Adjustment Manual
Advanced Signal Calibrator
ASC-400

Adjustment Manual
Advanced Signal Calibrator
JOFRA ASC-400
Copyright 2014 AMETEK Denmark A/S

128897 02 2014-12-05 2
List of contents
1.0Overview....................................................................................................................................3
2.0Initiating Communication ........................................................................................................4
3.0Adjusting and calibrating the ASC-400 ..................................................................................5
4.0Test equipment.........................................................................................................................5
5.0ASC-400 Adjustment procedures ...........................................................................................6
5.1Adjusting Isolated current (mA) Input:.............................................................................................. 6
5.2Adjusting Isolated voltage Input:......................................................................................................6
5.3Adjusting current (mA) Input: ...........................................................................................................6
5.5Adjusting Voltage input: ...................................................................................................................7
5.6Adjusting Voltage Output: ................................................................................................................7
5.7Adjusting Low Resistance Output:...................................................................................................8
5.8Adjusting High Resistance Output:..................................................................................................8
5.9Adjusting Resistance input:..............................................................................................................8
5.10Adjusting Thermocouple (mV) Output:............................................................................................. 9
5.11Adjusting Thermocouple (mV) input:................................................................................................ 9
5.12Adjusting Thermocouple CJC:.........................................................................................................9
5.13Barometric reading (ASC-400-1 only):...........................................................................................10
5.14System Calibration Date: ...............................................................................................................10
5.15Barometric Pressure Calibration Date: ..........................................................................................10
6.0Exiting calibration procedures..............................................................................................11

128897 02 2014-12-05 3
1.0 Overview
The ASC-400 Advanced Signal Calibrator has a built in adjustment function for
readjustment of the calibrator. This adjustment function is based on a simple ASCII protocol,
and you can get access to that function by the USB interface.
You can use a terminal program like HyperTerminal by accessing the instrument via the USB
interface, or you can develop your own dedicated adjustment program in Visual Basic,
Labview, etc.
There is no front panel adjustment available on the ASC-400.
In this manual only the terminal mode will be described.

128897 02 2014-12-05 4
2.0 Initiating Communication
Before you can initiate the Communication needed for a readjustment, you have to install a
USB-driver. You can find the USB-driver on the memory stick which was included together
with the instrument. The driver will be located in the subfolder: utilities.
To install the driver you have to connect the instrument to your computer and then turn on
the calibrator. After a while the computer will ask for a driver and you have to locate the
driver on the USB-stick in the subfolder utilities.
When the driver is installed you will get a virtual COMPORT named AMETEK Advanced
Signal Calibrator. Start up your preferred terminal program and locate this Virtual
COMPORT in the terminal setup. Now you are ready to recalibrate the instrument.
As long as the calibrator has been within at a stable temperature within the range of 18°C
to 28°C for an hour or more, the calibrator only needs 5 minutes to warm up. If
temperature conditions were previously below 10°C or higher then 40°C, then the unit
must be allowed to stabilize for a minimum of 3 hours prior to adjustment. To initiate the
calibration mode use the terminal to send the CAL_START command. The following will be
displayed on the terminal.
Calibration is password protected Enter Password:
The password is 900. Enter the password correctly and the following will be displayed on the
terminal.
Calibration Menu
0: Exit
1: ISO Current Input (mA)
2: ISO Voltage Input (volts)
3: Current Input (mA)
4: Current Output (mA)
5: Voltage Input (volts)
6: Voltage Output (volts)
7: Low Resistance Source (ohms)
8: High Resistance Source (ohms)
9: Resistance Measure (ohms)
10: Thermocouple Output (mV)
11: Thermocouple Input (mV)
12: Thermocouple CJC
13: Barometric Pressure
14: System Calibration Date
15: Barometric Pressure Calibration Date
Enter Selection:

128897 02 2014-12-05 5
3.0 Adjusting and calibrating the ASC-400
You should recalibrate the ASC-400 at the required calibration interval (defined by the
factory as 1 year) and adjust if necessary.
Adjustment of the ASC-400 is a menu driven process. It consists of 15 different menu selec-
tions for calibration of the different functions. The only requirement being that mV must be
adjustment before CJC.
Once a particular adjustment menu selection has been made the user is prompted to either
input a signal into the ASC-400 or enter the output value of a signal from the ASC-400.
When inputting signals into the ASC-400, the readings are taken after the {enter} key is
pressed and before the next prompt. Make sure the input to the ASC-400 is stable before the
{enter} key is pressed and remains stable until the next prompt appears.
When entering the outputted value of a signal, make sure that value is stable before you enter
it; there is no backspace.
4.0 Test equipment
Recommended test equipment is listed in the table below. Equipment with similar or better
specifications can be used if the listed equipment is not available.
Equipment Manufacturer Model Quantity Purpose
Digital Multimeter Fluke 8508A 1 All functions
except CJC and
ohm measure.
Calibrator Fluke 5520A 1 All source
functions and
CJC.
Low thermal EMF
banana to banana
leads (red).
Multi Contact 28.0074-100-22 2 All functions
except mV and
CJC.
Low thermal EMF
banana to banana
leads (black).
Multi Contact 28.0074-100-21 2 All functions
except mV and
CJC.
TC – banana
cable 1 mV source and measure.
Thermocouple
type J TC – TC
cable.
1 CJC.
Tube for
barometric
reference.
1 Barometric
reference.
For the barometric reference in ASC-400-1, a barometric reference with an accuracy of 0.125
mbar or better is required.

128897 02 2014-12-05 6
5.0 ASC-400 Adjustment procedures
5.1 Adjusting Isolated current (mA) Input:
1. Connect Calibrator mA output to Digital Multimeter mA input and to ASC-400
Isolated mA measure terminals.
2. Type “1” in the Calibration menu.
Prompt = “Input 0 mA to ASC400 - Press <enter> when stable”
3. Apply 0.000 mA (Digital Multimeter reading) to the input and press “enter”
when stable.
Prompt = “Input 24 mA to ASC400 - Press <enter> when stable”
4. Apply 24.000 mA (Digital Mulimeter reading) to the input and press “enter”
when stable. ASC-400 now returns to the Calibration menu.
5.2 Adjusting Isolated voltage Input:
1. Connect Calibrator V output to Digital Multimeter V input and to ASC-400
Isolated V measure terminals.
2. Type “2” in the Calibration menu.
Prompt = “Input 0 Volt to ASC400 - Press <enter> when stable”
3. Apply 0.000 V (Digital Multimeter reading) to the input and press “enter” when
stable.
Prompt = “Input 30 Volt to ASC400 - Press <enter> when stable”
4. Apply 30.000 V (Digital Multimeter reading) to the input and press “enter”
when stable. ASC-400 now returns to the Calibration menu.
5.3 Adjusting current (mA) Input:
1. Connect Calibrator mA output to Digital Multimeter mA input and ASC-400 mA
measure terminals.
2. Type “3” in the Calibration menu.
Prompt = “Input 0 mA to ASC400 - Press <enter> when stable”
3. Apply 0.000 mA (Digital Multimeter reading) to the input and press “enter”
when stable.
Prompt = “Input 24 mA to ASC400 - Press <enter> when stable”
4. Apply 24.000 mA (Digital Multimeter reading) to the input and press “enter”
when stable. ASC-400 now returns to the Calibration menu.

128897 02 2014-12-05 7
5.4 Adjusting current (mA) Output:
1. Connect Digital Multimeter mA input to ASC-400 mA source terminals.
2. Type “4” in the Calibration menu.
Prompt = “First calibration point. Enter mA output:”
3. Enter multimeter read value when stable (example: 0.0000) and press “enter”.
Prompt = “Second calibration point. Enter mA output:”
4. Enter multimeter read value when stable (example: 24.0000) and press “enter”.
ASC-400 now returns to the Calibration menu.
5.5 Adjusting Voltage input:
1. Connect Calibrator V output to Digital Multimeter V input and ASC-400 V
measure terminals.
2. Type “5” in the Calibration menu.
Prompt = “Input 0 volt to ASC400 - Press <enter> when stable”
3. Apply 0.000 V (Digital Multimeter reading) to the input and press “enter” when
stable.
Prompt = “Input 20 volt to ASC400 - Press <enter> when stable”
4. Apply 20.000 V (Digital Multimeter reading) to the input and press “enter”
when stable. ASC-400 now returns to the Calibration menu.
5.6 Adjusting Voltage Output:
1. Connect Digital Multimeter V input to ASC-400 V source terminals.
2. Type “6” in the Calibration menu.
3. Follow the menu prompts.
Prompt = “First calibration point. Enter V output:”
4. Enter multimeter read value when stable (example: 0.0000) and press “enter”.
Prompt = “Second calibration point. Enter V output:”
5. Enter multimeter read value when stable (example: 20.0000) and press “enter”.
ASC-400 now returns to the Calibration menu.

128897 02 2014-12-05 8
5.7 Adjusting Low Resistance Output:
1. Connect Digital Multimeter ohm input (4-wire) to ASC-400 Ohms source
terminals.
2. Set up Digital Multimeter for True ohm mode, 1 mA ( 3 mA max.) excitation
current.
3. Type “7” in the Calibration menu.
Prompt = “First calibration point. Enter ohms output:”
4. Enter multimeter read value when stable (example: 5.000) and press “enter”.
Prompt = “Second calibration point. Enter ohms output:”
5. Enter multimeter read value when stable (example: 400.000) and press “enter”.
ASC-400 now returns to the Calibration menu.
5.8 Adjusting High Resistance Output:
1. Connect Digital Multimeter ohm input (4-wire) to ASC-400 Ohms source
terminals.
2. Set up Digital Multimeter for True ohm mode, 0.1 mA (0.3 mA max.) excitation
current.
3. Type “8” in the Calibration menu.
Prompt = “First calibration point. Enter ohms output:”
4. Enter multimeter read value when stable (example: 400.00) and press “enter”.
Prompt = “Second calibration point. Enter ohms output:”
5. Enter multimeter read value when stable (example: 4000.00) and press “enter”.
ASC-400 now returns to the Calibration menu.
5.9 Adjusting Resistance input:
1. Connect Calibrator to ASC-400 Ohms measure terminals using 4-wire
connection.
2. Set up Calibrator for 4-wire connection.
3. Type “9” in the Calibration menu.
Prompt = “Input 15 ohm to ASC400 - Press <enter> when stable”
4. Apply 15.00 ohm to the input and press “enter” when stable.
Prompt = “Input 400 ohm to ASC400 - Press <enter> when stable”
5. Apply 400.00 ohm to the input and press “enter” when stable.
Prompt = “Input 4000 ohm to ASC400 - Press <enter> when stable”
6. Apply 4000.0 ohm to the input and press “enter” when stable. ASC-400 now
returns to the Calibration menu.

128897 02 2014-12-05 9
5.10 Adjusting Thermocouple (mV) Output:
1. Connect Digital Multimeter V input to ASC-400 mV source terminals (use TC to
banana cable).
2. Type “10” in the Calibration menu.
3. Follow the menu prompts.
Prompt = “First calibration point. Enter mV output:”
4. Enter multimeter read value when stable (example: -10.0000) and press
“enter”.
Prompt = “Second calibration point. Enter mV output:”
5. Enter multimeter read value when stable (example: 75.0000) and press “enter”.
ASC-400 now returns to the Calibration menu.
5.11 Adjusting Thermocouple (mV) input:
1. Connect Calibrator V output to Digital Multimeter V input and ASC-400 mV
measure terminals (use TC to banana cable).
2. Type “11” in the Calibration menu.
Prompt = “Input 0 mV to ASC400 - Press <enter> when stable”
3. Apply 0.000 mV (Digital Multimeter reading) to the input and press “enter”
when stable.
Prompt = “Input 75 mV to ASC400 - Press <enter> when stable”
4. Apply 75.000 mV (Digital Multimeter reading) to the input and press “enter”
when stable.
5.12 Adjusting Thermocouple CJC:
1. Connect Calibrator TC output to ASC-400 TC measure terminals (use
Thermocouple type J cable).
2. Type “12” in the Calibration menu.
Prompt = “Input a type J thermocouple at 0.0 degrees C - Press <enter> when
stable”
3. Apply 0°C to the input and press “enter” when stable (wait minimum 5
minutes).

128897 02 2014-12-05 10
5.13 Barometric reading (ASC-400-1 only):
1. Connect a Barometric reference source to ASC-400 barometric sensor using a
tube (5 mm inner diameter / 8 mm outer diameter). ASC-400 barometric sensor
is located below the batteries underneath a “Calibration void” label.
2. Type “13” in the Calibration menu.
Prompt = “Apply 0.95 bar absolute - Press <enter> when stable”
3. Apply 0.95 bar absolute to the ASC-400 and press “enter” when stable.
Prompt = “Apply 1.05 bar absolute - Press <enter> when stable”
4. Apply 1.05 bar absolute to the ASC-400 and press “enter” when stable. ASC-
400 now returns to the Calibration menu.
5. Apply a new “Calibration void” label over the ASC-400 barometric sensor after
calibration.
5.14 System Calibration Date:
1. Type “14” in the Calibration menu.
2. Follow the menu prompts.
Prompt = “Calibration Date: 2014 9 5 13 1 24”
Prompt = “Enter new date <year> <month> <day> <hour> <minute> <second>:”
Example: 2014 09 05 13 55 14
5.15 Barometric Pressure Calibration Date:
1. Type “15” in the Calibration menu.
2. Follow the menu prompts.
Prompt = “Calibration Date: 2014 9 5 13 1 24”
Prompt = “Enter new date <year> <month> <day> <hour> <minute> <second>:”
Example: 2014 09 05 13 55 14


128897 02 2014-12-05 11
6.0 Exiting calibration procedures
When you are finish with the adjustment type 0to exit the calibration menu.
Calibration Menu
0: Exit
1: ISO Current Input (mA)
2: ISO Voltage Input (volts)
3: Current Input (mA)
4: Current Output (mA)
5: Voltage Input (volts)
6: Voltage Output (volts)
7: Low Resistance Source (ohms)
8: High Resistance Source (ohms)
9: Resistance Measure (ohms)
10: Thermocouple Output (mV)
11: Thermocouple Input (mV)
12: Thermocouple CJC
13: Barometric Pressure
14: System Calibration Date
15: Barometric Pressure Calibration Date
Enter Selection:
Note…
Adjustment Verification:
This procedure does not cover the verification of the unit. As a rule of thumb the
unit should never use up more than 50% of its specifications immediately after
adjustment. Also the person adjusting the ASC-400 can exit and enter calibration
mode at will, while doing the verification as they go.

AMETEK Test & Calibration Instruments
A business unit of AMETEK Measurement &
Calibration Technologies Division offering the
following industry leading brands for test and
calibration instrumentation.
JOFRA Calibration Instruments
Temperature Calibrators
Portable dry-block calibrators, precision
thermometers and liquid baths. Temperature
sensors for industrial and marine use.
Pressure Calibrators
Convenient electronic systems ranging from
-25 mbar to 1000 bar - fully temperature-
compensated for problem-free and accurate
field use.
Signal Instruments
Process signal measurement and simulation for
easy control loop calibration and measurement
tasks.
M&G Dead Weight Testers & Pumps
Pneumatic floating-ball or hydraulic piston dead
weight testers with accuracies to 0.015% of
reading. Pressure generators delivering up to
1,000 bar.
Crystal Pressure
Digital pressure gauges and calibrators that are
accurate, easy-to-use and reliable. Designed for
use in the harshest environments; most products
carry an IS, IP67 and DNV rating.
Lloyd Materials Testing
Materials testing machines and software that
guarantees expert materials testing solutions.
Also covering Texture Analysers to perform
rapid, general food testing and detailed texture
analysis on a diverse range of foods and
cosmetics.
Davenport Polymer Test Equipment
Allows measurement and characterization of
moisture-sensitive PET polymers and polymer
density.
Chatillon Force Measurement
The hand held force gauges and motorized
testers have earned their reputation for quality,
reliability and accuracy and they represent the
de facto standard for force measurement.
Newage Hardness Testing
Hardness testers, durometers, optical systems
and software for data acquisition and analysis.
Information in this document is subject to change without notice. ©2014, by AMETEK, Inc., www.ametek.com. All rights reserved.
www.ametekcalibration.com
United Kingdom
Tel [phone]
[email protected]
France
Tel [phone]
[email protected]
Germany
Tel [phone]
[email protected]
Denmark
Tel [phone]
[email protected]
USA
Florida
Tel [phone]
[email protected]
California
Tel [phone]
[email protected]
India
Tel [phone]
[email protected]
Singapore
Tel [phone]
[email protected]
China
Shanghai
Tel [phone]
Beijing
Tel [phone]
Guangzhou
Tel [phone]
[email protected]
