Allmand MH 1000 Product manual

MODEL MH-1000
ALLMAND BROS. INC
P.O. BOX 888
HOLDREGE, NE 68949
PHONE: [phone]
FAX: [phone]
PARTS FAX: [phone]
MAXI-HEAT® SERIES
MAXI-HEAT®SERIES
OPERATOR’S AND PARTS MANUAL
SEPTEMBER 2011
For Parts and Updates visit Allmand on the Web at www.allmand.com
REV H-1 IDF 500
Beginning with Serial Number 0001MXH09
80025368_B
Not for Reproduction

Not for Reproduction

2
OPERATORS MANUAL
I nspection Check List.....................................................................3
Introduction....................................................................................4
Safety Decals.................................................................................5
Set-up Procedure...........................................................................8
Specications.................................................................................9
Serial Number Location..................................................................9
Fuel and Lubricating Oil...............................................................10
Starting Procedure........................................................................11
Maintenance and Towing Instructions..........................................12
Troubleshooting Heaters..............................................................13
Electrical Schematics...................................................................17
Ductwork Installation Options.......................................................22
PARTS MANUAL
Trailer Assembly Parts and Accessories................................ A-1A
Heater Assembly Parts and Accessories............................... B-1A
Engine/Generator Assembly Parts andAccessories............. C-1A
Optional Parts and Accessories.............................................. D-1A
Decals..................................................................................... E-1A
Warranty...............................................................Inside Back Cover
Note: Call out item numbers are continuous through each section of the parts
manual.
TABLE OF CONTENTS
RECORDS
Serial Number:
Model Number:
Engine Type:
Engine Serial Number:
Accessories:
Not for Reproduction

23
PREPARING THE MAXI-HEAT FOR DELIVERY OR RENTAL
The Allmand Maxi-Heat®requires service as well as proper operation in order to provide the
performance and safety for which it was designed. Never deliver or put a machine into ser-
vice with known defects or missing instructions or decals. Always instruct the customer in
the proper operation and safety procedures as described in the operator’s manual. Always
provide the manual with the equipment for proper and safe operation.
Check List:
 Visually inspect the equipment to ensure that all instructions and decals are in place and
legible.
 Check the hitch assembly and safety tow chains.
 Check the jack to make sure it operates properly.
 Inspectthetirestoensuregoodconditionandproperination.
 Checklugnutsandtorqueto80-90ft.lbs.Lugnutsshouldberetorquedafterrst100
mi of towing.
 Check the ground rod cable and the ground lug. Make sure they are clean, undamaged
and functional.
 Make sure the battery is fully charged and the terminals are tight and clean. Ensure the
electrolyte is at the correct level.
 Checktheserviceintervalsforoillters,fuellter,aircleanerandengineoil(seeopera-
tor’s manual).
 Check the oil, fuel and coolant levels.
 Start engine and turn heaters on to ensure proper operation.
 Check to make sure the operator’s manual is with the equipment.
NOTE: See operator’s manual for scheduled maintenance intervals.
SAFETY WARNING!
NEVER ALLOW ANYONE TO OPERATE THE EOUIPMENT WITHOUT
PROPER TRAINING.
ALWAYS READ THE INSTRUCTIONS FIRST.
INSPECTION CHECK LIST
Not for Reproduction

4
4
INTRODUCTION
SAFETY SYMBOLS
The purpose of the SAFETY INFORMATION SYMBOL shown below is to at-
tract your special attention to safety-related information contained in the text.
SAFETY WARNING!
FAILURE TO UNDERSTAND AND COMPLY WITH SAFETY RELATED
INFORMATION AND INSTRUCTIONS MAY RESULT IN INJURY TO THE
OPERATOR OR OTHERS. IF YOU DO NOT UNDERSTAND ANY PART
OF THIS INFORMATION CONTACT YOUR DEALER FOR CLARIFICA-
TION PRIOR TO OPERATING EQUIPMENT.
The word NOTE is used to bring your attention to supplementary
information in relation to various aspects of proper operation and
maintenance.
NOTE: Keep this manual accessible during operation to
provide convenient reference.
NOTE: Any reference in this manual to LEFT or RIGHT
shall be determined by looking at the trailer from the REAR.
This manual provides the information necessary for the safe operation and
maintenance of the Allmand Maxi-Heat®.
Specicoperatingdetailsandspecicationsarecontainedinthispublication
to familiarize the operator and maintenance person with the correct and safe
procedures necessary to maintain and operate this equipment.
Take time to read this book thoroughly. If you are uncertain about any of the
informationcontainedinthismanual,contactyourdealerforclaricationbe-
fore operation of the machine.
NOTE:
Not for Reproduction

4
45
SAFETY DECALS
SAFETY WARNING!
ALWAYS REPLACE ANY SAFETY AND
INSTRUCTION DECALS THAT BECOME
DAMAGED, PAINTED, OR OTHERWISE
ILLEGIBLE.
Refer to these reperesentations
of the safety warning decals used
on the Maxi-Heat to insure correct
ordering if replacing becomes neces-
PART NO. 090023
Inside Rear Door
PART NO. 090108
Left Side of Trailer
PART NO. 090120
Left Side of Trailer
PART NO. 090133
Left Side of Trailer
PART NO. 090042
Inside Rear Door PART NO. 090143
Inside Rear Door
PART NO. 090122
Right Side of Trailer
should be checked
and replacedif necessary.
PART NO. 090147
Inside Heater Outlet Door PART NO. 090179
Inside Rear Door
PART NO. 090163
Breaker Box Lid in
Engine Compartment
Not for Reproduction

6
6
PART NO. 09007
Inside Rear Door
PART NO. 090304
Inside Rear Door
HEATER OPERATING INSTRUCTIONS
Inside Rear Door
FAN SHUTDOWN INSTRUCTIONS
Inside Rear Door
SAFETY DECALS
Not for Reproduction

6
67
SAFETY DECALS
PART NO. 100910
CAUTION
1). NEUTRAL BONDED TO FRAME
2). MACHINE TO BE GROUNDED IN ACCORDANCE WITH REQUIREMENTS AS OUTLINED BY LOCAL INSPECTIONSAUTHORITIES
3). TURN OFFALL POWER BEFORE SERVICING
4). THE REQUIREMENTS OF LOCALAUTHORITIES HAVING JURISDICTION SHALL BE FOLLOWED
5). DO NOT START THE HEATER WHEN EXCESS OIL HAS ACCUMULATED IN THE CHAMBER
6). DO NOT FILLTHE TANK WHILE THE UNIT IS OPERATING
7). DO NOT TAMPER WITH THE UNIT. ONLY COMPETENT SERVICEMEN SHOULD MAKEADJUSTMENTS
8). DO NOT OPERATE THE UNIT IN CLOSE PROXIMITY TO COMBUSTIBLE SURFACES OR MATERIALS
101062
GROUND ROD USE INSTRUCTIONS
1). Remove the ground rod stowed inside trailer (on le side, near engine)
2). Unroll the electrical wire lead from the ground rod
3). Drive the ground rod a minimum of 2-1/2 FT into the earth for adequate electrical ground. Consult local
authories for more informaon.
4). Aach the ground rod lead wire to the ground lug
5). AFTER SHUTDOWN OF MACHINE: Remove the lead connecng the ground rod to the unit; remove the
ground rod from the earth; and return ground rod to storage locaon inside trailer 101063
PART NO. 101062
GENERAL CAUTION STATEMENT
PART NO. 101063
GROUND ROD USE INSTRUCTIONS
Not for Reproduction

8
8
MAXI-HEAT®SETUP PROCEDURE
TheFrostFighterheaterunitsneedtobesetupforeachoperationandtunedtooperateefciently
depending on the altitude of intended use. As you go up in elevation, the air gets thinner. As the air
gets thinner the ability to burn or consume a certain amount of fuel is diminished. When you move the
machine to a different elevation you may need to change the nozzle size and air settings to get a clean
efcientburn.Thenozzlesizeisdeterminedbythenumberofgallonsperhournumber(GPH).Anumber
is stamped on the nozzle indicating the amount of fuel that the nozzle will deliver to the burning chamber.
For higher elevations, selecting a nozzle that delivers less fuel allows you to make the air mixture adjust-
mentsneededtoburnallofthefuelwithlessair(thinnerair).
Test Equipment:
Bacharach Oil Burner Smoke Tester – is used to determine the amount of soot in the exhaust gasses.
This can indicate the level of combustion being achieved. It is recommended that the Smoke Tester be
used for tuning the Maxi Heat Frost Fighters.
Instructions for setting up the Maxi Heat at elevations above sea level.
1. Installfuelpressuregages(ifnotequipped).
2. Set Fuel Pressure to 140 PSI
3. Head Setting at #6.
4. Shutter Setting – Full open. #5Setting.
· Fine adjustment – very little change in air mixture results when changing the settings from 1 to
10.
5. Band Setting - ½ open. — #5 Setting
· Starting at 50% open allows adjustment in both directions during tuning.
6. Installnozzlesizethatgivesamediumtogoodburn(2or3)onTrue-SpotSmokeTester
· While the fuel pressure is maintained at 140 PSI, Head Setting at #6, and Shutter and Band Set-
tings are at the #10 and #5 settings, test nozzles until you have a nozzle that gives satisfactory
initial smoke tester readings.
· Example:
1. Initialstartupwithsettingsasnotedabove(Fuel140PSI,Shutter#10,Band#5)givesa
smokereadingbetween6&9(heavysmokeonteststripwithvisiblesmokecomingfromthe
stack and possibly a rumbling sound coming from the burner.
2. Smokeindicatestoomuchfuelornotenoughair.(fuelnotbeingtotallyburned)
Action:
1. Turn off switch and let the Frost Fighter cool down.
2. Shut off the power to the Frost Fighter.
3. RemoveFuelRail,anddeterminethenozzleratinginGPH(gallonsperhour)e.g.3.
4. Selectanozzlethathasanoutputlowerthan3.(Readthefollowingsuggestionsforselectinga
nozzle size and depending on the initial startup and smoke test readings you can make an informed
decision on which nozzle to select.
· For heavy smoke and a rumbling sound you may select a 2.5 GPH nozzle for the next test.
· For heavy smoke and no rumbling, you may want to select a 2.75 GPH nozzle for the next test.
5. Install nozzle,
Not for Reproduction

8
89
ENGINE/GENERATOR
ISUZU 3CE1 Diesel Engine
Starting: 12V Electric 8D Battery
Oil sump capacity: 6.7qts(6.3L)
Low Oil Pressure Shutdown: Solenoid actuated fuel
rack instant shutdown
Generator: 8kW , 60 Hz, 1-ph, 1800 rpm
CAT C1.5 Diesel Engine
Starting: 12V Electric 8D Battery
Oil sump capacity: 5.9qts(5.6L)
Low Oil Pressure Shutdown: Solenoid actuated fuel
rack instant shutdown
Generator: 8kW , 60 Hz, 1-ph, 1800 rpm
DIMENSIONS
Height: 6’
Length: 16’
Width: 6’ 8”
SPECIFICATIONS AND SERIAL NUMBERING LOCATION
HEATERS
Two(2)I.C.E.FrostFighterIDF500
325,000 BTU Output with 2.5 gph, 60° solid nozzle
WEIGHT
Empty: 3,500 lbs.
With Fuel: 4,651 lbs.
Eachstandardheaterincludesone(1)16in.
heated air outlet, which connects easily to the
ducting. Limit to 110feet of 16” ducting.
Heated Air Output: 2,850 CFM per heater w/o duct.
Temperature Rise:185°with duct creating
0.5 in. static pressure
Operating Time: More than 24 hours without refuel-
SERIAL NUMBER LOCATIONS
TRAILER: Plate attached to right rear corner of
frame
ISUZU ENGINE: Plate attached to top of valve
cover
CAT ENGINE: Plate attached to injector pump on
right side of engine
FUEL SYSTEM
Fuel Requirements: No.1 fuel oil
Fuel Capacity: 191.1 Gallons
Fuel Consumption:
Engine:ISUZU3CD10.5gal/hour(1.9L/
hr)
Engine:CATC1.50.5gal/hour(1.9L/hr)
6. Checkignitertipsforcorrectlocationfortheunityouaresettingup.Adjustifnecessary.(seeowners
manual)
For the IDF 500:
· 5/32 apart
· ¼” above center of nozzle
· 1/8” in front of nozzle
7. Re-install the fuel rail, hook up fuel lines etc.
8. RestarttheheaterandchecktheuegasforsmokeusingtheTrue-SpotSmokeTester.
9. Ifyougetasmoketestreadinginthe2to3rangeyouwillbereadytonetunetheburnerto
achieve a #1 or possibly a 0 on the smoke scale. If you still have heavy smoke, you may have to go
downanothernozzlesizetobeabletogettheburnertoburnefciently.
Fine Tuning the Frost Fighter Burners
1. Use the True-Spot Smoke Tester to determine where you are on the Smoke Scale.
2. To reduce the amount of smoke, open the band 1 or 2 numbers and recheck with the True-Spot
Smoke Tester.
3. Make further adjustments if necessary to achieve the lowest number you can on the Smoke Scale.
4. Tighten the air band and shutter-securing screws to prevent them from moving after you have made
the adjustments.
MAXI-HEAT®SETUP PROCEDURE
Not for Reproduction

10
10
FUEL AND LUBRICATING OIL
The temperatures mentioned in the table are
the ambient temperatures at the time the engine is
started. However, if the running ambient tempera-
tures are much higher than the starting tempera-
tures, a compromise must be struck and a higher
viscosityoilused(providedstartingissatisfactory).
Multigrade oils overcome the problem provided
theyhaveasuitablespecication.
NOTE: In testing this engine at the factory, the
manufacturer uses on oil for moderate and low tem-
peratures. This oil is specially formulated to assist
in the break in period, and the manufacturer would
like this oil to be left in the engine for the rst 50
hours. Additional information on fuel and lubrication
specications can be found in the Engine Instruction
Manual.
Periodic Maintenance Schedule
FUEL AND LUBRICATING OIL REQUIREMENTS
Isuzu 3CD1 CAT C1.5
Not for Reproduction

10
10 11
HEATER STARTING:
NOTE: Circuit breakers for heaters must be switched
to the ON position.
NOTE. Allow engine to come to full RPM and warm
up before starting heaters.
1.With engine operating, turn toggle switch at heater
to manual position.
IF HEATER FAILS TO START:
1.Press and hold manual reset button on burner relay
for 30 seconds.
2.Check fuel level.
3.Checkfuellterandsuctiontubing.
4. Check nozzle assembly.
BEFORE TURNING THE ENGINE OFF, THE
HEATERS MUST BE SWITCHED TO THE
POSITION WHICH ALLOWS THE FANS TO
COMPLETE A COOL DOWN CYCLE FOR THE
HEAT EXCHANGER
TO STOP HEATER:
Flip switch to “OFF” position
BURNERS WILL STOP BUT THE FAN WILL
AUTOMATICALLY CONTINUE TO CYCLE UN-
TIL THE UNIT COOLS DOWN
ENGINE SHUTDOWN:
1. Shut heater off. Allow time for the fans to turn off.
2. Turn ignition switch to “OFF” position.
BEFORE STARTING:
1.Filltheenginewiththespeciedgradeandquan-
 tityoflubricatingoiltocorrectlevel(check
dipstick).
2.Ensure there is an adequate supply of fuel.
3.Ensurethattheaircleanerisrmlyattachedand
air joints are properly sealed. Air cleaner element
should be checked and replaced if necessary.
STARTING ENGINE
1.Heater switches must be in OFF position.
2.Open door for heater outlets.
NOTE: Engine will not start with heater outlet
door closed.
3.Turn the key switch to the PREHEAT position,hold
until the glow indicator light goes out, then release
switch.
4.Turn the key switch to the START position and the
engine should start. Release the key immediately
when the engine starts. If engine fails to start it
may be necessary to cycle the glow plugs again.
NOTE: If engine fails to start, see engine opera-
tors
handbook for cold start procedures.
NOTE: The low engine oil pressure shutdown sole-
noid is activated by an oil pressure switch, therefore
it will take several seconds of engine cranking to
build oil pressure in the switch before fuel will be al-
lowed to the engine.
OPERATING INSTRUCTIONS
1.Do not start heater when excess oil has
accumulated in chamber.
2.Donotllfueltankwhileunitisoperating.
3.Do not shut off by disconnecting supply cord.
4.Do not use gasoline, crankcase oil or heavier
STARTING PROCEDURES
SAFETY WARNING!
SAFETY WARNING!
Not for Reproduction

12
12
NOTE: DO NOT TAMPER WITH UNIT. HAVE A
COMPETENT SERVICEMAN MAKE ANY ADJUST-
MENTS.
NOTE: Before moving guards out of position insure
power cord is disconnected.
SAFETY WARNING!
FAN COULD CYCLE ON AUTOMATICALLY
High Limit Switch:
The limit switch should be checked every heating
season to insure the burner will shut down if temper-
ature exceeds 200°F
  *Thiscanbedonebyrestrictingtheairow
through the unit. After tests are complete, re-
move
restrictors as ducts must be open for proper
operation.
Fan Switch:
The adjustable fan switch will turn on the fan when
the heat exchanger temperature is at 900F and off at
600F. If the fan fails to stop when the heat exchanger
has cooled, replace switch.
Fuel Filter:
Replace element at least every six months of normal
usage, or more frequently in dirty conditions.
Flame Detector:
Theamedetectorislocatedintheburnerhousing
below the transformer. Periodically clean cell detec-
tor face with
a soft nonabrasive cloth.
Burner:
The electrode spacing must be checked and adjust-
ed, if necessary, after every nozzle change. Nozzles
should be replaced annually or sooner if burner
cannot be set up to operate properly. Nozzle size is
dependent on altitude of operation. Nozzle size and
type are marked on the rating plate.
Motors:
No lubrication is necessary since the bearings are
the sealed type.
Fuel System:
Do not store unit containing diesel fuel for long periods.
MAINTENANCE AND TOWING INSTRUCTIONS
NOTE: Service intervals have been estab-
lished for operation under normal conditions.
Where equipment is operated under severe
conditions(very dusty, extreme cold, etc.) af-
fected items should be serviced more frequently.
For detailed information see the Engine Instruc-
tion Manual for Heater Unit Installation-Operating
Maintenance instructions.
CLEANING PROCEDURE
The unit should be cleaned periodically as follows:
1. Remove front cap.
2. Removecoverpanel(jackettofront).
3. Remove fan thermostat cover on outer jacket
 (onthenearestburner).Loosenthethermostat
and remove from the jacket. Remove high limit
thermostat.
4. Slide heat exchanger out of jacket and place
frontfacedownonoor.
5. Access for combustion chamber and heat
exchanger cleaning is obtained through the
burner head opening and by removing the heat
 exchangercapring(s).
TOWING INSTRUCTIONS
Before towing the Maxi-Heat, the trailer should
be inspected visually to assure that the following
operations have been completed:
1. Hitch is securely attached to towing vehicle
 (safetychainsecured).
2. Front jack retracted.
3. Ducting removed from heaters and stored.
4. Doors are closed and secure.
5. Check for adequate tire pressure.
6. Taillights are connected and operating.
7. Remove ground rod from earth and secure in
trailer.
Not for Reproduction

CLEANING PROCEDURE
Not for Reproduction

CLEANING PROCEDURE
Not for Reproduction

12
12 13
TROUBLESHOOTING
Electrode Adjustments
Not for Reproduction

14
14
TROUBLESHOOTING
Not for Reproduction

14
14 15
TROUBLESHOOTING
Not for Reproduction

16
16
TROUBLESHOOTING
Not for Reproduction

16
16 17
TAILLIGHT WIRING SCHEMATIC
Not for Reproduction
