Alliance Laundry Systems T453I Troubleshooting guide

Operation/Maintenance/Programming
www.comlaundry.com
Drying Tumblers
Refer to Page 3 for Model Numbers
START
25
C
HIGH
TEMP
MED
TEMP
LOW
TEMP
NO
HEAT
123
SELECT
TEMP
INSERT
COIN
PUSH
START
123
SELECT
TEMP
INSERT
COIN
PUSH
START
START
25
C
HIGH
TEMP
MED
TEMP
LOW
TEMP
NO
HEAT
T477C
T478C
T433I
NOTA: El manual en
españolaparecedespués
del manual en inglés.
Part No. M414462R1
March 2001
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

M414462 1
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
In the U.S.A., installation must conform to the latest edition of the American National Standard Z223.1
“National Fuel Gas Code”and Standard ANSI/NFPA 70 “National Electric Code”.
In Canada, installation must comply with Standards CAN1-B149.1 or CAN1-B149.2 codes for gas burning
appliances and equipment and CSA C22.1, latest edition, Canadian Electric Code, Part I.
In Australia, installation must comply with the Australian Gas Association Installation Code for Gas
Burning Appliances and Equipment.
IMPORTANT: Information must be obtained from a local gas supplier on instructions to be followed if the
user smells gas. These instructions must be posted in a prominent location.
Step-by-step instructions of the above safety information must be posted in a prominent location near the
tumbler for customer use.
FOR YOUR SAFETY, the information in this
manual must be followed to minimize the
risk of fire or explosion or to prevent
property damage, personal injury or death.
W033
• Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
– Do not try to light any appliance.
– Do not touch any electrical switch; do
not use any phone in your building.
– Clear the room, building or area of all
occupants.
– Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
– If you cannot reach your gas supplier,
call the fire department.
• Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
W052
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
W053
WARNING
POUR VOTRE SÉCURITÉil est impératif de
suivre les instructions de ce manuel pour
minimiser les risques d’incendie ou
d’explosion et pour éviter les dommages
matériels, les blessures corporelles ou la
mort.
W033Q
•Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides
inflammables dans le voisinage de cet
appareil ou de tout autre appareil.
•QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ :
–Ne pas tenter d’allumer d’apareil.
–Ne touchez àaucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment oùvous vous
trouvez.
–Évacuez la pièce, le bâtiment ou la
zone.
–Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
–Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
•L’installation et l’entretien doivent être
assurés par un installateur ou un service
d’entretien qualifiéou par le fournisseur
de gaz.
W052Q
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables
dans le voisinage de cet appareil ou de
tout autre appareil.
W053Q
MISE EN GARDE

2M414462
© Copyright 2001, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Table of
Contents
Introduction......................................................................................... 3
Model Identification ............................................................................. 3
Customer Service.................................................................................. 4
Wiring Diagram.................................................................................... 4
Nameplate Location.............................................................................. 5
Safety Information.............................................................................. 7
Important Safety Instructions ............................................................... 8
Operating Instructions ....................................................................... 11
Step 1: Clean Lint Screen/Compartment.............................................. 11
Step 2: Load Laundry ........................................................................... 11
Step 3: Determine Required Temperature ............................................ 11
Step 4: Determine Control Type........................................................... 11
Manual Timer Tumblers .................................................................. 12
Electro-Mechanical Coin Control Tumbler ..................................... 13
NetMaster Coin Control................................................................... 14
NetMaster Card Control................................................................... 15
Electronic OPL Control ................................................................... 16
Electronic Coin Control ................................................................... 17
Reversing Operation ........................................................................ 18
Reverse Control Switch ................................................................... 18
Programming the Electronic OPL Control...................................... 19
Signal .................................................................................................... 20
Reversing .............................................................................................. 20
Status Lights ......................................................................................... 20
Automatic Dry and Condition Mode.................................................... 21
Time Dry and No Heat Modes.............................................................. 22
Custom.................................................................................................. 23
Custom Cycle Record ..................................................................... 23
Special Cycle Mode.............................................................................. 24
Special Time Mode............................................................................... 24
Security Lock-Out ................................................................................ 24
Show Mode........................................................................................... 24
Temperature Sensor.............................................................................. 25
Temperature Adjustment ...................................................................... 25
Temperature Display (°F/°C)................................................................ 25
Cylinder Temperature Display ............................................................. 25
Maintenance ........................................................................................ 27
Daily ..................................................................................................... 27
Monthly................................................................................................. 28
Every Three Months ............................................................................. 29
Every Six Months ................................................................................. 29
Before You Call for Service ............................................................... 31

3
M414462 © Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Introduction
Model Identification
Information in this manual is applicable to these
models: †
†Includes models with MT, EC, OM, CD, RM, EP, CX, CY, EX, EY, NX, NY, ZC, ZR, ZX, ZY, NC and NR
control suffixes.
Gas Steam Electric/Other
25 Pound
(220 Liter)
DT0220SFG DT0220SRG DT0220SSH DT0220SSL DT0220SEL DC0220SEL
JT0220SFG JT0220SRG JT0220SSH JT0220SSL JT0220SEL JC0220SEL
ST0220SFG ST0220SRG ST0220SSH ST0220SSL ST0220SEL SC0220SEL
DC0220SFG DC0220SRG DC0220SSL JC0220SSL
JC0220SFG JC0220SRG SC0220SSL
SC0220SFG SC0220SRG
Stacked
30 Pound
(300 Liter)
DT0300DFG DT0300DRG DT0300DSH DT0300DSL DT0300DEL DC0300DEL
JT0300DFG JT0300DRG JT0300DSH JT0300DSL JT0300DEL JC0300DEL
ST0300DFG ST0300DRG ST0300DSH ST0300DSL ST0300DEL SC0300DEL
DC0300DFG DC0300DRG DC0300DSL JC0300DSL
JC0300DFG JC0300DRG SC0300DSL
SC0300DFG SC0300DRG
NT0300DRG
30 Pound
(270 Liter)
DT0270SFG DT0270SRG DT0270SSH DT0270SSL DT0270SEL DC0270SEL
JT0270SFG JT0270SRG JT0270SSH ST0270SSL JT0270SEL JC0270SEL
ST0270SFG ST0270SRG ST0270SSH DC0270SSL ST0270SEL SC0270SEL
DC0270SFG DC0270SRG JC0270SSL SC0270SSL
JC0270SFG JC0270SRG JT0270SSL
SC0270SFG SC0270SRG
35 Pound
(350 Liter)
DT0350SFG JT0350SRG DT0350SSH JT0350SSL DT0350SEL DC0350SEL
JT0350SFG ST0350SRG JT0350SSH ST0350SSL JT0350SEL JC0350SEL
ST0350SFG DC0350SRG ST0350SSH DC0350SSL ST0350SEL SC0350SEL
DC0350SFG JC0350SRG DT0350SSL JC0350SSL
JC0350SFG SC0350SRG SC0350SSL AT0350SSL
SC0350SFG AT0350SRG
DT0350SRG

Introduction
M414462
4© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Information in this manual is applicable to these
models: †
†Includes models with MT, EC, OM, CD, RM, EP, CX, CY, EX, EY, NX, NY, ZC, ZR, ZX, ZY, NC and NR
control suffixes.
Customer Service
If literature or replacement parts are required, contact
the source from whom the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
For technical assistance, call [phone].
Wiring Diagram
The wiring diagram is located in the literature packet
supplied with all the non-European models. On
European models, it is located in the junction box.
The wiring diagram is inside the electrical junction
boxes located on the back of 0300D models, or under
the front control panel on 0220S, 0270S, and 0350S
models.
Gas Steam Electric/Other
50 Pound
ATB50CG DTB50EG STB50CSH STB50CSL STB50CE JCB50CE
STB50CG JTB50EG JTB50CSH JTB50CSL JTB50CE SCB50CE
DTB50CG JT50EG DTB50CSH DTB50CSL DTB50CE JC50CE
JTB50CG JC50EG JT50CSH JT50CSL JT50CE DCB50CE
JT50CG JCB50EG JCB50CSH SCB50CSH SC50CE SCB50AT
JC50CG SC50EG JC50CSH DCB50CSH
JCB50CG SCB50EG ATB50CSH
SC50CG DCB50CG
SCB50CG DCB50EG
STB50EG
75 Pound
STB75CG DTB75EG STB75CSH JTB75CSL STB75CE JCB75CE
DTB75CG JTB75EG JTB75CSH DTB75CSL JTB75CE SCB75CE
JTB75CG JT75EG DTB75CSH JT75CSL DTB75CE ST75CE
ATB75CG STB634 JT75CSH DCB75CSH JT75CE JC75CE
JT75CG DCB75CG ATB75CSH JCB75CSH DCB75CE SC75CE
DTB634 JCB75CG STB75CSL SCB75CSH
STB75EG SCB75CG SCB75CSL JCB75CSL
DCB75CSL
120 Pound
ST120FG JC120FG ST120CSH JC120CSH ST120AT SC120AT
JT120FG DC120FG JT120CSH DC120CSH
DT120FG AT120FG DT120CSH AT120CSH
SC120FG SC120CSH
170 Pound
ST170FG SC170FG ST170CSH SC170CSH
Not Applicable
JT170FG AT170FG JT170CSH AT170CSH
JC170FG DT170FG JC170CSH DT170CSH
DC170FG DC170CSH

Introduction
5
M414462 © Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Nameplate Location
When calling or writing for information about your
product, be sure to mention model and serial numbers.
Model and serial numbers are located on the
nameplate as shown. The model number may also be
found inside the door.
Figure 1
1Nameplate
MODEL NO:
SERIAL NO:
V-/ HERTZ/ PHASE
AMPS, WIRES + GROUND
TOTAL kW, MOTOR kW
REQ'D CIRCUIT BREAKER: AMPS
FAN OUTPUT:
@MAX "WC STATIC PRESSURE
EQUIPPED FOR: GAS@ "WC MANIFOLD PRESS.
MIN SUPPLY
PRESSURE:
ANS 72152
CLOTHES DRYER.
VOL II
CGA 72
AMPLFIEDRER
TESTED FOR NATURAL &
LIQUID PETROLEUM GASSES
MAX SUPPLY
PRESSURE:
"WC. "WC.
INPUT: BTU/hr @ BTU/cu.ft.
MADE IN U.S.A./FABRIQUE AU ETATS UNIS/FABRICADO EN LOS ESTADOS UNIDOS 70051001
T448I
MODEL NO:
SERIAL NO:
T453I
120 POUND TUMBLER
1
1
50 AND 75 POUND TUMBLERS
170 POUND TUMBLER
1
0220S, 0270S, 0350S 0300D

M414462
6© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Notes

7
M414462 © Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Safety Information
Precautionary statements (“CAUTION,”
“WARNING,”and “DANGER”), followed by specific
instructions, are found in this manual and on machine
decals. These precautions are intended for the personal
safety of the operator, user, servicer, and those
maintaining the machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT”is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE”is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
IMPORTANT: Warranty is void unless drying
tumbler is installed according to instructions in this
manual. Compliance with minimum specifications
and requirements detailed herein, and with
applicable local gas fitting regulations, municipal
building codes, water supply regulations, electrical
wiring regulations, and any other relevant
statutory regulations. Because of varied
requirements, applicable local codes should be
thoroughly understood and all pre-installation
work arranged for accordingly.
NOTE: The WARNING and IMPORTANT
instructions appearing in this manual are not meant
to cover all possible conditions and situations that
may occur. It must be understood that common
sense, caution and carefulness are factors which
CANNOT be built into this tumbler. These factors
MUST BE supplied by the person(s) installing,
maintaining or operating the tumbler.
Always contact your dealer, distributor, service agent
or the manufacturer on any problems or conditions you
do not understand.
DANGER indicates the presence of a
hazard that will cause severe personal
injury, death, or substantial property
damage if the danger is ignored.
DANGER
WARNING indicates the presence of a
hazard that can cause severe personal
injury, death, or substantial property
damage if the warning is ignored.
WARNING
CAUTION indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
Failure to install, maintain, and/or operate
this machine according to manufacturer’s
instructions may result in conditions which
can produce serious injury, death and/or
property damage.
W051
WARNING

Safety Information
M414462
8© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT
Important Safety Instructions
1. Read all instructions before using the tumbler.
2. Refer to the GROUNDING INSTRUCTIONS
for the proper grounding of the tumbler.
3. Do not dry articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry cleaning solvents, or other
flammable or explosive substances as they give
off vapors that could ignite or explode.
4. Do not allow children to play on or in the
tumbler. Close supervision of children is
necessary when the tumbler is used near children.
This is a safety rule for all appliances.
5. Before the tumbler is removed from service or
discarded, remove the door to the drying
compartment and the door to the lint
compartment.
6. Do not reach into the tumbler if the cylinder is
revolving.
7. Do not install or store the tumbler where it will
be exposed to water and/or weather.
8. Do not tamper with the controls.
9. Do not repair or replace any part of the tumbler,
or attempt any servicing unless specifically
recommended in the User-Maintenance
instructions or in published user-repair
instructions that you understand and have the
skills to carry out.
10. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
11. To reduce the risk of fire, DO NOT DRY plastics
or articles containing foam rubber or similarly
textured rubberlike materials.
12. Always clean the lint filter daily.
13. Keep area around the exhaust opening and
adjacent surrounding area free from the
accumulation of lint, dust, and dirt.
14. The interior of the tumbler and the exhaust duct
should be cleaned periodically by qualified
service personnel.
15. If not installed, operated and maintained in
accordance with the manufacturer’s instructions
or if there is damage to or mishandling of this
product’s components, use of this product could
expose you to substances in the fuel or from fuel
combustion which can cause death or serious
illness and which are known to the State of
California to cause cancer, birth defects or other
reproductive harm.
16. Tumbler will not operate with the loading door
open. DO NOT bypass the door safety switch to
permit the tumbler to operate with the door open.
The tumbler will stop tumbling when the door is
opened. Do not use the dryer if it does not stop
tumbling when the door is opened or starts
tumbling without pressing or turning the START
mechanism. Remove the tumbler from use and
call the service person.
17. Tumbler will not operate with lint panel open.
DO NOT bypass lint panel safety switch to
permit the tumbler to operate with the lint panel
open.
18. Do not put articles soiled with vegetable or
cooking oil in the tumbler, as these oils may not
be removed during washing. Due to the
remaining oil, the fabric may catch on fire by
itself.
19. To reduce the risk of fire, DO NOT put clothes
which have traces of any flammable substances
such as machine oil, flammable chemicals,
thinner, etc. or anything containing wax or
chemicals such as in mops and cleaning cloths, or
anything dry-cleaned at home with dry-cleaning
solvent in the tumbler.
20. Use the tumbler only for its intended purpose,
drying water-washed fabrics.
21. ALWAYS disconnect the electrical power to the
tumbler before servicing. Disconnect power by
shutting off appropriate breaker or fuse.
22. Install this tumbler according to these
INSTALLATION INSTRUCTIONS. All
connections for electrical power, grounding, and
gas supply must comply with local codes and be
made by licensed personnel when required. Do
not do it yourself unless you know how!
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your tumbler, follow these basic
precautions:
W054
WARNING
