ELECTRICAL SERVICE PANEL
INLET SIDE
18" RECOMMENDED
18" MINIMUM
4X DOUBLE NUT BOTTOM WITH FLAT WASHER,
SINGLE NUT ON TOP
4X VIBRATION ISOLATORS
(OPTIONAL)
USE 3/8" OR 1/2" THREADED ROD
Model A710V1/V3 Dehumidifier
Quick Start Guide
1A. PLACEMENT
AVOID
HVAC SUPPLY
HVAC RETURN
AIRFLOW
DIRECTION
INLET OUTLET INLET OUTLET
90-2554
90-2555
90-2556
1B. CLEARANCES
2. HANGING
3. NUT & WASHER
4. LEVEL
90-2530
90-2531
90-2531
90-2557
The Quick Start Guide is to be used as reference only. Installation is to be in accordance with Installation and Operating Instructions provided with the dehumidifier.
18"
MIN.
OUTLET OUTLET
18"
MIN.

3/4" MNPT X 3/4" FEMALE PIPE
(INCLUDED)
P-TRAP
(INCLUDED)
3/4" MNPT X 3/4" FEMALE PIPE
(INCLUDED)
P-TRAP
(INCLUDED)
3/4" PIPE X 3/4" PIPE COUPLING
(NOT INCLUDED)
PVC HARD PIPE
(NOT INCLUDED)
3/4" PIPE TEE
(INCLUDED)
3/4" FEMALE PIPE X 3/4" FNPT
(INCLUDED)
3/4" MNPT X 3/4" BARB (INCLUDED)
3/4" FLEXIBLE TUBE
(NOT INCLUDED)
HIGHER
THAN
FILTER
FRAME
OPTIONAL
VACUUM
BREAK
+ - A B ODT
Sensor
Remote
Gh Rf Cf Gs YW
HVAC EQUIP.
DH
DH
R/+
C/-
B
A
MODEL A77 CONTROL
90-2534
90-2481
90-2553
5. DRAIN CONNECTION
6. WIRING
NOTES:
• Mount control at canopy height.
• Do not mount in direct path of
dehumidifier outlet air.
• Shield control from lights.
anden.com
P.O. Box 1467
Madison, WI 53701-1467
800.972.3710 F: 608.257.4357
Printed in USA
©2020 Anden – A Quality brand from Research Products Corporation
10015129 B2209017A 10.20
8. CODES (LOCATED ON BACK OF WIRE ACCESS COVER)
See the Installation Instructions for troubleshooting error codes. For additional assistance, Technical Support is
available Monday through Friday, 7:00 a.m. to 5:00 p.m. CST, at [phone].
Contact Technical Support before replacing the unit or components and for additional troubleshooting.
ERROR CODE FAILURE MODE
E1 Internal %RH / Temperature Sensor Failure
E3 Model A77 Remote Control Communication Loss
E4 Insufficient Capacity
E5 High Temperature Thermistor Failure
E6 Low Temperature Thermistor Failure
E7 Float Switch Open
E8 Inlet Air Temperature Out of Range
E9 Fan or Compressor Fault
IMPORTANT NOTES:
• Do not double trap.
• Prime drain trap when installation is complete.
• Drain line must maintain a constant downward slope.
• Support the drain lines to prevent dips or sags.
• Do not submerge the end of the drain line in water to avoid microbial growth.
• Vacuum break is recommended when using a condensate pump or when
connecting multiple drain lines.
A710V1
L6-30P
A710V3
L7-30P
7. SET-UP & SEQUENCE OF OPERATION WITH MODEL A77
(REFER TO THE INSTALLATION MANUAL FOR SET UP AND WIRING OF ANY OTHER CONTROL)
1. Plug unit in and turn power switch to ON.
2. The on-board control screen should display OFF.
90-1854
NOTE: The first button press will only turn on the
backlight.
3. Hold the MODE button on the on-board control
for 3 seconds to enter the Installer Set-up Menu.
90-1854
SEQUENCE OF OPERATION
1. At the Model A77, press the ON button; the Model A77 will display the measured RH and ON.
2. Use the UP or DOWN button on the Model A77 to adjust the humidity setting as desired.
3. If the RH measured by the Model A77 rises above the setting, the dehumidifier will turn on.
“DEHUMIDIFYING” will appear on the dehumidifier control display and ON will blink on the Model A77 to
show that there is a call for dehumidification. The dehumidifier will turn off when the RH measured by the
Model A77 drops 3% RH below the setting.
NOTE: When using the Model A77, there is an initial 3 minute delay at power-up before the dehumidifier
compressor will turn on.
4. Press the UP or DOWN button to change
to ENABLED.
90-1854
5. Press MODE repeatedly until DONE shows
on screen.
90-1854
6. Press ON/OFF to turn ON.
90-1854
