Datasheet | Media Converters
AT-MC104
Fiber SC multi-mode to fiber SC single-mode
media converters
Fiber Connections
The Allied Telesis range of Fast Ethernet media
converters provide a complete family of
conversion devices, allowing users to extend the
size of UTP and multi-mode fiber networks with
the use of single-mode fiber cabling. Supporting
SC connected single-mode fiber, these
converters can be used to extend networks up
to a distance of 40km.
Auto-negotiation and MissingLink™
When connecting media converters to auto-
negotiating Fast Ethernet switches, these media
converters will automatically connect the link in
either full or half-duplex mode, allowing the link
to be established with the greatest bandwidth.
Alternatively, the MissingLink™ feature allows
accurate reporting to network management
systems as well as allowing devices with
redundant link capability to be inter-connected
with these media converters, as a failure in one
fiber link will be signalled to the switch, allowing
the second link to become active.
Simple Installation
The media converters allow the installer to test
the integrity of fiber connection, by forcing the
converters to communicate over the fiber cable.
This Link Test feature allows installers to check
for cable faults without the need for expensive
fiber-optic test equipment.
Standalone or Rack-mount
Each small media converter is powered by an
external power supply unit for use in standalone
applications. Where multiple media converters
are being used, up to 12 standalone devices can
be inserted into a low-cost rack-mount chassis,
allowing all the converters to be powered by a
single internal power supply. In critical
applications, a second load sharing internal
power supply can be installed into the rack-
mount chassis.
Hassle Free Support
Allied Telesis Fast Ethernet media converters
offer free technical support, ensuring trouble-
free installation.
Key Features
•Half and full-duplex operation
•Transparent to IEEE 802.1Q packets
•Rack-mountable using optional
AT-MCR12,AT-TRAY4 or AT-TRAY1 chassis
•Wall-mountable using AT-WLMT
•MissingLink™
•Link Test
•RoHS Compliant
MC104 Series
Fast Ethernet Media Converters
Allied T
elesis www.alliedtelesis.com

Link Test
The link test is a fast and easy way for you to test the
connections between the media converter ports and the
end-nodes that are connected to the ports. If a network
problem occurs, you can perform a link test to
determine which port is experiencing a problem, and be
able to focus your troubleshooting efforts on the cable
or end-node where the problem resides.
MissingLinkTM
The MissingLinkTM feature enables the two ports on the
media converter to pass the ‘Link’ status of their
connections to each other. When the media converter
detects a loss of connection to an end-node, the media
converter shuts down the connection to the other port,
thus notifying the end-node that the connection has
been lost.
Technical Specifications
Status Indicators
Front Panel
Power Indicates power is applied to the
converter
Link (2) Indicates a valid receive link exists
Activity (2) Indicates TX/RX on the port
ML Indicates MissingLinkTM enabled
Switches
ML Indicates MissingLinkTM enabled
Packet Transmission Characteristics
Round Trip Delay 0.4µs Maximum
Bit Error Rate (BER) <10-12
Power Characteristics
External Power Supply 120V AC, 60Hz (US model)
240V AC, 50Hz (European models)
Input Supply Voltage 12vDC
Max Current 500mA
Power Consumption 6W
Environmental Specifications
Operating Temp 0°C to 40°C
(32°F to 104°F)
Storage Temp. –20°C to 80°C
Relative Humidity 5% to 95% non-condensing
Operating Altitude 0 to 10,000 feet
RoHS Compliant
Physical Characteristics
Dimensions 10.5cm x 9.5cm x 2.5cm
(W x D x H) (4.12” x 3.75” x 1.0”)
Weight 294g (10.4oz)
Electrical/Mechanical Approvals
EMC FCC Class A
Safety compliant UL-Cul, CSA/CSA, NRTL, TUV,
CE compliant
Ordering Information
AT-MC104XL-xx
Multi-mode fiber to single-mode SC (15km) fiber
AT-MC104LH-xx
Multi-mode fiber to single-mode SC (40km) fiber
Where xx = 10 AC power supply, US power cord
20 AC power supply, European power cord
30 AC power supply, UK power cord
40 AC power supply, Australian power cord
Associated Products
AT-TRAY1
Rack-mounting tray for one media converter
AT-TRAY4
Rack-mounting tray for up to four media converters
AT-WLMT
Wall-mount bracket for one cedia converter
AT-MCR12
12 slot AC/DC powered chassis for cedia converters
MC104 Series |Fast Ethernet Media Converters
USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |T: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 T
ai Seng Link |Singapore |534182 |T: [phone] |F: [phone]
www.alliedtelesis.com
©2007 Allied T
elesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-00340-00 Rev F
Port Type
(Connector)
Cable
Distance
Optical
Frequency
Launch Power (dBm) Receive Power (dBm)
Max. Avg. Min. Min.
Sensitivity
Typical
Sensitivity Saturation
100FX MMF (2km) 2km 1310nm -14.0 -16.8 -19.0 -31.8 -34.5 -14.0
100FX SMF (15km) 15km 1310nm -8.0 -11.5 -15.0 -31.0 -31.0 -8.0
100FX SMF (40km) 40km 1310nm 0.0 -3.0 -5.0 -35.0 -38.0 0.0
