Operation/Maintenance
Drying Tumblers
110 Pound Capacity
Part No. D0583
September 2007
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

i
Addendum A
Information in this manual is applicable to these models:
HD110
D0583

Page 1
For optimumefficiency andsafety, werecommend thatyou readthe manual beforeoperating theequipment. Storethis manualin afile
orbinder andkeep forfuture reference.
WARNING: For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion or to prevent property damage, personal injury, or death.
- Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or
any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliances.
• Do not touch any electrical switch; do not use any phone in your building.
• Clear the room, building, or area of all occupants.
• Immediately call your gas supplier from a neighbor's phone. Follow thegas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
WARNING: In the event the user smells gas odor, instructions on what to do must be posted in a
prominent location. This information can be obtained from the local gas supplier.
WARNING: Wear safety shoes to prevent injuries.
WARNING: Purchaser must post the following notice in a prominent location:
FOR YOURSAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING: A clothes dryer produces combustible lint and should be exhausted outside the
building. The dryer and the area around the dryer should be kept free of lint.
WARNING: Be safe, before servicing machine, the main power should be shut off.
WARNING: Purchaser must post the following notice in a prominent location:
IMPORTANT NOTES - PLEASE READ

Page 2
WARNING: To avoid fire hazard, do not dry articles containing foam rubber or similar texture materials.
Do not put into this dryer flammable items such as baby bed mattresses, throw rugs, undergarments
(brassieres, etc.) and other items which use rubber as padding or backing. Rubber easily oxidizes causing
excessive heat and possible fire. These items should be air dried.
WARNING: Synthetic solvent fumes from drycleaning machines create acids when drawn through the
dryer. These fumes cause rusting of painted parts, pitting of bright or plated parts, and completely
removes the zinc from galvanized parts, such as the tumbler basket. If drycleaning machines are in the
same area as the tumbler, the tumbler's make-up air must come from a source free of solvent fumes.
WARNING: Do not operate without guards in place.
WARNING: Check the lint trap often and clean as needed but at least a minimum of once per day.
WARNING: Alterations to equipment may not be carried out without consulting with the factory and
only by a qualified engineer or technician. Only Manufacturer’s parts may be used.
WARNING: Remove clothes from dryer as soon as it stops. This keeps wrinkles from setting in and
reduces the possibility of spontaneous combustion.
WARNING: Be safe - shut main electrical power and gas supply off externally before attempting
service.
WARNING: Never use drycleaning solvents, gasoline, kerosene, or other flammable liquids in the dryer.
FIREANDEXPLOSION WILLOCCUR. NEVERPUT FABRICSTREATEDWITH THESELIQUIDS
INTOTHEDRYER.NEVERUSETHESELIQUIDSNEARTHEDRYER.
WARNING: Do not place items exposed to cooking oils in your dryer. Items contaminated
with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.
WARNING: Never let children play near or operate the dryer. Serious injury could occur if a child
should crawl inside and the dryer is turned on.
WARNING: Never tumble fiberglass materials in the dryer unless the labels say they are machine
dryable. Glass fibers break and can remain in the dryer. These fibers cause skin irritation if they
become mixed with other fabrics.
WARNING: Before operating gas ignition system - purge air from natural gas or propane gas lines
per manufacturer’s instructions.
WARNING: To reduce the risk of electric shock, disconnect this appliance from the power supply
before attempting any user maintenance other than cleaning the lint trap. Turning the controls to the
OFF position does not disconnect this appliance from the power supply.
IMPORTANT NOTES - PLEASE READ

Page 3
AVERTISSEMENT. Assurez-vousdebien
suivre les instructions donnees dans cette
notice pour reduire au minimum le risque
d’incendie ou d’explosion ou pour eviter tuot
dommage materiel, toute blessure ou la mort.
__ Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
apparell.
__ QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
•Ne pas tenter d’allumer d’apparell.
• Ne touchez a aucun interrupteur. Ne pas
vous servir des telephones se trouvant dans
le batiment ou vous vous trouvez.
• Evacuez la piece, le batiment ou la zone.
•Appelez immediatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
•Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
__ l’installation et l’entretien doivent etre assures
par un installateur ou un service d’entretien
qualifie ou par le fournisseur de gaz.
ATTENTION:L’ACHETEUR DOIT PLACER L’AVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
ATTENTION:L’ACHETEUR DOIT PLACER L’AVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
POUR VOTRE SECURITE
Ne pas entreposer ni utiliser d’ essence
ni d’autres vapeurs ou liquides
inflammables dans le voisinage de cet
appareil ou de tout autre appareil.
IMPORTANT NOTES - PLEASE READ

Page 4
PAGE
ImportantNotices..............................................................................................................1-3
TableofContents ................................................................................................................. 4
CustomerService ................................................................................................................. 5
Warnings, Symbols ...........................................................................................................6-7
RulesforSafeOperationofDryer ......................................................................................... 8
EnergySavingTips ............................................................................................................... 9
OperatingInstructions-TwoTimerModels ....................................................................10-12
ServiceSavers.................................................................................................................... 13
TroubleshootingCharts ..................................................................................................14-16
Direct-SparkIgnitionOperation .....................................................................................17-18
GeneralMaintenance .......................................................................................................... 19
BurnerAirInletAdjustment ................................................................................................ 20
BasketAlignment(TM200GearReducer) .....................................................................21-22
BasketAlignment(GearMotor) .......................................................................................... 23
ShimmingtheBasketandSpiderAssembly ......................................................................... 24
AirSwitchAdjustment ........................................................................................................ 25
DryerswithReversingControlTimer..............................................................................26-27
LargeGearReducerMaintenance ....................................................................................... 28
TABLE OF CONTENTS
(C)CopyrightAllianceLaundrySystemsLLC
Allrightsreserved.Nopartofthecontentsofthisbookmaybereproducedortransmittedinanyformorbyanymeans
withouttheexpressedwrittenconsentofhepublisher.

Page 5
Ifliteratureorreplacementpartsarerequired,contactthesourcefromwhich
themachinewaspurchasedorcontactAllianceLaundrySystemsat(920)748-
3950forthenameandaddressofthenearestauthorizedpartsdistributor.
Fortechnicalassistance,call(920)748-3121.
CUSTOMERSERVICE

Page 6
Thefollowingsymbolsareusedinthismanualand/oronthemachine.
Symbol Description
NOTE!
on
marche
Ein
conectado
off
arrêt
Aus
desconectado
Hot! DoNotTouch
Heiß! NichtBeruhren
Hautetemperature!Nepas
toucher
Caliente! notocar
start
demarrage
Start
arranquedeunmovimiento
emission of heat in general
êmissiondechaleuren
general
Warmeabgabeallgemein
emisióndecalor
cooling
refroidissement
Kühlen
enfriamiento
dangerousvoltage
tensiondangereuse
Gefährlicheelektrische
Spannung
tension peligrosa
SYMBOLS

Page 7
rotationintwodirections
rotationdanslesdeuxsens
DrehbewigunginzweiRichtungen
movimientorotativoenlosdos
sentidos
End of Cycle
caution
attention
Achtung
atencion;precaucion
directionofrotation
sensdemouvementcontinuderotation
DrehbewegunginPfeilrichtung
movimientogiratorioorotatorio
en el sentido de la flecha
Symbol Description
SYMBOLS

Page 8
RULES FOR SAFE OPERATION OF DRYER
RULESFORSAFE
OPERATIONOFDRYER 1. Be sure your dryer is installed properly in accordance with the
recommendedinstructions.
2. CAUTION
Be safe—shut main electrical power supply and gas supply off
externallybeforeattemptingservice.
3. CAUTION
Never use drycleaning solvents: gasoline, kerosene, or other
flammable liquids in the dryer. Fire and explosion will
occur.
Never put fabrics treated with these liquids into the dryer.
Never use these liquids near the dryer.
Always keep the lint screen clean.
Never use heat to dry items that contain plastic, foam or
sponge rubber, or rags coated with oils, waxes or paints. The
heat may damage the material or create a fire hazard. Rubber
easily oxidizes, causing excessive heat and possible fire.
Never dry the above items in the dryer.
4. Never let children play near or operate the dryer. Serious
injury will occur if a child should crawl inside and the dryer
is turned on.
5. Never use dryer door opening and top as a step stool.
6. Readandfollow manufacturer'sinstructionson packages of
laundry and cleaning aids. Heed any warnings or precautions.
7. Nevertumble fiberglass materials in the dryer unless the
labels say they are machine dryable. Glass fibers break and
can remain in the dryer and could cause skin irritation if they
become mixed into other fabrics.
8. Reference
Lightingandshut-downinstructionsandwiringdiagramsare
located on the rear wall of the dryer cabinet.
9. The dryer must not be installed or stored in an area where it
will be exposed to water and/or weather.

Page 9
ENERGY SAVING TIPS
ENERGYSAVINGTIPS
ABOVE2,000FEET
(610 M)
1. Installdryerso that youcanuse short, straightventing.
Turned elbows and long vent tubing tend to increase drying
time.Longerdryingtimemeanstheuseofmoreenergyand
higheroperatingcosts.
2. Operate dryer using full-size loads. Very large loads use
extra energy. Very small loads waste energy.
3. Dry light-weight fabrics separately from heavy fabrics. You
will use less energy and get more even drying results by
drying fabrics of similar weight together.
4. Clean the lint screen area daily. A clean lint screen helps
give faster, more economical drying.
5. Do not open the dryer door while drying. You let warm air
escape from the dryer into the room.
6. Unload the dryer as soon as it stops. This saves having to re-
start your dryer to remove wrinkles.
NOTE
It is best to run a properly sized bag of rags and/or old
towels through one or two cycles prior to drying in service.
Thisprocess willremove anyfilms orresidualcoatings left
bythemanufacturingprocess.
CAUTION
Syntheticsolventfumesfromdrycleaningmachinescreate
acids when drawn through the dryer. These acid fumes
causerustingofpaintedparts,pittingofbrightplatedparts
and completely removes the zinc from galvanized metal
parts,such asthe tumblerbasket.
If the dry cleaning machines are in the same area as the
tumbler, then the tumbler make-up air must come from a
source free of solvent fumes.
ELEVATIONSABOVE 2,000FEET(610 M)
Input ratings shown on the rating plate (serial tag) are for elevations
up to 2,000 feet (610 m). For elevations above 2,000 feet (610 m),
rating should be reduced at a rate of 4% for each 1,000 feet (305 m)
above sea level.

Page 10
OPERATING INSTRUCTIONS—TWO TIMER MODELS

Page 11
OPERATING INSTRUCTIONS—TWO TIMER MODELS
OPERATINGINSTRUCTIONS—TWOTIMERMODELS
1. After loading the dryer with the water washed clothes load,
close the loading door. For better drying, do not load dryer
withcombinationofgarmentsthattwist.
2. Turnthe60-minutedryingtimertothedesireddryingtime.
The drying cycle light will be on and indicate the drying. The
light shuts off when drying time is complete. (figure 1 on
page10.)
3. Turn the 15-minute cooling cycle timer to the desired cool
down time. After the drying cycle is completed, then the
cooling cycle time will automatically operate. The cooling
light will be on and indicate the cooling of the clothes load.
The light shuts off when cooling time is completed. (figure 1
onpage11.)
4. Temperature Selector—Select temperature per type of load
beingdriedinthedryer.
High Heat—Mixed and heavy fabrics, set dial to 195°F
(77°C).
Normal—Cottons and linens, set dial to 170°F (77°C).
PermanentPressHeat—Polyknitsynthetics,blends, light-
weight fabrics, set dial to 150°F (66°C).
Low Heat—Delicate, sheer fabrics, easy-to-dry, set dial to
135°F (58°C).
5. Thermometer—Usethiswithyourtemperatureselection.
Note what temperature is too hot or too cold. (figure 3 on
page10.)
6. Turnswitchto“ON”or“I”position.(figure1on
page10.)
7. Close the dryer door, but the basket will not rotate until the
PUSH-TO-START BUTTON is pressed. Press in the
PUSH-TO-STARTBUTTON(approximately 2seconds)
untilthe dryer starts runningandthenrelease button. (figure 1
onpage10.)
OPERATING
INSTRUCTIONS—
TWOTIMERMODELS

Page 12
OPERATING INSTRUCTIONS—TWO TIMER MODELS
OPERATING
INSTRUCTIONS—
TWOTIMERMODELS
OPERATINGINSTRUCTIONS—TWOTIMERMODELS
(continued)
Whatishappeningtothedryingoperation:
a. The fan motor will operate.
b. The basket will rotate.
c. The heat source will be energized.
d. The heated air will mix with the water washed
clothestoevaporatethemoisturefromthegarments.
e. The thermostats willfunctionto maintain asafe
temperaturethroughoutthedryingcycle.
f. The heat will be shut off and the motor will continue
to run to cool the dry load to a desired handling
temperature.
8. Whenthedrying timer completesitstime,thenthecooling
timer will be energized and the cooling light will be “On”.
Whenthe cooling timer completesitstime,the cooling light
will turn “Off” and the “End-of-Cycle” light will be “On”.
The “End-of-Cycle” light will go off when the “Start/Stop”
switch is turned to “Off” or “O”. At the end of the cool-down
cycle, the clothes load is dry.
9. To shut the dryer “Off”, move the “Start/Stop” switch to
“Off” or “O” position. This switch is a safety switch to
immediately stop the dryer's operation.
SpecialReversingFeature—Setthe “Reversing/Non-
reversing” switch to “Reversing”. See service manual for
setting of time of each reversal. Reversing of the basket is
designed for loads that twist (example—bed sheets and large
mixed loads). “Non-reversing” is for small or medium-size
itemsthat don't twist.

Page 13
To help you troubleshoot the dryer, listed below are the most
common reasons for service calls and some answers to the
problems. Before you call service, please review the following
items:
1. Is the door completely closed?
2. Are the controls set to the “ON” or “I” position?
3. Did you push the “start”control?
4. Has a fuse blown or a circuit breaker tripped?
5. Arethefusestight?
6. Check for low voltage.
1. Isthedryer set for“coolingtime”rather than“drying
time”?
2. Are the gas valves in the dryer and the valve on the main gas
lineturnedon?
3. Check for low or intermittant gas pressure.
1. Timed cycle—Did you allow enough heating time before the
cool-down part of the cycle?
2. Is the lint screen blocked?
3. Is the exhaust duct to the outside clean and not blocked?(A
blocked exhaust will cause slow drying and other
problems.)
The dryer has a safety device which automatically shuts off the gas
if the burner fails to light in a short time. If this happens, turn the
dryer off. Check and see if the manual gas valve is open. Wait 5
minutes for the safety device to reset. Then reset the dryer controls.
If the dryer still fails to heat, call for service. All panels, covers and
doors must be in place and closed before starting the dryer.
VERYIMPORTANT
When calling the factory for service, always refer to the
modelnumberandserialnumber.
SERVICE SAVERS
TROUBLESHOOTING
DRYERWON’TSTART
DRYERWON’THEAT
CLOTHESARENOT
SATISFACTORILYDRY
GASDRYERIGNITION

Page 14
TROUBLESHOOTING CHART
TROUBLE CAUSE REMEDY
Check fuses on circuit breakers. Make sure main control
switch is ON.
Check power source; voltage, phase and frequency must
be the same as specified on electrical rating plate.
Turn timer clockwise to desired time setting.
Check wire connections in electrical box on rear of dryer.
Check coils and contacts.
Check voltage at motor terminals. Voltage must be within
+ 10% of voltage shown on motor rating plate. If not,
Check with local power company for recommended
corrective measures.
Check with local power company to insure that wiring is
adequately sized for load.
Check all electrical connections and tighten any loose
connections.
Check Installation sheet in service section for
recommended make-up air openings.
Clean lint accumulation on and around motors.
Close door.
Adjust switch by removing cover and bend actuator lever to
clear switch button 3/8" (10 mm) with cover in place.
Replace switch.
Replace contactor.
Replace V-belt.
Adjust belt tension.
Tighten set screw.
Remove load.
Check Installation Manual for proper leveling procedures.
Accidental damage to the fan blade can change the dynamic
balance. Damaged fans should be replaced.
Adjust basket clearance.
Tighten set screws. Make sure sheaves are in proper
alignment.
Adjust belt tension.
Occcasionally screws, nails, etc., will hang in the basket
perforations and drag against the sweep sheets surround-
ing the basket. Such foreign objects should be removed
immediately.
No power.
Incorrect power.
Time off.
Loose wiring
connections.
Defective starting
relay.
Low voltage.
Inadequate wiring.
Loose connections.
Inadequate air.
Poor housekeeing.
Loading door
OPEN.
Door switch out of
adjustment.
Defective door
switch.
Defective basket
motor contractor.
V-belt broken.
V-belt loose.
Motor pulley loose.
Basket overloaded.
Not leveled.
Fan out of balance.
Basket rubbing.
V-belt sheaves.
Belt.
Foreign objects.
Motor will not start.
Motor tripping on thermal
overload.
Basket motor will not run.
Motor runs, but basket will
not revolve.
Dryer noisy or vibrating.

Page 15
Check for correct control voltage - 24V.
Check power supply, check secondary voltage on trans-
former and check wiring and wiring diagram.
Close lint door.
Replace valve assembly.
Turn manual gas valve on.
Replace fuse.
Replace door switch.
Check ground.
Clean out lint compartment daily. Check back draft damper
for foreign objects, lint accumulation or other causes that
may prevent damper from operating. Check duct work for
lint build-up. Check installation sheet to insure that duct
work and make-up air openings are adequately sized. Check
exhaust outlet. If a screen has been improperly installed on
the outlet, it may be clogged with lint or frozen over in
winter. Never install a screen on the exhaust outlet. Vacuum
within dryer drops to .09 inches or water column, or less, for
normal operation of dryer, vacuum reading can be made with
a vacuum U-Gauge by removing a sheet metal screw in the
front panel of dryer, and inserting the rubber tube of the
vacuum gauge into screw opening.
See Air Switch Adjustment Sheet in Service Manual.
Replace air switch.
Check manifold pressure and adjust to pressure specified on
rating plate. If this pressure cannot be obtained, have gas
supplier check main pressure.
Dryer is orificed for type of gas specified on rating plate.
Check with gas supplier to determine specifications for gas
being used. If different from rating plate, contact factory and
obtain proper orifices.
Turn power ON.
Replace relay.
Replace thermostat.
Replace thermostat.
Open door.
Incorrect voltage.
No voltage.
Lint door open.
Defective gas valve.
Gas turned off.
Line fuse or heater
circuit fuse blown to
unit.
Defective door
switch.
Spark igniter not
igniting gas.
Air switch not
operating.
Air switch out of
adjustment.
Air switch defective.
Gas pressure too low.
Improper orifice.
Electric power to
heating unit turned
off.
Defective relay.
Defective
thermostat.
Defective safety
overload
thermostat.
Lint compartment
door open.
TROUBLE CAUSE REMEDY
Dryer runs, but no heat.
TROUBLESHOOTING CHART

Page 16
Blow out.
Adjust gas pressure per rating plate.
Send to factory for correct orifices.
Clean exhaust.
Check ground.
Replace orifices. Check factory for correct size.
Replace orifices. Check factory for correct size.
Make-up air must be 4 to 6 times the exhaust area of the
dryer.
Remove lint.
Must be full open or replace.
Adjust gas pressure as specified on rating plate.
Check Service section for recommended sizes. Remove
obstructions or lint build up from duct work. NEVER use
smaller size exhaust duct. ALWAYS use larger size.
Replace thermostat.
Replace timer.
Check all valves in steam supply and return. Make sure
they are OPEN.
Remove and clean. Replace if defective.
On dryers using solenoid temperature control, thermostat
controls operation of solenoid valve by advancing
thermostat.
On dryers using solenoid temperature control, thermostat
controls operation of solenoid valve. If defective, replace
thermostat.
Check for inlet and outlet marking on check valve and invert
if neccessary.
Remove plug and blow down strainer or remove and clean
thoroughly if heavily clogged.
Check piping per steam installation instructions.
Check trap for size and capacity. If dirty and sluggish,
clean thoroughly or replace. Check return line for high
back pressure, or another trap charging against the trap
functioning improperly.
Main burners burning
improperly.
Main burner cycles on and
off.
Low or high gas flame.
Dryer too hot.
Dryer does not stop at end
of time period (6).
Dryer runs no steam to
coils.
Water in steam line.
TROUBLE CAUSE REMEDY
Dirt in burner.
High gas pressure.
Orifice too large.
Restricted or blocked
exhaust.
Defective ground.
Incorrect main
burner orifices.
Incorrect main
burner orifice.
Inadequate make-up
air.
Lint accumulated.
Exhaust duct
dampers.
High gas pressure.
Partially restricted or
inadequately sized
exhaust system.
Defective thermostat.
Defective timer.
Valve closed.
Steam trap blocked.
Solenoid valve.
Thermostat.
Check valve installed
incorrectly.
Strainer clogged.
Steam piping in-
stalled incorrectly.
Trap not functioning.
TROUBLESHOOTING CHART

Page 17
NOTE: Some models are equipped with a dual ignition system.
The dual ignition system contains two direct spark
ignition modules in parallel. Each module has its own
flame sense circuit and acts independently of the other.
If either bonnet limit thermostat opens because of high
heat or flame impingement, the entire ignition system
will shut down.
1. When a call for heat is received from the control supplying
24VAC to the ignition control module, the pre-purge delay
timer begins. This delay time allows any air/sediment to be
ejected prior to burner ignition. Following the pre-purge delay
period, the gas valve is energized and the spark ignitor sparks
for the trial for ignition period.
2. When a flame is detected during the trial for ignition period, the
spark ignitor shuts off and the gas valve remains energized.
3. If no flame is detected by the flame sense circuit, the ignition
control module will go into safety lockout. The valve will be
turned off immediately. If the module has multiple retries and
no flame is detected, the gas valve is de-energized and the
module goes into an interpurge delay. After this delay, the
module will attempt another trial for ignition period. This will
continue until the number of retries has been used up. At that
time, the module will go into safety lockout.
4. Recovery from safety lockout requires one of the following:
a. A manual reset by opening and closing the loading door.
b. After one hour if the control thermostat is still calling for
heat, the module will automatically reset and the trial for
ignition period will start over.
5. Opening the loading door will cause the flame to extinguish.
Closing the door and starting the dryer will restart the trial for
ignition period.
6. Once the control thermostat has been satisfied and/or the
drying timer has been timed out, the ignition control
module(s) will be de-energized, the gas valve(s) will be de-
energized and the flames will extinguish.
7. The machine will continue to run in a cooldown mode without
heat. This process will cool the load to the touch and help to
eliminate wrinkling.
DIRECT-SPARK IGNITION OPERATION
DIRECTSPARK
IGNITION
OPERATION
