Section 1
Safety Information
Throughout this manual and on machine decals, you will find precautionary statements (“CAUTION,”
“WARNING” and “DANGER”) followed by specific instructions. These precautions are intended for the personal
safety of the operator, user, servicer, and those maintaining the machine.
aDANGER
Danger indicates an imminently hazardous situation that, if not avoided, will cause severe personal injury or death.
WARNING
Warning indicates a hazardous situation that, if not avoided, could cause severe personal injury or death.
CAUTION
Caution indicates a hazardous situation that, if not avoided, may cause minor or moderate personal injury or property
damage.
Additional precautionary statements (“IMPORTANT” and “NOTE”) are followed by specific instructions.
IMPORTANT
The word “IMPORTANT” is used to inform the reader of specific procedures where minor machine damage will
occur if the procedure is not followed.
NOTE
The word “NOTE” is used to communicate installation, operation, maintenance or servicing information that is
important but not hazard related.
In the interest of safety, some general precautions relating to the operation of this machine follow.
• Failure to install, maintain and/or operate this product according to the manufacturer’s
instructions may result in conditions which can produce serious injury, death and/or property
damage.
• Do not repair or replace any part of the product or attempt any servicing unless specifically
recommended or published in this Service Manual and unless you understand and have the
skills to carry out the servicing.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the product is properly grounded and to reduce the risk of fire,
electric shock, serious injury or death.
W006R2
WARNING

4802850
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
NOTE: The WARNINGS and IMPORTANT INSTRUCTIONS appearing in this manual are not meant to
cover all possible conditions and situations that may occur. Common sense, caution and care must be
exercised when installing, maintaining or operating the washer.
Always contact your dealer, distributor, service agent or the manufacturer about any problems or conditions you do
not understand.
Locating an Authorized Servicer
Alliance Laundry Systems is not responsible for personal injury or property damage resulting from improper
service. Review all service information before beginning repairs.
Warranty service must be performed by an authorized technician, using authorized factory parts. If service is
required after the warranty expires, Alliance Laundry Systems also recommends contacting an authorized technician
and using authorized factory parts.
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer before servicing.
• Never start the washer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer is properly grounded.
• Motor not grounded! Disconnect electric power before servicing motor.
W485
WARNING
Repairs that are made to your products by unqualified persons can result in hazards due to
improper assembly or adjustments subjecting you or the inexperienced person making such
repairs to the risk of serious injury, electrical shock or death.
W007
WARNING
If you or an unqualified person perform service on your product, you must assume the
responsibility for any personal injury or property damage which may result. The manufacturer
will not be responsible for any injury or property damage arising from improper service and/or
service procedures.
W008
WARNING

802850 5
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Section 2
Introduction
Customer Service
If literature or replacement parts are required, contact
the source from whom the machine was purchased or
contact Alliance Laundry Systems at [phone]
for the name and address of the nearest authorized
parts distributor.
For technical assistance, call either of the numbers
listed below:
[phone] Ripon, Wisconsin
[phone] Wevelgem, Belgium
Nameplate Location
When calling or writing about your product, be sure to
mention model and serial numbers. Model and serial
numbers are located on nameplate(s) as shown.
FLW2123N
Nameplate

6802850
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
Model Identification
Information in this manual is applicable to these machines:
AFB50RSP111TW01
AFN50FSP111TW01
AFN50RSP111TW01
AFN51FSP111TN01
ATSA0AWN
ATSA5AWN
CTSA0AWN

802850 7
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
Theory of Operation
(Front Control Shown)
FLW1774S
Control
(Located in control
cabinet)
Cycle
Selector
Start
Switch
Mixing
Valve
Pressure Switch
(Located in control
cabinet)
Inner
Basket
Outer
Tub
Electric
Drain
Pump
Inverter
Control
Belt
Motor
Temperature
Selector

8802850
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
General
This frontload washer provides some of the same
principles of operation as the typical topload washers.
It senses water level, it dispenses the desired laundry
detergent, agitates the clothes for good cleaning action,
pumps the water out of the washer and spins the
clothing in preparation for the dryer.
The difference in operation is primarily the rotational
washing agitation created for the horizontal basket and
drum. This agitation tumbles the clothes in a clockwise,
pause, and counter-clockwise direction. This reversing
tumbling action provides an efficient washing process
and requires less water.
The cycle begins by pressing the start button, which
locks the loading door after the vend is satisfied. The
type of cycle and water temperature are determined by
the temperature selector switch and the cycle select
switch.
The inner basket starts agitating during the wash water
fill. A column of air is trapped in a pressure bulb and
hose. The air pressure continues to increase as the inner
basket fills with water until it is great enough to
activate the pressure switch which then causes the wash
fill to stop.
The regular and perm press agitate cycle tumble the
clothing in a clockwise direction for a period of 15
seconds, pauses for nine seconds and then tumbles the
clothing in a counterclockwise direction for 15
seconds. This agitation continues until the wash cycle.
The machine stops agitating and turns on the pump
which removes the wash water.
Upon completion of the wash cycle, the machine goes
into two rinse cycles. Fresh cold water is brought into
the inner basket via the mixing valve until the pressure
switch shuts off the water while agitating. The rinse
cycle consists of agitation for a predetermined amount
of time, then a spin mode with the pump running while
the machine goes into a series of 4 short 500 RPM
spins.
After all the rinse cycles have been completed, the
washer goes into a final high spin cycle to extract as
much water as possible from the clothing to prepare
them for the dryer. The spin speeds and duration of
this final high spin cycle are determined by the type of
wash cycle selected (refer to Table 1 or Table 2).
NOTE: Washer may not reach 1000 RPM because
of an out-of-balance condition. Control may limit
speed to 850, 650 or 500 RPM depending on severity
of out-of-balance condition.
Technical
The basic operational system of this washer consists of
the control, temperature switch, inverter control,
pressure switch, water valves, electric pump, A.C.
motor and cycle select switch.
The control performs all timing functions like the timer
in a topload washer.
The inverter control uses a speed sensor on the motor
to measure the drum RPM. Before entering any spin
step, the inverter control measures the RPM of motor to
sense out-of-balance. The inverter control will try to
redistribute the clothes if an out-of-balance condition
exists; the inverter control will limit the spin speed to
several speeds depending on the severity of the out-of-
balance condition. If the out-of-balance condition is
severe enough, the inverter control will limit speed to
90 RPM and will not spin.
NOTE: An out-of-balance switch is used to detect
any out-of-balance condition during spins. If this
switch opens during a spin step, the inverter control
immediately stops and then restarts the spin.
Models Through Serial No. 0911014602
Regular Perm Press Delicate
650
RPM 3 minutes 4 minutes 4 minutes
1000
RPM 3 minutes 2 minutes 0 minutes
Table 1
Models Starting Serial No. 0911014603
Regular Perm Press Delicate
500
RPM 0 minutes 0 minutes 4 minutes
650
RPM 3 minutes 6 minutes 0 minutes
1000
RPM 3 minutes 0 minutes 0 minutes
Table 2

802850 9
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Section 3
Troubleshooting
1. Motor Circuit
2. Troubleshooting Knocking Noise
If a frontload washer produces a noise similar to a
knock on a door, it might be due to a flat spot on
the belt. The knocking sound is made when the
flat spot hits the pulley. The knocking may occur
during a pulse spin and fade after reaching a
higher RPM.
To correct this condition, replace the belt.
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer before servicing.
• Never start the washer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer is properly grounded.
• Motor not grounded! Disconnect electric power before servicing motor.
W485
WARNING
Windings
Tach. Circuit
White
Gray
Red
Red Red
54321
Resistance Values:
Tachometer Circuit:
Terminals 4–5
Approx. 115 ohms
Windings:
Terminals 1–2, 2–3, 1-3
Approx. 4.5 ohms

10 802850
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
3. No Spin Due to Out-of-Balance Switch Wiring Problem Starting Serial
Nos. Beginning 0307
A “no spin” condition could be the result of an open circuit in the wire harness or out-of-balance switch. First, check
that the harness is still connected to the out-of-balance switch. The out-of-balance switch is a normally closed
switch. (continued)
Figure 1
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer before servicing.
• Never start the washer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer is properly grounded.
• Motor not grounded! Disconnect electric power before servicing motor.
W485
WARNING
Wire Clamp
First Section
of Tape 4.5 In.
(11.43 cm)
From End of
Terminals
Third Section
of Tape 14 In.
(35.56 cm)
From End of
Terminals
Wire Tie
FLW1842B
45 degrees
Cut Off
Broken
Wires Here

802850 11
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
If broken wires are found at the out-of-balance switch
wire support, cut off portion of wires as shown in
Figure 1 and add new UL approved terminals.
a. To test the electrical circuit, disconnect
electrical power to the washer.
b. Remove the “H1” connector from the inverter
control assembly.
c. Use an Ohm meter to check the black/white to
violet/white wires. Circuit should read closed.
An open reading indicates a bad switch or
wire harness problem.
d. Flex the harness at the plastic wire clamp and
test continuity. If the base wire harness has an
open circuit it MUST be replaced or the
broken wires must be repaired with UL
approved terminals.
e. After replacing or repairing the wire harness,
wrap electrical tape around wires in two
locations as indicated below and in Figure 1.
Then secure the harness wires to the original
factory locations using clamp and wire tie.
Refer to Figure 1.
(1) The plastic wire clamp should be angled
toward the switch at 45 degrees.
(2) The clamp should wrap around the first
section of tape on the harness, which should
be placed approximately 4.5 inches (11.43
cm) from end of terminals.
(3) The harness should be secured to the
inverter control shield with a wire tie.
(4) The tie should wrap around the third section
of tape on the harness, which should be
placed approximately 14 inches (35.56 cm)
from end of terminals. Refer to Figure 1.
4. Troubleshooting LEDs on
Washer Inverter Controls
Starting Machine Serial No.
0911014603
There are three LEDs on the control to assist with
troubleshooting (refer to Figure 2):
• Green LED on constant = 5VDC power
supply present
• Green LED flashing one second on/one
second off = inverter control power up
• Red LED flashing four times/second =
inverter control is communicating with
front end control
5. No Spin (Washer)
A no spin condition is not caused by intermittent
operation of the motor or motor control (inverter
assembly). DO NOT replace these components for no
spin complaints if the unit passes the following
procedure:
Figure 2
FLW1844B
LEDs
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer before servicing.
• Never start the washer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer is properly grounded.
• Motor not grounded! Disconnect electric power before servicing motor.
W485
WARNING

12 802850
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
5. No Spin (continued)
No spin.
FLW1789S
Allow unit to go
through complete
final spin cycle.
Does unit spin at
high speed?
Motor and
motor control
board are
operating
properly. Do
not replace
them.
Yes
With no load, rapid
advance to final spin
or select spin only
cycle. Close door
and start washer.
BEFORE replacing
the motor control
board, conduct the
following tests.
No
Is pressure
switch or
pressure
switch wiring
inoperative?
Is load
out-of-
balance? Unit makes three
attempts to re-
balance out-of-
balance loads. If all
attempts fail, final
high speed spin is
aborted. ONLY
proper loading can
correct problem.
Yes
Is there a slow
drain, clogged
pump or
oversudsing
condition? Pressure switch
must register an
"empty" condition
before unit will
enter spin. Clear
drain or pump.
Yes
Replace switch
and/or wiring.
No
No Does unit
spin now?
No
Check for broken out-of-
balance switch wires.
Refer to
No Spin Due to
Out-of-Balance Switch
Wiring Problem Starting
Serial Nos. Beginning
0307
paragraph.
Yes
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer before servicing.
• Never start the washer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer is properly grounded.
• Motor not grounded! Disconnect electric power before servicing motor.
W485
WARNING

802850 13
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
6. Troubleshooting Shock Absorbers
A squeaking noise, oil seen on the base of the washer,
or an out-of-balance condition may mean one or more
shock absorbers need to be replaced.
To determine if there is an inoperative shock:
1. Remove front access panel.
2. Check height of rod or rod spacing above shock.
If all four shocks are uniform and have about two
inches of rod showing when basket is empty,
shocks don’t need replacing. Refer to Figure 3. If
one or more shocks is showing less than two
inches of rod, then an internal spring has broken
and all four shocks should be replaced.
3. Check base of washer below shock absorbers for
grease or oil. Shocks are not oil filled. Any oil is
from grease used internally to lubricate damper of
shock. A small amount of grease/oil on base is
normal and doesn’t indicate failure. A large
amount of grease/oil indicates a shock that might
fail soon. Do not replace shock until the internal
spring has broken as described in Step 2.
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer before servicing.
• Never start the washer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer is properly grounded.
• Motor not grounded! Disconnect electric power before servicing motor.
W485
WARNING

14 802850
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
Figure 3
Good Shock Shows
Approximately 2
inches of Rod
FLW1845B
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer before servicing.
• Never start the washer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer is properly grounded.
• Motor not grounded! Disconnect electric power before servicing motor.
W485
WARNING

802850 15
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
7. Error Code Listing
Error Conditions
If any of the following errors occur, the control enters Error Mode. For all fatal errors, the control will
terminate the current cycle, turn off all outputs, and flash two LEDs one second on/one second off to indicate
the error.
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the washer before servicing.
• Never start the washer with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the washer is properly grounded.
• Motor not grounded! Disconnect electric power before servicing motor.
W485
WARNING
Motor Failure
Error. If the control receives the motor failure signal from the motor control, the control will enter Error Mode. The control will turn off all outputs and flash the DOOR and FINAL
SPIN LEDs one second on/one second off to indicate a motor failure error. This is a fatal
error. The machine must be unpowered to clear this error.
Fill
Error. If the control receives no full input from the pressure switch indicating the cylinder is full within 30 minutes of starting the fill, the control will enter Error Mode. The control will
turn off all outputs and flash the WASH and DOOR LEDs one second on/one second off
to indicate a fill error. This is a fatal error. The machine must be unpowered to clear this
error.
Door Open
Error. If the control senses the door open during Run Mode, the control will enter Error Mode. The control will turn off all outputs and flash the WASH and RINSE LEDs one second on/
one second off to indicate a door open error. This is a fatal error. The machine must be
unpowered to clear this error.
Door Lock/Unlock
Error. If the door doesn’t lock in 15 seconds in Door Locking Mode or the door doesn’t unlock in 3 minutes in Door Unlocking Mode, the control will enter Door Lock Error Mode. The
control will turn off all outputs and flash the DOOR LED one second on/one second off to
indicate a door lock/unlock error.
To clear this error in Door Locked Mode the door must either open or lock. If the door
locks, the cycle will start normally. If the door opens, the control will revert back to Start
Mode.
To clear this error in Door Unlocking Mode the door must unlock or open. If the door
unlocks or opens, the control will enter End of Cycle Mode.
SPI Communications
Error. This error occurs when there is a problem with communications between the front-end control and the motor control. The control will turn off all outputs and flash the FINAL
SPIN and RINSE LEDs one second on/one second off to indicate an SPI communications
error. This is a fatal error. The machine must be powered down at this point.
Open/Shorted
Temperature
Sensor Error (Models
equipped with
heater)
Any time the control senses a temperature less than 32°F (0°C) or greater than 212°F
(100°C) while heating, the control will turn off the heater output and not attempt to heat.
The control will continue and finish the cycle normally. At the end of the cycle the
control will flash the HEATING LED one-second on/one second off to indicate an open/
shorted temperature sensor error. This error will be cleared when the door is opened at the
end of the cycle.

16 802850
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
8. Washer Will Not Start – No LEDs/Lights Lit (No response to start switch)
Is there 120 VAC
to control
transformer?
(2)
(3)
No
Yes
Yes
Is there
continuity across
terminals "H9-3" to "H9-7"
on the machine control when
the start switch is
depressed?
Replace machine
control.
No
Yes
(1)
Is there 24 VAC
from "H1-1" to "H1-3"
on the machine control ?
Replace
transformer.
Check wiring
to transformer.
No
Correct wiring
to and/or replace
start switch.
FLW1726S

802850 17
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
Washer Will Not Start – No LEDs/Lights Lit (No response to start switch)
120 VAC/60Hz
3
2
1

18 802850
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting
9. Washer Will Not Start – Door Open Error (Wash/Rinse LEDs Flashing –
Door must be closed and attempting to lock)
Is there
120 VAC across
"H4-5" to "H6-5" on the
machine
control?
(1)
(2)
Yes
No
Is there 120 VAC
from the RED wire
on door lock assembly
to neutral?
Replace the
door switch.
Replace machine
control.
Yes
No
Is there
120 VAC from
the BLK wire on the door
switch to
neutral?
(3)
Correct wiring
to the door switch.
Replace door
lock assembly.
Yes
No
FLW1775S
