DELIVERY
This Alto-Shaam appliance has been
thoroughly tested and inspected to insure only the
highest quality unit is provided. Upon receipt,
check for any possible shipping damage and
report it at once to the delivering carrier. See
Transportation Damage and Claims section
located in this manual.
This appliance, complete with unattached
items and accessories, may have been delivered in
one or more packages. Check to ensure that all
standard items and options have been received
with each model as ordered.
Save all the information and instructions
packed with the appliance. Complete and return
the warranty card to the factory as soon as
possible to assure prompt service in the event of a
warranty parts and labor claim.
This manual must be read and understood by
all people using or installing the equipment
model. Contact the Alto-Shaam service
department if you have any questions concerning
installation, operation, or maintenance.
NOTE: All claims for warranty must include the
full model number and serial number of
the unit.
UNPACKING
1. Carefully remove the
appliance from the
carton or crate.
NOTE: Do not discard the
carton and other
packaging material
until you have
inspected the unit
for hidden damage
and tested it for
proper operation.
2. Read all instructions in this manual carefully
before initiating the installation of this appliance.
DO NOT DISCARD THIS MANUAL.
This manual is considered to be part of the
appliance and is to be provided to the owner
or manager of the business or to the person
responsible for training operators. Additional
manuals are available from the Alto-Shaam
service department.
3. Remove all protective plastic film, packaging
materials, and accessories from the appliance
before connecting electrical power. Store any
accessories in a convenient place for future use.
®
®
®

O&C MANUAL • 1200-TH/III MARINE
P G . 2
SAFETY PROCEDURES
AND PRECAUTIONS
Knowledge of proper procedures is essential to the
safe operation of electrically and/or gas energized
equipment. In accordance with generally accepted
product safety labeling guidelines for potential
hazards, the following signal words and symbols
may be used throughout this manual.
Used to indicate the
presence of a hazard that
will cause severe personal
injury, death, or substantial
property damage if the
warning included with this
symbol is ignored.
Used to indicate the
presence of a hazard that
can cause personal injury,
possible death, or major
property damage if the
warning included with this
symbol is ignored.
Used to indicate the
presence of a hazard that
can or will cause minor or
moderate personal injury
or property damage if the
warning included with this
symbol is ignored.
Used to indicate the
presence of a hazard that
can or will cause minor
personal injury, property
damage, or a potential
unsafe practice if the
warning included with this
symbol is ignored.
Used to notify personnel of
installation, operation, or
maintenance information that is
important but not hazard related.
1.This appliance is intended to cook, hold or
process foods for the purpose of human
consumption. No other use for this
appliance is authorized or recommended.
2. This appliance is intended for use in
commercial establishments where all
operators are familiar with the purpose,
limitations, and associated hazards of this
appliance. Operating instructions and
warnings must be read and understood by
all operators and users.
3. Any troubleshooting guides, component
views, and parts lists included in this manual
are for general reference only and are intended
for use by qualified technical personnel.
4. This manual should be considered a
permanent part of this appliance. This
manual and all supplied instructions,
diagrams, schematics, parts lists, notices, and
labels must remain with the appliance if the
item is sold or moved to another location.
NOTE:

O&C MANUAL • 1200-TH/III MARINE
P G . 3
S I T E I N S T A L L A T I O N
This Alto-Shaam
appliance must be
installed in a location
that will permit it to
function for its
intended purpose and
to allow adequate
clearance for ventila-
tion, proper cleaning,
and maintenance
access.
1. The oven must be installed on a stable and
level surface.
2. DO NOT install this appliance in any area where
it may be affected by any adverse conditions
such as steam, grease, dripping water, high tem-
peratures, or any other severely adverse condi-
tions.
3. DO NOT store or use any flammable liquids or
allow flammable vapors in the vicinity of this
oven or any other appliance.
4. This appliance must be kept free and clear of
any combustible materials.
5. This appliance must be kept free and clear of
any obstructions blocking access for mainte-
nance or service.
Emissions testing conducted by Underwriters
Laboratories, Inc.®was found to be in compliance
with the applicable requirements of NFPA96: 2004
Edition, Par. 4.1.1.2. U.L emissions sampling of
grease laden vapor resulted in a total of 0.55 mil-
ligrams per cubic meter with no visible smoke and
is considered representative of all oven models in
the line. Based on these results, hood installation
and/or outside venting should not be a require-
ment in most areas. Verify local codes for loca-
tions where more restrictive codes are applicable.
®
TO PREVENT PERSONAL INJURY,
USE CAUTION WHEN MOVING OR
LEVELING THIS APPLIANCE.
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN IN
OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.
IMPROPER INSTALLATION, ALTERATION, 
ADJUSTMENT, SERVICE OR MAINTENANCE
COULD RESULT IN SEVERE INJURY, DEATH
OR CAUSE PROPERTY DAMAGE.
INSTALLATION
DO NOT store or use any flammable
liquids or allow flammable vapors
in the vicinity of any appliance.
MINIMUM CLEARANCE REQUIREMENTS
18" (457mm) minimum clearance at back from heat
producing equipment.

O&C MANUAL • 1200-TH/III MARINE
P G . 4
S I T E I N S T A L L A T I O N
I N S T A L L A T I O N
25-3/4" (654mm)
69-15/16" (1776mm)
7-3/4" (197mm)
77-11/16" (1973mm)
22-1/4" (565mm) 27-1/8" (688mm)
33" (836mm)
33-11/16" (856mm)
11-13/16" 
(299mm)
33-13/16" (858mm)
53-3/8" (1355mm)
9-1/16" (229mm)9-1/16" (229mm)
33-13/16" (858mm)
53-3/8" (1355mm)
Electrical Connection
(Dual Cord)

Electrical Connection
(Single Cord)

PRODUCT\PAN CAPAC TY (PER COMPARTMENT)
120 lb (54 kg) MAXIMUM
VOLUME MAXIMUM: 60 QUARTS (76 LITERS)
OPT ONS & ACCESSOR ES
Carving Holders
Prime Rib HL-2635
Steamship (Cafeteria) Round 4459
HACCP Network Options
HACCP Documentation
HACCP with itchen Management
RE F E R TO H A C CP SP E C F C A T ON #9015, DA TE D ON OR
A F TE R OC TOBE R 2005 F OR A P P L C A BL E P A RT N U MBE RS.
Door Lock with ey L -22567
Drip Pan, Extra Deep 13162
Drip Pan, Extra Deep with Drain 4932
Legs, Flanged, 6" (152mm) LG-23067
Shelves, Stainless Steel
Flat Wire SH-2325
Rib Rack SH-2773
Pan Grid, Wire
18" x 26" Sheet Pan Insert PN-2115
WE GHT
NET:420 lb (191 kg)
SH PP NG:475 lb(215 kg)
CRATE D MENS ONS:
34" X26" X77" (1194mm x 940mm x 1219mm)

O&C MANUAL • 1200-TH/III MARINE
P G . 5
SITE INSTALLATION
INSTALLATION
A number of adjustments are associated with initial
installation and start-up. It is important that these
adjustments be conducted by a qualified service
technician. Installation and start-up adjustments
are the responsibility of the dealer or user. These
adjustments include but are not limited to door
adjustment, leveling, electrical hook-up and instal-
lation of optional casters or legs.
LEVELING
Level the appli-
ance from side-to-
side and front-to-back
with the use of a spirit level. For ovens installed
with casters, it is important that the installation
surface be level due to the probability of frequent
oven repositioning.
We recommend checking the level of the appliance
periodically to make certain the floor has not shift-
ed nor the appliance moved.
NOTE: Failure to properly level this oven can
cause improper function.
RESTRAINT REQUIREMENTS
—MOBILE EQUIPMENT
Any appliance that is not furnished with a power
supply cord but that includes a set of casters must
be installed with a tether. Adequate means must
be provided to limit the movement of this appli-
ance without depending on or transmitting stress
to the electrical conduit. The following require-
ments apply:
1. Casters must be a maximum height of 6" (152mm).
2. Two of the casters must of be the locking type.
3. Such mobile appliances or appliances on mobile
stands must be installed with the use of a flexible
connector secured to the building structure.
A mounting connector for a restraining device is
located on the lower back flange of the appliance
chassis or on an oven stand, approximately 18"
(457mm) from the floor. A flexible connector is not
supplied by nor is it available from the factory.
RISK OF ELECTRIC SHOCK.
Applianc must b s cur d
to building structur .

O&C MANUAL • 1200-TH/III MARINE
P G . 6
WHEN MOUNT NG
DR P STR P, SEAL
STR P TO THE UN T
W TH AN R.T.V.
SEALANT TO PREVENT
MO STURE FROM
PENETRAT NG NTO
OVEN COMPARTMENT
DR P
STR P* 3: #8-32 X 1/ 2" SCREWS*
*SEE ALTO-SHAAM PARTS L ST FOR ALTO-SHAAM PART NUMBERS.
STANDARD DR P PAN*
[BOTTOM OF OVEN NTER OR • BELOW
S DE-RACKS]
DR P
TRAY*
DRIP TRAY INSTALLATION INSTRUCTIONS
LOW TEMPERATURE TH/ SER ES
COOK NG & HOLD NG OVENS
I N S T A L L A T I O N
FAILURE TO PROPERLY INSTALL
THE DRIP TRAY CAN OR WILL
CAUSE MAJOR EQUIPMENT
DAMAGE AND WILL RESULT IN A
LEAKAGE HAZARD THAT CAN
CAUSE PERSONAL INJURY.
SITE INSTALLATION

O&C MANUAL • 1200-TH/III MARINE
P G . 7
The appliance must be installed by a qualified
service technician. The cabinet must be properly
grounded in accordance with the National
Electrical Code and applicable local codes.
Plug the unit into a properly grounded receptacle
ONLY, positioning the unit so that the plug is
easily accessible in case of an emergency. Arcing
will occur when connecting or disconnecting the
unit unless all controls are in the “OFF” position.
Proper receptacle or outlet configuration or
permanent wiring for this unit must be installed
by a licensed electrician in accordance with
applicable local electrical codes.
For 230V units: To prevent an electrical shock
hazard between the appliance and other
appliances or metal parts in close vicinity, an
equalization-bonding stud is provided. An
equalization bonding lead must be connected to
this stud and the other appliances / metal parts to
provide sufficient protection against potential
difference. The terminal is marked with the
following symbol.
NOTE: The appliance must be connected to an
electrical circuit that is protected by an external
GFCI outlet.
ELECTRICAL CONNECTION
INSTALLATION
To avoid electrical shock, this
appliance MUST be adequately
grounded in accordance with local
electrical codes or, in the absence of
local codes, with the current edition
of the National Electrical Code
ANSI/NFPA No. 70. In Canada, all
electrical connections are to be made
in accordance with CSA C22.1,
Canadian Electrical Code Part 1 or
local codes.
ELECTRICAL CONNECTIONS MUST
BE MADE BY A QUALIFIED SERVICE
TECHNICIAN IN ACCORDANCE WITH
APPLICABLE ELECTRICAL CODES.
ELECTR CAL
VOLTAGE PHASE CYCLE / HZ AMPS kW CORD & PLUG INCLUDED
S NGLE CORD :
230V 1 50/60 15.0 6.6 CEE 7/7, 220-230V PLUG
DOUBLE CORD : ( PER COMPARTMENT / CORD )
230V 1 50/60 15.0 3.3 CEE 7/7, 220-230V PLUG

O&C MANUAL • 1200-TH/III MARINE
P G . 8
OPERATING INSTRUCTIONS
USER SAFETY INFORMATION
The Alto-Shaam cook and hold oven is intended
for use in commercial establishments by qualified
operating personnel where all operators are
familiar with the purpose, limitations, and associ-
ated hazards of this appliance. Operating
instructions and warnings must be read and
understood by all operators and users.
S T A R T- U P O P E R A T I O N
BEFORE INITIAL USE:
Interior oven surfaces must be heated to remove
surface oils and the accompanying odor produced
during the first use of the oven.
1. Wipe all wire shelves, side racks and the full
cabinet interior with a clean, damp cloth.
Install the side racks and shelves. Shelves are
installed with the curved edge toward the back
of the unit.
2. Close the oven doors, press the ON key and set
the temperature to 300°F (149°C) by using the
UP/DOWN arrow keys.
3. Allow the oven to cycle for approximately 2
hours or until no odor is detected.
PREHEATING:
Always preheat the appliance for a minimum of
45 minutes before cooking product. Follow the
operating instructions indicated on the next page
of this manual.
AT NO TIME SHOULD THE INTERIOR OR
EXTERIOR BE STEAM CLEANED, HOSED
DOWN, OR FLOODED WITH WATER OR
LIQUID SOLUTION OF ANY KIND. DO NOT
USE WATER JET TO CLEAN.
SEVERE DAMAGE OR ELECTRICAL HAZARD
COULD RESULT.
WARRANTY BECOMES VOID IF APPLIANCE IS FLOODED.
METAL PARTS OF THIS EQUIPMENT
BECOME EXTREMELY HOT WHEN IN
OPERATION. TO AVOID BURNS,
ALWAYS USE HAND PROTECTION
WHEN OPERATING THIS APPLIANCE.

O&C MANUAL • 1200-TH/III MARINE
P G . 9
OPERATING INSTRUCTIONS
PRESETS ABCDEFGHI CANCEL
ABCDEFGHI CANCEL
Single Control, Single Cord
This model has one control with two ON/OFF eys, one to control the top cooking cavity, one to
control the bottom cooking cavity. Each compartment is controlled and programmed separately.
E L E C T R O N I C C A B I N E T C O N T RO L I D E N T I F I C AT I O N
햳햴 햵 햶 햷 햸 햹햺 햻 햽 햾
햿
헀
헂
헁
햲햳햴 햵 햶 햷 햸 햹햺 햻 햽 햾
햿
헀
헂
헁
Dual Control, Dual Cord
This model has two controls, one to control the top cooking cavity, one to control the bottom cooking cavity.
Each compartment is controlled and programmed separately.
햲
햲
1.ON/ OFF Key
2.COOK Key
3.T ME Key
4.PROBE Key
5.HOLD Key)
6.Lock ndicator
7.Halo Heat ndicator
8.Oven Preheat Light
9.LED Display
10.Ready ndicator Light
11.UPand DOWN ARROWS
12.START Key
13.Green ndicator Lights
14.Amber ndicator Lights
15.PRESET Program Keys
16.CANCEL Key
UPPER
COMPAR MEN
LOWER
COMPAR MEN

O&C MANUAL • 1200-TH/III MARINE
P G . 10
1.O / OFF Key
The ON/OFFcontrol system key operates the
functions of the control panel. If there is any
power loss during operation, the ON/OFF indica-
tor light will flash. To clear, push key and release.
2.COOK Key — Temperature range 200° to 325°F (93° to 162°C)
Used to select cooking mode and to review the
cook temperature setting.
3.TIME Key — Maximum time 24 hours
Used to select cook time and to review set time.
4.PROBE Key — Temperature range 50° to 195°F (10° to 91°C)
Used to select internal product probe temperature
mode and to review probe temperature setting.
5.HOLD Key — Temperature range 60° to 205°F (15° to 96°C)
Used to select food holding mode and to review set
holding temperature.
6.Lock Indicator
When illuminated, this symbol indicates settings
used in the cooking sequence are locked and
cannot be changed.
7.Halo Heat Indicator
When the oven is preheating, the Halo Heat
indicator will illuminate during preheating and
remain steady until the oven reaches the set
cooking temperature. When the temperature has
stabilized, the indicator will illuminate periodi-
cally as the oven calls for heat.
8.Oven Preheat Light
Illuminates until the oven is preheated.
9.LED Display
Indicates interior oven air temperature, internal
product probe temperature, time, or when used
in conjunction with other keys, will review
original cooking, holding and probe temperature
settings. The display will also indicate various
programming and diagnostic information.
10.Ready Indicator Light
Illuminates when the oven has finished preheating.
11.UPand DOW ARROWS
Used to increase or decrease set time, including
cooking, holding and probe temperature settings.
12.STA RT Key
Used to initiate a selected mode sequence when
p re sse d and re le ase d . You may stop any mode of
operation by p re ssing a nd h o ld ing the START ey
until you hear a beep.
13.Green Indicator Lights
Located within each function key, the green light
functions as an operator prompt indicating addi-
tional operator action is required and also identi-
fies current mode of operation.
14.Amber Indicator Lights
Located below the COO , TIME, PROBE and HOLD
eys, these indicators will illuminate to identify
the current mode of operation and allows the
operator to identify the information currently
shown in the LED display.
15.PRESET Program Keys
Provides memory storage and operation of up to
eight operator set cooking programs for specific
products (A thru H). I enables locking abilities.
16.CA CEL Key
Used to erase a program from memory storage.
ABCDEFGHI CANCEL
햲햳햴 햵 햶 햷 햸 햹햺 햻 햽 햾
햿
헀
헂
CONTROL FEATURES
Do not use the oven if the controls are not properly functioning. Refer to the Trouble Shooting Guide
located in this manual or call an authorized service technician.
MPORTANT
헁
S cond ON/OFF
k y on singl
control units only
OPERATING INSTRUCTIONS

O&C MANUAL • 1200-TH/III MARINE
P G . 11
OPERATING INSTRUCTIONS
OVEN BEEPING is used to indicate a YES or Oresponse to operator input.
Beeps also indicate mode CHA GES and ERROR conditions.
One brief beep indicates a YES (enabled) response to the information entered into the control.
Two brief beeps indicate a O(disabled) response to the information entered into the control.
A beep that lasts for one second indicates an oven mode TRA SITIO . Example: Preheat to Ready-Start.
Three brief beeps indicate the oven is in the READY mode for product loading and START-UP.
Fo r brief beeps indicate an existing FAULT condition. Refer to the Trouble Shooting section of this manual.
Beeper volume can be changed. With the control in the OFF mode, press and hold the DOW ARROW Key. After 4 seconds,
the display will exhibit one of the 4 volume levels (0 being OFF or the lowest, and 3 being the highest). After each change, the
button must be released and the display must clear before the procedure can be repeated to select a different volume level.
AUDIBLE IGNAL
Turn the Oven Control Panel Off:
Press and hold the O /OFF Key for three seconds. Oven will
beep. The O /OFF indicator light will go out.
top an Operation:
Press and hold the START Key for several seconds until the control
beeps, indicating the operation has been cancelled. The oven will
remain in a power-on state.
Arrow Keys:
Cook, Hold and Probe Temperature set points can be adjusted by
1° when pressing the ARROW Keys. To change a set point more
rapidly, press and hold the ARROW Key along with the key for the
temperature function, and the temperature changes in steps of 10°F or 5°C.
The Time setting is adjusted in increments of one minute by pressing
the ARROW Keys. To make adjustment in steps of ten minutes, press
and hold the TIME Key and ARROW Key at the same time.
Probe Usage:
When the oven probe remains inserted in the probe bracket, the LED
temperature display will indicate the ambient air temperature inside
the oven. To use the probe for cooking remove it from the bracket
and wipe the full length of the metal probe with a disposable alcohol
pad to clean and sanitize before using.
Only the tip of the probe senses the internal product temperature;
therefore, it is important the tip be placed correctly in the product for
internal temperature accuracy. Push the probe tip halfway into the
product, positioning the tip at the center of the food mass. When
inserting the probe into solid foods such as meat roast or poultry
breasts, push the probe in from a straight downward position or in from
the side to the center position. If placing into a semi-liquid or liquid
product, the probe cable must be secured to keep the probe positioned
properly. Do not let the probe tip touch the edges, bottom or side of a
container. Tape the probe cable to the lip or edge of the container.
Display High/Low Probe Temperatures:
To observe the recorded maximum or minimum
probe temperature when cooking by probe,
press the following keys while the probe
remains in the product:
Highest Temperature: Press PROBE Key and
UPARROW Key at same time.
Lowest Temperature: Press PROBE Key and
DOW ARROW Key at same time.
Halo Heat Indicator:
When the oven is preheating the Halo Heat
indicator light will remain illuminated until it
reaches the set cook temperature. Once the
temperature has stabilized, this indicator will
illuminate periodically as the oven calls for heat.
Green and Amber Indicators:
Each program key includes a green light which
indicates a requirement for additional
programming by the operator or the current
operational state of the oven.
The COOK, TIME, PROBE, and
HOLD keys include an amber
indicator light to identify the
information being displayed.
Power Fail Detect:
If the power were to fail for any reason while
heating, the control will retain, in memory, the
programmed operating conditions. When power
is restored, the control will resume operating
from the point where it was interrupted and the
O/OFF indicator light will flash, indicating that
such an event did occur. The operator can turn
off the flashing light by pressing the O /OFF key.
NOTE: If s ch an event has occ rred,
it i s s t rong l y recom m ende d t h at yo
ens re the food is safe for cons mption
according to local health reg lations.
O P E R AT I N G F E AT U R E & F U N C T I O N
●
Amber
Green
NOTE: When cooking by probe, insert the probe into the
raw product after the oven has been preheated.
WAIT ONE FULL MINUTE to allow the probe temperature
to decrease to the internal temperature of the product.
Press the start button to begin the cooking process after
t h i s p r o b e t e m p e r a t u r e a d j u s t m e n t p e r i o d . A f a l s e
probe reading of the internal product temperature will
cause the oven to default to a holding temperature.

O&C MANUAL • 1200-TH/III MARINE
P G . 12
Cook by Time: IS TH E MA I ELECTRICAL POWER SWITCH O ?
Press and release control O /OFFkey.
•The green indicator light on the ON/OFF key will illuminate.
• The oven will beep for one second.
• The oven will begin operating in the hold mode.
• The amber hold indicator will illuminate.
• The previously set hold temperature will be displayed.
Press the HOLD Key.
➥To change the hold temperature, press the UPor DOWN ARROW eys.
ote: If the oven is being used for hot food holding only, adjust the
set holding temperature. Do no t press the COO , TIME, or PROBE eys.
Press COOK Key to preheat.
• The green indicator light on the COO ey will illuminate.
• Last set cooking temperature will be displayed.
➥To change the cook temperature, press the
UPor DOWN ARROW eys.
• The green indicator light on the TIME ey and
on the PROBE ey alternately flash.
Press TIME Key.
• The green indicator light on the TIME ey will illuminate.
• Last set time is displayed.
➥To change the cook time, press the UPor DOWN ARROW eys.
• The green indicator light on the TIME ey will illuminate.
• Halo Heat and Pre-Heat indicator will illuminate.
➥The oven is automatically programmed to preheat to the cook temperature.
• The oven will beep when preheated and the preheat indicator light will go out.
• Both the Ready and Start indicator lights will flash.
➥The set cook temperature will be maintained by the oven and appear in the display
while in the ready/start mode.
Load the food inside oven and close the oven door.
ote: The oven will beep 3 times every 25 seconds until the oven is loaded and the START
ey pressed.
Press and release STA RT key.
COOK
• The oven will beep.
• The green indicators for power, cook, time, and start will illuminate.
• The display will alternate between showing the set cook temperature and the remaining time.
HOLD
• The oven will beep at the end of the timed cooking cycle.
• The green indicator for cook will remain illuminated.
• The display will alternate between showing the set hold temperature and the amount of
time the product has remained in the holding mode.
• The Ready indicator light will illuminate after 2 hours in the hold mode.
ote: The ready indicator does not necessarily indicate a product-ready state. For best
results, the product must remain in the oven at the set holding temperature for the
minimum number of hours indicated in the individual cooking instructions.
• The oven will remain operating in the hold mode until the control ON/OFF ey is pressed.
H E L P F U L H I N T
To avoid prolonged
preheat times between
loads, leave the
oven in the
hold mode.
TO MAINTAIN SAFE TEMPERATURE LEVELS,
COLD FOOD FOR RETHERMALIZATION OR
REHEATING MUST NEVER BE ADDED TO THE
OVEN WHILE HOT FOODS ARE BEING HELD.
OPERATING INSTRUCTIONS

O&C MANUAL • 1200-TH/III MARINE
P G . 13
Cook by Probe: IS THE MAI ELECTRICAL POWER SWITCH O ?
Press and release control O /OFF Key.
• The green indicator light on the ON/OFFkey will illuminate.
• The oven will beep for one second.
•The oven will begin operating in the hold mode.
• The amber hold indicator will illuminate.
• The previously set hold temperature will be displayed.
Press the HOLD Key.
➥To change the hold temperature, press the UPor DOWN ARROW eys.
ote: If the oven is being used for hot food holding only, adjust the set holding
temperature. Do no t press the COO , TIME, or PROBE keys.
Press COOK Key to preheat.
• The green indicator light on the COO ey will illuminate.
• Last set cooking temperature will be displayed.
➥To change the cook temperature, press the UPor DOWN ARROW eys.
• The green indicator light on the TIME ey and on the PROBE ey alternately flash.
Press PROBE Key.
• The green indicator light on the PROBE ey will illuminate.
• Last set internal product temperature is displayed.
➥To change the internal product temperature, press the UPor DOWN ARROW eys.
• The green indicator light on the PROBE ey will illuminate.
• Halo Heat and Pre-Heat indicator will illuminate.
➥The oven is automatically programmed to preheat to the cook temperature.
• The oven will beep when preheated and the preheat indicator extinguished.
• Both the Ready and Start indicator lights will flash.
➥The set cook temperature will be maintained by the oven and appear in the display
while in the ready/start mode.
Load the food inside oven. Remove probe from its bracket, wipe the probe tip with a disposable
alcohol pad and insert probe properly into the product. Close the oven door.
Note: Oven will beep 3 times every 25 seconds until oven is loaded and START ey pressed.
Press and release STA RT key.
COOK
• The oven will beep.
• The green indicators for power, cook, probe, and start will illuminate.
• The display will alternate between showing the probe temperature and the elapsed time.
HOLD
• The oven will beep when the set probe temperature has been reached.
• The green indicator for cook will remain illuminated.
• The display will alternate between showing the set hold temperature and the amount of
time the product has remained in the holding mode.
• Ready indicator light will illuminate after 2 hours in the hold mode.
ote: The ready indicator does not necessarily indicate a product-ready state. For best
results, the product must remain in the oven at the set holding temperature for the
minimum number of hours indicated in the individual cooking instructions.
• The oven will remain operating in the hold mode until the control ON/OFF ey is pressed.
OPERATING INSTRUCTIONS
TO MAINTAIN SAFE TEMPERATURE LEVELS,
COLD FOOD FOR RETHERMALIZATION OR
REHEATING MUST NEVER BE ADDED TO THE
OVEN WHILE HOT FOODS ARE BEING HELD.

O&C MANUAL • 1200-TH/III MARINE
P G . 14
Preset Menu Keys:
Alto-Shaam Cook and Hold ovens allow the operator to set up to eight cooking programs. Each cooking
program can be preset in any program mode to cook by time or internal product temperature. Cooking
programs are recalled and stored using the PRESET eys labeled "A through H." These keys, along with the key
labeled "I" share additional functions described in the "User Options" section of this manual.
Programming a Cooking Program
Prior to this procedure, make sure the oven is “OFF”. Select the food product to be programmed.
Press and release control ON/OFFkey. The oven will beep for one second and power to the unit
will be indicated by an illuminated green indicator light located in the upper left corner of the
ON/OFF key. The oven will begin operating in the hold mode. The amber hold indicator will be
illuminated and the last set hold temperature will be displayed.
Press HOLD ey. To change the hold temperature, press the UPor DOWN
ARROW eys.
Press COO ey. Oven preheat indicator will illuminate and the last set cooking temperature
is displayed. To change the cook temperature, press the UPor DOWN ARROW eys.
To cook by time — press the TIME ey. Last set cooking time is displayed.
To change the set time, press the UPor DOWN ARROW eys. The green Time
indicator will illuminate.
To cook by probe — press the PROBE ey. Last set internal product temperature is displayed. To
change the set temperature, press the UPor DOWN ARROW eys. The green Probe indicator will
illuminate.
The oven preheat indicator will illuminate. Oven is now in the preheat mode and is
automatically programmed to preheat to the cook temperature.
Select a letter code for the product programmed by the previous steps. Press and hold the
selected PRESET key until you hear a brief, four second beep. The letter key program indicator
light will illuminate and the product programmed is now stored in memory for the specific letter
key pressed. Additional programs can be stored in the remaining PRESET eys if not previously
programmed.
ote: The last PRESET ey used will be the oven cooking run sequence for the next product
to be programmed. Settings can be manually changed for the next product and an alternate
pre-programmed letter key selected.
Erasing a Cooking Program
To erase a program, the oven must be in either the power-up hold mode or in the preheat mode. The oven
cannot be running a Preset Menu program.
When the oven is in the power-up hold mode or in the preheat mode, press and hold both the CANCEL ey and
the appropriate letter PRESET ey to be erased. Hold both keys until the oven beeps and the program's indicator
light goes out to indicate the program has been erased.
—or —
PRESETS A
After programming a specific product into memory in a programmable preset key,
it is very important to make a written permanent record of the product and the program
letter assigned. Menu card (PE-23384) is provided for this purpose.
MPORTANT
OPERATING INSTRUCTIONS

O&C MANUAL • 1200-TH/III MARINE
P G . 15
Cook Using Preset Menu Keys:
Press and release control O /OFFKey.
• The green indicator light on the ON/OFF key will illuminate.
•The oven will beep for one second.
• The oven will begin operating in the hold mode.
• The amber hold indicator will illuminate.
• The previously set hold temperature will be displayed.
•PRESET eys with stored cooking programs will have green indicator illuminated.
Press Desired PRESET Key (A through H)
• Halo Heat and Pre-Heat indicator will illuminate.
➥The oven is automatically programmed to preheat to the cook temperature programmed.
• The oven will beep when preheated and the preheat indicator will go out.
• Both the Ready and Start indicator lights will flash.
➥The set cook temperature will be maintained by the oven and appear in the display
while in the ready/start mode.
Load the food inside oven. If cooking by probe, remove probe from its bracket, wipe the probe tip
with a disposable alcohol pad and insert probe properly into product. Close the oven door.
ote: The oven will beep 3 times every 25 seconds until the oven is loaded and the
START key pressed.
Press and release STA RT Key.
COOK
• The oven will beep.
• The green indicators for power, cook, probe or time, and start will illuminate.
• If programmed to cook by time, the display will alternate between showing the set cook
temperature and the time remaining.
• If programmed to cook by probe, the display will alternate between showing the set cook
temperature and the elapsed time.
HOLD
• The oven will beep when the set probe temperature has been reached or set time has elapsed.
• The green indicator for cook will remain illuminated.
• The display will alternate between showing the set hold temperature and the
amount of time the product has remained in the holding mode.
• The Ready indicator light will illuminate after 2 hours in the hold mode.
ote: The ready indicator does not necessary indicate a product-ready state. For best
results, the product must remain in the oven at the set holding temperature for the
minimum number of hours indicated in the individual cooking instructions.
• The oven will remain operating in the hold mode until the control ON/OFF ey is pressed.
PRESETS A
OPERATING INSTRUCTIONS

O&C MANUAL • 1200-TH/III MARINE
P G . 16
PRESET Keys Lock and Unlock
PRESET eys A through H can be locked in order to
prevent storing, altering or erasing a program.
To lock the PRESET eys, press and hold the "I" ey
until the oven beeps. Release the “I” key. The
green indicator on the "I" key will illuminate.
Oven PRESET eys A through H are now locked.
ote: Only the oven PRESET keys A through H are
affected by this lock-out in order to also allow
the oven to be used with the unprogrammed
Cook, Probe, or Hold modes.
To unlock the PRESET eys, press and hold the
CANCEL ey along with the "I" ey until you hear a
brief beep. Release all keys. The green indicator on
the "I" key will extinguish. The oven preset keys are
now unlocked.
Fahrenheit or Celsius Selection
With the control in the off mode,
press and hold the UPARROW ey
until the display toggles between
Fahrenheit and Celsius. After each
change the button must be released.
The display must clear before the
procedure can be repeated.
Control Panel Lock and Unlock
The control panel can be locked at any time in order
to prevent inadvertent or accidental setting changes.
To lock the control panel, press and hold the UPARROW
ey and then press the ON/OFF ey.
You will hear a brief beep and the panel lock
indicator will illuminate. Release all keys. The
oven's control panel is now locked.
ote: The control panel is now fully locked with
the exception of the ON/OFF ey and ARROW
keys. You will be unable to turn the oven
control off at this point.
To unlock the control panel, press and hold the
DOWN ARROW ey and then press the ON/OFF ey.
You will hear two brief beeps and the panel lock
indicator will extinguish. Release all keys. The
panel is now unlocked and ready for normal use.
Beeper Volume Selection
With the control in the off mode,
press and hold the DOWN ARROW ey
until the display shows one of the 4
volume levels (0 being OFF or the
lowest, and 3 being the highest).
After each change, the button must be
released and the display must clear
before the procedure can be repeated
to select a different volume level.
Lock
ndicator
EFGHI CANCEL
Preset
Lock
OPERATING INSTRUCTIONS
USER OPTIONS

O&C MANUAL • 1200-TH/III MARINE
P G . 17
HOL D NG TE MP E RA TU RE RA N GE
MEAT F AH RE N HE T CEL S U S
BEEF ROAST — Rare 140°F 60°C
BEEF ROAST — Med/Well Done 160°F 71°C
BEEF BRIS ET 160° — 175°F 71° — 79°C
CORN BEEF 160° — 175°F 71° — 79°C
PASTRAMI 160° — 175°F 71° — 79°C
PRIME RIB — Rare 140°F 60°C
STEA S — Broiled/Fried 140° — 160°F 60° — 71°C
RIBS — Beef or Pork 160°F 71°C
VEAL 160° — 175°F 71° — 79°C
HAM 160° — 175°F 71° — 79°C
POR 160° — 175°F 71° — 79°C
LAMB 160° — 175°F 71° — 79°C
POULTRY
CHIC EN — Fried/Baked 160° — 175°F 71° — 79°C
DUC 160° — 175°F 71° — 79°C
TUR EY 160° — 175°F 71° — 79°C
GENERAL 160° — 175°F 71° — 79°C
FSH/ SEAFOOD
FISH — Baked/Fried 160° — 175°F 71° — 79°C
LOBSTER 160° — 175°F 71° — 79°C
SHRIMP — Fried 160° — 175°F 71° — 79°C
BAKED GOODS
BREADS/ROLLS 120° — 140°F 49° — 60°C
M SCELLANEOUS
CASSEROLES 160° — 175°F 71° — 79°C
DOUGH — Proofing 80° — 100°F 27° — 38°C
EGGS —Fried 150° — 160°F 66° — 71°C
FROZEN ENTREES 160° — 175°F 71° — 79°C
HORS D'OEUVRES 160° — 180°F 71° — 82°C
PASTA 160° — 180°F 71° — 82°C
PIZZA 160° — 180°F 71° — 82°C
POTATOES 180°F 82°C
PLATED MEALS 180°F 82°C
SAUCES 140° — 200°F 60° — 93°C
SOUP 140° — 200°F 60° — 93°C
VEGETABLES 160° — 175°F 71° — 79°C
The holding temperatures listed are suggested guidelines.
General Holdin Guideline
Chefs, cooks and other specialized food service
personnel employ varied methods of cooking.
Proper holding temperatures for a specific food
product must be based on the moisture content of
the product, product density, volume, and proper
serving temperatures. Safe holding temperatures
must also be correlated with palatability in
determining the length of holding time for a
specific product.
Halo Heat maintains the maximum amount of
product moisture content without the addition of
water, water vapor, or steam. Maintaining
maximum natural product moisture preserves the
natural flavor of the product and provides a more
genuine taste. In addition to product moisture
retention, the gentle properties of Halo Heat
maintain a consistent temperature throughout the
cabinet without the necessity of a heat distribution
fan, thereby preventing further moisture loss due to
evaporation or dehydration.
When product is removed from a high
temperature cooking environment for immediate
transfer into equipment with the lower temperature
required for hot food holding, condensation can
form on the outside of the product and on the inside
of plastic containers used in self-service
applications. Allowing the product to release the
initial steam and heat produced by high temperature
cooking can alleviate this condition. To preserve the
safety and quality of freshly cooked foods, however,
a maximum of 1 to 2 minutes must be the only time
period allowed for the initial heat to be released
from the product.
Most Halo Heat Holding Equipment is provided
with a thermostat control between 60° and 200°F
(16° to 93°C). If the unit is equipped with vents,
close the vents for moist holding and open the vents
for crisp holding.
OPERATING INSTRUCTIONS

O&C MANUAL • 1200-TH/III MARINE
P G . 18
CLEANING AND PREVENTIVE MAINTENANCE
PROTECTING STAINLESS STEEL SURFACES
It is important to guard against
corrosion in the care of
stainless steel surfaces.
Harsh, corrosive, or
inappropriate chemicals can
completely destroy the
protective surface layer of stainless steel. Abrasive
pads, steel wool, or metal implements will abrade
surfaces causing damage to this protective coating
and will eventually result in areas of corrosion.
Even water, particularly hard water that contains
high to moderate concentrations of chloride, will
cause oxidation and pitting that result in rust and
corrosion. In addition, many acidic foods spilled
and left to remain on metal surfaces are
contributing factors that will corrode surfaces.
Proper cleaning agents, materials, and
methods are vital to maintaining the appearance
and life of this appliance. Spilled foods should be
removed and the area wiped as soon as possible
but at the very least, a minimum of once a day.
Always thoroughly rinse surfaces after using a
cleaning agent and wipe standing water as quickly
as possible after rinsing.
CLEANING AGENTS
Use non-abrasive cleaning products designed for use
on stainless steel surfaces. Cleaning agents must be
chloride-free compounds and must not contain
quaternary salts. Never use hydrochloric acid
(muriatic acid) on stainless steel surfaces. Always use
the proper cleaning agent at the manufacturer's
recommended strength. Contact your local cleaning
supplier for product recommendations.
CLEANING MATERIALS
The cleaning function can usually be accomplished
with the proper cleaning agent and a soft, clean
cloth. When more aggressive methods must be
employed, use a non-abrasive scouring pad on
difficult areas and make certain to scrub with the
visible grain of surface metal to avoid surface
scratches. Never use wire brushes, metal scouring
pads, or scrapers to remove food residue.
C
CARE AND CLEANING

O&C MANUAL • 1200-TH/III MARINE
P G . 19
EQUIPMENT CARE
Under normal circumstances, this
oven should provide you with long
and trouble free service. There is no
preventative maintenance required,
however, the following Equipment
Care Guide will maximize the potential life and
trouble free operation of this oven.
The cleanliness and appearance of this equipment
will contribute considerably to operating efficiency
and savory, appetizing food. Good equipment that
is kept clean works better and lasts longer.
CLEAN DAILY
1. Disconnect unit from power
source, and let cool.
2. Remove all detachable items
such as wire shelves, side
racks, and drip pans. Clean
these items separately.
3. Wipe the interior metal surfaces
of the oven with a paper towel to
remove loose food debris.
4. Clean the interior metal surfaces of the cabinet
with a damp clean cloth or sponge and any good
commercial detergent.
NOTE: Avoid the use of abrasive cleaning com-
pounds, chloride based cleaners, or cleaners
containing quaternary salts. Never use
hydrochloric acid (muriatic acid) on stain-
less steel.
5. Spray heavily soiled areas with a water soluble
degreaser and let stand for 10 minutes, then
remove soil with a plastic scouring pad.
6. Wipe control panel, door vents, door handles,
and door gaskets thoroughly since these areas
harbor food debris.
7. Rinse surfaces by wiping with sponge and clean
warm water.
8. Remove excess water with sponge and wipe dry
with a clean cloth or air dry. Leave doors open
until interior is completely dry. Replace side
racks and shelves.
9. Wipe door gaskets and control panel dry with a
clean, soft cloth.
10. Interior can be wiped with a sanitizing solution
after cleaning and rinsing. This solution must
be approved for use on stainless steel food
contact surfaces.
11. To help maintain the protective film coating on
polished stainless steel, clean the exterior of the
cabinet with a cleaner recommended for stain-
less steel surfaces. Spray the cleaning agent on
a clean cloth and wipe with the grain of the
stainless steel.
12. Clean any glass with a window cleaner.
Always follow appropriate state or local health
(hygiene) regulations regarding all applicable clean-
ing and sanitation requirements for equipment.
CLEAN THE DOOR VENTS
Door vents need to be inspected and cleaned
as required.
CLEAN THE PROBES DAILY
Remove all food soil from probes.
Wipe entire probe and cable assembly
with warm detergent solution and a
clean cloth. Remove detergent by
wiping each probe and cable
with clean rinse water and a
cloth. Wipe probes and probe brackets with disposable
alcohol pad or sanitizing solution recommended for
food contact surfaces. Allow probe and cable to air dry
in probe holding bracket.
CHECK THE COOLING FAN IN THE OVEN
CONTROL AREA
While the oven is warm, check that the cooling fan in
the oven control area is functioning. The fan is located
at the back of the unit, toward the top.
CHECK OVERALL CONDITION OF
OVEN ONCE A MONTH
Check the oven once a month for physical damage and
loose screws. Correct any problems before they begin
to interfere with the operation of the oven.
CARE AND CLEANING
AT NO TIME SHOULD THE INTERIOR OR
EXTERIOR BE STEAM CLEANED, HOSED
DOWN, OR FLOODED WITH WATER OR
LIQUID SOLUTION OF ANY KIND. DO NOT
USE WATER JET TO CLEAN.
SEVERE DAMAGE OR ELECTRICAL HAZARD
COULD RESULT.
WARRANTY BECOMES VOID IF APPLIANCE IS FLOODED.
DO NOT USE OVEN IF CONTROLS ARE NOT
PROPERLY FUNCTIONING
Refer to the Trouble Shooting Guide located in this
manual or call an authorized service technician.
