Operator’s Manual
Cook & Hold Ovens
Smoker Ovens
Deluxe Control
300-TH
500-TH
750-TH
1000-TH
1200-TH
1750-TH
750-SK
1000-SK
1200-SK
1750-SK
MN-46708-EN
REV.01
11/20
EN

Del uxe Control C ook & Ho l d ▪ Opera tor’s Manual ▪ MN- 4 6708 ▪ Rev 1 ▪ 11/20
2
Manufacturer’s Information
Copyright © Copyright 11/20 by Alto-Shaam, Inc.
All rights reserved.
This manual or any portion thereof may not be reproduced or used in any
manner whatsoever without the express written permission of Alto-Shaam, Inc.
Trademarks All trademarks referenced in this documentation are the property of their
respective owners.
Manufacturer Alto-Shaam, Inc.
P.O. Box 450
W164 N9221 Water Street
Menomonee Falls, WI 53052
Original instructions The content in this manual is written in American English.

FOREWORD
De l uxe C ontro l Cook & Ho l d ▪ Oper a tor’s Manual ▪ MN- 46 7 0 8 ▪ Rev 1 ▪ 11/20
3
FOREWORD
Enjoy your Alto-Shaam® Cook & Hold Oven!
Halo Heat®
Technology
Cook & Hold Oven
Precise, low-temperature cooking with Halo Heat technology perfected prime rib
for decades. Free up time with overnight cooking for corned beef, confit, and
even yogurt. Cook your food to perfection and hold for hours without
compromising food quality. No fans. No hood needed. Only big flavor and
savings.
Smoker Oven
The Alto-Shaam smoker oven can make a big impact on your operation. Use hot
or cold smoke to prepare anything from brisket to cheese. Cook your food to
perfection, and/or smoke it to perfection, then hold it for hours without
compromising food quality.
Extend Your Manufacturer’s Warranty
Register Register your Alto-Shaam appliance online. Registering your appliance ensures
prompt service in the event of a warranty claim.
Your personal information will not be shared with any other company.
alto-shaam.com/warranty
Alto-Shaam 24/7 Emergency Repair Service
Call Call 800-558-8744 to reach our 24-hour emergency service call center for
immediate access to local authorized service agencies outside standard business
hours. The emergency service access is provided exclusively for Alto-Shaam
equipment and is available throughout the United States through Alto-Shaam’s
toll free number.
Availability Emergency service access is available seven days a week, including holidays.

FOREWORD
Del uxe Control C ook & Ho l d ▪ Opera tor’s Manual ▪ MN- 4 6708 ▪ Rev 1 ▪ 11/20
4
This page intentionally left blank.

TABLE OF CONTENTS
De l uxe C ontro l Cook & Ho l d ▪ Oper a tor’s Manual ▪ MN- 46 7 0 8 ▪ Rev 1 ▪ 11/20
5
TABLE OF CONTENTS
Safety
Manufacturer’s Information . . . . . . . . . . . . . . . . . . . . . . . . 2
Foreword 3
Enjoy your Alto-Shaam® Cook & Hold Oven! . . . . . . . . . . . . . . 3
Extend Your Manufacturer’s Warranty . . . . . . . . . . . . . . . . . . 3
Alto-Shaam 24/7 Emergency Repair Service . . . . . . . . . . . . . . . 3
Table of Contents 5
Safety 7
The Meaning of Signal Words . . . . . . . . . . . . . . . . . . . . . . . 7
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Labels 11
Label Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installation 15
Dimension Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
How to Receive the Appliance . . . . . . . . . . . . . . . . . . . . . . . 21
How to Unpack the Oven . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Pre-Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
How to Install the Oven. . . . . . . . . . . . . . . . . . . . . . . . . . . 28
How to Connect the Electrical Wiring . . . . . . . . . . . . . . . . . . . 34
How to Install the Drip Tray . . . . . . . . . . . . . . . . . . . . . . . . 37
How to Stack Two Ovens . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Operation 39
How to Turn On and Turn Off the Oven . . . . . . . . . . . . . . . . . 39
How to Prepare the Oven for First Use . . . . . . . . . . . . . . . . . . 40
How to View and Set up WiFi Connection. . . . . . . . . . . . . . . . . 41
How to Set up an Ethernet Connection . . . . . . . . . . . . . . . . . . 44
How to Use the Door Vents . . . . . . . . . . . . . . . . . . . . . . . . 46
How to Preheat the Oven. . . . . . . . . . . . . . . . . . . . . . . . . . 47
How to Cook with Programmed Recipes . . . . . . . . . . . . . . . . . 48
How to Cook and Hold by Time in Manual Mode . . . . . . . . . . . . 50
Understanding the Probes . . . . . . . . . . . . . . . . . . . . . . . . . 53
How to Cook by Probe in Manual Mode . . . . . . . . . . . . . . . . . 54
How to Hold by Probe. . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
How to Prepare the Smoker Box for Smoking . . . . . . . . . . . . . . 60
How to Hot Smoke in Manual Mode . . . . . . . . . . . . . . . . . . . 61
How to Cold Smoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
How to Create a Recipe . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
How to Modify, Duplicate, or Delete a Recipe . . . . . . . . . . . . . . 70
How to Load Recipes from a USB Drive. . . . . . . . . . . . . . . . . . 71

TABLE OF CONTENTS
Del uxe Control C ook & Ho l d ▪ Opera tor’s Manual ▪ MN- 4 6708 ▪ Rev 1 ▪ 11/20
6
How to Save Recipes to a USB Drive . . . . . . . . . . . . . . . . . . . 73
How to Update Software with a USB Drive . . . . . . . . . . . . . . . 75
How to Change Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 77
How to View Oven Information . . . . . . . . . . . . . . . . . . . . . . 79
How to Download HACCP Data . . . . . . . . . . . . . . . . . . . . . . 80
How to Calibrate the Temperature Probe . . . . . . . . . . . . . . . . 82
Maintenance 85
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
How to Clean the Oven. . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Troubleshooting 89
Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Cheflinc.alto-shaam.com is Not Available on Your Device . . . . . . . 92
Cannot Connect to cheflinc.alto-shaam.com . . . . . . . . . . . . . . 93
The Oven is not Displayed on the Dashboard . . . . . . . . . . . . . . 94
Unable to Assign Recipes from the Dashboard to Ovens in the Field 95
Warranty 97
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Declaration of Conformity 99

SAFETY
De l uxe C ontro l Cook & Ho l d ▪ Oper a tor’s Manual ▪ MN- 46 7 0 8 ▪ Rev 1 ▪ 11/20
7
SAFETY
The Meaning of Signal Words
This manual contains signal words where needed. These signal words must be
obeyed to reduce the risk of death, personal injury, or equipment damage. The
meaning of these signal words is explained below.
DANGER
Danger indicates a hazardous situation which, if not avoided,
will result in serious injury or death.
WARNING
Warning indicates a hazardous situation which, if not avoided,
could result in serious injury or death.
CAUTION
Caution indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE
Notice indicates a situation which, if not avoided, could result
in property damage.
NOTE: Note indicates additional information that is important to a
concept or procedure.

SAFETY
Del uxe Control C ook & Ho l d ▪ Opera tor’s Manual ▪ MN- 4 6708 ▪ Rev 1 ▪ 11/20
8
Safety Precautions
Before you begin Read and understand all instructions in this manual.
Electrical precautions Obey these electrical precautions when using the appliance:
▪Connect the appliance to a properly grounded outlet. Do not use the appliance if
it is not properly grounded. Consult an electrician if there is any doubt that the
outlet used is properly grounded.
▪Keep the cord away from hot surfaces.
▪Do not attempt to service the appliance or its cord and plug.
▪Do not operate the appliance if it has a damaged cord or plug.
▪Do not immerse the cord or plug in water.
▪Do not let the cord hang over the edge of a table or counter.
▪Do not use an extension cord.
Usage precautions Obey these usage precautions when using the appliance:
▪Only use this appliance for its intended use of heating or cooking.
▪Always keep liquids, or foods that can become liquid when heated, level and at or
below eye level where they can be seen.
▪Always open the appliance door very slowly. Escaping hot vapors or steam can
cause serious injury.
▪Use utensils and protective clothing such as dry oven mitts when loading and
unloading the appliance.
▪Use caution when using the appliance. Floors adjacent to the appliance may
become slippery.
▪Do not cover or block any of the openings of this appliance.
▪Do not cover shelves or any other part of this appliance with metal foil.
▪Do not use this appliance near water such as a sink, in a wet location, near a
swimming pool, or similar locations.
Maintenance
precautions
Obey these maintenance precautions when maintaining the appliance:
▪Obey precautions in the manual, on tags, and on labels attached to or shipped
with the appliance.
▪Only clean the appliance when the oven is disconnected from the power source.
▪Do not store the appliance outdoors.
▪Do not clean the appliance with metal scouring pads.
▪Do not use corrosive chemicals when cleaning the appliance.
▪Do not use a hose or water jet to clean the appliance.
▪Do not use the appliance cavity for storage.
▪Do not leave flammable materials, cooking utensils, or food inside the appliance
when it is not in use.
Continued on next page

SAFETY
De l uxe C ontro l Cook & Ho l d ▪ Oper a tor’s Manual ▪ MN- 46 7 0 8 ▪ Rev 1 ▪ 11/20
9
Continued from previous page
Operator training All personnel using the appliance must have proper operator training. Before
using the appliance:
▪Read and understand the operating instructions contained in all the
documentation delivered with the appliance.
▪Know the location and proper use of all controls.
▪Keep this manual and all supplied instructions, diagrams, schematics, parts lists,
notices, and labels with the appliance if the appliance is sold or moved to another
location.
▪Contact Alto-Shaam for additional training if needed.
Operator
qualifications
Only trained personnel with the following operator qualifications are permitted
to use the appliance:
▪Have received proper instruction on how to use the appliance.
▪Have demonstrated their ability with commercial kitchens and commercial
appliances.
The appliance must not be used by:
▪Persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given
supervision concerning use of the appliance by person responsible for their
safety.
▪People impaired by drugs or alcohol.
▪Children should be supervised to ensure that they do not play with the appliance.
▪Children shall neither clean nor maintain the appliance.
Condition of
appliance
Only use the appliance when:
▪All controls operate correctly.
▪The appliance is installed correctly.
▪The appliance is clean.
▪The appliance labels are legible.
Servicing the
appliance
▪Only trained personnel are permitted to service or repair the appliance. Repairs
that are not performed by an authorized service partner or trained technician will
void the warranty and relieve Alto-Shaam of all liability.
▪To prevent serious injury, death or property damage, have the appliance
inspected and serviced at least every twelve (12) months by an authorized service
partner or trained technician.
▪Contact Alto-Shaam for the authorized service partner in your area.
Continued on next page

SAFETY
Del uxe Control C ook & Ho l d ▪ Opera tor’s Manual ▪ MN- 4 6708 ▪ Rev 1 ▪ 11/20
10
Continued from previous page
Personal Protective
Equipment (PPE)
Wear the following Personal Protective Equipment (PPE) while cleaning the
appliance:
▪Protective gloves
▪Protective clothing
▪Eye protection
▪Face protection
Use of restraining
devices
A restraining device (tether) must be installed to any appliance that is hard-wired
and mounted on casters. The tether must:
▪Be secured to the building’s structure.
▪Limit the movement of the appliance so that no stress is transmitted to the
electrical conduit.
A connection point for the tether is located on the back of the appliance.
A tether is not supplied by nor available from the manufacturer.
