Allen-Bradley PowerFlex 755T User manual

Installation Instructions
Original Instructions
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and
Ground Plate Kits
Catalog Numbers 20-750-CBOX1-F5, 20-750-CBOX1-F6, 20-750-GNDPLT-F5, 20-750-GNDPLT-F6
Product Advisories
Topic Page
Product Advisories 1
Required Tools 2
Frame 5 Conduit Box with Debris Hood Kit Contents (Cat. No. 20-750-CBOX1-F5) 2
Frame 5 Conduit Box Installation 3
Frame 6 Conduit Box with Debris Hood Kit (Cat. No. 20-750-CBOX1-F6) 9
Frame 6 Conduit Box and Debris Hood Installation 10
Frame 5 Ground Plate Kit Contents (Cat. No. 20-750-GNDPLT-F5) 16
Frame 5 Ground Plate Installation 17
Frame 6 Ground Plate Kit Contents (Cat. No. 20-750-GNDPLT-F6) 20
Frame 6 Ground Plate Installation 21
Additional Resources 23
ATTENTION: Only qualified personnel, which are trained and approved to install PowerFlex® 755T products and familiar with associated machinery, should plan
or implement the installation, start-up, and subsequent maintenance of the system. Failure to comply can result in personal injury and/or equipment damage.
ATTENTION: The information that is contained in this publication is merely a guide for proper installation. Rockwell Automation, Inc. cannot assume
responsibility for the compliance or the noncompliance to any code, national, local or otherwise for the proper installation of this drive or associated equipment.
A hazard of personal injury and/or equipment damage exists if codes are ignored during installation.
ATTENTION: This product contains Electrostatic Discharge (ESD) sensitive parts and assemblies. Static control precautions are required when you install these
assemblies. Component damage can result if ESD control procedures are not followed. If you are not familiar with static control procedures, reference any
applicable ESD protection handbook.

2Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
Required Tools
Frame 5 Conduit Box with Debris Hood Kit Contents (Cat. No. 20-750-CBOX1-F5)
The frame 5 conduit box with debris hood kit contains the following components.
Tool Description Details
Allen (hex) socket wrench 4 mm
Electric drill and bits (Bit sizes to meet conduit size requirements)
Flat-nose screwdriver 6.4 mm (0.25 in.)
Hexagonal socket wrench 11 mm
Phillips screwdriver/bit #2
Torx, star, or hexalobular screw driver/bit #T20, #25, #30
Torque wrench 1...12 N•m (8.8…106 lb•in)
Torque wrench 6...50 N•m (53…443 lb•in)
Item Quantity Description Item Quantity Description
1 1 Conduit box bottom plate 5 2 M6 x 12 mm torx screws (for conduit box)
2 5 M5 x 10 mm slotted-torx screws (for conduit box bottom plate) 6 1 Conduit box cover
3 1 Conduit box 7 1 M6 x 12 mm torx screw (for conduit box cover)
4 4 M5 x 10 mm slotted-torx screws (for conduit box) 8 1 Debris hood with captive screws
1 2 3 4 5
6 7 8
Debris Hood
Conduit Box
Frame 5 with Conduit Box and Debris Hood Kit Installed

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 3
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
Frame 5 Conduit Box Installation
Follow these steps to install the frame 5 conduit box and debris hood.
1. Use the pilot holes in the conduit box bottom plate to drill the required holes for control and input/output power wire conduit fittings.
Pilot holes for control power
wire conduit fittings.
Pilot holes for input/output
power wire conduit fittings.

4Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
2. Loosen the four M4 captive screws that secure the cover to the assembly, and remove the cover.
4x
2
M4 (Captive)
F - 6.4 mm (0.25 in.) or 4 mm hex
2.6 N•m (23 lb•in)

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 5
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
3. Place the conduit box onto the chassis of the drive, so that the conduit box flanges are located on the inside of the drive chassis.
4. Insert and tighten the four M5 x 10 mm slotted-torx screws in the holes on the bottom sides of the chassis to secure the conduit box to the
chassis.
5. Insert and tighten the two M6 x 12 mm torx screws in the holes on the bottom of the chassis to secure the conduit box to the chassis.
4
M5 x 10 mm
T25 or F - 6.4 mm (0.25 in.)
3.6 N•m (32 lb•in)
Conduit box flanges must be
inside the drive chassis.
Detail A
See Detail A
Conduit box flanges must be
inside the drive chassis.
5
M6 x 12 mm
T30
10.2 N•m (90 lb•in)

6Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
6. Insert and tighten the five M5 x 10 mm slotted-torx screws in the bottom of the conduit box to secure the bottom plate to the conduit box.
7. Route the control and power cables through the bottom plate of the conduit box and connect them to the appropriate input and output
power terminals. See the PowerFlex 750-Series Products with TotalFORCE® Control Installation Instructions, publication 750-IN100, for
power wiring information.
6
M5 x 10 mm
T25 or F - 6.4 mm (0.25 in.)
3.6 N•m (32 lb•in)
Tie wrap connection points
(3) for cable shields.

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 7
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
8. Insert and tighten the M6 x 12 mm torx screw in the hole on the front of the conduit box to secure the front plate to the conduit box.
9. Secure the cover to the chassis as shown in step 2 on page 4.
8
M6 x 12 mm
T30
10.2 N•m (90 lb•in)

8Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
10. Place the debris hood on the top of the chassis and tighten the four M5 captive Phillips-head screws.
10
M5 (Captive)
P2
3.6 N•m (32 lb•in)

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 9
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
Frame 6 Conduit Box with Debris Hood Kit (Cat. No. 20-750-CBOX1-F6)
The frame 6 conduit box with debris hood kit contains the following components.
Item Quantity Description
1 1 Conduit box bottom plate with captive screws
2 1 Conduit box with captive screws
3 1 Conduit box cover with captive screws
4 1 Debris hood with captive screws
1 2
3 4
Debris Hood
Conduit Box
Frame 6 with Conduit Box and Debris Hood Kit Installed

10 Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
Frame 6 Conduit Box and Debris Hood Installation
Follow these steps to install the frame 6 conduit box and debris hood.
1. Use the pilot holes in the conduit box bottom plate to drill the required holes for control and input/output power wire conduit fittings.
Pilot holes for control power
wire conduit fittings.
Pilot hole for DC bus power
wire conduit fittings.
Pilot holes for AC motor output
power wire conduit fittings.
Pilot holes for control wire
conduit fittings.
Pilot hole for AC input power
wire conduit fittings.

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 11
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
2. Loosen the eight M4 captive screws that secure the cover to the assembly, and remove the cover.
8x
2
M4 (Captive)
F - 6.4 mm (0.25 in.) or 4 mm hex
2.6 N•m (23 lb•in)

12 Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
3. Remove the two M8 nuts and washers from the PE ground studs on the chassis.
4. Place the two slots in the tab at the top of the conduit box onto the ground studs.
5. Align and tighten the four M4 captive slotted-torx screws on the conduit box to secure it to the chassis.
6. Tighten the two M8 nuts and washers on the PE ground studs.
4
5
M4 (Captive)
T20
3.6 N•m (32 lb•in)
4
5
5
6
M8
13 mm
9.0 N•m (80 lb•in)
3. Remove Nuts and Washers.

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 13
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
7. Align the screws on the bottom plate with the holes on the conduit box and tighten the six M4 captive slotted-torx screws to secure the plate
to the box.
8. Route the power cables through the bottom plate of the conduit box and connect them to the appropriate input and output power
terminals. See the PowerFlex® 750-Series Products with TotalFORCE Control Installation Instructions, publication 750-IN100, for power
wiring information.
7
M4 (Captive)
T20
3.6 N•m (32 lb•in)
7
7
Three cable tie connection
points for cable shields.

14 Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
9. Align the two slots at the top of the front cover with the two tabs on the conduit box and place the cover on the box.
10. Align and tighten the four M4 captive slotted-torx screws on the front plate to secure it to the conduit box.
11. Secure the cover to the chassis as shown in step 2 on page 11.
10
M4 (Captive)
T20
3.6 N•m (32 lb•in)
10
10
9. Align Slots on Tabs.

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 15
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
12. Place the debris hood on the top of the chassis and tighten the four M4 captive slotted-torx screws.
12
M4 (Captive)
T20
3.6 N•m (32 lb•in)

16 Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
Frame 5 Ground Plate Kit Contents (Cat. No. 20-750-GNDPLT-F5)
The frame 5 ground plate kit contains the following components.
Item Quantity Description Item Quantity Description
1 1 Ground plate 4 2 M4 x 11 mm (ground screws)
2 4 M5 x 10 mm slotted-torx screws (for ground plate brackets) 5 2 Cable clamp, EMC
3 2 M6 x 12 mm torx screws (for ground plate tabs) 6 2 Cable clamp, 1.10…1.40 cable diameter
1 2 3
4 65
1 2 3
4 65
Ground Plate
Frame 5 with Ground Plate Kit Installed

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 17
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
Frame 5 Ground Plate Installation
Follow these steps to install the frame 5 ground plate.
1. Loosen the four M4 captive screws that secure the cover to the assembly, and remove the cover.
4x
1
M4 (Captive)
F - 6.4 mm (0.25 in.) or 4 mm hex
2.6 N•m (23 lb•in)

18 Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
2. Insert and tighten the four M5 x 10 mm torx screws in the holes on the side panels of the chassis to secure the ground plate to the chassis.
3. Insert and tighten the two M6 x 12 mm torx screws in the holes on the bottom of the chassis to secure the ground plate to the chassis.
2
M5 x 10 mm
T25 or F - 6.4 mm (0.25 in.)
3.6 N•m (32 lb•in)
3
M6 x 12 mm
T30
10.2 N•m (90 lb•in)

Rockwell Automation Publication 750-IN112A-EN-P - July 2019 19
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
4. As required, insert the M4 slotted torx screws to secure ground wires to the ground plate.
5. As required, insert the appropriate sized cable clamps into the ground plate receptacles and secure the power wires.
6. Secure the cover to the chassis as shown in step 1 page 17.
4
5
Tie wrap connection points
(3) for cable shields.

20 Rockwell Automation Publication 750-IN112A-EN-P - July 2019
PowerFlex 755T Frames 5 and 6 Conduit Box with Debris Hood and Ground Plate Kits
Frame 6 Ground Plate Kit Contents (Cat. No. 20-750-GNDPLT-F6)
The frame 6 ground plate kit contains the following components.
Item Quantity Description Item Quantity Description
1 1 Ground plate 3 2 Cable clamp, EMC
2 2 Cable clamp, 1.10…1.40 cable diameter
1 2 3
Ground Plate
Frame 6 with Ground Plate Kit Installed
