Alliance Laundry Systems Hardmount Coin and OPL Installation and operation manual

Operation/Maintenance
www.comlaundry.com
Part No. F232134R5
June 2008
Washer-Extractors
Cabinet Hardmount Mechanical Timer
Coin and OPL Models
Refer to page 6 for Model Identification
CHM166C
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)

© Copyright 2008, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
F232134 1
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table of
Contents
Table of Contents................................................................................ 1
Safety Information.............................................................................. 2
Explaination of Safety Messages.......................................................... 2
Important Safety Instructions ............................................................... 2
Safety Decals ........................................................................................ 4
Operator Safety..................................................................................... 5
Introduction......................................................................................... 6
Model Identification ............................................................................. 6
Nameplate Location.............................................................................. 7
Replacement Parts ................................................................................ 7
Customer Service.................................................................................. 7
Communications ................................................................................... 9
Central Pay System .......................................................................... 9
Card Reader ..................................................................................... 9
Operation............................................................................................. 10
Control Panel ........................................................................................ 10
Operating Instructions .......................................................................... 10
Supply Dispenser .................................................................................. 12
Mechanical Timer Cycles ..................................................................... 13
Maintenance ........................................................................................ 14
Daily ..................................................................................................... 14
Beginning of Day............................................................................. 14
End of Day ....................................................................................... 14
Weekly.................................................................................................. 15
Monthly................................................................................................. 15
Quarterly ............................................................................................... 17
Care of Stainless Steel .......................................................................... 18

F232134
2© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
Explaination of Safety Messages
Precautionary statements (“DANGER,” “WARNING”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION Manual for the proper
grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, kerosene, waxes, cooking-oils, dry-
cleaning solvents, or other flammable or
explosive substances as they give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas is
flammable; do not smoke or use an open flame
during this time.
6. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This is a safety
rule for all appliances.
DANGER indicates the presence of a
hazard that will cause severe personal
injury, death, or substantial property
damage if the danger is ignored.
DANGER
WARNING indicates the presence of a
hazard that can cause severe personal
injury, death, or substantial property
damage if the warning is ignored.
WARNING
CAUTION indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions: W023
WARNING

Safety Information
3
F232134 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power source.
13. Use washer only for its intended purpose,
washing textiles.
14. Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
15. ALWAYS disconnect the washer from electrical
supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
16. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and be
made by licensed personnel when required.
17. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc. or anything
containing wax or chemicals such as in mops and
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to catch on fire by itself.
18. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
19. Keep washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have washer checked by a qualified
service person.
20. If the supply cord is damaged, it must be replaced
by a special cord or assembly available from the
manufacturer or its service agent.
21. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
22. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT bypass
the loading door switch by permitting the washer
to operate with the loading door open.
23. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of the reach of children at all times
(preferably in a locked cabinet).
24. Always follow the fabric care instructions
supplied by the textile manufacturer.
25. Never operate the washer with any guards and/or
panels removed.
26. DO NOT operate the washer with missing or
broken parts.
27. DO NOT bypass any safety devices.
28. Failure to install, maintain and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE: The WARNINGS and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining or operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.

Safety Information
F232134
4© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
IMPORTANT: Ensure that the recommended
clearances for inspection and maintenance
are provided. Never allow the inspection and
maintenance space to be blocked.
Safety Decals
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals
could result in injury to the operator or service
technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If
questions regarding safety arise, contact the
manufacturer immediately.
Use manufacturer-authorized spare parts to avoid
safety hazards.
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty. SW004
WARNING
Install the machine on a level floor of
sufficient strength. Failure to do so may
result in conditions which can produce
serious injury, death and/or property
damage. W703
WARNING
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury. SW025
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched. SW014
WARNING

Safety Information
5
F232134 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operator Safety
To ensure the safety of machine operators, the
following maintenance checks must be performed
daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage. SW039
WARNING

F232134
6© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
Model Identification
Information in this manual is applicable to these
models:
HC18MC2 HC35MDX NC27MD2 SC27MH2 SC50MV3 UC27MD2
HC18MD2 HC35MH2 NC27MDX SC27MN2 SC50MX2 UC27MN2
HC18MDX HC35MN2 NC27MX2 SC27MV2 SC50MY2 UC27MX2
HC18MH2 HC35MV2 NC35MD2 SC27MX2 SC60MD2 UC30ML2
HC18MN2 HC35MX2 NC35MDX SC30MD2 SC60ML2 UC30MN2
HC18MV2 HC40MD2 NC35MX2 SC30ML2 SC60MN2 UC30MX2
HC18MX2 HC40ML2 NC50MD2 SC30MN2 SC60MX2 UC35MC2
HC20MD2 HC40MN2 NC50MDX SC30MX2 SC60MY2 UC35MC3
HC20ML2 HC40MX2 NC50MX2 SC30MY2 SC80MC3 UC35MD2
HC20MN2 HC40MY2 SC18MC2 SC35MC2 SC80MD3 UC35MD3
HC20MX2 HC50MC2 SC18MC3 SC35MC3 SC80MH3 UC35MH2
HC20MY2 HC50MD2 SC18MD2 SC35MD2 SC80MN3 UC35MH3
HC25MC2 HC50MH2 SC18MD3 SC35MD3 SC80MV3 UC35MN2
HC25MD2 HC50ML2 SC18MH2 SC35MH2 UC18MC2 UC35MN3
HC25MDX HC50MN2 SC18MH3 SC35MH3 UC18MC3 UC35MV2
HC25MH2 HC50MV2 SC18MN2 SC35MN2 UC18MD2 UC35MV3
HC25ML2 HC50MX2 SC18MN3 SC35MN3 UC18MD3 UC35MX2
HC25MN2 HC50MY2 SC18MV2 SC35MV2 UC18MH2 UC40MN2
HC25MV2 HC60MD2 SC18MV3 SC35MV3 UC18MH3 UC50MC2
HC25MX2 HC60ML2 SC18MX2 SC35MX2 UC18MN2 UC50MC3
HC25MY2 HC60MN2 SC20MD2 SC40MD2 UC18MN3 UC50MD2
HC27MC2 HC60MX2 SC20ML2 SC40ML2 UC18MV2 UC50MD3
HC27MD2 HC60MY2 SC20MN2 SC40MN2 UC18MV3 UC50MH2
HC27MDX HC80MC3 SC20MX2 SC40MX2 UC18MX2 UC50MH3
HC27MH2 HC80MD2 SC20MY2 SC40MY2 UC20MD2 UC50MN2
HC27MN2 HC80MD3 SC25MC2 SC50MC2 UC20ML2 UC50MN3
HC27MV2 HC80MH3 SC25MD2 SC50MC3 UC20MN2 UC50MV2
HC27MX2 HC80MN3 SC25MH2 SC50MD2 UC20MX2 UC50MV3
HC30MD2 HC80MV3 SC25ML2 SC50MD3 UC25MC2 UC50MX2
HC30ML2 NC18MD2 SC25MN2 SC50MH2 UC25MD2 UC60MN2
HC30MN2 NC18MDX SC25MV2 SC50MH3 UC25MH2 UC80MC3
HC30MX2 NC18MX2 SC25MX2 SC50ML2 UC25MN2 UC80MD3
HC30MY2 NC25MD2 SC25MY2 SC50MN2 UC25MV2 UC80MH3
HC35MC2 NC25MDX SC27MC2 SC50MN3 UC25MX2 UC80MN3
HC35MD2 NC25MX2 SC27MD2 SC50MV2 UC27MC2 UC80MV3

Introduction
7
F232134 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Nameplate Location
The nameplate is located at the rear of the machine and
inside door. Always provide the machine’s serial
number and model number when ordering parts or
when seeking technical assistance.
Replacement Parts
If literature or replacement parts are required,
contact the source from whom the machine was
purchased or contact Alliance Laundry Systems
at [phone] for the name and address
of the nearest authorized parts distributor.
Customer Service
For technical assistance, call:
[phone]
Ripon, Wisconsin U.S.A.
CHM167R
1Nameplate
CHM167R
1

Introduction
F232134
8© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
* Denotes Brand
Figure 1
Model Number Familiarization Guide
Sample Model Number: *C60MX20060001
CModel Number Prefix
60 Washer-Extractor Capacity (pounds dry weight of laundry)
MType of Electrical Control
XActuation (X = Prep for coin)
2Washer-Extractor Speed Capability (2 = 2 speed)
OElectrical Characteristics
U6 Design Series
0001 Option Identification (varies from machine to machine)
CHM2028N
CHM2028N
*C60MX2OU60001
00000000000
500000
208 – 240
60 3 3
0
18
3
60
N/A N/A
470
7
EXAMPLE OF NAMEPLATE

Introduction
9
F232134 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Communications
Central Pay System
(Central Pay System Models Only)
The models are usually designated by the “Prep for
Central Pay” option. The control will accept
communications with the central pay system in order
to perform vending transactions to pay for cycles.
For detailed information on the Central Pay System
Communications, refer to the manufacturer.
Card Reader
(Card Reader Models Only)
The models are usually designated by the “Prep for
Card Reader” option. The control will accept
communications with a Card Reader in order to
perform vending transactions when a card is inserted
to pay for cycles. The Card Reader can also allow the
owner to program and collect audit information.
For detailed information on the Card Reader
Communications, refer to the manufacturer.

F232134
10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
Control Panel
Figure 2 shows the control panel for mechanical timer-
controlled machines.
The ON indicator light shows when a cycle is started
and will stay lit until cycle is complete.
Figure 2
The ADD BLEACH WHEN LIT indicator light
indicates, when lit, appropriate time to add bleach.
The CYCLE INDICATOR dial displays current cycle
step.
The depressed pushbutton on the cycle selector switch
indicates currently selected cycle.
Operating Instructions
1. Turn on the main power source (circuit breaker).
For non-coin models: Turn on the On/Off switch
on the front panel to the On position. Refer to
Figure 4.
2. Push button and turn handle clockwise to open.
Refer to Figure 3.
Figure 3
For non-coin models: Press and hold the DOOR
UNLOCK button on the left side of the control
panel while performing the above step. Refer to
Figure 3 and Figure 4.
Figure 4
B002R
1ON Indicator Light
2Pushbutton Cycle Selector Switch
3ADD BLEACH WHEN LIT Indicator Light
4CYCLE INDICATOR Dial
P
R
E
W
A
S
H
CYCLE INDICATOR WASH CYCLES
S
P
I
N
W
A
S
H
ON
ADD BLEACH
WHEN LIT
HOT
HEAVILY
SOILED
WARM
PERM-
PRESS
WARM
NORMAL
WASH
COLD
DELICATE
KNITS
R
I
N
S
E
B002R
3
2
1
4
U001IE1B
U135R
U001IE1B
On
Off
DOOR UNLOCK
U135R

Operation
11
F232134 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
3. Load to capacity whenever possible. DO NOT
OVERLOAD. Refer to Figure 5.
NOTE: Underloading can cause out-of-balance
conditions that can shorten machine life.
Figure 5
4. Close door and turn handle counterclockwise
until button pops out. Refer to Figure 6.
Figure 6
5. Select wash cycle. Refer to Figure 7.
Figure 7
6. At start of cycle, add liquid and/or powder
supplies to supply dispenser. Refer to Figure 8.
a. Add detergent to container 1.
b. Add softener to container 3.
For non-coin models: Liquid supplies may be
injected directly into the supply dispenser by an
external chemical supply dispenser. Refer to
Installation and Programming Manuals.
U003IE1A
U005IE1B
U005IE1B
U002IE1A
S
P
I
N
CYCLE INDICATOR WASH CYCLES
P
R
E
W
A
S
H
W
A
S
H
R
I
N
S
E
ON
ADD BLEACH
WHEN LIT
HOT WARM WARM COLD
HEAVILY
SOILED
PERM-
PRESS
NORMAL
WASH
DELICATE
KNITS
To avoid personal injury, recommended
inlet water temperature should be no
higher than 125°Fahrenheit (51°Celsius).
W709
WARNING

Operation
F232134
12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
7. If the machine is a coin operated unit, insert
required number of coins to start machine. Refer
to Figure 8.
8. If the machine is a card operated unit, insert and
remove card. Contact the card reader
manufacturer for details.
9. If the machine is interfaced with a central/remote
pay console, make payment and select the
machine. Contact the pay system manufacturer
for more details.
For non-coin models: Press the Start button.
Refer to Figure 9.
Figure 9
10. Add bleach to container 2 when ADD BLEACH
WHEN LIT is illuminated. Refer to Figure 10.
Figure 10
Supply Dispenser
A terminal strip in the input power junction box
provides control signals for an external chemical
supply system on OPL models.
Supply Signal Output Times (OPL models)
Supply Dispenser Flush Times
B157R
1Detergent
2Bleach
3Softener
Figure 8
U136R
B157R
1
2
3
On Start
Off
WARM COLD
DELICATE
KNITS
U136R
B158R
Output Time
1 Prewash Fill
2 When ADD BLEACH
WHEN LIT is illuminated
3 Rinse 3 Fill
4 When ADD BLEACH
WHEN LIT is illuminated
Container Time
1EveryFill
2WashFill
3 Rinse 3 Fill
B158R
ON
ADD BLEACH
WHEN LIT

Operation
13
F232134 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Mechanical Timer Cycles
Step Time (Min.)* Water Level Program Water Temperature
Hot Warm Warm Cold
Prewash 2
High
Warm Warm Cold Cold
Drain 1
Supply 1 Warm Warm Cold Cold
Wash 4
Low
Hot Warm Warm Cold
Drain 1
Extract 0.5
Supply 1
Supply 2 Cold Cold Cold Cold
Rinse 1 1.5
High Cold Cold Cold Cold
Drain 1
Extract 0.5
Supply1
Rinse 2 1.5
High Cold Cold Cold Cold
Drain 1
Extract 0.5
Supply 1
Rinse 3 1.5
High
Cold Cold Cold Cold
Drain 1
Extract 4
Shakeout 0.5
Supply 1
Supply 3 Hot Hot Hot Hot
* Cycle times are for the factory-preset jumper configuration. See Programming Manual for information.

F232134
14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Maintenance
IMPORTANT: Replace all panels that are removed
to perform service and maintenance procedures.
Do not operate the machine with missing guards or
with broken or missing parts. Do not bypass any
safety devices.
Daily
IMPORTANT: Door lock should be checked daily
to ensure proper operation. Also check that all
safety and instruction labels are on the machine.
Any missing or illegible safety instructions labels
should be replaced immediately.
Beginning of Day
1. Inspect water inlet valve hose connections on the
back of the machine for leaks.
2. Inspect steam hose connections for leaks (where
applicable).
3. Check door interlock before starting operation:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door, and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
End of Day
1. Clean the door gasket of residual detergent and
all foreign matter.
2. Clean between the door gasket and the door glass
with a damp cloth.
3. Clean automatic supply dispenser lid and general
area. Flush dispenser with clean water.
4. Clean the machine’s top, front and side panels
with mild detergent. Thoroughly rinse and dry all
surfaces after cleaning them.
5. Leave loading door open at the end of each day to
allow moisture to evaporate.
NOTE: Unload the machine promptly after each
completed cycle to prevent moisture buildup. Leave
loading door open after each completed cycle to
allow moisture to evaporate.
Sharp edges can cause personal injury.
Wear safety glasses and gloves, use
proper tools and provide lighting when
handling sheet metal parts. W366R1
WARNING

Maintenance
15
F232134 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Weekly
1. Check the machine for leaks.
a. Start an unloaded cycle to fill the machine.
b. Verify that door and door gasket do not leak.
c. Verify that the drain valve is operating and
that the drain system is free from obstruction.
If water does not leak out during the first wash
segment, the drain valve is closed and
functioning properly.
Monthly
NOTE: Disconnect power to the machine at its
source before performing the monthly maintenance
procedures.
1. Use the following procedures to determine if
V-belt(s) require replacement or adjustment. Call
a qualified service technician in either case.
a. Check V-belt(s) for uneven wear and frayed
edges.
b. For groove-pulley drive systems, verify
alignment by placing a straightedge across
both pulley faces. The straightedge should
make contact with the pulleys in four places.
Refer to Figure 11.
Figure 11
c. For flat-pulley drive systems, verify allowable
distance of belt from edge of pulley. Refer to
Table 1 below.
H040I
1Motor
2Motor Pulley
3Straightedge
4Basket Pulley
H040I
1
23
4
Flat-Pulley Alignment
Model Allowable
Distance from Edge
20 .09 in. (2 mm)
25 .09 in. (2 mm)
30 .09 in. (2 mm)
40 .09 in. (2 mm)
50 – 60 .38 in. (10 mm)
Table 1

Maintenance
F232134
16 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 12
2. For 80 pound capacity models only, lubricate
bearings and seals each month OR after every
200 hours of operation. Refer to Figure 12.
a. Use a premium-grade lithium-based #2
grease. Never mix two types of grease, such
as petroleum and silicone.
b. Pump the grease gun slowly, permitting only
the following number of strokes:
●Bearing grease fitting, 2 strokes
●Seal grease fitting, 1 stroke
NOTE: Do not pump the grease gun until grease
comes out of the bearing housing. This can result in
overlubrication, causing damage to bearings and
seals.
3. Remove back panel and check overflow hose and
drain hose for leaks.
4. Unlock the hinged lid and check the supply
dispenser hoses and hose connections.
5. Clean inlet hose filter screens:
a. Turn water off and allow valve to cool, if
necessary.
b. Unscrew inlet hose and remove filter screen.
c. Clean with soapy water and reinstall. Replace
if worn or damaged.
6. Tighten motor mounting bolt locknuts and
bearing bolt locknuts. Check to see that the pin is
in place.
H047I
1Bearing Grease Fitting
2Seal Grease Fitting
H047I
1
2

Maintenance
17
F232134 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
7. Use compressed air to clean lint from motor.
8. Clean interior of machine, both basket and shell,
by wiping with a water-soaked sponge or cloth.
9. Use compressed air to clean all electrical
components of moisture and dust.
10. Verify the insulation is intact on all external wires
and that all connections are secure. If bare wire is
evident, call a service technician.
Quarterly
NOTE: Disconnect power to the machine at its
source before performing the quarterly
maintenance procedures.
1. Tighten door hinges and fasteners, if necessary.
2. Using a Teflon-based spray lube, lubricate the
door lock by applying the spray to the door lock
pin while turning the door handle.
3. Tighten anchor bolts, if necessary.
4. Verify that the drain motor shield is in place and
secure, if so equipped.
5. Check all painted surfaces for exposed metal.
(Matching paint is available from the
manufacturer.)
●If bare metal is showing, paint with primer or
solvent-based paint.
●If rust appears, remove it with sandpaper or by
chemical means and then paint with primer or
solvent-based paint.
6. Clean customer-supplied steam filter, where
applicable. Refer to Figure 13.
a. Turn off steam supply and allow time for the
valve to cool.
b. Unscrew Cap.
c. Remove Element and clean.
d. Replace Element and Cap.
Figure 13
7. Check the bearing mounting bolts to make sure
they are torqued properly. Refer to Table 2 for
specifications.
H042I
1Cap
2Filter Element
Machine
Capacity Bearing Torque
18-25 All 75 ft.-lbs.
27-60 All 105 ft.-lbs.
80 Front 200 ft.-lbs.
80 Rear 97 ft.-lbs.
Table 2
H042
I
1
2

Maintenance
F232134
18 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Care of Stainless Steel
●Remove dirt and grease with detergent and water.
Thoroughly rinse and dry after washing.
●Avoid contact with dissimilar metals to prevent
galvanic corrosion when salty or acidic solutions
are present.
●Do not allow salty or acidic solutions to
evaporate and dry on stainless steel. Wipe clean
of any residues.
●Rub in the direction of the polish lines or “grain”
of the stainless steel to avoid scratch marks when
using abrasive cleaners. Use stainless steel wool
or soft, non-metal bristle brushes. Do not use
ordinary steel wool or steel brushes.
●Remove discoloration or heat tint from
overheating by scouring with a powder or by
employing special chemical solutions.
●Do not leave sanitizers or sterilizing solutions on
stainless steel equipment for prolonged periods
of time.
●When an external chemical supply is used, ensure
no siphoning of chemicals occurs when the
washer-extractor is not in use. Highly
concentrated chemicals can cause severe damage
to stainless steel and other components of the
machine. Damage of this kind is not covered by
the manufacturer’s warranty. Locate the pump
below the washer-extractor’s injection point to
prevent siphoning of chemicals into the machine.
●If the stainless steel appears to be rusting, the
source of the rust may actually be an iron or steel
part not made of stainless steel, such as a nail or
screw. Tip: Paint all carbon steel parts with a
heavy protective coating. Stainless steel fasteners
should be used whenever possible.
