Alliance Laundry Systems F232182R1 Owner's manual

www.comlaundry.com
Programming
Washer-Extractors
Pocket Hardmount
Vari a b le - S pee d
V-Series Microcomputer
Refer to Page 9 for Model Identifiction
Part No. F232182R1
March 2006
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2006, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
F232182 1
Table of
Contents
Safety.................................................................................................... 3
Key to Symbols..................................................................................... 4
Operator Safety..................................................................................... 6
Safe Operating Environment ................................................................ 6
Environmental Conditions ............................................................... 6
Machine Location ............................................................................ 7
Input and Output Services................................................................ 7
AC Inverter Drive ............................................................................ 8
Misuse................................................................................................... 8
Introduction......................................................................................... 9
Model Identification ............................................................................. 9
Customer Service.................................................................................. 9
Machine Familiarization Guide ............................................................ 11
Programming ...................................................................................... 13
Key Functions in Program Mode.......................................................... 13
Setup Mode........................................................................................... 13
Degrees Displayed in Fahrenheit or Celsius.................................... 14
Procedure for Temperature Calibration ........................................... 14
Auxiliary Heat.................................................................................. 15
Supply 5 or Auxiliary Fill................................................................ 15
Temperature-Controlled Fill ............................................................ 15
Automatic Cool-Down..................................................................... 15
Cycle Count .......................................................................................... 15
Cycle Programming .............................................................................. 15
Cycle Options................................................................................... 16
Segment Programming..................................................................... 16
Test Cycle ............................................................................................. 19
Cycle Segment Charts........................................................................... 21
V-Computer Cycle Charts .................................................................... 25
Cycle Programming Worksheet............................................................ 31

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
2F232182

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 3
F232182
Safety
Anyone operating or servicing this machine must
follow the safety rules in this manual. Particular
attention must be paid to the CAUTION, WARNING,
and DANGER blocks which appear throughout the
manual.
The following warnings are general examples that
apply to this machine. Warnings specific to a particular
operation will appear in the manual with the
discussion of that operation.
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Dangerous voltages are present in the
electrical control box(es) and at the motor
terminals. Only qualified personnel
familiar with electrical test procedures,
test equipment, and safety precautions
should attempt adjustments and
troubleshooting. Disconnect power from
the machine before removing the control
box cover, and before attempting any
service procedures.
SW005
WARNING
Death or serious injury can result if
children become trapped in the machine.
Do not allow children to play on or around
this machine. Do not leave children
unattended while the machine door is
open.
SW001
DANGER
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty.
SW004
WARNING
Ensure that the machine is installed on a
level floor of sufficient strength and that
the recommended clearances for
inspection and maintenance are provided.
Never allow the inspection and
maintenance space to be blocked.
SW020
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched.
SW014
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety
F232182
4
Key to Symbols
The lightning flash and arrowhead within the triangle
is a warning sign indicating the presence of dangerous
voltage.
The exclamation point within the triangle is a warning
sign indicating important instructions concerning the
machine and possibly dangerous conditions.
This warning symbol indicates the presence of
potentially dangerous drive mechanisms within the
machine. Guards should always be in place when the
machine is in operation.
This warning symbol indicates the presence of possibly
dangerous chemicals. Proper precautions should be
taken when handling corrosive or caustic materials.
This warning symbol indicates the presence of hot
surfaces that could cause serious burns. Stainless steel
and steam lines can become extremely hot and should
not be touched.
This warning symbol indicates the presence of
possibly dangerous pinch-points. Moving mechanical
parts can crush and/or sever body parts.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety
5
F232182
Figure 1
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals could
result in injury to the operator or service technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If questions
regarding safety arise, contact the factory immediately.
Use factory-authorized spare parts to avoid safety
hazards.
PHM2008P
®
WARNING
MACHINE MAY BE HOT
AND CAUSE BURNS
ATTEMPT NO ENTRY UNTIL
BASKET HAS STOPPED
DO NOT WASH ITEMS CONTAINING
HAZARDOUS CHEMICALS, FLAMMABLE
FUMES OR FLAMMABLE MATERIALS.
USE MACHINE WITH WATER ONLY.
SERIOUS INJURY MAY RESULT.
DO NOT LET CHILDREN OPERATE OR
PLAY WITH OR AROUND WASHER.
WARNING
MACHINE MAY BE HOT
AND CAUSE BURNS
ATTEMPT NO ENTRY UNTIL
BASKET HAS STOPPED
SERIOUS INJURY MAY RESULT
WARNING
MACHINEMAY BE HOT
ANDCAUSE BURNS
ATTEMPTNO ENTRY UNTIL
BASKETHAS STOPPED
SERIOUSINJURY MAY RESULT
Before Power is Connected
To unlock door to remove contents of basket, retract
the door locking plunger with a knife blade or other
thin object while at the same time applying some
pressure to the door latch handle in a clockwise
direction.
DO NOT
PUSH
External Supply
Signals
THIS MACHINE MUST BE
PROTECTED
BY A CIRCUIT BREAKER
DO NOT USE FUSES
WARNING
Avoid contact with
external steam
pipes. Serious
injury may result.
WARNING !
HIGH VOLTAGE INSIDE
DISCONNECT MAIN POWER BEFORE
REMOVING COVER. ONLY SPECIALLY
TRAINED PERSONNEL SHOULD TURN
POWER ON WHEN COVER IS REMOVED.
HAZARDOUS CHEMICALS MAY BE PRESENT.
HOT WATER IS USED TO FLUSH COMPARTMENTS.
WEAR HAND AND EYE PROTECTION WHEN ADDING DETERGENTS/CHEMICALS.
AVOID OPENING DISPENSER LID WHILE COMPARTMENTS ARE BEING FLUSHED.
REFER TO MANUALS.
Présence de products chimiques dangereux possible.
De l´ eau chaude est utillsáe pour la vidange des compartiments.
Toujours porter des gants et des lunettes de protection lors
de l´ ajout de détergents/produits chimiques.
Évites d´ ouvrie la couvarcÍe du distributeur lors de la vidange
des compartiments.
Se reporter aux instructions des guides de l´utillsatsur.
CAUTION
ATTENTION
Cold Water
0231368-00
2-5.7 BAR, 30-85 PSI
Hot Water
0231367-00
2-5.7 BAR, 30-85 PSI, MAX 90˚C, 180˚F

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety
F232182
6
Operator Safety
To ensure the safety of machine operators, the following
maintenance checks must be performed daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
Safe Operating Environment
Safe operation requires an appropriate operating
environment for both the operator and the machine. If
questions regarding safety arise, contact the factory
immediately.
Environmental Conditions
●Ambient Temperature. Water in the machine will
freeze at temperatures of 32°F (0°C) or below.
Temperatures above 120°F (50°C) will result in
more frequent motor overheating and, in some
cases, malfunction or premature damage to solid
state devices that are used in some models.
Special cooling devices may be necessary.
Water pressure switches are affected by increases
and decreases in temperature. Every 25°F (10°C)
change in temperature will have a 1% effect on
the water level.
●Humidity. Relative humidity above 90% may
cause the machine’s electronics or motors to
malfunction or may trip the ground fault
interrupter. Corrosion problems may occur on
some metal components in the machine.
If the relative humidity is below 30%, belts and
rubber hoses may eventually develop dry rot.
This condition can result in hose leaks, which
may cause safety hazards external to the machine
in conjunction with adjacent electrical
equipment.
●Ventilation. The need for make-up air openings
for such laundry room accessories as dryers,
ironers, or water heaters must be evaluated
periodically. Louvers, screens, or other
separating devices may reduce the available air
opening significantly.
●Radio Frequency Emissions. A filter is available
for machines in installations where floor space is
shared with equipment sensitive to radio
frequency emissions.
●Elevation. If the machine is to be operated at
elevations of over 3280 feet (1000 meters) above
sea level, pay special attention to water levels and
electronic settings (particularly temperature) or
desired results may not be achieved.
●Chemicals. Keep stainless steel surfaces free of
chemical residues.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage.
SW039
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety
7
F232182
●Water Damage. Do not spray the machine with
water. Short circuiting and serious damage may
result.
Machine Location
●Foundation. The concrete floor must be of
sufficient strength and thickness to handle the
floor loads generated by the high extract speeds
of the machine.
●Service/Maintenance Space. Provide sufficient
space to allow comfortable performance of
service procedures and routine preventive
maintenance.
This is especially important in connection with
machines equipped with an AC inverter drive.
Consult installation instructions for specific details.
Input and Output Services
●Water Pressure. Best performance will be
realized if water is provided at a pressure of
30 – 85 psi (2.0 – 5.7 bar). Although the machine
will function properly at lower pressure,
increased fill times will occur. Water pressure
higher than 100 psi (6.7 bar) may result in
damage to machine plumbing. Component
failure(s) and personal injury could result.
●Steam Heat (Optional) Pressure. Best
performance will be realized if steam is provided
at a pressure of 30 – 80 psi (2.0 – 5.4 bar). Steam
pressure higher than 125 psi (8.5 bar) may result
in damage to steam components and may cause
personal injury.
For machines equipped with optional steam heat,
install piping in accordance with approved
commercial steam practices. Failure to install the
supplied steam filter may void the warranty.
●Compressed Air. For machines requiring
compressed air service, best performance will
be realized if air is provided at a pressure of
80 – 100 psi (5.4 – 6.7 bar).
●Drainage System. Provide drain lines or troughs
large enough to accommodate the total number of
gallons that could be dumped if all machines on
the site drained at the same time from the highest
attainable level. If troughs are used, they should
be covered to support light foot traffic.
●Power. For personal safety and for proper
operation, the machine must be grounded in
accordance with state and local codes. The
ground connection must be to a proven earth
ground, not to conduit or water pipes. Do not use
fuses in place of the circuit breaker. An easy-
access cutoff switch should also be provided.
Always disconnect power and water supplies before a
service technician performs any service procedure.
Where applicable, steam and/or compressed air supplies
should also be disconnected before service is performed.
Do not place volatile or flammable fluids
in any machine. Do not clean the machine
with volatile or flammable fluids such as
acetone, lacquer thinners, enamel
reducers, carbon tetrachloride, gasoline,
benzene, naptha, etc. Doing so could
result in serious personal injury and/or
damage to the machine.
SW002
DANGER
Replace all panels that are removed to
perform service and maintenance
procedures. Do not operate the machine
with missing guards or with broken or
missing parts. Do not bypass any safety
devices.
SW019
CAUTION
Ensure that a ground wire from a proven
earth ground is connected to the ground
lug near the input power block on this
machine. Without proper grounding,
personal injury from electric shock could
occur and machine malfunctions may be
evident.
SW008
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety
F232182
8
AC Inverter Drive
Machines equipped with the AC inverter drive require
special attention with regard to the operating
environment.
●An especially dusty or linty environment will
require more frequent cleaning of the AC inverter
drive cooling fan filter and of the AC inverter
drive itself.
●Power line fluctuations from sources such as
uninterruptible power supplies (UPS) can
adversely affect machines equipped with the AC
inverter drive. Proper suppression devices should
be utilized on the incoming power to the machine
to avoid problems.
●A clean power supply free from voltage spikes
and surges is absolutely essential for machines
equipped with the AC inverter drive. Nonlinear
inconsistencies (peaks and valleys) in the power
supply can cause the AC inverter drive to
generate nuisance errors.
If voltage is above 240 Volt for 200 Volt
installations or above 480 Volt for 400 Volt
installations, a buckboost transformer is required.
●Sufficient space to perform service procedures
and routine preventive maintenance is especially
important for machines equipped with the AC
inverter drive.
Misuse
Never use this machine for any purpose other than
washing fabric with water.
●Never wash petroleum-soaked rags in the
machine. This could result in an explosion.
●Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
●Never allow children to play on or around this
machine. Death or serious injury can result if
children become trapped in the machine. Do not
leave children unattended while the machine door
is open. These cautions apply to animals as well.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9
F232182
Introduction
Model Identification
Information in this manual is applicable to these
models:
* This manual appliesto models with U7 or U8 in the
8th and 9th or 9th and 10th positions in the model
number (e.g., UW60VVXU70001).
This manual is designed as a guide to programming
the pocket hardmount washer-extractor equipped with
the V-computer and AC inverter drive.
The manuals, installation instructions, and wiring
diagrams which accompany the machine have been
included with the machine at no charge. Additional
copies are available at a nominal charge.
NOTE: Read this manual thoroughly before
attempting to program the microcomputer.
NOTE: Do not use this manual in conjunction with
earlier model computer-controlled machines. Do
not use technical literature intended for earlier
models when operating this machine.
NOTE: All information, illustrations, and
specifications contained in this manual are based
on the latest product information available at the
time of printing. We reserve the right to make
changes at any time without notice.
Customer Service
If literature or replacement parts are required, contact
the source from which the machine was purchased
or contact Alliance Laundry Systems LLC at
[phone] for the name and address of the
nearest authorized parts distributor.
For technical assistance, call any of the following
numbers:
[phone]
Ripon, Wisconsin
www.comlaundry.com
A record of each machine is on file with the
manufacturer. Always provide the machine’s serial
number and model number when ordering parts or
when seeking technical assistance.
UW35VV*
UW60VV*
UW80VV*
UW100VV*
UW125VV*

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
F232182
10
Model Number Familiarization Guide
Sample Model Number: UW60VVXU70001
UW Model Number Prefix
60 Washer-Extractor Capacity (pounds dry weight of laundry)
VType of Electrical Control
VWasher-Extractor Speed Capabilities
XElectrical Characteristics
7Design Series
0001 Option Identification (varies from machine to machine)
PHM628N
Figure 2
PHM628N
UW60VVXU70001
00000000000
200 – 240
50 – 60 2/3 1/3
20
60 27 813
N/A N/A 0.0
14
ETL Listed
Conforms To ANSI/UL Std. 1206, 3rd Ed
Certified To CAN/CSA Std. C22.2 No.53-1968
Drawings:
EXAMPLE OF NAMEPLATE

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
11
F232182
Machine Familiarization Guide
The machine familiarization guide in Figure 3
identifies the major operational features of the
machine.
Figure 3
P005I
1Emergency Stop Button 8Side Panel
2Supply Valve Box 9Front Panel
3Supply Dispenser 10 Rub Rail
4Door Handle 11 Shell Front
5Door Box 12 Door Hinge
6Door Latch Extension Arm 13 Door
7Door Latch 14 Control Module
WARNING
MACHINEMAY BE HOT
ANDCAUSE BURNS
ATTEMPTNO ENTRY UNTIL
BASKETHAS STOPPED
SERIOUSINJURY MAY RESULT
R
DoorUnlock
PressandHold
EmergencyStop
Up Down Start Stop
P005I
1
2
3
4
5
6
7
8
9
10
11
12
13
14

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232182
12
Notes

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 13
F232182
Programming
The V-computer board is inside the control module.
Near the center of the board is a small toggle switch:
this is the Run/Program Mode switch.
The Run/Program switch is normally in the down (Run
Mode) position. To enter Program Mode, flip the
switch to the up position. The display will now show
the current temperature in the sump.
Figure 4
Since the keypad operates in a slightly different
fashion when in Program Mode, pay careful attention
to the programming instructions provided in this
manual.
Key Functions in Program Mode
Up – The Up key is used to increase cycle numbers
(1 through 30) and other numerical values such as
times or temperatures (when creating wash formulas).
Down – The Down key is used to decrease cycle
numbers (1 through 30) and other numerical values
such as times or temperatures (when creating wash
formulas).
Start – The Start key acts as an enter key in Program
Mode. Use this key to enter data and move to the next
function in the cycle.
Stop – The Stop key saves all data and terminates the
programming procedure. If it is the first key pressed in
Program Mode, the computer enters Setup Mode. The
Stop key can be pressed again to exit Setup Mode and
return to Program Mode.
Setup Mode
Setup options are programmable options that are in
effect for all wash formulas. These options include:
●Degrees displayed in Fahrenheit or Celsius
●Auxiliary heat enabled or disabled
●Supply 5 or Auxiliary fill
●Temperature-controlled fill enabled or disabled
●Automatic cool-down enabled or disabled
NOTE: These options can be read or changed only
in Setup Mode.
To enter Setup Mode, press the Stop key while the
display is showing the temperature in the sump. Once
in Setup Mode, use the Up or Down key to change the
selected option. Use the Start key to accept the
selected option and move on to the next one. Press the
Stop key to exit Setup Mode.
CHM474R
1Run/Program Mode Switch
2Temperature Calibration Screw
Dangerous voltages are present in the
electrical control box(es) and at the motor
terminals. Only qualified personnel
familiar with electrical test procedures,
test equipment, and safety precautions
should attempt adjustments and
troubleshooting. Disconnect power from
the machine before removing the control
box cover, and before attempting any
service procedures.
SW005
WARNING
1
2

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
F232182
14
Degrees Displayed in Fahrenheit or
Celsius
This setup option affects the programming and display
of all temperatures. If “FAr” is selected, all
temperatures will display in Fahrenheit. If “CEL” is
selected, all temperatures will display in Celsius.
Acceptable ranges for programmable temperatures are
75° – 200°F or 25° – 93°C.
Procedure for Temperature Calibration
1. Ensure that the V-Computer has no input power
applied.
2. Mount an accurate temperature sensor probe
(part of temperature calibration equipment) in the
bottom of the machine basket. Make sure the
wires for the probe exit the top of the door to
ensure the door gasket does not leak.
3. Close door and ensure that the door is locked.
4. Open machine top cover and remove control
component cover(s), if necessary, to gain access
to the V-Computer and output control board.
NOTE: For more accurate calibration proceed with
steps 5-9. For a quick estimated calibration skip to
step 10.
5. Note wire connections on the output control
board for the AC Drive control. Some machines
will have six wires connected to “STF,” “STR,”
“RH,” “RM,” “RL,” and “COM” individually or a
single connector labeled “J11-1.” Remove these
wires or connector to ensure the basket will not
rotate. Also remove the input power to the drive.
NOTE: If this step is not followed, damage can
occur to the calibration temperature probe.
6. Restore input power to the machine.
7. Wait until machine message displays “CY”
followed by a two-digit cycle number (01 – 30).
8. Program one of the unused cycles to Fill to High
Level using both of the water inlet valves. Select
a time limit that would be sufficient to complete
the calibration procedure.
9. When machine has completed the Fill to High
Level, press and hold the Up key to display the
machine temperature. Make sure that the
V-Computer is in the correct temperature unit
(deg F or C). Refer to Setup Mode section of
manual to change.
10. Using a flat bladed screwdriver, turn the machine
temperature calibration screw until the displayed
temperature of the machine and the temperature
of the temperature calibration equipment are
accurate to the nearest degree (refer to Figure 4).
11. When the temperatures match, calibration is
completed.
12. Remove power from the machine input.
13. Reconnect any wires/connectors/fuses that were
removed, making sure they are installed exactly
as they were removed.
14. Reinstall all machine protective covers.
15. Remove the temperature calibration probe from
the bottom of the machine basket.
16. Restore input power to machine.
17. Machine is now ready for use.
Dangerous voltages are present in the
electrical control box(es) and at the motor
terminals. Only qualified personnel
familiar with electrical test procedures,
test equipment, and safety precautions
should attempt adjustments and
troubleshooting. Disconnect power from
the machine before removing the control
box cover, and before attempting any
service procedures.
SW005
WARNING
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
15
F232182
Auxiliary Heat
Heat is a dedicated output of the V-computer, which
controls an optional heat source. If “noHt” is selected,
the heat output will never energize during a cycle
(except briefly in the test cycle to ensure that the
output functions properly), regardless of programmed
temperature settings. If “HEAt” is selected, the output
will energize during a cycle if the three following
conditions are true:
●A nonzero heat temperature is programmed.
●The computer senses that the present temperature
is below the programmed target temperature.
●There is at least a low water level in the machine.
NOTE: Do not enable the auxiliary heat setup
option and disable the temperature-controlled fill
option on machines not equipped with auxiliary
heat. The machine will pause for 40 minutes during
any cycle segment where the fill water temperature
does not equal or exceed the programmed value of
the heat step.
Supply 5 or Auxiliary Fill
If “SUP5” is selected, the output labeled AF on the
solid state output board can be used to control a fifth
supply signal. This setup option must be selected to
program an “SUP5” or an “SUP6” (supply 1 and
supply 5 combined) in a cycle step.
If “AFIL” is selected, the output labeled AF can be
used to control an auxiliary fill valve. Auxiliary fills
can be programmed to low, medium, or high water
level. This setup option must be selected to program an
“AFIL” in a cycle step.
Temperature-Controlled Fill
If “tFIL” is selected, a temperature-controlled fill can
be programmed for any segment. This setup option
must be selected to program a “tFIL” in a cycle step. If
“ntFL” is selected, this feature is disabled.
Automatic Cool-Down
If “CooL” is selected, the automatic cool-down feature
is enabled. If the wash solution is 140°F (60°C) or
higher when a cycle step calls for a drain, the washing
action will continue and the cold water valve will
begin flushing cold water into the wash solution. Once
the wash solution temperature drops below 140°F
(60°C), the drains open and the cycle continues as
programmed. If “noCL” is selected, this feature is
disabled.
Cycle Count
To display the current cycle count, press the Start key
while the display is showing the temperature in the
sump. The display will show a two-digit number
indicating how many cycles have been run to
completion (cycles which were stopped in progress are
not counted). Press the Start key to return to Program
Mode without resetting the count. Press the Up or
Down key to reset the count to zero and return to
Program Mode.
Cycle Programming
To edit an existing cycle or create a new cycle, press
the Up key while the display is showing the
temperature in the sump. The display will show
“CY01.” Press the Up or Down key until the desired
cycle number is displayed. Press the Start key to begin
editing the selected cycle.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
F232182
16
Cycle Options
Cycle options are programmable options that are in
effect for the duration of the selected wash cycle.
These options include:
●Agitation action
●Agitation speed (defaults to normal wash speed
regardless of setting)
●Recirculation pump enabled or disabled (for
possible future application)
NOTE: Cycle option settings are unique to the cycle
for which they are programmed.
Use the Up or Down key to change the selected option.
Use the Start key to accept the selected option and
move on to the next one.
Agitation Action
The programmer may choose among four agitation
actions. Refer to Table 1.
Table 1
The selected agitation applies to the entire cycle. It is
possible to progam a different agitation action for each
of the 30 cycles. When “Ag 3” or “Ag 4” is in effect,
there is no agitation during the fill.
Agitation Speed
If “AgSn” or “AgSL” is selected, the machine will
default to normal wash speed regardless of the setting.
Recirculation Pump
This cycle option setting is intended to be used with
a possible future recirculation application. Selecting
either “nPnP” or “PUnP” will have no bearing on
the wash cycle. However, the “nPnP” setting is
recommended to prevent the corresponding output
on the output board from energizing.
Press the Start key after selecting this last cycle option
setting to begin editing the cycle segments.
Segment Programming
All cycle programs (“CY01” – “CY30”) can be
customized within a preset program structure. Each
cycle program consists of eleven program segments.
Refer to Table 2.
Table 2
Agitation Action Options
Display Description Percentage
Ag 1
27 seconds forward,
3 seconds pause,
27 seconds reverse,
3 seconds pause
90%
Ag 2
10 seconds forward,
20 seconds pause,
10 seconds reverse,
20 seconds pause
33%
Ag 3
3 seconds forward,
27 seconds pause,
3 seconds reverse,
27 seconds pause
10%
Ag 4
4 seconds forward,
56 seconds pause,
4 seconds reverse,
56 seconds pause
6.7%
Cycle Program Segments
Segment Display
PreWash PrE
Wash UASH
Fill 1 FIL1
Fill 2 FIL2
Fill 3 FIL3
Fill 4 FIL4
Fill 5 FIL5
Fill 6 FIL6
Fill 7 FIL7
Fill 8 FIL8
Fill 9 FIL9

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
17
F232182
When modifying a cycle, a time must be entered for
each segment. To skip a segment or spin, set the time
to “00” and press the Start key. Table 3 gives the time
parameters for each segment and spin, as well as the
allowable temperature range.
Table 3
NOTE: Spin times in cycle segments 1 – 10 are
entered in seconds (30 to 240), and time for final
spin in segment 11 is entered in minutes (1 to 10).
1. Press the Up key until the computer display
shows the segment to be edited. Press the Start
key.
2. Use the Up or Down key to select the desired
segment time. Set this value to zero to skip the
segment. Press the Start key.
NOTE: The computer does not count down the
remaining cycle time during fills, drains, cool-
down, or prior to first achieving the programmed
heat temperature when heating. The computer
resumes counting down cycle time once the
programmed fill level is reached, when the machine
has drained, and after a programmed heat
temperature is reached.
3. If the temperature-controlled fill setup option is
enabled, the display will show “tFIL.” Press the
Start key.
4. Use the Up or Down key to select the desired fill
temperature. Refer to Table 4 for fill options.
Table 4
If the temperature-controlled fill setup option is
enabled and a target temperature is set, the
selected fill valve(s) will energize for the first
three seconds of the segment fill. The computer
will then begin operating the fill valves in an
attempt to reach the target temperature. Press the
Start key.
5. Use the Up or Down key to select the desired fill
level. Refer to Table 5.
Table 5
Time and Temperature Parameters
Function Minimum Maximum
PreWash 2 minutes 30 minutes
Wash 2 minutes 20 minutes
Fill 1 2 minutes 15 minutes
Fill 2 2 minutes 15 minutes
Fill 3 2 minutes 15 minutes
Fill 4 2 minutes 15 minutes
Fill 5 2 minutes 15 minutes
Fill 6 2 minutes 15 minutes
Fill 7 2 minutes 15 minutes
Fill 8 2 minutes 15 minutes
Fill 9 2 minutes 15 minutes
Intermediate Spin* 30 seconds 240 seconds
Final Spin** 1 minute 10 minutes
Temperature 75°F (25°C) 200°F (93°C)
* Programmed with wash segment through Fill 8.
** Programmed with Fill 9.
Fill Temperature Options
Display Fill Type
CFIL Cold Fill
HFIL Hot Fill
bFIL Warm Fill
AFIL Auxiliary Fill*
*This is available only if the “SUP5”/“AFIL” setup
option is set to “AFIL.”
Water Level Options
Display Fill Level
Lo Low Level
nEd Medium Level
HI High Level

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
F232182
18
6. Press the Start key.
7. Use the Up or Down key to select the desired
supply option. Refer to Table 6.
Table 6
8. Press the Start key.
9. If the temperature-controlled fill or the auxiliary
heat setup option is enabled, use the Up or Down
key to select the desired segment temperature. To
disable auxiliary heat and temperature-controlled
fill for this segment, set this value to zero. Press
the Start key.
NOTE: If the temperature-controlled fill setup
option is enabled and an auxiliary fill has been
selected for the segment, the segment temperature
should be set to zero. Otherwise, the auxiliary fill
valve will enable for only three seconds at the
beginning of the fill before the computer begins
using the hot and cold fill valves to reach the
programmed temperature.
10. Use the Up or Down key to select the desired
drain option. If “drAI” is selected, the machine
will drain after the segment time has elapsed. If
“nodr” is selected, the machine will not drain and
the spin step will be skipped entirely. Press the
Start key.
NOTE: The drain step in the final segment (Fill 9)
cannot be skipped.
11. For final “FIL9” spin only, use the Up or Down
key to select the desired spin speed. Refer to
Table 7.
Table 7
12. Press the Start key.
13. Use the Up or Down key to select the desired spin
time. Set this value to zero to skip the spin step.
Press the Start key. The display will now show
the identifier for the next program segment (or
return to the temperature display if the edited
segment is the Fill 9 segment).
NOTE: Every intermediate spin is followed by a
25 second coast-down period, which occurs during
the fill step for the following segment.
14. Press the Stop key at any time to complete the
cycle programming procedure.
Supply Options
Display Supply
SUP0 No Supply
SUP1 Supply 1
SUP2 Supply 2
SUP3 Supply 3
SUP4 Supply 4
SUP5 Supply 5*
SUP6 Supply 1 and 5*
SUP7 Supply 3 and 4
*This is available only if the “SUP5”/“AFIL” setup
option is set to “SUP5.”
Spin Options
Display Spin Speed
SPn1 Low Spin
SPn2 Medium Spin
SPn3 High Spin
