ALPHA LITE FS Series User manual

USER MANUAL
SPOT LIGHT FS SERIES
July 2018

Safety Information /1
Safety Information
1. Do not open or disassemble the cover to reduce the risk of electric shock.
2. Please wear safety equipment such as safety helmet during work.
3. The work should be done under the direction of approved specialist
who is trained in safety and mechanical installations.
4. Be sure to fix the safety chain on the product when installing and moving.
5. Please install the signs below for people to bypass
when install the product on high truss.
WARNING

Summary /2
Summary
Safety Information
Summary
Fixture Information
Fixture Exterior View
Dimensions
Power Connection
Through and DMX512 Connection
Smart LCD Control
Setting
Spot Light Encoder Menu
Function Setting Order
Error and Information Message
Technical Specifications
Photometric Diagram
Mode & DMX Channel & RDM
DMX Protocols
1
2
3
4
5
7
8
9
11
12
17
18
19
20
21
22

Information /3
Information
FS Series uses a multi-focusing zoom lens based on ALPHA LITE’s
unique technology, and there is no yellowing phenomenon at
the boundary of illuminated light by multi focus LED and color
temperature change by chromatic aberration.
FS Series is a single light source with a large capacity, such as
a halogen lamp, and the texture of the light source projected by
the lens is very soft. Also, the boundary of the shadow is formed
smoothly without sharpness.
Beam cutting is excellent by adjusting the angle of the barn door.
FS Series is light weight compare to capacity, and designed
sturdy housing.
FS Series applies wireless DMX communication method, so user
can set up lighting fixture simply without a signal cable.
The touch LCD that includes intuitive manual operation and
address display window was designed with the user’s convenience.
Also, the housing is designed for easy maintenance and repair.

Fixture Exterior View /4
Fixture Exterior View
Stirrup
Focus Knob
Install Area
Handle
Install
Area
Connector
Panel
LCD
Screen
Fixed Knob
Install Area

Dimensions /5
Dimensions (FS-1.5 / FS-2.0)
550
(21.6)
285
(11.2)
474
(18.6)
327
(12.8)
362
(14.2)
177
(6.9)
ø200
(ø7.8)
210
(8.2)
38
(1.5)
367
(14.4)
(w/ Knob)
165
(6.4)
362
(14.2) ~170 (~6.7)
343
(13.5)
52
(2)
470
(18.5)
242
(9.5)
70
(2.7)
35
(1.3)
mm
(inch)

Dimensions /6
Dimensions (FS-3.0)
mm
(inch)
500
(19.6)
350
(13.7)
505
(19.8)
370
(14.5)
420
(16.5)
205
(8)
ø250
(ø9.8)
223
(8.7)
38
(1.5)
432
(17)
(w/ Knob)
173
(6.8)
415
(16.3) ~224 (~8.8)
390
(15.3)
52
(2)
500
(19.6)
270
(10.6)
70
(2.7)
35
(1.3)

Power Connection /7
Power Connection
Power
Connection
Power
Connection
AC power at 100-250V, 50-60Hz
1. Observe the proper voltage range
2. If power is supplied outside the range, noise may be generated from the SMPS.
3. If the operating voltage is out of the proper voltage range,
SMPS function may be degraded or damaged.
1. ON/OFF SWITCH
2. POWER IN
3. DMX IN
4. DMX OUT
5. USB PORT
1 2 3 4 5

DMX512
Connection
DMX-OUTPUT
XLR Mounting-sockets
DMX-INPUT
XLR Mounting-plugs
3-pin or 5-pin XLR sockets are equipped for DMX input and output, depending on user needs.
Connect the controller to a lighting, or lighting fixture to other lighting fixture.
If user uses a standard DMX controller, the DMX output of the controller can connect directly
to the DMX input of the first fixture in the DMX chain.
User must use an adapter cable for connect the DMX controller to other XLR output.
1-Shield
2-Signal (-)
3.Signal (+)
4-Not Connected
5-Not Connected
1-Shield
2-Signal (-)
3.Signal (+)
4-Not Connected
5-Not Connected
Connect the DMX output of the first lighitng fixture in DMX chain to the DMX input of the next
fixture, and connect one output to the input of the next fixture until all fixtures are connected.
In the last lighting fixture, the DMX cable must be end with a terminator(120 Ω resistor)
in DMX output signal (+, -).
Through and DMX512 Connection /8
Through and DMX512 Connection

Smart LCD Control /9
Smart LCD Control
Current Mode
Main Screen
DMX Address
The number indicates the address of the
DMX512. To change the DMX512 Address,
touch and input the value.
In normal operation, the number will not blink.
Intensity (Lighting Brightness)
Displays the brightness value(0~100%)
of the equipment.
Rotate Screen
Change the top and bottom of the LCD screen
according to the installation direction of
the equipment.
5
6
7
8
9
10
11
2
3
4
Setting
Setting or changing the function of
the equipment.
5
2
3
4

Wireless communication status
6
Current CRI
7
Smart LCD Control /10
Smart LCD Control
CCT (Color Temperature)
The number indicates the color temperature of the equipment.
In Mode 1, possible to set the color temperature value user want.
In Mode 2, displays the color temperature value by the channel setting.
Fixture ID Display
User can set and change any number(001~999) using the touch screen or RDM,
and it is not related to DMX512 Address.
After the input is completed, the set number is changed to the main screen.
8
9
Equipment Information
Displays model number, firmware version and equipment internal temperature.
10
Displays the strength of the connection signal with the wireless module.

Setting /11
Setting
Intensity (Lighting Brightness)
Brightness value is adjusted by touch on the
gradient or press +,-.
Channel Mode
1 : Dimming (Channel 1)
2 : Dimming (Channel 1),
CCT (Channel 2)
LCD Screen Setting
LCD ON : The screen stays on all the time.
LCD OFF 30s : After 30 seconds, the screen goes off.
12
14
11
12
13
Wire Set
Wire Mode: Connect DMX 512 cable
Wirelss Mode: Connect Wireless DMX 512
Unlink Function: Disconnect the link of
the wireless module.
14
11
13

1. The encoder is not working while LCD touch setting
2. LCD touch setting is not working while the encoder activates.
3. When press the encoder on the main screen, the menu setting appears.
4. Press the encoder to select the value and enter the menu.
5. Turning the encoder clockwise or counterclockwise to increase or decrease the value.
6. The menu configuration of the encoder is the same as for LCD touch.
Menu Screen Configuration
Spot Light Encoder /12
Spot Light Encoder
1. Mode Select
Select user mode or DMX512 mode.
2. Set Kelvin
Select Kelvin value either user mode or 1 channel of DMX512 mode.
3. LCD 30 Sec On/OFF
Choose whether to keep the LCD on or off after 30 seconds.
4. Fixture ID Setting
Select the screen shown either the Fixture ID or the main screen.
5. Product Info
Check firmware version, model number and RDM UID number.
6. Rotate Display
Rotate the top and bottom of the screen.
7. Wire Mode Set (Appear only wireless module is applied)
Select wired mode or wireless mode.

User Mode
Setting
Function Setting Order /13
Function Setting Order
1. Press the encoder, the menu setting appears.
2. Move to ‘MODER SELECT’ and press the encoder.
3. It will be displayed as (2). Move to ‘USER MODE’ and press encoder.
4. On the screen (3), turning the encoder clockwise to increase the value
and counterclockwise to decrease the value.
5. Press the encoder and all the value are saved. Automatically go to main screen.
(1) (2) (3)

DMX512 Mode
Setting
Function Setting Order /14
Function Setting Order
1. Press the encoder, the menu setting appears.
2. Move to ‘MODER SELECT’ and press the encoder.
3. It will be displayed as (2), move to ‘DMX MODE’ and press encoder.
4. On the screen (3), select channel mode and press the encoder.
5. On the screen (4), the cursor is on the units digit of DMX ADDRESS.
Turning the encoder clockwise to increase the value and counterclockwise
to decrease the value. Go to 10th digit pressing the encoder,
go to 100th digit pressing the encoder one more time.
Press the encoder again to move to OK. Press again to move to the screen (5).
6. When you turn the encoder on the screen (5), move BACK and OK.
BACK will go back to edit the configured DMX512 ADDRESS.
OK saves the set DMX512 ADDRESS value and returns to the main screen.
(1) (2) (3) (4) (5)

Kelvin Setting
Function Setting Order /15
Function Setting Order
1. Press the encoder, the menu setting appears.
2. Move to ‘SET KELVIN’ and press the encoder.
3.
On the screen (2), turn the encoder clockwise or counterclockwise to set KELVIN value.
Press the encoder and all the value are saved. Automatically go to main screen.
(1) (2)
LCD 30 Sec
ON/OFF Setting
1. Press the encoder, the menu setting appears.
2. Move to ‘LCD 30Sec ON/OFF’ and press the encoder.
3. On the screen (2), turn the encoder clockwise or counterclockwise to set LCD ON/OFF.
Press the encoder and the setting saved.
4. LCD OFF 30Sec is will be off after 30sec, and LCD ON is constantly on.
(1) (2)

FIXTURE ID
Setting
Function Setting Order /16
Function Setting Order
1. Press the encoder, the menu setting appears.
2. Move to ‘FIXTURE NUMBER’ and press the encoder.
3. On the screen (2), select ‘FIXTURE NUMBER’ and press the encoder.
4. On the screen (3), the cursor is on the units digit. Turning encoder to set the value.
Go to 10th digit pressing the encoder, go to 100th digit pressing the encoder one more time.
Press encoder again to move to OK. Press again to saved and FIXTURE ID is displayed.
(1) (2) (3)
PRODUCT INFO
Setting
1. Press the encoder, the menu setting appears.
2. Move to ‘PRODUCT INFO’ and press the encoder.
3. On the screen (2), Product information is shown.
Back to main screen by pressing the encoder.
(1) (2)

ROTATE DISPLAY
Setting
Function Setting Order /17
Function Setting Order
1. Press the encoder, the menu setting appears.
2. Move to ‘ROTATE DISPLAY’ and press the encoder.
3. The screen is upside down.
*Appear only
wireless module
is applied
(1) (2)
WIRE MODE SET 1. Press the encoder, the menu setting appears.
2. Move to ‘WIRE MODE SET’ and press the encoder.
3. On the screen (2), turn the encoder clockwise or counterclockwise
to set WIRE MODE or WIRELESS MODE.
WIRELESS UNLINK is for unlink with wireless module.
(1) (2)

Temperature
Sensor
Detects the temperature of the currnet equipment,
and appears the temperature on the LCD when it reaches a certain temperature.
- LED
- Drive
- Housing
Fan Sensor The fan speed level is displayed on the LCD by detecting the speed.
Error and Information Message /18
Error and Information Message

Technical Specifications /19
Technical Specifications
Optical System
FS-1.5 FS-2.0 FS-3.0
Focusable Fresnel Lens
200mm / 8”
20°~60° (Half Peak Angle)
12kg / Pole Up 14kg
Adjusting Sliding Stirrup, High Strength Tilt Lock
16mm / 28mm
±270°
100-240V, 50/60Hz
250W
Full 2900~6000K (Bi-Color)
CRI 95~98
0~100% Continuous
5-PIN DMX In and Through, DMX Wireless, LCD On Board Controller, RDM
RDM Setup
-20~45°C
IP20
50,000 hours
200mm / 8”
12kg / Pole Up 14kg
350W
250mm / 10”
15kg / Pole Up 17kg
550W
Lens Diameter
Beam Angle
Weight
Handling
Mounting
Tilt Angle
Power Supply Range
Power Consumption
White Light
Color Rendition
Dimming
Control
Remote Device Management
Ambient Temperature Operation
IP Rating
Estimated LED Lifetime
