AirDeck Instructions and User Guide
Instructions ...........................................................................................................................................................3-6
Care & Maintenance
Instructions ...............................................................................................................................................................7
Disclaimer & Copyright
Disclaimer..................................................................................................................................................................8
Copyright ...................................................................................................................................................................8
Contents

3www.altradgeneration.com
AirDeck Instructions and User Guide
Installers should adhere to all current Health and Safety Rules, such as the wearing of protective
clothing, ie hard hat, high visibility Vest/Jacket, metal toe capped boots and hand protective gloves.
AirDeck products are tested to the requirements of PAS59 safety standard.
Ensure the area is free from debris. Lay out the AirDeck bags to
allow for complete oor coverage. One bag when inated meas-
ures 750mm x 750mm x2100mm (wxhxl) and covers 1.6 m2. 50
bags, for example, will cover 80m2.
Make sure that the inator is ready for use and that the battery is fully charged.
Three green lights on the charger indicate that the battery is charged to its maximum.
1.
2.

4
[e-mail]
AirDeck Instructions and User Guide
Open the access ap and expose the valve. Remove the screw
cap.
Fully inate the liner until it completely lls the outer. The
pressure regulator on the blower will ensure that the
AirDeck is not over inated.
Insert the Inator through the valve and inate with the Inator
at maximum.
3.
5.
4.

5www.altradgeneration.com
AirDeck Instructions and User Guide
Once the liner is full of air, make sure the non-return ap is well seated and then screw the cap
on tightly.
On full ination of the AirDeck, make sure that the liner does not
protrude and that the ap will close fully to protect the liner.
Should this not be the case, deate the liner slightly and adjust
by pulling the liner through the access overlap ap at the far
end of the liner.
6.
7.
8.

6
[e-mail]
AirDeck Instructions and User Guide
Add more bags by following Steps 1-7 and clip them together.
If the bags are not constrained by outer walls and are being
used in an open situation, use bags with clips both top and
bottom to ensure no movement of the bags
Cover the whole oor area. Clip the last bag in the row to its
neighbour before inating further bags. If necessary, partly
inated bags can be squeezed in to small or awkward gaps.
To deate the bags remove the valve screw cap. Push back
the ap using the red tab until it locks in position. Using the
extract facility on the pump, if it has one, draw out all the air.
Alternatively the bags will deate rapidly if the valve is just left
open.
Make sure the bags are fully deated and
then fold for on-site storage. Take care to
store the bags and liners in a protected
environment
9.
10.
11.
12.

7www.altradgeneration.com
Care and Maintenance
With care, regular inspections and under normal conditions of use and storage you might expect
a full working life of up to three years.
•Please make sure you follow all recommendations for use as indicated on the liner taking
particular care not to walk on the liners when setting out for deployment and that no sharp
objects are within the folds when folding for storage
•Wherever possible store in a cool dark place and avoid both extremes of temperature and wide
and rapid uctuations of temperature
•Increased and rough handling may cause fabric failure and will result in a reduction of operating
life. The year and month of manufacture is marked on each liner as a guide to the operating life
you might expect
• Check that the liner stays inated at each deployment and replace if necessary. To do this:
• Remove the old liner through the front ap
• Fully unfold the new liner and part inate to remove creases
• Deate and then pull through the front ap by reaching in through the overlap ap at
the far end until centrally located
•Keep a record of checks, use and frequency of deployment

8
[e-mail]
Disclaimer & Copyright
Disclaimer
Whilst Generation (UK) Ltd has taken every reasonable eort to ensure the information contained
within this publication is correct and complete at the time of printing, you should be aware
that there will be periodical changes and Generation (UK) Ltd does not accept any liability for
any inconvenience, loss or damage caused as a result of any inaccuracy or omission within this
publication.
Copyright
No unauthorised reproduction of any images, text or other matter contained herein is permitted.
All rights are expressly reserved, including copyright, design right, moral and patent rights (where
applicable). We reserve the right to take legal action in respect of any infringement of said rights.
