AMF Servotech User manual

SERVOTECH BREAD DIVIDER
• Anewconceptindoughdividingthatcombinesthegentledough
handlingofaramandknifedividerwiththeprecisescalingofthe
latestservocontroltechnology.
• Uniquedesignforusewithawiderangeofdoughsincludingspecialty,
wholewheat,rye,cinnamonraisin,andwhite.

SERVOTECH BREAD DIVIDER
FEATURES &BENEFITS
ELECTRICAL FEATURES
• Precisescalingaccuracy.
• Servodrivesandrecipecontrollogicallowsthemostaccuratecontrolofpressureinsidedoughchamberfor
variousdoughtypes.Ramandknifestrokescanalsobeadjustedrelativetoscalingweight.Thisconcept
controlsdoughchambervolumeandmaintainsrst-in,rst-outdoughprocessing.Theelectronically
controlledmotionscanalsobecustomizedforspecicapplications,andrecalledbyrecipemanagementwhile
usingallstandardmechanicalcomponents.
• Ramandknifeelectroniclinearactuatorsreplacecams,bushings,leversandgreasepointsthusreducing
maintenance,extendingmachinelifeandaccuracybyeliminatingbacklashfromwear.
• Highpressurelubricationdistributionsysteminsuresproperlubricationofsurfaceswhilereducingoil
consumption.
• Servodrivesalsoprovideelectronictorquelimitingfunctionstoprotectmachinesfromforeignobjects,
individualaxisforward/reversejogfunctiontoclearobstruction,andsingletouchcleaningpositionforfaster
maintenanceandsanitation.
• Stainlesssteelandplasticmaterialsfordoughcontactsurfacesandlighterramandpistonassembliesfacilitate
cleaningandhandling.
• Automaticprimaryandsecondaryconveyorspeedmanagementmaintaindoughballspacingatdifferent
operatingrates.
• Rigidstainlesssteelframeandreardoordesignoffersunmatchedaccessinthevolumetricdividerforquick
andcompletesanitation.
OperatorpanelisstainlesssteelNEMA4ratedand
containsthefollowing:
• AllenBradleyPanelView600+operatorinterface
whichdisplays:
-Operationspeedandproductcounter
-Conveyorandsifterspeedadjustments
-Recipeselection,modicationandaddition
-Status,alarmandhistorymessages
• AllenBradleypushbuttonsforthefollowing
functions:
-Start
-Stop
-Alarmacknowledge/reset
-Emergencystop
NEMA12remoteenclosure(paintedsteel)including:
• Mainpowerdisconnect
• AllenBradleyCompactLogixprogrammablelogic
controller
• AllenBradleyKinetix6000servodrivesfor
processmotionaxis
• AllenBradleyACinvertersforconveyorsandour
sifters

MECHANICAL FEATURES
OPTIONS
FrameAssembly
• Stainlesssteelframestructureandguardswithsafetyinterlocks
• Clean-in-placeramandknifesupports
• Easyaccessreardoor
• Allcomponentslocatedabovethedischargeconveyorforeasy
cleaning
ConveyorsandSiftersAssembly
• ACvariablespeedprimaryandsecondaryconveyors
• Cantileveredconveyorsupportframesforeasybeltremovaland
replacement
• ACvariablespeed,highcapacityoursifters
DivisionandScalingSystem
• Primaryhopper
• Doughhopperhigh/lowlevelmonitor
• Sanitarystainlesssteelhopper,doughchamberandknife
• Plastic/stainlesssteelram
• Servocontrolsandlinearactuatorsreplacemaincams,dashpot
assembliesandshearpinsafeties
• Stainlesssteeldivisionboxwithreplaceable,lowfrictionplastic
wearplateandinterchangeablepistons
• Ejectorandpistonstopperadjustmentsmechanicallylocked
onheavydutywormgearsseparatedfromthedividinghead
movement
• Adjustabledoughballdeectorrollers
• Pressurizedlubricationsystemwithindividual,adjustable,multi-
pointinjection Divider Box and Ejector
Ram and Knife
SPECIFICATIONS
AirRequirements-5SCFMat90PSIG
ApproximateDimensions:
84”Lx86”Wx66”H(2134mmx2184mmx1676mm)
Doorclearance44”(1118mm)radius
ApproximateShippingWeight:
4,350lb.(1973kg)
NEMA4Xstainlesssteelmainelectricalenclosure•
Arcashpaneloption•
Oilingsystem•
Removable Sifter
Closedloopweightregulatorforprocessvariation•
compensation
Internallightingkit•
Framemountedswingbeamandhoist•
Throughputrange:
Scalingrangefrom6oz.to54oz.(170gto1531g)at65
lb./in3doughdensity
6-30strokesperminute
5,6,7,8pockets
Electricalrequirements:
30KVA
Standardvoltage-460volts/3phases/60Hz(other
voltagesavailable)
PLCI/OVoltage:24VDCin/120VACout
Primary Hopper

Europe Ofce:
6 The Sidings
Station Road, Guiseley
Leeds LS20 8BX, England
Tel: [phone]
Fax: [phone]
[e-mail]
1-800-BAKERS-1
www.amfbakery.com
FOR MORE INFORMATION PLEASE CALL YOUR ACCOUNT MANAGER OR
AMF’s focus on continuous improvement may result
in changes to machinery specications without notice. 08/2010
Asia Ofce:
Room 15-2, A-Building
Thunis Dev. Building
No.11 Hui Xin East St.
Chaoyang District
Beijing, China 100029
Tel: [phone]
Fax: [phone]
[e-mail]
Headquarters:
2115 W. Laburnum Ave.
Richmond, Virginia 23227
Tel: [phone]
or 1-804-355-7961
Fax: [phone]
[e-mail]
SERVOTECH BREAD DIVIDER
DIMENSIONAL DRAWING
