2
13.2 Network port maintenance .............................................................................. 13-4
13.3 User and T1/E1 port maintenance .................................................................. 13-5
13.4 File transfers ................................................................................................... 13-9
14 —Troubleshooting
14.1 LED activity ..................................................................................................... 14-2
14.2 Alarms ............................................................................................................. 14-4
15 —Statistics
15.1 Frame relay statistics ...................................................................................... 15-2
15.2 V.35/X.21 CE statistics ................................................................................... 15-6
15.3 T1 CE statistics ...............................................................................................15-9
15.4 E1 CE statistics .............................................................................................15-13

Table of contents
vi Speed Touch 591s Technical Practices
90-8785-01 February 2001
App A. Pin and signal assignments A-1
Glossary
Index

Speed Touch 591s Technical Practices vii
February 2001 90-8785-01
Foreword
This guide describes the Speed Touch 591s. It consists of the following chapters.
•Chapter 1 introduces SHDSL technology.
•Chapter 2 describes features and typical applications.
•Chapter 3 describes installation.
•Chapter 4 describes node configuration procedures that are common to all
versions.
•Chapters 5 to 7 describe configuration procedures for the frame relay version.
•Chapters 8 and 9 describe configuration procedures for the V.35 CE version.
•Chapters 10 to 12 describe configuration procedures for the T1 and E1 CE
versions.
•Chapter 13 describes maintenance and file transfers.
•Chapter 14 describes LED activity and alarms.
•Chapter 15 describes available statistics.
•The appendix lists pin and signal assignments for Speed Touch 591s ports.

Foreword
viii Speed Touch 591s Technical Practices
90-8785-01 February 2001
Conventions
The following conventions are used to indicate important information.
An em dash (—) in a table cell means that the information does not apply.
An empty cell in a table means that the system or component does not support the
item.
Steps with softkeys use ↵to indicate the Return key.
An asterisk (*) next to a softkey indicates the default option.
The procedures in this document do not direct you to select the PROCEED softkey;
follow the prompt on the screen.
Table 1 lists the documentation conventions used to describe the operations and
procedures in a node management session.
When there are options in a procedure, they are identified by letters, as shown in the
following sample procedure.
Procedure 1 Sample
1This step offers three options. Choose one of the options.
aThis is the first option.
bThis is the second option.
cThis is the third option.
2This step has no options.
Danger —Indicates that the described activity or situation may pose
a threat to personal safety.
Warning —Indicates that the described activity or situation may
cause equipment damage.
Caution —Indicates that the described activity or situation may
cause service interruption.
Note —Provides special information.

Foreword
Speed Touch 591s Technical Practices ix
February 2001 90-8785-01
Table 1 Documentation conventions for node management sessions
Softkey trees
Softkey trees are used throughout this document to provide an overview of the
configuration options available to the user. They are followed by specific
information on procedures and variables for each configuration option.
Convention Action Examples
<key> Enter a keyboard key ↵
<Esc>
SOFTKEY Select the softkey TO_ENDPOINT
PROCEED
<identifier> Enter the object identifier <shelf>
<slot>
<value> Enter the numeric value <5>
<word> Enter characters exactly as shown <CPSS>

Foreword
x Speed Touch 591s Technical Practices
90-8785-01 February 2001

Speed Touch 591s Technical Practices xi
February 2001 90-8785-01
Mandatory regulations
The mandatory regulations govern the installation and operation of the Speed Touch
591s. Adhere to these instructions to ensure that regulatory compliance requirements
are met.

Mandatory regulations
xii Speed Touch 591s Technical Practices
90-8785-01 February 2001
List of terms
Table 2 lists the expansions of abbreviations used.
Table 2 Abbreviations
General requirements
Abbreviation Expansion
AS/NZS Australia/New Zealand Standards
CE Conformité Européenne
CSA Canadian Standards Association
EEC European Economic Community
EMC Electromagnetic Compatibility
EN European Norm
FCC Federal Communications Commission
IEC International Electrotechnical Committee
LVD Low Voltage Directive
NRTL Nationally Recognized Testing Laboratory
REN Ringer Equivalent Number
SELV Safety Extra Low Voltage
TNV Telecommunications Network Voltage
TTE Telecommunications Terminal Equipment
UL Underwriters Laboratories
Warning —The system contains no user-serviceable parts. Send
parts requiring service to qualified personnel.
Caution —1 To prevent accidental shorting of cards, the cards must
be correctly aligned between the card guides before insertion.
Caution —2 Do not connect the power cable to the unit when the
power supply is plugged in. Always connect the power cable to the
unit before you plug in the power supply.

Mandatory regulations
Speed Touch 591s Technical Practices xiii
February 2001 90-8785-01
Equipment interconnection points
Interconnection points of the system are defined as follows:
•SELV for the user, T1, E1, and serial ports on the Speed Touch 591s
•TNV for the SHDSL network port on the Speed Touch 591s
TNV can be classified as TNV1, TNV2, or TNV3.
TNV1 circuits are telecommunications circuits that have voltages below SELV
limits, may be subject to overvoltages, and can be connected off premises (to an
outside plant).
TNV2 circuits are telecommunications circuits that have voltages exceeding SELV
limits, are not subject to overvoltages, and do not connect off premises(to an outside
plant).
TNV3 circuits are telecommunications circuits that have voltages above SELV
limits, may be subject to overvoltages, and can be connected off premises (to an
outside plant). The SHDSL network port on the Speed Touch 591s is TNV3.
Connect SELV circuits on this equipment only to other circuits that comply with the
requirements of SELV circuits as defined in CSA C22.2 No. 950, UL1950,
EN60950, AS/NZS 3260, and IEC950.
Connect TNV circuits on this equipment only to other circuits that comply with the
requirements of TNV circuits as defined in CSA C22.2 No. 950, UL1950, EN60950,
AS/NZS 3260, and IEC950.
External power supply
EMC compliance
EMC compliance may require the use of ferrites, shielded cables, or other special
accessories. Where required, these special accessories must be installed per the
instructions.
Regulatory symbols
The following sections show examples of generally used regulatory approvals
symbols. These symbols may be used on product markings such as approvals labels
and are described in IEC417.
Warning —The Speed Touch 591s is intended for use when
powered by an appropriate external power supply available only from
Alcatel. The use of any other power supply may invalidate regulatory
approvals of this equipment.

Mandatory regulations
xiv Speed Touch 591s Technical Practices
90-8785-01 February 2001
Power on
This symbol indicates that the principal On/Off switch is in the On (|) position.
Figure 1 On position symbol for On/Off switch
Power off
This symbol indicates that the principal On/Off switch is in the Off (O) position.
Figure 2 Off position symbol for On/Off switch
Standby
This symbol indicates that the switch is in the standby position and that the primary
power is still On.
Figure 3 Standby position symbol for On/Off switch
9715
9716
9726

Mandatory regulations
Speed Touch 591s Technical Practices xv
February 2001 90-8785-01
Protective grounding terminal
These symbols indicate a terminal that must be connected to earth ground prior to
making any other connections to the equipment.
Figure 4 Supply wire protective earth
Figure 5 Protective earth
Dangerous voltage
This symbol alerts the user to the presence of uninsulated dangerous voltage within
the product’s enclosure that could cause electric shock. This label would be installed
on the outside of the product enclosure.
Figure 6 Dangerous voltage symbol
Instructions
This symbol alerts the user to the presence of important operating and maintenance
(servicing) instructions in the product documentation.
Figure 7 Important instructions symbol
9717
9718
9719
9720

Mandatory regulations
xvi Speed Touch 591s Technical Practices
90-8785-01 February 2001
Industry Canada regulations
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilitiesof the localtelecommunications company. The equipment
must also be installed using an acceptable method of connection. The customer
should be aware that compliance with the above conditions may not prevent
degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative designated
by the supplier. Any repairs or alterations made by the user to this equipment, or
equipment malfunctions, may give the telecommunications company cause to
request the user to disconnect the equipment.
For their own protection, users should make sure that the electrical ground
connections of the power utility, telephone lines, and internal metallic water pipe
system, if present, are connected together. This precaution may be particularly
important in rural areas.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme àla norme NMB-003 du Canada.
Note —The Industry Canada (formerly known as the Department
of Communications) label identifies certified equipment.
This certification means that the equipment meets certain
telecommunications network protective, operational and safety
requirements as prescribed in the Terminal Equipment Technical
Requirements document(s). Industry Canada does not guarantee that
the equipment will operate to the user’s satisfaction.
Warning —Users should not attempt to make electrical ground
connections; contact an electrical inspection authority, or electrician,
as appropriate.
Note —1 The RingerEquivalence Number(formerly known asLoad
Number,seenotebelow)assignedtoeachterminaldeviceprovidesan
indication of the maximum number of terminals allowed to be
connected to a telephone interface. The termination on an interface
may consist of any combination of devices, subject only to the
requirement that the sum of the Ringer Equivalence Numbers of all
the devices does not exceed 5.
The REN for the node is not applicable.
Note —2 Asof August14,1996,theLoadNumber has beenchanged
to Ringer Equivalence Number by Industry Canada, to coincide with
theFCC oftheUnitedStatesforthepurposeofcountryharmonization
and promoting the goals of NAFTA.

Mandatory regulations
Speed Touch 591s Technical Practices xvii
February 2001 90-8785-01
Safety approval for dc systems
The dc source for the system must meet the requirements of a SELV source in
accordance with CSA C22.2 No. 950. The system is intended for use with a SELV
secondary source that is electrically isolated from the ac source, and that is reliably
connected to earth.
United States Federal Communications Commission
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a commercial
environment. This equipment generates, uses and can radiate radio frequency
energy, and if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference, in which case the users will
be required to correct the interference at their own expense.
In the event that repairs are needed to this equipment, contact:
Alcatel CID
810 Commerce Park Drive,
Ogdensburg, NY 13669
[phone]
Safety approval for dc systems
The dc source for the system must meet the requirements of a SELV source in
accordance with UL1950. The system is intended for use with a SELV secondary
source that is electrically isolated from the ac source, and that is reliably connected
to earth.
CSA NRTL
This equipment is certified by the Canadian Standards Association as meeting the
requirementsof UL1950,SafetyofInformationTechnologyEquipment(orUL1459,
Safety of Telephone Equipment). CSA is listed by the American Federal
Occupational Safety and Health Administration as equivalent to Underwriters
Laboratories and other American safety testing laboratories under the Nationally
Recognized Testing Laboratories program.
European regulations
This product has been CE marked in accordance with the requirements of European
Directive 93/68/EEC.
This product complies with the requirements of European Directive(s) 73/23/EEC
(LVD), 89/336/EEC (EMC) and 91/263/EEC (TTE).
This equipment must be permanently earthed.

Mandatory regulations
xviii Speed Touch 591s Technical Practices
90-8785-01 February 2001
EMC compliance
For the Speed Touch 591s to meet the requirements of EN55022 Class B, a ferrite
bead must be installed on the network connection cables.
The network port must have a Steward ferrite bead (part number 28A2025-0A2) or
equivalent, installed as closely as possible to the port.
Safety approval for dc systems
The dc source for the system must meet the requirements of a SELV source as
defined in EN60950.
United Kingdom regulations
Power supply cord wiring
The instructions for power supply cord and plug wiring are no longer mandatory. If
this information is required, consult the Australian regulations section for details,
since both countries have identical power supply cord and plug wiring requirements.
External power supply
Norway regulations
Apparatus maa tilkobles jordet stikkontakt. Jordet Stikkontakt skal benyttes naar
apparatet tilkobles datanett.
The equipment must be connected to an earthed mains socket outlet. An earthed
mains socket outlet mustbe used when the equipment is connected to a data network.
Sweden regulations
Apparaten skall anslutas till jordat uttag nar den anslutas till ett natverk.
The product should be connected to a mains socket outlet with earthing contact.
Switzerland regulations
The mains plug must comply with SEV/ASE 1011.
Warning —The Speed Touch 591s is intended for use when
powered by an appropriate external power supply available only from
Alcatel. The use of any other power supply may invalidate regulatory
approvals of this equipment.

Mandatory regulations
Speed Touch 591s Technical Practices xix
February 2001 90-8785-01
Australian regulations
The core wires in the mains lead use the following color codes:
•green and yellow: earth
•blue: neutral
•brown: live
The colors of the core wires in the mains lead of this equipment may not correspond
with the colored markings identifying the terminals in the plug. Proceed as follows
if power supply cord rewiring is required:
•the green and yellow core wire must be connected to the terminal in the plug that
is marked with the letter E or with the earth symbol, or is colored green and
yellow
•the blue core wire must be connected to the terminal that is marked with the letter
N, or is colored black
•the brown core wire must be connected to the terminal that is marked with the
letter L, or is colored red
Warning —This equipment must be earthed.

Mandatory regulations
Speed Touch 591s Technical Practices xx
February 2001 90-8785-01
