Allen-Bradley 1757-FFLD User manual

F OUNDATION Fieldbus
Linking Device
1757-FFLD
User Manual
AB Drives

Important User Information
Solid state equipment has operational characteristics differing from those of
electromechanical equipment. Safety Guidelines for the Application, Installation and
Maintenance of Solid State Controls (Publication SGI-1.1 available from your local
Rockwell Automation sales office or online at
http://www.rockwellautomation.com/literature) describes some important
differences between solid state equipment and hard-wired electromechanical devices.
Because of this difference, and also because of the wide variety of uses for solid state
equipment, all persons responsible for applying this equipment must satisfy
themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or
consequential damages resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes.
Because of the many variables and requirements associated with any particular
installation, Rockwell Automation, Inc. cannot assume responsibility or liability for
actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of
information, circuits, equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written
permission of Rockwell Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety
considerations.
WARNING Identifies information about practices or circumstances that can
cause an explosion in a hazardous environment, which may lead
to personal injury or death, property damage, or economic loss.
IMPORTANT Identifies information that is critical for successful application
and understanding of the product.
ATTENTION Identifies information about practices or circumstances that can
lead to personal injury or death, property damage, or economic
loss. Attentions help you identify a hazard, avoid a hazard, and
recognize the consequence
SHOCK HAZARD Labels may be located on or inside the equipment (for example,
drive or motor) to alert people that dangerous voltage may be
present.
BURN HAZARD Labels may be located on or inside the equipment (for example,
drive or motor) to alert people that surfaces may be dangerous
temperatures.

1Publication 1757-UM010A-EN-E - January 2006
Table of Contents
Preface Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-1
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-1
Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . P-2
Chapter 1
Use RSLogix 5000 Software to
Create a Linking Device
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Example System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Create a Project for the Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Create a Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Conventions for Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Add the Communication Module, Linking Device
and the Logix Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Add the Bridge Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Add the Linking Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Add the Logix Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Configure the Linking Device and Logix Block Properties. . . . . 1-8
Launch RSFieldbus Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Configure the Linking Device and Your Field Devices . . . . . . . . . . 1-12
Chapter 2
Introduction to Function Blocks In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Function Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Function Block Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Function Block Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Parameter Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Parameter Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Function Block Links. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Mode Parameter (MODE_BLK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Elements of MODE_BLK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Mode Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Mode Priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Mode Calculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Chapter 3
1757-FFLD Function Blocks In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Parameter Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
RES - Resource Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Block Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
RESTART Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Non-volatile Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Timeout for Remote Cascade Modes . . . . . . . . . . . . . . . . . . . . . . 3-3
Alert Notification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
FEATURES / FEATURE_SEL Parameters. . . . . . . . . . . . . . . . 3-4
Supported Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
AB Drives

Publication 1757-UM010A-EN-E - January 2006
Table of Contents 2
BLOCK_ERR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Resource Function Block Options . . . . . . . . . . . . . . . . . . . . . . . . 3-8
LGX - Logix Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Block Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Supported Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Block Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Chapter 4
About the Linking Device’s Web
Pages
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Typical Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Web Page Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Security Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Use of the Web Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Navigate the Web Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Manage the Administrator Account . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Set the User Name and Password. . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Change the User Name and Password . . . . . . . . . . . . . . . . . . . . . 4-7
Reset the User Name and Password. . . . . . . . . . . . . . . . . . . . . . . 4-8
Logout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Chapter 5
Diagnostic Web Pages In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
H1 Live List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
VCR Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
VCR Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
HSE and H1 VCR Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Ethernet Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Ethernet Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Ethernet Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Diagnostic Log Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Chapter 6
Advanced Diagnostics and Hidden
Web Pages
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Advanced Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
H1 Captures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
HSE Captures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Hidden Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Date and Time Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Reset the Linking Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6

Publication 1757-UM010A-EN-E - January 2006
Table of Contents 3
Appendix A
Troubleshoot the Linking Device In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
1757-FFLD LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Reset the Linking Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Reset Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Reset to Factory Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
Appendix B
Data Types and Data Structures Data Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Data Structures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
DS-65 - Value & Status (Floating Point Structure) . . . . . . . . . . . B-2
DS-66 - Value & Status (Discrete Structure) . . . . . . . . . . . . . . . . B-2
DS-69 - Mode Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
DS-70 - Access Permissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
DS-72 - Discrete Alarm Structure. . . . . . . . . . . . . . . . . . . . . . . . . B-3
DS-73 - Event Update Structure. . . . . . . . . . . . . . . . . . . . . . . . . . B-3
DS-74 - Alarm Summary Structure. . . . . . . . . . . . . . . . . . . . . . . . B-4
DS-85 - Test Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
Appendix C
Fieldbus Status Codes for RSLogix
5000 Projects
Input Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
Output Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7
Glossary
Index
AB Drives

Publication 1757-UM010A-EN-E - January 2006
Table of Contents 4

1Publication 1757-UM010A-EN-E - January 2006
Preface
Introduction
This publication provides information needed to use the 1757-FFLD,
FOUNDATION Fieldbus Linking Device. The linking device serves as a link
between Fieldbus Foundation’s High Speed Ethernet (HSE) and H1 segments.
It also serves as a link between EtherNet/IP and H1 segments. The linking
device provides connectivity for FOUNDATION Fieldbus devices to Logix
controllers, such as ControlLogix, CompactLogix, and FlexLogix.
This publication defines the Foundation Fieldbus function blocks and
function block parameters that reside in the linking device.
This publication also provides user information about the linking device’s Web
pages. The Web pages provide status and diagnostic information about the
linking device. The information found on these pages assists with configuring
and maintaining a FOUNDATION Fieldbus system.
For information on configuring and programming a linking device in a system
with Logix controllers, see the RSFieldbus Application Guide, publication
RSFBUS-AT001.
Related Documentation
These FOUNDATION Fieldbus Specification documents contain information
that you may find helpful as you read this manual:
These documents are available from the Fieldbus Foundation as part of the H1
Communications and User Layer Technical Specification.
For more information go to
http://www.fieldbus.org/ProductsAndServices/FFProductCatalog/
and look under Final Specifications.
Title Publication Number
1757-FFLD Installation Instructions 1757-IN021
RSFieldbus Installation Guide RSFBUS-IN001
RSFieldbus User Manual RSFBUS-UM001
RSFieldbus Application Guide RSFBUS-AT001
Title Number
System Architecture FF-800
Function Block Application Process, Parts 1-3 FF890, FF891, and FF892
Technical Overview FD-043
Foundation Fieldbus System Engineering Guidelines AG-181
Foundation Fieldbus Application Guide 31.25 kbit/s Wiring and
Installation
AG-140, Revision 1.0
AB Drives

Publication 1757-UM010A-EN-E - January 2006
Preface 2
Conventions Used in This
Manual
We use the following conventions in this manual:
Convention Meaning Example
click Click left mouse button once. (Assumes cursor is positioned on
object or selection.)
Click Browse.
double-click Click left mouse button twice in quick succession. (Assumes
cursor is positioned on object or selection.)
Double-click the H1 icon.
right-click Click right mouse button once. (Assumes cursor is positioned on
object or selection.)
Right-click the Fieldbus Networks icon.
drag and drop Click and hold the left mouse button on an object, move the
cursor to where you want to move the object, and release the
mouse button.
Drag and drop the desired block into the Strategy
window.
select Click to highlight a menu item or list choice. Select H1-1 from the drop-down list.
check/uncheck Click to activate/deactivate a checkbox. Check the Do not show this dialog again
checkbox.
⇒Shows nested menu selections as menu name followed by menu
selection.
Click File ⇒Page Setup ⇒Options.
expand Click the + to the left of a given item /folder to show its
contents.
In the H1-1 window, expand the linking device.
<Enter> Keys to be pressed are shown in angle brackets. Press <Enter>.
>APID Example< Data to be typed at a prompt or in an entry field. Enter >APID Example< for the name.

1Publication 1757-UM010A-EN-E - January 2006
Chapter 1
Use RSLogix 5000 Software to Create a
Linking Device
In This Chapter
Example System
The linking device serves as a link between Fieldbus Foundation’s High Speed
Ethernet (HSE) and H1 segments. The linking device provides connectivity
for FOUNDATION Fieldbus devices to a ControlLogix controller as shown
in this example system:
For See Page
1757-FFLD Example System 1-1
Create a Project for the Controller 1-2
Add the Communication Module,
Linking Device and the Logix
Blocks
1-4
Launch RSFieldbus Software 1-12
Configure the Linking Device and
Your Field Devices
1-12
S T A T U S
W D OG
BA TT
N S 1
M O D E
H1
H1
H1
H1
H1-1
H1-2
H1-3
H1-4
F O U ND A T I O N F i e l dbu s
F O U ND A T I O N F i e l dbu s
L i n k i ng D e v i ce
RSFieldbus
24V dc
Power
Supply
Power
Conditioner
Field Device Field Device
1757-FFLD Linking Device
ControlLogix Controller
with 1756-ENBT
AB Drives

Publication 1757-UM010A-EN-E - January 2006
1-2 Use RSLogix 5000 Software to Create a Linking Device
Create a Project for the
Controller
To configure and program a Logix5000 controller, use RSLogix 5000 software
to create and manage a project for the controller.
Project – The file on your workstation (or server) that
stores the logic, configuration, data, and documentation
for a controller.
•The file for the project has an .ACD extension.
•When you create a project, the project name is
the same as the name of the controller.
•The controller name is independent of the project
name. You can rename either the project name or
the controller name.
Name of the Project
If you rename the project or controller, both names are
shown.
Name of the Controller
Controller organizer – graphical overview of the
project. Use the controller organizer to navigate to the
various components of a project.
To open a folder and show its contents, either:
•Double-click the folder.
•Click the + sign.
To close a folder and hide its contents, either:
•Double-click the folder.
•Click the – sign.
