AmeriGlide RAVE User manual

Owner’s Manual and Warranty Information
IMPORTANT! YOU MUST READ AND UNDERSTAND THISENTIRE MANUAL BE READ AND UNDERSTOODBEFORE ATTEMPTING TO
OPERATE THIS LIFT. IF THERE ISANYTHING IN THISMANUAL YOU DO NOT CLEARLY UNDERSTAND, CONTACT YOUR DEALER FOR
CLARIFICATION, OR CALL AMERIGLIDE TOLL FREE AT 1-866-294-4460 BEFORE YOU OPERATE THIS LIFT.
RAVE STAIR LIFT

Rave Stair Lift Manual | | www.Ameriglide.com | 1-866-294-4460
2
Table of Contents
AmeriGlide, is proud to extend our world-class line of stair lifts with the Rave series. Engineered for ease of use
and years of trouble-free operation, Rave is built in the USA and supported by a staff with extensive industry
experience in accessibility equipment.
This Owner’s Manual should be read and understood in its entirety prior to attempting to operate the equipment.
All operating procedures must be followed in order to avoid possible injury and/or property damage.
CONTENTS
Introduction and Dealer Information .......... 3
Operation and Description of Features........ 4
Important Operating Notes ........................... 6
Maintenance..................................................... 7
Troubleshooting............................................... 7
Limited Warranty ............................................ 8
GENERAL SPECIFICATIONS
Application: Indoor, straight run stairways
Track Length: 32 feet (max)
Rated Load: Seat: 350 lbs (135 kg)
Rated Speed: 19 ft. per minute
Power Supply: 115 VAC, 60 Hz, 3-Wire Grounded Outlet
Motor: 24 VDC
Drive System: Rack and pinion
Track: Extruded aluminum
Angle of Incline: 25° to 50°
IMPORTANT
SERIAL NUMBER of your stair lift is:_______________________________
This serial number contains important information about your lift and may be needed if the lift requires replacement parts. Please keep it accessible.

Rave Stair Lift Manual | |www.Ameriglide.com|1-866-294-4460 3
Introduction and Dealer Information
INTRODUCTION
Your new Rave stairlift will help you enjoy independent living by adding safety, peace of mind and convenience
to your home.
In order to achieve the maximum functionality your lift offers, it is essential that you readthis Owner's
Manual carefullyand understand its contents prior to using your lift. This Owner's Manual has been
prepared to provide clear, concise operating and maintenance instructions.
AmeriGlide uses special precision and care to engineerand manufacture easy, trouble-free equipment that
operate dependably for years. However, as with all electrical and mechanical equipment, proper operation
and periodic maintenance is required.
Please note that only authorized AmeriGlide dealers, who are committed to providing qualityservice,
have technicians whohave been trained to install, maintain and repair AmeriGlide lifts. Damages caused
by non-AmeriGlide authorized technicians or non-genuine replacement parts will not be covered under your
Limited Warranty.
DEALER INFORMATION
Name: _______________________________________________________________
Address:______________________________________________________________
_____________________________________________________________________
Telephone Number: ____________________________________________________
Email:________________________________________________________________
If you have questions concerning the operation or maintenance of your stair lift, please contact your dealer.

Rave Stair Lift Manual | |www.Ameriglide.com|1-866-294-4460
4
Operation and Description of Features
OPERATION AND DESCRIPTION OF FEATURES
To avoid causing damage to your stair lift or other property, and to avoid personal injury, you should become
familiar with the locationand function of the features included on your lift before using it. It is particularly
important that you familiarize yourself with the safety devices described below.
OPERATING CONTROL: A constant pressure rocker switch is located on the arm rest. The rocker switch must
be toggled to move the lift. The lift stops any time the rocker switch is released. The lift automaticallystops at
the ends of the track. During normal operation, press and hold the rocker switch in the proper direction until
the stair lift stops itself.
WIRELESS REMOTE CONTROLS: There are two wireless remote controls included with your lift, one for the top
of the stairway and one for the bottom. To operate the wireless remote controls, press and holdone of the
buttons (one button is up and one is down). When abutton is pressed, the lift will begin to move after ahalf-
second delay.
Operating control
Swivel seat lever
Folding footrest
On / Off Power Switch
Folding seat
Folding armrest
(included on some
models)

Rave Stair Lift Manual | |www.Ameriglide.com|1-866-294-4460 5
Operation and Description of Features
FOLDING SEAT AND ARMREST (included as an option on some models): Seat and
armrest folds up to provide more stairway room when the lift is not in use.
FOLDING FOOTREST: The footrest can befolded up and out of the way when the lift is
not in use. Thefootrest must be in the down position when riding the lift. Sensors are
provided in the footrest to detect obstructions. When an obstructionis encountered, the
lift will stop. The obstruction must be removed in order for the lift to operate.
SWIVEL SEAT: The swivel seat lever is provided on both sides of the seat, allowing the seat to be
swiveled 70° and 90° at boththe upper and lower landings. To operate the swivel, raise the lever.
Ensure that the swivel seat locks into position before sitting down or getting off. A safetysensoron
the swivel seat prohibits the lift from being used when the seat is not locked in the riding position.
SAFETY BELT: The safety belt must be securely fastened around waist or chest before operating the lift.
FINAL LIMIT SWITCH: In the unlikely event that the lift would over-travel its normal stopping
inoperable. A service technician must check the lift to put it back into service.
