Allen-Bradley Powermonitor 3000 User manual

Bulletin 1404
Powermonitor 3000
1404-M4, 1404-M5, 1404-M6,
1404-M8
User Manual
Allen-Bradley HMIs

Important User Information
Solid state equipment has operational characteristics differing from those of
electromechanical equipment. Safety Guidelines for the Application,
Installation and Maintenance of Solid State Controls (Publication SGI-1.1
available from your local Rockwell Automation sales office or online at
http://www.ab.com/manuals/gi) describes some important differences
between solid state equipment and hard-wired electromechanical devices.
Because of this difference, and also because of the wide variety of uses for
solid state equipment, all persons responsible for applying this equipment
must satisfy themselves that each intended application of this equipment is
acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for
indirect or consequential damages resulting from the use or application of
this equipment.
The examples and diagrams in this manual are included solely for illustrative
purposes. Because of the many variables and requirements associated with
any particular installation, Rockwell Automation, Inc. cannot assume
responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to
use of information, circuits, equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without
written permission of Rockwell Automation, Inc. is prohibited.
Throughout this manual we use notes to make you aware of safety
considerations.
WARNING Identifies information about practices or circumstances
that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property
damage, or economic loss.
IMPORTANT Identifies information that is critical for successful
application and understanding of the product.
ATTENTION Identifies information about practices or circumstances
that can lead to personal injury or death, property
damage, or economic loss. Attentions help you:
•identify a hazard
•avoid a hazard
•recognize the consequence
SHOCK HAZARD Labels may be located on or inside the drive to alert
people that dangerous voltage may be present.
BURN HAZARD Labels may be located on or inside the drive to alert
people that surfaces may be dangerous temperatures.

1Publication 1404-UM001D-EN-E - October 2004
Table of Contents
Preface Using This User Manual. . . . . . . . . . . . . . . . . . . . . . . Preface-1
For More Information on Additional Power and Energy
Management Products . . . . . . . . . . . . . . . . . . . . . . . . Preface-2
Terms and Conventions. . . . . . . . . . . . . . . . . . . . . . . Preface-3
Chapter 1
Safety
Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Other Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Chapter 2
Product Description
Master Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Display Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Performance Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Communications Options . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Chapter 3
Powermonitor 3000 Operations
Metering Functionality. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Display Module Functionality . . . . . . . . . . . . . . . . . . . . . . 3-12
Configuration Using the Display Module . . . . . . . . . . . . . . 3-21
Metering Update Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-33
Chapter 4
Communications
Configuring Communications. . . . . . . . . . . . . . . . . . . . . . . 4-1
Data Messaging Overview . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Data Messaging- Application Considerations. . . . . . . . . . . . 4-24
Chapter 5
Setpoint Programming and
Operation
Theory of Setpoint Operation . . . . . . . . . . . . . . . . . . . . . . 5-1
Configuring Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Chapter 6
I/O Operations
Relay and KYZ Output Operations. . . . . . . . . . . . . . . . . . . 6-1
Status Input Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Chapter 7
Data Logging
Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Configurable Trend Log. . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Min/Max Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13
Time-of-use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16
Chapter 8
Advanced Features
Oscillography . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Harmonic Analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Sag and Swell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
Table of Contents 2
Load Factor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16
Transient Detection, Metering and Capture. . . . . . . . . . . . . 8-18
Appendix A
Powermonitor 3000 Data Tables
Appendix B
Catalog Number Explanation
Master Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Display Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
Appendix C
Sample Applications
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
System Clock Sample Applications. . . . . . . . . . . . . . . . . . . C-2
Multiple Data Table Reads Using DeviceNet. . . . . . . . . . . C-17
User-Configured Data Table Setup Using ControlLogix and
EtherNet/IP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-27
Communicating with a SLC5/05 (1747-L552) Controller and
ControlNet Scanner (1747-SCNR), Unscheduled Messaging C-33
Appendix D
Technical Specifications
Product Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . D-3
Appendix E
Frequently Asked Questions
Appendix F
Powermonitor 3000 EtherNet/IP
Device Profile
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-1
Object Model and Interface . . . . . . . . . . . . . . . . . . . . . . . . F-1
Identity Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-2
Assembly Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-5
PCCC Object. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-8
NVS Object. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-11
Additional Powermonitor 3000 Ethernet Features . . . . . . . F-15
SNTP Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-15
End of Interval Pulse Producer / Consumer. . . . . . . . . . . F-16
Dynamic Web Server Functionality . . . . . . . . . . . . . . . . . F-17

Publication 1404-UM001D-EN-E - October 2004
Table of Contents 3
Appendix G
Powermonitor 3000 ControlNet
Device Profile
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-1
Object Model and Interface . . . . . . . . . . . . . . . . . . . . . . . . G-1
Identity Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-2
Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-2
Instance Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-2
Common Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-3
Assembly Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-5
PCCC Object. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-8
NVS Object. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-12
Glossary
Index
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
Table of Contents 4

1Publication 1404-UM001D-EN-E - October 2004
Preface
Using This User Manual
What This User Manual Contains
Review the table below to familiarize yourself with the topics
contained in this User Manual.
For information about: Refer to
Chapter:
Safety 1
Product Description 2
Communications Options
Powermonitor 3000 Operations 3
Metering Functionality
Display Module Functionality
Configuration Using the Display Module
Metering Update Rate
Communications 4
Configuring Communications
Data Messaging Overview
Data Messaging- Application Considerations
Setpoint Programming and Operation 5
Theory of Setpoint Operation
Configuring Setpoints
I/O Operations 6
Relay and KYZ Output Operations
Status Input Operations
Data Logging 7
Event Log
Configurable Trend Log
Min/Max Log
Advanced Features 8
Oscillography
Harmonic Analysis
Sag and Swell
Load Factor
Transient Detection, Metering and Capture
Powermonitor 3000 Data Tables A
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
Preface 2
What This User Manual Does Not Contain
Topics related to installation and wiring are not covered in this
manual. Refer to the Powermonitor 3000 Installation Instructions,
publication 1404-IN007 for the following information:
•Selecting an enclosure for the Powermonitor 3000 and
associated equipment.
•Mounting and wiring of the Master Module.
•Mounting and connection of the Display Module (refer to
publication 1404-IN005).
•Selection and connection of current transformers (CTs) and
potential transformers (PTs)
•Wiring to native and optional communications ports.
For More Information on
Additional Power and
Energy Management
Products
Catalog Number Explanation B
Sample Applications C
Technical Specifications D
Frequently Asked Questions E
Glossary Glossary
Index Index
For this information: Refer to
Publication
Powermonitor 3000 Installation Instructions (all communication options) 1404-IN007
Bulletin 1404 Powermonitor 3000 Display Module Installation Instructions 1404-IN005
Bulletin 1404 Series B Ethernet Communications Release Note 1404-RN008
Bulletin 1403 Powermonitor II Tutorial 1403-1.0.2
Bulletin 1403 Powermonitor II Instruction Sheet 1403-5.0
Cat. No. 1403-NSC Smart Communications Card Instruction Sheet 1403-5.1
Cat. No. 1403-NENET Ethernet Communications Card Instruction Sheet 1403-IN005
Cat. No. 1403-NDNET DeviceNet Communications Card Instruction Sheet 1403-IN054
Cat. No. 1402-LS51 Installation and Operation Manual 1402-5.0
Cat. No. 1407-CGCM User Manual 1407-UM001
Bulletin 9307 RSPower32 P32-TD001
Bulletin 9307 RSEnergyMetrix ENEMTX-TD
001

Publication 1404-UM001D-EN-E - October 2004
Preface 3
Terms and Conventions
In this manual, the following terms and conventions are used:
Abbreviation Term
AWG American Wire Gage
BSD Berkeley Sockets Distribution
BTR Block Transfer Read
BTW Block Transfer Write
CSA Canadian Standards Association
CIP Control and Information Protocol
CNET ControlNet Industrial Control Network
CT Current Transformer
DC Daughter Card
DM Display Module
DPRAM Dual Port RAM
EMI Electromagnetic Interference
EOI Rockwell Automation's Electronic Operator Interface group
HTML Hyper-Text Markup Language
ID Identification
I/O Inputs and Outputs
IEC International Electrotechnical Commission
LED Light Emitting Diode
LSM Line Synchronization Module
NEMA National Electrical Manufacturers Association
NAP Network Access Port
NVS Non-Volatile Storage
EtherNet/IP Open Device Vendor’s Association’s Ethernet Industrial Protocol
PT Potential Transformer
(Also known as VT in some countries)
PM 3000 Powermonitor 3000 Master Module
PLC Programmable Logic Controller
RFI Radio Frequency Interference
RAM Random Access Memory
RTOS Real Time Operating System
R I/O Remote Input/Output
PCCC Rockwell Automation’s proprietary Programmable Controller
Communications Commands protocol.
RMS Root–mean–square
SNTP Simple Network Time Protocol
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
Preface 4
SPDT Single Pole Double Throw
SLC Small Logic Controller
trrbl “Task Request Response Block” used by RTOS for inter-task
communication
UL Underwriters Laboratories
VA Volt–ampere
VAR Volt–ampere Reactive
Abbreviation Term

1Publication 1404-UM001D-EN-E - October 2004
Chapter 1
Safety
Safety Considerations
Before installing and using this product, please read and understand
the following precautions.
ATTENTION Only qualified personnel, following accepted safety
procedures, should install, wire and service the
Powermonitor 3000 and its associated components.
Before beginning any work, disconnect all sources of
power and verify that they are de-energized and
locked out. Failure to follow these instructions may
result in personal injury or death, property damage
or economic loss.
ATTENTION Never open a current transformer (CT) secondary
circuit with primary current applied. Wiring between
the CTs and the Powermonitor 3000 should include a
shorting terminal block in the CT secondary circuit.
Shorting the secondary with primary current present
allows other connections to be removed if needed.
An open CT secondary with primary current applied
produces a hazardous voltage, which can lead to
personal injury, death, property damage or economic
loss.
IMPORTANT The Powermonitor 3000 is not designed for nor
intended for use as a circuit protective device. Do
not use this equipment in place of a motor overload
relay or circuit protective relay.
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
1-2 Safety
Other Precautions
IMPORTANT The relay output contacts and solid-state KYZ output
contacts on the Powermonitor 3000 may be used to
control other devices through setpoint control or
communications. The response of these outputs to a
communications failure is configurable by the user.
Be sure to evaluate the safety impact of the output
configuration on your plant or process.
ATTENTION Electrostatic discharge can damage integrated circuits
or semiconductors. Follow these guidelines when
you handle the module.
•Touch a grounded object to discharge static
potential.
•Wear an approved wrist strap-grounding device.
•Do not open the module or attempt to service
internal components.
•If available, use a static safe workstation.
•When not in use, keep the module in its static
shield bag.

1Publication 1404-UM001D-EN-E - October 2004
Chapter 2
Product Description
The Bulletin 1404 Powermonitor 3000™is uniquely designed and
developed to meet the needs of both producers of and users of
electric power. A Powermonitor 3000 system consists of:
•Master Module which provides metering, data logging, native
RS-485 communications and other advanced features depending
on the model
•Optional Display Module for configuration, entering commands
and displaying data
•Optional communications port to serve data to other devices
using a choice of networks
•Optional external devices and applications that display and
utilize data for reporting, control and management of power and
energy usage
The Powermonitor 3000 is a microprocessor-based monitoring and
control device ideally suited for a variety of applications including:
•Load Profiling – Using the configurable trending utility to log
power parameters such as real power, apparent power and
demand, for analysis of power usage by loads over time
•Demand Management – Understanding when and why demand
charges occur lets you make informed decisions that reduce
your electrical power costs
•Cost Allocation – Knowing your actual energy costs promotes
manufacturing efficiencies
•Distribution System Monitoring – Using power parameters to
show power flow, system topology and distribution equipment
status
•Emergency Load Shedding – Monitoring power usage to
preserve system stability in the event of sudden utility outage
•Power System Control – Managing system voltage, harmonic
distortion and power factor
The Powermonitor 3000 is a sophisticated modern alternative to
traditional electromechanical metering devices. A single Powermonitor
3000 can replace many individual transducers and meters. The
Powermonitor 3000 is simple to install, configure and operate, and
provides you with accurate information in a compact economical
package.
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
2-2 Product Description
Master Module
The Master Module contains the main microprocessor-based
monitoring functions, including terminations for power system
connections, status inputs, control outputs, a native RS-485
communications port and a port for the Display Module.
Configuration
Although the Powermonitor 3000 ships from the factory with default
settings, you need to configure it for your particular requirements.
You may configure the Powermonitor 3000 using the optional Display
Module. Alternately, you may use an external device or application to
write configuration, operational parameters and commands to the
Master Module through its native or optional communications port.
Optional external applications that you may use for Powermonitor
3000 configuration include RSPower32TM and RSEnergyMetrixTM
software operating on a computer with a Microsoft WindowsTM
operating system. Contact your local Rockwell Automation sales office
or distributor, or visit http://www.software.rockwell.com/ for more
information on available software packages.
Communications
Every Powermonitor 3000 comes with a native RS-485
communications port that supports the Allen-Bradley DF1 half-duplex
slave and Modbus RTU slave protocols. The native port is suitable for
communicating to master devices including:
•A-B PLC®-5, SLC™500 and ControlLogix processors
•RSLinx™software with DDE/OPC server functionality
•Modbus RTU masters
•Other third-party devices
•Software that you develop
You may also specify Powermonitor 3000 units with optional
communications ports including:
•Serial RS-232 (DF1 half-duplex or Modbus RTU slave)
•Remote I/O
•DeviceNet™
•Ethernet®and EtherNet/IP™
•ControlNet™

Publication 1404-UM001D-EN-E - October 2004
Product Description 2-3
You may easily integrate a Powermonitor 3000 into a programmable
controller based control and monitoring system using your choice of
the native or optional communications methods listed above.
Display Module
The Bulletin 1404 Display Module is an optional user interface device.
The Display Module provides the most economical and simplest
method for setting up and configuring the Master Module for
operation.
The Display Module has a highly visible, two-line LED display and
four operator buttons with tactile feedback. Use the buttons and
display to navigate through a series of menus for configuration,
commands and data display.
The Display Module is shipped with a 3-meter (10-ft.) long, shielded
4-pair cable that provides power and serial communications between
the Master Module and the Display Module. The Display Module fits
into a standard ANSI 4-inch analog meter cutout for panel mounting.
Only one Display Module may connect to a Master Module, although
you may use one Display Module to configure and monitor any
number of Master Modules one at a time.
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
2-4 Product Description
Performance Features
The Powermonitor 3000 is available in four basic models, designated
M4, M5, M6 and M8. Each model offers specific functionality as
indicated in the table below. The M5 model offers M4 functionality
and can be field-upgraded to an M6 or M8 model for an additional
charge.
Table 2.1 Product Features of Powermonitor 3000 Module
M4 M5 M6 M8 Master Module Features
••••Voltage, current, power measurements and display
••••Compatible with PLC-5, SLC 500, and ControlLogix
••••Compatible with RSLinx, RSPower32, RSEnergyMetrix and
RSView32
••••Output control via control relays or PLC
••••Demo mode for training
••••10 user configurable setpoints
••••Discrete condition monitoring via status inputs
••••Electronic KYZ pulse output
••••Form C ANSI C37.90-1989 rated relay for direct breaker tripping
••••Time stamped data logging of system measurements and events
••••Configurable trend log, up to 45,000 records deep
••••Event log 50 records deep
••••Firmware upgrades without removing module
••••Total harmonic distortion (THD) and Crest Factor
••••Automatic network-based time synchronization via SNTP (for
Ethernet Series B)
••••Daylight Savings Time (Master Module FRN 2.5x)
•••ANSI C12.20 Class 0.5 revenue metering accuracy(1)
(1) Class 0.2 revenue metering accuracy available as an extra-cost option.
•••EN60687 Class 0.5 revenue metering accuracy(1)
•••Canadian Revenue Meter specification accuracy
•••Field upgradeable to M6 or M8 (extra cost option)
••10 additional setpoints with more options
••Event Log an additional 50 records deep
••User configurable oscillography up to 400 cycles @ 60 Hz
••TIF, K-factor and IEEE-519 Pass/Fail
••Sag and swell detection with oscillogram capture
••Load factor log 12 records (months) deep
••Calculates amplitude and % distortion for harmonics 1 to 41
•Calculates amplitude and % distortion for harmonics 1 to 63
•Sub-cycle transient capture and metering
•Event Log with user comment entry
•Transducer and Energy Meter modes with improved update rate

Publication 1404-UM001D-EN-E - October 2004
Product Description 2-5
Communications Options
In addition to the native RS-485 communications port, several
factory-installed communications options are also available. These
options make is possible for a user to select Powermonitor 3000 units
to provide power and energy information into a variety of existing or
new control systems and communications networks. Each
communications option supports bi-directional data transfer with
external devices or applications. Metering measurement, logging,
configuration and status data may be accessed via communications.
Communications options are set in the Master Module. You may
configure communications using the Display Module or via
communications to an external application such as RSPower32 or
RSEnergyMetrix. Refer to the information later in this manual on
configuration and operation of the communications options.
Refer to the Powermonitor 3000 Installation Manual (publication
1404-IN007) for installation and wiring information related to your
selected communications options.
The last 3 characters of the catalog number specify the
communications option of the Powermonitor 3000.
RS-485 Native Communications
A catalog number ending in -000 specifies a Powermonitor 3000
equipped with only a native RS-485 communications port with the
following performance features:
•Baud rates 1200, 2400, 4800, 9600, 19,200
•RS-485 cable length 1219 m (4000 ft) at 19,200 baud maximum
•Cable type: 2-wire shielded (Belden™9841)
•Multi-drop capabilities up to 32 nodes
•Update rate: 100 mSec minimum
•Read/Write data table access to all data
•One user-configurable data table
•Supports DF1 half-duplex and Modbus RTU communications
protocol
•Used for field firmware upgrades
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
2-6 Product Description
RS-232 Optional Communications
A catalog number ending in -232 specifies a Powermonitor 3000 with
one RS-232 communications ports in addition to the native RS-485
communications port. The user selects which of the two ports is
active, as the two ports may not be used concurrently. The RS-232
port has the following performance features:
•Baud rates 1200, 2400, 4800, 9600, 19,200
•RS-232 cable length 15.24 m (50 ft) maximum
•Cable type: 3-wire shielded (Belden 9608)
•Point-to-point wiring
•Update rate: 100 mSec minimum
•Read/Write data tables for access to all data
•One user-configurable data table
•Supports DF1 half-duplex slave communications protocol
•Supports Modbus RTU slave protocol
Remote I/O Optional Communications
A catalog number ending in -RIO specifies a Powermonitor 3000 with
a Remote I/O communication port in addition to the native RS-485
communications port. The Remote I/O option permits concurrent use
of both communications ports. The Remote I/O port has the following
performance features:
•One-quarter rack slave device
•Three baud rates: 57.6k, 115.2k, 230.4k
•Cable lengths up to 3048 meters (10,000 feet)
•Node capacity up to 32 nodes
•Update rates for discrete I/O: 5 mSec
•Update rates for block transfers: 50 mSec minimum
•Two discrete inputs
•Eleven discrete outputs
•Read/Write block transfer data tables for access to all data

Publication 1404-UM001D-EN-E - October 2004
Product Description 2-7
DeviceNet Optional Communications
A catalog number ending in -DNT specifies a Powermonitor 3000 with
a DeviceNet port in addition to the native RS-485 port. The DeviceNet
option permits concurrent use of both communications ports. The
DeviceNet port has the following performance features:
•Adapter class device
•Four baud settings: 125k, 250k, 500k and AutoBaud
•Remotely settable baud rate
•Cable length up to 500 meters maximum
•Node capacity up to 64 nodes including master
•Remotely settable node address
•Shielded twisted-pair media containing both signal and power
conductors
•Update rates for I/O channel: 100 mSec minimum
•Update rates for explicit messaging: 250 mSec minimum
•Configurable I/O channel assembly instance: six parameters
default, twenty-three maximum
•Configurable explicit assembly instance: seventeen parameters
default, twenty-three parameters maximum
•Explicit assembly instances for access to all data
•Two I/O assembly instances
•May be reset remotely through Identity Object
•Support for up to four concurrent clients
•Supports DeviceNet heartbeat facility
Ethernet Optional Communications
A catalog number ending in -ENT specifies a Powermonitor 3000 with
one active 10BaseT Ethernet communication port in addition to the
native RS-485 port. The Ethernet port has the following performance
features:
•Connect to Allen-Bradley PLC-5E, SLC 5/05, ControlLogix
Ethernet Bridge and the 1761-NET-ENI module products
•Built-in Internet web page support
•Compatible with RSPower32, RSEnergyMetrix, RSView32 and
RSTrend™ software
•Ethernet communication rate: 10Mbps (Series A)
10/100Mbps (Series B)
Allen-Bradley HMIs

Publication 1404-UM001D-EN-E - October 2004
2-8 Product Description
•Compatible with commercially available network bridges,
routers, hubs and switches
•Fully software configurable
•Supports RSLinx (Series A emulates SLC 5/03+ with Ethernet;
Series B emulates a ControlLogix Ethernet Bridge)
•Supports Allen-Bradley Client Server Protocol (CSP)
•Supports EtherNet/IP (CIP) protocol
•Configurable I/O channel assembly instance: six parameters
default, twenty-three maximum
•Configurable explicit assembly instance: seventeen parameters
default, twenty-three parameters maximum
•Explicit assembly instances for access to all data
•Two I/O assembly instances
•Remotely resettable through Identity Object
•Supports up to 64 CIP/HTTP concurrent connections
•Data read latency: less than 10 mSec
•Update rates for real-time metering data: 100 mSec minimum
•Update rates for logged data: 250 mSec minimum
•Supports Allen-Bradley pass-thru communications
•Supports network-based time synchronization via SNTP
(Series B)
•Supports networked demand period synchronization (Series B)
•Supports Class 1 scheduled connection for I/O data (Series B)
ControlNet Optional Communications
A catalog number ending in -CNT specifies a Powermonitor 3000 with
a ControlNet communications interface in addition to the native
RS-485 port. The ControlNet interface has the following features:
•Adapter class device
•Supports redundant media or single media applications; physical
connections include NAP port and two BNC connectors
•ControlNet International conformace tested and approved
•Compatible with ControlLogix, PLC5, SLC, PanelView,
RSEnergyMetrix, RSPower32 and more
•All Powermonitor data readable/writable via unscheduled
(UCMM or Class 3) connection to Powermonitor assembly object
instances 3-64
