Allen-Bradley 140G-M-EXT3 User manual

140G-M-EXT3
140G-M-EXT4
140G-M-EXSLI3
140G-M-EXSLO3
140G-M-EXS4
3p 4p
Extended front terminals and spread extended front terminals for 140G-M
Terminali anteriori prolungati e terminali anteriori prolungati divaricati
Vorderseitige verlängerte Anschlüsse und vorderseitige verlängerte V-förmige Anschlüsse
Prises de raccordement avant prolongées et prises de raccordement avant prolongées écartées
Terminales frontales prolongados y terminales frontales prolongados separados
加长前接线端⼦ 和扩展加长前接线端⼦ 140G-M 固定式
Bul. 140G/140MG
DIR 1000479R0822 Version 01
WARNING: To prevent electrical shock, disconnect from power source before
installing or servicing. Install in suitable enclosure. Keep free from contaminants.
(Follow NFPA70E requirements).
AVVERTENZA: Per prevenire infortuni, togliere tensione prima dell'installazione o
manutenzione. Installare in custodia idonea. Tenere lontano da contaminanti.
(Seguire i requisiti NFPA70E).
WARNUNG: Vor Installations- oder Servicearbeiten Stromversorgung zur
Vermeidung von elektrischen Unfällen trennen. Die Geräte müssen in einem
passenden Gehäuse eingebaut und gegen Verschmutzung geschützt werden. (Befolgen
Sie die Anforderungen nach NFPA70E).
AVERTISSEMENT: Avant le montage et la mise en service, couper l'alimentation
secteur pour éviter toute décharge. Prévoir une mise en coffret ou armoire appropriée.
Protéger le produit contre les environnements agressifs. (Vous devez respecter la
norme NFPA70E).
ADVERTENCIA: Desconéctese de la corriente eléctrica, antes de la instalación o
del servicio, a fin de impedir sacudidas eléctricas. Instálelo en una caja apropiada.
Manténgalo libre de contaminantes. (Cumpla con los requisitos NFPA70E).
ATENÇÃO: Para evitar choques, desconectar da corrente elétrica antes de fazer a
instalação ou a manutenção. Instalar em caixa apropriada. Manter livre de
contaminantes. (Cumpra as exigências da norma NFPA70E).
Installation - Installazione - Instalación
Instalação - -
DIR 1000479R0822 Version 01 - 140G-M-EXT3, 140G-M-EXT4, 140G-M-EXSLI3, 140G-M-EXSLO4, 140G-EXS4
警告：感電事故防止のため、取付けまたは修理の際は電源から取り外してく
ださい。適切なケース内に取付けてください。また、汚染物質がないことを
確認してください。（NFPA70Eの要件に従ってください）
警告：为了防止触电，在安装或维修之前必须先切断电源。安装在合适的设备
箱内。防止接触污染 。符合NFPA70E要求）物

12
140G-M-ETX3
140G-M-ETX4
9 Nm
140G-M-EXSLI3
140G-M-EXSLO3
80 lb-in
CH 6
Installation of lower spread terminal not shown in illustration
DIR 1000479R0822 Version 01 (L5324) - B0908
Copyright © 2016 Rockwell Automation, Inc. All Rights Reserved. Printed in Italy.
Allen-Bradley, Rockwell Software, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Publication 140G-IN039B-MU-P - May 2016
Rockwell Automation maintains current product environmental compliance information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/
sustainability-ethics/product-environmental-compliance.page
9 Nm
80 lb-in
CH 6
3140G-M-EXS4
9 Nm
80 lb-in
CH 6
