Altronix AL600UL3 User manual

AL600UL3
AL600UL3X
Triple Output
Power Supply/Charger
Installation Guide
For a red enclosure, add an “R” suffix to the part # e.g. AL600UL3R
Altronix Corp.
140 58th St. Brooklyn, NY
LI
S
TED
S
E
C
URITY
SIGNALING
LISTED
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
Rev. 120612

      
 
     
     
    
    
     
   
    
     
   
    
        
      
   
       
     
    
        
      
     
        
        
Overview:
The AL600UL3/AL600UL3X Triple Output Power Supply/Charger is specifically designed for use with access control
and fire-protective signaling systems and accessories. The AL600UL3/AL600UL3X converts a 115VAC 60Hz input into
three (3) outputs (see specifications).
Specifications:
Agency Listings:
• UL Listed for Access Control System Units
(UL 294) and UL Listed Standard for Safety for Fire
Protective Signaling Systems (UL 1481).
• cUL Listed: CSA Standard C22.2 No.205-M1983,
Signal Equipment.
• MEA - NYC Department of Buildings Approved.
• CSFM - California State Fire Marshal Approved.
• NFPA 72 compliant (Fire-Protective Signaling Service).
Input:
• Input 115VAC /60Hz, 3.5 amp.
• AC input and DC output LED indicators.
Output:
• Class 2Rated power-limited outputs
(5VDC and 12VDC only).
• 1.75 amp continuous supply current at
5VDC and 12VDC regulated outputs.
• 3amp continuous supply current at 24VDC
(for Fire-Protective Signaling use Special applications).
• Filtered and electronically regulated outputs.
100 mV p/p output ripple.
Output (cont’d.):
• Short circuit and thermal overload protection.
Battery Backup
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switch over to stand-by battery when
AC fails.
• Maximum charge current 0.7 amp.
• Zero voltage drop when switched over to battery backup.
Supervision:
• AC fail supervision (form “C” contacts).
• Low battery and battery presence supervision
(form “C” contacts).
Additional Features:
•Power supply, enclosure, cam lock and battery leads.
• Enclosure accommodates up to two (2) 7AH batteries.
Enclosure dimensions (H xWxD):
AL600UL3
13.5” x13” x3.25” (342.9mm x330.2mm x82.55mm)
AL600UL3X
15.5” x12” x4.5” (393.7mm x304.8mm x114.3mm).
Stand-by Specifications (Current is specified on AL3XB input):
Output 4 hr. of Stand-by &
5 Minutes of Alarm
24 hr. of Stand-by &
5 Minutes of Alarm
60 hr. of Stand-by &
5 Minutes of Alarm
5VDC - 1.75 amp 5VDC - 0.3 amp 5VDC - 0.1 amp
24VDC / 40AH Battery 12VDC - 1.75 amp 12VDC - 0.3 amp 12VDC - 0.1 amp
24VDC - 3 amp 24VDC - 0.3 amp 24VDC - 0.1 amp
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and with all local
codes and authorities having jurisdiction. Product is intended for indoor use only.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s
upper keyholes over the two upper screws; level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install the three fasteners. Place the enclosure’s upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pgs. 7-8).
Secure enclosure to earth ground. It is recommended to first review the following tables for screw terminals, switch
selection and LED status indications. This will greatly facilitate installation hook-up.
Carefully review:
Stand-by Specifications (pg. 2)
LED Diagnostics (pg. 4)
Terminal Identification Table (pg. 4)
2. Connect AC power (115VAC 60Hz) to the terminals marked [L, N] (Fig. 1, pg. 3). Use 14 AWG or larger for all
power connections (Battery, DC output, AC input). Use 22 AWG to 18 AWG for power-limited circuits
(AC Fail/Low Battery reporting).
Keep power-limited wiring separate from non power-limited wiring (115VAC / 60Hz Input, Battery Wires).
Minimum 0.25” spacing must be provided.
For Fire Alarm applications the outputs are “Special Applications” only, see list (refer to Appendix A, pg. 5).
3. Measure output voltage before connecting devices. This helps avoiding potential damage.
- 2 - AL600UL3/AL600UL3X
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

4. Connect 5VDC devices to be powered at 5VDC to the terminals marked [+ 5VDC -- ].
5. Connect 12VDC devices to be powered at 12VDC to the terminals marked [+ 12VDC -- ].
6. Connect 24VDC devices to be powered at 24VDC to the terminals marked [+ 24VDC -- ].
7. Connect two (2) 12V Stand-by batteries.
Note: For Access Control applications batteries are optional. When batteries are not used, a loss of AC will result in
the loss of output voltage. Batteries must be lead acid or gel type if used. Two (2) 12V Stand-by batteries
connected in series to the terminals marked [+ BAT -- ] (Fig. 1 , pg. 3).
8. It is required to connect supervisory trouble reporting devices to outputs marked [AC FAIL, LOW BAT] (Fig. 1, pg. 3).
Use 22 AWG to 18 AWG for AC Fail & Low Battery reporting. AC Failure will report in 5 minutes.
Note: When used in fire alarm or access control applications, “AC Fail” relay should be utilized to visually indicate
that AC power is on. To delay report for 6 hours cut “AC Delay” jumper (Fig. 1a, pg. 3).
9. Please ensure that the cover is secured with the provided Key Lock.
Fig. 1
CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and fire hazard
replace fuse with the same type and rating. Do not expose to rain or moisture.
+DC ---
NC C NO NC C NO
+ BAT ---
AC DC Bat
Risk of Fire, Replace Fuses As Marked
Opened - 24V Closed - 12V
AC Fail
Bat Fail
J1
SW1
5A 250V
15A 250V
AC Delay
15
L G N
Wire Strap
(from
Enclosure
to Door)
+ 12VDC --- + 5VDC ---+ 24VDC ---
+ INPUT1 ---
24VDC output
is non
power-limited
5VDC and
12VDC outputs
are power-limited
Battery
connection
(non power-limited)
(non power-limited)
(non
power-
limited)
Earth
Ground
CAUTION: Optional rechargeable stand-by batteries must match the power supply
output voltage setting.
Optional Rechargeable
Stand-by Battery
Optional Rechargeable
Stand-by Battery
Battery and
AC Supervision
Circuit
(power-limited)
J1
AC Delay
Fig. 1a
Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing.
AL600UL3/AL600UL3X - 3 -
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

             
       
                  
               
 
      
Maintenance:
Unit should be tested at least once ayear for the proper operation as follows:
Output Voltage Test: Under normal load conditions the DC output voltage should be checked for proper voltage level
(see Terminal Identification Tables).
Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage at the
battery terminals and at the board terminals marked [+ BAT -- ] to ensure that there is no break in the battery
connection wires.
Note: Maximum charge current under discharge is 0.7 amp.
Note: Expected battery life is 5years; however, it is recommended changing batteries in 4years or less if necessary.
LED Diagnostics:
AL600ULXB - Power Supply/Charger
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC. Stand-by battery supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
Red (Bat) Battery Status
ON Normal operating condition.
OFF Battery fail/low battery.
Terminal Identification:
AL600ULXB - Power Supply/Charger
Terminal Legend Function/Description
L, G, N 115VAC 60 Hz
+DC – 24VDC @ 6 amp total continuous non power-limited output (supplies power to ALX3B).
AC Fail
NC, C, NO
Indicates loss of AC power, e.g. connect to audible device or alarm panel. Relay normally energized
when AC power is present. Contact rating 1 amp @ 28VDC.
Bat Fail
NC, C, NO
Indicates low battery condition, e.g. no battery presence. Relay normally energized when DC power
is present. Contact rating 1amp @28VDC. Low battery threshold: 24VDC output threshold is set
approximately @21VDC
+BAT – Stand-by battery connections. Maximum charge current 0.7 amp.
AL3XB - Power Output Module
Terminal Legend Function/Description
-- INPUT + 24VDC from power supply (AL600ULXB)
+ 24VDC -- 24VDC @ 3 amp continuous non power-limited output
+ 12VDC -- 12VDC @ 1.75 amp continuous power-limited output.
+ 5VDC -- 5VDC @ 1.75 amp continuous power-limited output.
- 4 - AL600UL3/AL600UL3X
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

Appendix A - UL Listed Compatible Devices
A.1 Four (4) Wire Smoke Detectors
Table A-1 below lists four (4) wire smoke detectors compatible with AL600UL3/AL600UL3X output.
System Sensor
Smoke Detector/Base Detector Type Max Stand-by
Current (mA)
Alarm Current
(mA)
B112LP Base 0.12 36
B114LP Base * *
B404B Base * *
DH100ACDC Photoelectric 0.15 0.70
DH100ACDCLP Photoelectric 0.15 0.70
DH100ACDCLPW Photoelectric 0.15 0.70
DH400ACDCI Ionization Duct 25 95
DH400ACDCP Photoelectric Duct 25 95
1112/24/D Ionization 0.05 50
1424 Ionization 0.10 41
1451 (w/B402B Base) Ionization 0.10 39
2112/24ATR Photoelectric 0.50 60/70
2112/24AITR Photoelectric 0.50 60/70
2112/24/D Photoelectric 0.05 50
2112/24T/D Photoelectric w/135o Thermal 0.05 50
2112/24TSRB Photoelectric w/135o Thermal Supervisory Relay 15 45
2312/24TB Photoelectric 0.12 50
2412 (12 volt) Photoelectric 0.12 77
2424 Photoelectric 0.10 41
2451 Photoelectric 0.10 39
2451TH (with/B402B Base) Photoelectric 0.10 39
2W-MOD Loop Test/Maintenance Mod. 30 50
4W-B (12/24 volt) Photoelectric I3 .05 23
4WT-B (12/24 volt) Photoelectric I3w/Therm .05 23
4WTA-B (12/24 volt) I3 Photo w/Therm/Sounder .05 35
4WTR-B (12/24 volt) I3 Photo w/Therm/Relay .05 35
4WITAR-B (12/24 volt) I3 Photo w/Isolated Therm/Sounder/Relay .05 50
2W-MOD2 I3 Loop Test/Maintenance Mod. .05 *
RRS-MOD I3 Reversing Relay/Sync Module .05 *
6424 Projected Beam 10 28.4
Beam 1224(S) Projected Beam 17 38.5
* Contact manufacturer for current draws.
A.2 Relays
Table A-2 below lists relays compatible with AL600UL3/AL600UL3X output.
Manufacturer Model
System Sensor
PR-1
PR-2
PR-3
EOLR-1
R-10T
R-14T
Current (mA)
15
30
30
30
23
23
Manufacturer
System Sensor
Model
R-20T
R-24T
R-10E
R-14E
R-20E
R-24E
Current (mA)
40
40
23
23
40
40
AL600UL3/AL600UL3X - 5 -
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

Notes:
- 6 - AL600UL3/AL600UL3X
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

        
Enclosure Dimensions (BC300):
AL600UL3
13.5” x13” x3.25” (342.9mm x330.2mm x82.55mm)
1.40”
(36mm)
1.40”
(36mm)
4.85”
(123mm)
4.85”
(123mm)
1.40”
(36mm)
1.40”
(36mm)
5.10”
(130mm)
5.10”
(130mm)
13.0”
(330mm)
5.10”
(130mm)
6.5625”
(167mm)
1.20”
(31mm)
1.20”
(31mm) 1.20”
(31mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
1.0”
(25mm)
1.0”
10.5”
1.0”
1.0”
(25mm)
0.75”
(19mm)
0.75”
(19mm)
0.9375”
(24mm)
0.9375”
(24mm)
11.0”
(279mm)
12.5”
(318mm)
(
25mm
) (
267mm
) (
25mm
)
AL600UL3/AL600UL3X - 7 -
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

       
         
        
        
Enclosure Dimensions (BC400):
AL600UL3X
15.5” x12” x4.5” (393.7mm x304.8mm x114.3mm)
5.0”
(127.0mm)
2.0”
(50.8mm)
2.0”
(50.8mm)
1.5”
(38.1mm) 1.5” (38.1mm)
1.5”
(38.1mm)
5.0”
(127.0mm)
1.5”
(38.1mm)
1.75”
(44.45mm)
1.75”
(44.45mm)
4.5”
(114.3mm)
1.25”
(31.75mm)
4.5”
(114.3mm) 1.25”
(31.75mm)
1.25”
(31.75mm)(31.75mm)
1.1”
(27.94mm)
1.1”
(27.94mm)
0.79”
(20.06mm)
1.1”
(27.94mm)
0.91”
(23.114mm)
0.91”
(23.114mm)
1.375”
(34.925mm)
1.125”
(28.575mm)
15.5”
(393.7mm)
4.615”
(117.22mm)
12.23”
(310.64mm)
4.615”
(117.22mm)
1.5” 1.5”
4.615” 4.615”
1.25”
(38.1mm) (117.22mm) (117.22mm) (38.1mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
web site: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IIAL600UL3/AL600UL3X B19N MEMBER
- 8 - AL600UL3/AL600UL3X
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
