Alpha Climatic Assembly Instructions

1
Alpha Climatic Installation & User Instructions
Part No 3.022144 (hard wired) - 3.022143 (RF)
1. Description
The Alpha Climatic Programmable Modulating Boiler Energy Manager is a multi-
channel time and temperature programmer with integrated thermostat and “BUS”
system to transfer data between the boiler and controller, enabling full remote
control of the boiler functions and display of information. With enhanced boiler
control, the unit further increases boiler and system efficiency.
Within the governments Standard Assessment Process (SAP) the Alpha Climatic
controls are classed as an “Enhanced Load Compensator” capable of measuring
and maintaining the temperature inside the building by modulating and limiting the
boiler flow temperature depending on the measured room temperature.

2

3
2. Mounting of the controller
The controller must be mounted in a position where it can not be influenced by direct
sunlight, any device which might emit heat, near a door, window or be obstructed by
curtains. It must be installed approximately 1.5m from the floor and any radiators
within the same room must not have thermostatic radiator valves or any other
thermostatic control fitted to them.

4
3. Wall Mounting
Using a small screwdriver press down
on the tab at the top of the controller
(4) and separate the front control panel
from the rear case.
Hold the rear casing in its chosen
position level against the wall and
mark the fixing holes.
Drill two 5mm holes in the wall, insert
the wall plugs provided and fix the rear
case to the wall using the 30mm
screws.
Hard wired models only - Connect
the boiler data wire (not supplied) to
the + and –terminals in the rear casing
Connections are not polarity sensitive.

5
Re-fit the front control panel, lower the control cover (1) and secure the control panel
using the two 10mm screws provided (3).
Installing the batteries (RF Controller Only)
Using a small screw driver un-clip the bottom of the battery cover (2) and remove.
Insert two Size AA batteries in the position shown in the back of the battery
compartment and refit the battery cover
Note: The RF Climatic controller must not be programmed until the receiver
unit is connected to the boiler and RF communication is established.
4. Connecting the Climatic controller
Controls connections are boiler specific, for further details or boiler models not
shown please refer to boiler installation manual.
DO NOT connect Climatic controller to 230v terminals 1 & 2
within boiler control panel!

6
For Alpha E-Tec / Evoke –Hard Wired
•Gain access to the boiler terminal block as described in the boiler installation
and service instructions.
•Pass the wire from the Climatic controller through the cable entry point in the
terminal block cover and connect it to terminals 44 & 41 (wires can be
connected either way round).
•Secure the wire under the cable clamp
•Remove link wire from terminals 1 & 2
(DO NOT connect Climatic wires into terminals 1 & 2!)
•Re-assemble in reverse order.
For Alpha E-Tec / Evoke –RF Wireless
•Gain access to the boiler terminal block as described in the boiler installation
and service instructions.
•Plug the connecting wire (supplied with controller) onto the Climatic receiver
PCB terminal marked “OT” only.
•Use the two screws provided from the fixing posts and fix the receiver PCB into
position (Note: Wiring connector faces inwards)

7
•Route the wire along the groove in the control panel to terminal block
connections 44 & 41 (the wires can be connected either way round).
•Remove link wire from terminals 1 & 2
•(DO NOT connect Climatic wires into terminals 1 & 2!)
•Re-assemble in reverse order.
RF Climatic PCB in Alpha E-Tec / Evoke boiler
Cable route to
terminals 41 & 44
PCB receiver
wiring terminal
facing inwards

8
For Alpha Intec –Hard Wired
•Gain access to the boiler terminal block as described in the boiler installation
and service instructions.
•Pass the wire from the Climatic controller through the rubber grommet in the
terminal block cover
•Connect it to terminals 12 & 13.
•Remove link wire from terminals 1 & 2
•(DO NOT connect Climatic wires into terminals 1 & 2!)
•Secure the wire under the cable clamp and re-assemble in reverse order.
For Alpha Intec –RF Wireless
•Gain access to the boiler terminal block as described in the boiler installation
and service instructions.
•Remove the screws from the fixing posts in the back of the control panel,
position the receiver and re-fit the screws to secure it in place.
•Connect the wires from the receiver terminal to the BUS connections 12 & 13
on the boiler terminal block (the wires can be connected either way round).

9
•Remove link wire from terminals 1 & 2
•(DO NOT connect Climatic wires into terminals 1 & 2!)
•Tuck the wire behind the tabs on the PCB cover and re-assemble in reverse
order.
RF Climatic PCB in Alpha Intec boiler

10
5. Control button functions.
1. Mode selection switch
2. Reset, previous display
3. Heating on/off temperatures
4. Reset to factory settings
5. Programming menu selection
6. Menu selection
7. DHW temperature set
8. CH temperature set
9. Information e.g. flow temperature
10. Auto/Manual override
11. Scroll/temperature adjust
12. Scroll/temperature adjust
Note: With a Climatic controller
fitted, CH temp and DHW temp
controls on the boiler will no
longer be active.

11
6. Display Symbol Descriptions
Symbol
Description
Symbol
Description
DHW and heating on
Outside temp. display
DHW only
Inside temp. display
Cooling and DHW modes enabled
Remote phone activation (not used)
Request for heating or cooling
Holiday mode
Cylinder heating in progress (if
present)
Indicates it is possible to adjust a
parameter using buttons 11 and 12
Request for DHW
000:000
Describes current status
Request for Heating
Anomaly or Fault
Reset/escape to previous screen
Solar active
Displays room temp. and numerical
data
External probe connected
Functioning in wireless mode (RF
models only)
Battery condition low (RF models
only)

12
7. Climatic RF Communication
For the RF (Wireless) model the symbol is shown to indicate communication
between the Controller and the Receiver. If the symbol is not shown the connection
has failed. If the symbol is flashing there is a weak signal or fault with the
communication.
8. Programming
a. Set Time
Turn the mode selection switch to CH/DHW on .
Press the button to enter the time setting mode, then press OK and the
hour will flash.
Using the +/- buttons adjust the time to the correct hour then press OK, the minutes
will now flash, using the +/- buttons adjust the minutes then press OK.
The day of the week will flash, using the +/- buttons set to the correct day of the
week and press OK then ESC to get back to main menu.

13
b. Set Heating Programme
Press the button and TIME will appear, press + and CH PRG will flash,
press OK and MONDAY will appear.
Using the + button you can programme individual days or blocks of days then press
OK.
On 1 will be displayed and the time will flash, using the +/- buttons you can select
the time you wish the heating to turn on followed by OK,
Then using the +/- buttons you can set the time you wish the heating to turn off.
Press OK and the next on period will appear, repeat the previous procedure for the
next on-off periods for the rest of the day to a maximum of four on periods.
After one minute the display will return to main menu or keep pressing ESC.
NOTE: if four on off periods are not required then set the unused periods on off
times the same. E.g. On 23:00 off 23:00.

14
c Set Hot Water Programme
Note: The hot water programmes only need to be set for the following system types:
Alpha System Boiler & Diverter Kit or Alpha Flowsmart
Press the button and TIME will appear, press + twice and HW PRG will
flash, press OK and MONDAY will appear.
Using the + button you can programme individual days or blocks of days then press
OK.
On 1 will flash on the display with a time below it, using the +/- buttons you can
select the time you wish the hot water to turn on followed by OK
Then using the +/- buttons you can set the time you wish the hot water to turn off.
Press OK and the next on period will appear, repeat the previous procedure for the
next on-off periods for the rest of the day to a maximum of four on periods.
After one minute the display will return to main menu or keep pressing ESC.
NOTE: If on/off periods are not required then set the unused period on/off times the
same. e.g. On 23:00 off 23:00.

15
d. Setting the Temperature
Note: There are two temperature settings, comfort and economy.
The comfort temperature is the room temperature required during the heating on
period.
The economy temperature is the minimum allowable room temperature, e.g. if the
economy temperature is set to 10ºc and the temperature drops below this during a
heating off period the boiler will switch on to maintain the 10ºc setting.
Press the button and the word COMFOR will appear with the temperature
flashing above and a symbol. Using the +/- buttons set the temperature as
required then press OK to store.
Press the button twice and the word ECONOM will appear with the temperature
flashing above and a symbol. Using the +/- buttons set the temperature as
required then press OK to store.

16
9. Mode Selection
a. The mode selection switch (1) has five settings.
a. In this mode the control is switched off but the boiler frost protection is
still active.
b. In this mode the control is switched off but provides frost protection for
its immediate location.
c. This mode provides hot water only (summer setting).
d. This mode provides hot water and timed and temperature controlled
heating (winter setting).
e. This mode is used in conjunction with an air conditioning unit to provide
summer cooling control.
b. Central Heating Temperature setting (8)
The central heating temperature setting adjusts the primary heating water
temperature to the user’s requirement. In winter mode, when the dial is turned the
temperature setting is displayed on the screen.

17
The primary flow temperature might not reach the temperature set by the user when
in operation because the programmer will control the boiler output to give optimum
performance to reach the required room temperature setting.
c. External weather compensation probe (optional)
When an optional external weather sensor is fitted the CH temperature control dial
will no longer adjust by degrees °C, instead the display will show a scale of 1 to 9.
Outside Air Temperature
Max Flow Temp

18
Each number 1-9 corresponds to a line on the graph (values in brackets are low
temp. circuits). Example: Setting 6 would give a maximum flow temperature of 60°C
at an outside air temperature of 10°C.
d. Domestic Hot Water Temperature setting (7)
The domestic hot water temperature setting adjusts the temperature of the water
delivered to the hot tap to the user’s requirement. When the dial is turned the
temperature setting is displayed on the screen.
e. Continuous override
The override function is used to manually control the boiler, press the
button and use the +/- buttons to set the desired room temperature. To turn off the
manual override press the button.
f. Temporary override
To access Temporary override press the +/- buttons to set the desired temperature
and the symbol will flash in the top right hand corner of the display. The room
temperature will be maintained until the next timed on or off period or press the
button to come out of temporary override.

19
g. Room frost protection
If the programmer detects and indoor temperature of 5ºC the boiler will operate at
minimum heating output until the room temperature has been raised to 5.6ºC.
h. Cooling Mode
In this mode the programmer can be used to control an air-conditioning unit, turn the
selector to to enable.
NOTE: For more information please contact Alpha Heating Innovation.
i. Information
Pressing the INFO button allows the user to scroll through a menu showing various
temperatures and the functioning state of the programmer.
With each press of the INFO button a value will be displayed e.g. DHW T 50ºC, if a
value is not present “- -“will be displayed. The display of the INFO is subject to the
boiler model and the method of connection of the programmer.
To return to the main menu press ESC button or wait for 60 seconds.

20
The displayed information parameters are as follows;
EXT T: External temperature (if external probe is fitted).
RH%: Relative room humidity (with optional probe fitted) –NOT USED
HF TMP: Primary flow temperature.
HR TMP: Primary return temperature.
DWIN T: DHW input temperature.
DHW T: DHW output temperature.
PAN T: Solar collector temperature.
CH PRS: Primary system pressure.
SERVIC: Days remaining before a boiler service is required.
VER “X”: “X” identifies the type of communication protocol with the boiler in use:
VER PI = IMG-Bus. The display shows the software version of the programmer remote control.
ZONE: Not used on this model.
j. Faults diagnostics and errors
The Climatic remote control continually controls the functioning of the boiler and
signals any anomalies, stating the corresponding error code on the display.
The error codes are listed in the boiler installation manual.
