Datasheet | Multi-Rate Pluggable Transceivers

AT-SPZX80

80km 1000ZX SFP

Industry Standard

The AT-SP series offers the latest industry

standard in flexible, full-duplex Gigabit Ethernet

connectivity.These hot-swappable, fiber

interfaces simply plug into a SFP slot on

Allied Telesis SFP compatible products.

Configurations can be optimized to meet varied

distance and service requirements.

Product Compatibility

The AT-SP series SFPs are compatible with all

the Allied Telesis range of products that support

SFP uplink connections.

Technical Specifications

Media Type SMF

Wavelength 1550nm

Maximum Data Rate 1.25Gbps

Distance 80km

Digital Diagnostics Yes

Transmit Power (min) 0dBm

Transmit Power (typ) 2dBm

Transmit Power (max) -3dBm

Receive Sensitivity (typ) -26dBm

Receive Sensitivity (max) -24dBm

Power Budget (min) 24dBm

Fiber Connectors: LC

StandardData Rates Supported

Optical Gigabit Ethernet

Environmental Specifications

Operating Temp. -5°C to 70°C

Operating Humidity 0% to 85% (non-condensing)

Storage Temperature -40°C to 85°C

Storage Humidity 0% to 85% (non-condensing)

Key Features

•Copper and fiber solutions

•Connect up to 80km

•Compact size

•Flexible architecture

•Plug & Play ease-of-use

•Self-locking mechanism

•Data: support for fiber channel and 2x fiber

channel

•Telecom: support for OC3/STM-1,

OC12/STM-4 and OC48/STM-16

•Two year warranty

Ordering Information

AT-SPZX80

80km 1000ZX SFP,9Micron SMF (1550nm)

AT-SPZX80

Small Form Pluggable (SFP) Modules

©2007 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000145 Rev F
