NXT-1200VG/NXD-1200VG DATA SHEET
Modero®Touch Panels
12” Modero
Multimedia
Touch Panel
Whether you need powerful video processing, ample on-screen real estate or versatile mounting options -
the 12” Modero Standard fits the bill. The included RGB or Video Kit allows component or composite video
signals and audio signals to be input for superior audiovisual reproduction. The Modero user interface
reveals crisp, clear pictures and sound, state-of-the-art graphics and a user-friendly format for integrating
and automating audio, video, and on-screen dynamic images.
DIGITAL STREAMING
Powered by a DSP core, the 12” Modero Multimedia Touch Panel has the muscle to handle high quality digital streaming
– both component video and audio, in wired or wireless configurations. The 12” Modero features full support for standard
MPEG-2 video and audio.
ALL ETHERNET
As with all next generation Modero panels, the 12” Modero uses industry-standard Ethernet connectivity for both wired and
wireless networking. Integration and installation have never been easier.
• 12”coloractive-matrixdisplaywith4:3aspectratio
• ScreenResolution(HW):800x600pixels
• Displaycolors:262K(24-bitcolordepth)
• Channeltransparency:8-bitAlphachanneltransparency
• SupportsanalogstereoaudioandRGB/component(withRGBKit)orcomposite/S-Videosignals(withVideoKit)
• StreamingMPEG-2video/audio,NetworkVideo-MotionJPEG
• Videoformats:NTSC,PALandSECAM
• VNCviaAMX’sexclusiveG4ComputerControl
• Built-inSpeakers(2)andmicrophone
• MotionSensor(PIR)andLightSensor
• 256MBSDRAM/128MBCompactFlashMemory(upgradeable)
• Wired10/100Ethernet

NXT-1200VG/NXD-1200VG DATA SHEET
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
NXT-1200VG (FG2250-61)
NXD-1200VG (FG2251-61)
DIMENSIONS (HWD)
•NXD-1200VG (with faceplate): 12 3/8” x 12 9/16” x 3 1/4”
(31.4 cm x 32.0 cm x 8.3 cm)
•NXT-1200V (fully raised): 10 15/16” x 12 5/16” x 12 1/2”
(27.7 cm x 31.3 cm x 31.8 cm)
•NXT-1200V (fully lowered): 6 3/4” x 12 5/16” x 12 1/2”
(17.2 cm x 31.3 cm x 31.8 cm)
•CB-TP12 (conduit/wallbox): 11 1/2” x 11 5/8” x 3 1/2”
(29.3 cm x 29.5 cm x 8.9 cm)
•MB-TP12 (VESA mounting box): 12 3/8” x 12 5/8” x 3 1/2”
(31.4 cm x 32.0 cm x 8.9 cm)
POWER
12” Modero Panels (full draw): 2.3 A @ 12 VDC
(stand-alone)
MEMORY
•256 MB on-board memory
•128 MB Compact Flash (upgradeable to 1 GB factory
programmed)
WEIGHT
•NXD-1200VG: 10.80 lbs (4.90 kg)
•NXT-1200VG: 10.80 lbs (4.90 kg)
LCD PARAMETERS
•Aspect Ratio: 4:3
•Brightness (luminance): 250 cd/m2
•Channel transparency: 8-bit Alpha channel transparency
•Contrast ratio: 300:1
•Display area (HW): 183.10 mm x 247.40 mm
•Display colors: 256K (18-bit color depth)
•Dot/pixel pitch: 0.297 mm
•Screen resolution (HV): 800 x 600
•Video formats: NTSC, PAL, and SECAM (shown within
variable-size video windows)
•Viewing angles (160° total viewing angle):
- Horizontal: + 80° (left and right from center)
- Vertical: + 80° (up and down from center)
SUPPORTED AUDIO SAMPLE RATES
48000Hz, 44100Hz, 32000Hz, 24000Hz, 22050Hz, 16000Hz,
12000Hz, 11025Hz, and 8000Hz
CERTIFICATIONS
FCC, CE, and EN60950
FRONT PANEL COMPONENTS
•Light Sensor: Photosensitive light detector for automatic
adjustment of the panel brightness
•Motion Sensor (PIR): Proximity Infrared Detector to wake
the panel when panel is approached
•Front Setup Access Button: Pushbutton (gray) used to
either put the panel into a “sleep” or “wake” state
•Microphone: Used for intercom applications
•Speakers: Stereo output with a frequency response of
450 Hz - 7 KHz
REAR PANEL COMPONENTS
•RGB Connector: Made available only by using an NXA-RGB
interface card installed within the touch panel. Used with
Component/RGB signals
•Audio/Video Connector: RJ-45 connector for
communication of differential audio/video signals
•Ethernet 10/100 Port: RJ-45 port for 10/100 Mbps
communication
•PWR Connector: 2-pin 3.5 mm mini-Phoenix connector
•Stereo Output Connector: Stereo output through a 3.5mm
mini-jack
•USB Connector: Two Type A USB ports
•Mini-USB Connector: 5-pin Mini-USB connector
OPERATING / STORAGE ENVIRONMENTS
•Operating Temperature: 10° C (50° F) to 40° C (104° F)
•Operating Humidity: 20% to 85% RH
•Storage Temperature: -20° C (-4° F) to 60° C (140° F)
•Storage Humidity: 5% to 85% RH
INCLUDED ACCESSORIES
•Installation Kit for 12” and 17” NXD panels (KA2251-01):
- 2-pin mini-Phoenix connector (41-5025)
- Three Phillips-head screws (#4-20 x 0.250 Black)
(80-0114-08)
- One CAT5 Suppression Ferrites (04-0014)
- Four Drywall clips (62-5924-05) and #6-metal strips
(80-0192)
•Installation Kit for 12” NXT panels (KA2251-03):
- 2-pin mini-Phoenix connector (41-5025)
- Three Phillips-head screws (#4-20 x 0.250 Black)
(80-0114-08)
- Two CAT5 Suppression Ferrites (04-0014)
•Included within the RGB Kit (FGxxxx-xxRGB) is the
following:
- Modero VG Touch Panel (NXD/NXT-1200/1500/1700VG)
- NXA-AVB/RGB Breakout Box (FG2254-11)
- NXA-RGB internal RGB/VGA Interface Card (FG2260)
- NXA-MTC/RGB Modero 10’ foot Table Top Cable (with
RGB connector) (CA2250-70)
- TP4-RGBCBL BNC to RGB adapter cable (FG2275-30)
•Included within the Video Kit (FGxxxx-xV) is the following:
- Modero VG Touch Panel (NXD/NXT-1200/1500/1700VG)
- Modero 10’ foot Table Top Cable (CA2250-50)
- NXA-AVB/ETHERNET Breakout Box (FG2254-10)
OPTIONAL ACCESSORIES
•CB-TP12 Conduit/Wallbox (FG031-10)
•CC-USB (Type A) to Mini-B 5-Wire programming cable
(FG10-5965)
•Kensington Lock Kit (FG2259-10)
(optional only with NXT models)
•MB-TP12 Universal VESA Mounting Box for NXD panels
(FG031-50):
•NXA-AVB/ETHERNET Breakout Box (FG2254-10)
•NXA-AVB/RGB Breakout Box (FG2254-11)
•NXA-BASE/B (FG2255)
•NXA-MTC/RGB Modero 10’ foot Table Top Cable
(with RGB connector) (CA2250-70). This cable is not
wall-rated for NXD models.
•RGB upgrade kit for Composite Video touch panels
(FG2255-11):
- NXA-AVB/RGB Breakout Box (FG2254-11)
- NXA-MTC/RGB Modero 10’ foot Table Top Cable (with
RGB connector) (CA2250-70)
- NXA-RGB internal RGB/VGA Interface Card (FG2260)
- TP4-RGBCBL BNC to RGB adapter cable (FG2275-30)
- NXT Table Top replacement I/O plate (with RGB
connector opening) (62-2250-59)
- NXD WallMount replacement adhesive overlay for existing
I/O plate (53-2250-03)
Note: The NXT replacement I/O plate is a single piece which
is meant to be swapped-out with the pre-existing plate
shipped with Composite Video panels. On NXD panels, the
RGB connector opening is pre-drilled into the I/O plate but
can only be accessed by replacing the adhesive cover and
maintaining the existing overlay. When upgrading NXD
panels with this kit, don’t replace the NXD I/O plate, only the
adhesive cover.
•NXA-PCI80211G Wireless Card (FG2255-04)
•NXA-RK12 Rackmount kit for 12” Wall Mount panels
(FG2904-50)
•NXT-BP (FG2250-10)
•NXT-CHG (FG2250-50)
•PSN6.5 Power Supply (12 VDC) (FG423-41)
•TP4-RGBCBL BNC to RGB adapter cable (FG2275-30)
•Upgrade Compact Flash (factory programmed with
firmware):
- NXA-CFTPV256M - 256 MB compact flash card
(FG2116-43)
- NXA-CFTPV512M - 512 MB compact flash card
(FG2116-44)
- NXA-CFTPV1G - 1 GB compact flash card (FG2116-45)

NXT-1200VG/NXD-1200VG DATA SHEET
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
ETHERNETAUDIO/VIDEO
A
PWR
L
12VDC
ETHERNETAUDIO / VIDEORGB
AL
PWR
12VDC
PROGRAM
PROGRAM
PWR
AUDIO / VIDEO ETHERNETRGB
ETHERNETAUDIO/VIDEO
A
PWR
L
12VDC
AL
12VDC
PROGRAM
PROGRAM
9 15/16”
(25.2 cm)
8 5/8”
(21.9 cm)
11 1/2”
(29.1 cm)
1 5/8”
(4.2 cm)
3 1/4”
(8.3 cm)
1/2”
(1.2 cm)
12 5/16”
(31.3 cm)
12 9/16”
(32 cm)
11 3/4”
(29.7 cm)
12 1 /2”
(31.8 m)
12 11/16”
(32.2 cm)
10 15/16”
(27.7 cm)
12 3/8”
(31.4 cm)
10 15/16”
(27.7 cm)
6 3/4”
(17.2 cm)
11 1/4”
(28.5 cm)
5/8”
(1.5 cm)
3 1/4”
(8.3 cm)
NXT-1200VG
(Front View)
NXT-1200VG
(Right View)
NXT-1200VG
(Right View)
NXD-1200VG
(Front View)
NXD-1200VG
(Right & Left Views)
NXD-1200VG
(Top View)
Interconnect Options
Connector Plates
NXT-1200VG/RGB
NXT-1200VG
NXT-1200V
Interconnect Options
Connector Overlays
NXD-1200VG/RGB
NXD-1200VG
NXD-1200V
