AMF KX PLUS User manual

KX PLUS BUN DIVIDER
Superior Scaling Accuracy and Operating Efficiency With
AMF’s Extrusion Technology
•200 - 300% more accurate scaling than a conventional
K-Head divider
•Elimination of divider oil
•Scaling remains consistent over the life of the divider -
15 years or more, with proper maintenance
Dough-Friendly Design
•Single screw changing unit for gentle, low-shear pres
surization
•“Peristaltic” motion metering pump to control through
put without shear - and with 100% purge per revolution,
ensuring “first-in, first-out”
•E-Z Flow distribution manifold is a “valveless” design to
vary scaling weight without increasing back pressure
•Arotary motion cut-off provides a gentle slicing action
• Economical Extrusion Bun Divider
• Direct replacement for K-Head Divider
Low-Maintenance, Long-Life Design
•Rotary motion poly single screw charging unit with
low maintenance single piece jaw coupling
•Rotary motion metering pump
•Rotary cut-off knives for smooth, continuous motion
•40% fewer parts than on a conventional divider
•Electronic synchronization system that eliminates
chain and shaft drives, drastically reducing required
downtime and maintenance
Easy Installation, Operator Friendly Controls
•Mounts in the same location as a K-Head, requiring
virtually no additional space
•Recipe management system stores operating settings
for each product, provides quick, accurate,
consistent set-up of the divider on a regular basis
Features &
Benefits

KX PLUS BUN DIVIDER
Electronic proofer synchronization kit with proofer
drive
Stainless Steel, NEMA-4 rated Operator Station can be
mounted on divider, rounder, or proofer tower
Operator Panel includes the following:
•Allen Bradley PanelView 550 keypad operator inter
face to control:
Stuffing Pump Pressure Set Point
Metering Pump speed
Knife speed
Alarm Messages
Product Codes
•Allen Bradley Push-buttons for:
Two-button start
Stop
Emergency stop
•NEMA-12 remote electrical enclosure including:
Main disconnect switch
Allen Bradley 5/03 PLC
Toshiba Inverters
Closed loop pressure control system with
pressure transducer
•Designed and manufactured in accordance with
BISSC standards
•Heavy duty stainless steel frame for durability and
corrosion resistance
•Polished stainless steel guards and 100 lb. hopper
for easy sanitation
•Single Auger Stuffing Pump with Stainless Steel
Housing for durability and maximum pumping
efficiency with minimal temperature increase
•Stuffing Pump drives are direct coupled, no chains
or pulleys
•All Nord Severe Duty Gearmotor Drives
•Stainless Steel metering pump for precise, linear
flow control with ultra low shear peristaltic action
•EZ Flow Distribution and scaling manifold features
internal flow diverters to precisely balance flow
without additional back pressure.
•UHMW cut-off knives slice cleanly, without tearing
gluten strands
•Precise doughball placement at any speed
•Easy access to all operational areas, no tools
required for sanitation
•Manually actuated divider pushback employs a large
air cylinder for slow, steady movement of divider
from rounder and allows for easy maintenance and
sanitation access to the cut-off area
•Venturi-style vacuum system provides for efficient
pumping and degassing
Electrical
Features
Mechanical
Features

• Allen Bradley 5/04 PLC Upgrade
• Stainless-steel remote electrical panel in lieu of painted
• CE confirmed electrical package
• Woods, AB, or other inverters in lieu of Toshiba
• Operator Interface in lieu of Allen Bradley PanelView 550
• Extrusion type non-stick rounder belt
• Spiral Tunnel Rounder Bars designed for extrusion dividers
• Rounder Bar Lift Kit
• Automatic divider pushback
• Rounder belt speed control package
• Product memory increase
• Larger hopper
• Integrated controls for pump and conveyor system
• Do-Flow or Post Mix Developer
• Stainless Steel Chilled Rounder Bed with integral divider cart
• Pneumatic “Pulse” Flour Sifter
• Stainless Steel Zig Zag Rotary Gate Kit
• NEW Magnetic Pan Indexer with integral recipe management
• Spare parts kit
Specifications
Options KX PLUS BUN DIVIDER

Dimensional
Drawing
KX PLUS BUN DIVIDER
For more information please call
your Account Manager or 1-800-BAKERS-1.
Headquarters
AMF Bakery Systems
2115 West Laburnum Avenue
Richmond, Virginia 23227
1-800-225-3771 or 804-355-7961
FAX: [phone]
www.amfbakery.com [e-mail]
European operation
West Park Ring Road
Leeds LS16 6QQ England
Tel.: [phone]
Fax: [phone]
06/2001
AMF’s continuing engineering is constantly improving product performance. Consequently machinery specifications are subject to change without notice.
