Quick Start
PowerFlex 70 Adjustable
Frequency AC Drive
When reading this document, look for this symbol “ ” to guide
you through the 5 BASIC STEPS needed to install, start-up and
program the PowerFlex 70. The information provided Does Not
replace the User Manual and is intended for qualified drive service
personnel only. For detailed PowerFlex 70 information including
application considerations and related precautions refer to the following:
For Allen-Bradley Drives Technical Support:
Title Publication Available…
PowerFlex 70 User Manual 20A-UM001… on the CD supplied with the drive or
at www.ab.com/manuals/dr
PowerFlex Reference Manual PFLEX-RM001…
Title Online at…
Allen-Bradley Drives Technical Support www.ab.com/support/abdrives
Step x
Step 1 Read the General Precautions
!
ATTENTION: This drive contains ESD (Electrostatic Discharge)
sensitive parts and assemblies. Static control precautions are required
when installing, testing, servicing or repairing this assembly.
Component damage may result if ESD control procedures are not
followed. If you are not familiar with static control procedures,
reference A-B publication 8000-4.5.2, “Guarding Against Electrostatic
Damage” or any other applicable ESD protection handbook.
!
ATTENTION: An incorrectly applied or installed drive can result in
component damage or a reduction in product life. Wiring or application
errors, such as, undersizing the motor, incorrect or inadequate AC
supply, or excessive ambient temperatures may result in malfunction of
the system.
!
ATTENTION: Only qualified personnel familiar with adjustable
frequency AC drives and associated machinery should plan or
implement the installation, start-up and subsequent maintenance of the
system. Failure to comply may result in personal injury and/or
equipment damage.

English-2 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
!
ATTENTION: To avoid an electric shock hazard, verify that the
voltage on the bus capacitors has discharged before performing any
work on the drive. Measure the DC bus voltage at the +DC terminal of
the Power Terminal Block and the -DC test point (refer to the User
Manual for location). The voltage must be zero.
!
ATTENTION: Configuring an analog input for 0-20mA operation and
driving it from a voltage source could cause component damage. Verify
proper configuration prior to applying input signals.
!
ATTENTION: Hazard of personal injury or equipment damage exists
when using bipolar input sources. Noise and drift in sensitive input
circuits can cause unpredictable changes in motor speed and direction.
Use speed command parameters to help reduce input source sensitivity.
!
ATTENTION: Risk of injury or equipment damage exists. DPI or
SCANport host products must not be directly connected together via
1202 cables. Unpredictable behavior can result if two or more devices
are connected in this manner.
!
ATTENTION: The “adjust freq” portion of the bus regulator function
is extremely useful for preventing nuisance overvoltage faults resulting
from aggressive decelerations, overhauling loads, and eccentric loads. It
forces the output frequency to be greater than commanded frequency
while the drive’s bus voltage is increasing towards levels that would
otherwise cause a fault; however, it can also cause either of the
following two conditions to occur.
1. Fast positive changes in input voltage (more than a 10% increase
within 6 minutes) can cause uncommanded positive speed changes;
however an “OverSpeed Limit” fault will occur if the speed reaches
[Max Speed] + [Overspeed Limit]. If this condition is unacceptable,
action should be taken to 1) limit supply voltages within the
specification of the drive and, 2) limit fast positive input voltage
changes to less than 10%. Without taking such actions, if this operation
is unacceptable, the “adjust freq” portion of the bus regulator function
must be disabled (see parameters 161 and 162).
2. Actual deceleration times can be longer than commanded
deceleration times; however, a “Decel Inhibit” fault is generated if the
drive stops decelerating altogether. If this condition is unacceptable, the
“adjust freq” portion of the bus regulator must be disabled (see
parameters 161 and 162). In addition, installing a properly sized
dynamic brake resistor will provide equal or better performance in most
cases.
Note: These faults are not instantaneous and have shown test results
that take between 2 and 12 seconds to occur.

PowerFlex 70 Adjustable Frequency AC Drive Quick Start English-3
CE Conformity(1)
Conformity with the Low Voltage (LV) Directive and Electromagnetic
Compatibility (EMC) Directive has been demonstrated using
harmonized European Norm (EN) standards published in the Official
Journal of the European Communities. PowerFlex Drives comply with
the EN standards listed below when installed according to the User and
Reference Manuals.
CE Declarations of Conformity are available online at:
http://www.ab.com/certification/ce/docs.
Low Voltage Directive (73/23/EEC)
•EN50178 Electronic equipment for use in power installations.
EMC Directive (89/336/EEC)
•EN61800-3 Adjustable speed electrical power drive systems Part 3:
EMC product standard including specific test methods.
General Notes
•If the adhesive label is removed from the top of the drive, the drive
must be installed in an enclosure with side openings less than 12.5
mm (0.5 in.) and top openings less than 1.0 mm (0.04 in.) to maintain
compliance with the LV Directive.
•The motor cable should be kept as short as possible in order to avoid
electromagnetic emission as well as capacitive currents.
•Use of line filters in ungrounded systems is not recommended.
•PowerFlex drives may cause radio interference if used in a
residential or domestic environment. The installer is required to take
measures to prevent interference, in addition to the essential
requirements for CE compliance listed below, if necessary.
•Conformity of the drive with CE EMC requirements does not
guarantee an entire machine or installation complies with CE EMC
requirements. Many factors can influence total machine/installation
compliance.
•PowerFlex drives can generate conducted low frequency
disturbances (harmonic emissions) on the AC supply system. More
information regarding harmonic emissions can be found in the
PowerFlex Reference Manual.
EMC Instructions
(1) CE Certification testing has not been completed for 600 Volt class drives.

English-4 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
Essential Requirements for CE Compliance
Conditions 1-6 listed below must be satisfied for PowerFlex drives to
meet the requirements of EN61800-3.
1. Standard PowerFlex 70 CE compatible Drive.
2. Review important precautions/attention statements throughout this
manual before installing drive.
3. Grounding as described on page 1-5 of the User Manual.
4. Output power, control (I/O) and signal wiring must be braided,
shielded cable with a coverage of 75% or better, metal conduit or
equivalent attenuation.
5. All shielded cables should terminate with the proper shielded
connector.
6. Conditions in Table A.
Table A PowerFlex 70 EN61800-3 EMC Compatibility
Minimum Mounting Clearances
Specified vertical clearance requirements are intended to be
from drive to drive. Other objects can occupy this space;
however, reduced airflow may cause protection circuits to
fault the drive. In addition, inlet air temperature must not
exceed the product specification.
Maximum Surrounding Air Temperature
Important: Some drives are equipped with an adhesive label on the top of the
chassis. Removing the adhesive label from the drive changes the NEMA enclosure
rating from Type 1 Enclosed to Open Type.
Frame(s)
Drive Description
Second Environment
First Environment
Restricted
Distribution
Restrict Motor
Cable to
40 m (131 ft.)
Internal
Filter
Option
External
Filter
Input
Ferrite (1)
ADrive Only ✔✔
See PowerFlex
Reference Manual
with any Comm Option ✔✔
with Remote I/O ✔✔✔
BDrive Only ✔✔
with any Comm Option ✔✔
with Remote I/O ✔✔ ✔
C,
D,
E
Drive Only ✔
with any Comm Option ✔
with Remote I/O ✔✔
(1) Input cables through a Ferrite Core (Frames A, B and C Fair-Rite #2643102002 or equivalent,
Frames D and E Fair-Rite #2643251002 or equivalent).
Step 2 Mount the Drive – Minimum Requirements
Enclosure Rating Temperature Range
Open Type, IP 20, NEMA Type 1 & Flange Mount 0 - 50°C (32 - 122°F)
IP54, IP 66 & NEMA Type 4X/12 0 - 40°C (32 - 104°F)
76.2 mm
(3.0 in.)
76.2 mm
(3.0 in.)

PowerFlex 70 Adjustable Frequency AC Drive Quick Start English-5
Table B PowerFlex 70 Frames
Figure 1 PowerFlex 70 Frames A-E
Dimensions are in millimeters and (inches).
Dimensions
Output Power Frame Size
kW
ND (HD)
HP
ND (HD)
208-240V AC Input 400-480V AC Input 600V AC Input
Not
Filtered Filtered
IP66
(4X/12)
Not
Filtered Filtered
IP66
(4X/12)
Not
Filtered Filtered
IP66
(4X/12)
0.37 (0.25) 0.5 (0.33) A B B A B B A – B
0.75 (0.55) 1 (0.75) A B B A B B A – B
1.5 (1.1) 2 (1.5) B B B A B B A – B
2.2 (1.5) 3 (2) B B B B B B B – B
4 (3) 5 (3) – C D B B B B – B
5.5 (4) 7.5 (5) – D D – C D C – D
7.5 (5.5) 10 (7.5) – D D – C D C – D
11 (7.5) 15 (10) – D D – D D D – D
15 (11) 20 (15) – E E – D D D – D
18.5 (15) 25 (20) – E E – D D D – D
22 (18.5) 30 (25) – – – – D D D – D
30 (22) 40 (30) – – – – E E – E E
37 (30) 50 (40) – – – – E E – E E
A
E
B
D
F
C
B
AC
D E
IP20/66 (NEMA Type 1/4X/12) Flange Mount
FrameABCDEF
Weight (1)
kg (lbs.)
IP20 / NEMA Type 1
A 122.4 (4.82) 225.7 (8.89) 179.8 (7.08) 94.2 (3.71) 211.6 (8.33) 5.8 (0.23) 2.71 (6.0)
B 171.7 (6.76) 234.6 (9.24) 179.8 (7.08) 122.7 (4.83) 220.2 (8.67) 5.8 (0.23) 3.60 (7.9)
C 185.0 (7.28) 300.0 (11.81) 179.8 (7.08) 137.6 (5.42) 285.6 (11.25) 5.8 (0.23) 6.89 (15.2)
D 219.9 (8.66) 350.0 (13.78) 179.8 (7.08) 169.0 (6.65) 335.6 (13.21) 5.8 (0.23) 9.25 (20.4)
E 280.3 (11.04) 555.8 (21.88) 207.1 (8.15) 200.0 (7.87) 491.0 (19.33) 6.9 (0.27) 18.60 (41.0)
IP66 / NEMA Type 4X/12
B 171.7 (6.76) 239.8 (9.44) 203.3 (8.00) 122.7 (4.83) 220.2 (8.67) 5.8 (0.23) 3.61 (8.0)
D 219.9 (8.66) 350.0 (13.78) 210.7 (8.29) 169.0 (6.65) 335.6 (13.21) 5.8 (0.23) 9.13 (20.1)
E 280.3 (11.04) 555.8 (21.88) 219.8 (8.65) 200.0 (7.87) 491.0 (19.33) 6.9 (0.27) 18.60 (41.0)
Flange Mount
A 156.0 (6.14) 225.8 (8.89) 178.6 (7.03) 123.0 (4.84) 55.6 (2.19) – 2.71 (6.0)
B 205.2 (8.08) 234.6 (9.24) 178.6 (7.03) 123.0 (4.84) 55.6 (2.19) – 3.60 (7.9)
C 219.0 (8.62) 300.0 (11.81) 178.6 (7.03) 123.0 (4.84) 55.6 (2.19) – 6.89 (15.2)
D 248.4 (9.78) 350.0 (13.78) 178.6 (7.03) 123.0 (4.84) 55.6 (2.19) – 9.25 (20.4)
E 280.3 (11.04) 555.8 (21.88) 207.1 (8.15) 117.2 (4.61) 89.9 (3.54) – 18.60 (41.0)
(1) Weights include HIM and Standard I/O.

English-6 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
Step 3 Wire the Drive – Wire Recommendations
Type Wire Type(s) Description
Min. Insulation
Rating
Power
(1)
Standard 600V, 90°C (194°F)
XHHW2/RHW-2
Anixter
B209500-B209507, Belden
29501-29507, or
equivalent
•Four tinned copper
conductors with XLPE
insulation.
•Copper braid/aluminum foil
combination shield and
tinned copper drain wire.
•PVC jacket.
Signal
(1) (2) (3)
Standard
Analog I/O
Belden 8760/9460(or
equiv.)
0.750 mm2(18AWG), twisted
pair, 100% shield with drain.
300V,
75-90 degrees
C (167-194
degrees F)
Belden 8770(or equiv.) 0.750 mm2(18AWG), 3
cond., shielded for remote pot
only.
Digital I/O
(1) (2) (3)
Shielded Multi-conductor shielded
cable such as Belden
8770(or equiv.)
0.750 mm2(18AWG), 3
conductor, shielded.
300V,
60 degrees C
(140 degrees F)
(1) Control and signal wires should be separated from power wires by at least 0.3 meters (1 foot).
(2) If the wires are short and contained within a cabinet which has no sensitive circuits, the use of
shielded wire may not be necessary, but is always recommended.
(3) I/O terminals labeled “(–)” or “Common” are not referenced to earth ground and are designed to
greatly reduce common mode interference. Grounding these terminals can cause signal noise.
Terminal Block Specifications
Name Frame Description
Wire Size Range(1) To rque
Maximum Minimum Maximum Recommended
Power Terminal
Block
A, B &
C
Input power and
motor connections
3.5 mm2
(12 AWG)
0.3 mm2
(22 AWG)
0.66 N-m
(5.5 lb.-in.)
0.6 N-m
(5 lb.-in.)
D Input power and
motor connections
8.4 mm2
(8 AWG)
0.8 mm2
(18 AWG)
1.7 N-m
(15 lb.-in.)
1.4 N-m
(12 lb.-in.)
E Input power and
motor connections
25.0 mm2
(3 AWG)
2.5 mm2
(14 AWG)
2.71 N-m
(24 lb.-in.)
2.71 N-m
(24 lb.-in.)
I/O Terminal
Block
All Signal & control
connections
1.5 mm2
(16 AWG)
0.05 mm2
(30 AWG)
0.55 N-m
(4.9 lb.-in.)
0.5 N-m
(4.4 lb.-in.)
SHLD Terminal All Terminating point
for wiring shields
— — 1.6 N-m
(14 lb.-in.)
1.6 N-m
(14 lb.-in.)
(1) Maximum/minimum sizes that the terminal block will accept - these are not recommendations.
Power & Ground Wiring
PE
L1
R
L2
S
L3
T
T1
U
T2
V
T3
W
PE +DC BRK
Required
Input Fusing
Required Branch
Circuit Disconnect

PowerFlex 70 Adjustable Frequency AC Drive Quick Start English-7
Standard and Enhanced Control I/O Terminal Block
No. Signal
Factory Default
Description
Related Param.
1 Digital In 1 Stop – CF
(CF = Clear
Fault)
11.2 mA @ 24V DC
19.2V minimum on state
3.2V maximum off state
Important: Use only 24V DC, not suitable for 115V
AC circuitry.
Inputs can be wired as sink or source. See page 8.
361 -
366
2 Digital In 2 Start
3 Digital In 3 Auto/Man
4 Digital In 4 Speed Sel 1
5 Digital In 5 Speed Sel 2
6 Digital In 6 Speed Sel 3
7 24V Common – Drive supplied power for Digital In1-6 inputs.
See examples on page 8.
150mA maximum load.
8 Digital In Common –
9 +24V DC –
10 +10V Pot Reference – 2 k ohm minimum load.
11 Digital Out 1 – N.O.(1) NOT Fault Max Resistive Load
250V AC / 30V DC
50 VA / 60 Watts
Minimum DC Load
10 µA, 10 mV DC
Max Inductive Load
250V AC / 30V DC
25 VA / 30 Watts
380 -
387
12 Digital Out 1 Common
13 Digital Out 1 – N.C.(1) Fault
14 Analog In 1 (– Volts) (2)
Voltage –
Reads
value at 14
& 15
Non-isolated, 0 to +10V, 10 bit, 100k ohm input
impedance.(3)
320 -
327
15 Analog In 1 (+ Volts)
16 Analog In 1 (– Current) Non-isolated, 4-20mA, 10 bit, 100 ohm input
impedance.(3)
17 Analog In 1 (+ Current)
18 Analog In 2 (– Volts) (2)
Voltage –
Reads
value at 18
& 19
Isolated, bipolar, differential, 0 to +10V unipolar (10
bit) or ±10V bipolar (10 bit & sign), 100k ohm input
impedance.(4)
19 Analog In 2 (+ Volts)
20 Analog In 2 (– Current) Isolated, 4-20mA, 10 bit & sign, 100 ohm input
impedance.(4)
21 Analog In 2 (+ Current)
22 10V Pot Common
Analog Out (– Volts)
Analog Out (– Current)
(2)
Output
Freq
0 to +10V, 10 bit, 10k ohm (2k ohm minimum) load.
0 to 20mA, 10 bit, 400 ohm maximum load.(5)
Referenced to chassis ground.
Common if internal 10V supply (terminal 10) is
used.
340 -
344
23 Analog Out (+ Volts)
Analog Out (+ Current)
24 Digital Out 2 – N.O.(1) Run See description at No.s 11-13. 380 -
387
25 Digital Out 2 Common
26 Digital Out 2 – N.C.(1) NOT Run
(1) Contacts shown in unpowered state. Any relay programmed as Fault or Alarm will energize (pick
up) when power is applied to drive and deenergize (drop out) when fault or alarm exists. Relays
selected for other functions will energize only when that condition exists and will deenergize when
condition is removed.
(2) These inputs/outputs are dependent on a number of parameters. See “Related Parameters.”
(3) Differential Isolation - External source must be less than 10V with respect to PE.
(4) Differential Isolation - External source must be maintained at less than 160V with respect to PE.
Input provides high common mode immunity.
(5) Analog output current is only available with Enhanced Control drives.

English-8 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
I/O Wiring Examples
Input/Output Connection Example(3)
Related Param.
Potentiometer(1)
10k Ohm Pot.
Recommended
(2k Ohm minimum)
Joystick(1)
±10V Input -
100k ohm input
impedance
[Speed Ref A Sel] = “Analog In 1” 090
to
095
320
to
327
361
to
366
Potentiometer Joystick
Analog Input
Bipolar:
±10V
Unipolar:
0 to +10V, 100k
ohm impedance
4-20 mA, 100 ohm
impedance
[Speed Ref A Sel] = “Analog In 2”
Bipolar(1) Unipolar (Voltage) Unipolar (Current)
Analog/Digital
Output
0 to +10V Output -
Can drive a 2k
Ohm load (25 mA
short circuit current
limit)
Analog Output Digital N.O. / N.C. Output 341
to
344
380
to
387
2 Wire Control(2) -
Non-Reversing
Requires 2-wire
functions only
([Digital In1 Sel]).
Using 3-wire selec-
tions will cause a
type 2 alarm.
24V DC Input(4): [Digital In2 Sel] = “Run” 361
to
366
Internal Supply External Supply
3 Wire Control
Requires 3-wire
functions only
([Digital In1 Sel]).
Using 2-wire selec-
tions will cause a
type 2 alarm.
24V DC Input(4): [Digital In1 Sel] = “Stop – CF”, [Digital In2 Sel] = “Start”
Internal Supply External Supply
(1) Refer to the Attention statement on page 2 for important bipolar wiring information.
(2) Important: Programming inputs for 2 wire control deactivates all HIM Start buttons.
(3) Examples show hardware wiring only. Refer to page 7 for parameters that must be adjusted.
(4) If desired, a User Supplied 24V DC power source can be used. Refer to the “External” example.
14
15
22
10
18
19
22
Com
Power Source
-10V +10V
18
19
–
+
18
19
Common
+
20
21
Common
+
+–
22
23
11
12
13
24
25
26
Power
Source
or
2
7
8
9
Stop-Run
+24V Common
2
8
Stop-Run
1
2
7
8
9
Stop
Start
+24V Common
1
2
8
Stop
Start

PowerFlex 70 Adjustable Frequency AC Drive Quick Start English-9
❏1. Verify input supply voltage.
❏2. Check output wiring.
❏3. Check control wiring.
❏4. Apply AC power and control voltages to the drive.
If any of the six digital inputs are configured to Stop – CF
(CF = Clear Fault) or Enable, verify that signals are present or the
drive will not start. Refer to Troubleshooting – Abbreviated Fault &
Alarm Listing on page 16 for a list of potential digital input conflicts.
If the STS LED is not flashing green at this point, refer to Status
Indicators on page 9.
❏5. Select Start-Up method: SMART Start or Assisted Start-Up.
Step 4 Start-Up Check List
Status Indicators
Name Color State Description
Green Flashing Drive ready, but not running and no faults are present.
Steady Drive running, no faults are present.
Yellow Flashing,
Drive Stopped
An inhibit condition exists, the drive cannot be started.
Check parameter 214 [Start Inhibits].
Flashing,
Drive Running
An intermittent type 1 alarm condition is occurring.
Check parameter 211 [Drive Alarm 1].
Steady,
Drive Running
A continuous type 1 alarm condition exists.
Check parameter 211 [Drive Alarm 1].
Red Flashing A fault has occurred.
Steady A non-resettable fault has occurred.
Refer to the Communication
Adapter User Manual.
Status of DPI port internal communications (if present).
Status of communications module (when installed).
Status of network (if connected).
Status of secondary network (if connected).
STS
PORT
MOD
NET A
NET B

English-10 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
Step 5 Program the Drive – Parameter Files & Groups
Inputs & Outputs
File J
Communication
File H
Utility
File E
Dynamic Control
File D
Speed Command
File C
Motor Control
File B
Monitor
File A
Metering
Drive Data
Motor Data
Torq Attributes
Volts per Hertz
Speed Feedback*
Spd Mode & Limits
Speed References
Discrete Speeds
Speed Trim
Slip Comp
Process PI
Speed Regulator*
Ramp Rates
Load Limits
Stop/Brake Modes
Restart Modes
Power Loss
Direction Config
HIM Ref Config
MOP Config
Drive Memory
Diagnostics
Faults
Alarms
Comm Control
Masks & Owners
Datalinks
Security*
Analog Inputs
Analog Outputs
Digital Inputs
Digital Outputs
*Enhanced Control Only.
Frequently Used Parameters
MOTOR CONTROL (File B)
Motor Data
041 [Motor NP Volts]
Set to the motor nameplate rated volts.
Default:
Min/Max:
Units:
Drive Rating Based
0.0/[Rated Volts]
0.1 VAC
042 [Motor NP FLA]
Set to the motor nameplate rated full load
amps.
Default:
Min/Max:
Units:
Drive Rating Based
0.0/[Rated Amps] ×2
0.1 Amps
047
048
045 [Motor NP Power]
Set to the motor nameplate rated power.
Default:
Min/Max:
Units:
Drive Rating Based
0.00/100.00
0.00/412.48
0.01 kW/HP
See [Mtr NP Pwr Units]
046
046 [Mtr NP Pwr Units]
Selects the motor power units to be used.
Default:
Options: 0
1
Drive Rating Based
“Horsepower”
“kiloWatts”
047 [Motor OL Hertz]
Selects the output frequency below
which the motor operating current is
derated. The motor thermal overload will
generate a fault at lower levels of current.
Default:
Min/Max:
Units:
Motor NP Hz/3
0.0/500.0 Hz
0.1 Hz
042
220
Torq Attributes
053 [Torque Perf Mode]
Sets the method of motor torque
production.
Default:
Options:
0
0
1
2
3
“Sensrls Vect”
“Sensrls Vect”
“SV Economize”
“Custom V/Hz”
“Fan/Pmp V/Hz”
062
063
069
070
[Motor Cntl Sel]
Sets the method of motor control used in
the drive.
Important: “FVC Vector” mode requires
autotuning of the motor, both coupled
and uncoupled to the load.
(1) Enhanced firmware 2.001 & later.
Default:
Options:
0
0
1
2
3
4
“Sensrls Vect”
“Sensrls Vect”
“SV Economize”
“Custom V/Hz”
“Fan/Pmp V/Hz”
“FVC Vector”(1)
32
E C
Standard
E C

PowerFlex 70 Adjustable Frequency AC Drive Quick Start English-11
MOTOR CONTROL (File B)
Torq Attributes
061 [Autotune]
Provides a manual or automatic method
for setting [IR Voltage Drop] and [Flux
Current Ref], which affect sensorless
vector performance. Valid only when
parameter 53 is set to “Sensrls Vect” or
“SV Economize.”
Default:
Options:
3
0
1
2
3
“Calculate”
“Ready”
“Static Tune”
“Rotate Tune”
“Calculate”
053
062
“Ready” (0) = Parameter returns to this setting following a “Static Tune” or “Rotate
Tune.” It also permits manually setting [IR Voltage Drop] and [Flux Current Ref].
“Static Tune” (1) = A temporary command that initiates a non-rotational motor
stator resistance test for the best possible automatic setting of [IR Voltage Drop].
A start command is required following initiation of this setting. The parameter
returns to “Ready” (0) following the test, at which time another start transition is
required to operate the drive in normal mode. Used when motor cannot be
rotated.
“Rotate Tune” (2) = A temporary command that initiates a “Static Tune” followed
by a rotational test for the best possible automatic setting of [Flux Current Ref]. A
start command is required following initiation of this setting. The parameter
returns to “Ready” (0) following the test, at which time another start transition is
required to operate the drive in normal mode. Important: Used when motor is
uncoupled from the load. Results may not be valid if a load is coupled to the motor
during this procedure.
“Calculate” (3) = This setting uses motor nameplate data to automatically set [IR
Voltage Drop] and [Flux Current Ref].
SPEED COMMAND (File C)
Spd Mode & Limits
080 [Speed Mode]
Sets the method of speed regulation.
Default:
Options:
0
0
1
2
“Open Loop”
“Open Loop”
“Slip Comp”
“Process PI”
121
thru
138
[Feedback Select]
Selects the source for motor speed
feedback. Note that all selections are
available when using Process PI.
“Open Loop” (0) - no encoder is present,
and slip compensation is not needed.
“Slip Comp” (1) - tight speed control is
needed, and encoder is not present.
“Encoder” (3) - an encoder is present.
“Simulator” (5) - Simulates a motor for
testing drive operation & interface check.
Default:
Options:
0
0
1
2
3
4
5
“Open Loop”
“Open Loop”
“Slip Comp”
“Reserved”
“Encoder”
“Reserved”
“Simulator”
081 [Minimum Speed]
Sets the low limit for speed reference
after scaling is applied. Refer to
parameter 083 [Overspeed Limit].
Default:
Min/Max:
Units:
0.0 Hz
0.0/[Maximum Speed]
0.1 Hz
092
095
082 [Maximum Speed]
Sets the high limit for speed reference
after scaling is applied. Refer to
parameter 083 [Overspeed Limit].
Default:
Min/Max:
Units:
50.0 or 60.0 Hz
(Dependent on voltage
class)
5.0/400.0 Hz
5.0/500.0 Hz
0.0 Hz
055
083
091
094
202
!
ATTENTION: Rotation of the motor in an undesired direction can
occur during this procedure. To guard against possible injury and/or
equipment damage, it is recommended that the motor be
disconnected from the load before proceeding.
Standard
E C
E C

English-12 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
SPEED COMMAND (File C)
Speed References
090 [Speed Ref A Sel]
Selects the source of the speed
reference to the drive unless [Speed Ref
B Sel] or [Preset Speed 1-7] is selected.
For more information on selecting a
speed reference source, refer to the
PowerFlex 70 User Manual, “Speed
Reference Control”.
(1) See Appendix B of the User Manual
for DPI port locations.
(2) Enhanced Control Drives Only.
Default:
Options:
2
1
2
3-8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23-
29
30
“Analog In 2”
“Analog In 1”
“Analog In 2”
“Reserved”
“MOP Level”
“Reserved”
“Preset Spd1”
“Preset Spd2”
“Preset Spd3”
“Preset Spd4”
“Preset Spd5”
“Preset Spd6”
“Preset Spd7”
“DPI Port 1”(1)
“DPI Port 2”(1)
“DPI Port 3”(1)
“Reserved”
“DPI Port 5”(1)
“Reserved”
“HighRes Ref”(2)
002
091
thru
093
101
thru
107
117
thru
120
192
thru
194
213
272
273
320
361
thru
366
091 [Speed Ref A Hi]
Scales the upper value of the [Speed Ref
A Sel] selection when the source is an
analog input.
Default:
Min/Max:
Units:
[Maximum Speed]
–/+[Maximum Speed]
0.1 Hz
082
092 [Speed Ref A Lo]
Scales the lower value of the [Speed Ref
A Sel] selection when the source is an
analog input.
Default:
Min/Max:
Units:
0.0 Hz
–/+[Maximum Speed]
0.1 Hz
081
Discrete Speeds
101
102
103
104
105
106
107
[Preset Speed 1]
[Preset Speed 2]
[Preset Speed 3]
[Preset Speed 4]
[Preset Speed 5]
[Preset Speed 6]
[Preset Speed 7]
Provides an internal fixed speed
command value. In bipolar mode
direction is commanded by the sign of
the reference.
Default:
Min/Max:
Units:
5.0 Hz
10.0 Hz
20.0 Hz
30.0 Hz
40.0 Hz
50.0 Hz
60.0 Hz
–/+[Maximum Speed]
0.1 Hz
090
093
DYNAMIC CONTROL (File D)
Ramp Rates
140
141
[Accel Time 1]
[Accel Time 2]
Sets the rate of accel for all speed
increases.
Default:
Min/Max:
Units:
10.0 Secs
10.0 Secs
0.1/3600.0 Secs
0.1 Secs
142
143
146
361
thru
366
142
143
[Decel Time 1]
[Decel Time 2]
Sets the rate of decel for all speed
decreases.
Default:
Min/Max:
Units:
10.0 Secs
10.0 Secs
0.1/3600.0 Secs
0.1 Secs
140
141
146
361
thru
366
Max Speed
Accel Time Accel Rate
=
Max Speed
Decel Time Decel Rate
=

PowerFlex 70 Adjustable Frequency AC Drive Quick Start English-13
DYNAMIC CONTROL (File D)
Load Limits
148 [Current Lmt Val]
Defines the current limit value when
[Current Lmt Sel] = “Cur Lim Val.”
Default:
Min/Max:
Units:
[Rated Amps] ×1.5
(Equation approximates
default value.)
Drive Rating Based
0.1 Amps
147
149
151 [PWM Frequency]
Sets the carrier frequency for the PWM
output. Drive derating may occur at
higher carrier frequencies. For derating
information, refer to the PowerFlex
Reference Manual, publication
PFLEX-RM001….
Default:
Min/Max:
Units:
4 kHz
2, 3, 4, 5, 6, 7, 8, 9, 10 kHz
2, 4, 8, 12 kHz
1 kHz
Stop/Brake Modes
155
156
[Stop Mode A]
[Stop Mode B]
Active stop mode. [Stop Mode A] is active
unless [Stop Mode B] is selected by
inputs.
(1) When using options 1 or 2, refer to
the Attention statements at [DC Brake
Level].
Default:
Default:
Options:
1
0
0
1
2
3
“Ramp”
“Coast”
“Coast”
“Ramp”(1)
“Ramp to Hold”(1)
“DC Brake”
155
156
[Stop/Brk Mode A]
[Stop/Brk Mode B]
See description above.
161
162
[Bus Reg Mode A]
[Bus Reg Mode B]
Sets the method and sequence of the DC
bus regulator voltage. Choices are
dynamic brake, frequency adjust or both.
Sequence is determined by programming
or digital input to the terminal block.
Dynamic Brake Setup
If a dynamic brake resistor is connected
to the drive, both these parameters must
be set to either option 2, 3 or 4.
Refer to the Attention statement on page
2 for important information on bus
regulation.
Default:
Options:
1
4
0
1
2
3
4
“Adjust Freq”
“Both-Frq 1st”
“Disabled”
“Adjust Freq”
“Dynamic Brak”
“Both-DB 1st”
“Both-Frq 1st”
160
163
E C
Standard
Standard
!
ATTENTION: If a hazard of injury do to movement of equipment or
material exists, an auxiliary mechanical braking device must be
used.
E C v2
E C v2
!
ATTENTION: The drive does not offer protection for externally
mounted brake resistors. A risk of fire exists if external braking
resistors are not protected. External resistor packages must be
self-protected from over temperature or a protective circuit must be
supplied. See the PowerFlex 70 User Manual for more information.

English-14 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
DYNAMIC CONTROL (File D)
Stop/Brake Modes
163 [DB Resistor Type]
Selects whether the internal or an
external DB resistor will be used.
If a dynamic brake resistor is connected
to the drive, [Bus Reg Mode A & B] must
be set to either option 2, 3 or 4.
Default:
Options:
0
2
0
1
2
“Internal Res”
“None”
“Internal Res”
“External Res”
“None”
161
162
Restart Modes
169 [Flying Start En]
Enables/disables the function which
reconnects to a spinning motor at actual
RPM when a start command is issued.
Default:
Options:
0
0
1
“Disabled”
“Disabled”
“Enabled”
170
UTILITY (File E)
Drive Memory
201 [Language]
Selects the display language when using
an LCD HIM. This parameter is not
functional with an LED HIM.
Default:
Options:
0
0
1
2
3
4
5
6
7
8-9
10
“Not Selected”
“Not Selected”
“English”
“Français”
“Español”
“Italiano”
“Deutsch”
“Reserved”
“Português”
“Reserved”
“Nederlands”
INPUTS & OUTPUTS (File J)
Analog Inputs
322
325
[Analog In 1 Hi]
[Analog In 2 Hi]
Sets the highest input value to the analog
input x scaling block.
Default:
Min/Max:
Units:
10.000 Volt
10.000 Volt
4.000/20.000 mA ,
0.000/20.000 mA ,
–/+10.000V,
0.000/10.000V
0.001 mA,
0.001 Volt
091
092
323
326
[Analog In 1 Lo]
[Analog In 2 Lo]
Sets the lowest input value to the analog
input x scaling block.
Default:
Min/Max:
Units:
0.000 Volt
0.000 Volt
4.000/20.000 mA,
0.000/10.000V (No. 323),
–/+10.000V (No. 326)
0.000/10.000V,
0.001 mA,
0.001 Volt
091
092
E C
!
ATTENTION: The drive does not offer protection for externally
mounted brake resistors. A risk of fire exists if external braking
resistors are not protected. External resistor packages must be
self-protected from over temperature or the protective circuit shown
in Appendix C of the User Manual, or equivalent, must be supplied.
ATTENTION: Equipment damage may result if a drive mounted
(internal) resistor is installed and this parameter is set to “External
Res.” Thermal protection for the internal resistor will be disabled,
resulting in possible device damage.
Standard
E C

PowerFlex 70 Adjustable Frequency AC Drive Quick Start English-15
INPUTS & OUTPUTS (File J)
Digital Inputs
361
362
363
364
365
366
[Digital In1 Sel]
[Digital In2 Sel]
[Digital In3 Sel]
[Digital In4 Sel]
[Digital In5 Sel]
[Digital In6 Sel]
Selects the function for the digital inputs.
(1) When [Digital Inx Sel] is set to option
2 “Clear Faults” the Stop button
cannot be used to clear a fault
condition.
To access Preset Speed 1, set [Speed
Ref A Sel] or [Speed Ref B Sel] to
“Preset Speed 1”.
(4) Enhanced Control Drives Only.
(5) Enhanced Firmware V2.001 and later.
(6) Opening an “Enable” input will cause
the motor to coast-to-stop, ignoring any
programmed Stop modes.
(7) A dedicated hardware enable input is
available via a jumper selection. Refer
to the User Manual for further
information.
(8) Auto/Manual - Refer to the User
Manualfor details.
(9) Typical 3-Wire Inputs - Requires that
only 3-wire functions are chosen.
Including 2-wire selections will cause a
type 2 alarm.
Default:
Default:
Default:
Default:
Default:
Default:
Options:
4
5
18
15
16
17
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15-17
18
19
20
21
22
23
24
25
26
27
28
29
30
31-33
34
35
36-40
41-42
43
44
45
46
“Stop – CF”(1)
“Start”
“Auto/ Manual”
“Speed Sel 1”
“Speed Sel 2”
“Speed Sel 3”
“Not Used”
“Enable”(6)
“Clear Faults”(1)
“Aux Fault”
“Stop – CF”(1)
“Start”(9)(11)
“Fwd/ Reverse”(9)
“Run”(10)
“Run Forward”(3)
“Run Reverse”(3)
“Jog”(9) “Jog1”(4)
“Jog Forward”
“Jog Reverse”
“Stop Mode B”
“Bus Reg Md B”
“Speed Sel 1-3”(2)
“Auto/ Manual”(8)
“Local”
“Acc2 & Dec2”
“Accel 2”
“Decel 2”
“MOP Inc”(12)
“MOP Dec”(12)
“Excl Link”(12)
“PI Enable”
“PI Hold”
“PI Reset”
“Reserved”
“Precharge En”(4)(12)
“Spd/Trq Sel1-3”(5)
“Jog 2”(4)
“PI Invert”(4)
“Reserved”
“UserSet Sel1-2” (5)
“Run Level”(5)(12)
“RunFwd Level”(5)(12)
“RunRev Level”(5)(12)
“Run w/Comm”(5)(12)
100
156
162
096
140
194
380
124
(10)Typical 2-Wire Inputs - Requires that only 2-wire functions are chosen. Including
3-wire selections will cause a type 2 alarm.
(11)A “Dig In ConflictB” alarm will occur if a “Start” input is programmed without a “Stop”
input.
Type 2 Alarms - Some digital input programming may cause conflicts that will result
in a Type 2 alarm. Example: [Digital In1 Sel] set to 5 “Start” in 3-wire control and
[Digital In2 Sel] set to 7 “Run” in 2-wire.
Refer to the User Manual for information on resolving this type of conflict.
(12) Refer to Option Definitions in the User Manual.
(2) 321“Speed Sel 1-3”
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
Reference A
Reference B
Preset Speed 2
Preset Speed 3
Preset Speed 4
Preset Speed 5
Preset Speed 6
Preset Speed 7
(3) 321“Spd/TrqSel1-3”
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
Zero Torque
Spd Reg
Torque Reg
Min Spd/Trq
Max Spd/Trq
Sum Spd/Trq
Absolute
Zero Trq

English-16 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
For a complete listing of Faults and Alarms, refer to the PowerFlex 70
User Manual.
Troubleshooting – Abbreviated Fault & Alarm Listing
Fault
No. Type(1)
Description Action
Auxiliary Input 2 ➀Auxiliary input interlock is open. Check remote wiring.
Motor Overload 7 ➀
➂
Internal electronic overload trip.
Enable/Disable with [Fault Config
1].
An excessive motor load exists.
Reduce load so drive output current
does not exceed the current set by
[Motor NP FLA].
OverSpeed Limit 25 ➀Functions such as Slip
Compensation or Bus Regulation
have attempted to add an output
frequency adjustment greater
than that programmed in
[Overspeed Limit].
Remove excessive load or
overhauling conditions or increase
[Overspeed Limit].
SW OverCurrent 36 ➀Drive output current has
exceeded the 1ms current rating.
This rating is greater than the 3
second current rating and less
than the hardware overcurrent
fault level. It is typically 200-250%
of the drive continuous rating.
Check for excess load, improper DC
boost setting. DC brake volts set too
high.
IR Volts Range 77 “Calculate” is the autotune default
and the value determined by the
autotune procedure for IR Drop
Volts is not in the range of
acceptable values.
Re-enter motor nameplate data.
FluxAmpsRef
Rang
78 The value for flux amps
determined by the Autotune
procedure exceeds the
programmed [Motor NP FLA].
1. Reprogram [Motor NP FLA] with
the correct motor nameplate
value.
2. Repeat Autotune.
(1) See the User Manual for a description of fault types.
Alarm
No. Type(1)
Description
Dig In
ConflictA
17 ➁Digital input functions are in conflict. Combinations marked with a “ ” will
cause an alarm.
Acc2/Dec2 Accel 2 Decel 2 Jog Jog Fwd Jog Rev Fwd/Rev
Acc2 / Dec2
Accel 2
Decel 2
Jog
Jog Fwd
Jog Rev
Fwd / Rev

PowerFlex 70 Adjustable Frequency AC Drive Quick Start English-17
Dig In
ConflictB
18 ➁A digital Start input has been configured without a Stop input or other
functions are in conflict. Combinations that conflict are marked with a “ ”
and will cause an alarm.
Dig In
ConflictC
19 ➁More than one physical input has been configured to the same input function.
Multiple configurations are not allowed for the following input functions.
Forward/Reverse Run Reverse Bus Regulation Mode B
Speed Select 1 Jog Forward Acc2 / Dec2
Speed Select 2 Jog Reverse Accel 2
Speed Select 3 Run Decel 2
Run Forward Stop Mode B
(1) See User Manual for a description of alarm types.
Alarm
No. Type(1)
Description
Start Stop–CF Run Run Fwd Run Rev Jog Jog Fwd Jog Rev
Fwd/
Rev
Start
Stop–CF
Run
Run Fwd
Run Rev
Jog
Jog Fwd
Jog Rev
Fwd /
Rev
Manually Clearing Faults
Step Key(s)
1. Press Esc to acknowledge the fault. The fault information will be
removed so that you can use the HIM.
2. Address the condition that caused the fault.
The cause must be corrected before the fault can be cleared.
3. After corrective action has been taken, clear the fault by one of
these methods:
•Press Stop
•Cycle drive power
•Set parameter 240 [Fault Clear] to “1.”
•“Clear Faults” on the HIM Diagnostic menu.
Esc

www.rockwellautomation.com
Corporate Headquarters
Rockwell Automation, 777 East Wisconsin Avenue, Suite 1400, Milwaukee, WI, 53202-5302 USA, Tel: [phone], Fax: [phone]
Headquarters for Allen-Bradley Products, Rockwell Software Products and Global Manufacturing Solutions
Americas: Rockwell Automation, 1201 South Second Street, Milwaukee, WI 53204-2496 USA, Tel: [phone], Fax: [phone]
Europe/Middle East/Africa: Rockwell Automation SA/NV, Vorstlaan/Boulevard du Souverain 36, 1170 Brussels, Belgium, Tel: [phone], Fax: [phone]
Asia Pacific: Rockwell Automation, 27/F Citicorp Centre, 18 Whitfield Road, Causeway Bay, Hong Kong, Tel: [phone], Fax: [phone]
Headquarters for Dodge and Reliance Electric Products
Americas: Rockwell Automation, 6040 Ponders Court, Greenville, SC 29615-4617 USA, Tel: [phone], Fax: [phone]
Europe/Middle East/Africa: Rockwell Automation, Brühlstraße 22, D-74834 Elztal-Dallau, Germany, Tel: [phone], Fax: [phone]
Asia Pacific: Rockwell Automation, 55 Newton Road, #11-01/02 Revenue House, Singapore 307987, Tel: [phone], Fax: [phone]
U.S. Allen-Bradley Drives Technical Support
Tel: [phone], Fax: [phone], Email: [email protected], Online: www.ab.com/support/abdrives
Publication 20A-QS001E-EN-P – February 2005 P/N 198682-P05
Supersedes June 2004 Copyright © 2005 Rockwell Automation, Inc. All rights reserved. Printed in USA.
