Alfalaval Toftejorg SaniMidget SB User manual

Covering: Standard machines
3-A standard version (clip-on & weld-on). UltraPure standard version (clip-on & weld-on)
Machines delivered with ATEX/IECEx Certification in accordance with Directive 2014/34/EU
Q-doc - Equipment Doc (3.1 Inspection Certificate - EN 10204)
Q-doc - Qualification Doc (Qualification Documentation, FAT/SAT)
First published: 2009-09
ESE01844-EN10 2019-11
Original manual
Instruction Manual
Alfa Laval Toftejorg™ SaniMidget SB, SaniMagnum SB & SaniMega SB

Table of contents
The information herein is correct at the time of issue but may be subject to change without prior notice
1. EU Declaration of Conformity ....................................................................... 4
2. Safety .................................................................................................... 5
2.1. Important information ............................................................................. 5
2.2. Warning signs ..................................................................................... 5
3. Introduction ............................................................................................ 6
3.1. Introduction ........................................................................................ 6
3.2. Intended use ...................................................................................... 7
3.3. Patents and trademarks ......................................................................... 7
3.4. Marking ............................................................................................ 8
3.5. ATEX/IECEx marking ............................................................................. 9
3.6. ATEX/IECEx temperature class and code ...................................................... 10
3.7. Quality system, 3-A Sanitary Standards and European Hygienic Design Group (EHEDG) 11
4. Installation .............................................................................................. 12
4.1. General description ............................................................................... 12
4.2. Functioning ........................................................................................ 13
4.3. General safety and installation instructions ..................................................... 14
4.4. Specific conditions for safe use in accordance with ATEX/IECEx certification .............. 16
4.5. Installation ......................................................................................... 19
4.6. Assembly .......................................................................................... 20
5. Operation ............................................................................................... 23
5.1. Normal operation ................................................................................. 23
5.2. Safety precautions ................................................................................ 24
6. Maintenance ........................................................................................... 25
6.1. Service and repair of ATEX/IECEx certified machines ......................................... 25
6.2. Service and repair of machines ordered with Alfa Laval Q-doc .............................. 25
6.3. Recommended service intervals ................................................................ 26
6.4. Dissassembly ...................................................................................... 27
6.5. Reassembly ....................................................................................... 27
7. Technical data ......................................................................................... 28
7.1. Alfa Laval Toftejorg SaniMidget SB .............................................................. 28
7.2. Alfa Laval Toftejorg SaniMagnum SB ........................................................... 30
7.3. Alfa Laval Toftejorg SaniMega SB and SaniMega SB HF ..................................... 32
8. Parts lists and drawing ............................................................................... 34
8.1. Part lists for Alfa Laval Toftejorg SaniMxxxx SB ................................................ 34
8.2. Part lists for Alfa Laval Toftejorg SaniMidget SB UltraPure ................................... 35
9. Product programme .................................................................................. 36
9.1. Standard configurations .......................................................................... 36
9.2. Available add-ons ................................................................................. 37
10. General information ................................................................................... 38
10.1.Service and repair ................................................................................ 38
10.2.How to contact Alfa Laval Kolding A/S ......................................................... 38
3

1 EU Declaration of Conformity
The Designated Company
Alfa Laval Kolding A/S
Company Name
Albuen 31, DK-6000 Kolding, Denmark
Address
[phone]
Phone No.
hereby declare that
Tank Cleaning Machine Alfa Laval
Designation
Toftejorg SaniMidget SB, SaniMagnum SB & SaniMega SB
Type
From serial number 2019-0001 to 2030-99999
is in conformity with Machinery Directive 2006/42/EC and the following harmonized standard is used:
DS/EN ISO 12100:2011 Safety of Machinery - Risk Assessment
is in conformity with (Ex / ATEX) Directive 2014/34/EU and the following harmonized standards are used:
EN ISO 80079-36:2016, EN ISO 80079-37:2016, DS/EN ISO/IEC 80079-34:2011, Annex A, paragraph A.5.3 Rotating machines
EC Type Examination Certificate no. Baseefa10ATEX0187X and IECEx BAS 19.0107X
Marking:
The QAN (Quality Assurance Notification) is carried out by SGS Fimko Oy, Särkiniementie 3, Helsinki 00211, Finland. Notified Body No. 0598.
EU Type Examination Certification is carried out by SGS Fimko Oy, Särkiniementie 3, Helsinki 00211, Finland. Notified Body no. 0598.
IECEx Certificate of Conformity is carried out by Baseefa Ltd., Rockhead Business Park, Staden Lane, Buxton, Derbyshire SK17 9RZ, United
Kingdom. IECEx Accepted Certification Body (ExCB).
The person authorised to compile the technical file is the signer of this document.
Global Product Quality Manager
Pumps, Valves, Fittings and Tank Equipment Lars Kruse Andersen
Title Name Signature
Kolding 2019-09-01
Place Date (YYYY-MM-DD)
This Declaration of Conformity replaces Declaration of Conformity dated 2016-01-22
4

2 Safety
Unsafe practices and other important information are emphasized in this manual.
Warnings are emphasized by means of special signs.
Always read the manual before using the tank cleaning machine!
2.1 Important information
WARNING
Indicates that special procedures must be followed to avoid serious personal injury.
CAUTION
Indicates that special procedures must be followed to avoid damage to the cover.
NOTE
Indicates important information to simplify or clarify procedures.
2.2 Warning signs
General warning:
ATEX/IECEx warning:
5

3Introduction
SaniMidget/SaniMagnum/SaniMega SB
3.1 Introduction
This manual has been prepared as a guide for installing, operating and maintaining your Alfa Laval Toftejorg Rotary Spray Head
tank cleaning machine. Should you require further assistance, our Technical Sales Support department and worldwide net of
sales offices are pleased to help you. Please quote the type, article and serial numbers with all of your enquiries; this helps
us to help you. The marking is placed on the body of the tank cleaning machine.
This manual covers the Alfa Laval Alfa Laval Toftejorg SaniMxxxx SB (Slide Bearing) series that consists of four main product
series; the Alfa Laval Toftejorg SaniMidget SB, the Alfa Laval Toftejorg SaniMidget SB UltraPure, the Alfa Laval Toftejorg
SaniMagnum SB and the Alfa Laval Toftejorg SaniMega SB. All versions are similar in design. Differences are in material
selection for the rotor and dimensions.
The Alfa Laval Toftejorg SaniMidget SB UltraPure is equipped with a rotor made from USP Class VI certified material and the Alfa
Laval Toftejorg SaniMxxxx SB is equipped with a rotor made from material that meets the 3-A Sanitary Standard 20-25. The
USP Class VI polymer used has not been part of the 3-A Third Party Verification (TPV). Consequently the Alfa Laval Toftejorg
SaniMidget SB UltraPure has not been verified to meet 3-A Sanitary Standards.
Important
information:
Before installing the machine and setting it into operation, carefully read the General safety and
installation instructions (page 14) and the specific conditions for safe use in accordance with ATEX/IECEx
directive 2014/34/EU (page 16) and take all necessary precautions according to your application and
local regulations.
NOTE
The illustrations and specifications contained in this manual were effective at the date of printing. However, as continuous
improvements are our policy, we reserve the right to alter or modify any unit specification on any product without prior notice or
any obligation.
The English version of the instruction manual is the original manual. We make reservations in regard to possible mistranslations in
language versions of the instruction manual. In case of doubt, the English version of the instruction manual applies.
6

3 Introduction
SaniMidget/SaniMagnum/SaniMega SB
3.2 Intended use
It is to be verified by the end-user:
- that the tank cleaning machine is in conformity with respect to tank, vessel or container size in which it will be used.
- that the construction materials (both metallic and non-metallic) are compatibility with product, flushing media, cleaning
media, temperatures and pressure under the intended use.
The tank cleaning machine is intended for use in closed tank, vessel or container. If used in open environment see 4.3 General
safety and installation instructions (page 14).
Steam cleaning
If stream cleaning is done through the machine, the steam pressure must not cause the machine to rotate.
See paragraph 4.4 Specific conditions for safe use in accordance with ATEX/IECEx certification (page 16).
See General Installation Instructions on page 14 of this manual for information on recommended installation position.
3.3 Patents and trademarks
This Instruction Manual is published by Alfa Laval Kolding A/S without any warranty. Improvements and changes to this
Instruction Manual may at any time be made by Alfa Laval Kolding A/S without prior notice. Such changes will, however,
be incorporated in new editions of this Instruction Manual.
Alfa Laval, Kolding A/S. All rights reserved.
TheAlfaLavallogotypeisatrademarkoraregisteredtrademark of Alfa Laval Corporate AB. "Toftejorg" is a trademark or
registered trademark of Alfa Laval Kolding A/S. The Alfa Laval Toftejorg™ SaniMxxx SB series product has patent in the US
(US 8.137.481). Other products or company names mentioned herein may be the trademarks of their respective owners. Any
rights not expressly granted herein are reserved.
7

3Introduction
SaniMidget/SaniMagnum/SaniMega SB
3.4 Marking
Alfa Laval tank cleaning machines are all marked to allow recognition of machine type, machine name, Serial number and
manufacturing address. The marking is placed on the body of the tank cleaning machine.
Serial number explanation
Machines supplied with or without standard documentation:
yyyy-xxxxx: serial number
yyyy: year
xxxxx: 5 digit sequential number
8

3 Introduction
SaniMidget/SaniMagnum/SaniMega SB
3.5 ATEX/IECEx marking
The Alfa Laval Toftejorg SaniMidget SB, SaniMagnum SB and SaniMega SB are certified as category I components. The ATEX
certification is carried out by the Notified Body SGS Fimko Oy, who has issued the certificate no. Baseefa10ATEX0187X.
The IECEx certification is carried out by the Certification Body SGS Baseefa Ltd., who has issued the certificate no. IECEx BAS
19.0107X.
Note
Explosion protection type is constructional safety “c”.
The marking on the ATEX/IECEx certified Alfa Laval Toftejorg SaniMidget SB, SaniMagnum SB and SaniMega SB is as follows
(for information on marking position see section 3.1 Introduction):
Serial number explanation
Machines supplied with or without standard
documentation:
yyyy-xxxxx: serial number
yyyy: year
xxxxx: 5 digit sequential number
”SaniMxxx SB” = SaniMidget SB, SaniMidget SB UltraPure,
SaniMagnum SB or SaniMega SB
Marking for machines supplied with Q-Doc + FAT-SAT documentation
NOTE
Only available for Alfa Laval Toftejorg SaniMidget SB UltraPure.
Serial number explanation
Machines supplied with Q-Doc + FAT-SAT
documentation
yyyy-F/S-xxx: serial number
yyyy: year
xxx: 3 digit sequential number
9

3Introduction
SaniMidget/SaniMagnum/SaniMega SB
3.6 ATEX/IECEx temperature class and code
The maximum surface temperature depends mainly on operating conditions which are the temperature of the cleaning fluid and
the ambient temperature.
Group II EPL Ga
The gas temperature class is corrected with a safety margin of 80% due to a requirement for Group ll EPL Ga equipment.
The gas temperature class depends on the cleaning fluid temperature or the ambient temperature, whichever of the two is
the highest.
Table for determining temperature class (gas atmospheres)
Gas
Temperature class
Cleaning fluid temperature,
Tp(°C)
Ambient temperature,
Tamb (°C)
85°C (T6) ≤+68°C ≤+68°C
100°C (T5) ≤+80°C ≤+80°C
135°C (T4) ≤+108°C ≤+108°C
175°C ≤+140°C ≤+140°C
Group III EPL Da
The dust temperature class depends on the cleaning fluid temperature or the ambient temperature, whichever of the two is
the highest.
No dust layer is considered.
Table for determining temperature class (dust atmospheres)
Dust
Temperature code
Cleaning fluid temperature,
Tp(°C)
Ambient temperature,
Tamb (°C)
T85°C ≤+85°C ≤+85°C
T100°C ≤+100°C ≤+100°C
T135°C ≤+135°C ≤+135°C
T140°C ≤+140°C ≤+140°C
Example of gas class determination
Cleaning fluid temperature is 67°C and ambient temperature is 75°C.
Gas class = T5
ATEX/IECEx marking on the equipment:
10

3 Introduction
SaniMidget/SaniMagnum/SaniMega SB
3.7 Quality system, 3-A Sanitary Standards and European Hygienic Design Group (EHEDG)
The Alfa Laval Toftejorg SaniMxxxx SB and Alfa Laval Toftejorg SaniMidget SB UltraPure are designed to meet 3-A Sanitary
Standards as well as the guidelines of the European Hygienic Design Group (EHEDG) and thus comply with requirements to
design, materials, finish and documentation.
Third Party Verification (TPV) shows that the Alfa Laval Toftejorg SaniMxxxx SB meets the requirements of the 3-A Sanitary
Standard 78-## and EHEDG certificate of cleanability according to EHEDG doc. 2 shows the machines self cleanability features.
All machines are produced according to Alfa Laval Kolding’s ISO 9001 international Standard certified quality system.
Copy of certificates can be downloaded from:
EHEDG: https://www.ehedg.org/testing-certification/certified-equipment/
3-A: http://www.3-a.org/3-A-Symbol/Search-Database-of-Current-Certificates
11

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
4.1 General description
The Alfa Laval Toftejorg SaniMxxxx SB series are tank cleaning machines intended for industrial use in closed tanks, vessels
and containers under typical CIP procedures. They have a broad range of application areas within pharmaceutical, food,
dairy and chemical industries.
The Alfa Laval Toftejorg SaniMxxxx SB is a sanitary cleaning device of the rotating fan spray type for permanent installation
that provides either a 270° upward cleaning pattern or a 360° cleaning pattern. The machine is designed to be completely
self-cleaning as proven by the EHEDG test method. If Installed according to the description on page 14, the Alfa Laval Toftejorg
SaniMxxxx SB is completely self-draining in the shown position and completely inspectable. All product contact surfaces are
AISI 316L stainless steel or polymer material that conforms to FDA21CFR§177 and EU 10/2011. For the Alfa Laval Toftejorg
SaniMxxxx SB plastic material that meets the requirements of 3-A Sanitary Standard 20-## is used. For the Alfa Laval Toftejorg
SaniMidget SB/UltraPure a USP Class VI plastic material is used.
The unique design is totally free of weldings, threads, screws and press-fits to facilitate self-cleanability. The cleaning device
is lubricated by the cleaning media. No oil, grease or other lubricants are used.
The Alfa Laval Toftejorg SaniMxxxx SB is designed for use in pharmaceutical, biotechnological, food and dairy processing
applications. It may be used in reactors, mixing/processing tanks, spray dryers and other process equipment with a volume
from 7.5-220 m³ (2-60,000 US gallons)*. For larger volumes, multiple Alfa Laval Toftejorg SaniMxxxx SB’s may be applied.
* to comply with EU 10/2011 the minimum batch size should be considered. Declaration of EU 10/2011 conformance can be
supplied on request.
Application assistance and recommendations for optimal position is available.
For use in explosive hazard zones the ATEX/IECEx version can be used, provided it is installed according to safety instructions
in local regulations.
12

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
4.2 Functioning
The flow of cleaning media comes through the down-pipe, flushes the connector and exists through the bearing surfaces, slots
and leakage passages. This causes the head of the Alfa Laval Toftejorg SaniMxxxx SB to rotate, with fans of water laid out in a
swirling pattern on the entire perimeter exposed to the spray pattern. This generates a vibrating impact in the impact pattern
and a dynamic cascading flow that covers all internal surfaces of the tank, vessel or reactor.
The Alfa Laval Toftejorg SaniMxxxx SB is (as the rest of the UltraPure and Sani portfolio) designed according to GMP – compliant
materials, self-cleaning and drainable. The self-cleaning feature of the device is due to the unique design that includes cleaning
of the downpipe. The device is designed with no hindrance to gravity draining. The patented easy assembly and disassembly of
the device allows for only one clip to be used and without any press fits. Upon removing the clip this ensures that no parts can
fall into the tank (the Alfa Laval Toftejorg SaniMxxxx SB must be held in one hand and the clip in the other hand).
Spray pattern
360°270°up
13

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
4.3 General safety and installation instructions
It is recommended to install a filter with mesh size 250 µm (0.01”) in the supply line to avoid particles, scale etc. from clogging
the inside of the cleaner. However, particles up to 0.8 mm can pass the cleaning slots in the rotor.
Before installation, all supply lines and valves must be thoroughly flushed to remove remains from welding, grinding dust,
scale and other foreign matter. During handling and installation handle the machine with care in order not to damage the
fine surface of the machine.
Randomly selected Alfa Laval Toftejorg SaniMxxxx SB machines are tested at the factory before shipping, in accordance
with “Test Requirements for SaniMxxxx SB”.
Warning: Precautions shall be made to prevent starting the cleaning operation, while personnel are inside the tank or
otherwise can be hit by water jets from the cleaner head.
NOTE
The machine shall be installed in accordance with national regulations for safety and other relevant regulations and standards. In
EU-countries the complete system must fulfil the EU-machine Directive and depending of application, the EU-Pressure Equipment
Directive, the EU-ATEX/IECEx Directive and other relevant Directives and shall be CE-marked before it is set into operation.
1Connector
2 Rotor
3Stator
4Clip
4114-0016
14

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
Note: Only valid for Alfa Laval Toftejorg SaniMidget SB:
Please note that when doing installation or re-assembly, the rotor must be placed correctly according to below drawing in
order to ensure normal operation.
The arrow on the rotor shows the flow direction.
Correct orientation of rotor
Note: Flow direction
4114-0017
Important
information:
Recommended installation position:
The Rotary Spray Head tank cleaning machine should be installed in vertical position (upright or upside
down). If the machine is installed in any angle to vertical, the life time may vary. If installing at an angle to
vertical, ensure that the clip cannot fall out by gravity. To maintain drainability,thedeviceshouldnotbe
tilted more than 25° to vertical.
For information on use in potential explosive atmospheres see paragraph 4.4 Specific conditions for safe use in accordance with
ATEX/IECEx certification page 16.
15

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
4.4 Specific conditions for safe use in accordance with ATEX/IECEx certification
Directive 2014/34/EU
NOTE
Explosion protection type is constructional safety “c”.
Warning: Operated in a hazardous area
The unit my be operated in a hazardous area only when completely filled with cleaning fluid/steam.
If a medium other than the cleaning fluid/steam is passed through the equipment, the flow must not be
high enough to cause the equipment to operate.
Warning: Operating guidance
The unit shall be operated in line with guidance provided by IEC/TS 60079-32-1 for tank cleaning.
Warning: Temperature class and ambient temperature range
The maximum surface temperature depends mainly on operating conditions which are the temperature
of the cleaning fluid and ambient temperature.
The temperature class and ambient temperature range are shown in paragraph 3.6 ATEX/IECEx
temperature class and code, page 10.
Warning: Max. permitted temperature
When working:
The maximum permitted cleaning fluid temperature and ambient temperature is 95°C.
When not working:
The maximum permitted ambient temperature is 140°C.
Warning: Draining using compressed air
Draining using compressed air must not be done in ex classified zone.
Draining using compressed air is possible in non ex classified zones (see page 14).
Warning: Earthing
All metal and other conductive or dissipative material should be connected to earth with the exception of
very small items.
For further information see IEC/TS 60079-32-1:2013 Explosive atmospheres – Part 32-1: Electrostatic
hazards, guidance. With focus on clause 6.2.3, 7.2.1, 7.3, 7.9.2, 13.
Warning: Earthedwheninuse
The unit must be effectively earthed at all times when in use.
16

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
4.4 Specific conditions for safe use in accordance with ATEX/IECEx certification
Warning: Max. permitted steaming temperature
The maximum permitted steam temperature through the machine and ambient temperature is 140°C.
Warning: Steaming tanks larger than 100 m³
Tanks with capacities larger than 100 m³ that could contain a flammable atmosphere should not be
steam cleaned, as steam cleaning tanks produces an electrostatically charged mist. Tanks smaller
than 100 m³ may be steam cleaned.
For further information see IEC/TS 60079-32-1:2013 Explosive atmospheres – Part 32-1: Electrostatic
hazards, guidance. With focus on clause 7.10 and 8.5.
Tank size information
NOTE: The tank cleaning machine has been certified by accredited notified body and can operate in tanks having an enclosed
volume up to 100 m³ as long as all ATEX/IECEx warnings in the instruction manual are complied with.
General guidelines for tanks larger than 100 m3:
Tanks larger than 100 m³ must not be steam cleaned – See guide IEC/TS 60079-32-1:2013 clause 7.10.5 and 8.5
To use the unit in tanks larger than 100m³ is possible under certain conditions.
It is necessary to know the current factors such as tank size, cleaning solvent and product.
Additives can be used in the cleaning solvent, or, for example, the tank can be filled with nitrogen. The basic guidelines are
described in the guide IEC/TS 60079-32-1:2013.
It must be ensured that the equipollently bonding of all conductive metal objects is in accordance with national regulations
for use.
The cleaning fluid conductivity must correspond to the products in the group “High conductivity”, cf. IEC/TS 60079-32-1:2013
clause 7.1 and 7.2.
High conductivity > 10 000 pS/m
Medium conductivity between 25 × εr pS/m and 10 000 pS/m
Low conductivity <25×εrpS/m
For liquids with a dielectric constant of around 2, (e.g. hydrocarbons), these classifications reduce to:
High conductivity > 10 000 pS/m
Medium conductivity between 50 pS/m and 10 000 pS/m
Low conductivity <50pS/m
Following a guidance document such as IEC/TS 60079-32-1:2013 to establish safe use of machinery and process is the users
own responsibility and is not covered by the ATEX/IECEx certification for this unit except for tanks up to 100 m3.Forfurther
information see IEC/TS 60079-32-1:2013 Explosive atmospheres – Part 32-1: Electrostatic hazards, guidance with focus on
clause 7.1.3, 7.1.4, 7.2.1, 7.2.4.
17

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
4.4 Specific conditions for safe use in accordance with ATEX/IECEx certification
Warning: Process generated electrostatic
The user must address the electrostatic hazards generated from the process of the equipment in
accordance with guidance document IEC/TS 60079-32-1:2013.
Warning: Electrostatically charged liquid
Liquids can become electrostatically charged when they move relative to contacting solids or the
spraying of liquids can also create a highly charged mist or spray. The liquid must be made electrically
conductive by additives or otherwise.
For further information see IEC/TS 60079-32-1:2013 Explosive atmospheres – Part 32-1: Electrostatic
hazards, guidance. With focus on clause 7.1.3, 7.1.4, 7.2.1, 7.2.4.
Warning: Appropriate cleaning fluid
The cleaning fluid should be appropriate for the application (e.g. so no chemical reaction can take place
between the cleaning fluid and the residue of process fluid/powder/compound which can generate
heat or a hybrid mixture).
Chemical reactions in Zone 20 - Hybrid mixtures:
End-user must ensure that the cleaning fluid used does not create a hybrid mixture according to IEC
60079-10-1:2015 Annex I.1 in connection with powder / dust residues in the tank in zone 20.
This should ensure that the atmosphere does not change to a classification that lies outside the
machine’s certified scope. When the machine is used for cleaning tanks containing potentially flammable
dust atmospheres, and a potentially flammable fluid is used as the cleaning fluid then an assessment of
the hybrid mixture shall be undertaken by the user, prior to operation.
For further information see IEC 60079-10-1:2015 Explosive atmospheres – Part 10-1: Classification of
areas – Explosive gas atmospheres. With focus on clause 3.6.6 and Annex I – Hybrid mixtures.
Warning: Fluid pressure
SaniMidget SB and SaniMagnum SB
The maximum permitted cleaning fluid pressure is 3 bar.
SaniMega SB and SaniMega SB HF
The maximum permitted cleaning fluid pressure is 4 bar.
In addition to the above mentioned precautions relating to the ATEX/IECEx guidelines Directive 2014/34/EU, the Safety
Precautions on page 16 must be observed.
18

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
4.5 Installation
The Alfa Laval Toftejorg SaniMxxxx SB clip-on versions are installed on:
1” BPE US down pipe (16B102-xx or 16B132-xx)
1½” BPE US down pipe (16B152-xx or 16B182-xx or 17Bxxx-xx)
2” BPE US down pipe (18Bxxx-xx)
The Alfa Laval Toftejorg SaniMxxxx SB weld-on versions are installed on:
1” BPE US down pipe (16B203-xx or 16B233-xx)
1”ISO down pipe (16B202-xx or 16B232-xx)
DIN Range 1 Ø28 down pipe (16B102-xx or 16B132-xx)
1½” BPE US down pipe (17B203-x0 or 17B233-x0)
2” BPE US down pipe (18B203-x0, or 18B233-x0, or 18B263-x0, or 18B293-x0)
Correct down-pipe dimensions are important to ensure volumetric flow rates as provided in this manual. Clip-on hole centre for
1” must be less than 15 mm (0.59”) from the bottom end (recommended 13-15 mm – 0.51”-0.59”) of the down-pipe and for the
1½” and 2” less than 34 mm (1.33”) from the bottom end (recommended 30-34 mm – 1.18”-1.33”). For weld-on versions no
clip hole is needed – the connector (containing the clip hole) is welded on the end of the down pipe.
Important
information:
Alfa Laval Toftejorg SaniMxxxx SB weld-on versions:
To continue to meet the requirements of the 3-A Sanitary Standard 78-##, the weld-on version shall be
welded onto the end of a straight down pipe. This straight down pipe shall be connected to the supply
system in a dismountable manner. This shall allow for easy disassembly and reassembly (e.g. a sanitary
clamp coupling) to allow visual inspection (through the down pipe) of the inside of the down pipe and the
inside of the connector. Welding must be performed in accordance with 3-A accepted Standard 605-##..
19

4 Installation
SaniMidget/SaniMagnum/SaniMega SB
4.6 Assembly
The Alfa Laval Toftejorg SaniMxxxx SB itself is assembled as follows (for the weld-on version, weld the connector onto the down
pipe as explained above):
1. Insert the cylindrical end of the stator (3) through the Rotor (2). If the logo is upside down then the rotor is wrongly orientated
(see below for correct orientation of logo).
Note: The arrow on the rotor shows the flow direction
4114-0018
2. The cylindrical end of the stator (3) is then inserted into the centreholeoftheConnector(1).Thestatorcanbeinsertedtoits
full extent in one position only. When the stator is fully inserted into the connector, the rotor (2) will be fixed between the
bearing surface of the stator and connector
A
4114-0019
A: Down pipe if weld-on version
20
