Anden A130 User manual

DEHUMIDIFER CONTROL
ON/OFF BUTTON
USED TO TURN
DEHUMIDIFIER ON
AND OFF
UP/DOWN
BUTTONS USED TO
CHANGE HUMIDITY
SETTING
MODE BUTTON USED
FOR OPTIONAL
VENTILATION FEATURE
INLET FILTER ACCESS DOOR DRAIN POWER
SWITCH
OUTLET
SAFETY INSTRUCTIONS
WARNING
1. 120 Volts may cause serious injury from electric shock. Disconnect electrical power before starting installation or servicing. Leave power
disconnected until installation/service is completed.
2. Sharp edges may cause serious injury from cuts. Use care when cutting plenum openings and handling duct work.
3. Dropping may cause personal injury or equipment damage. Handle with care and follow installation instructions.
CAUTION
1. Read all instructions before beginning installation.
2. Improper installation may cause property damage or injury. Installation, service, and maintenance must be performed by a qualified service
technician.
3. Do not use in pool applications. Pool chemicals can damage the dehumidifier.
4. Do not use solvents or cleaners on or near the circuit board. Chemicals can damage circuit board components.
5. Wait 24 hours before running the unit if it was not shipped or stored in the upright position
6. Do not use dehumidification to prevent window condensation in the winter. To address window condensation, use ventilation to lower
indoor humidity in the winter.
READ AND SAVE THESE INSTRUCTIONS
Model A130 Dehumidifier
Installation and Operating Instructions
1

TABLE OF CONTENTS
SPECIFICATIONS
TABLE 1 – SPECIFICATIONS Model A130
Unit Weight 113 lbs
Capacity (AHAM DH-1-2008 80°F, 60% RH) 130 pints per day @ 310 CFM
Power (115 VAC, Single Phase, 60Hz) 8.3 Amps operating current
Dehumidifier Inlet Air Conditions Dehumidification: 50°F – 104°F, 40°F dew point minimum
Ventilation: 40°F – 140°F, 0% RH – 99% RH (non-condensing)
Filter MERV 11
Airflow External Static Pressure ("w.c.) Airflow (CFM)
0.0 310
0.2 270
0.4 225
0.6 175
0.7" w.c. is maximum design external static pressure.
SAFETY INSTRUCTIONS ...........................................1
SPECIFICATIONS .................................................2
SET UP DEHUMIDIFIER FOR INSTALLATION ........................3
Duct Collars....................................................3
Control Location................................................4
LOCATION CONSIDERATIONS .....................................4
DRAIN INSTALLATION ............................................5
Leveling .......................................................5
Condensate Pan, Condensate Pump and Float Switch ..............5
MODEL A77 – REMOTE OR EXTERNAL CONTROL AND WIRING......6
Alternate External Controls ......................................6
Wiring to Disable the Dehumidifier when
the Air Conditioning is Running..................................6
SYSTEM SET UP & CHECKOUT .....................................7
Installer Test Mode .............................................8
START UP AND SEQUENCE OF OPERATION ........................9
Using the Dehumidifier Control ..................................9
Using Model A77 Remote Control ................................9
TROUBLESHOOTING ............................................10
Table 2 – Diagnostic Codes .....................................10
Table 3 – Troubleshooting Guide .................................11
LIMITED WARRANTY .............................................11
SERVICE PARTS ................................................. 12
2

SET UP DEHUMIDIFIER FOR INSTALLATION
IMPORTANT: Cut the strap securing the compressor shipping support
bracket and remove the strap and shipping bracket. See FIGURE 1.
PACKAGING CONTENT
1. Dehumidifier
2. Inlet/Outlet Collars
3. Installation and Operating Insttructions
4. Parts Bag
a. #10 x 1/2 Screws (9)
b. Threaded Barbed Fitting for Drain Connections
c. Torx Bit
5. 10 Foot, 3/4" Drain Tube
DUCT COLLARS
If suspending the unit over the canopy but not ducting the unit, no
duct collars are needed (see FIGURE 2). If ductwork will be installed to
a suspended unit, attach the inlet and outlet duct collars as shown in
FIGURE 3; the outlet cover does not need to be moved. If placing the
unit on the floor, remove the outlet cover and install the outlet collar to
the top of the unit, and relocate the cover to the end of the unit (see
FIGURE 4).
CLIP OFF
PLASTIC
STRAP
REMOVE SCREWS (2)
DISCARD SHIPPING BRACKET
REINSTALL SCREWS (2)
OUTLET COVER
OUTLET COVER OUTLET DUCT
COLLAR WITH
BACK DRAFT
DAMPER
INLET
DUCT
COLLAR
MOVE OUTLET
COVER AND
INSTALL DUCT
COLLAR TO
TOP DISCHARGE
LOCATION
90-2013
90-2016
90-2014 90-2014
FIGURE 1 – REMOVE SHIPPING BRACKET
FIGURE 2 – HANGING INSTALL – NO DUCTING
FIGURE 3 – HANGING INSTALL WITH DUCTING FIGURE 4 – FLOOR MOUNT INSTALL
3

LOCATION CONSIDERATIONS
• Allow sufficient clearance for filter removal and to
prevent airflow obstruction
• Electrical service access will require the removal
of the side panel shown. Allow sufficient space for
service on this side of the unit.
• When suspending the unit, a condensate pan
with float switch is recommended to prevent any
leaks that may occur due to unforeseen drain line
obstructions.
CONTROL LOCATION
For floor mount installation, leave the control
mounted to the top of the unit. For suspended
installations, it will be easier to see if the control is
relocated to the front of the unit.
To move the control:
1. Remove the front control panel cover.
2. Remove the filter access door and filter.
3. Detach the on-board control by removing the four
(4) screws around the control. NOTE: Use one hand
to support the bottom of the on-board control
when removing.
4. Keep the control in the unit and relocate to the front
access hole.
5. Secure the control with the same four screws used
to attach the control to the top of the unit.
6. Secure the control panel cover to the top of the unit.
CONTROL
PANEL COVER
CONTROL
CONTROL
CONTROL
PANEL COVER
FILTER ACCESS DOOR
TOP VIEW
FILTER MINIMUM
CLEARANCE
FOR FILTER
(EITHER SIDE)
20"
6" MINIMUM
CLEARANCE
FOR PROPER
AIR FLOW
ELECTRICAL SERVICE ACCESS THIS SIDE
6 FT. POWER CORD
90-2017
90-2020
FIGURE 5 – CONTROL LOCATION
FIGURE 6 – FILTER ACCESS CLEARANCE
4

DRAIN INSTALLATION
The drain outlet on the dehumidifier can be hard piped using a 3/4" PVC Slip x 3/4" MNPT fitting and 3/4" nominal drain tubing or the provided 3/4"
MNPT x 3/4" hose barb fitting and 3/4" clear PVC tubing can be used to drain the dehumidifier. Always maintain a constant downward slope from the
dehumidifier to the drain and do not allow soft tubing to curl up which may result in air lock. NOTE: PTFE thread seal tape is recommended for the
threaded connection and hand tighten only. If hard pipe is used, PVC primer and cement is recommended for the slip fit connection.
LEVELING
The feet can be adjusted to level the unit, and if
required, to accommodate drain fittings and a
secondary condensate pan. Leveling is required to
ensure proper drainage from the dehumidifier. See
FIGURE 7.
CONDENSATE PAN, CONDENSATE PUMP AND FLOAT SWITCH
A condensate pan is recommended when suspending
the dehumidifier over the canopy. Adhere to local
codes regarding draining of the condensate pan. If a
condensate pump is needed, install it in the condensate
pan as well.
Install a condensate overflow safety switch (i.e. float
switch) in the condensate pan, remove the factory
installed jumper wire between the Float Switch
terminals on the control and wire the float switch to the
dehumidifier as shown in FIGURE 8. Overflow safety
switches on condensate pumps can be wired to the
Float Switch terminals in a similar fashion.
0.38" MIN
2.00" MAX
3/4" FNPT DRAIN
FLOAT
Switch
DH DH
NORMALLY CLOSED
FLOAT SWITCH
90-2021
90-1857
FIGURE 7 – LEVEL THE UNIT
FIGURE 8 – FLOAT SWITCH WIRING
5

MODEL A77 – REMOTE OR EXTERNAL CONTROL AND WIRING
NOTE: Use 18-22 AWG wire for control wiring.
The internal dehumidifier control can be used to control humidity, or a
remote Model A77 Control or other external control (see below) can be
wired to the dehumidifier.
Without an external control, the dehumidifier will turn on its blower for
three minutes every 15, 30 or 45 minutes depending on how often the
unit is set to sample the air. The dehumidifier can also be set to sample
the air continuously (see AIR SAMPLING on page 8). The blower is
turned on to get a representative reading of the room relative humidity.
A shorter sampling period reduces the duration of any humidity spikes
that might occur when neither the air conditioning nor the dehumidifier
are running. To reduce energy consumption the sampling time can be
set to a longer period.
Installing an A77 or other control eliminates the need to run the
dehumidifier blower for sampling as the control is constantly measuring
the humidity close to the canopy. When the humidity level rises above
the setting, the dehumidifier is turned on.
To install the Model A77 control:
1. Turn off power to the dehumidifier using the ON/OFF switch.
2. Run a 4-wire thermostat cable (use 18–22 AWG wire) from the Model A77 to the control of the dehumidifier.
3. Trim about 1/4" of insulation from the end of the wires on each end. Insert the wire into the terminals as shown in FIGURE 9 and tighten to secure.
4. Restore dehumidifier power. There is a delay of three minutes after restoring power before the dehumidifier will respond to the control.
5. Go to REMOTE CONTROL on page 7 to configure the dehumidifier control to respond to an A77 control.
The Model A77 will measure the relative humidity and turn the dehumidifier on and off to control the humidity level to the desired setting. The
humidity setting can be adjusted from the control while the display allows easy access and monitoring of the humidity level in the space. It is
recommended that the Model A77 be mounted at/near canopy height.
Press the ON button on the Model A77 to turn on the control. The UP/DOWN arrow buttons are used to set the desired humidity setting. At all other
times, the Model A77 will display the measured humidity level. Reference the Model A77 Installation & Operating Instructions for set-up.
ALTERNATE EXTERNAL CONTROLS
A Model 8840 thermostat can be used to control the HVAC equipment, and for dehumidifier control in place of the Model A77. The Model 8840
thermostat has Wi-Fi capability so the conditions in the room can be monitored at any time from any location. Additionally, up to four remote sensors
can be mounted near the canopy and connected to a single thermostat. The four humidity measurements can be averaged and the thermostat will
turn on the dehumidifier based on the averaged value.
Reference the 8840 Installation Instructions and Owner’s Manual for wiring, set-up and operating details.
+ - A B ODT
SensorRemote
Gh Rf Cf Gs YW
HVAC EQUIP.
DH
DH
R/+
C/-
B
A
MODEL A77 CONTROL
90-1860
FIGURE 9 – MODEL A77 REMOTE CONTROL WIRING
6

SYSTEM SET-UP & CHECKOUT
Skip set up and proceed to INSTALLER TEST MODE on page 8 unless:
• A Model A77 or other external control is to be installed
• changing the air sampling rate
1. Make sure the wire access cover has been snapped back onto the
on-board control.
2. Plug unit in and turn power switch to ON.
3. The on-board control screen should display OFF.
90-1854
NOTE: If the display backlight is not on, the first button press (any
button) will only turn on the backlight. Press the button a second time
to achieve function.
4. Hold the MODE button on the on-board control for 3 seconds to
enter the Installer Set-up Menu.
5. Navigate through the following screens to set up the dehumidifier
for the installed application.
Use the UP or DOWN buttons to select items and use MODE to
switch to the next set-up option. To exit installer set-up, all options
must be scrolled through using the MODE button.
6. After the installer set up options have been completed, DONE will
blink for 3 seconds and the control will return to the OFF screen.
90-1854
90-1854
REMOTE CONTROL
90-1854
If not installing an A77, leave
DISABLED and press MODE to go
to the next screen..
90-1854
If installing an A77, use the UP or
DOWN button to select ENABLED,
then press MODE to go to the next
screen.
VENTILATION
The ventilation feature can be used for air cycling if desired. The air
cycling time can be set from 0 to 60 minutes. The dehumidifier will turn
on the dehumidifier fan to cycle air for the set time, every hour.
90-1854
If not using the dehumidifier to
cycle air, leave DISABLED and
press MODE to go to the next
screen.
90-1854
If using the dehumidifier for air
cycling, use the UP or DOWN
button to select ENABLED, then
press MODE to go to the next
screen.
90-1854
Press MODE at the VENT TIMED
screen to set the air cycling time.
90-1854
Press the UP or DOWN button to
adjust the air cycling time per hour
from 0 to 60 minutes. After
selecting time, press MODE to go
to the next screen.
7

EXTERNAL CONTROL
90-1854
If using the dehumidifier on-board
control, leave DISABLED and press
MODE to go to the next screen.
90-1854
If using a Model 8800 series
thermostat or alternate control as
an external control, use the UP or
DOWN button to select ENABLED,
then press MODE to go to the next
screen.
AIR SAMPLING
90-1854
Use the UP or DOWN button to
adjust how frequently the
dehumidifier samples the air to
determine whether or not to
dehumidify. Fewer minutes means
the dehumidifier will sample more
frequently to minimize humidity swings, but increases cost to operate
due to more frequent fan operation. Press MODE when done to move to
the next screen.
RH OFFSET
90-1854
An offset can be applied to the
on-board humidity reading to
avoid discrepancies with other
humidity measuring devices in the
home. Use the UP or DOWN
button to select an offset from -5%
to 5%. Press MODE to exit the
installer set-up screens.
INSTALLER TEST MODE
If everything is properly wired, the dehumidifier and all of the
wired components will turn on and off during Installer Test
Mode to demonstrate that all are properly operating. Installer
Test Mode lasts for four (4) minutes. If the ON/OFF button is
pressed during test mode, the dehumidifier will exit Installer
Test Mode and return to the OFF screen.
DEHUMIDIFICATION ONLY
90-1854
If the dehumidifier is not
already OFF, press the ON/
OFF button to turn it off.
90-1854
Press and hold the ON/
OFF button and MODE
buttons for 3 seconds. The
measured humidity, AIR
SAMPLING and TEST will
show on the display.
90-1854
After three (3) minutes the
dehumidifier compressor
will turn on and
DEHUMIDIFYING will
replace AIR SAMPLING on
the control screen.
90-1854
After one minute of
compressor operation, all
outputs will turn off and
DONE will blink for 3
seconds and then return to
the OFF screen.
90-1854
8

START UP AND SEQUENCE OF OPERATION
USING THE DEHUMIDIFIER CONTROL
1. Press the ON/OFF button to turn the dehumidifier control ON. The display will show the current setting, and the dehumidifier blower will turn on
to start sampling the air.
The setting will be replaced by the measured humidity and “AIR SAMPLING” will show on the display.
2. Use the UP or DOWN button to adjust the humidity setting as desired.
3. After three (3) minutes of sampling, the measured humidity will be compared to the setting:
a. If the humidity is above the setting, the dehumidifier compressor turns on and “AIR SAMPLING” will be replaced by “DEHUMIDIFYING”. The
compressor remains on until the measured humidity falls 3% RH below the setting.
b. If the measured humidity is below the setting, the blowers turn off and the display returns to showing the RH setting.
4. The dehumidifier will sample again after the number of minutes selected during the Air Sampling portion of the System Set Up (see page 8), or
any time the humidity setting is lowered.
USING THE MODEL A77 REMOTE CONTROL
1. Press the ON/OFF button to turn the dehumidifier control ON. “REMOTE” will show on the display to indicate that an external control is wired to
the dehumidifier.
2. At the Model A77, press the ON button; the Model A77 will display the measured RH.
3. Use the UP or DOWN button on the Model A77 to adjust the humidity setting as desired.
4. If the RH measured by the Model A77 rises above the setting, the dehumidifier will turn on. “DEHUMIDIFYING” will appear on the dehumidifier
control display to show that the Model A77 is calling for dehumidification. The dehumidifier will turn off when the RH measured by the Model A77
drops 3% RH below the setting.
9

TROUBLESHOOTING
Technical Support is available Monday through Friday,
7:00 a.m. to 5:00 p.m. CST, at [phone]. Use the
guides on the following pages to identify and correct system
faults. Contact Technical Support before replacing the unit
or any components and for additional troubleshooting.
TABLE 2 – DIAGNOSTIC CODES
Diagnostic
Code Failure Mode Action Reset
E1 Internal Humidity or
Temperature Sensor
Open or Shorted
1. Check the connection between the sensor board and control board.
2. If connection okay, replace sensor board, Part No. 5460.
Cycle Power
E2 High Refrigeration
Pressure
1. Verify that the fan works, the backflow damper swings freely and there is no blocked or restricted ductwork.
2. If the fault persists, call Technical Support.
Cycle Power
E3 Model A77
Remote Control
Communication Loss
1. Check connections between Model A77 and dehumidifier control board. Terminals should be fully
inserted and secured in the control board and Model A77 control terminals.
2. If connections are correct and secure, turn off the dehumidifier and remove the Model A77. Use a
short section of 4-wire cable to reconnect the Model A77 to the control board. Turn the dehumidifier
back on and increase the dryness level setting on the Model A77. If the dehumidifier turns on, the
problem is with the wiring between the dehumidifier and control.
3. If the dehumidifier does not turn on, call Technical Support.
Self-Correcting
E4 Insufficient Capacity 1. Check the frost sensor connection at the power board. Terminal should be fully seated on the power
board pins.
2. Remove the side access panel and verify that the sensor is secured to the suction line.
3. If the sensor is connected and secured to the refrigeration line proceed to the next step.
4. Reset the fault by cycling power to the dehumidifier.
5. Turn the humidity setting down (below room/home humidity level) to make a dehumidification call.
6. Allow the fan and compressor to run for approximately 10-15 minutes and then enter diagnostic
test mode by simultaneously pressing the UP ARROW and MODE buttons for 3 seconds. The LCD
will display the temperature measured by the internal sensor while also displaying AIR SAMPLING
and ON, the humidity measured by the internal sensor while also displaying %RH and ON, and the
frost sensor temperature while also displaying ON. Scroll through these values and by using the UP/
DOWN arrow buttons.
7. Record values and call Technical Support.
Cycle Power
E5 High Temperature
Thermistor Failure
1. Check the high temperature sensor connection at the power board. Terminal should be fully seated
on the power board pins.
2. Remove the side access panel and verify the sensor is not damaged and connected to the
refrigeration line coming from the compressor.
3. If the sensor is connected and secured to the refrigeration line, it may need to be replaced with Part
No. 5456 – contact Technical Support to confirm.
Cycle Power
E6 Low Temperature
Thermistor Failure
1. Check the low temperature sensor connection at the power board.
2. Remove the side access panel and verify the sensor is not damaged and connected to the suction line.
3. If the sensor is connected and secured to the refrigeration line, it may need to be replaced with Part
No. 5455 – contact Technical Support to confirm.
Cycle Power
E7 Float Switch Open 1. Empty the condensate pan.
2. Check the float switch connection at the control board.
3. If not using a float switch, verify jumper is between float switch terminals on dehumidifier control board.
4. If the problem persists, replace the float switch.
Self-Correcting
E8 Inlet Air Temperature
Out of 50°F – 104°F
range or dew point
below 40°F
1. Verify all ductwork is properly sealed.
2. If no signs of leak points, contact Technical Support.
Self-Correcting
DIAGNOSTIC CODES
When an error occurs, the Diagnostic
Code along with SERVICE REQUIRED
will be displayed on the control screen.
90-1854
10

TABLE 3 – TROUBLESHOOTING GUIDE
Symptom Possible Reason Troubleshooting Procedure
Dehumidifier does not
turn on/run.
No power to unit. • Check that the dehumidifier is plugged in.
• Check that the power switch is turned ON.
• Check that the control is turned ON.
• Check that the circuit breaker has not tripped.
Dehumidifier blower is
running but with little or
no airflow.
Pressure drop across
dehumidifier is too high.
• Check dehumidifier air filter and replace if necessary.
• Check for blocked duct work and clear.
Dehumidifier blower is
running but compressor
is not.
Float switch open. • If float switch installed, check connections at control board and empty condensate pan.
• If no float switch installed check that the jumper is installed at the float switch terminals on the control
board.
Coil frosting – defrost. • Lack of or reduced airflow. Check dehumidifier air filter and replace if necessary.
• Check for blocked duct work.
• Inlet air conditions below 60°F. Increase the humidity setting.
Inlet air temperature is
outside of the 50°F –
104°F range or the dew
point is below 40°F and
there is a demand for
dehumidification.
• Verify all ductwork is properly sealed.
Dehumidifier is not
draining properly.
Drain line blocked or unit
not level.
• Verify that the unit is level.
• Check the drain line blockages and for a continuous downward slope.
Dehumidifier is
producing hot air.
Normal function. • Air is reheated across the condenser coil, resulting in a temperature rise between inlet and outlet, this is
normal.
LIMITED WARRANTY
Your Research Products Corporation Anden™ Dehumidifier is expressly warranted for five (5) years from date of installation to be free from defects in materials or workmanship.
Research Products Corporation’s exclusive obligation under this warranty shall be to supply, without charge, a replacement for any component which is found to be defective within such
five (5) year period and which is returned not later than thirty (30) days after said five (5) year period by you to either your original supplier or to Research Products Corporation, Madison,
Wisconsin 53701, together with the model number and installation date of the dehumidifier.
THIS WARRANTY SHALL NOT OBLIGATE RESEARCH PRODUCTS CORPORATION FOR ANY LABOR COSTS AND SHALL NOT APPLY TO DEFECTS IN WORKMANSHIP OR MATERIALS
FURNISHED BY YOUR INSTALLER AS CONTRASTED TO DEFECTS IN THE DEHUMIDIFIER ITSELF.
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL BE LIMITED IN DURATION TO THE AFORESAID FIVE YEAR PERIOD. RESEARCH PRODUCTS
CORPORATION’S LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, OTHER THAN DAMAGES FOR PERSONAL INJURIES, RESULTING FROM ANY BREACH OF THE AFORESAID
IMPLIED WARRANTIES OR THE ABOVE LIMITED WARRANTY IS EXPRESSLY EXCLUDED. THIS LIMITED WARRANTY IS VOID IF DEFECT(S) RESULT FROM FAILURE TO HAVE THIS UNIT
INSTALLED BY A QUALIFIED HEATING AND AIR CONDITIONING CONTRACTOR. IF THE LIMITED WARRANTY IS VOID DUE TO FAILURE TO USE A QUALIFIED CONTRACTOR, ALL DISCLAIMERS
OF IMPLIED WARRANTIES SHALL BE EFFECTIVE UPON INSTALLATION.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages so the above exclusion or limitations may
not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
WARRANTY REGISTRATION
Visit us online at anden.com to register your Anden product. If you do not have online access, please mail a postcard with your name, address, phone number, email address, product
purchased, model number, date of purchase, and dealer name and address to: Research Products Corporation, P.O. Box 1467, Madison, WI 53701.
Your warranty registration information will not be sold or shared outside of this company.
11

anden.com
P.O. Box 1467
Madison, WI 53701-1467
800.972.3710 F: 608.257.4357
Printed in USA
©2019 Anden – A Quality brand from Research Products Corporation
10013580 B2208340B 2.19
SERVICE PARTS
90-2031
17
3
9
19
6
7
18
11
14
13
2
16
15
5
10
1
8
12
4
No. Part Description Part No.
1Filter, 14" x 19" x 1" 5701
2Internal Control Board, Deh 5444
3User Interface Assembly, Deh 5738
4Hole Cover, UI Ctrl, Deh 5447
5Door, Filter Access, Deh 5571
6Outlet Duct Panel, Deh 5449
7Backflow Damper, 10", Deh 5450
8Inlet Duct Panel, Deh 5451
9Cover, Outlet, Deh 5452
10 Fan, 130pt Deh, with 10MFD Capacitor 5572
No. Part Description Part No.
11 Wire Harness, Power, Deh 5454
12 Sensor, Low Temperature, Deh 5455
13 Sensor, High Temperature, Deh 5456
14 Leveling Foot, Deh 5457
15 Capacitor, 50MFD, 370VAC 5594
16 Capacitor, 10MFD, 250VAC 5573
17 RH Sensor, Deh 5460
18 Drain Tube + Fitting 5665
19 Compressor Overload Switch 5574
12
