Alemite 7234-B User manual

Service Guide
Alemite Corporation
PO Box 473515, Charlotte, North Carolina 28247-3515
Copyright
©
1997 by Alemite Corporation
This document contains confidential information that is the property of Alemite Corporation
670453
and is not to be copied, used, or disclosed to others without express written permission.
Revision (7-97)
SER 7234-B
7234-B
7235-B
3-7/8 "
(9.8 cm)
7 " (17.8 cm)
7-7/8 "
(20 cm)
19 " (48.3 cm)
Dia.
21"
(53.3 cm)
17/32 " (13.5 mm) Dia.
Figure 1 Heavy-Duty Hose Reels Models 7234-B and 7235-B
Description
Caution
These reels must be ceiling mounted at a
height no greater than 16 feet (4.9 m) from
the floor to comply with the warranty.
Hose reel Models 7234-B and 7235-B are
designed to be mounted to the wall, ceiling, or floor.
They can also mount to truck beds.
The reels mount as a single unit or in banks of as
many as required. Banked reels should be a
minimum of 9 " (23 cm) apart on center. For ease in
reel maintenance, a space of up to 15 " (38 cm) is
recommended. See Figure 6 .
Each model reel is spring-powered and self-
retracting. A latch locks the reel once the required
length of hose is released. A pull releases the latch
and allows the hose to retract onto the reel.
Models 7234-B and 7235-B
Model 7234-B contains a high-pressure swivel
assembly. This swivel is designed to dispense
grease from either 1/4 " or 3/8 " ID two-wire braid
delivery hose.
A medium-pressure swivel assembly is included
with Model 7235-B. Free-flowing lubricants such as
Heavy-Duty Hose Reels
Accessories
Material Delivery Hoses
Reel
Model High-Pressure Material Delivery Hose Medium-Pressure Material
Delivery Hose Low-Pressure Air and Water Delivery Hose
1/4 " ID Two-Wire Braid 3/8 " ID Two-Wire Braid 1/2 " ID Single-Wire Braid 3/8 " ID Fabric-Reinforced
7234-B 317874-30, 317874-50 317870-50
7235-B 317856-20, 317856-30,
317856-40, 317856-50 317803-25, 317803-30, 317803-40, 317803-50
Delivery hose length is designated by the dash number. Example : 317874-30 is 30 feet long.
motor and gear oil, and automatic transmission fluid are
dispensed from 1/2 " ID single-wire braid delivery hose. Air and
water is transported through 3/8 " fabric-reinforced hose.

SER 7234-B Heavy-Duty Hose Reels
Revision (7-97) 2 Alemite Corporation
19
1617
18
20
21
26
27
28
29
30
31
38
39
40
41
22
23
A
Accessory Items
B
14
Apply
Thread
Sealant
Here
3
2
1
High-Pressure
Medium-
Pressure
456
8
7
9
11
10
Apply
Thread Sealant Here
12 13
15
24
25
Mark to
Indicate Flat
12
32
32
35
36
37
25
33 32
32
32
34
Early
Model
Figure 2 Heavy-Duty Hose Reels - Exploded View

Heavy-Duty Hose Reels SER 7234-B
Alemite Corporation 3 Revision (7-97)
Item
No. Part No. Description Qty Notes Numeric Order Part # (Item #)
1 393539-85 Swivel Assembly, High-Pressure 1 Model 7234-B 1001-86 (A)
393539-99 Swivel Assembly, Medium-Pressure 1 Model 7235-B 1001-88 (A)
2 Adapter, 90 ° Swivel 1 337437 (B)
3 Screw 2 393539-2 (19)
4 Ball 20 393539-3 (22)
5 Body, Swivel 1 393539-4 (40)
6 Ring, Back-Up (Nylon) 1 393539-5 (41)
7 O-Ring 1 393539-8 (20)
8 O-Ring 1 393539-10 (26)
9 Stud, Hollow 1 393539-11 (29)
393539-84 Swivel Assembly, Medium-Pressure 1 Obsolete 393539-12 (24)
10 Adapter, 90 ° Swivel 1 393539-14 (34)
11 Stud, Hollow 1 393539-17 (25)
12 Ring, Split, Back-Up (Nylon) 2 393539-19 (33)
13 O-Ring 2 393539-20 (38)
14 Body, Swivel 1 393539-23 (16)
15 393539-97 Ring, Snap 1 393539-24 (17)
16 393539-23 Washer, Flat, 1/4 " 4 393539-25 (28)
17 393539-24 Locknut, 1/4 " -20 4 393539-26 (18)
18 393539-26 U-Bolt 2 393539-73 (39)
19 393539-2 Sheave Assembly 1 393539-84
20 393539-8 Gasket, Spring Case 1 393539-85 (1)
21 393539-90 Arbor, Spring (Plastic) [Includes Key] 1 393539-88 (31)
22 393539-3 Arbor, Spring (Aluminum) 1 393539-89 (30)
23 393539-98 Setscrew, 3/8 " -16 x 1/2 " 1 393539-90 (21)
24 393539-12 Shaft, Main 1 393539-91 (35)
25 393539-17 Ring, Snap 2 393539-92 (37)
26 393539-10 Base Assembly 1 393539-93 (36)
27 393539-94 Nut (Nylon) 1 393539-97 (15)
28 393539-25 Nut, Latch Stud, 1/2 " -20 1 393539-98 (23)
29 393539-11 Guide and Roller Assembly 1 393539-99
30 393539-89 Locknut, 5/16 " -18 4
31 393539-88 Setscrew, 1/2 " -13 x 3/8 " 1
32 393539-74 Pawl Assembly, Latch 1
33 393539-19 Locknut, 10 -32 6
34 393539-14 Spring, Latch (Early Models Only) 1
35 393539-91 Spring, Latch 1
36 393539-93 Bushing, Latch 1
37 393539-92 Screw, Machine 1
38 393539-20 Nut, Jam, 3/8 " -24 1
39 393539-73 Spring Case and Ratchet Assembly 1
40 393539-4 Stud, (Return Spring Outer Anchor) 1
41 393539-5 Spring, Power 1
Accessory Items
A1001-86 Adapter, 90 ° Union, 3/8 " NPSM (f) 1 Model 7234-B
1001-88 Adapter, 90 ° Union, 1/2 " NPSM (f) 1 Model 7235-B
B 337437 Kit, Hose Stop 1
Legend :
Part numbers left blank (or in italics ) are not available separately
designates a repair kit item
Repair Kits
Part No. Kit Symbol Description
393539-95 Kit, for obsolete Medium-Pressure Swivel (contains tube of silicone grease)
393539-100 Kit, Medium-Pressure Swivel Repair

SER 7234-B Heavy-Duty Hose Reels
Revision (7-97) 4 Alemite Corporation
Service Hints
Refer to the Overhaul Procedures for Details
Personal Injury can Occur
Remove Tension from Power Spring
Prior to Disassembly Personal Injury can Occur
Install Power Spring
in the Proper Direction Reel will Malfunction
Setscrew can
Damage Shaft
Always Secure the Power Spring
with Hose Clamps Prior to Removal
Product Leakage
can Occur
Apply a High Quality Thread Sealant
or Teflon Tape to Components
that Connect to the Main Shaft
Always Refer to the Troubleshooting Chart
for Reasons the Reel may not Retract
Mating Surfaces
are Subject to Wear
Inspect Swivel Body and Stud
Prior to Repair Kit Installation
Power Spring can Hang
on Spring Arbor and/or the Stud
Use Extreme Caution During Separation
of Spring Case from Sheave
Mark the Main Shaft
to Indicate Flat
Medium-Pressure
Swivel Assembly

Heavy-Duty Hose Reels SER 7234-B
Alemite Corporation 5 Revision (7-97)
IMPORTANT: Prior to performing any
maintenance procedure, the following safety
precautions must be observed. Personal
injury may occur.
WARNING
Release all pressure within the system
prior to performing any overhaul procedure.
• Disconnect the air supply line to the pump’s
motor.
• Into an appropriate container, operate the
control valve to discharge remaining pressure
within the system.
• Disconnect the material connecting hose.
Never point a control valve at any portion of your
body or another person. Accidental discharge of
pressure and/or material can result in injury.
Read each step of the instructions carefully. Make
sure a proper understanding is achieved before
proceeding.
Remove and Replace
NOTE : These procedures address the most
common repair made to the reel. Refer to
Figure 2 for component identification on the
following procedures.
For Overhaul procedures, refer to the section entitled
Overhaul .
Spring Arbor and Power Spring
Should the reel fail to retract, either the Power Spring
and/or Arbor are broken or have been installed incorrectly.
1. Close the shut-off valve to stop the supply of oil to the
reel, if applicable.
2. Operate the control valve into a collection container to
release any pressure within the system.
3. Disconnect the material hose from the reel.
• Cap each connection to prevent spillage of oil.
4. Remove the hardware that secures then reel to its
mount.
5. Position the assembly on its reel (base assembly
upward) on a suitable work surface.
IMPORTANT: Make sure there is no tension
on Power Spring ( 41 ).
6. Rotate the Base, Guide and Roller assembly in both
directions to ensure the reel assembly is not operating
properly.
7. Remove Union Adapter ( A ) from Main Shaft ( 24 ) if
used.
• Cap the Main Shaft as required.
8. Loosen Setscrew ( 31 ) that secures the Main Shaft to
Base Assembly ( 26 ).
• Mark the Main Shaft to indicate the flat to ensure the
Setscrew seats properly upon reassembly.
See Figure 2 .
9. Remove the Base Assembly [with Guide and Roller
Assembly ( 29 )] from Spring Case and Ratchet
Assembly ( 39 ).
10. Remove Snap Ring ( 25 ) that secures Main Shaft ( 24 )
to the Spring Case and Ratchet Assembly.
• Use care not to mar the surface of the Main Shaft.
Spring Case and Ratchet Assembly
11. Remove Jam Nut ( 38 ) that secures Stud ( 40 ) to the
Spring Case and Ratchet Assembly.
WARNING
Power Spring can uncoil during separation
of Spring Case and Ratchet Assembly from
Sheave Assembly. Personal injury can occur.
Alemite Corporation recommends to secure the
Power Spring with two (2) cable ties or two steel
hose clamps prior to removal.
Should the Power Spring require disposal, secure
with two (2) steel hose clamps.
IMPORTANT: Separate the Spring Case and
Ratchet Assembly from Sheave Assembly
( 19 ) with care. Check to ensure the Power
Spring remains coiled during this process
12. Remove Locknuts ( 33 ) that secure the Spring Case and
Ratchet Assembly to the Sheave Assembly.
13. Separate the Spring Case and Ratchet Assembly from
the Power Spring and Sheave Assembly.
• Use a wide blade or other suitable tool.

SER 7234-B Heavy-Duty Hose Reels
Revision (7-97) 6 Alemite Corporation
Spring ArborPower Spring Direction of Rotation
when Hose is
Pulled from Reel
Sheave
Assembly
Steel Hose Clamps
for Disposal
Cable Ties for Removal
NOTE : If the Spring Case and Ratchet
Assembly and the Power Spring separate
from the Sheave Assembly as a unit:
• Grip the assembly firmly and turn end-for-end
(Power Spring upward).
• Secure the Power Spring with the proper retainer
positioned 180 degrees apart. See inset in
Figure 3 .
• Separate the Power Spring from the Spring Case
and Ratchet Assembly.
14. Secure the Power Spring with two tie wraps positioned
180 degrees apart as necessary.
If the Power Spring is Broken
15. Properly secure the Power Spring with clamps and
discard.
If the Spring Arbor is Broken
16. Remove additional Snap Ring ( 25 ) from the Main
Shaft.
• Use care not to mar the surface of the Main Shaft.
17. Remove Setscrew ( 23 ) that secures Spring Arbor ( 22 )
to the Main Shaft.
NOTE : Certain models contain a plastic
Spring Arbor ( 21 ) that attaches to the Main
Shaft with a Key.
Prior to reassembly, lubricate the following with multi-
purpose lithium grease. The:
• top and bottom surfaces of Power Spring ( 41 )
• surface of Sheave Assembly ( 19 ) that contacts the
Power Spring
• Main Shaft ( 24 )
• bearing surface in the Sheave Assembly
• bearing in Spring Case and Ratchet Assembly ( 39 )
NOTE : Refer to Figures 2 and 4 for compo-
nent identification on assembly procedures.
Spring Case and Ratchet Assembly
IMPORTANT: Position Power Spring ( 41 ) in
the proper direction. Inverse installation will
cause the reel to malfunction.
18. Install Power Spring (with tie wraps) onto the Sheave
Assembly.
• Make sure to align the eye of the Power Spring with
the hole in the Sheave Assembly.
19. Install Stud ( 40 ) [threads upward] into the eye of the
Power Spring and into the Sheave Assembly as
required.
Figure 3 Power Spring and Spring Arbor Orientation on Sheave Assembly

Heavy-Duty Hose Reels SER 7234-B
Alemite Corporation 7 Revision (7-97)
20. Install Spring Arbor ( 22 ) onto the Main Shaft and
secure with Setscrew ( 23 ).
• Make sure the Setscrew contacts the flat of the Main
Shaft.
• See Figure 3 for the proper position of the Arbor.
NOTE : Certain models contain a plastic
Spring Arbor ( 21 ) that attaches to the Main
Shaft with a Key.
21. Install Snap Ring ( 25 ) onto the Main Shaft.
• Use care not to mar the surface of the Main Shaft.
22. Make sure the position of Spring Case Gasket ( 20 ) is
properly aligned on the Sheave Assembly.
• Hold the Gasket in place with spots of grease.
WARNING
Power Spring can uncoil during tie wrap
removal. Personal injury can occur.
23. Carefully remove the tie wraps from the Power Spring.
24. Install the Spring Case and Ratchet Assembly onto the
Power Spring and Sheave Assembly.
• Make sure the hole in the Spring Case and Ratchet
Assembly engages the Spring Case Stud.
• Make sure to the Gasket is positioned properly.
25. Install Jam Nut ( 38 ) that secures the Stud to the Spring
Case and Ratchet Assembly.
• Tighten the Nut securely.
26. Install Locknuts ( 33 ) that secure the Spring Case and
Ratchet Assembly to the Sheave Assembly.
• Tighten the Locknuts securely.
27. Install additional Snap Ring ( 25 ) onto the Main Shaft.
• Use care not to mar the surface of the Main Shaft.
Base Assembly
28. Install the Base, Guide and Roller Assembly onto the
Spring Case and Ratchet Assembly.
29. Align Setscrew ( 31 ) with the mark on the Main Shaft.
30. Tighten the Setscrew that secures the Main Shaft to
Base Assembly.
31. Bench Test the reel.
• Refer to the section entitled Bench Test for details.
Overhaul
NOTE : Refer to Figure 2 for component
identification on all overhaul procedures.
Disassembly
IMPORTANT: Prior to disassembly, release
tension on Power Spring ( 33 ).
1. Pull on the material hose to disengage the ratchet on
Spring Case and Ratchet Assembly ( 39 ).
2. Allow the material hose to retract onto the reel.
3. Turn the reel in the same direction until the Power
Spring bypasses Spring Arbor ( 21 or 22 ).
• A pronounced “click” will sound.
Spring Case and Ratchet Assembly
Follow procedures 1-17 in the section entitled Remove
and Replace Spring Arbor and Power Spring .
Sheave Assembly
4. Remove Spring Case Gasket ( 20 ) from the Sheave
Assembly.
5. Remove the Main Shaft assembly from the bottom of
the Sheave Assembly.
Medium-Pressure Swivel Assembly
The medium-pressure swivel assembly can be
disassembled. O-Rings ( 7 and 8 ), Back-Up Ring ( 6 ),
Screws ( 3 ) and Balls ( 4 ) are serviced in a kit.
NOTE : The obsolete medium-pressure
swivel can also be repaired with a kit.
See Figure 2 .
High-Pressure Swivel Assembly
The high-pressure swivel assembly cannot be repaired.
It is serviced as an assembly.
Base Assembly
6. Remove Nut ( 27 ) that secures Machine Screw ( 37 ) to
Base Assembly ( 26 ).
• Remove the Machine Screw and Latch Bushing ( 36 )
from the Base Assembly and Latch Spring ( 35 ).
NOTE : Earlier models contain Latch Spring
( 34 ). The Latch Bushing and Machine Screw
are not applicable.
7. Remove Latch Stud Nut ( 28 ) that secures Latch Pawl
Assembly ( 32 ) to the Base Assembly.
• Remove the Latch Pawl Assembly from the Base
Assembly.

SER 7234-B Heavy-Duty Hose Reels
Revision (7-97) 8 Alemite Corporation
Clean and Inspect
NOTE : Use the repair kit for replacement
parts. Make sure all the components are
included in the kit before discarding used
parts.
1. Clean all metal parts in a modified petroleum-based
solvent. The solvent should be environmentally safe.
• Make sure to remove the old sealant from the
threads of all components.
2. Inspect all parts for wear and/or damage.
• Replace as necessary.
3. Remove any burrs from the Main Shaft as required.
Assembly
Prior to assembly, lubricate the following with multi-
purpose lithium grease. The:
• top and bottom surfaces of Power Spring ( 41 )
• surface of Sheave Assembly ( 19 ) that contacts the
Power Spring
• Main Shaft ( 24 )
• bearing surface in the Sheave Assembly
• Bearing in Spring Case and Ratchet Assembly ( 39 )
Lubricate O-Rings ( 7 and 8 ) with silicone grease.
NOTE : Refer to Figures 2 and 4 for com-
ponent identification on assembly proce-
dures.
Sheave Assembly
1. Position Sheave Assembly ( 19 ) with studs upward.
2. Install Main Shaft ( 24 ) [grooves upward] into the
Sheave Assembly.
Follow procedures 18-27 in the section entitled
Remove and Replace SpringArbor and Power Spring .
Medium-Pressure Swivel Assembly
3. Install the complete Swivel assembly to the Main
Shaft and the material hose.
• Apply a high quality thread sealant or Teflon tape
to the male threads of the Swivel Assembly.
• Tighten the connection securely.
Base Assembly
4. Install Latch Pawl Assembly ( 32 ) [stud first] into the
inside of Base Assembly ( 26 ).
5. Install Latch Stud Nut ( 28 ) that secures the Latch
Pawl Assembly to the Base Assembly.
High-Pressure
Swivel Assembly
1
19
33
22
24
26
27
28
29
30
37
31
32
35
36
38
39
41
40
20
High-Pressure
Swivel Assembly
1
High-Pressure
Swivel Assembly
1
High-Pressure
Swivel Assembly
25
23
Figure 4 Heavy-Duty Hose Reels - Section View
Refer to Figure 2
Parts List
for Parts Identification

Heavy-Duty Hose Reels SER 7234-B
Alemite Corporation 9 Revision (7-97)
Installation
1. Position the Guide and Roller Assembly to correspond
with the mount position of the reel as required.
• Refer to section entitled Mount Positions for details.
2. Mount the reel assembly with the appropriate hardware.
3. Attach the connecting hose to Union Adapter (A).
4. Feed the end of the material hose through Guide and
Roller Assembly (29) and the opening in Sheave
Assembly (19).
• Attach the hose to the Swivel Assembly.
5. Loosely attach the material hose to the Sheave Assembly
with U-Bolts (18). *
IMPORTANT: Final U-Bolt adjustment must
occur after the hose has been pressurized.
6. Rotate the Sheave Assembly to wrap the hose onto the
reel.
• The clicking sound is Power Spring (41) bypassing the
cam on the Spring Arbor.
7. Install the control valve as required.
• Use a thread sealant.
8. Pull the hose fully from the reel and pressurize the
system.
9. Tighten the U-Bolts.
10. Retract the hose onto the reel.
11. Install and secure the hose stop to the desired position.
Setting Spring Tension
CAUTION
Do not overwind the Power Spring.Too much tension
reduces the life of the Spring.
To adjust tension on the Power Spring:
12. Add / remove one coil of hose to / from the Sheave
Assembly.
IMPORTANT: When the hose is fully extended
from the reel, the Power Spring should be a min-
imum of 1/2 turn from a fully wound condition.
13. Repeat step 12 until the proper tension is achieved.
* Which slots in the Sheave Assembly the U-Bolts are
installed depends on the mounting position of the reel. Refer
to section entitled Mount Positions for details.
6. Install Machine Screw (37) through the flanged end
of Latch Bushing (36).
7. Install the Machine Screw and Latch Bushing
assembly through Latch Spring (35) and into the
Base Assembly.
• Make sure to attach the Latch Spring to the Latch
Pawl Assembly.
NOTE: Earlier models contain Latch
Spring (34). The Latch Bushing and
Machine Screw are not applicable.
8. Install Nut (27) that secures the Machine Screw to
the Base Assembly.
• Tighten the Nut securely.
9. Install the BaseAssembly onto the Main Shaft of the
Spring Case and Ratchet Assembly.
• Make sure the Setscrew hole aligns with the flat of
the Main Shaft (aligned with mark).
10. Install Setscrew (31) that secures the BaseAssembly
to the Spring Case and Ratchet Assembly.
• Tighten the Setscrew securely.
NOTE: Position the Guide and Roller
Assembly to correspond with the mount
position of the reel. Refer to section enti-
tled Mount Positions for details.
11. Install Guide and Roller Assembly (29) onto the
studs of the Base Assembly.
12. Install Locknuts (30) that secure the Guide and
Roller Assembly to the Base Assembly.
• Tighten the Locknuts securely in a crisscross
pattern.
Bench Test
While facing the Spring Case and RatchetAssembly,
turn the reel in a counterclockwise direction and allow
the ratchet to engage the Latch Pawl Assembly.
If the reel does not tension or engage properly, check
that:
• Power Spring (41) is installed in the proper
direction.
• Spring Arbor (21) is oriented properly with the
Power Spring.
• Latch Spring (35) is connected to the Latch Pawl
Assembly.

SER 7234-B Heavy-Duty Hose Reels
Revision (7-97) 10 Alemite Corporation
Guide and Roller
Assembly
Slots
Guide and Roller Assembly
with Base
Sheave
Assembly
Perpendicular
Alignment
Base
Guide and Roller Assembly
with Base
Slots
Parallel
Alignment
Base
Guide and Roller
Assembly
Parallel Perpendicular
Mount Positions
The reel can mount to either the floor, wall, or ceiling.
The selected mount position influences the position of
the Guide and Roller Assembly as it relates to the Base.
For example, when the reel mounts to the ceiling, the
Guide and Roller Assembly will always be parallel with
the Base. See Figure 5.
When a parallel alignment is dictated, the chosen slots
in the Sheave Assembly must correspond to this
configuration.
The Sheave Assembly contains four sets of slots.
Locate each U-Bolt in the appropriate slot dictated by the
alignment. See Figure 5.
Figure 5 U-Bolt Location on Sheave Assembly for Parallel and Perpendicular Base Alignment
Caution
Failure to follow the recommended slot selection
for the chosen alignment can result in reel lockup.
When the material hose is fully extended from the
Sheave Assembly and the proper slots are chosen, the
latching mechanism will not engage the ratchet. This
prevents reel lockup.
Ceiling Mount
IMPORTANT: It is mandatory that these
reels be ceiling mounted no higher than 16'
(4.9 m) from the floor. Should the existing
ceiling height be greater, mount the reel to a
suspension bracket. See Figure 6.

Heavy-Duty Hose Reels SER 7234-B
Alemite Corporation 11 Revision (7-97)
9 " (23 cm) Minimum
15 " (38 cm) Recommended
Welded Angle Iron
to Form Base
(Locally Fabricated)
Suspension Angle Iron
for Attachment to Joist
7/16 " -14 x 1 " Bolt
Figure 6 Suspension Bracket for Ceilings Greater than 16 Feet (4.9 meters) - Typical

SER 7234-B Heavy-Duty Hose Reels
Revision (7-97) 12 Alemite Corporation
Reel Operation
Reel Lockup
Caution
Do not remove the hose completely from the reel
to rapidly. Too much force can cause the reel to
over-run, latch, and lockup. If this occurs, the reel
cannot be extended to release the latch mecha-
nism.
Should the reel lockup, it will be necessary to have an
assistant maintain tension on the hose while the latching
mechanism is manually released.
WARNING
The reel is under maximum Spring tension.
Personal injury can occur.
1. Grip the Sheave Assembly securely with gloved hands.
2. Turn the SheaveAssembly in the direction just enough
that allows Latch Pawl Assembly (32) to be free of
tension from the Ratchet.
• This direction further increases tension on the Power
Spring.
3. While maintaining the position of the Sheave assembly
with one hand, move the Latch Pawl Assembly away
from the Ratchet Assembly.
• Use a screwdriver or other suitable tool.
4. Instruct the assistant to allow the hose to retract slowly
onto the Sheave Assembly.
Troubleshooting Chart
Indications Possible Problems Solution
Reel does not latch Spring (35) broken or not attached to Latch Pawl (32) Replace or secure Spring (35)
Reel does not retract 1. Spring Arbor (21 /22) broken* or installed incorrectly
2. Power Spring (41) broken* or installed incorrectly
3. Reel installed over 16 ' (4.9 m)
4. Hose length greater than 50 ' (15.2 m)
1 and 2. Replace or orientate
components properly.
3. Install reel at 16 ' (4.9 m)
4. Install a hose not to exceed 50 '
(15.2 m) in length
Reel retracts partially Improper Power Spring (41) tension Set tension properly
Reel does not unlatch
after maximum length
of hose is removed
1. Power Spring (41) wound solid
2. Hose removed from the reel too quickly 1. Decrease Spring (41) pre-wind 2. Remove hose slowly when close
to being fully extended
Material leakage at the
Swivel Assembly 1. Connection not sufficiently tight
2. Worn or damaged Swivel Assembly
1. Tighten material hose to Swivel
and Swivel to Main Shaft (24)
2. Repair or replace Swivel
Material leakage at
Union Adapter (A)1. Connection not sufficiently tight
2. Worn or damaged Union Adapter (A)
1. Tighten material hose toAdapter
and Adapter to Main Shaft (24)
2. Replace Adapter
* The possible causes for broken components are listed in italics
Changes Since Last Printing
Added Medium-Pressure Swivel Assembly 393539-99
