Amina APU-RS8iC User manual

Installation guide APU-RS8iC
APU-RS16iC
19” Rack Mount, 1U,
Multi-channel Loudspeaker
Protection Unit


3
Index
Caution: Read before installing these products.........4
Introduction ..................................................................................4
Compatibility...........................................................................4
Loudspeaker settings...............................................................5
Check model numbers........................................................ 5
Cautions when changing loudspeaker settings.....5
Loudspeaker settings...............................................................6
Changing settings.................................................................6
Recording settings ................................................................6
Connection....................................................................................7
Connection cautions............................................................ 7
Wiring diagram......................................................................7
Wiring the loudspeaker connectors ............................8
Fitting the connectors.........................................................8
Positioning.....................................................................................9
Front panel mounting .........................................................9
Operation.......................................................................................9
Cautions in use.......................................................................9
Using the APU-RSiC .............................................................9
Troubleshooting........................................................................ 10
Specifications............................................................................ 10
Warranty ...................................................................................... 10

4
Caution: Read
before installing
these products
• To ensure optimal performance,
please read this guide carefully. Keep
it in a safe place for future reference.
• Install this product in a cool, dry
and clean place - away from direct
sunlight, heat sources, vibration, dust
and moisture.
• Do not expose this unit to sudden
temperature changes or locate it in
an environment with high humidity.
This is to prevent condensation
forming inside which may cause
damage to this unit and possibly to
devices connected to it.
• Do not clean this unit with chemical
solvents as this might damage the
finish. Use a clean, dry or damp cloth.
• Do not attempt to modify or repair
this unit.
• Be sure that all connections are made
in accordance with this guide.
• Contact your distributor or the
manufacturer if a fault should occur.
• This unit features internal jumpers
that may be adjusted by the installer.
Take care when removing and re-
fitting the lid not to damage the four
machine screws. Ensure the screws
are tight when re-fitting them.
• This product does not require any
power connection. Never attempt to
connect mains or any other power
source to it.
Introduction
Compatibility
The APU-RS8iC and APU-RS16iC are
compatible with all ‘i’-series loudspeakers
(for example, Edge5i & Mobius7i) and the
iQ range (legacy). The installation of the
different rackmount models is the same.
The APU-RSiC features a separate high-
pass filter and a current sensing
re-settable fuse to protect each
loudspeaker from being over-driven and
potentially damaged.
If the APU-RSiC senses excessive drive
current from the system’s amplifier it
will automatically reduce the sound level
from the loudspeaker until the amplifier’s
volume is reduced.
NOTE: APU-RSiC is not suitable
for 100V/70V line systems
(high impedance/fixed
voltage), subwoofers or other
manufacturers’ loudspeakers.

5
Loudspeaker
settings
Check model numbers
The APU-RSiC settings are compatible
with three groups of loudspeaker models.
These are shown in the table below.
APU-RSiC
1N /A
3 Edge3i, Mobius3i,
MobiusDuali
5 Edge5i, Mobius5i,
Mobius5i/S200
7 Edge7i, Mobius7i
NOTE: The factory setting for all jumpers
is Group 1.
If not changed from Group 1,
higher performing loudspeakers
will have their performance
characteristics limited.
• Before changing any settings, make a
note of which loudspeaker model will
be connected to each channel of the
APU-RSiC.
Cautions when changing
loudspeaker settings
Ensure that each channel is
correctly set to match the
connected loudspeaker before
use. Failure to do so could result
in loudspeaker damage.
• The APU-RS8iC and APU-RS16iC are
low voltage, passive devices, however
ALWAYS disconnect them from all
loudspeakers and amplifiers before
changing loudspeaker settings.
• Ensure that jumpers are fully pushed
down onto their pins when changing
settings.
• Only fit one jumper for each channel.
• Ensure the lid is securely fitted to the
product after changing settings.
• Only remove and replace the lid
fixing screws by hand. Always use the
correct tool and do not over tighten.

6
Loudspeaker
settings
Changing settings
• Unscrew the four screws on the sides
of the chassis.
• Remove the lid.
• Identify the 8 or 16 configuration
jumpers located on the PCB (two are
shown in the enlarged diagram on
the right).
Each jumper has four settings marked
on the PCB - 1, 3, 5 and 7. In the
diagram, the arrowed jumpers are set
to the factory setting - group 1.
• Referring to the table at the start of
this section, set each jumper to the
correct setting for the connected
loudspeaker.
• Check that all settings have been
correctly made.
• Re-fit the lid.
Recording settings
There is an area on the product serial
number label where the fuse settings can
be marked for each channel once the
jumpers have been set.
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
1
3
3
5
5
7
7
1
3
5
7
1
3
5
7
1
1
3
5
7
1
3
5
7
1
The label drawing shows
an example of a system
that has 10 loudspeakers
connected of differing
types.
XX
XXXX
XX
XX

7
Connection
Connection cautions
• NEVER connect more than one
loudspeaker to an output channel.
• It is not recommended to connect
amplifiers with power outputs that
are far greater than the loudspeaker’s
peak power rating.
Wiring diagram
The diagram below shows an example of
the wiring for channels 1 and 2.
Each channel of the amplifier is wired
to the ‘AMP’ terminals of one of the APU-
RSiC channels.
The corresponding loudspeaker is
wired to the ‘SPK’ terminals of the same
channel.
NOTE: The + terminals of the amplifiers
and loudspeakers must connect
to the + terminals of the APU-
RSiC to maintain correct polarity
all the way from amplifier to
loudspeaker.
Amplifier
Channel 2Channel 1
AMP SPK
CH1
AMP SPK
CH2
AMP SPK
CH3
AMP SPK
CH4
AMP SPK
CH5
AMP SPK
CH6
AMP SPK
CH7
AMP SPK
CH8
AMP SPK
CH9
AMP SPK
CH10
AMP SPK
CH11
AMP SPK
CH12
AMP SPK
CH13
AMP SPK
CH14
AMP SPK
CH15
AMP SPK
CH16
Edge-i or
Mobius-i
series
loudspeaker
Edge-i or
Mobius-i
series
loudspeaker

8
Connection
Wiring the loudspeaker
connectors
The loudspeaker connectors are supplied
packed separately with the APU-RSiC to
simplify the fitting of cables from each
amplifier and loudspeaker channel.
• Strip each cable back by 6-8mm and
twist the wire ends.
• Identify the polarity of the cable.
The + cable is usually marked with a
stripe or a rib.
Stripe Rib
The + cable must be connected onl y
to + terminals throughout the system
(at the APU-RSiC, the amplifier and the
loudspeaker).
• Unscrew the cable fixing screws.
• Pass the loudspeaker cable into the
terminal openings.
To maintain polarity the + cable must
always be connected to the LEFT
terminal.
• Tighten the fixing screws to secure
the cable.
Fitting the connectors
• Each connector can now be fitted by
pressing it into the opening on the
back of the APU-RSiC.
The slot in the connector should
engage with the edge of the PCB inside
the opening.

9
Positioning
Front panel mounting
The APU-RSiC is designed to fit into a
standard 19 inch equipment rack via 4
mounting holes in the front panel and
has a height of 1U (44.5mm/1 3
/
4inches).
The fixing hole dimensions are shown in
the diagram below.
R
10.0mm
(/")
25 64
7.0mm
( / ")
932
32.0mm
(1 / ")
14
44.5mm
(1 / ")
34
Alternatively, the APU-RSiC can be
placed on a shelf. Other equipment (up
to 10kg/22lbs) may be placed on top if
necessary. Take care not to scratch the
top of the case and that any weight is
not directly over the centre of the APU-
RSiC.
NOTE: The APU-RSiC does NOT require
ventilation and therefore its
installation position is not critical.
The APU-RSiC should ALWAYS be
installed in a dry environment that does
not exceed 35 degrees Centigrade (95
degrees Fahrenheit).
The product’s steel case provides all
necessary shielding from magnetic fields
generated by the APU-RSiC itself (these
are very small) or from other equipment
placed nearby.
Operation
Cautions in use
It is not recommended that you
intentionally cause the APU-RSiC to
automatically protect the loudspeakers
by deliberately over-driving them. If you
find that the APU-RSiC automatically
reduces the audio volume from the
loudspeakers frequently it may suggest
that the amplifier being used is too
powerful or that the layer of plaster over
the loudspeakers is too thick.
WARNING: DO NOT switch on the
amplifier unless both APU-RSiC and
loudspeakers are connected to it.
Damage may occur to the amplifier if
it is operated without a loudspeaker
connected to the output of the APU-RSiC.
Using the APU-RSiC
There are no controls on the APU-
RSiC and no need to change any
settings unless the model of connected
loudspeaker is changed.

10
Troubleshooting
Symptom Solution
No sound from one
or more channels
Check that the sound source and all of the system amplifiers
are switched on.
If the problem persists, switch off the system and check that
the connections to each channel have been correctly and
securely made. Ensure that there are no whiskers of wire
touching at the connectors and causing the signal to short-
circuit.
Volume reduces
periodically in
one or more of the
loudspeakers
This may be due to over-driving. If so, reduce the volume.
Never overdrive the system intentionally.
There may be too much plaster over the loudspeakers.
If you cannot resolve the problem, contact your supplier.
Specifications
Dimensions: 1U height front panel, 482mm x 44.5mm (19” x 1 3
/
4”),
case depth, 213mm (8 3
/
8”)
Weight: 3.14kg (6lbs 14oz) Nett, 3.68kg (8lbs 2oz) Gross
Fuse protection: Self-resetting, current sensing type. Fuse threshold
set via internal jumpers
Compatibility APU-RS8iC/16iC: Suitable for use with all Amina ‘i’ series products and
iQ series (legacy)
Number of channels: 8 or 16
Connection type: Screw terminals
Maintenance requirements: Protection fuses can be set by installer if necessary.*
*Repeated tripping of fuses may require fuse replacement by the manufacturer to
ensure optimal speaker performance.
Warranty
The APU-RSiC is designed to operate reliably for many years. Correctly installed and
operated in accordance with these instructions, Amina warranties the APU-RSiC against
defective materials and workmanship for a period of ten years.


Amina Technologies Ltd
Cirrus House, Glebe Road
Huntingdon, Cambs, PE29 7DL England
T: +44 (0)1480 354390
W: www.aminasound.com / E: info@aminasound.com
Copyright 2022
APU-RSiC V2.3
This manual suits for next models
1
Table of contents
Other Amina Speakers manuals

Amina
Amina MOBIUS 7 User manual

Amina
Amina AIW750E User manual

Amina
Amina BackboxSW 345 User manual

Amina
Amina Life-Fidelity LFi2T Manual

Amina
Amina AIW150i User manual

Amina
Amina AIW2X User manual

Amina
Amina EdgeiBSS-EN54 Series User manual

Amina
Amina MOBIUS 7 User manual

Amina
Amina MobiusiB User manual

Amina
Amina iQ1 User manual
