Alstom EPAC 3100 Assembly instructions

(3$&
(3$&
1XPHULFDOGLVWDQFHUHOD\ZLWKLQWHJUDWHG
DXWRPDWLFDQGFRQWUROHTXLSPHQW
 ,QVWDOOHU·V*XLGH *,

EPAC 3100/3500 GI 1.6882
P-2
PAGE NOT USED

GI 1.6882 EPAC 3100/3500
P-3
PREFACE
Dear reader,
Wearecontinuouslyendeavoringtoimprovethestandardofqualityofourbrochures.Thisform
hasbeendesignedtoenableyou tosendinyourremarksand comments.Pleasereturntheform,
duly filled in, to the following address. Thank you in advance.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Address:
ALSTOM P & C
Marketing Department
Avenue de Figuières
F-34975 LATTES CEDEX
Have you found any errors in the brochure ? If so, please indicate where they are.
Did you find the brochure comprehensible and well set out ?
Please indicate here any proposals for improvement.
Have we supplied you with sufficient information to permit the understanding of the product
presented here ?
If not, what is missing and at what points should we supply additional indications ?
Name: Position:
Date: Utility or company:
Address: Telephone:
Post/Zip Code : City:
Country:
Concerning the item:

EPAC 3100/3500 GI 1.6882
P-4
INTRODUCTION
The documentation covering the EPAC 3100/3500 Distance Protection is subdivided into 3
documents. Each document provides its recipient with the information needed for the perfor-
mance of his or her tasks. The following table summarizes the titles of the documents, their
recipients and the supply date.
Document Title Recipient Supply date
Installer’s Guide Installer of Equipment Delivered with each
equipment
User's Guide Expert in charge On order
of equipment
Commissioning and Agent specializing On order
Maintenance Guide in commissioning equipment
and in preventive maintenance

GI 1.6882 EPAC 3100/3500
P-5
REASON FOR UP-DATES
GI 1.6882 INSTALLER'S GUIDE EPAC 3100/3500
First edition: 06/97
Indice Updating Updating subject
date

EPAC 3100/3500 GI 1.6882
P-6
EPAC 3100/3500 INSTALLER'S GUIDE GI 1.6882
Index Updating No. AMENDED No. AMENDED
date PAGE INDEX PAGE INDEX
STATE OF UP-DATES
A
B
C
D
E
F
G
H
I
J
K
L
M
N
P-1
P-2
P-3
P-4
P-5
P-6
P-7
P-8
PRELIMARY PAGES
CHAP 1
1-1
1-2
1-3
1-4
CHAP 2
2-1
2-2
2-3
2-4
2-5
2-6
CHAP 3
3-1
3-2
3-3
3-4
3-5
3--6
CHAP 4
4-1
4-2
4-3
4-4
CHAP 5
5-1
5-2
5-3
5-4
5-5
5-6
5-7
5-8
5-9
5-10
5-11
5-12
APPEND.
A-1
A-2
A-3
A-4
TEXT AND DRAWING PAGES

GI 1.6882 EPAC 3100/3500
P-7
GENERAL CONTENT
CHAPTER 1 - TRANSPORTATION AND STORAGE CONDITIONS ______________________________ 1-1
1.1. TRANSPORTATION____________________________________________________________ 1-3
1.2. STORAGE ON SITE OR IN A WAREHOUSE _______________________________________ 1-4
1.2.1 Normal Storage Conditions ____________________________________________________ 1-4
1.2.2 Long-Term Storage Conditions __________________________________________________ 1-4
CHAPTER 2 - UNPACKING _____________________________________________________________ 2-1
2.1. UNPACKING_________________________________________________________________ 2-3
2.2. REPACKING _________________________________________________________________ 2-5
CHAPTER 3 - MECHANICAL CHARACTERISTICS AND INSTALLATION CONDITIONS______________ 3-1
3.1. OVERALL DIMENSION_________________________________________________________ 3-3
3.2. WEIGHT ____________________________________________________________________ 3-4
3.3. ASSEMBLY __________________________________________________________________ 3-5
CHAPTER 4 - ELECTRICAL CONDITIONS __________________________________________________ 4-1
4.1. ELECTRIC POWER SUPPLY ______________________________________________________ 4-3
4.2. GROUNDING ________________________________________________________________ 4-4
CHAPTER 5 - EXTERNAL CONNECTIONS _________________________________________________ 5-1
5.1. ANALOG INPUT CONNECTIONS________________________________________________ 5-3
5.2. INPUT AND OUTPUT CONTACTS CONNECTIONS __________________________________ 5-6
5.3. POWER SUPPLY CONNECTIONS _______________________________________________ 5-10
5.4. EQUIPMENT FAULT SIGNALLING CONNECTIONS_________________________________ 5-10
5.5. COMMUNICATION OPTION CONNECTIONS ____________________________________ 5-10
APPENDICES ________________________________________________________________________ A-1
FRONT PANEL CONNECTIONS AND REAR PANEL TERMINAL BLOCK CONNECTIONS ___________ A-3
FIBRE OPTIC CONNECTIONS ___________________________________________________________ A-3
SIMPLIFIED DIAGRAM EPAC 3132 ______________________________________________________ A-4

EPAC 3100/3500 GI 1.6882
P-8
PAGE NOT USED

GI 1.6882 EPAC 3100/3500
CHAPTER 1
TRANSPORTATION AND STORAGE
CONDITIONS

EPAC 3100/3500 GI 1.6882
PAGE NOT USED

1-1
GI 1.6882 EPAC 3100/3500
CONTENT
PAGE
1.1. TRANSPORTATION____________________________________________________________ 1-3
1.2. STORAGE ON SITE OR IN A WAREHOUSE _______________________________________ 1-4
1.2.1 Normal Storage Conditions ____________________________________________________ 1-4
1.2.2 Long-Term Storage Conditions __________________________________________________ 1-4

1-2
EPAC 3100/3500 GI 1.6882
PAGE NOT USED

1-3
GI 1.6882 EPAC 3100/3500
TheEPACisdeliveredinacardboardbox. Thefollowingequipmentiscontainedinsidethebox:
- the EPAC 3100/3500,
- a plastic bag containing the installer’s guide,
- the assembly kit screw-in or Faston connectors,
- two floppy disk with the man machine interface sofware.
The EPAC 3100 is the frame mounted "L Case" EPAC.
The EPAC 3500 is the cabinet mounted "L Case" EPAC.
1.1. TRANSPORTATION
Thegrossweightoftheequipmentinitspackingis12kg. Itcaneasilybemovedbyoneperson.
Theprecautionstobetakenwhentransportingthepackagearethoseusedforthetransportation
of electronic equipment.
The cardboard box can withstand a weight of 100 kg without being deformed. You should
therefore avoid stacking more than 5 boxes of the same equipment or any other package
weighting more than 80 kg on top of it.
When handling the box, avoid dropping or knocking it. If the box falls more than 0.80 metres
ononeofitssurfaces,theequipmentcomponents(modules,connectors,board-guides,etc.)may
be damaged or distorted. If the box falls on its corner, the equipment may be damaged in the
same way. Great care must therefore be taken when handling the box.
The packing guarantees that the equipment will remain in good condition when submitted to
accelerations of less than 3 g (g = 9.81 m/s2) for all modes of transport (overland, railway, sea
and air).
The vibration resistance of the EPAC 3100/3500 is in conformance with the response curve
defined by the IEEE Seismic Testing of Relays standard.

1-4
EPAC 3100/3500 GI 1.6882
1.2. STORAGE ON SITE OR IN A WAREHOUSE
1.2.1 Normal Storage Conditions
While the equipment is stored on site, it must be kept in its original packing.
Thecardboardboxmustbeputonapalletsothatitdoesnotabsorbanyhumidityfromtheground.
1.2.2 Long-Term Storage Conditions
For long-term storage in a warehouse and for certain types of transport (overland, sea and
tropical),werecommendtheuseofmoisturebarriersinordertokeepthelevelofhumidityinside
the envelope at a level lower than 5 g of water per m3.
These packages contain dessicant pouches that must be renewed every 6, 12 or 24 months
depending on whether the packing is provided for overland, sea or tropical conditions. The
dessicant pouches are put inside the envelope but do not touch the equipment. Therefore the
equipment may be stored for 3 years in the following storage conditions (no tests are needed
during this period to check that the relay operates correctly):
- stored in a sheltered area without air-conditioning,
- temperature: - 40°C to 70°C,
- relative humidity: less than 95% with no condensation.

GI 1.6882 EPAC 3100/3500
CHAPTER 2
UNPACKING

EPAC 3100/3500 GI 1.6882
PAGE NOT USED

2-1
GI 1.6882 EPAC 3100/3500
CONTENT
PAGE
2.1. UNPACKING_________________________________________________________________ 2-3
2.2. REPACKING _________________________________________________________________ 2-5

2-2
EPAC 3100/3500 GI 1.6882
PAGE NOT USED

2-3
GI 1.6882 EPAC 3100/3500
2.1. UNPACKING
Procedure:
1. Place the box on the ground or on a pallet, with the pictogram the right way up.
2. Cut the adhesive tape width-wise using the blade of a sharp instrument, on the upper
right and left edges.
3. Remove the tape to get access to the staples holding flaps.
4. Remove the staples.
5. Open the flaps by folding them back, as shown on the packing diagram.
6. Remove the various elements from the cardboard box, and check that the contents cor-
respond to the list given in chapter 1.
7. Remove the packing blocks and put the EPAC on a table with the assembly kit and
documents.
8. Put the packing blocks back into the box.
If the EPAC 3100/3500 is to be temporarily used on site,
keep the packing and re-use it to repack the equipment.
However,ifthe EPAC3100/3500isinstalleddefinitively,
the packing can be destroyed.

2-4
EPAC 3100/3500 GI 1.6882
Figure 2.1a: Packing / Unpacking the EPAC 3100/3500
Superior hand packing block
Product
Inferior hand packing block
Card board
base
UP
DOWN
