AMX AXT-CA10 User manual

10.4"color lcd tiltscreens
The 10.4" Color LCD TiltScreen features a brilliant touch screen, 5 MB
or memory (4 MB flash memory), and G3 firmwaregraphics.
Create fully automated pop-up pages with the TPDesign3 Windows®
software. Revolutionary all-in-one button design combines bitmap
images, symbols, and multiple text fonts into a unified, easy-to-copy
command function.
Experience vivid graphics with the Color Active Touch Panel (CA10
series). Resize an adjustable video window with the Color Video Touch
Panel (CV10 series).

AXT-CA10: 10.4"
COLOR ACTIVE TILTSCREEN
•Screen tilts for best viewing
angle
•10.4" color-active LCD with a
640 x 480 pixel resolution
POWER
•1A@12VDC
MEMORY
•5MB (4 MB flash)
WIRING
•4-pin AXlink and 2-pin
12VDC power jacks
•DB-9 male PC/mouse input
BASE DIM. (WD)
•11.46" x 9.46"
(29.12 cm x 24.0 cm)
TILTSCREEN HEIGHT
•Lowered - 4.14" (10.52 cm)
•Raised - 9.84" (24.99 cm)
TILTSCREEN ENCLOSURES
•Black plastic with matte finish
WEIGHT
•4.6 lbs (2.08 kg)
AXT-CV10: 10.4" COLOR VIDEO
TILTSCREEN (NTSC/PAL)
•Screen tilts for best viewing
angle
•10.4" color-active LCD with a
640 x 480 pixel resolution
•Includes a resizeable video
window
POWER
•1A@12 VDC
MEMORY
•5MB (4 MB flash)
WIRING
•4-pin AXlink and 2-pin
12VDC power jacks
•DB-9 male PC/mouse input
•RCA female connector
BASE DIM. (WD)
•11.46" x 9.46"
(29.12 cm x 24.0 cm)
TILTSCREEN HEIGHT
•Lowered - 4.14" (10.52 cm)
•Raised - 9.84" (24.99 cm)
TILTSCREEN ENCLOSURES
•Black plastic with matte finish
WEIGHT
•4.6 lbs (2.08 kg)
AXT-CG10: 10.4" COLOR GRAPHIC
TILTSCREEN (VGA - XGA/DOS)
•Screen tilts for best viewing
angle
•10.4" color-active LCD with a
640 x 480 pixel resolution
•Features a full-screen VGA
graphics window
•Includes a resizeable video
window
POWER
•1A@12 VDC
MEMORY
•5MB (4 MB flash)
WIRING
•4-pin AXlink and 2-pin
12VDC power jacks
•DB-9 male PC/mouse input
•RCA female connector
•15-pin DB-15 (high density)
male connector
BASE DIM. (WD)
•11.46" x 9.46"
(29.12 cm x 24.0 cm)
TILTSCREEN HEIGHT
•Lowered - 4.14" (10.52 cm)
•Raised - 9.84" (24.99 cm)
WEIGHT
•4.6 lbs (2.08 kg)
AXD-CA10: 10.4" COLOR ACTIVE
WALL TOUCH PANEL
•Installs into a flat surface
•Viewing angle can be
changed dependant on
location: wall or podium
POWER
•1A@12VDC
BASE DIM. (HWD)
•8.88" x 12.88" x 2.19"
(22.56 cm x 32.72 cm x
5.56 cm)
BEZEL COLORS
•Black or white
DECOR-STYLE ENCLOSURES
•Matte finish, screwed security
overlay, and BB-TP3 Backbox
OPTIONS
•BB-TP3 Backbox
WEIGHT
•6.1 lbs (2.77 kg)
AXD-CV10: 10.4" COLOR VIDEO
WALL TOUCH PANEL
•Installs into a flat surface
•Viewing angle can be
changed dependant on
location: wall or podium
POWER
•1A@12 VDC
BASE DIM. (HWD)
•8.88" x 12.88" x 2.19"
(22.56 cm x 32.72 cm x
5.56 cm)
BEZEL COLORS
•Black or white
DECOR-STYLE ENCLOSURES
•Matte finish, screwed security
overlay, and BB-TP3 Backbox
OPTIONS
•BB-TP3 Backbox
WEIGHT
•6.1 lbs (2.77 kg)
AXD-CG10: 10.4" COLOR
GRAPHIC WALL TOUCH PANEL
•Installs into a flat surface
•Viewing angle can be
changed dependant on
location: wall or podium
POWER
•1A@12 VDC
BASE DIM. (HWD)
•8.88" x 12.88" x 2.19"
(22.56 cm x 32.72 cm x
5.56 cm)
BEZEL COLORS
•Black or white
DECOR-STYLE ENCLOSURES
•Matte finish, screwed security
overlay, and BB-TP3 Backbox
OPTIONS
•BB-TP3 Backbox
WEIGHT
•6.1 lbs (2.77 kg)
AXM-CA10: 10.4" COLOR ACTIVE
RACK-MOUNT PANEL
•Installs into a flat surface
•Viewing angle can be
changed dependant on
location: wall or podium
POWER
•1A@12VDC
BASE DIM. (HWD)
•8.72" x 19.00" x 1.78"
(22.15 cm x 48.26 cm x
4.52 cm)
DECOR-STYLE ENCLOSURES
•Matte finish, screwed security
overlay, and Low-Profile
Backbox
OPTIONS
•Up to 24 pushbuttons (/PB),
12 on each side
WEIGHT
•6.1 lbs (2.77 kg)
AXM-CV10: 10.4" COLOR VIDEO
RACK-MOUNT PANEL
•Installs into a flat surface
•Viewing angle can be
changed dependant on
location: wall or podium
POWER
•1A@12 VDC
BASE DIM. (HWD)
•8.72" x 19.00" x 1.78"
(22.15 cm x 48.26 cm x
4.52 cm)
DECOR-STYLE ENCLOSURES
•Matte finish, screwed security
overlay, and Low-Profile
Backbox
OPTIONS
•Up to 24 pushbuttons (/PB),
12 on each side
WEIGHT
•6.1 lbs (2.77 kg)
AXM-CG10: 10.4" COLOR
GRAPHIC RACK-MOUNT PANEL
•Installs into a flat surface
•Viewing angle can be
changed dependant on
location: wall or podium
POWER
•1A@12 VDC
BASE DIM. (HWD)
•8.72" x 19.00" x 1.78"
(22.15 cm x 48.26 cm x
4.52 cm)
DECOR-STYLE ENCLOSURES
•Matte finish, screwed security
overlay, and Low-Profile
Backbox
OPTIONS
•Up to 24 pushbuttons (/PB),
12 on each side
WEIGHT
•6.1 lbs (2.77 kg)
