Ametek OCS 500N6 Series Instruction Manual

M a n u a l
F o r O p e r a t i o n
OCS 500N6 series
OCS 500N6F series
The Damped Oscillatory and
Ring Wave generator in one box
OCS 500N6x series - designed as a modular system - is the
most intelligent solution offering exactly what you need for full-
compliant immunity tests against damped oscillatory and ring
wave phenomena. The distinct operation features, convenient
DUT connection facilities, a clearly arranged menu structure and
display philosophy as well as the pre-programmed standard test
routines make testing easy, reliable and safe. Extendable by a
variety of test accessories the OCS 500N6 is universal
equipment for abroad range of recommendations even for three-
phase applications up to 100A.
ANSI /IEEE C62.41
ANSI /IEEE C37.90
EN/IEC 61000-4-10
EN/IEC 61000-4-12
EN/IEC 61000-4-18
IEC 60255-1
Version:
5. 24 / 17.03.2021
The benchmark for emc
Replaces:
5. 23 / 13.12.2018
File name
UserManual-OCS500N6-E-V5.24.doc
Print Date
17.03.21

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 2 / 80
AMETEK CTS GmbH
Sternenhofstrasse 15
4153 Reinach BL1
Switzerland
Phone: [phone]
Fax: [phone]
URL : http://www.ametek-cts.com
Copyright © 2021 AMETEK CTS GmbH All right reserved.
Specifications subject to change

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 3 / 80
Contents
1. General.............................................................................................................................5
1.1. Purpose ..............................................................................................................................................5
1.2. Safety label on the device ..................................................................................................................5
1.3. Standards covered by OCS 500N6 / N6F generators........................................................................6
1.4. Models and options ............................................................................................................................6
1.5. Special Models ...................................................................................................................................7
2. Operating Functions .......................................................................................................8
2.1. OCS 500N6.x models.........................................................................................................................8
2.1.1. Front view OCS 500N6.x....................................................................................................................8
2.1.2. Rear view OCS 500N6.x ..................................................................................................................10
2.2. OCS 500N6F models .......................................................................................................................12
2.2.1. Front view OCS 500N6F.x................................................................................................................12
2.2.2. Rear view OCS 500N6F.x................................................................................................................14
3. Operation .......................................................................................................................16
3.1. Description of the menus..................................................................................................................16
3.2. Menu structure..................................................................................................................................17
3.3. Main Menu OCS 500N6.x.................................................................................................................18
3.4. Main Menu OCS 500N6F.x ..............................................................................................................19
3.5. Phase synchronization in 3-phase system.......................................................................................20
3.6. Service..............................................................................................................................................21
3.7. Setup ................................................................................................................................................23
4. Test Equipment OCS 500 Nx ........................................................................................24
4.1. Assembling OCS 500N6...................................................................................................................24
4.2. Assembling OCS 500N6Fx...............................................................................................................25
5. Technical data ...............................................................................................................26
5.1. Slow damped oscillatory as per IEC 61000-4-18 ..............................................................................26
5.2. Fast damped oscillatory as per IEC 61000-4-18...............................................................................28
5.3.RINGWAVE Immunity requirements as per ANSI C 62.41 (IEC 61000-4-12).................................29
5.4. General Specifications OCS 500N6.x ..............................................................................................30
5.5. General Specifications OCS 500N6F.x............................................................................................31
6. Damped Oscillatory 100 kHz or 1 MHz as per IEC 61000-4-18...................................32
6.1. Operation..........................................................................................................................................32
6.1.1. Quick start.........................................................................................................................................33
6.1.2. Standard test routines ......................................................................................................................34
6.1.3.User Test Routines...........................................................................................................................36
6.2. Coupling decoupling network ...........................................................................................................37
6.2.1. Coupling/decoupling network for ac/dc power lines.........................................................................37
6.2.2. Coupling to Signal- and Datalines....................................................................................................38
6.2.3. Ri setting for slow damped oscillatory wave 100 Ω or 200 Ω...........................................................39
6.3. Menu Damped Osc. 1MHz EXT.......................................................................................................40
6.3.1. Coupling as per IEC 60255 with CNV 508 N4..................................................................................40
6.3.2. Quick start.........................................................................................................................................41
6.3.3. Standard test routines ......................................................................................................................41
6.3.4. User Test Routines...........................................................................................................................43
7. Fast Damped Oscillatory 3 MHz, 10 MHz or 30 MHz as per IEC 61000-4-18.............44
7.1. Operation..........................................................................................................................................44
7.1.1. Quick start.........................................................................................................................................45
7.1.2. Standard test routines ......................................................................................................................46
7.1.3. User Test Routines...........................................................................................................................48
7.2. Coupling decoupling network ...........................................................................................................49
7.2.1. Coupling/decoupling network for ac/dc power lines.........................................................................49
7.2.2. Coupling to Signal and Datalines .....................................................................................................49

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 4 / 80
8. Ring Wave......................................................................................................................50
8.1. Operation..........................................................................................................................................50
8.1.1. Quick Start........................................................................................................................................51
8.1.2. Standard test Routine.......................................................................................................................52
8.1.3. User Test Routines...........................................................................................................................55
8.2. Ringwave and damped oscillatory pulse generation........................................................................56
8.3. Coupling decoupling network ...........................................................................................................57
8.3.1. Coupling to ac / dc power supply lines.............................................................................................57
8.3.2. Coupling to Signal- and Datalines....................................................................................................58
8.4. Test set-up........................................................................................................................................59
9. Damped Oscillatory Magnetic Field as per IEC 61000-4-10.......................................60
9.1. General.............................................................................................................................................60
9.2. Menu Damped Osc. Wave 1 MHz magnetic field (MF)....................................................................61
10. Maintenance...................................................................................................................62
10.1. General.............................................................................................................................................62
10.1.1. Test set- up.......................................................................................................................................62
10.2. Calibration and Verification...............................................................................................................63
10.2.1. Factory calibration ............................................................................................................................63
10.2.2. Guideline to determine the calibration period of AMETEK CTS instrumentation.............................63
10.2.3. Calibration of Accessories made by passive components only .......................................................63
10.2.4. Periodically In-house verification......................................................................................................63
10.3. Verification Ringwave.......................................................................................................................64
10.3.1. Verification Parameter......................................................................................................................64
10.4. Verification Damped Oscillatory Wave.............................................................................................65
10.4.1. Verification Parameter slow damped oscillatory wave.....................................................................65
10.4.2. Verification Setup .............................................................................................................................66
10.4.3. Verification Parameter fast damped oscillatory wave ......................................................................67
10.5. Verification Damped Oscillatory Wave 100 / 1000 kHz magnetic field ............................................71
10.5.1. Verification Parameter......................................................................................................................71
11. Delivery Groups.............................................................................................................72
11.1. Basic equipment...............................................................................................................................72
11.2. Accessories and options...................................................................................................................72
11.3. USB Interface ...................................................................................................................................74
11.4. Optical Interface ...............................................................................................................................74
12. Appendix........................................................................................................................75
12.1. Declaration of CE-Conformity...........................................................................................................75
12.2. OCS 500 N6- General Diagram........................................................................................................77
12.3. OCS 500 N6F- General Diagram 1-phase devices..........................................................................78
12.4. OCS 500 N6F- General Diagram 3-phase devices..........................................................................79
12.5. OCS 500N6 1-phase operating with 3-phase devices .....................................................................80

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 5 / 80
1.
General
1.1.
Purpose
The compact OCS 500Nx generator is a multifunction compact generator that simulates conducted
electromagnetic interference effects for immunity testing to international, national, and manufacturers’standards.
The system is designed for full compliance conducted electromagnetic compatibility (EMC) test requirements.
The application range is for testing of industrial, light industrial, household or commercial equipment, including
many product family and product standards as per following basic standards
Only qualified personnel who deal with attendant hazards in impulse generators, are allowed to perform
installation and servicing. Before put in service the attached safety and user manual must be readed and applied.
The Safety and user manual are an essential part of the equipment and must be available to the operator at all
times. The user must obey all safety instructions and warnings.
It is the user’s responsibility to ensure that the test rig does not emit excessive electromagnetic interference (EMI)
that might affect other equipment. The test system itself does not produce any excessive radiation; however, the
injection of interference pulses into the EUT can result in the device and/or its associated cables radiating EMI.
To avoid radiating unwanted interference the standards organizations recommend that the test setup be located
in a Faraday cage.
1.2.
Safety label on the device
Please take note of the following explanations of the symbols used in order to achieve the optimum benefit from
this manual and to ensure safety during operation of the equipment.
This symbol warns of a potential risk of shock hazard. The symbol on the instrument
shows, that that it can source 1000 volt or more, including the combined effect of
normal and common mode voltages. Use standard safety precautions to avoid
personal contact with these voltages.
This symbol indicates where a caution is required. Refer to the operating instructions
located in the manual in order to protect against personal injury or damage the
equipment
CAUTION
The CAUTION symbol indicates a potential hazard. It calls attention to a procedure,
practice or condition which, if not followed, could possibly cause damage to equipment.
Such damage may invalidate the warranty. If a CAUTION is indicated, do not proceed
until its conditions are fully understood and met.
WARNING
The WARNING symbol indicates a potential hazard. It calls attention to a procedure,
practice or condition which, if not followed, could possibly cause bodily injured or
death. If a WARNING is indicated, do not proceed until its conditions are fully
understood and met.
Attention
Before using this equipment, read the operating manual and the
separate delivered safety manual carefully

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 6 / 80
1.3.
Standards covered by OCS 500N6 / N6F generators
Fully equipped OCS 500N6 / N6F generators cover the following standards
- IEC 61000-4-10
Oscillatory Magnetic Field test
- IEC 61000-4-12
- ANSI-IEEE C62.41.2
- ANSI-IEEE C62.45
Ring wave immunity test
- IEC 61000-4-18
Oscillatory waves immunity test
Slow damped oscillatory wave (100 kHz or 1 MHz)
Fast damped oscillatory wave (3, 10, 30 MHz) OCS500N6F only
- IEC 60255-26
Measuring relays and protection equipment
- 1 MHz burst immunity tests
1.4.
Models and options
This manual is for the written for the following device model and options:
Device:
Unit for damped waves as per IEC 61000-4-12 / -18 and ANSI C62-41:
- incl. damped oscillatory waves 100 kHz and 1 MHz
- incl. Ring Wave 100 kHz
Model
name till 2008
coupling network
AC voltage
DC voltage
OCS 500 N6
OCS 500 M6
1-phase
250 V / 16 A
250 V / 10 A
OCS 500 N6.2
OCS 500 M6S2
1-phase
250 V / 32 A
250 V / 20 A
OCS 500 N6.3
OCS 500 M6S3
3-phases
3x400 V / 16 A
250 V / 10 A
OCS 500 N6.4
OCS 500 M6S4
3-phases
3x400 V / 32 A
250 V / 20 A
OCS 500 M6S5
3-phases
3x400 V /100 A
250 V / 20 A
OCS 500 M6-690V
1-phase
690 V / 32 A
250 V / 20 A
OCS 500 M6S8
3-phases
3x440 V /100 A
250 V / 20 A
OCS500 N6.11
3-phases
3x690 V /32 A
250 V / 32 A
OCS500N6F
1-phases
250 V / 16 A
250 V / 16 A
OCS500N6F.1
1-phases
250 V / 32 A
250 V / 32 A
OCS500N6F.2
3-phases
3x440 V / 16 A
250 V / 16 A
OCS500N6F.3
3-phases
3x440 V / 32 A
250 V / 32 A
OCS500N6F.4
See special model
3-phases
3x440 V / 32 A
250 V / 32 A
Model for 3kV on direct HV output
coupling network
AC voltage
DC voltage
OCS500N6.5
CDN1-16 A
250 V / 16 A
250 V / 16 A
OCS500N6.6
CDN1-32 A
250 V / 32 A
250 V / 32 A
OCS500N6.7
CDN3-16 A
3x440 V / 16 A
250 V / 16 A
OCS500N6.8
CDN3-32 A
3x440 V / 32 A
250 V / 32 A
OCS500M6S8

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 7 / 80
1.5.
Special Models
Modell
Remarks
AC voltage
DC voltage
OCS500N6.1
Damped Oscillatory generator as per IEC 61000-4-18 incl
Damped Oscillatory waveform 100kHz and 1MHz
No Ringwave module
250V/16A
250V / 10A
OCS500N6.9
With built-in Ringwave module only, 1 phase CDN
250V/16A
250V / 10A
OCS500N6.10
With built-in Ringwave module only, 1 phase CDN
250V/32A
250V / 20A
OCS500N6.11
Damped Oscillatory generator as per IEC 61000-4-12, IEC
61000-4-18 and ANSI C62-41
incl. Ringwave 0.5us/100kHz & Damped Oscillatory waves
100kHz and 1MHz
3x690V / 32A
250V / 32A
OCS500N6.12
Damped Oscillatory generator as per IEC 61000-4-18, with
waveforms 100kHz and 1MHz, w/o Ringwave
3x690V / 32A
250V / 32A
OCS500N6.13
Damped Oscillatory Wave waveforms 100kHz/1MHz up to
3kV and Ringwave 100kHz;
In minirack 25HU, weight approx. 50kg
3x440V / 100A
250V / 32A
OCS500N6.14
Damped Oscillatory generator as per IEC 61000-4-18,
100kHz and 1MHz damped oscillatory waves,
no Ringwave
3x440V/32A
250V / 32A
OCS500N6.15
Damped Oscillatory generator as per IEC 61000-4-18,
100kHz and 1MHz damped oscillatory waves,
no Ringwave,
In 25HU minirack
3x440V100A
250V / 32A
OCS500N6.16
With built-in Ringwave module 0.5us/100kHz
3x440V/16A
250V / 10A
OCS500N6.17
With built-in Ringwave module 0.5us/100kHz, calibrated
as per IEC 61008-1 and 61009-1 for RCCB option
3x440V/32A
250V / 32A
OCS500N6.18
With built-in Ringwave module 0.5us/100kHz
In minirack 16HU, weight approx. 50kg
3x440V/100A
250V / 32A
OCS500N6.19
Damped Oscillatory generator as per IEC 61000-4-18,
100kHz and 1MHz damped oscillatory waves,
no Ringwave
3x440V/16A
250V / 16A
OCS500N6.22
Damped Oscillatory generator as per IEC 61000-4-12, -4-
18 and ANSI C62.41, incl Damped Oscillatory waveform
100kHz and 1MHz up to 3kV, incl Ring Wave waveform
3x690V/100A
250V / 32A
OCS 500N6F.4
Fast Damped Oscillatory Generator
as per IEC 61000-4-12, IEC 61000-4-18 and calibrated
as per IEC 61008-1 and 61009-1 for RCCB option,
incl. Ringwave and IMN2, with USB-optical remote control
interface; incl. OptoLink 3 meters,
optional slow damped module S-DOW/N6F
3x440 V / 32 A
250V / 32A

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 8 / 80
2.
Operating Functions
2.1.
OCS 500N6.x models
2.1.1.
Front view OCS 500N6.x
1"Test On"
2Function keys "F1..F7
3Display
4Exit
5Cursor keys "" and "→"
6Knob (Inc. / Dec.)
7Escape
8CRO trigger output 5V
9 LED coupling 1 ph. version
10 EUT test supply L, N, PE 1ph version
11 LED coupling 3 ph. version
12 EUT test supply 3-phase version
13 Direct output HV –COM
1 Test On
By pressing the key "Test On" the power supply of the highvoltage part will be ready for start.The red LED indicates the
trigger of a burst event.
2 Function keys "F1 .. F7
Parameters and functions, displayed in the lowest line, can be selected with the related function key.
3 Display
All functions and parameters are displayed (8 lines with max. 40 characters).
4 Exit
Pressing of the Exit function will cause a reset of the firmware. This is only possible if no test routine is running.
5 Cursor keys
Parameters and functions can be changed on-line. The selection of these parameters is realized with the cursor moving to
the left or to the right.
6 Knob (Inc. / Dec)
The knob increments or decrements test parameters with a numeric value orselects from a list of parameters.
7 ESC
When pressing the ESC button the user moves back one page in the menu. The displayed parameters before are stored.
8 Trigger output
At the BNC output the generator trigger can be used as oscilloscope trigger output. It is synchronous to the impulse events.
9 LED coupling
The LED Indicates the actual coupling mode for the 1-phase version.
10 EUT test supply
For single-phase EUT the coupling/decoupling network is part of the generator. The EUT is powered via the safety banana
plugs at the front panel of the simulator

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 9 / 80
1"Test On"
2Function keys "F1...F7
3Display
4Exit
5Cursor keys "" and "→"
6Knob (Inc. / Dec)
7Escape
8CRO trigger output 5V
9 LED coupling 1 ph. version
10 EUT test supply L, N, PE 1ph version
11 LED coupling 3 ph. version
12 EUT test supply 3-phase version
13 Direct output HV –COM
11 LED coupling
The LED Indicates the actual coupling mode for the 3-phase version.
12 EUT test supply
For single- or three-phase EUT thecoupling/decoupling network is part of the generator. The EUT is powered via the safety
banana plugs at the front panel of the simulator
13 Direct HV and COM output
The HV and COM output are the designed for an external using of the impulse. This output is floating and is
used for external coupling/decoupling networks or magnetic field antenna.
Attention
The direct HV and COM output of the generator is located at the front panel of the instrument. It
is not allowed to connect these outputs to any other coupling/decoupling network than
manufactured by AMETEK CTS, e.g. the types CNV or CNI.
Before to connect any external networks to this output the operator must contact the
manufacturer. Any damages due to this matter are not covered by warranty.
The direct pulse output shall also not be used to connect the generator directly to any power
conducting lines.

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 10 / 80
2.1.2.
Rear view OCS 500N6.x
1EUT supply input neutral
2 EUT power mains supply line
3Sync input
4Test supply input PE
5Reference earth connection
6Warning lamp
7 Ventilation
8 Safety Circuit
1 EUT power mains supply input - Neutral
The neutral N is conducted to the EUT via the coupling/decoupling network to the front panel output N.
2 EUT power mains supply input - Phase
The phase of the power mains supply for the EUT is connected to the lack banana connector L. The 3-phase
device has all power mains supply ports on the lower part at the rear side.
3 SYNC input
Input port for an ac synchronization voltage, to which the events shall be synchronized. If no voltage is available
the tests will start automatically in asynchronous mode. Normally the Sync input shall be connected directly from
the L power mains input (2) of the EUT. The input voltage range is 10 to 250Vac
4 EUT power mains supply input –Protective Earth (PE)
The protective earth PE is conducted directly to the front panel output PE.
5 Reference earth connection PE
The generator must be connected to the reference earth plane of the test set up.
6 Warning lamp
A voltage free contact is available for external warning indications (warning lamp). The relays contact
(250V / 5A) will switch after pressing TEST ON button.
7 Ventilation
After long term duration tests the generator should keep on running for some minutes to cool down the system.
8 Safety circuit
A test can only be started if the safety circuit is closed. By opening the safety circuit during a running test, the
test will be stopped immediately and the high voltage will be switched Off and grounded. For s
The safety circuit will not switch off the EUT Mains supply. For switch off the EUT mains a similar safety circuit
must be used as described in a rack solution in the safety manual.

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 11 / 80
9 External trigger
10 Power on switch and fuse
11 Mains selector 115V / 230V
12 Fuse of the high voltage power supply
13 Parallel interface IEEE
14 USB Serial interface
15 Remote control connector
16 FAIL 1 / FAIL 2 connector
9 External trigger (BNC plug)
Trigger input for a pulse release (5-15V positive trigger).
10 Power on switch
The switch is part of the mains filter. Mains fuses are part of the filter. (230V / 1A and 115V / 2A)
11 Mains selector
Selection of 115V / 230V
12 Fuse of the high voltage power supply
The high voltage power supply is protected by this fuse „F3“. In case that no high voltage is generated but the
control unit works properly this fuse shall be checked.
13 Parallel interface GPIB / IEEE 488
IEEE 488 interface with IEEE connector
14 USB Serial interface
USB interface “USB B” connector. For data transfer a USB interface is available. The internal RS 232 interface
is converted to USB standard. Therefore the user must set the same Baud rate in the device and control
software.
Using the USB interface the user can have emc problems during EMC tests Our experiences says, that usually
the computer USB port is disturbed by interference’s. Therefore a high quality USB cable (USB 2.0 standard)
must be used.
15 Remote control connector CN
External coupling devices are controlled via this remote control connector.
16 Fail detection FAIL 1 EUT control (TEST STOP)
Grounding this input will cause a complete stop of the running test procedure. (+15V to ground) The test must
be completely restarted.
Fail detection FAIL 2 EUT control (TEST PAUSE)
Grounding this input will cause a break for the running test procedure (+15V to ground).The test will be
continued when the input is disconnected from ground.

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 12 / 80
2.2.
OCS 500N6F models
2.2.1.
Front view OCS 500N6F.x
1"Test On"
2Function keys "F1..F7
3Display
4Exit
5Cursor keys "" and "→"
6Knob (Inc. / Dec)
7Escape
8Trigger output 5V
9 LED mains coupling 1/3 ph.
10 EUT test supply 1ph/3ph
11 Fast damped output for I/O lines
12 Direct output HV –COM
1 Test On
By pressing the key "Test On" the power supply of the highvoltage part will be ready for start.The red LED indicates the
trigger of a burst event.
2 Function keys "F1 ... F7
Parameters and functions, displayed in the lowest line, can be selected with the related function key.
3 Display
All functions and parameters are displayed (8 lines with max. 40 characters).
4 Exit
Pressing of the Exit function will cause a reset of the firmware. This is only possible if no test routine is running.
5 Cursor keys
Parameters and functions can be changed on-line. The selection of these parameters is realized with the cursor moving to
the left or to the right.
6 Knob (Inc. / Dec)
The knob increments or decrements test parameters with a numeric value orselects from a list of parameters.
7 ESC
When pressing the ESC button the user moves back one page in the menu. The displayed parameters before are stored.
8 Trigger
At the BNC output (5V pos slope) the generator trigger can be used as oscilloscope trigger output. It is synchronous to the
impulse events.

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 13 / 80
1"Test On"
2Function keys "F1..F7
3Display
4Exit
5Cursor keys "" and "→"
6Knob (Inc. / Dec)
7Escape
8CRO trigger output 5V
9LED mains coupling 1/3 ph.
10 EUT test supply 1ph/3ph
11 Fast damped output for I/O lines
12 Direct output HV –COM
9 LED mains coupling
The LED Indicate the actual coupling mode for the 1-phase or 3-phase.
10 EUT test supply
For single- or three-phase EUT thecoupling/decoupling network is part of the generator. The EUT is powered via the safety
banana plugs at the front panel of the simulator
11 Fast damped output for I/O lines
Coaxial output plug for the fast damped oscillatory wave to a capacitive coupling clamp for testing I/O lines.
12 Direct HV and COM output
The HV and COM output are the designed for an external using of the impulse. This output is floating and is
used for external coupling/decoupling networks or magnetic field antenna.
Attention
The direct HV and COM output of the generator is located at the front panel of the instrument. It
is not allowed to connect these outputs to any other coupling/decoupling network than
manufactured by AMETEK CTS, e.g. the types CNV or CNI.
Before to connect any external networks to this output the operator must contact the
manufacturer. Any damages due to this matter are not covered by warranty.
The direct pulse output shall also not be used to connect the generator directly to any power
conducting lines.

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 14 / 80
2.2.2.
Rear view OCS 500N6F.x
1EUT supply input neutral
2 EUT power mains supply line
3Sync input
4Test supply input PE
5Reference earth connection
6Warning lamp
7 Ventilation
8 Safety Circuit
1 EUT power mains supply input - Neutral
The neutral N is conducted to the EUT via the coupling/decoupling network to the front panel output N.
2 EUT power mains supply input - Phase
The phase of the power mains supply for the EUT is connected to the lack banana connector L. The 3-phase
device has all power mains supply ports on the lower part at the rear side.
3 SYNC input
Input port for ac voltage pulse synchronization to the mains. If no voltage is available the tests will start
automatically in asynchronous mode. Normally the Sync input shall be connected directly from the L power
mains input (2) of the EUT. The input voltage range is 10..250 Vac
4 EUT power mains supply input –Protective Earth (PE)
The protective earth PE is conducted directly to the front panel output PE.
5 Reference earth connection
The generator must be connected to the reference earth plane of the test set up.
6 Warning lamp
A voltage free contact is available for external warning indications (warning lamp). The relays contact
(250V / 5A) will switch after pressing TEST ON button.
7 Ventilation
After long term duration tests the generator should keep on running for some minutes to cool down the system.
8 Safety circuit
A test can only be started if the safety circuit is closed. By opening the safety circuit during a running test, the
test will be stopped immediately and the high voltage will be switched off and grounded. For s
The safety circuit will not switch off the EUT Mains supply. For switch off the EUT mains a similar safety circuit
must be used as described in a rack solution in the safety manual.

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 15 / 80
9 External trigger
10 Power on switch and fuse
11 Mains selector 115V / 230V
12 Fuse of the high voltage power supply
13 Parallel interface IEEE
14 Optical interface (USB)
15 Remote control connector
16 FAIL 1 / FAIL 2 connector
9 External trigger (BNC plug)
Trigger input for a pulse release. Trigger level 5-15V positive going.
10 Power on switch
The switch is part of the mains filter. Mains fuses are part of the filter. (230V / 1A and 115V / 2A)
11 Mains selector
Selection of 115V / 230V
12 Fuse of the high voltage power supply
The high voltage power supply is protected by this fuse „F3“. In case that no high voltage is generated but the
control unit works properly this fuse shall be checked.
13 Parallel interface GPIB / IEEE 488
IEEE 488 interface with IEEE connector
14 Optical interface (USB)
For data transfer an optical USB interface is available. The user must set the same Baud rate in the device and
control software. (Default setting 9600 baud).
When the interface is not used, the input and output must be closed by the delivered sticks. Otherwise unwanted
light can start an interrupt on the optical input circuit.
15 Remote control connector CN
External coupling devices are controlled via this remote control connector.
16 Fail detection FAIL 1 EUT control (TEST STOP)
Grounding this input will cause a complete stop of the running test procedure. (+15V to ground) The test must
be completely restarted.
Fail detection FAIL 2 EUT control (TEST PAUSE)
Grounding this input will cause a break for the running test procedure (+15V to ground).The test will be
continued when the input is no more connected to ground.

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 16 / 80
3.
Operation
3.1.
Description of the menus
The simulator is operated by an easy menu control system. Seven function
keys are available to select parameters and functions. All functions are
indicated on the display; max. 8 lines and 40 characters.
The selected parameter is blinking and can be changed by turning the knob (Inc. /Dec.).
The takeover of the input value occurs after about 500ms encoder downtime. This allows
the operator a brief check of the correct input value.
➔ : The digit to be changed can be selected with the cursor (➔).
- Settled values are direct indicated on the screen.
- Status on the bottom lines shows the desired status after pressing the function
key.
ESC: ESC will take you back to the previous level in the menu and set the displayed
values. The latest settings are stored automatically and will be recalled when the
menu is selected again.
EXIT: The firmware will reset to the main screen.
EM TEST
OCS 500N6
Damped Oscillatory
V 2.00
Oscillatory
Ringwave
SWN: 001234
The serial number and the version number SWN are used
for traceability reasons. These numbers are listed in the
test reports and calibration certificates. These numbers
also are listed within the test reports generated by the
AMETEK CTS software ISM IEC.
Start-up display example OCS 500N6

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 17 / 80
3.2.
Menu structure
Page 0...4
Page 0
Page 1
Page 2
Page 3
Page 4..x
MAIN MENU
F1 Damped Osc. 100kHz IEC 61000-4-18
F2 Damped Osc. 1MHz IEC 61000-4-18
F3 Ringwave 100kHz IEC 61000-4-12
F4 Damped Osc. 100kHz MF IEC 61000-4-10
F5 Damped Osc. 1MHz MF IEC 61000-4-10
F6 Damped Osc. 1MHz ext. IEC 60255-26
F7 Service
Damp. Osc.100kHz IEC 61000-4-18
F1 Quick Start
F2 Standard test routines
F3 User test routines
Quick Start
F1 Start
F2 Change
F3 Continue
Start
Start the test routine
Change
Select all parameters
Continue
Continue the test routine
Damped Osc. 1MHz IEC 61000-4-18
F1 Quick Start
F2 Standard test routines
F3 User test routines
Standard test routines
Preprogrammed test routines as
per standard requirements
Standard routines
F1 Common Mode
F2 Differential Mode
Standard routines
F1 Level 1
F2 Level 2
F3 Level 3
F7 Manual
Ringwave IEC 61000-4-12
F1 Quick Start
F2 Standard test routines
F3 User test routines
User test routines
Preprogrammed test routines for
evaluation and design support
User test routines
F1 Synchronous to the mains
F2 Random burst release
F3 Change V after T by U
F4 Change polarity after T
User test routines
F1 Start
F2 Change
F3 Continue
Damped Osc. 100Hz MF IEC 61000-4-10
F1 Quick Start
F2 Standard routines
F3 User test routines
F7 Magnetic field correction factor
Setup Magnetic field
F1 Coil factor Cf [1/m]
Magnetic field factors
Correction factors for magnetic field
antenna
Damped Osc. 1MHz IEC 60255-26
F1 Quick Start
F2 Standard test routines
F3 User test routines
Damped Osc. 1MHz IEC 60255-26
Standard test routines
F1 Common Mode 1
F2 Common Mode 2
F3 Differential Mode
Damped Osc. 1MHz IEC 60255-26
User test routines
F1 Synchronous to the mains
F2 Random burst release
F3 Change V after T by U
F4 Change polarity after T
Damped Osc. 1MHz IEC 60...
F1 Level 1
F2 Level 2
Damped Osc. 1MHz Ext IEC 60255-
26
F1 Quick Start
F2 Standard test routines
F3 User test routines
Setup
F1 Change language
F2 LCD backlighting
F3 Interfaces
F4 Beeper
F5 Power –on counter
Change language
German or English
LCD backlighting
On, Off or Auto
Interfaces Select all parameters
Beeper (on, off)
Power.on counter Display of
Power on time and Testing time
Service
F1 Addresses
F2 Setup
F3 Change standard levels
F7 Status
Change standard level
F1 set all parameters acc.to
standard
F2 Damped Osc. 100kHz
F3 Damped Osc. 1MHz
F4 Ringwave 100kHz
F5 Damped Osc. 1MHz MF
Change standard level
F1 Level 1
F2 Level 2
F3 Level 3
F4 Level 4
F6 Coupling Diff / Common
mode

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 18 / 80
3.3.
Main Menu OCS 500N6.x
Page 1
MAIN MENU
F1 : Damped Osc. 100 kHz IEC 61000-4-18
F2 : Damped Osc. 1MHz IEC 61000-4-18
F3 : Ringwave 100 kHz IEC 61000-4-12
F4 : Damped Osc. 100kHz MF IEC 61000-4-10
F5 : Damped Osc. 1MHz MF IEC 61000-4-10
F6 : Damped Osc. 1MHz ext. IEC 60255-26
F7 : Service
F1
F2
F3
F4
F5
F6
F7
F1 Damped Oscillatory 100 kHz
With function key F1 the user can select Damped Oscillatory 100 kHz as per IEC 61000-4-18. The test pulses
are oscillatory waves with a frequency of 100 kHz and a rise time of 75ns.
F2 Damped Oscillatory 1MHz
With function key F2 the user can select Damped Oscillatory 1MHz as per IEC 61000-4-18. The test pulses are
oscillatory waves with a frequency of 1MHz and a rise time of 75ns...
F3 Ringwave 100 kHz
With function key F3 the user can select the Ring Wave 100 kHz as per IEC 61000-4-12. The test pulses are
oscillatory waves with a frequency of 100 kHz and a rise time of 0.5s.
F4 Damped Oscillatory 100 kHz Magnetic Field
With function key F4 the user can select the Damped Oscillatory Magnetic Field Test as per IEC 61000-4-10. The
test pulses are the same as used under F1 Damped Oscillatory 100 kHz.
F5 Damped Oscillatory 1MHz Magnetic Field
With function key F5 the user can select the Damped Oscillatory Magnetic Field Test as per IEC 61000-4-10. The
test pulses are the same as used under F2 Damped Oscillatory 1MHz.
F6 Damped Oscillatory 1MHz Ext.
With function key F6 the user can select Damped Oscillatory 1MHz as per IEC 60255-26 with coupling to the
external coupling device CNV 508N4. The test pulses are oscillatory waves with a frequency of 1MHz and a rise
time of 75ns...
F7 Service
Setup and servicing routines are available.

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 19 / 80
3.4.
Main Menu OCS 500N6F.x
Page 1
MAIN MENU
F1 Fast Damped Osc. IEC 61000-4-18
F2 Slow Damped Osc. IEC 61000-4-18
F3 Ringwave Gen. 100 kHz IEC 61000-4-12
F4 Damped Osc. 1MHz ext. IEC 60255-26
F7 : Service
F1
F2
F3
F4
F5
F6
F7
Page 2 Fast Damped Osc
SETUP Fast Damped Osc.
F1 Damped Osc. 3MHz IEC 61000-4-18
F2 Damped Osc. 10MHz IEC 61000-4-18
F3 Damped Osc. 30MHz IEC 61000-4-18
F1
F2
F3
F4
F5
F6
F7
Page 2 Slow Damped Osc
SETUP Slow Damped Osc.
F1 Damped Osc. 100 kHz IEC 61000-4-18
F2 Damped Osc. 1 MHz IEC 61000-4-18
F3 Damped Osc. 100 kHz MF IEC 61000-4-18
F4 Damped Osc. 1 MHz MF IEC 61000-4-18
F1
F2
F3
F4
F5
F6
F7
Page 2 Ringwave (See menu structure Chap 3.2)
Ringwave. IEC 61000-4-12
F1 Quickstart
F2 Standard test routines
F3 User test routines
F1
F2
F3
F4
F5
F6
F7
Page 2 Standard test routines Ringwave (See menu structure Chap 3.2)
Damped Osc 1MHz ext. IEC 60255-26
F1 Quickstart
F2 Standard test routines
F3 User test routines
F1
F2
F3
F4
F5
F6
F7

AMETEK CTS OCS 500 N6 series
Manual for Operation V 5.24 20 / 80
3.5.
Phase synchronization in 3-phase system
The built in hardware phase synchronization is between the sync input and PE.
The user must connect the synchronize line L1 with the sync plug.
The synchronization is based on a 3-phase system where neutral is connected to
PE in the supply system.
As Standard line L1 is connected to the sync plug. For coupling other lines, the
OCS500 hardware will not shift the phase angle in relation to the used coupling.
The tables below shows the correction angels considering the phase in a 3-phase system with connected L1 to
the sync input. The user must set the correction angle value manually.
Synchronization: L1 to Sync input
Sync.
Source
Settled phase angel value for coupling:
Coupling
L1-PE
L1-N
L1-PE
L2-N
L2-PE
L3-N
L3-PE
L1-L2
L1-L3
L2-L3
Sync.-
Angel
0°
0°
0°
0°
0°
0°
0°
90°
90°
90°
90°
90°
90°
90°
180°
180°
180°
180°
180°
180°
180°
270°
270°
270°
270°
270°
270°
270°
Example: For setting the coupling L1-L2 with a 180° phase angle set the generator phase to 180°
