Alliance Laundry Systems 802756R3 User manual

for your
frontload
washer
www.comlaundry.com
Inside . . .
Safety Information . . . 3
Operation. . . . . . . . . . . . . 6
Clothing Care . . . . . . . 17
Maintenance . . . . . . . . 18
Troubleshooting. . . . . 21
Part No. 802756R3
May 2010
REMARQUE: Le guide est rédigé en
anglais et en français. La version française
figure à la suite de la version anglaise.

-2-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
For your safety and to reduce the risk of fire or an explosion, do not store or use
gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
W022
WARNING

-3-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Safety Information
Explanation of Safety
Messages
Throughout this manual and on machine decals, you
will find precautionary statements (“DANGER,”
“WARNING,” and “CAUTION”) followed by specific
instructions. These precautions are intended for
the personal safety of the operator, user, servicer,
and those maintaining the machine.
Additional precautionary statements
(“IMPORTANT” and “NOTE”) are followed by specific
instructions.
IMPORTANT: The word “IMPORTANT” is used to
inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
Save These Instructions
1. Read all instructions before using the washer.
2. Refer to the Grounding Information in the
Installation Instructions for the proper
grounding of the washer.
3. Do not wash articles that have been previously
cleaned in, washed in, soaked in, or spotted
with gasoline, dry-cleaning solvents, or other
flammable or explosive substances as they
give off vapors that could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to
the wash water. These substances give off
vapors that could ignite or explode.
Indicates an imminently hazardous
situation that, if not avoided, will
cause severe personal injury or death.
DANGER
Indicates a hazardous situation that, if
not avoided, could cause severe
personal injury or death.
WARNING
Indicates a hazardous situation that, if
not avoided, may cause minor or
moderate personal injury or property
damage.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING
© Copyright 2010, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced
or transmitted in any form or by any means without the expressed written consent
of the publisher.

-4-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
5. Under certain conditions, hydrogen gas may
be produced in a hot water system that has
not been used for two weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot
water system has not been used for such a
period, before using a washing machine or
combination washer-dryer, turn on all hot
water faucets and let the water flow from
each for several minutes. This will release any
accumulated hydrogen gas. THE GAS IS
FLAMMABLE. DO NOT SMOKE OR USE AN
OPEN FLAME DURING THIS TIME.
6. Do not allow children to play on or in the
washer. Close supervision of children is
necessary when the washer is used near
children. This is a safety rule for all appliances.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum
is moving.
9. Do not install or store the washer where it will
be exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the
washer, or attempt any servicing unless
specifically recommended in the user-
maintenance instructions or in published user-
repair instructions that you understand and
have the skills to carry out.
12. To reduce the risk of an electric shock or fire,
DO NOT use an extension cord or an adapter
to connect the washer to the electrical power
source.
13. Use your washer only for its intended purpose,
washing clothes.
14. ALWAYS disconnect the washer from
electrical supply before attempting any
service. Disconnect the power cord by
grasping the plug, not the cord.
15. Install the washer according to the
Installation Instructions. All connections for
water, drain, electrical power and grounding
must comply with local codes and be made by
licensed personnel when required. Do not do it
yourself unless you know how!
16. To reduce the risk of fire, clothes which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil, flammable
chemicals, thinner, etc. or anything containing
wax or chemicals such as in mops and cleaning
cloths, must not be put into the washer. These
flammable substances may cause the fabric
to catch on fire by itself.
17. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or
product.
18. Keep your washer in good condition. Bumping
or dropping the washer can damage safety
features. If this occurs, have your washer
checked by a qualified service person.
19. Replace worn power cords and/or loose plugs.
20. Be sure water connections have a shut-off
valve and that fill hose connections are tight.
CLOSE the shut-off valves at the end of each
wash day.
21. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT by-
pass the loading door by permitting the
washer to operate with the loading door open.
22. Check washer for water leaks after each use. If
water is found, turn off the water supply and
call for service immediately. Don’t use washer
until it is repaired by an authorized service
agent.
23. If the washer’s volume or type of sound
changes from what is normally heard, call an
authorized service agent immediately to
prevent possible damage to other
components.
24. Never start a cycle and leave the property
without first checking to make sure the wash
cycle is complete.

-5-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
25. Always read and follow manufacturer’s
instructions on packages of laundry and
cleaning aids. Heed all warnings or
precautions. To reduce the risk of poisoning or
chemical burns, keep them out of the reach of
children at all times (preferably in a locked
cabinet).
26. Always follow the fabric care instructions
supplied by the garment manufacturer.
27. Never operate the washer with any guards
and/or panels removed.
28. DO NOT operate the washer with missing or
broken parts.
29. DO NOT by-pass any safety devices.
30. Failure to install, maintain, and/or operate this
machine according to the manufacturer's
instructions may result in conditions which
can produce bodily injury and/or property
damage.
31. Replace washer fill hoses every five years.
32. If unit is a stacked washer and dryer, do not
operate washer and dryer if the units have
been separated.
NOTE: The WARNING and Important Safety
Instructions appearing in this manual are not
meant to cover all possible conditions and
situations that may occur. Observe and be aware
of other labels and precautions that are located
on the machine. They are intended to provide
instructions for safeuse of the machine. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Always contact your dealer, distributor or service
agent about any problems or conditions you do not
understand.

-6-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Operation
Before Washing
Prepare Wash Load
Empty Pockets and Cuffs
Make sure all pockets are empty and turn them
inside out. One bobby pin, metal or plastic toy, nail
or sharp object in a load can catch laundry, cause
tears and plug the pump. Facial tissue left in a
pocket will produce extreme “lint”. A crayon or
lipstick in a wash load may cause stains that
cannot be removed. Roll down cuffs and shake out
grass, sand and gravel.
Mend Rips and Tears
Little holes can become bigger in the washer. Mend
holes and tears before placing garments in the
washer.
Close Zipper and Fasten Hooks
These can catch on garments in a wash load and
tear them. Tie belts and sashes so they won’t wind
around clothes.
Put Small Items in Bag
Small items such as baby socks may get stuck
around the door. Put them inside a mesh garment
bag.
Check For Colorfastness
Squeeze a portion of garment in warm or hot sudsy
water. If the color bleeds or runs, wash the item
separately in cold water.
Sort Items
Different items use different wash cycles and
temperatures. Always follow the manufacturer’s
care label. Proper sorting is easy if you follow a few
guidelines:
1. Sort by Color:
Separate items into loads of
whites, darks, lights and non-
colorfast.
2. Sort by Fabric and Construction:
Separate items into loads of
cottons/linens, permanent press,
synthetics/blends/poly knits, and
delicates.
3. Sort by Temperature:
Separate items into loads
that can be washed in cold,
warm or hot water.
4. Sort by Type and Amount of Soil:
Heavily soiled clothes will need extra
treatment. Lightly soiled clothes can become
dingy if washed with heavily soiled items.
5. Sort Lint “Shedders” From Lint “Receivers”:
Some fabrics attract lint and should not be
washed with lint-shedding loads. Lint
shedders are cottons, terry towels, chenille
bedspreads, rugs and clothes that have been
heavily bleached.
Lint receivers are synthetics, permanent or
durable press, knits (including socks),
corduroy, and other smooth fabrics.
Pretreat
Pretreat shirt collars and cuffs with a pretreat
product or liquid detergent when placing them in
the washer. Before washing, treat special stains
individually.
Whites
TLW1991
TLW1991N
TLW1990N
TLW1990N
Cottons
TLW1991
TLW1991N
Cold
TLW1991N
TLW1991N

-7-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Loading the Washer
Load Articles
•Load items by the amount of space they take
up, not by their weight. Mix large and small
items in a load to get the best washing
results.
•Load items loosely into the wash drum. The
bulk of the clothes rather than the weight will
determine load size.
Bulky Items
•Use the HANDWASH/DELICATE cycle for
bulky items such as blankets and comforters.
The cycle includes gentle agitation to clean
items delicately and thoroughly. The extra
rinse cycle may be selected to ensure
complete removal of soap residue. A final spin
extracts the moisture at a low speed to
maintain the load’s balance and minimize wear
to the articles.
Load Sizes
•Load sizes vary. Small and large items should
be washed together to create a balanced load.
If washing a large item,two bath towelsshould
be added to even the load.
•Smaller loads can create an unbalanced
condition and cause premature wear on the
washer. Do not hesitate to fill the entire inner
drum of the washer. The load will compress a
great deal when wet. This allows room for
proper tumbling.
Water Level
•The washer will automatically adjust the water
level to the type and size of the load during
any fill.
Wash Temperature
Boosted Hot Water (on select models only)
The Boosted Hot Wash will boost the water
temperature in the tub to 60°C (140°F) and is
useful for improved cleaning of some loads. The red
HEATING light will light up when heating. The cycle
will not advance until 60°C (140°F) has been
reached.
The time needed to reach this temperature may
add an additional 30 to 60 minutes to the cycle
time. Hot water is the most effective for cleaning
but it is not recommended for all fabric types (read
labels).
NOTE: The Boosted Hot Wash can be turned off by
changing the cycle selector knob to OFF and
restarting a cycle with a different water
temperature setting.
Hot Water
The Hot Wash temperature is determined by the
actual temperature of the hot water supplied to
the washer. For models with Boosted Hot Wash,
the heater element will not be on. Hot water is the
most effective for cleaning, but it is not
recommended for all fabric types (read labels).
Warm Water
The Warm Wash is useful for providing a thorough
cleaning on lightly soiled clothing without damaging
fabric or adding to color fading.
The Warm Rinse is useful in preventing wrinkles on
certain fabrics. Check labels for fabric
manufacturer’s recommendations.
Do not wash or dry items soiled with
vegetable or cooking oils. Some oils may
remain after washing and may cause the
fabric to catch on fire by itself.
W527
WARNING

-8-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Cold Water
The Cold Wash is ideal for delicate items. Although
its cleaning abilities are not as great as hot or
warm water, it is useful for colors that bleed easily
and for sensitive fabrics.
The Cold Rinse is optional in every cycle and is the
most beneficial for fabrics. Cold rinses reduce
wrinkling and color fading. In addition, cold rinses
will save money and energy.
NOTE: In wash temperatures colder than 16oC
(60oF), detergents do not dissolve well. This may
cause ineffective cleaning, or lint and residue to
form.
NOTE: Always follow manufacturer’s care labels.
Wash Temperature Guide
Energy
You can save energy when washing by following a few
guidelines:
1. Heating water accounts for the greatest
energy expense when washing. Save on heating
water by using warm or cold washes as well as
cold rinses.
2. Wash full loads, but do not overload.
Water Temperature Use Comments
BOOSTED HOT
(select models only)
(approximately 60°C [140°F])
• Sturdy whites and colorfast items
• Work clothes
• Heavily soiled items
•Diapers
• Best cleaning for heavily soiled
items
• Best for sanitizing
HOT
(approximately 49°C [120°F]
or as determined by outside hot
water supply)
• Sturdy whites and colorfast items
• Work clothes
• Soiled items
•Diapers
• Best cleaning for soiled items
• Good for sanitizing
WARM
(approximately 38°C [100º F]) • Rinsing of some items (OPTIONAL) • Light and moderately soiled items
• Non-colorfast or dark colors
• Permanent press
• Silks, woolens, nylon, acrylic
• Reduces wrinkling in permanent
press fabrics
•Lessfading
• Reduces shrinking in knits
COLD
(approximately 16°C [60º F]) • Rinsing of most items • Non-colorfast fabrics
• Extra delicate clothing
• Saves energy
• Reduces color fading
• Reduces wrinkling
• Reduces shrinking
49oC
(120oF)
38oC
(100oF)
16oC
(60oF)
HOT
WARM
COLD
TLW1994N

-9-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Operating Your Washer
NOTE: Always follow manufacturer’s care labels.
Determine Proper Cycle
NOTE: The cycle times might be longer if a
Boosted Hot Wash, if available, is selected.
Regular Cycle
Use for sturdy items, like play or work clothes,
towels, T-shirts, etc. This cycle includes a wash
tumble and two rinses with an optional third rinse.
The final spin starts with a medium spin and
finishes with a high spin.
Permanent Press Cycle
Use for permanent press items and synthetics.
This cycle includes a wash tumble and two rinses
with an optional third rinse. The final spin starts
with a medium spin and finishes with a high spin.
Handwash/Delicate Cycle
Wash delicate items usually washed by hand on this
cycle. The cycle includes a wash tumble and two
rinses with an optional third rinse. The final spin
extracts moisture at a low spin.
Rinse & Spin Cycle
Use to quickly rinse items. The rinse is followed by a
high spin.
Spin Only Cycle
Use to extract water from wet items. This cycle
uses the high spin.
OFF
Use to stop a cycle or change cycles.
Extra Rinse
This optional setting is useful for detergent
sensitive skin. By pressing the “EXTRA RINSE”
button to “ON,” the REGULAR, PERMANENT
PRESS and HANDWASH/DELICATE cycles will each
provide an additional rinse.
To Wash Clothes
IMPORTANT: Before using your new washer, make
sure the washer cord is plugged into a 120 Volt
electrical outlet that has the proper grounding
and polarity. Make sure the washer hoses are
connected to the hot and cold water faucets, and
that the faucets are turned on. Be sure the drain
hose is not kinked and is inserted into a drain.
Refer to the INSTALLATION INSTRUCTIONS for
details of proper washer installation.
IMPORTANT: Prior to first wash, use an all
purpose cleaner, or a detergent and water
solution, and a damp cloth to remove shipping
dust from inside of wash drum.
1. Get the clothes ready for washing. Empty
pockets and cuffs. Sort items into separate
loads. Pretreat stains and heavilysoiled areas.
IMPORTANT: Remove all sharp objects from
laundry to avoid tears and rips to items
during normal machine operation.
WARNING
To reduce the risk of fire, electric shock,
serious injury or death to persons, read
the Safety Information section before
operating your washer.
W522
TLW1991N
TLW1991N

-10-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
2. Measure and add low sudsing, high efficiency
(HE) detergent, fabric softener and bleach to
the dispenser drawer. Refer to section on
Using Your Dispenser Drawer. Follow
instructions on detergent package for
amount to use.
NOTE: High efficiency (HE)
detergents are designed
especially for frontload washers
to reduce oversudsing and
maximize cleaning results. Look
for the HE logo or “high efficiency” on the
detergent’s label.
IMPORTANT: If using non-HE detergent, avoid
oversudsing by using only 1/2 of the detergent
manufacturer's recommended amount.
3. Load clothes into wash drum. Refer to section
on Load Sizes.
NOTE: Small items such as baby socks may get
caught around the door. Place these articles
inside a mesh garment bag.
When washing bulky items such as blankets and
comforters, use the HANDWASH/DELICATE cycle.
The cycle includes gentle agitation to clean items
delicately and thoroughly. The extra rinse cycle may
be selected to ensure complete removal of soap
residue. A final spin extracts the moisture at a low
speed to maintain the load’s balance and minimize
wear to the articles.
4. Close the loading door tightly. The washer will
not operate with the loading door open.
5. Set WASH/RINSE temperatures.
FLW2169N
FLW2169N
FLW2170N
FLW2170N
FLW2177N
FLW2171N
To reduce the risk of serious injury, do
not bypass the loading door switch by
permitting the washer to tumble or spin
with the loading door open.
W095
WARNING

-11-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
There are four or five WASH/RINSE temperatures
available – Boosted Hot Wash/Cold Rinse (select
models only), Hot Wash/Cold Rinse, Warm Wash/
Warm Rinse, Warm Wash/Cold Rinse, Cold Wash/
Cold Rinse.
The Energy Saver settings, marked with an
asterisk (*) on some models, show which
temperature settings will use the least energy.
Refer to the Water Temperature section for the
temperature that works best for your garments.
6. Select EXTRA RINSE if desired.
The extra rinse control is useful for detergent
sensitive skin. By pressing the EXTRA RINSE to ON,
the REGULAR, PERMANENT PRESS, and
HANDWASH/DELICATE cycles will each provide an
additional rinse. If the rinse is desired, press the
switch to ON. When the extra rinse is not wanted,
OFF should be selected.
7. Select the cycle according to the type of
fabric being washed. Use the indicator dot on
the cycle selector knob as a guide.
8. Press and hold the START button for two
seconds to start the washer. The DOOR light
will come on after a short delay, water fill will
begin, and wash drum will begin tumbling.
NOTE: Washer door MUST be closed tightly to
start washer.
If items need to be added or removed after a cycle
has started, turn the cycle selector knob to the
OFF position. Wait until the DOOR light goes off
(approximately 45 seconds after cycle has been
stopped), open door, add or remove items, and
start the cycle again.
There is no agitator on this washer. Instead, the
clothing gently tumbles through the water. The
wash action consists of a period of tumbling in one
direction, a brief pause, and then a reverse tumble
in the opposite direction. The pauses are part of
the tumble action and add to the unique cleaning
capabilities of the washer. They are part of the
cycle.
NOTE: There will be extended pauses when
Boosted Hot Wash, if available, is selected
because the water is being heated.
To Change Cycles
If the selected cycle is not the correct cycle for the
fabric being washed, you may change the cycle
selection at any time until the first wash fill is
complete. Once the washer has filled for the first
part of the cycle (the wash portion), the current
cycle must be aborted and a new cycle must be
started.
To change the cycle before the first fill is
complete:
Change the cycle selected on the cycle selector
knob.
WARNING
Window may be hot in the Boosted Hot
and Hot wash cycles.
W325
TLW2078N
TLW2078N

-12-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
To change the cycle after the first fill is complete
and before the first wash is complete:
1. Abort the current cycle by changing the cycle
selector knob to the OFF position.
2. Set the WASH/RINSE temperature selector.
3. Set cycle selector knob.
4. Turn on extra rinse, if desired.
5. Press and hold the START button for two
seconds.
To change the cycle after the first wash is
complete:
NOTE: This should only be done if the speed of the
final extract is incorrect for the fabric being
washed. For example, if washing delicate items on
the REGULAR cycle, the high speed extract may
damage the fabric. Or, if washing towels or jeans
on the HANDWASH/DELICATE cycle, the lower
speed extract would increase drying time.
1. Abort the current cycle by changing the cycle
selector switch to the OFF position.
2. Restart the cycle from the beginning. Refer to
the To Wash Clothes section.
To Pump Out Water After Aborting Cycle
Run a SPIN ONLY cycle. This cycle will perform a high
speed extract operation that will pump all of the
water out of the washer.
Manual Soaking
To soak a clothes load, start a wash in the desired
cycle. After fill is complete and wash drum has
started tumbling, turn the cycle selector knob to
OFF. When the clothes have soaked the desired
length of time, turn the cycle selector knob to the
cycle and press the start button to restart the
cycle.
DOOR Light
When the washer is started, the DOOR light will
come on after a short delay. The light will turn off
approximately 45 seconds after the cycle is
complete.
WASH Light
This light comes on during the wash part of each
cycle.
RINSE Light
This light comes on for the rinse portion of each
cycle.
FINAL SPIN Light
This light comes on while the wash load is in the final
spin of the cycle.
HEATING Light (Red Light – on select
models only)
This light comeson during the Boosted Hot setting
only. While the washer is heating, the HEATING light
will turn on.
Out of Balance Load
If at the end of the cycle, the load is dripping wet,
the washer has limited the spin speed. This is to
prevent damage to the unit if there is a severely
unbalanced load.
If this condition occurs, redistribute the load
manually and run a RINSE & SPIN cycle.
If the condition persists, consider steps discussed
in the Before Washing section.

-13-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Available Washing Cycles
The cycles of your washer include several different
settings. Refer to the table below for what can be
expected during the cycles that you select.
Regular Cycle
Activity Water Temperatures
Wash Fill & Tumble Boosted Hot (select models),
Hot, Warm or Cold
Spin Pulse Spin
Rinse Fill & Tumble Cold
Spin Pulse Spin
Extra Rinse (Optional) Fill & Tumble Cold
Spin Pulse Spin
Final Rinse Fill & Tumble Warm or Cold
Spin Pulse Spin
Spin Medium Spin (650 rpm)
Final Spin High Spin (1000 rpm)
Fluff Tumble
Permanent Press Cycle
Activity Water Temperatures
Wash Fill & Tumble Boosted Hot (select models),
Hot, Warm or Cold
Spin Pulse Spin
Rinse Fill & Tumble Cold
Spin Pulse Spin
Extra Rinse (Optional) Fill & Tumble Cold
Spin Pulse Spin
Final Rinse Fill & Tumble Warm or Cold
Spin Pulse Spin
Spin Medium Spin (650 rpm)
Final Spin High Spin (1000 rpm)
Fluff Tumble

-14-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Common Washer Sounds
Handwash/Delicate Cycle
Activity Water Temperatures
Wash Fill & Tumble Boosted Hot (select models),
Hot, Warm or Cold
Spin Pulse Spin
Rinse Fill & Tumble Cold
Spin Pulse Spin
Extra Rinse (Optional) Fill & Tumble Cold
Spin Pulse Spin
Final Rinse Fill & Tumble Warm or Cold
Spin Pulse Spin
Final Spin Low Spin (500 rpm)
Fluff Tumble
Rinse & Spin Cycle
Activity Water Temperatures
Rinse Fill & Tumble Warm or Cold
Spin Pulse Spin
Spin Medium Spin (650 rpm)
Final Spin High Spin (1000 rpm)
Fluff Tumble
NOTE: The Rinse setting will give a cold rinse when the optional Extra Rinse is selected.
Sounds Cause
Accelerating This sound is heard during the spin portion of every cycle.
Tapping These sharp sounds may come from metal fasteners, zippers, belt buckles or coins hitting
the wash drum or door glass.
Thumping Washer may be out of balance. Washer is designed to balance the load. If the washer is
severely unbalanced, turn cycle selector knob to OFF and redistribute the load.
Rumbling Washer may not be level. Stop washer and adjust leveling legs. Refer to INSTALLATION
INSTRUCTIONS for details.

-15-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Using Your Dispenser Drawer
Detergent Compartment
The detergent compartment is located on the right
side of the dispenser drawer. Refer to
compartment 1 of illustration.
Use low sudsing, high efficiency (HE) powdered or
liquid detergents that are recommended for use
with frontload washers. Powdered bleach can also
be used in the dispenser along with the detergent.
NOTE: High efficiency (HE)
detergents are designed
especially for frontload washers
to reduce oversudsing and
maximize cleaning results. Look
for the HE logo or “high efficiency” on the
detergent’s label.
NOTE: If using non-HE detergent, avoid
oversudsing by using only 1/2 of the detergent
manufacturer's recommended amount.
When adding detergent, use only the recommended
amount. Adding too much detergent or using
regular sudsing detergent could result in an
oversudsing condition, which would require
additional rinsing with cold water. Use care when
adding detergent so as not to spill into the other
compartments. Detergent mixed with fabric
softener can make the softener gummy.
NOTE: The normal level of suds should be below
center of the door.
1Detergent
2Bleach
3Fabric Softener
3
21
FLW2172N

-16-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Liquid Bleach Compartment
The bleach compartment islocated in the left front
corner of the dispenser drawer. Refer to
compartment 2 of illustration. It has been
designed to prevent the dispensing of undiluted
bleach onto the clothes load.
Use liquid bleach in the dispenser. Powdered bleach
must not be used in this compartment. Powdered
bleach can be usedin the detergent compartment
only and can be added along with the detergent.
DO NOT use more than the maximum level
indicated for the bleach compartment. Adding
more than the maximum amount could result in
early dispensing of the product and possible
damage to fabrics.
Carefully pour recommended amount of bleach into
the compartment before starting wash load.
Be careful not to spill undiluted bleach. It is a
strong chemical and can damage some fabrics if it
is not properly diluted. Follow bleach
manufacturer’s label for proper use.
Carefully close dispenser door. Do not allow bleach
to spill into other compartments.
Fabric Softener Compartment
The fabric softener compartment is located in the
left rear corner of the dispenser drawer. Refer to
compartment 3 of illustration.
Use no more than the maximum level indicated for
the fabric softener compartment. Adding more
than the maximum amount could result in early
dispensing of the product and possible staining of
fabrics.
Add fabric softener to compartment before
beginning wash load. The fabric softener will be
dispensed during the last rinse cycle.
Carefully close dispenser door. Do not allow
softener to spill into other compartments.
To Clean the Dispenser
Pour hot water into the dispenser drawer, making
sure it flushes through each compartment. Use a
small brush to thoroughly clean out any residue.
It is not necessary to remove the dispenser drawer
for normal maintenance. If the dispenser drawer
needs to be removed for any reason, use dispenser
drawer removal tool, Part No. 318P4, to avoid
damage to the drawer.

-17-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Clothing Care
Clothing Concerns
To keep clothes looking white or bright, use good washing practices at all times to prevent a gradual build-up
of soil or water hardness minerals on them. If you notice that your clothes are not as bright as they should
be, take corrective measures immediately.
Problem Cause Solution
Gray or Dingy Clothes Insufficient Detergent Add recommended amount of low-sudsing detergent to
dispenser drawer before loading clothes. Mild detergents are
not suitable for average soil.
Improper Sorting Wash whites separately. Separate light from heavily soiled
items. Clothes can pick up soil from dirty wash water.
Water Not Hot Enough White clothes will stay whiter with hot wash water. Increase
temperature.
Yellowed Clothes Unremoved Soil Skin soil is hard to remove. Check hem edge of sheets and
pillowcases, bottom end of t-shirts, etc. If this portion is
white and center is yellow, the fabric contains unremoved soil.
Use sufficient detergent and a hot wash. Chlorine bleach or
powered bleach may be needed.
Clothes Stained from Iron in the
Water To test for an iron stain, use a rust remover that is recommended for use with washing machines on a portion of
the garment. Follow bottle directions for larger items.
Older Clothes Some white fabrics turn yellow with age and cannot be
whitened.
Clothes Tearing or Damaged Improper Use of Chlorine Bleach No correction for bleach damaged clothes. Always keep level
at or below maximum in bleach dispenser compartment.
Insufficient Precare Fasten all hooks and zippers. Mend tears. Remove objects
from pockets.
Excessive Lint Improper Sorting Fabrics that shed lint cannot be washed with fabrics that
receive lint.
Insufficient Detergent Use enough detergent so lint remains suspended in water and
flushed out. Do not oversuds the water.
Mixing Fabric Types Knits and permanent press attract lint. Wash these only with
similar items. Use fabric softener in dispenser drawer.
Wrinkling Improper Sorting Heavy items like towels should not be washed with light items
like nightgowns.
Improper Cycle Make sure cycle selected is appropriate for type of clothes.
Improper Temperature Using a warm or cold wash and a cold rinse reduces wrinkling.

-18-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Maintenance
Lubrication
•All moving parts are sealed in a permanent
supply of lubricant or are equipped with oilless
bearings. Additional lubrication will not be
necessary.
•Do not lubricate the door hinge. If the hinge
makes noise, replace the hinge.
Cold Weather Care
•If the washer is delivered on a cold day (below
freezing), or is stored in an unheated room or
area during the cold months, do not attempt
to operate it until the washer has had a
chance to warm up.
Care of Your Washer
•Use only a damp or sudsy cloth for cleaning
the control panel. Some spray pretreat
products may harm the finish on the control
panel or damage the interior of the hood.
•Wipe the washer cabinet as needed. If
detergent, bleach or other washing products
are spilled on the cabinet, wipe immediately.
Some products will cause permanent damage
if spilled on the cabinet.
•Do not use scouring pads or abrasive
cleansers.
•The wash drum and window will need no
particular care although they may need rinsing
or wiping after an unusual load has been
washed.
•The outside of the door window can be cleaned
with household window cleaner.
•Running an occasional rinse cycle with bleach
will help to avoid a musty smell in the wash
drum.
Cleaning Glass Sealing Area
In order to assure that the door properly seals
against water leaks, the following surfaces should
be wiped off periodically:
•The outside perimeter of the door glass where
the seal contacts the glass
•The front surface of the door seal lip
Usually a mild soap solution will work. If there is an
extreme build-up of minerals from a hard water
supply, the surfaces may need to be cleaned with a
lime removal chemical.
Replacing Hoses
•Hoses and other natural parts deteriorate
after extended use. Hoses may develop
cracks, blisters or material wear from the
temperature and constant high pressure they
are subjected to.
•All hoses should be checked on a monthly
basis for any visible signs of deterioration.Any
hose showing the signs of deterioration listed
above should be replaced immediately.
•All hoses should be replaced every five years.
Filter Screens
•Check the filter screens in the fill hoses for
debris or damage annually. Clean or replace
them if necessary.
•If the washer is filling with water slower than
normal, check the filter screens. Clean or
replace them if necessary.
•Order filter screen Part No. F270300 from
the nearest authorized
parts distributor.

-19-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Vacations and Extended
Non-Use
•To avoid possible property damage due to
flooding, turn off the water supply to the
washer whenever there will be an extended
period of non-use.
•Leave the loading door open during extended
periods of non-use to allow the wash drum to
dry out and avoid a musty smell.
Reinstallation of Shipping
Materials
To prevent damage while moving the unit, the
shipping materials MUST be reinstalled.
•Disconnect washer from electrical supply.
•While supporting the front access panel,
remove two screws from the bottom edge of
the panel.
•Gently lower the panel to remove it from the
washer.
•Place the shock sleeves on all four shock
absorbers. Refer to the illustration below.
•Insert hooked end of shipping brace into the
open slot of the motor mount.
•Attach the brace with the five bolts and
washers. Refer to the illustration below.
•Reinstall front access panel.
Refer to the INSTALLATION INSTRUCTIONS for
proper procedures whenever the washer is moved.
Cleaning Foreign Object Trap
The washer’s pump has a trap that may collect
foreign objects. The trap may need to be cleaned if
water is draining slower than usual. To clean:
•Disconnect washer from electrical supply.
•While supporting the front access panel,
remove two screws from the bottom edge of
the panel.
•Gently lower the panel to remove it from the
washer.
NOTE: The pump may have some water in it. Use a
rag or a container to catch water. If the wash
drum is full of water, use a wet/dry shop vacuum
to catch the water.
•With rag or vacuum ready, unscrew the cap on
the left side of the pump and remove trap.
•Clean the debris from
the trap.
•Reinstall the trap and
access panel.
•Reconnect washer to
electrical supply.
FLW2182N
FLW2182N
Shock
Sleeves
Bolts and Lockwashers
Motor
Mount
Hooked End of
Shipping Brace

-20-
802756
© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Preventative Maintenance
Follow these guidelines to ensure the washer
operates properly. Call for service if you observe any
of the following: water of any amount on the floor,
an increase in operating noise or water remaining in
the wash basket after a cycle.
Frequency Maintenance Procedure
Monthly 1. Check all hoses and the drain for leaks.
2. Check the door lock for proper operation.
3. Clean the dispenser drawer. Refer to Using Your Dispenser Drawer.
4. Check to make sure the washer is level.
Every six months 1. Clean the filter screens in the fill hoses.
2. Clean the door gasket with a bleach and water solution.
Every five years Have a qualified service technician conduct general preventative maintenance on the washer to ensure it
operates properly.
