Alpha ESS Storion-SMILE-T10 User manual

V01
Installation Manual
Energy Storage System (ESS)
Storion-SMILE-T10

___________________________________________________________________
Alpha ESS Co., Ltd. Page I of 46
Your Smart Energy
IMPRINT
IMPRINT
Germany
Alpha ESS Europe GmbH
Tel.: [phone]
E-mail: [email protected]
Web: www.alpha-ess.de
Add: Paul-Ehrlich-Straße 1a
63225 Langen
China
Alpha ESS Co., Ltd.
Tel.: [phone]
E-mail: [email protected]
Web: www.alpha-ess.com
Add: JiuHua Road 888, High-Tech Industrial Development Zone
226300 Nantong City, Jiangsu Province
Australia
Alpha ESS Australia Pty. Ltd.
Tel.: [phone]
E-mail: [email protected]
Web: www.alpha-ess.com.au
Add: Suite 1, Level 1, 530 Botany Road, Alexandria, NSW, 2015
Italy
Alpha ESS Italy S.r.l.
Tel.: [phone]
E-mail: [email protected]
Web: https://it.alpha-ess.com/
Add: Via Loda,17-41013 Castelfranco Emilia(MO)
Dec. 16th, 2018

___________________________________________________________________
Alpha ESS Co., Ltd.
Page II of 46
Your Smart Energy
Copyright Statement
Copyright Statement
This manual is under the copyright of Alpha ESS Co., Ltd. with all rights reserved.
Please keep the manual properly and operate in strict accordance with all safety and
operating instructions in this manual. Please do not operate the system without read-
ing through the manual.
Version Information
Version
Date
Content
V01
16122018
new

___________________________________________________________________
Alpha ESS Co., Ltd. Page III of 46
Your Smart Energy
Content
Content
IMPRINT.......................................................................................................................I
Copyright Statement.................................................................................................II
Version Information ..................................................................................................II
Content......................................................................................................................III
Introduction...........................................................................................................5
1.1System Introduction.......................................................................................5
1.2 General Precautions.......................................................................................6
1.3 Parts List .........................................................................................................8
1.4 System Appearance......................................................................................10
1.4.1 Battery .......................................................................................................................10
1.4.2 HV50056....................................................................................................................12
1.4.3 Inverter Cable Box.....................................................................................................13
1.5 Liability Limitation........................................................................................13
Installation...........................................................................................................14
2.1 Installation Site and Environment...............................................................14
2.1.1 General......................................................................................................................14
2.1.2 Restricted Locations..................................................................................................15
2.2 Installation.....................................................................................................16
2.3 Wiring.............................................................................................................22
2.4 Power Meter ..................................................................................................30
2.4.1 Meter ADL-3000 (If Applicable) .................................................................................30
2.4.2 ACR10R Meter (If Applicable)...................................................................................34
System Operation ...............................................................................................35
3.1 Switch on.......................................................................................................35
3.2 Switch off.......................................................................................................35
EMS Introduction and Set up.............................................................................36
4.1 Function Description....................................................................................36
4.2 Setting............................................................................................................37
4.3 EMS Communication Checking...................................................................40
4.4 Assembling of the Front Panels..................................................................41

___________________________________________________________________
Alpha ESS Co., Ltd.
Page IV of 46
Your Smart Energy
Content
Online Monitoring............................................................................................... 41
Annex................................................................................................................... 44
6.1 Datasheet –AlphaESS Storion-SMILE-T10................................................ 44

___________________________________________________________________
Alpha ESS Co., Ltd. Page 5 of 46
Your Smart Energy
Introduction
Introduction
1.1 System Introduction
AlphaESS Storion-SMILE-T10 (incl. M4856-S, HV50056 and SMILE-T10-INV) can be
applied in DC-coupled systems (mostly new installation), AC-coupled systems (mostly
retrofit) and Hybrid-coupled systems (mostly retrofit, and PV capacity-increase), as the
following scheme:
Figure 1 DC-coupled Storage System – Scheme
Figure 2 AC-coupled Storage System – Scheme

___________________________________________________________________
Alpha ESS Co., Ltd.
Page 6 of 46
Your Smart Energy
Introduction
Figure 3 Hybrid-coupled Storage System – Scheme
CAUTION:
For the AC-/ Hybrid-coupled system, unlike DC, two power meters are to be
mounted.
1.2 General Precautions
DANGER
Danger to life due to high voltages of the PV array, battery and electric shock.
When exposed to sunlight, the PV array generates dangerous DC voltage which will
be present in the DC conductors and the live components of the inverter. Touching
the DC conductors or the live components can lead to lethal electric shocks. If you
disconnect the DC connectors from the system under load, an electric arc may occur
leading to electric shock and burns.
Do not touch uninsulated cable ends.
Do not touch the DC conductors.
Do not open the inverter and battery.
Do not wipe the system with damp cloth.
Have the system installed and commissioned by qualified people with the
appropriate skills only.
Prior to performing any work on the inverter or the battery pack, disconnect
the inverter from all voltage sources as described in this document.
WARNING
Risk of chemical burns from electrolyte or toxic gases.
During standard operation, no electrolyte shall leak from the battery pack and no
toxic gases shall form. Despite careful construction, if the Battery Pack is damaged
or a fault occurs, it is possible that electrolyte may be leaked or toxic gases formed.

___________________________________________________________________
Alpha ESS Co., Ltd. Page 7 of 46
Your Smart Energy
Introduction
Do not install the system in any environment of temperature below -10°C or
over 50°C and in which humidity is over 85%.
Do not touch the system with wet hands.
Do not put any heavy objects on top of the system.
Do not damage the system with sharp objects.
Do not install or operate the system in potentially explosive atmospheres or
areas of high humidity.
Do not mount the inverter and the battery pack in areas containing highly
flammable materials or gases.
If moisture has penetrated the system (e.g. due to a damaged enclosure),
do not install or operate the system.
Do not move the system when it is already connected with battery modules.
Secure the system to prevent tipping with restraining straps in your vehicle.
The transportation of AlphaESS Storion-SMILE-T10 must be made by the
manufacturer or an instructed personal. These instructions shall be recorded
and repeated.
A certified ABC fire extinguisher with minimum capacity of 2kg must be
carried along when transporting.
It is totally prohibited to smoke in the vehicle as well as close to the vehicle
when loading and unloading.
For the exchange of a battery module, please request for new hazardous
goods packaging if needed, pack it and let it be picked up by the suppliers.
In case of contact with electrolyte, rinse the affected areas immediately with
water and consult a doctor without delay.
CAUTION:
Risk of injury through lifting or dropping the system.
The inverter and battery are heavy. There is risk of injury if the inverter or battery is
lifted incorrectly or dropped during transport or when attaching to or removing from
the wall.
Lifting and transporting the inverter and battery must be carried out by more
than 1 person.

___________________________________________________________________
Alpha ESS Co., Ltd.
Page 8 of 46
Your Smart Energy
Introduction
1.3 Parts List
Check the following parts list to ensure it is complete.
AlphaESS delivers a total system separately on site to client, this consists of:
SMILE-T10_INV
T10-INV box (X1)
Communication
cable (X1)
Screw package:
Expansion tube (X6)
Expansion screw
(X6)
DC power cables:
Positive-Negative
power line (X1)
Gasket (X6)
AC terminal (X12)
Cable bond (X1)
Hexagon nuts with
flange (X2)
Cable tie (X30)
Communication
cable (X1)
BAT-BAT
DC connectors:
Positive X2, negative
X2
Bracket A (X1)
Bracket B (X1)
3-phasig Meter (X1):
ADL3000 or ACR10R
Installation Manual
(X1)
M4856-S
Battery pack (X1)
PE Protective bag
(X1)
Screw M5*10(X4)
Screw package:
Expansion tube (X4)
Expansion screw (X4)
Gasket (X4)

___________________________________________________________________
Alpha ESS Co., Ltd. Page 9 of 46
Your Smart Energy
Introduction
Bracket (X2)
Battery connector:
Black power line
(X1)
Battery
communication line
(X1)
Hexagon nuts with
flange (X4)
Cable tie (X6)
HV50056
HV50056 box (X1)
RJ45 Connectors
(X12)
Screw package:
Expansion tube (X5)
Expansion screw (X5)
Battery power cables:
Positive power cable
(X1)
Negative power cable
(X1)
Gasket (X5)
Terminal resistance
(X1)
Cable bond (X1)
Hexagon nuts with
flange (X4)
User Manual (X1):
M4856-S&HV50056
Quick Installation
Manual (X1):
M4856-S&HV50056

___________________________________________________________________
Alpha ESS Co., Ltd.
Page 10 of 46
Your Smart Energy
Introduction
1.4 System Appearance
Figure 4 Storion-SMILE-T10 Delivery Scope
Object
Description
1
Hybrid Inverter with Cable Box
2
HV50056 (High-voltage Control Box)
3
M4856-S (BAT1)
4
M4856-S (BAT2)
5
M4856-S (BAT3)
6
M4856-S (BAT4)
1.4.1 Battery
1
2
3
4
5

___________________________________________________________________
Alpha ESS Co., Ltd. Page 11 of 46
Your Smart Energy
Introduction
1.4.1.1 Specifications
Figure 5 M4856 Inteface Definition
No.
Description
1
Positive Pole
2
Negative Pole
3
2 x COM Port (CAN)
4
Dip Switch
5
LED
1.4.1.2 LED Display
In normal condition, LED display three status:
Status
Normal
Protection
LED Display
Green light blinks for
1sec
Red light blinks for
1sec
Red and green light
blink for 1sec
1
2
3
4
5
Fault

___________________________________________________________________
Alpha ESS Co., Ltd.
Page 12 of 46
Your Smart Energy
Introduction
1.4.2 HV50056
1.4.2.1 Specification
Figure 6 High-voltage Control Box – Left & Right View
Figure 7 High-voltage Control Box – Front View, Inside –Front View
No.
Description
No.
Description
1
Bat+
10
INV COM Port
2
Bat-
11
External LCD Wiring Port
3
Earthing Point X 2 (Required To Con-
nect With Grounding Copper)
12
SD Card
4
LMU COM Port (CAN)
13
Dip Switch
5
AC Auxiliary Input
14
Dry Contact
6
Inv-
15
LCD Screen
7
Inv+
16
LED Indicator
8
LAN COM Port
17
Molded Case Circuit Breaker
(MCCB)
9
EMS Meter Communication Port
18
AC Switch (For AC Auxiliary In-
put)
2
1
3
5
6
4
7
10
11
12
13
14
8
9
17
18
15
16

___________________________________________________________________
Alpha ESS Co., Ltd. Page 13 of 46
Your Smart Energy
Introduction
1.4.3 Inverter Cable Box
Figure 8 Inverter Cable Box
Item
Description
1
On-Grid Wiring Ports (L1, L2, L3, N, PE)
2
Back Up Wiring Ports (L1, L2, L3, N, PE)
3
On-Grid AC Breaker
4
Back Up AC Breaker
1.5 Liability Limitation
Any product damage or property loss caused by the following conditions AlphaESS
does not assume any direct or indirect liability.
Product modified, design changed or parts replaced without AlphaESS
authorization;
Changes, or attempted repairs and erasing of series number or seals by non
AlphaESS technician;
System design and installation are not in compliance with standards and
regulations;
Failure to comply with the local safety regulations (VDE for DE, SAA for AU);
Transport damage (including painting scratch caused by rubbing inside
packaging during shipping). A claim should be made directly to shipping or
insurance company in this case as soon as the container/packaging is
unloaded and such damage is identified;
Failure to follow any/all of the user manual, the installation guide and the
maintenance regulations;
Improper use or misuse of the device;
Insufficient ventilation of the device;
The maintenance procedures relating to the product have not been followed
to an acceptable standard;
Force majeure (violent or stormy weather, lightning, overvoltage, fire etc.);
Damages caused by any external factors.
1 2
3 4

___________________________________________________________________
Alpha ESS Co., Ltd.
Page 14 of 46
Your Smart Energy
Installation
Installation
This Manual introduces the basic steps how to install and set up AlphaESS Storion-
SMILE-T10
M4856-S is a sealed component with no access to battery terminals or cell components
within module.
NOTE: please pay attention for unpacking the battery, the worst case is that
some components could be damaged.
2.1 Installation Site and Environment
2.1.1 General
The M4856-S has two versions, one is indoor, and another is outdoor. This SMILE-
T10 energy storage system (indoor version) can only be installed in an indoor location.
This SMILE-T10 energy storage system (outdoor version) can be installed in an
outdoor or an indoor location.
Where SMILE-T10 systems are installed within a room, shall be located so that access
to SMILE-T10 is not obstructed by the structure of the building, fixtures and fittings
within the room.
SMILE-T10 adopts natural ventilation. The location should be clean, dry and
adequately ventilated. The room’s entry doors and panels shall open in the direction of
egress and allow unobstructed access to the SMILE-T10 for installation and
maintenance purposes.
The following location are not allowed for installation:
habitable rooms;
in ceiling spaces;
wall cavities;
on roofs not specifically deemed suitable;
areas of access/egress;
under stairways;
under access walkways;
sites where the freezing point is reached, like garages, carports or other
places;
sites with humidity and condensation over 85%;
sites which are salty and where humid air can penetrate;
earthquake areas –additional security measures are required here;
sites that are higher than 3000 meters above the sea level;
sites with explosive atmosphere;
sites with direct sunlight;
sites with extreme change of ambient temperature;
wet rooms;
sites with highly flammable materials or gases; or

___________________________________________________________________
Alpha ESS Co., Ltd. Page 15 of 46
Your Smart Energy
Installation
sites with a potentially explosive atmosphere;
2.1.2 Restricted Locations
Wherethe SMILE-T10 is located on orwithin 300mm ofthe wall or structure separating
it from the habitable room, the barrier shall extend —
(i) 1000 mm beyond the vertical sides of the SMILE-T10;
(ii) 300 mm above the SMILE-T10; and
(iii) to the extent of the bottom of the SMILE-T10.
Please refer to Figure 9.
Figure 9 Distancelimit of Installation to Neighboring Objects
Where the top of the SMILE-T10 is within 300 mm of the ceiling or structure above the
SMILE-T10, the ceiling or structure surface shall be suitably non-combustible for an
area of 600 mm past the extremities of the SMILE-T10.
Where more than 4 batteries are installed, some batteries shall be installed beside,
distance between two rows batteries shall be not less than 100 mm
SMILE-T10 shall be mounted with the highest point no greater than 2.2 m above the
floor or platform.

___________________________________________________________________
Alpha ESS Co., Ltd.
Page 16 of 46
Your Smart Energy
Installation
2.2 Installation
Figure 10 Unpacking the Battery
Step 1: Take out the battery from the packaging box.
Note: the packaging box must be placed in accordance with the marking
direction, the upward carton, the other direction of the unpacking is wrong.
Figure 11 Removing Front Panel
Step 2: Pull the buckle from the bottom right in the middle and pull the top two guide
rods to remove the front panel.

___________________________________________________________________
Alpha ESS Co., Ltd. Page 17 of 46
Your Smart Energy
Installation
Figure 12 Assembling Battery Brackets
Step 3: Use a screwdriver to assemble the battery mounting bracket on the outside of
the battery, as Figure 12 shows.
Figure 13 Placing Battery
Step 4: Confirm the installation place at first.
Push the battery against the wall and confirm the location of the battery with a
horizontal ruler.
Pack the PE bag on the battery to block out the dust before drilling.
Please drill four holes (two on each side) directly on the wall at the marking positions
of the brackets with an impact drill (bit φ 8.0mm, length 20cm), and the depth of each
hole is about 7 cm.

___________________________________________________________________
Alpha ESS Co., Ltd.
Page 18 of 46
Your Smart Energy
Installation
Figure 14 Mounting Battery
Step 5: Insert the expansion tube into the drilled hole. Pass the expansion screw
through the gasket and lock with a screwdriver, as Figure 14 shows.
Step 6: M4856-S canbe stackable with max. 4 batteries in each row. To install another
battery repeat Steps 1~5.
Figure 15 Unpacking the High-voltage Control Box
Step 7: Take the HV50056 out of the packaging box. Pull out the top two guide rods
and remove the front panel. Remove the rear bracket from the HV50056, as shown in
Figure 15.
