AMP Lighting PilotPro APL-3022-L-B-BZ Operating and safety instructions

- 1 -
Specications and product details subject to change without notice.
© Copyright 2019, AMP® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3900
Help Hotline:
1-813-978-3900 • Mon-Fri 9am-6pm (EST)
www.amplighting.com

Package Contents
Product Dimensions
To avoid the risk of re, explosion, or electric shock, this product should
be installed, inspected, and maintained by a qualied electrician only, in
accordance with all applicable electrical codes.
To avoid electric shock:
1. Be certain electrical power is OFF before and during installation and
maintenance.
2. Luminaire must be connected to a wiring system with an equipment-
grounding conductor.
To avoid explosion:
1. Make sure the supply voltage is the same as the rated luminaire
voltage.
2. Do not install where the marked operating temperatures exceed the
ignition temperature of the hazardous atmosphere.
3. Do not operate in ambient temperatures above those indicated on the
luminaire.
For supply connections use wire rated for at least 90°C (194°F)
Warning: these luminaire should ONLY be installed by a qualied electrician.
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.
A. (1) Fixture Body
B. (1) Mounting Plate
C. (3) Anchor Bolts
D. (3) Cap Nuts
6”
- 3 -- 2 -
40”
5.5”
AMP® PilotPro Bollard (Lamp Ready)
APL-3022-L-B-BZ
INSTALLATION & MAINTENANCE GUIDE
Important Safety Instructions: Read Before Installation
!
Important Safety Instructions: Read Before Installation
!
www.amplighting.com [email protected] • 813.978.3900

- 5 -- 4 -
Lay Conduit and Junction Box
1
Dig a hole in the ground and lay the conduit and junction box in
your desired location.
Ground
Soil
Conduit
Install Anchor Bolts to Mounting Plate
2
Thread anchor bolts onto
mounting plates until they
become ush to the plate.
Adjust if leveling is needed.
Mounting
Plate
Anchor Bolt
Junction Box
Conduit
Install Anchor Bolts to Concrete
3
CAUTION: Install according to all applicable local codes.
Make sure the conduits are centered on the bottom of the plate.
Install the anchor bolts in the concrete foundation making sure the
leveling nuts and base remain on top of the concrete. Level the base
by adjusting the leveling threads on the underside of the plate.
Anchor Bolt
Concrete
Leveling Threads
Mounting Plate
Conduit
18”
Remove the cover from the
junction box by loosening the
screws. Pass the xture supply
wires through the conduit to
the junction box. Place the
base and xture over the
anchor bolts. Then, put the
washers and lock washers over
the anchor bolts. Secure by
threading the cap nuts onto
the anchor bolts. Hand tighten
until snug.
Install Fixture Body to Anchor Bolts
4
Cap Nut
Base
Fixture Body
Anchor Bolt
Supply Wire
Screw
Cover
Junction Box
Conduit
AMP® PilotPro Bollard (Lamp Ready)
APL-3022-L-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com [email protected] • 813.978.3900

- 7 -- 6 -
Wire Connection
5
Feed the main supply cable into the junction box. Strip the leads on the
xture supply wire and the main supply cable. Using wire connectors,
(sold separately) connect the leads from the xture supply wire to the
main supply cable leads and connect the grounding wires to the ground
screw in the junction box. After wiring, carefully tuck slack wires into the
junction box. Attach the cover onto the junction box and secure with the
previously removed screws. Bury the conduits and the junction box with
the previously removed dirt.
Supply Wire from Fixture Main Supply Cable
Wire Connectors
Junction Box
Ground Screw
Conduit
Screw
Cover
Loosen the set screws from the
top of the xture and remove the
louver.
Remove Louver
6
Set Screw
Louver
Fixture Body
Install Lamp
7
Insert the bulb with the correct
wattage and type marked on the
xture label and tighten into place.
CAUTION: Do not exceed
maximum wattage marked on
luminaire label.
Socket
bulb
Install/Replace Bulb
Remove the louver to expose the lamp, then replace it with the correct
wattage and type marked on the xture label. Then reinstall the louver.
IMPORTANT: Bulbs must be protected from moisture and dust at all times.
Always reinstall louver when removed.
Place the louver back onto the
xture and secure with previously
removed set screws.
Install Louver
8
Set Screw
Louver
Fixture Body
AMP® PilotPro Bollard (Lamp Ready)
APL-3022-L-B-BZ
INSTALLATION & MAINTENANCE GUIDE
www.amplighting.com [email protected] • 813.978.3900

- 8 -
